Sculpt AXIS I1000 Operation manual

1
1. PREFACE
2. SPECIFICATIONS AND CLEARANCES
3. PRELIMINARY INSTALL GUIDE
4. INSTALL GUIDE
5. OPERATION & MAINTENANCE
6. TEST REPORTS
7. WARRANTY
8. FINAL WORDS
I1000 | I1000DS FREESTANDING
INSTALLATION & USER GUIDE
AXIS
NOTICE TO INSTALLER:
These instructions must be left with the owner, who should keep them for future use.
Edition: 26/10/2022

2
COMPLIANCE PLATE AND SERIAL NUMBER.
The instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions.
Please ensure to download the latest version of this manual from our website: www.sculptreplaces.com.au/installation-manuals/
© Copyright 2021 Sculpt Fireplaces Collection

3
Thank you for choosing Sculpt Fireplaces as your heater of choice.
Your replace is the result of careful design, artisan engineering and safety tests.
If it is properly installed, used and maintained, you may be sure that you will have an outstanding
heating feature in your home for years to come.
We advise you to read through this guide in order to become acquainted with the installation
methods specic to your replace.
It is recommended that this replace be installed by a qualied and licensed trades professional.
You will nd in this guide the answers to most of your questions, should you require further
assistance we recommend you contact your retailer.
Before igniting your replace for the rst time, please carefully read this manual.
Follow @sculptreplacecollection on Instagram, SculptFireplaceCollection on Facebook and be
sure to post your latest masterpiece installed with the hashtag #sculptres.
We hope we’ve helped make you the envy of your friends this winter and for years to come.
From all of us,
Sculpt Fireplace Collection
CONGRATULATIONS!

4
IMPORTANT
Heating capacity of the following appliances are a guide only and refers to areas with 2.4m ceilings
and 6 or more star rated buildings. Heating output may vary depending on factors such as building
characteristics, quality of insulation, type of rewood used and climate zone.
All dimensions shown are approximate. Check all dimensions accurately prior to installation. In line with
our policy of continuous improvement, we reserve the right to alter specications without notice.
All units comply and MUST be installed to Australian & New Zealand Standard AS/NZS 2918:2018.
When in use some parts may become hot. A suitable re guard is recommended where very young,
elderly or inrm are concerned.
ALL FIREPLACES IN THIS MANUAL CONFORM TO AUSTRALIAN AND NEW ZEALAND STANDARDS
AS/NZS 2918:2018 DOMESTIC SOLID FUEL BURNING APPLIANCES & AS/NZS 4012/40132014.
The instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions.
© Copyright 2021 Sculpt Fireplaces Collection

5
2. SPECIFICATIONS
AXIS I1000 Single Sided
Solid steel rebox with rebricks
Up to 15 to 30 Squares*
1.2g/kg
66%
Secure swing door opening system
4.6m
197mm, 250mm, 200mm
Recommended for well insulated homes
10 year rebrick and 5 year rebox warranty**
180kg
Width: 1220mm Depth: 1055mm Thickness: 9mm
***
Material
Heating Capacity
Avg Emissions
Avg Eciency
Glass Door
Minimum Flue Height
Flue Dimensions
Outside Air Kit
Warranty
Weight
Minimum Hearth Dimensions
* Heating capacity of the following appliances are a guide only and refers to areas with 2.4m ceilings
and 6 or more star rated buildings. Heating output may vary depending on factors such as building
characteristics, quality of insulation, type of rewood used and climate zone.
** See warranty pg. 23 of the manual
*** Refer to pg. 6 for further details about the clearances & hearth
100
58,8
33,5
83
50,65
FRONT SIDE
450mm
1000mm
833mm
340mm
587mm

