Schmid Watson User manual

Watson Ethernet
Operating Manual
Document Identification
Watson-Ethernet-Manual.doc
Document Version
3.3-01
Document Revision
2010-01-20
Distribution
Customer

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
ii
Revision: 2010-01-20
Revision History
Revision
Date
Author
Remarks
3.3-01
100120
MLr
Update for tabletop FW 5.1
3.2-01
091119
MLr
Update for plug-in FW 3.1
3.1-01
090226
MLr
Replaced SZ.846 with SZ.847 tabletops
3.0-01
080208
RBt
Update for plug-in FW 3.0
2.2-02
070814
RBt
Clarifications on DEFAULT and BITRATE commands
2.2-01
070727
RBt
Update for plug-in FW 2.4
2.1-01
070228
RBt
Update for plug-in FW 2.3
2.0-01
060427
RBt
Update for plug-in FW 2.0/2.1/2.2
1.1-01
060225
RBt
Update for plug-in FW 1.1 and tabletop FW 2.2
1.0-01
051130
RBt
First version
Copyright 2010 by Schmid Telecommunication, Zurich, Switzerland. All rights reserved. Reproduction of part or all of
the contents in any form is expressly prohibited without the prior written consent of Schmid Telecommunication.
Schmid Telecommunication has used its discretion, best judgments and efforts in preparing this document. Any in-
formation contained in this document is provided without any warranty of any kind. Schmid Telecommunication he-
reby disclaims any liability to any person for any kind of damage. Schmid Telecommunication may make improve-
ments and/or changes of this document at any time.

Revision: 2010-01-20
Declaration of Conformity
Tabletop
Watson Ethernet tabletop 1p Ethernet
SZ.847.V350
Watson Ethernet tabletop 2p 1xEth
SZ.847.V450
Plug-in
Watson Ethernet plug-in, 4 x Ethernet, 4 x DSL
SZ.866.V654
Manufacturer:
Schmid Telecom AG, Binzstrasse 35, CH-8045 Zurich
The products mentioned above comply with the regulations of the following European Directives:
2004/108/EC
Directive containing requirements regarding
electromagnetic compatibility.
The compliance of the above mentioned product with the re-
quirements of the directive 2004/108/EC is ensured by com-
plete application of the following harmonized European Stan-
dards:
EN 300386:2000
2006/95/EC
Directive containing requirements regarding
safety.
The compliance of the above mentioned product with the re-
quirements of the directive 2006/95/EC is ensured by com-
plete application of the following harmonized European Stan-
dards:
EN 60950:2006 (IEC 60950:2005)
99/5/EEC
Directive containing requirements regarding
Radio & Telecommunication Terminal
Equipment.
The compliance of the above mentioned product with the re-
quirements of the directive 99/5/EEC is ensured by complete
application of the following harmonized European Standards:
EN 55022:1998, EN 55024:1998
EN 60950:2006 (IEC 60950:2005)
2002/96/CE
Directive containing requirements regarding
the prevention of waste electrical and elec-
tronic equipment (WEEE), and in addition,
the reuse, recycling and other forms of re-
covery of such wastes so as to reduce the
disposal of waste.
The product mentioned above is labeled in accordance with
European Directive 2002/96/EC concerning waste electrical
and electronic equipment (WEEE). The Directive determines
the framework for the return and recycling of used appliances
as applicable throughout the European Union. This label is
applied to the product to indicate that the product is not to be
thrown away, but rather reclaimed upon end of life per this
Directive.

