ScienTECH 6205SB User manual

IoT Enabled Smart Building
Scientech 6205SB
Product Tutorial
Ver 1.0
Designed & Manufactured by-
An ISO 9001:2008 company
Scientech Technologies Pvt. Ltd.
94, Electronic Complex, Pardesipura, Indore - 452 010 India,
+ 91-731 4211100, : [email protected] , :www.ScientechWorld.com

Scientech 6205SB IoT Enabled Smart Building
`2
Scientech 6205 IoT Enabled Smart Building
Table of Contents
1. Introduction 4
2. Features 5
3. Technical Specifications 7
4. Scope of learning 9
5. Smart Sensor Gateway Node Details 10
6. Theory 19
7. Sensor hardware and connection details
8. Installing CH340G Driver
9. Installing Arduino Software
10. Configuration of IP Camera 29
11. Quick Guide
12. Assignments
●Assignment 1 48
To make a basic LED blink program using Arduino.
●Assignment 2 51
To make ADC and UART program in Arduino.
●Assignment 3 53
To Program for on board LCD.
●Assignment 4 55
Testing and understanding PIR sensor with relay light.
●Assignment 5 57
Testing and understanding temperature and humidity sensor.
●Assignment 6 59
Testing and understanding CO2sensor.
●Assignment 7 61
Testing and understanding LPG sensor with relay light.
●Assignment 8 63
Testing and understanding smoke sensor with relay light.

Scientech 6205SB IoT Enabled Smart Building
`3
●Assignment 9 65

●Assignment 10 67
To make a program to control lights of Scientech 6205SB using
RFID tags
●Assignment 11 69
To receive data string wirelessly from Scientech6205SB using
Zigbee and Display it in Serial Monitor of Arduino
●Assignment 12 71
To implement an Arduino program to collect the sensors data from
Smart Sensor Gateway and send it to free cloud using ESP8266.
13. Warranty 78
14. List of Accessories 79

Scientech 6205SB IoT Enabled Smart Building
`4
Safety Instructions
Read the following safety instructions carefully before operating the product.
To avoid any personal injury, or damage to the product, or any products connected to
it;
Do not operate the instrument if you suspect any damage within.
The instrument should be serviced by qualified personnel only.
For your Safety:
Use proper Mains cord : Use only the mains cord designed for this product.
Ensure that the mains cord is suitable for your
country.
Ground the Instrument : This product is grounded through the protective earth
conductor of the mains cord. To avoid electric shock
the grounding conductor must be connected to the
earth ground. Before making connections to the input
terminals, ensure that the instrument is properly
grounded.
Observe Terminal Ratings : To avoid fire or shock hazards, observe all ratings and
marks on the instrument.
Use only the proper Fuse : Use the fuse type and rating specified for this product.
Use in proper Atmosphere : Please refer to operating conditions given in the
manual.
1. Do not operate in wet / damp conditions.
2. Do not operate in an explosive atmosphere.
3. Keep the product dust free, clean and dry.

Scientech 6205SB IoT Enabled Smart Building
`5
Introduction
With advances in technology, there is a constant demand for improvement in standard
of living, security and energy efficiency. Every building be it residential, commercial
or industrial runs on some or the other form of energy, thus there is a need to reduce
and optimize this energy consumption. Efficient energy management not only reduces
consumption but also reduces energy costs.
Scientech 6205SB IoT Enabled Smart Building training setup is specially designed to
help understand the concept of smart buildings and how various sensors can be
deployed and their data can be used to generate events and trigger alarms. Scientech
smart building comes with various sensors. The data from these sensors can be used
to generate various events like switching on and off lights, triggering an alarm,
providing access to a user using RFID tags and readers. This product helps explore
various aspects of smart building intended to optimize energy usage and security.
Scientech 6205 Smart building complete set

Scientech 6205SB IoT Enabled Smart Building
`6
Features
●Platform to learn, explore, and develop IoT skills.
●Three floors with six blocks table top building structure.
●Each block of building with LED lights.
●Arduino software compatible hardware.
●LPG gas, smoke, fire, PIR, temperature, humidity, and CO2sensors.
●RFID module for access control application.
●Touch switch panel with 4 power sockets and bulb intensity control output.
●Wi-Fi camera interface.
●Battery smart sensor gateway for sensor connectivity.
●USB and zigbee connectivity for personal computer (PC) interface.
●Wi-Fi connectivity for cloud interface.
●Sensor gateway with color LCD display.
●Buzzer and input/output switch for testing.
●Wi-Fi connectivity and android app for field testing.
●eal time graph analysis on PC and mobile.
●10 din sockets for sensors and actuators interface.
●On board charging and protection circuit for battery.
●Signal test points and switch fault.
●Inbuilt voltmeter and ammeter.
●Compact tabletop ergonomic design.
●Ready experimental details.
●User friendly, self-explanatory system.

