Schumacher SPR1630 User manual

0099002106E-02
Jump Starter
and DC Power Source
Arrancador
y Fuente de Poder de CC
Bloc d’alimentation
et aide démarrage
OWNERS MANUAL / MANUAL DEL USUARIO /
MANUEL D’UTILISATION
PLEASE SAVE THIS OWNERS MANUAL AND READ BEFORE EACH USE. This manual
will explain how to use the portable power safely and effectively. Please read and follow these
instructions and precautions carefully.
POR FAVOR CONSERVE ESTE MANUAL DEL USUARIO Y LEALO ANTES DE CADA
USO. En este manual le explica cómo utilizar la fuente de poder de manera segura y conable.
Por favor, lea y siga las siguientes instrucciones y precauciones.
ESSAYER DE GARDER LE MANUEL D’INSTRUCTIONS ET LE LIRE AVANT CHAQUE
UTILISATION. Ce manuel explique comment utiliser l’unité d’une façon sûre et efcace. S’il vous
plaît lisez et suivez ces instructions et précautions.
FOR MODELS / PARA MODELOS / POUR LES MODÈLES
BE01254
FR01240
SJ1330
SJ1331
SJ1426
SPR1630

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS. .............................................5
PERSONAL SAFETY PRECAUTIONS.......................................................................................................6
FEATURES .................................................................................................................................................6
CHARGING THE INTERNAL BATTERY OF THE JUMP STARTER...........................................................6
OPERATING INSTRUCTIONS ...................................................................................................................7
MAINTENANCE INSTRUCTIONS..............................................................................................................8
MOVING AND STORAGE INSTRUCTIONS...............................................................................................9
TROUBLESHOOTING................................................................................................................................9
REPLACEMENT PARTS...........................................................................................................................10
ACCESSORIES ........................................................................................................................................10
BEFORE RETURNING FOR REPAIRS....................................................................................................10
LIMITED WARRANTY...............................................................................................................................10

CONTENIDOS
INSTRUCCIONES IMPORTANTES DE SEGURIDAD – GUARDE ESTAS INSTRUCCIONES...............11
PRECAUCIONES DE SEGURIDAD PERSONAL.....................................................................................11
CARACTERÍSTICAS ................................................................................................................................12
PARA CARGAR LA BATERIA INTERNA DEL ARRANCADOR.................................................................12
INSTRUCCIONES DE OPERACIÓN........................................................................................................13
INSTRUCCIONES DE MANTENIMIENTO ...............................................................................................14
INSTRUCCIONES PARA EL MANEJO Y ALMACENAMIENTO...............................................................15
LOCALIZACIÓN Y SOLUCIÓN DE PROBLEMAS ...................................................................................15
REPUESTOS............................................................................................................................................16
ACCESORIOS ..........................................................................................................................................16
ANTES DE DEVOLVER A REPARACIONES............................................................................................16
GARANTÍA LIMITADA...............................................................................................................................16

TABLE DES MATIÈRES
CONSIGNES DE SÉCURITÉ IMPORTANTES – CONSERVER CES INSTRUCTIONS..........................17
MESURES DE SÉCURITÉ PERSONNELLE............................................................................................18
CARACTÉRISTIQUES..............................................................................................................................18
CHARGEMENT DE LA BATTERIE INTERNE DE L’AIDE AU DÉMARRAGE ..........................................18
CONSIGNES D’UTILISATION ..................................................................................................................19
INSTRUCTIONS D’ENTRETIEN ..............................................................................................................20
INSTRUCTIONS DE STOCKAGE ET EMPLACEMENT ..........................................................................21
DÉPANNAGE............................................................................................................................................21
PIÈCES DE RECHANGE..........................................................................................................................22
ACCESSOIRES ........................................................................................................................................22
AVANT DE RETOURNER POUR LES RÉPARATIONS............................................................................22
GARANTIE LIMITÉE.................................................................................................................................22

