Scientech Technologies 2703 User manual

SCR TriggeringTechniques
Scientech2703
LearningMaterial
Ver1.1
AnISO9001:2008 company
ScientechTechnologiesPvt. Ltd.
94, ElectronicComplex, Pardesipura, Indore-452 010 India,
[phone], : [e-mail] , : www.ScientechWorld.com

Scientech2703
ScientechTechnologiesPvt. Ltd. 2

Scientech2703
ScientechTechnologiesPvt. Ltd. 3
SCR TriggeringTechniques
Scientech2703
TableofContents
1. SafetyInstructions4
2. Introduction5
3. Features6
4. TechnicalSpecifications7
5. Theory8
6. Experiments
Experiment112
ToStudythetriggering ofSCR using UJT
Experiment214
ToStudythetriggering ofSCR using IC555
7. Datasheet17
8. Warranty23
9. ListofAccessories23

Scientech2703
ScientechTechnologiesPvt. Ltd. 4
SafetyInstructions
Readthefollowing safetyinstructionscarefullybeforeoperatingtheinstrument.To
avoidanypersonalinjuryordamagetotheinstrumentoranyproductconnectedtothe
instrument.
Donotoperatetheinstrumentifyoususpectanydamagewithin.
Theinstrumentshouldbeservicedbyqualifiedpersonnelonly.
Foryoursafety:
UseproperMainscord: Useonlythemainscorddesignedforthis
instrument.Ensurethatthemainscordis
suitableforyourcountry.
Ground theInstrument: Thisinstrumentisgroundedthroughthe
protectiveearthconductorofthemainscord.
Toavoidelectricshockthegrounding
conductormustbeconnectedtotheearth
ground.Beforemaking connectionstothe
inputterminals,ensurethattheinstrumentis
properlygrounded.
ObserveTerminalRatings: Toavoidfireorshockhazards,observeall
ratingsandmarksontheinstrument.
UseonlytheproperFuse: Usethefusetypeandratingspecifiedforthis
instrument.
UseinproperAtmosphere: Pleaserefertooperatingconditionsgivenin
themanual.
1. Donotoperateinwet/dampconditions.
2. Donotoperateinanexplosive
atmosphere.
3. Keeptheproductdustfree,cleanand
dry.

Scientech2703
ScientechTechnologiesPvt. Ltd. 5
Introduction
Scientech2703 isaplatformwhereStudentscanunderstandthevariousthyristor
firing techniquesbyusing IC555 andUJT. Thisisveryusefulforunderstanding of
pulsegeneration.2703 isprovidedwithinbuiltpowersupplies,socketsformaking
interconnectioninthecircuitandexhaustivelearningmaterial.

Scientech2703
ScientechTechnologiesPvt. Ltd. 6
Features
•InbuiltPowerSupply
•Easytooperateand understand
•Twotriggeringcircuitsonsingleboard
•Testpointstoobserveoutputpulses
•Socketstomakedifferentconnections
•OnboardDC sourcesof5Vand12 V

Scientech2703
ScientechTechnologiesPvt. Ltd. 7
TechnicalSpecifications
OnboardAC source: 18 V-0V-18 V
OnboardDC Supply: +5V, +12V
Onboardtriggeringcircuits:
555 ICtriggeringcircuit
UJTtriggering circuit
Interconnection: 2mm socket(Goldplated)
SCR : SCRsTYN616, 600V/16 A
Testpoints: 4nos(Goldplated)
Dimensions(mm): W420 xD255 xH100
PowerSupply: 110V-260VAC, 50/60Hz
Weight: 1Kg. (approximately)
OperatingConditions: 0-400C,80%RH
Learningmaterial: CD(Theory, procedure,referenceresults, etc),
Online(optional)