6
2. SPECIFICATIONS
This appliance and ue were tested at the following clearances.
The Axis I1000 Single sided free standing appliance and 8”ue system with a painted solid casing
between the appliance and ceiling conforming to joint Australian/New Zealand Standards 2918:2001,
Appendix B.
A minimum 1055mm deep X 1220mm wide and 9mm non-combustible hearth should be installed,
see joint AS/NZs 2918:2001 3.3.2). The oor protector (hearth) should extend 550mm in front of the
appliance fuel loading door and be placed centrally in the 1220mm width.
***The appliance must be elevated a minimum of 250mm above the hearth (on a non combustible
surface). If the heater is placed directly onto the hearth, the hearth dimensions required will be greater.
Please refer to AS/NZS 2918:2018 as per the minimum for a non-tested appliance.
Clearances & Hearth- Axis I1000 Single Sided
COMBUSTIBLE WALLS
COMBUSTIBLE WALLS
450MM
250MM
SWING DOOR
APPLIANCE
550MM
HEARTH
1055MM
1220MM
COMBUSTIBLE WALLS
COMBUSTIBLE WALLS
APPLIANCE
150MM 150MM
HEARTH
SWING DOOR
1055MM
1220MM
550MM
POSITION A PARALLEL POSITION
Diagram not to scale
POSITION B CORNER POSITION
Diagram not to scale

7
2. SPECIFICATIONS
AXIS I1000 DS Double Sided
Material
Heating Capacity
Avg Emissions
Avg Eciency
Glass Door
Minimum Flue Height
Flue Dimensions
Outside Air Kit
Warranty
Weight
Minimum Hearth Dimensions
Solid steel rebox with rebricks
Up to 15 to 30 Squares*
1.0g/kg
62%
2X Secure swing door opening systems
4.6m
197mm, 250mm, 300mm
Recommended for well insulated homes
10 year rebrick and 5 year rebox warranty**
180kg
Width:1220mm Depth:1605mm Thickness: 9mm***
100
58,8
33,5
83
50,65
FRONT SIDE
1000mm
588mm
340mm
506mm
830mm
* Heating capacity of the following appliances are a guide only and refers to areas with 2.4m ceilings
and 6 or more star rated buildings. Heating output may vary depending on factors such as building
characteristics, quality of insulation, type of rewood used and climate zone.
** See warranty pg. 23 of the manual
*** Refer to pg. 8 for further details about the clearances & hearth

8
2. SPECIFICATIONS
This appliance and ue were tested at the following clearances:
The Axis I1000 Double Sided free standing appliance and 8”ue system with a solid casing between the
appliance and ceiling conforming to joint Australian/New Zealand Standards 2918:2001, Appendix B.
A minimum 1055mm deep X 1220mm wide and 9mm thick non-combustible hearth should be installed,
see joint AS/NZS 2918:2018 3.3.2). The oor protector (hearth) should extend 550mm in front of the
appliance fuel loading door and be placed centrally in the 1220mm width.
Clearances & Hearth- Axis I1000 DS Double Sided
POSITION A PARALLEL POSITION
Diagram not to scale
***The appliance must be elevated a minimum of 250mm above the hearth (on a non combustible
surface). If the heater is placed directly onto the hearth, the hearth dimensions required will be greater.
Please refer to AS/NZS 2918:2018 as per the minimum for a non-tested appliance.

9
It is the users duty to make themselves aware of and apply all national or more restrictive local
standards and instructions (AS/NZS 2918:2018).
IMPORTANT
Prior to unpacking and installation ensure the appliance has not been damaged during transit. Please
ensure you check the glass, the door(s), the damper operation and the door locking mechanism
Before any work is carried out, as per local and national regulations and laws, this appliance MUST be
installed by a licensed professional as per AS/NZS 2918:2018.
IMPORTANT WARNING
It is strictly forbidden to use any combustible materials (ie: wooden framing, plaster, etc) near or around
this appliance. Any exception from this rule is a health and safety hazard which will result in a non-
compliant installation and a void of warranties.
Electrical cables and components must not be placed in the vicinity of the appliance as it is a re
hazard.
3. PRELIMINARY INSTALL GUIDE