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
iv
Revision: 2010-01-20
2002/95/CE
Directive containing requirements to approx-
imate the laws of the Member States on the
restrictions of the use of hazardous sub-
stances (RoHS) in electrical and electronic
equipment and to contribute to the protection
of human health and the environmentally
sound recovery and disposal of waste elec-
trical and electronic equipment.
The product mentioned above has been designed and pro-
duced following the Directive 2002/95/EC of the European
Parliament and of the Council of 27 January 2003 on the re-
striction of the use of certain hazardous substances in elec-
trical and electronic equipment and is compliant to the al-
lowed concentration values defined by the European Commit-
tee.
The compliance of the above mentioned products with the specified requirements of the applicable directives
and harmonized and non-harmonized standards is shown in the following internal and external test reports:
W5A Safety Report.pdf
W5B LTU 4xEth 4xDSL Protection Report 0.1.doc
Watson_ETH_EMC_Report_1.0.pdf
Watson_Ethernet_MS_EMC_External_Report_1_EMCKP1240A.pdf
SZ.847.Vxxx Safety Report EN60950.pdf (tabletop, external)
CE Label attached to the product(s):
on tabletop, for plug-in on minirack and on 19” subrack
Issued by:
Schmid Telecom AG
Binzstrasse 35
CH-8045 Zurich
Place and date:
Zurich, 2009-02-26
Signatures:
Signature 1
Ronny Colotto
Signature 2
Marcel Beerli

Revision: 2010-01-20
Important Safety Precautions
To reduce the risk of fire, bodily injury, and damage to the equipment the follow-
ing precautions must be observed:
Read and follow all warning notices and instructions marked on the product
or included in the manual.
Installation of this equipment has to be done by qualified personnel only.
To achieve safety and satisfactory EMC performance, the plug-in boards
have to be inserted into appropriate subracks. Subrack slots that are not
used must covered with a blanking plate.
The subracks must be connected to earth. This is achieved by installing the
subracks into properly grounded rack or by connecting the protective ground
terminal provided on some subracks to the earthing network.
If the subracks are installed in racks then these racks must be connected to
the earthing network according to ETS 300 253.
Where protective ground terminals are available on the subracks these ter-
minals are marked with the symbol . The following rules must be ob-
served:
The earthing network must be connected to the protective ground termin-
al continuously and securely.
Where the subracks are fitted with an AC power connector the earthing
network must be connected securely to the protective ground terminal
even if the AC power cord is disconnected from the subracks.
The protective grounding may only be disconnected from the subracks af-
ter the DSL line has been disconnected from the plug-in.
Ground terminals on the tabletop modems are marked with the symbol .
The following rules must be observed:
Use of the ground terminal is optional. If used then the earthing network
must be connected to the ground terminal continuously and securely.
Otherwise the ground terminal can be left open.
The grounding may only be disconnected from the modem after the DSL
line has been disconnected.
This product is to be used with telecommunications circuits. Take the follow-
ing precautions:
Never install telephone wiring during a lightning storm.
Never install telephone jacks in wet locations unless the jack is specifical-
ly designed for wet locations.
Never touch uninsulated telephone wires or terminals unless the tele-
phone line has been disconnected at the network interface.
Use caution when installing or modifying telephone lines.

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
vi
Revision: 2010-01-20
Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak.
Condensation may occur externally or internally if this product is moved from
a colder room to a warmer room. When moving this product under such con-
ditions, allow ample time for this product to reach room temperature and to
dry before operating.
This product is intended for use in environments as stated in the technical
specifications. Do not use this product in areas classified as hazardous loca-
tions. Such areas include patient care areas of medical and dental facilities,
oxygen-laden environments, or industrial facilities. Contact your local elec-
trical authority governing building construction, maintenance, or safety for
more information regarding the installation of this product.
Slots and openings in this product are provided for ventilation and should
never be blocked or covered, since these ensure reliable operation of this
product and protect it from overheating. This product should not be placed in
a built-in apparatus such as a rack unless the apparatus has been specifically
designed to accommodate the product, proper ventilation is provided for the
product, and the product instructions have been followed.
This product should be placed away from radiators, heat registers, stoves, or
other pieces of equipment that produce heat. Allow sufficient air circulation
around the product and the AC adapter during use to ensure adequate cool-
ing of the device.
Do not use this product in a wet location.
Normal operation of this product is only possible when the external housing is
left in place.
This product should be operated only from the type of power source indicated
on the product's electrical ratings label. If you have questions about the type
of power source to use, contact your local Schmid Distributor or local power
company.
Be sure that the power outlet you plug the power cord into is easily accessi-
ble and located as close to the equipment operator as possible. When you
need to disconnect power to this product, be sure to unplug the power cord
from the electrical outlet.
Ensure that the voltage select switch, if provided on this product, is in the cor-
rect position for the type of voltage in your country (115 VAC or 230 VAC).
Do not allow anything to rest on any of the attached cables and do not posi-
tion this product where persons will walk or trip on the cables.
Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Never push a foreign object through an opening in this product.