Scientech 6205SB IoT Enabled Smart Building
`7
Technical Specifications
Microcontroller : ATMega2560
Sensors and Actuator connector : 10nos.
Digital I/O Pins : 34
Analog Input Pins : 16
UART : 2 nos.
I2C : 1 no.
Switch faults : 30nos.
Test points : 30nos.
Power Supplies : 5V and 3.3V
Variable POT : 1 no (10K)
Switches : 3nos.
Digital Voltmeter and Ammeter : 0 - 25V/10A
Buzzer and LED : 1 no. each
Color LCD : 1.77 inch
Battery : 3.7V/4400mAh
USB : 2.0
Wi-Fi Module : 1no. (2.4GHz)
Zigbee Transceiver : 2nos. (2.4GHz/63mW)
Flash Memory : 256 KB of which 8 KB for bootloader
SRAM : 8 KB
EEPROM : 4 KB
Clock Speed : 16 MHz
Node operating voltage : 5V DC
Camera : Wi-Fi IP Camera
Touch Panel : 4 Switches, 1 Regulator
RFID Module with 5 cards : 125KHz
LPG Gas Sensor : MQ06
Smoke Sensor : MQ135
Fire Sensor : TTL
PIR Sensor : TTL
Temperature Sensor : 0 - 100 Degree Celsius
Humidity Sensor : 0 100 %RH
CO2Sensor : 0-2000ppm
Interconnection for modules : 2 mm patch cords and FRC cables
Power Supply : 110V - 260V AC, 50/60Hz
Weight : 3.5Kg (approximately)
Operating Conditions : 0-400C, 85% RH

Scientech 6205SB IoT Enabled Smart Building
`8
Smart Sensor Gateway Node Details
Scientech 6205SSG Smart Sensor Gateway is an all in one development platform for
embedded system and IoT with inbuilt Wi-Fi, XBee, LCD and USB for output of the
data as well as plenty of extra GPIO to interface sensors and actuators.
It has inbuilt microcontroller ATmega2560, 54 digital input/output pins (of which 15
can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a
USB connection, a power jack, an ICSP header, and a reset button.
It can be powered via the USB connection, Inbuilt Battery or with an external power
supply. The power source is selected automatically. The adapter can be connected by
plugging a USB Cable into the input of USB connector. Scientech6205SB has inbuilt
battery of 4400mah capacity and by switching on the power switch inbuilt booster
circuit will power the Scientech6205SB from battery.
The ATMega2560 used in Scientech 6205 SSG is a low-power CMOS 8-bit
microcontroller based on the AVR enhanced RISC architecture. By executing
powerful instructions in a single clock cycle, the ATmega2560 achieves throughputs
approaching 1 MIPS per MHz allowing the system designed to optimize power
consumption versus processing speed.
Note: To charge the battery power the system over USB port and keep the power
switch on. Maximum charging time is 5 hours and it has inbuilt battery charging and
protection circuit for low voltage.

Scientech 6205SB IoT Enabled Smart Building
`9
Programmable GPIO Pinouts:
Pins
GPIO
Description
Pin 1
A14
Analog Pin
Pin 2
D10
Analog Pin
Pin 3
D12
Digital Pin
Pin 4
D6
Digital Pin

Scientech 6205SB IoT Enabled Smart Building
`10
1. Potentiometer:
Scientech Smart Sensor Gateway comes with a built-in 10K Potentiometer.
2. Power Supplies and Ground
2.1 +5 V DC Supply:
Scientech Smart Sensor Gateway is provided with three (3) +5V power supply
pins that can be connected using patch cords.
2.2 +3.3V DC Supply:
Scientech Smart Sensor Gateway is provided with three (3) +3.3V power supply
pins that can be connected using patch cords.
2.3 GND:
Scientech Smart Sensor Gateway is provided with three GND (ground) pins that
can be connected using patch cords.

Scientech 6205SB IoT Enabled Smart Building
`11
Power LED:
The status of power supply in Scientech Smart Sensor Gateway can be determined by
the status of a built-in LED.

3. LCD: LCD used in Scientech 6205 is a full color 128x160 TFT LCD display
module. Three buttons up, down, enter are provided to move cursor up, down
and select an option respectively.
4.1 LCD Pinouts
Pins
GPIO
LCD Port
Description
Pin 1
D42
DATA0
LCD DATA Pins
Pin 2
D43
DATA1
Pin 3
D44
DATA2
Pin 4
D45
DATA3
Pin 5
D46
DATA4
Pin 6
D47
DATA5
Pin 7
D48
DATA6
Pin 8
D49
DATA7
Pin 9
D50
CS
LCD Chip Select
Pin 10
D51
RS
LCD Register Select
Pin 12
D52
EN
LCD Enable
Pin 13
D53
RESET
LCD Reset

Scientech 6205SB IoT Enabled Smart Building
`12
4.2 LCD Button Pinouts
Pins
GPIO
Button Name
Description
Pin 1
D6
UP
LCD Menu Button
Pin 2
D8
Enter
Pin 3
D10
Down
4. Voltage and Current Meter:
Scientech Smart Sensor Gateway is provided with an in-built voltmeter and ammeter
for user to enable easy testing and debugging.
Voltmeter Range: 0-25V
Ammeter Range: 0-10A
Values of voltmeter and ammeter are displayed on the panel.
Note:
●Always connect voltmeter parallel to the device across which potential is to be
measured.
●Always connect ammeter in series with the device through which current is to be
measured.
●Do not short ammeter to 5V supply.