Scientech2703
ScientechTechnologiesPvt. Ltd. 8
Theory
TriggeringofSCR usingUJT
TheUJTis oftenusedasatriggerdevice forSCR’sandTRIAC’s. Themostcommon
UJT circuitinusetodayistherelaxationoscillator,whichisshowninfigure1.
Figure1
Thediode-resistance,resistance,resistance-capacitanceandthediode-resistance-
capacitance circuitproduce prolongedpulses, sopowerdissipationismoreatthegate.
Thepowerloss canbelimitedbytheuseofthisUJTinthefiring circuit.Pulse
triggeringispreferredasitoffersseveralmeritsoverRandRCtriggering.Gate
characteristicswidespread;pulses canbeadjustedeasilytosuitsuchawidespectrum
ofgatecharacteristics.Thepowerlevelinpulsetriggeringislowasthegatedriveis
discontinuous;pulsetriggering is thereforemoreefficient. Theabovefigure1iscalled
therelaxationoscillator.Theresistorandcapacitorconnectedtotheemitterforman
RC timing circuit. Normally, thevalueofcapacitorisfixedandthevalueofresistoris
ofpotentiometertype.Thecharging rateofthecapacitordependsonthevalueofthe
resistorandsince theresistorisvariabletheRCtimeconstantcanbecontrolled.
Whenthevoltageacross thecapacitorisequaltomorethanthepeakvoltageVPofthe
UJT, itstartsconducting.Since theUJThasanegativeresistance,itsvoltagestarts
decreasing up tothevalleyvoltage,andthecapacitordischargesup tothevalley
voltage.
Thisrepetitiveprocess producingatrainofpulsesatitsoutputisshowninfigure2.
Fromtheoutputvoltagewaveformitisclearthattheoutputpulseshasaverysmall
widthandthatalongrelaxationtimeexistsbetweenthetwopulses.Thereforeitis
saidthatthedeviceisrelaxedinthisdurationandiscalledtherelaxationoscillator.

Scientech2703
ScientechTechnologiesPvt. Ltd. 9
Figure2
Animportantdesignconsiderationinthistypeofcircuitconcernspremature
triggeringofSCR.Inthefiring circuitt1=R1C1aretimeconstantforcharging circuit
andt2=Ra3C1aredischarging timeconstant. Heret2 ismuchsmallerthant1. Resistance
R3shouldbesufficientlysmallsothatnormalleakagecurrentdropacross R3,when
UJT isoff,isnotabletotriggertheSCR. Inotherwords,
VBB.R3/RBB+R2+R3<SCR triggervoltage
WHERE,
RBB =RB1+RB2 (INTERNALRESISTANCE OFUJT BASES)
THEOUTPUTPULSEFROMUJTISCONNECTEDTOTHEGATE OFSCR.BY
USING APOTTHEGATE CURRENTCANBECONTROLLEDAND MONITOR
THEANODETOCATHODECURRENT. ITWILLSHOWATWHICHPOINT
THESCR ISGETTING TRIGGERED.

Scientech2703
ScientechTechnologiesPvt. Ltd. 10
TriggeringofSCR usingIC555:
TheAstableandMonostablecircuitsaresocommonlyrequiredthespecialmonolithic
ICcalledICtimers,havebeenmadeavailable.The555 IChasgainedwide
acceptance intermsofcostandversatility.SometypicalapplicationsareMonostable
andAstableMultivibrators,dc-dcconverters, digitallogicprobes,waveform
generators, Analogfrequencymetersandtachometers, temperaturemeasurementand
control,infraredtransmitters,burglarandtoxicgasalarms,voltageregulators,etc.
Thedevice 555 isamonolithictiming circuitthatcanproduce accurateandhighly
stabletimedelaysoroscillations.The555 ICisusedfortriggeringofSCR inbothdc
andac circuits.AnAstabletimeroperationisachievedbyaddingresistorRBtofigure
3andconfiguringasshowninfigure3.IntheAstableoperation,thetriggerterminal
andthethresholdterminalareconnectedsothataself-triggerisformed,operatingas
aMultivibrator.Whenthetimeroutputishigh,itsinternaldischargingTr.turnsoff
andtheVC1increasesbyexponentialfunctionwiththetimeconstant(RA+RB)*C.
WhentheVC1,orthethresholdvoltage,reaches2Vcc/3,thecomparatoroutputon
thetriggerterminalbecomeshigh,resettingtheF/Fandcausing thetimeroutputto
becomelow.ThisinturnturnsonthedischargingTr.andtheC1dischargesthrough
thedischargingchannelformedbyRB andthedischargingTr.WhentheVC1falls
belowVcc/3,thecomparatoroutputonthetriggerterminalbecomeshighandthe
timeroutputbecomeshighagain.ThedischargingTr.turnsoff andtheVC1rises
again.
Intheaboveprocess,thesectionwherethetimeroutputishighisthetimeittakesfor
theVC1torisefromVcc/3to2Vcc/3, andthesectionwherethetimeroutputislowis
thetimeittakesfortheVC1todropfrom2Vcc/3toVcc/3.Whentimeroutputis
high, theequivalentcircuitforchargingcapacitorC1isasfollows:
Figure3
Figure4