Watson-Ethernet-Manual.doc
Version 3.3-01
Watson Ethernet
Operating Manual
Revision: 2010-01-20
vii
Unplug the product from the electrical outlet and contact your local Schmid
Distributor under the following conditions:
The power cord, extension cord, or plug is damaged.
Liquid has been spilled or an object has fallen into this product.
This product has been exposed to water.
This product has been dropped or damaged in any way.
There are noticeable signs of overheating.
This product does not operate normally when you follow the operating in-
structions.
Do not attempt to service this product yourself, as opening or removing cov-
ers may expose you to dangerous high voltage points or other risks. Refer all
servicing to your local Schmid Distributor.
Upon completion of any service or repairs to this product, have your local
Schmid Distributor perform any safety checks required by the repair proce-
dure or by local codes to determine that the product is in proper operating
condition.

Revision: 2010-01-20
ix
Limited Product Warranty
Schmid Telecom warrants that for two (2) years from the date of shipment to the
Customer, all products manufactured by Schmid Telecom will be free from de-
fects in materials and workmanship. Schmid Telecom also warrants that products
will conform to the applicable specification and drawings for such products, as
contained in the Product Manual on in Schmid Telecom internal specifications
and drawings for such products (which may or may not be reflected in the Prod-
uct Manual). This warranty only applies if Customer gives Schmid Telecom writ-
ten notice of defects during the warranty period. Upon such notice, Schmid Tele-
com will, at its option, either repair or replace the defective item.
If Schmid Telecom is unable, in a reasonable time, to repair or replace any
equipment to a condition as warranted, Customers is entitled to a full refund of
the purchase price upon return of the equipment to Schmid Telecom. This war-
ranty applies only to the original purchaser and is not transferable without Schm-
id Telecom express written permission. This warranty becomes null and void if
Customer modifies or alters the equipment in any way, other than as specifically
authorized by Schmid Telecom.
Except for the limited warranty described above, the foregoing constitutes the
sole and exclusive remedy of the Customer and the exclusive liability of Schmid
Telecom and is in Lieu of any and all other warranties (expressed or implied).
Schmid Telecom specifically disclaims all other warranties, including (without li-
mitation), all warranties of merchantability and fitness for a particular purpose.
Some states do not allow the exclusion of implied warranties, so this exclusion
may not apply to Customer.
In no event will Schmid Telecom or its suppliers be liable to Customer for any in-
cidental, special, punitive, exemplary or consequential damages experienced by
either Customer or a third party (including, but not limited to, loss of data or in-
formation, loss of profits, or loss of use). Schmid Telecom is not liable for dam-
ages for any cause whatsoever (whether based in contract, tort, or otherwise) in
excess of the amount paid for the item. Some states do not allow the limitation or
exclusion of liability for incidental or consequential damages, so the above limita-
tion or exclusion may not apply to Customer.