10
For the installation and use of this appliance, the tter and the user should strictly adhere to local and
national regulations in addition to AS/NZS 2918:2018. The installer should comply with the instructions
and recommendations detailed in this manual. Safety and operation of the replace is directly
dependent thereon. The liability of the manufacturer can neither be retained nor assured following
failure of installation or incorrect use which does not comply with AS/NZS 2918:2018.
As each installation is unique, a qualied and licensed trades professional should take all required
preliminary precautions depending on the technical elements inherent to each job.
In-observance of the assembly instructions in conjunction with AS/NZS 2918:2018 entails the liability
of the person who carries it out.
As a result of faulty assembly, irrational use of parts or additional components that were not supplied
by the manufacturer, and/or modifying of the appliance or components will result in inferior or unsafe
operation. Should this occur the manufacturer bears no liability, and will result in a null and void product
warranty.
PRELIMINARY INSTALL INFORMATION
All images and diagrams in this manual are for installation reference purposes only and are not to
scale, the distributor and manufacturer bears no accuracy of these images and accepts no liability. The
purpose of these images and diagrams is to act as a guide in conjunction with the written components,
and are NOT to be used to instruct independently. The order of steps listed in this manual are
recommendation only.
It is strongly recommended that the licensed trade professional who is performing the installation of
this appliance, completely read and comprehend all instructions in this manual prior to proceeding.
Sculpt Fireplaces & Axis reserves the right to change these specications without prior notice.
PLEASE READ PRIOR TO INSTALL
ACCEPTABLE VARIANCE ALLOWANCE
Due to the production of these hand assembled and manufactured replaces, there is an acceptable
allowance of 3-5mm variance of the unit, including the door frame. This variance in production is non-
claimable under any warranties.
HEAT RESISTANT MATERIALS
Heat resistant materials must meet AS/NZS 2918:2018 clause 1.4.27 a material with an allowable
service temperature of 600° Celsius or greater.
3. PRELIMINARY INSTALL GUIDE

11
4. INSTALL GUIDE
Step 1. Ensure all components required are prepared.
Step 2. If a oor protector (hearth) is to be used, position now, refer to clearances (pg. 6 & 8) for a guide
on the appropriate positioning to accompany clearances and the oor protector (hearth).
Step 3. Position the appliance, refer to clearances (pg. 6 & 8) for minimum requirements.
Step 4. Prior to proceeding ensure both the rebox and hearth are xed in position.
Step 5. Refer to Flue System Installation (pg. 13) & AS/NZS 2918:2018.
PART A  FIREBOX INSTALLATION
Prior to proceeding with installation thoroughly investigate the materials composing the surrounding
back walls, oor and ceiling of the desired position of the rebox. Combustible heat degrading
materials, electric wiring or gas piping MUST NOT be located within the distance specied by the
clearances (pg. 6 & 8). Ensure the ooring can support the weight of the appliance (see weight in
specications). ALL preparatory work required prior to installing the rebox (external air intake etc)
must be completed before proceeding with installation.
We strongly recommend installing the appliance in a weather tight room. Dust from works may be
deposited on the appliance and burned when it is commissioned, causing ceilings to blacken. It is
therefore recommended that all preparatory works be completed prior to installing the appliance.
FIREBOX LOCATION

12
4. INSTALL GUIDE
AXIS I1000
BENCH *MIN 250MM HEARTH MIN 9MM THICK
ROOF CAVITY
CEILING PLATE
DROPPER BOX
MIN 150MM BELOW
CEILING
TRIPLE SKIN FLUE
BRACES
TO SUPPORT FLUE
ROOF FLASHING
VENTED COWL
COVER CONE
FLUE OUTER
BOTTOM LENGTH
OF FLUE MUST
BE VENTED
FLUE INNER
ROOF LINE
INTERIOR ROOF
FLUE
This diagram is not to scale, the author of this manual bears no liability to the misinterpretation of this diagram.
MIN 1000MM
CLEARANCE MIN 3000MM IN ALL DIRECTIONS
*The appliance must be elevated a minimum of 250mm above the hearth (on a non combustible surface). If the heater is
placed directly onto the hearth, the hearth dimensions required will be greater. Please refer to AS/NZS 2918:2018 as per
the minimum for a non-tested appliance.