• 5 •
CONTAINS SEALED, NON-SPILLABLE LEAD-ACID BATTERY. MUST BE DISPOSED OF PROPERLY.
WARNING: Possible explosion hazard. Contact with battery acid may cause severe burns and
blindness. Keep out of reach of children.
1. IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS.
WARNING: RISK OF EXPLOSIVE GASES.
WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE
EXPLOSIVE GASES DURING NORMAL OPERATION. IT IS IMPORTANT THAT YOU FOLLOW
THESE INSTRUCTIONS EACH TIME YOU USE THE UNIT.
To reduce the risk of battery explosion, follow these instructions and those published by the battery
manufacturer and the manufacturer of any equipment you intend to use in the vicinity of a battery.
Review cautionary markings on these products and on the engine.
WARNING! RISK OF ELECTRIC SHOCK OR FIRE.
1.1 Keep out of reach of children.
1.2 Do not disassemble the jump starter. Take it to a qualied service professional if service or repair is
required. Incorrect assembly may result in re or electrical shock.
1.3 Do not use the jump starter to jump a vehicle while charging the internal battery.
1.4 Do not recharge the jump starter with a damaged extension cord.
1.5 The jump starter gets hot during charging and must have proper ventilation.
1.6 Do not set the jump starter on ammable materials, such as carpeting, upholstery, paper, cardboard, etc.
1.7 Place the jump starter as far away from the battery being jumped as the cables will permit.
1.8 Do not expose the jump starter to rain or snow.
1.9 Never attempt to jump start a frozen battery.
1.10 Never place the jump starter directly above battery being jumped.
1.11 To prevent arcing, never allow the clamps to touch together or to contact the same piece of metal.
1.12 Use of an attachment not recommended or sold by the jump starter manufacturer may result in damage
to the unit or personal injury.
1.13 Never operate the jump starter if it is damaged.
1.14 If someone else uses the jump starter, ensure they are well informed on how to use it safely, and have
read and understood the operating instructions.
1.15 The jump starter is NOT designed to be installed as a replacement for a vehicle battery.
1.16 Use ONLY on vehicles, boats and garden tractors powered with a 12V DC battery system.
1.17 If the engine fails to start after the recommended number of attempts, disconnect the unit and look for
other problems that may need to be corrected.
1.18 Use the jump starter for jump starting lead-acid batteries only. Do not use for dry cell batteries that are
commonly used with home appliances.
Jump Starter and DC Power Source
OWNERS MANUAL
PLEASE SAVE THIS OWNERS MANUAL AND READ BEFORE EACH USE.
This manual will explain how to use the jump starter safely and effectively. Please
read and follow these instructions and precautions carefully.
FOR MODELS
BE01254
FR01240
SJ1330
SJ1331
SJ1426
SPR1630

• 6 •
2. PERSONAL SAFETY PRECAUTIONS
2.1 Wear complete eye protection and protective clothing when working near lead-acid batteries. Always
have someone nearby for help.
2.2 Have plenty of fresh water, soap and baking soda nearby for use, in case battery acid contacts your
eyes, skin, or clothing. Wash immediately with soap and water and seek medical attention.
2.3 If battery acid comes in contact with eyes, ush eyes immediately for a minimum 10 minutes and get
medical attention.
2.4 Neutralize any acid spills thoroughly with baking soda before attempting to clean up.
2.5 Remove all personal metal items from your body, such as rings, bracelets, necklaces and watches. A
battery can produce a short circuit current high enough to weld a ring to metal, causing a severe burn.
2.6 Never smoke or allow a spark or ame in the vicinity of the battery or engine.
3. FEATURES
1. Worklight ON/OFF switch
2. Rotary switch for USB and jump starter
3. Built-in work light
4. Battery status indicators
5. Battery status button
6. USB port
7. 12V DC power outlet
8. Battery clamps
9. Air compressor gauge
10. Air compressor ON/OFF switch
11. Internal battery charger port
12. Air compressor hose wrap cleats
13. Air compressor hose
14. Air compressor adapters and storage bag
3
5
4
6
7
8
1
2
9
14
13
10
11
12
4. CHARGING THE INTERNAL BATTERY OF THE JUMP STARTER
IMPORTANT: CHARGE IMMEDIATELY AFTER PURCHASE, AFTER EACH USE AND EVERY 30 DAYS,
TO KEEP THE UNIT’S INTERNAL BATTERY FULLY CHARGED AND PROLONG BATTERY LIFE.
4.1 CHECKING THE LEVEL OF THE INTERNAL BATTERY
Press the Battery Status button on the front of the unit. The LED lights will indicate the current charge
level as follows:
• RED – less than 20% of full charge; immediately charge the unit.
• YELLOW/ORANGE – 20-80% of full charge.
• GREEN – more than 80% of full charge.
4.2 CHARGING THE INTERNAL BATTERY
Charge the unit’s internal battery using an extension cord (not included).
NOTE: Use of an improper extension cord could result in a risk of re and electric shock.
1. To charge, ip the AC connector on the back of the unit DOWN and plug in an 18 AWG or larger
extension cord.
2. Plug the extension cord into a 120VAC electrical wall outlet.
3. While the jump starter is charging, the RED LED will be on. Complete charging may take up to 72 hours.
When the RED LED turns off, the jump starter is ready to use.