Scientech2703
ScientechTechnologiesPvt. Ltd. 11
Since thedurationofthetimeroutputhighstate(tH)istheamountoftimeittakesfor
theVC1 (t)toreach2Vcc/3,
TheequivalentcircuitfordischargingcapacitorC1,whentimeroutputislowis,as
follows:
Figure5
Since thedurationofthetimeroutputlowstate(tL)istheamountoftimeittakesfor
theVC1(t)toreachVcc/3,
Since RDisnormallyRB>>RDalthoughrelatedtothesize ofdischarging Tr.,
tL =0.693RBC1(10)
Consequently,ifthetimeroperatesinAstablemode,theperiodisthesamewith
'T=tH +tL=0.693(RA+RB)C1+0.693RBC1=0.693(RA+2RB)C1'becausetheperiod
isthesumofthechargetimeanddischargetime. Andsince frequencyisthe
reciprocaloftheperiod,thefollowing applies.
THEOUTPUTPULSEFROMUJTISCONNECTEDTOTHEGATE OFSCR.BY
USING APOTTHEGATE CURRENTCANBECONTROLLEDAND MONITOR
THEANODETOCATHODECURRENT.ITWILL SHOWATWHICHPOINT
THESCR ISGETTING TRIGGERED.

Scientech2703
ScientechTechnologiesPvt. Ltd. 12
Experiment1
Objective:
Tostudythetriggering ofSCR using UJT
EquipmentsNeeded:
1. PowerElectronicsBoard Scientech2703
2. Oscilloscope-Scientech803/831, orequivalent
3. 2mm patchcords.
4. Multi-meters
Circuitdiagram:
ThecircuitdiagramforTriggeringofSCR using UJT isshowninfigure6
Figure6

Scientech2703
ScientechTechnologiesPvt. Ltd. 13
Procedure:
•ConnectAmmeterbetweenpoint‘d’and‘c’tomeasureAnode-cathodecurrent
IAK (mA).
1. ConnectAmmeterbetweenpoint‘a’and‘b’tomeasurethegateCurrentI
g
(mA).
2. Connectvoltmeterbetweenpoint‘e’andgroundtomeasuretheanode-cathode
voltageVAK.
3. Rotatethepotentiometer‘P1’ fullyinclockwisedirectionand‘P2’ fullyin
counterclockwisedirection.
4. SwitchOnthepowersupply.
5. Varythepotentiometer‘P2’ inclockwisedirectionsoastoincreasetheanodeto
cathodevoltage. Setthisvoltageabove11V.
6. Varythepotentiometer‘P1’ incounterclockwisedirectionsoastoincreasethe
valueofgatecurrentinstepandmeasurethecorresponding valuesofanodeto
cathodecurrentIAK inanObservationTable1.
7. InitiallytherewillnotbeanycurrentflowacrosstheSCR,whilevarying the
gatecurrenttheammeterconnectedatpoint‘c’and‘d’suddenlyincreasesand
thevoltmeterconnectedatpoint‘e’andgroundwillsuddenlydecrease.This
showsthattheSCR istriggered.
8. Nowvarythe‘P1’, therewillnotbeanyeffectintheanode–cathodevoltageand
currentofSCR.
9. Torepeattheexperimentswitchoffthepowersupplyandfollowtheabove
procedurefromstep4.
ObservationTable:
SetVAK=+12V
S.No
Gatecurrent
IG(mA) Anodetocathode currentIAK(mA) Anodetocathode voltageVAK(V)