Revision: 2010-01-20
xi
Table of Contents
1Related Documents ......................................................................................................................... 1-1
2Overview........................................................................................................................................... 2-1
2.1 Introduction.............................................................................................................................. 2-1
2.2 Applications ............................................................................................................................. 2-1
3Modem Features .............................................................................................................................. 3-1
3.1 DSL.......................................................................................................................................... 3-1
3.1.1 Linerates and DSL sync rates...................................................................................... 3-1
3.1.2 Multipair operation ....................................................................................................... 3-2
3.1.3 Single-pair fallback....................................................................................................... 3-3
3.1.4 Power Backoff.............................................................................................................. 3-4
3.1.5 Symmetric and Asymmetric PSDs............................................................................... 3-4
3.1.6 DSL Performance Parameters..................................................................................... 3-4
3.1.7 Wetting Current............................................................................................................ 3-6
3.1.8 Master / Slave.............................................................................................................. 3-7
3.1.9 DSL Clocking............................................................................................................... 3-7
3.2 Ethernet (plug-in modem)........................................................................................................ 3-7
3.2.1 Ethernet over DSL ....................................................................................................... 3-7
3.2.2 Ethernet Bridging......................................................................................................... 3-8
3.2.3 MAC Defect Signaling.................................................................................................. 3-9
3.2.4 VLANs.......................................................................................................................... 3-9
3.2.5 VLAN Examples........................................................................................................... 3-9
3.2.6 Individual and shared forwarding databases ............................................................. 3-11
3.2.7 Stacked VLANs.......................................................................................................... 3-13
3.2.8 Class of Service (CoS)............................................................................................... 3-14
3.2.9 Spanning Tree Protocol............................................................................................. 3-16
3.3 Ethernet (tabletop modem).................................................................................................... 3-19
3.3.1 Ethernet over DSL ..................................................................................................... 3-19
3.3.2 VLAN features............................................................................................................ 3-19
3.3.3 Mixed mode operation ............................................................................................... 3-20
3.3.4 Cisco HDLC............................................................................................................... 3-20
3.4 Firmware update.................................................................................................................... 3-21
3.4.1 Plug-in........................................................................................................................ 3-21
3.4.2 Tabletop..................................................................................................................... 3-21
3.5 Management.......................................................................................................................... 3-21
3.5.1 Management interfaces ............................................................................................. 3-21
3.5.2 Chain Management through the DSL EOC................................................................ 3-23
3.5.3 Management IP Address Configuration..................................................................... 3-24
3.5.4Management VLAN configuration.............................................................................. 3-25
3.5.5 Transparent bridging with inband management ........................................................ 3-25
3.6 G.826 Performance Monitoring ............................................................................................. 3-26
3.7 Test loops.............................................................................................................................. 3-26
3.8 Password protection.............................................................................................................. 3-27
4Powering........................................................................................................................................... 4-1

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
xii
Revision: 2010-01-20
4.1 Plug-in...................................................................................................................................... 4-1
4.2 Tabletop................................................................................................................................... 4-1
5LEDs and Alarms ............................................................................................................................. 5-1
5.1 Plug-in LEDs............................................................................................................................ 5-1
5.1.1 Plug-in LED Indications................................................................................................ 5-1
5.2 Tabletop LEDs......................................................................................................................... 5-2
5.2.1 Front LEDs................................................................................................................... 5-2
5.2.2 Back LEDs................................................................................................................... 5-3
5.3 Alarm Conditions ..................................................................................................................... 5-3
5.4 Alarm Relays ........................................................................................................................... 5-3
5.4.1 Plug-in.......................................................................................................................... 5-3
5.5 Initialization Errors ................................................................................................................... 5-4
6The Monitor ...................................................................................................................................... 6-1
6.1 Introduction.............................................................................................................................. 6-1
6.2 Addressing of Plug-ins............................................................................................................. 6-2
6.2.1 Plug-in in Subrack........................................................................................................ 6-2
6.2.2 Plug-in in Minirack mechanics or tabletop housing...................................................... 6-2
6.2.3 Tabletop....................................................................................................................... 6-2
6.3 Naming of ports ....................................................................................................................... 6-3
6.4 Telnet Access.......................................................................................................................... 6-3
6.5 Monitor Command Structure ................................................................................................... 6-4
6.5.1 Welcome Screen ......................................................................................................... 6-4
6.5.2 Menus.......................................................................................................................... 6-4
6.5.3 Prefixes an Shortcuts................................................................................................... 6-5
6.5.4 Tab completion ............................................................................................................ 6-5
6.5.5 Help.............................................................................................................................. 6-5
6.5.6 Command History........................................................................................................ 6-5
6.5.7 Continuous Displays .................................................................................................... 6-6
7Monitor Command Reference......................................................................................................... 7-1
7.1 Introduction.............................................................................................................................. 7-1
7.2 Configuration Management CM............................................................................................... 7-2
7.2.1 General Commands..................................................................................................... 7-2
7.2.2 DSL Configuration (Plug-in)......................................................................................... 7-6
7.2.3 DSL Configuration (Tabletop)...................................................................................... 7-7
7.2.4 Ethernet Configuration (Plug-in) .................................................................................. 7-8
7.2.5 Ethernet Configuration (Tabletop)................................................................................ 7-9
7.2.6 Ethernet Bridging Configuration (Plug-in).................................................................. 7-10
7.2.7 Ethernet Bridging Configuration (Tabletop) ............................................................... 7-11
7.2.8 VLAN Configuration (Plug-in)..................................................................................... 7-11
7.2.9 VLAN Configuration (Tabletop).................................................................................. 7-14
7.2.10 Class of Service Configuration (Plug-in).................................................................... 7-15
7.2.11 Class of Service Configuration (Tabletop)................................................................. 7-17
7.2.12 Spanning Tree Configuration..................................................................................... 7-20
7.2.13 Management Configuration........................................................................................ 7-24
7.3 Fault and Maintenance Management FMM........................................................................... 7-27
7.3.1 Diagnostic.................................................................................................................. 7-27
7.3.2 Status (Plug-in).......................................................................................................... 7-28
7.3.3 Status (Tabletop) ....................................................................................................... 7-30
7.3.4 Alarms........................................................................................................................ 7-31
7.3.5 Test loops .................................................................................................................. 7-33