• 7 •
4. When the internal battery is fully charged, the charger will automatically go into maintain mode and
maintain the battery at full charge without damaging it. When in maintain mode, the GREEN LED will
light, as long as there is an AC cord connected to the charging port.
5. Charge the jump starter as soon as possible after use.
4.3 CHARGING THE INTERNAL BATTERY WHILE DRIVING
You may also charge the internal battery while driving, using a male-to-male charger cable (part number
94500109 – not included).
IMPORTANT: DO NOT CHARGE INTERNAL BATTERY FOR MORE THAN 30 MINUTES OR LEAVE THE
BATTERY UNATTENDED. IT COULD EXPLODE, CAUSING PROPERTY DAMAGE OR PERSONAL INJURY.
1. Make sure the car is running.
2. Insert one end of the accessory cable into the 12V DC power outlet.
3. Insert the other end of the accessory cable into the vehicle’s accessory outlet (lighter socket).
NOTE: The RED LED does not operate during this method of charging. Using this method to charge the
battery overrides the maintain mode and the battery can be overcharged.
4. Monitor the progress of the charge by pressing the Battery Status button on the front of the unit. When
the battery is fully charged, disconnect the accessory cable from the unit, and then from the lighter
socket of the vehicle.
NOTE: Completely disconnect the charger cable when the engine is not running.
5. OPERATING INSTRUCTIONS
5.1 JUMP STARTING A VEHICLE
IMPORTANT: Using the Engine Start feature without a battery installed in the vehicle will damage the
vehicle’s electrical system.
1. Turn the ignition OFF.
2. Lay the DC cables away from any fan blades, belts, pulleys and other moving parts.
3. For a negative-ground vehicle (as in most vehicles), connect the Instant Power’s POSITIVE (RED)
clamp to the POSITIVE (POS, P, +) battery post. Next, connect the NEGATIVE (BLACK) clamp to the
vehicle chassis or engine block, away from the battery.
4. For a positive-ground vehicle, connect the Instant Power’s NEGATIVE (BLACK) clamp to the
NEGATIVE (NEG, N, -) battery post. Next, connect the POSITIVE (RED) clamp to the vehicle chassis
or engine block away from the battery.
5. Turn the switch to the ON position
6. Crank the engine for no more than 8 seconds. If the engine does not start, wait 2 minutes before
cranking again.
7. After the engine starts, turn the switch to the OFF position and remove the unit from the battery.
8. Charge the unit.
5.2 USING THE USB PORT
The USB port provides up to 2A at 5V DC.
1. Ensure the battery clamps are securely clipped on the storage holders.
2. Turn the unit ON.
3. Plug your device into the USB port.
4. When nished using the USB port, turn the switch to the OFF position.
5. Charge the unit.
5.3 USING THE WORK LIGHT
The work light is controlled by a sliding ON/OFF switch located on the front of the unit.
• Make sure the lamp is turned OFF when the unit is being recharged or stored.
• Position the unit on a at, stable surface near the intended work area.
• Ensure the battery clamps are securely clipped on the storage holders.

