Schmalz SCPi Technical specifications

Ejector SCPi
Maintenance Instructions
WWW.SCHMALZ.COM
EN · 30.30.01.02074 · 00 · 06/19

Important information
2 / 9
EN · 30.30.01.02074 · 00 · 06/19
1 Important information
1.1 Note on using this document
In these maintenance instructions, J. Schmalz GmbH is generally referred to as Schmalz.
These maintenance instructions contain important notes and information about the different operat-
ing phases of the product:
•Transport, storage, start of operations and decommissioning
•Safe operation, required maintenance, rectification of any faults
The maintenance instructions describe the product at the time of delivery by Schmalz.
1.2 The technical documentation is part of the product
1. For problem-free and safe operation, follow the instructions in the documents.
2. Keep the technical documentation in close proximity to the product. The documentation must
be accessible to personnel at all times.
3. Pass on the technical documentation to subsequent users.
Failure to follow the instructions in these maintenance instructions can lead to life-threatening
injuries!
Schmalz is not liable for damage or malfunctions that result from failure to heed these instruc-
tions.
If you still have questions after reading the technical documentation, contact Schmalz service at:
www.schmalz.com/services
Published by
© J. Schmalz GmbH, 06/19
This document is protected by copyright. J. Schmalz GmbH retains the rights established thereby.
Reproduction of the contents, in full or in part, is only permitted within the limits of the legal provi-
sions of copyright law. Any modifications to or abridgments of the document are prohibited without
explicit written agreement from J. Schmalz GmbH.
J. Schmalz GmbH · Johannes-Schmalz-Str. 1 · 72293 Glatten, Germany · T: [phone]
[e-mail]

Important information
EN · 30.30.01.02074 · 00 · 06/19
3 / 9
1.3 Warnings in this document
Warnings warn against hazards that may occur when handling the product. This document contains
two levels of danger that you can recognize by the signal word.
Signal word
Meaning
WARNING
Indicates a medium-risk hazard which, if not avoided, could result in
death or serious injury.
NOTE
Indicates a danger that leads to property damage.
1.4 Symbols
This sign indicates useful and important information.
This symbol represents a prerequisite that must be met prior to an operational step.
This sign represents an action to be performed.
This sign represents the result of an action.
Actions that consist of more than one step are numbered:
1. First action to be performed.
2. Second action to be performed.
1.5 Warranty
IMPORTANT!
A warranty claim can only be accepted by Schmalz if the ejector has been installed and used in ac-
cordance with the corresponding operating instructions. In the case of inappropriate handling or use
of force, any warranty and liability claims shall be void.
Damage and defects resulting from inadequate maintenance and cleaning, improper use, repair or
attempted repair by unauthorized persons, as well as damage and defects resulting from alterations
or modifications to the ejector and from replaced parts or materials that do not conform to the origi-
nal specification are excluded from the warranty.

Safety
4 / 9
EN · 30.30.01.02074 · 00 · 06/19
2 Safety
Maintenance work may only be carried out by qualified personnel.
WARNING
Risk of injury due to incorrect maintenance or troubleshooting
Check the proper functioning of the product, especially the safety features, after
every
maintenance or troubleshooting operation.
NOTE
Improper maintenance
Damage to the ejector!
Switch off the supply voltage before any maintenance.
Ensure that it cannot be switched back on.
The ejector must always be operated with a silencer.

Replacing the ejector/silencer components
EN · 30.30.01.02074 · 00 · 06/19
5 / 9
3 Ejector components
1
Silencer
2
Type plate 1
3
4x mounting holes
4
Position of pneumatic controller
5
Vacuum switch with control and display el-
ement
6
Electrical connection, M12, 5-pin
7
Compressed air connection 1A (blow off)
8
Compressed air connection 1 (suction)
9
Bypass for exhaust air
10
Type plate 2
11
Vacuum connection
4 Replacing the silencer
This manual provides you with all the necessary information to replace a silencer on an SCPi.
4.1 Accessories, wearing parts set
Article/part
number
Designation
Description
10.02.02.03381
SD 111x21x45 SMPi/SCPi
Silencer (cuboid) SD 111x21x45 SMPi/SCPi
6
4
5
8
1
2
7
10
9
11
3

Removing the silencer
6 / 9
EN · 30.30.01.02074 · 00 · 06/19
4.2 Replacing the silencer
The ejector is disconnected from the compressed air supply and the power supply.
The vacuum and compressed air system is subjected to atmospheric pressure.
1. Loosen the fastening
screws
2. Pull the cover and silencer
downward to remove them
2.
1.
3 mm

Mounting the silencer
EN · 30.30.01.02074 · 00 · 06/19
7 / 9
4.3 Mounting the silencer
1. Attach the new silencer el-
ement to the basic body of
the ejector
2. Tighten the fastening screw
(0.4 Nm tightening torque)
3.
1.
2.
MA= 0.4 Nm

Connecting the SCPi to the compressed air and power supply
8 / 9
EN · 30.30.01.02074 · 00 · 06/19
4.4 Connecting the SCPi to the compressed air and power supply
WARNING
The silencer is not secured with the fastening screw.
When compressed air is supplied, individual components are accelerated and fly around.
There is a risk of injury.
Install and tighten the fastening screw with a tightening torque of 0.4 Nm before
switching the ejector on again.
1. Secure the SCPi at the place of use.
2. Connect the compressed air and vacuum.
3. Mount the electrical connections.
4. Switch on the SCPi via the control unit.
4.5 Checking for correct installation and function
Check for proper installation and function before starting the handling
process.