Watson-Ethernet-Manual.doc
Version 3.3-01
Watson Ethernet
Operating Manual
Revision: 2010-01-20
xiii
7.3.6 Reset Commands...................................................................................................... 7-33
7.4 Performance Management PM.............................................................................................. 7-34
7.4.1 G.826 Statistics.......................................................................................................... 7-34
7.4.2 Ethernet Statistics...................................................................................................... 7-35
7.4.3 Bit error rate tests ...................................................................................................... 7-36
7.5 Security and Remote Management SM................................................................................. 7-38
7.5.1 Connection control..................................................................................................... 7-38
7.5.2 Inventory.................................................................................................................... 7-38
7.5.3 Password................................................................................................................... 7-39
7.5.4 Firmware Update ....................................................................................................... 7-41
8SNMP................................................................................................................................................. 8-1
8.1 Introduction.............................................................................................................................. 8-1
8.1.1 AgentX......................................................................................................................... 8-1
8.1.2 Default Context and Card Contexts............................................................................. 8-2
8.1.3 SNMP Configuration.................................................................................................... 8-3
8.1.4 The Entity MIB.............................................................................................................. 8-3
8.1.5 VLAN indexing in the Default Context.......................................................................... 8-5
8.1.6 The ifTable............................................................................................................... 8-5
8.2 MIB Reference......................................................................................................................... 8-6
8.2.1 MIB II (RFC 1213)........................................................................................................ 8-6
8.2.2 P-BRIDGE-MIB (RFC 2674)........................................................................................ 8-6
8.2.3 Q-Bridge-MIB (RFC 2674)........................................................................................... 8-6
8.2.4 Entity MIB (RFC 2737)................................................................................................. 8-7
8.2.5 RMON (RFC 2819)...................................................................................................... 8-7
8.2.6 IF MIB (RFC 2863)....................................................................................................... 8-7
8.2.7 SNMP Notification MIB (RFC 3413)............................................................................. 8-7
8.2.8 SNMP Target MIB (RFC 3413).................................................................................... 8-8
8.2.9 SNMP-VIEW-BASED-ACM-MIB (RFC 3415).............................................................. 8-8
8.2.10 Etherlike MIB (RFC 3635)............................................................................................ 8-8
8.2.11 MAU MIB (RFC 3636).................................................................................................. 8-8
8.2.12 Bridge-MIB (RFC 4188)............................................................................................... 8-9
8.2.13 RSTP-MIB (RFC 4318)................................................................................................ 8-9
8.2.14 HDSL2-SHDSL-LINE-MIB (RFC 4319)........................................................................ 8-9
8.2.15 HDSL MIB.................................................................................................................. 8-10
8.2.16 Schmid MIB................................................................................................................ 8-11
8.2.17 Watson MIB............................................................................................................... 8-11
9Front and Rear Panels..................................................................................................................... 9-1
9.1 Front Panel (Plug-in)................................................................................................................ 9-1
9.2 Rear Panel (Tabletop) ............................................................................................................. 9-1
10 Connectors and Cables................................................................................................................. 10-1
10.1 Overview................................................................................................................................ 10-1
10.2 DSL Interface......................................................................................................................... 10-3
10.2.1 Connector .................................................................................................................. 10-3
10.2.2 DSL Cable.................................................................................................................. 10-4
10.3 Ethernet Interface.................................................................................................................. 10-5
10.4 Monitor Interface.................................................................................................................... 10-5
10.5 Power and Grounding............................................................................................................ 10-6
10.5.1 Tabletop Power Connector........................................................................................ 10-6
10.5.2 Tabletop ground connector........................................................................................ 10-6
11 Technical Specifications............................................................................................................... 11-1