Scientech2703
ScientechTechnologiesPvt. Ltd. 14
Experiment2
Objective:
TostudytheTriggeringofSCR using 555 IC.
EquipmentsNeeded:
1. PowerElectronicsBoard Scientech2703
2. Oscilloscope-Scientech803/831, orequivalent
3. 2mm patchcords.
Circuitdiagram:
ThecircuitdiagramforTriggering ofSCR using555 ICisshowninfigure7as
follows:
Figure 7

Scientech2703
ScientechTechnologiesPvt. Ltd. 15
Procedure:
1. ConnectAmmeterbetweenpoint‘c’and‘b’tomeasureAnode-cathodecurrent
IAK (mA).
2. ConnectAmmeterbetweenpoint‘f’ and‘e’tomeasurethegateCurrentI
G
(mA).
3. Connectvoltmeterbetweenpoint‘a’andgroundtomeasuretheanode-cathode
voltageVAK.
4. Rotatethepotentiometer‘P1’ fullyinclockwisedirectionand‘P2’ fullyin
counterclockwisedirection.
5. Switch‘On’thepowersupply.
6. Varythepotentiometer‘P2’ inclockwisedirectionsoastoincreasetheanodeto
cathodevoltage. Setthisvoltageabove11V.
7. Varythepotentiometer‘P1’ incounterclockwisedirectionsoastoincreasethe
valueofgatecurrentinstepandmeasurethecorresponding valuesofanodeto
cathodecurrentIAK inanObservationTable1.
8. Initiallytherewillnotbeanycurrentflowacross theSCR whilevarying thegate
currenttheammeterconnectedatpoint‘c’and‘d’suddenlyincreasesandthe
voltmeterconnectedatpoint‘e’andgroundwill suddenlydecrease.Thisshows
thattheSCR istriggered.
9. Nowvarythe‘P1’,therewillnotbeanyeffectintheanode-cathodevoltageand
currentofSCR.
Torepeattheexperimentswitchoff thepowersupplyandfollowtheprocedurefrom
step4

Scientech2703
ScientechTechnologiesPvt. Ltd. 16
ObservationTable:
SetVAK =+12V
S.No
Gatecurrent
IG(mA) Anodetocathode currentIAK (mA) Anodetocathode currentVAK (V)

Scientech2703
ScientechTechnologiesPvt. Ltd. 17
Datasheets
BocaSemiconductorCorp. (BSC)
PNUnijunctionTransistors
SiliconPNUnijunctionTransistors
..DesignedforuseInpulseandtiming circuits,sensing circuitsandthyristortrigger
circuits. Thesedevicesfeature:
1. LowPeakPointCurrent-2 µA(Max)
2. LowEmitterReverseCurrent-200 nA(Max)
3. PassivatedSurface forReliabilityandUniformity
MaximumRatings (TA=25°Cunless otherwisenoted.)
"IndicatesJEDECRegisteredDate.

Scientech2703
ScientechTechnologiesPvt. Ltd. 18
Notes:
Derate3mW/°CincreaseInambienttemperature.ThetotalPowerdissipation
(availablepowertoEmitterandBase-Two)mustbelimitedbytheexternalcircuitry.
1. Capacitordischarge-10µForloss, 30 voltsorloss.

Scientech2703
ScientechTechnologiesPvt. Ltd. 19

Scientech2703
ScientechTechnologiesPvt. Ltd. 20