13
4. INSTALL GUIDE
Listed below are the general instructions for ue system install, please refer to these during the ue
installation process.
• Inner active ue installed crimped/narrow end down
• Outer casing installed crimped/narrow end up (critical when exposed above the roof line).
• Flue pipes, seal all joints including at rebox spigot. Fix with a minimum of 3 stainless steel rivets.
• Flue pipe spaces, ax to ue pipe.
• Flue system termination point (Refer to AS/NZS 2918:2018 4.9.1)
• Overall ue height (from he hearth to the ceiling extension) must be a minimum of 4.6m as per AS/
NZS 2918:2018 4.9.1(a)
• Roof penetration and ashing method refer AS/NZS 2918:2018
The specications contain our recommendations for the ue diameter and height values (total height
from the wood heater evacuation). The inner surface area of the ue to which the inset wood heater is
connected must be equal to the wood heater evacuation surface area.
IMPORTANT
It is the installers duty to check that the ue is compliant with all relevant regulations and standards.
For the appliance to operate at it’s prime, the draw must be controlled and be between 12 and 20
pascals. In the case of negative pressure hood using mechanical extraction, the air-tightness of the
connecting ue, including its junction, must be such that smoke cannot be sucked into the extractor.
Step 1.Locate the appliance in position or by measuring at the ceiling, ensuring the ue pipe is in centre
position.
IMPORTANT: Ensure you check that the outer casing is unobstructed prior to proceeding with the
installation.
Step 2. Spike the centre with a nail. Transfer this position to the next surface above.
Step 3. Cut the ceiling penetration (as required), perform the same at the roof penetration.
Step 4. Frame the penetration with roong material or timber as required. Refer to minimum
requirement for roof penetration AS/NZS 2918:2018.
Step 5. Install the lower casing so that the lower end is ush with the underside of the ceiling material
and with the addition of the metal “L” brackets, ax to the outer casing at 90.
Step 6. Flash the outer casing to the roof material with the appropriate approved ashing.
Step 7. If using an outer/inner casing combination, now install the inner casing ensuring it extends a
minimum 1000mm above the high side of the roof line.
Step 8. Prepare the ceiling plate and place upside down over the ue spigot.
Step 9. Extend the ue pipe above the outer casing to suit the casing cover/cowl assembly.
Step 10. Install the cowl assembly (cover cone and cowl).
Step 11. Position and secure the ceiling plate with the screws and spacers.
Step 12. Clean the ue pipe to ensure all marks (nger or otherwise) are removed prior to proceeding.
Step 13. If ue oset is required, refer to AS/NZS 2918:2018 4.1
**IMPORTANT**
Please note the ue should not include more than two 45° bends. The angle of these bends cannot exceed
more than 45° and can have no more than one length of 900mm ue between them.
FLUE SYSTEM INSTALLATION
PROCESS FOR FLUE SYSTEM INSTALLATION

14
4. INSTALL GUIDE
These instructions are to be kept by the user, the installer under any circumstances MUST NOT dispose
of this manual. Following installation it is recommended the installer review any questions or queries
the new user might have, this should include lighting the re and explaining the various functioning
components of the appliance. Insist on the wood quality, on the need to light the re correctly and have
correct combustion in order to avoid all problems related to smoke emission in the room or blackened
glass.
THESE INSTALLATION INSTRUCTIONS ARE AN INTEGRAL PART OF THE APPLIANCE AND
SHOULD BE KEPT INDEFINITELY, SHOULD THE UNIT BE SOLD THIS MANUAL SHOULD
ACCOMPANY THE UNIT.
COMMISSIONING THE APPLIANCE
COMBUSTION AIR
DIRECT OUTDOOR AIR CONNECTION INDIRECT OUTDOOR AIR CONNECTION
SINGLE SIDED DOUBLE SIDED
FLUE FLUE
EXTERIOR WALL EXTERIOR WALL
I1000 I1000DS
AA
B
OR
This appliance cannot operate in a de-pressurised room.
The presence of a hood, mechanically controlled ventilation or another heating appliance requiring air in
a well insulated dwelling may cause disturbances (incorrect combustion, smoke drawn back into the
room, etc.). It is important that sucient quantity of air needed to burn the wood can be drawn from
the room. When the room’s air intake is insucient( well insulated houses - eg. 6 star or more rated), a
specic air intake must be installed in conjunction with the appliance (outdoor air kit).
In the case of an unconnected appliance, the air intake specic to the wood heater must have a
minimum 300cm2surface area. It must be located either directly outside, or in a room ventilated to
the outside, and must arrive at the base of the wood heater. It must be protected by a vermin proof
grate. Possible heat losses due to the creation of a duct that is too long should also be taken into
consideration.
It is preferable to connect to outdoor air in order to optimise combustion control. Depending on specic
building-related conditions (air tightness, presence of mechanically controlled ventilation, presence of a
kitchen hood, etc).

