STATIM 7000 Service Manual - Cassette
1
1. Cassette
1.1 Replacing the Cassette Seal and O-Rings
To ensure optimum performance of the Statim 7000, the seal is equipped with an
electronic tag to ensure only authentic seals are used and also to provide the
user a LCD message to replace the seal after 1000 cycles. The seal and O-rings
should be changed every 1000 cycles or every 12 months.

STATIM 7000 Service Manual - Cassette
2
Replacement seals are available from SciCan (p/n 01-110295S Lid Seal).
When the cassette seal has undergone 1000 cycles, an early message on the
LCD will display SEAL LIFE WARNING - 100 CYCLES REMAINING, with a
warning beep. The seals should be changed immediately. After 1100 cycles, your
unit will stop operating and a message will be displayed SEAL LIFE EXPIRED,
REPLACE. Replacement seals are available from your SciCan dealer.
To change the cassette lid seal, follow these steps:
1. Place the cassette lid and the new seal on a clean work surface.
2. Examine the position of the old seal in the cassette lid and arrange the
new seal in the same orientation, next to the lid.
3. Remove the old seal and discard.
4. Clean any residue out of the seal channel and flush out the channel with
distilled water.
5. Lubricate the new seal with the liquid seal lubricant provided.
6. Align the RFID tag in the new seal with the holes in the lid.
7. Insert the rounded edge of the seal under the round lip of the lid.
NOTE: When inserting the seal, seven round nibs should be visible. The nibs
should fit flush with the lid’s outer surface. Ensure the seal is completely inserted.
Feel around the periphery to ensure the seal is securely seated.
To change the cassette tray seals (O-Rings), follow these steps:
1. Remove the Perforated Rack (01-110294S)
2. Remove the Tray exhaust duct (01-110297S)
3. Remove the Steam Deflector (01-110293S)
4. Unscrew the first coupling (Exhaust Coupling, 01-110292S) and carefully
remove the two O-Ring seals.
5. Find the matching seals from the kit and install them on to the port valve.
6. Secure the first coupling to the cassette ensuring the metal spring is on
the outer wall of the cassette.

STATIM 7000 Service Manual - Cassette
3
7. Unscrew the second coupling (Inlet Coupling, 01-110291S) and carefully
remove the two O-Ring seals.
8. Find the matching seals from the kit and install them on to the port valve.
9. Secure the second coupling to the cassette ensuring the metal spring is
on the outer wall of the cassette.
10.Replace the Tray Exhaust duct, steam deflector, and perforated rack.
NOTE: During a cycle, steam may appear between the lid and the tray. If this
persists, remove the cassette and check that the seal is correctly installed.
Be careful. The metal parts may be hot, and the cassette may contain hot steam.
For the unit to function effectively, the steam deflector and perforated rack MUST
be placed back in the cassette in the proper position.
1.2 Replacing the Cassette Handle
Cracked or otherwise broken Statim 7000 cassette handles can be replaced by
following these steps:
1. Remove the two screws on the underside of each piece of the handle.
2. Remove the handle.
3. Separating the handle from the cassette may require pushing down
forcefully on the handle.
4. Replace and re-attach.

STATIM 7000 Service Manual - Cover
4
2. Cover
1. With the unit off, unplug the power cord from the wall outlet and remove
the cassette and reservoir from the unit.
2. Remove the water filter or water
bypass cartridge (if the unit is using
distilled water) from the reservoir
area.
3. Remove the eight screws across the
bottom front of the unit.
4. Push the cover forward from the
back a little to loosen it.

STATIM 7000 Service Manual - Cover
5
5. Detach the LCD/keypad by reaching
up inside the cover through the
armature opening to feel for a plastic
tab located directly behind the
Rubber and Plastics key.
6. Push this tab to the left to unlock the
LCD/keypad from the cover.
7. Place the LCD/keypad on top of the
armature so that it is out of the way
as you remove the cover.

STATIM 7000 Service Manual - Cover
6
8. Push the cover all the way forward
to slide it off from the front.
9. Reverse removal instructions to replace. NOTE: replacing cover may
change to include info on cover engaging a rail.

STATIM 7000 Service Manual – Cover Plate
7
3. Rear Chassis Cover Plate
Accessing the components behind the armature will require the removal of the
rear chassis cover plate. To remove this plate, follow these steps.
1. Power OFF the unit, unplug it and remove the cover. See Cover. NOTE:
The steam generator may be hot if the unit has been operating.
2. Disconnect the fan connectors.
3. Disconnect the inlet and outlet tubes on the biological air filter.
4. Remove the three screws across
the top and the three screws
across the bottom of the plate.
5. Lift the plate to remove.
6. Reverse instructions to replace.

STATIM 7000 Service Manual – Keypad & LCD
8
4. Membrane Keypad and LCD
The membrane keypad and LCD contain circuitry that is static sensitive.
Always wear a static strap when working with or near this circuitry. Transport
electronic components in a static protected bag.
To replace the membrane keypad or LCD, perform the following steps:
1. With the unit off, unplug the power cord from the wall outlet and remove
the cassette and reservoir from the unit.
2. Remove the water filter or water bypass cartridge (if the unit is using
distilled water) from the reservoir area.
3. Remove the eight screws across the bottom front of the unit.
4. Push the cover forward from the back to loosen it.
5. Detach the LCD by reaching up
inside the cover through the
armature opening to feel for a
plastic tab located directly
behind the Rubber and Plastics
key.
Push this tab to the left to unlock the
LCD from the cover.