• 8 •
5.4 POWERING A 12V DC DEVICE
The unit is a power source for all 12V DC accessories that are equipped with a 12V accessory plug. Use
it for power outages and on shing or camping trips.
NOTE: Do not power a 12V device with the unit while charging the internal battery.
1. Make sure the device to be powered is OFF before inserting the 12V DC accessory plug into the 12V
DC accessory outlet.
2. Open the protective cover of the DC power outlet on the unit.
3. Plug the 12V DC device into the DC power outlet and turn on the 12V DC device (if required).
4. When nished, turn off the DC device (if required) and unplug from the DC power outlet.
CAUTION: Do not use the unit to run appliances that draw more than 20A DC.
NOTE: Extended operation of a 12V DC device may result in excessive battery drain. Recharge the unit
immediately after unplugging the 12V DC device.
Estimated run-times
APPLIANCE TYPE EST WATTAGE APPROX. USAGE
Cell phone, uorescent light 4 watts 34 hrs
Radio, fan, depth nder 9 watts 14 hrs
Camcorder 15 watts 7 hrs
Electrical tool 24 watts 5 hrs
Electric cooler 48 watts 2 hours
Car vacuum, air compressor 80 watts 1.8 hrs
NOTE: Actual time may vary. Times are based on the internal battery being fully charged.
5.5 FOR MODELS WITH AN AIR COMPRESSOR
WARNING. Read the instructions of the product being inated before using the compressor. Avoid
overination; do not exceed the manufacturer’s recommended pressures. Do not leave the air
compressor unattended during use.
NOTE: Wrap cleats are provided for convenient storage of the air compressor hose. Wrap the hose
around these cleats when the hose is not in use.
1. Ensure the battery clips are securely on the storage holders.
2. Remove the air compressor hose from the storage cleats.
3. Connect the adapter to the valve stem by threading it onto the end. If necessary, use one of the
additional adaptors.
4. Press the air compressor power switch to turn ON and inate to the desired pressure or fullness (refer
to the gauge next to the switch).
5. When the desired pressure is reached, press the air compressor power switch to turn OFF and remove
the connector from the valve stem.
6. Allow unit to cool.
7. Recharge the unit before storing.
NOTE: The air compressor is rated for 150 PSI.
Estimated time for inating
Vehicle tires 13-16" 6-24 minutes
Bike tires 1-3 minutes
Sports balls 30 seconds
These times are approximate. Use the air compressor gauge to ensure the proper pressure has been reached. Do
not overinate.
6. MAINTENANCE INSTRUCTIONS
6.1 After use and before performing maintenance, unplug and disconnect the jump starter.
6.2 Use a dry cloth to wipe all battery corrosion and other dirt or oil from the battery clips, cords and the
jump starter case.
6.3 Ensure that all of the jump starter components are in place and in good working condition.
6.4 All servicing should be performed by qualied service personnel.