15
5. OPERATION & MAINTENANCE
This will make it possible to renew the air when the wood heater is in use and will guarantee that the
correct pressure is maintained inside the room. Ideally, this air intake should arrive under the wood
heater.
It is important to indicate that any future alteration of the usage conditions (installation of mechanical
ventilation, a hood or any other appliance requiring air, insulation works or weatherproong
improvements, etc.) may result in a malfunction such as the emission of smoke inside the room.
COMBUSTION AIR CONTINUED
SINGLE SIDED DIAGRAM

16
5. OPERATION & MAINTENANCE
OPERATION & USER GUIDE
IGNITION INSTRUCTIONS
Before any ignition ensure the damper and primary air is open in order to accelerate combustion and
evacuate the fumes. This adjustment should then be reduced as the re has stabilised in order to
maintain a longer re term and avoid any possible overheating. The door of the replace should be closed
in order to avoid any risk of back-ow.
Always slowly and gradually light the re; split wood and re starters are recommended. It is strictly
forbidden to use any volatile substances including; methylated spirits, gasoline, solvents or the likes as
these will result in a risk of explosion or thermal shocks by a sudden rise of temperature.
OPERATING THE WOOD BURNER WITH THE DOOR OPEN EXPOSES YOU TO MULTIPLE
HAZARDS FALLING EMBERS, SMOKE EMISSIONS IN THE ROOM, ETC.. ALWAYS OPERATE
THE APPLIANCE WITH THE DOOR CLOSED.
PRECAUTIONS FOR THE FIRST IGNITION - CURE WITH 10 SMALL FIRES
The rst ten res should be light, moderate and not overly loaded with wood. We recommend a small re
consisting of 3-4 logs weighing around 3kg in total.
PAINT
It is strongly recommended that no person(s) come into contact with the external faces of the appliance
without the protective gloves provided, this will avoid any ‘marking’on the paint surface prior to it being
cured. The paint will polymerise after several res. Do not scrub or clean the replace with any rough
surface (such as a sponge). In the case of accidental scratches, make several res until the paint is
cured, at which time you can delicately clean the outside of the appliance with a hot sponge. Do not
scratch or rub the replace while it is lit. It is recommended contact with the replace should be kept to
a minimum. Do not paint the replace using products NOT recommended by the supplier, please contact
your authorised dealer should you require further assistance.
Avoid scratches and markings on your appliance by not placing any objects on your appliance during
operation and when not in use.
VENTILATION
A strong burning smoke odour may be smelt during the rst several res, it is therefore recommended to
ventilate the premises by opening windows/doors in order for the paint to cure. This phenomenon will
disappear after these initial burns cycles.
LIGHTING THE FIRE
The re is started with the airways open. The re-lighting starter and the combustion control must allow
maximum air intake. In order to limit smoke emission, it is preferable to use the inverted or top-down re
lighting method (see illustration below). An initial load of 3kg of wood provides a good layer of embers.