STATIM 7000 Service Manual – Keypad & LCD
9
6. Detach the LCD and place it on
the Armature
7. Push the cover all the way forward to slide it off from the front.
8. Disconnect LCD connection from controller board.
9. Disconnect the membrane keypad connection from the controller board.
10.Disconnect the other membrane keypad connection from the auxiliary
heater board.
11.Gripping the membrane keypad facedown and lengthwise with both
hands, gently bend the sides back to release the LCD from its holding
clips.
NOTE: The LCD and membrane keypad are considered separate
components.

STATIM 7000 Service Manual - Armature
10
5. Armature
To remove the armature, follow these steps:
1. Power OFF the unit, unplug it and
remove the cover. See Cover.
2. Remove the screws located in each of
the armature’s bottom corners.
3. Loosen the screw located at the
armature’s front top edge. NOTE: this
screw is very long and does not need to
be completely removed.

STATIM 7000 Service Manual - Armature
11
4. Slide the armature forward.
5. Reverse removal instructions to replace.

STATIM 7000 Service Manual - Isoplate
12
6. Isoplate
To remove the isoplate from the armature, follow these steps:
1. Remove the armature from the chassis and place it on a secure work
surface. See Armature.
2. The isoplate is secured in the
armature using screws with
washers, on the top and bottom
of the armature. Remove and
retain all the screws with
washers.
3. When all fasteners are removed, slide the isoplate out of the armature.
4. Reverse removal instructions to replace.

STATIM 7000 Service Manual – Steam Generator
13
7. Steam Generator
To remove the steam generator, follow these steps:
1. Power OFF the unit, unplug it and remove the cover. See Cover. NOTE:
The steam generator may be hot if the unit has been operating.
2. Disconnect the fan connectors.
3. Disconnect the inlet and outlet tubes on the biological air filter.
4. Remove the rear chassis cover plate by removing the three screws across
the top and three screws across the bottom, and lifting the cover plate.
5. Disconnect the steam generator thermocouple from the controller board.
6. Cut the tie wraps holding the steam generator thermocouple.
7. Disconnect black steam generator thermal fuse wire from controller board
connector terminal block.
8. Disconnect the white steam
generator thermal fuse wire from
the upper terminal in the steam
generator.

STATIM 7000 Service Manual – Steam Generator
14
9. Disconnect, at both ends, the
copper tubing connecting the
steam generator to the
auxiliary heater.
10. Disconnect the compression
nut from the Teflon™ inlet tube.
11. Remove the two screws that
hold the steam generator to
the chassis.
12. Remove the steam generator.

STATIM 7000 Service Manual – Steam Generator
15
13. Reverse removal instructions to replace.
14. After you install a new steam generator, calibrate the unit. See Calibration.

STATIM 7000 Service Manual – Steam Gen. Check Valve
16
8. Steam Generator Check Valve
To inspect the check valve, turn ON the compressor using the Control Box, and
allow the unit to run for a few minutes. Allow the unit to cool to the touch.
Remove and inspect the air filter, the bacteria retentive filter and the compressor.
See Compressor.
If there is evidence of water in the bacteria retentive filter, replace the steam
generator check valve and the filter.
If there is evidence of water in the compressor or if the compressor filter is wet,
replace the steam generator check valve, compressor and filters.
To Remove the Steam Generator Check Valve, follow these steps:
1. Turn the power switch OFF, and unplug the unit.
2. Carefully cut the cable tie holding the compressor tube onto the check
valve inlet and pull the tube off the valve.
3. Disconnect the check valve. NOTE: Apply the wrench to the part of the
valve closest to the steam generator.
To Replace the Steam Generator Check Valve, follow these steps:
1. Prepare the right angle fitting by wrapping the threads with Teflon™ pipe
fitting tape (minimum one complete wrap).
2. Thread the new valve onto the right angle valve fitting in the top of the
steam generator. Using a wrench on the end of the valve closest to the

STATIM 7000 Service Manual – Steam Gen. Check Valve
17
fitting, tighten the valve SNUG. Do not overtighten the new valve. Use a
wrench to hold the right angle brass fitting so it does not move.
3. Carefully push the compressor tube onto the check valve and secure the
tube to the valve using a high temperature application cable tie.
Install replacement filters as required.

STATIM 7000 Service Manual – Steam Gen. Thermal Fuse
18
9. Steam Generator Thermal Fuse
To remove the steam generator thermal fuse, follow these steps:
1. Power OFF the unit, unplug it and remove the cover. See Cover. NOTE:
The steam generator may be hot if the unit has been operating.
2. Disconnect the fan connectors.
3. Disconnect the inlet and outlet tubes on the biological air filter.
4. Remove the rear chassis cover plate by removing the 3 screws across the
top and 3 screws across the bottom, and lifting the cover plate.
5. Disconnect the black thermal fuse lead wire from Controller Board
connector terminal and the white wire from the steam generator.
6. Trace the path of the black wire back to the base of the steam generator.
Cut all the cable ties holding the black wire.
7. Disconnect the compression nut
holding the Teflon™ tube from
the top of the steam generator.