• 9 •
7. MOVING AND STORAGE INSTRUCTIONS
7.1 Store inside, in a cool, dry place.
7.2 Do not store the clips on the handle, clipped together, on or around metal, or clipped to cables. The clips
on the jump starter are live when the switch is in the ON position and will produce arcing or sparking if
they come in contact with each other. To prevent accidental arcing, always place the switch in the OFF
position and keep the clips on the storage holders when not using it to jump start a vehicle.
7.3 If the jump starter is moved around the shop or transported to another location, take care to avoid/
prevent damage to the cords, clips and jump starter. Failure to do so could result in personal injury or
property damage.
IMPORTANT: Do not use and/or store the jump starter in or on any area or surface where damage
could occur if the internal battery should unexpectedly leak acid.
7.4 IMPORTANT:
• CHARGE IMMEDIATELY AFTER PURCHASE
• KEEP FULLY CHARGED
Charge the jump starter’s internal battery immediately after purchase, after every use and every 30 days.
All batteries are affected by temperature. The ideal storage temperature is at 70°F. The internal battery will
gradually self-discharge (lose power) over time, especially in warm environments. Leaving the battery in a
discharged state may result in permanent battery damage. To ensure satisfactory performance and avoid
permanent damage, charge the internal battery every month.
8. TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
The unit won’t jump start my car. Clamps are not making a good
connection to the battery.
Connections are reversed.
The internal battery is not
charged.
The vehicle’s battery is defective.
The unit is not turned on.
Check for poor connection to
battery and frame. Make sure
connection points are clean.
Disconnect the unit and reverse
the clamps.
Press the Battery Status button on
the front of the unit. The LEDs will
indicate the status of charge.
Have the battery checked.
Turn the unit’s ON/OFF switch to
the ON position.
The unit won’t power my 12V
device.
The 12V device is not turned on.
The internal battery is not
charged.
The 12V device draws more than
20A, has a short circuit, or the
internal fuse has blown.
Turn on the 12V device.
Check the battery charge status by
pressing the Battery Status button.
Disconnect the 12V device.
The internal 20A fuse needs
replacement by a qualied service
person.
The internal battery won’t hold a
charge.
The battery is bad (will not accept
a charge).
Have the battery checked.
The compressor shuts off. The compressor is overheated. Allow to cool for a few minutes,
then try again.

• 10 •
9. REPLACEMENT PARTS
Air compressor accessory kit (3 hose adapters)................................................................ 2299001425Z
10. ACCESSORIES
Male-to-male accessory cable..................................................................................................94500109
11. BEFORE RETURNING FOR REPAIRS
For REPAIRS OR RETURNS, visit 365rma.com
Visit batterychargers.com for Replacement Parts.
12. LIMITED WARRANTY
Go to batterychargers.com to register your product online.
SCHUMACHER ELECTRIC CORPORATION, 14200 FAA BLVD., FORT WORTH, TX 76155, MAKES
THIS LIMITED WARRANTY TO THE ORIGINAL RETAIL PURCHASER OF THIS PRODUCT. THIS
LIMITED WARRANTY IS NOT TRANSFERABLE OR ASSIGNABLE.
Schumacher Electric Corporation (the “Manufacturer”) warrants this jump starter for one (1) year and
the internal battery for ninety (90) days from the date of purchase at retail against defective material
or workmanship that may occur under normal use and care. If your unit is not free from defective
material or workmanship, Manufacturer’s obligation under this warranty is solely to repair or replace
your product with a new or reconditioned unit at the option of the Manufacturer. It is the obligation of
the purchaser to forward the unit, along with proof of purchase and mailing charges prepaid to the
Manufacturer or its authorized representatives in order for repair or replacement to occur.
Manufacturer does not provide any warranty for any accessories used with this product that are
not manufactured by Schumacher Electric Corporation and approved for use with this product.
This Limited Warranty is void if the product is misused, subjected to careless handling, repaired, or
modied by anyone other than Manufacturer or if this unit is resold through an unauthorized retailer.
Manufacturer makes no other warranties, including, but not limited to, express, implied or statutory
warranties, including without limitation, any implied warranty of merchantability or implied warranty of
tness for a particular purpose. Further, Manufacturer shall not be liable for any incidental, special or
consequential damage claims incurred by purchasers, users or others associated with this product,
including, but not limited to, lost prots, revenues, anticipated sales, business opportunities, goodwill,
business interruption and any other injury or damage. Any and all such warranties, other than the
limited warranty included herein, are hereby expressly disclaimed and excluded. Some states do not
allow the exclusion or limitation of incidental or consequential damages or length of implied warranty,
so the above limitations or exclusions may not apply to you. This warranty gives you specic legal
rights and it is possible you may have other rights which vary from this warranty.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS LIMITED WARRANTY AND THE
MANUFACTURER NEITHER ASSUMES OR AUTHORIZES ANYONE TO ASSUME OR MAKE
ANY OTHER OBLIGATION TOWARDS THE PRODUCT OTHER THAN THIS WARRANTY.
Schumacher® is a registered trademark of Schumacher Electric Corporation.