17
5. OPERATION & MAINTENANCE
OPERATION & USER GUIDE CONTINUED
Before establishing the rst re, remove all labels or equipment parts located in the ash box or in the
furnace.
While building your rst re, keep the combustion rate at a moderate level to ensure that the sealant binds
with the paint. All materials should be seasoned.
Please note: Before building a big re, establish several res. The curing process is necessary to ensure
that the paint is not damaged and that the insert is well seasoned.
Do not overload the furnace. The optimum amount of fuel should not exceed one third (1/3) of the insert
volume. Before reloading, make sure that the re has subsided. This will keep the replace from over-
ring.
Flow of air can be regulated by the damper controls at the front of the unit.
Except for the short time required to build a re, the replace door should be fully closed. If doors are left
partly open, ue gas may be drawn out of the opening creating risks from both re and smoke.
ESTABLISHING THE FIRST FIRE
IGNITION INSTRUCTIONS (continued)
After an extended time of non-use, it is recommended that the rebox be checked and cleaned by a
professional to ensure there is no obstruction in the ue and no blocking of the manoeuvring members
(damper) before ignition.
DAMPER AIR CONTROLS
The best way to control the re is to completely close the primary air slide and to adjust the speed with
the air ow control. If the air supply seems sucient you can partially open the primary air slide for a
while. The more air you will supply into the stove, the more intense your re will be, but with a shorter time
of combustion. On the contrary, a reduced quantity of air would increase the combustion with less heat
output.
Primary air slide
Door handle
IMPORTANT
This replace has a decorative outer casing which is not designed to have anything resting on top.
Do not place wood, pots, or any other items on top of the replace.

18
5. OPERATION & MAINTENANCE
IMPORTANT
Ventilation devices which operate with the replace on the same premises or on the premises which
share the same ventilation shaft may not function properly.
Please ensure the air grate is never blocked.
During installation please allow for access to have the replace and the connecting shaft cleaned.
If required, install cut-o and stiing devices.
RECOMMENDED FUEL
This replace is designed for only wood fuel. Any fuel other than wood is strictly forbidden.
As a general rule it is recommended; use dry, well-seasoned HARD WOOD with a 15% moisture content or
less in order for the unit to burn eectively and avoid any tarring. The heating output of wood depends on
the moisture percentage.
DIRECTLY CUT
3 MONTHS
6 MONTHS
9 MONTHS
75%
48%
37%
36%
78%
62%
46%
38%
33%
18%
16%
15%
35%
27%
24%
24%
1 YEAR
1 1/2 YEAR
2 YEARS
2 1/2 YEARS
C CL L
C: Chunks L: Logs
AVERAGE WOOD DRYING TIME BASED ON MOISTURE CONTENT
If the wood is piled up loosely, it will burn faster because the necessary oxygen for the combustion will
easily reach every piece of wood. This piling is recommended if you want to heat over a short period of
time. When the wood is piled more compact, it will burn slower because the oxygen won’t reach all the
logs at the same time. This piling is recommended if you want to heat over a longer period of time.
IT IS FORBIDDEN TO OPERATE THIS FIREBOX WITH THE DOOR OPEN.
DOOR: Do not open the door too fast as this will create a suction of smoke inside the room.
ATMOSPHERIC CONDITIONS
Misty or foggy weather may possibly favour back-ow of the smoke, which may be a health hazard. In
this case only use the replace as is necessary.
For safety reasons, assemblies of appliances and accessories not provided or recommended by Axis or
Sculpt Fireplaces are NOT PERMITTED. Unsuitable equipment may cause dysfunctions and disorder upon
use.
EXTINGUISHING THE FIRE
Stop fuelling the re and let it burn out. The re should burn out without any constraints. Do not close the
air slides before the re is completely extinguished, otherwise it may release noxious gases.
CAUTION: Do not hang or install objects within 2m of the appliance. This includes paintings, photos,
televisions, and any other combustible material.