Scientech 6205SB IoT Enabled Smart Building
`13
Pins
Voltmeter/Ammeter
Description
Pin 1
Voltmeter
V+
Pin 2
Voltmeter
V-
Pin 3
Ammeter
A+
Pin 4
Ammeter
A-
5. USB Port:
Scientech Smart Sensor Gateway is provided with a USB port which can be used to
connect to any system and can also be used for charging.
6. Buzzer:
Scientech Smart Sensor Gateway comes with a built-in buzzer that can be connected
using patch chord. This buzzer can be used as an actuator which responds to the
change of state in sensors.
7. LED:
Scientech Smart Sensor Gateway comes with a built-in LED that can be used as an
actuator. It can be used for testing and debugging.

Scientech 6205SB IoT Enabled Smart Building
`14
8. CN1 and CN2 Box Connectors:

Scientech 6205SB IoT Enabled Smart Building
`15
9. Fault Switches and Test Points Pinout:
Switch
Pins
GPIO
GPIO
SW1
Pin 1
A0
VCC
Pin 2
D2
Pin 3
A1
Pin 4
N/C
SW2
Pin 1
A2
GND
Pin 2
D3
Pin 3
A3
Pin 4
N/C
SW3
Pin 1
A4
D22
Pin 2
D4
Pin 3
A5
Pin 4
N/C
SW4
Pin 1
A6
D23
Pin 2
D5
Pin 3
D7
Pin 4
N/C
SW5
Pin 1
D21
D24
Pin 2
D20
Pin 3
A8
Pin 4
N/C

Scientech 6205SB IoT Enabled Smart Building
`16
SW6
Pin 1
A9
D25
Pin 2
D6
Pin 3
D11
Pin 4
N/C
SW7
Pin 1
A10
D26
Pin 2
D16
Pin 3
D17
Pin 4
N/C
SW8
Pin 1
A11
D27
Pin 2
D18
Pin 3
D19
Pin 4
N/C
SW9
Pin 1
A12
D28
Pin 2
D8
Pin 3
D7
Pin 4
NA
SW10
Pin 1
A13
D29
Pin 2
D10
Pin 3
D9
Pin 4
N/C

Scientech 6205SB IoT Enabled Smart Building
`17
DIN Connector Pinouts:

Scientech 6205SB IoT Enabled Smart Building
`18
I2C Pinouts
Connector
Pins
GPIO
Button Name
Description
Connector E
Pin3
Pin 3
D20
SDA
Serial DATA Line
Connector E
Pin2
Pin 2
D21
SCL
Serial Clock Line
Serial Pinouts (UART)
Device
Arduino Serial
Pins
GPIO
Description
USB
Serial(0)
NA
D0
RX of Controller
NA
D1
TX of Controller
Connector H
Serial(1)
Pin 3
D18
TX of Controller
Pin 2
D19
RX of Controller
Xbee Module
& Connector
G
Serial(2)
Pin 3
D16
TX of Controller
Pin 2
D17
RX of Controller
Wi-Fi Module
(ESP 8266)
Serial(3)
NA
D14
TX of Controller
NA
D15
RX of Controller

Scientech 6205SB IoT Enabled Smart Building
`19
Theory
Scientech 6205 Smart Building
Scientech 6205 Smart Building
1. Smart Touch Panel:
The built-in touch switch panel in Smart Building is programmed to enable easy
user control .It provides the user accessibility and control over various devices
such as lights etc.
This panel can be used to change state of lights in rooms of the smart building
and can also be used to control analog devices such as fans (speed), the output
of which can be seen as a function of intensity of light of the bulb connected to
the bulb holder of the Smart Building.

Scientech 6205SB IoT Enabled Smart Building
`20
2. RFID module:
RFID module is generally used for access control in smart building. Passive
RFID tags are used for communication with the RFID reader. The tags are read
and if their ids match with the ids stored in the database; access is provided.
RFID modules are therefore important from security and access control point of
view.
3. Bulb Holder:
Scientech 6205SB comes with a built-in bulb holder. A bulb connected onto this
            
affects the intensity of light of the bulb. This variation in the intensity of
brightness of bulb can be easily linked to variation of fan speed which is
controlled using a regulator.