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
xiv
Revision: 2010-01-20
11.1 Interfaces............................................................................................................................... 11-1
11.1.1 DSL Line Interface..................................................................................................... 11-1
11.1.2 Ethernet Interfaces..................................................................................................... 11-1
11.1.3 Monitor Interface........................................................................................................ 11-1
11.2 Power Consumption .............................................................................................................. 11-2
11.2.1 Plug-in........................................................................................................................ 11-2
11.2.2 Tabletop..................................................................................................................... 11-2
11.3 Ethernet................................................................................................................................. 11-2
11.4 Latency and Throughput........................................................................................................ 11-3
11.5 Management Functions......................................................................................................... 11-3
11.6 MTBF..................................................................................................................................... 11-3
11.7 Environment........................................................................................................................... 11-4
11.7.1 Climatic Conditions (Plug-in and Tabletop)................................................................ 11-4
11.7.2 Safety......................................................................................................................... 11-4
11.7.3 EMC........................................................................................................................... 11-4
11.8 Physical dimensions and weight............................................................................................ 11-4
11.8.1 Plug-in........................................................................................................................ 11-4
11.8.2 Tabletop..................................................................................................................... 11-4
12 Terminology ................................................................................................................................... 12-1
13 Product Order Codes..................................................................................................................... 13-1
13.1 Modems................................................................................................................................. 13-1
13.2 Accessories ........................................................................................................................... 13-1
13.2.1 Accessories for plug-in .............................................................................................. 13-1
13.2.2 Accessories for tabletop ............................................................................................ 13-2