19
OPERATION & USER GUIDE CONTINUED
IMPORTANT WARNING
Storing any ammable materials (paper, linen, furniture, solvents, ammable liquids, spray containers,
gas bottle, etc.) close to the replace is strictly forbidden.
All these products should never be stored even for a short while in wood storages or recesses laid out
under or near the appliance.
CAUTION: The window, the front panel of the appliance, as well as all external faces including the
facade, will attain high temperatures (above 100°). Uninitiated persons, young children and infants
should be monitored at all times while in the vicinity of the appliance.
SLOW BURNING
Please be aware that this method may cause unburnt matter to accumulate in the ue system. This may
in the long term cause a chimney re. Our recommendation is to therefore avoid closing the damper and
primary air for an extended length of time. Use only dry hard wood with a maximum moisture content of
15% to assist in reducing creosote build up, and regularly light a high intensity re to burn o the build up.
A draught is created from the dierence in temperature between the interior and the exterior ue. The higher
the temperature inside the ue, the more intense the draught is. Before closing the air inlets and reducing
the combustion level in the stove for a slow burn, the temperature inside the ue must be high enough to
adequately draw all the ue gas.
CAUTION: Continuous and intensive slow burn operation may cause early deterioration of the appliance and
its components, as well as a chimney re if the ue has not been regularly cleaned.
TRANSITION PERIOD, INSUFFICIENT CHIMNEY DRAUGHT AND POOR WEATHER CONDITIONS
Pay attention to the operations of the insert during transition periods and/or when chimney draught is
insucient or when weather conditions are unfavourable, especially during severe cold weather. Such
conditions may cause ue gas to ow into the room. To prevent such a situation, you should reduce the
intensity of re by curbing the inux of air into the combustion chamber until smoke disappears. Afterwards
you may increase air ow monitoring for any appearance of smoke in the room.
MAINTENANCE
The vitro-ceramic glass can withstand temperatures of up to 750°C. If the glass breaks following a handling
error, it is not recommended to replace it using a material other than that supplied by the manufacturer. The
original glass quality must be used to maintain any warranty of the wood stove.
CLEANING THE GLASS
The window of the replace requires regular cleaning with specic products intended for this use. The use
of moist hard wood with a moisture content above 15% causes excessive creosote build up on the glass.
Once again we recommend only burning very dry hard wood.
We recommend waiting for the glass to cool before cleaning it. The use of products that are too aggressive
(eg. abbrasive cleaners) may lead to the deterioration of some of the wood heater parts. An eective and
ecological method of cleaning the glass is to use a piece of damp newspaper dipped in ash and then rinsing
with clean water. You can also use a commercially available glass cleaning product.

20
MAINTENANCE CONTINUED
FLUE & FIREBOX
Flues should be professionally cleaned and checked twice a year, including at least once during the peak
period of use and more if required. A professional should also check seals, door ropes, bae plates and all
consumable parts of the rebox and ue to ensure the unit is in safe working order.
DO NOT REMOVE THE BAFFLE EXCEPT WHEN PERFORMING A CHIMNEY SWEEP
CAUTION: Cracked and/or broken components (eg. glass panels or baes) may render the installation/
operation unsafe. Do not use the appliance if this is the case and contact your dealer.
ASH PAN
The ash pan should be emptied regularly in order to avoid any overow and clogging of the re grate. Use
the cold handle supplied and pull the ash pan from the appliance. You will nd some ashes catching in the
cavities between the ribs of the replate. This bed of ashes caught between the replate is essential as it
will create a more eective start up operation of the re.
FORBIDDEN FUELS
This appliance is not designed for burning the following fuels:
• Solid mineral fuels (all coals or similar)
• Liquid mineral fuels (Gasoline, fuel oil, solvents, drainage oils or similar)
• Methylated spirit
• Creosote-treated woods and too moist or green woods
• Paper or cardboard
• Wood workshop residues (Shavings, saw dusts or similar)
• Other forbidden fuels that may harm the appliance or the environment
CHIMNEY SWEEPING
Prior to using and installing into an existing chimney, it’s necessary to perform a chimney sweep and
ensure it’s clear of any build up (cresote, bird’s nest, etc). Chimney sweeps should be performed twice a
year, including at least once during the period of use.
CHIMNEY FIRES
Chimney res can be caused due to incorrect use of the appliance and lack of periodic cleaning.
Visible signs of a chimney re include:
• Abundant fumes
• Strong smell of soot
• Roaring in the ue
• Signicant increase in the temperatue of the ue
• Cinders ying out of the top of the ue