Watson-Ethernet-Manual.doc
Version 3.3-01
Watson Ethernet
Operating Manual
Revision: 2010-01-20
xv
Figures
Figure 2-1: Ethernet Services ............................................................................................................ 2-1
Figure 2-2: Campus Networks........................................................................................................... 2-2
Figure 2-3: Linear Ethernet Network.................................................................................................. 2-2
Figure 2-4: Ethernet over WAN ......................................................................................................... 2-3
Figure 3-1: G.SHDSL and G.SHDSL.bis linerates............................................................................. 3-1
Figure 3-2: Wetting current jumper location....................................................................................... 3-6
Figure 3-3: Ethernet over DSL........................................................................................................... 3-7
Figure 3-4: Watson Ethernet plug-in Block diagram.......................................................................... 3-8
Figure 3-5: Transparent bridging ....................................................................................................... 3-8
Figure 3-6: Simple VLAN Example.................................................................................................. 3-10
Figure 3-7: VLAN configuration for traffic concentration.................................................................. 3-10
Figure 3-8: VLAN configuration for Inband Management ................................................................ 3-11
Figure 3-9: Individual VLAN learning (IVL) example........................................................................ 3-12
Figure 3-10: Shared VLAN learning (SVL) example........................................................................ 3-12
Figure 3-11: Stacked VLAN frame format........................................................................................ 3-13
Figure 3-12: Class of Service functions........................................................................................... 3-14
Figure 3-13: Ingress rate limiter example ........................................................................................ 3-16
Figure 3-14: Mixed mode operation................................................................................................. 3-20
Figure 3-15: Cisco HDLC................................................................................................................. 3-20
Figure 3-16: Management interfaces............................................................................................... 3-22
Figure 3-17: Chain Management through the DSL EOC................................................................. 3-23
Figure 3-18: IP networks for Management ...................................................................................... 3-24
Figure 3-19: Transparent bridging with inband management.......................................................... 3-25
Figure 3-20: Test Loops controlled by the DSL Master ................................................................... 3-26
Figure 3-21: Test Loops controlled by the DSL Slave...................................................................... 3-26
Figure 6-1: Plug-in Addressing Scheme............................................................................................ 6-2
Figure 8-1: SNMP Master agent and subagents................................................................................ 8-2
Figure 8-2: Default Context and Card Contexts................................................................................. 8-3
Figure 8-3 Entity MIB entPhysicalTable...................................................................................... 8-4
Figure 8-4: VLAN indexing in the Default Context............................................................................. 8-5
Figure 9-1: Plug-in front panel ........................................................................................................... 9-1
Figure 9-2: Tabletop rear panel ......................................................................................................... 9-1
Figure 10-1: Cabling and mechanics (plug-in)................................................................................. 10-1
Figure 10-2: Cabling and mechanics (tabletop)............................................................................... 10-2
Figure 10-3: DSL Connector............................................................................................................ 10-3
Figure 10-4: HDSL Cable, 4 pairs, 5m, open end............................................................................ 10-4
Figure 10-5: Ethernet Connector ..................................................................................................... 10-5
Figure 10-6: Monitor Connector....................................................................................................... 10-5
Figure 10-7: Power Connector......................................................................................................... 10-6
Figure 10-8: Ground Connector....................................................................................................... 10-6

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
xvi
Revision: 2010-01-20
Tables
Table 3-1: Naming of DSL spans, pairs and connection points......................................................... 3-3
Table 3-2: Power Backoff................................................................................................................... 3-4
Table 3-3: Wetting current jumper settings........................................................................................ 3-6
Table 3-4: Ingress rate limiter profiles ............................................................................................. 3-15
Table 3-5: Egress rate limiter profiles.............................................................................................. 3-16
Table 3-6: Recommended port cost values..................................................................................... 3-18
Table 5-1: LED mapping for plug-in................................................................................................... 5-1
Table 5-2: Plug-in LED indications..................................................................................................... 5-1
Table 5-3: Tabletop front LED indications.......................................................................................... 5-2
Table 5-4: Tabletop front LED indications during firmware download............................................... 5-2
Table 5-5: Tabletop backpanel Ethernet LED indications.................................................................. 5-3
Table 5-6: Software Initialization Errors (tabletop modem)................................................................ 5-4
Table 6-1: Port naming ...................................................................................................................... 6-3
Table 6-2: Monitor Command Subsets.............................................................................................. 6-4
Table 6-3: Command Shortcuts......................................................................................................... 6-5
Table 7-1: Command language elements.......................................................................................... 7-1
Table 7-2: DEFAULT values (plug-in)................................................................................................. 7-4
Table 7-3: DEFAULT values (tabletop)............................................................................................... 7-5
Table 10-1: DSL connector pin assignment (Plug-in)...................................................................... 10-3
Table 10-2: DSL connector pin assignment (Tabletop) ................................................................... 10-3
Table 10-3: Ethernet Connector....................................................................................................... 10-5
Table 10-4: Monitor Connector........................................................................................................ 10-5
Table 10-5: Power connector........................................................................................................... 10-6
Table 13-1: Watson Ethernet modem types.................................................................................... 13-1
Table 13-2: Accessories for plug-in ................................................................................................. 13-1
Table 13-3: Accessories for tabletop ............................................................................................... 13-2

Revision: 2010-01-20
1-1
1 Related Documents
[1] Schmid Telecom, Watson SHDSL Router Manual
[2] Schmid Telecom, Watson SHDSL Router GUI Manual
[3] Schmid Telecom, Watson SHDSL Router Application Manual
[4] Schmid Telecom, Watson Rack Operating Manual
[5] Schmid Telecom, Watson Minirack Mechanics Operating Manual
[6] Schmid Telecom, Watson Tabletop Housing for Plug-in Manual
[7] Schmid Telecom, Watson Ethernet Application Manual
[8] Schmid Telecom, Watson TDM Manual
[9] Schmid Telecom, WEM-2 Users Manual
[10] Schmid Telecom, Flashloader Operating Manual
[11] ETSI TS 101 524 (2006)

Revision: 2010-01-20
2-1
2 Overview
2.1 Introduction
The Watson Ethernet modems are SHDSL transmission systems compliant to
ITU-T G.991.2 Annex B (G.SHDSL.bis) and to ETSI TS 101 524 (2006).
SHDSL uses Trellis-coded PAM-16 and PAM-32 linecodes supporting multiple li-
nerates as well as 1-pair, 2-pair and 4-pair DSL transmission.
The Watson Ethernet modems are available as plug-in cards and as tabletop
units. Both plug-in cards and tabletops can work as DSL master modems (STU-
C) and as DSL slave modems (STU-R).
The modems can be configured with an RS-232 terminal through a command
line interface (Monitor).
For remote management a Telnet access to the Monitor is available. The plug-in
modems also have an SNMP agent integrated. One agent can control all plug-in
modems in a subrack and all tabletop modems connected to the subrack mod-
ems.
2.2 Applications
Figure 2-1 shows typical deployment scenarios of Watson Ethernet to deliver
Metro Ethernet Services:
Figure 2-1: Ethernet Services
Several Ethernet plug-in cards are installed in a subrack at the central office or
the point of presence. Depending on the service offered each plug-in can serve
between one and four customers. At the customer premises either a tabletop

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
2-2
Revision: 2010-01-20
modem or a plug-in card in a tabletop housing is installed. Traffic from each cus-
tomer is available at a dedicated Ethernet interface in the central office. Alterna-
tively traffic from several customers can be aggregated to a single Ethernet port.
Advanced VLAN functions allow for customer isolation and traffic management.
Watson Ethernet modems can also be used back-to-back as shown in Figure
2-2:
Figure 2-2: Campus Networks
For these applications either two tabletop modems or two plug-in modems (in an
appropriate housing) are connected back to back with one of the modems being
configured as DSL master and the other one as DSL slave. Depending on the
distance and the number of wire pairs available linerates up to 22.8 MBit/s are
available. VLAN and MAC Address filtering functions allow for traffic manage-
ment and optimal use of the available DSL bandwidth.
Deployment in linear networks is supported with the Watson Ethernet plug-in
card:
Figure 2-3: Linear Ethernet Network
In Figure 2-3 several sites (e.g. stations along a pipeline or a power line) are
connected with single or two pair DSL systems. In each site a single Watson
Ethernet plug-in card terminates the DSL spans coming from "East" and "West"
sides and gives four local Ethernet interfaces e.g. to connect local station control
equipment. Traffic from the local interfaces can be aggregated with traffic on the
DSL and can be sent to either direction along the line. Traffic streams are kept
separate through VLANs, and Class of Service/Priority functions allow for traffic
management.
4
x Ethernet
10
/
100
Mbps
4
x Ethernet
10
/
100
Mbps
4
x Ethernet
10
/
100
Mbps
G
.
SHDSL
G
.
SHDSL
.
bis
4
x Ethernet
10
/
100
Mbps
G
.
SHDSL
G
.
SHDSL
.
bis
G
.
SHDSL
G
.
SHDSL
.
bis
