Montigo H38DF-CLCR Instruction Manual
®
C US
Read and understand this manual.
Improper installation, adjustment,
alteration, service or maintenance
can cause serious injury, property
damage or even death. For
assistance or additional information
consult a qualified installer, service
agency or the gas supplier.
DANGER
XW2002
XW2004
Glass doors on gas fireplaces are
extremely hot while the fireplace is
on and remain hot even after the
fireplace has been turned off. Safety
screens are available and can reduce
the risks of severe burns. Please
keep children away from the fireplace
at all times.
CAUTION
Do not store or use gasoline or any
other flammable vapors and liquids in
the vicinity of this or any other gas
burning appliance. A fire or explosion
my occur causing serious injury,
property damage or even death.
WARNING
XW2006
Installer: Leave this manual with the
appliance. Do not remove.
Consumer: Retain this manual for
maintenance and future reference. Do
not Discard.
NOTICE
XW2012
IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier
from a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
NOTICE
XW2014
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
XG0213 020111
H38DF-CLCR
HL38DF-CLCR
HLS38DF-CLCR
Corner Unit
Resi
dential
Fireplace
Langley, BC V4W 4A1 | Ferndale, WA 98248
You must read and understand this
manual prior to installation, operation or
troubleshooting this appliance. Please
retain this owner’s manual for furure
reference and maintenance.
NOTICE
XW2010
XG0213 - 020111
INTRODUCTION ........................................................................3
BEFOREYOUSTART:................................................................4
SectionA:BeforeYouBegin...............................................4
Section1: Installation Overview and Product Dimensions .....................5
Clearances .........................................................................................6
Section2:FramingtheFireplace........................................6
NOTES FOR PLANNING VENTING: .........................................................7
Converting the unit from top vent to rear vent. ...................................... 7
CONVERTING TO TOP VENT / REAR VENT ..........................................7
Section3:TheDirectVentSystem.......................................7
INSTALLING A ROOF MOUNTED DIRECT VENT TERMINATION ........8
VENTING LAYOUT ..................................................................................... 8
Roof mounted Terminations ...................................................................8
VENTING COMPONENTS .........................................................................9
INSTALLING A WALL MOUNT, DIRECT VENT TERMINATION ...........10
(A) Installation of Termination with built in frame .................................10
(B) Installation of termination frame only at time of framing ................10
(C) Installation of termination frame in Masonry ..................................10
(D) Installation of termination from inside structure .............................10
(E). Installation of a termination shield for Vinyl Siding .......................10
VENTING LAYOUT ................................................................................... 11
Wall Mounted Terminations: Top Vent .................................................. 11
Wall Mounted Terminations: Rear Vent................................................12
VENTING COMPONENTS .......................................................................13
Connection and installation of vent components guidelines: ..............13
Heat Shields .......................................................................................14
Installing a Wall Mounted RHS102 Heat shield. .............................14
Installing a Wall Mounted RHS101 Heat shield. .............................14
Section4:Wiring.................................................................15
FUEL CONVERSION ................................................................................16
GAS PRESSURE ......................................................................................16
GAS CONNECTION .................................................................................16
Section5:InstallingtheGasLine......................................16
Section6:Finishing.............................................................17
Mantels & Surrounds .................................................................................17
Painting .......................................................................................17
Section7:RemovingtheDoor...........................................18
Remove the Horizontal Access Panel: .....................................................18
Installing the Front Door: ...........................................................................18
Installing the Logset ...................................................................................19
Installing the Ember Material .....................................................................19
Section8:InstallingtheAccessories................................19
Installing Firestones in N.G. (Natural Gas) Fireplaces .............................20
Installing Firestones in L.P. (Propane) Fireplaces ...................................20
StartupSequence:................................................................21
Operation .......................................................................................21
Section9:Lighting...............................................................21
Honeywell Intermittent Pilot .......................................................................21
SIT Nova 820 .......................................................................................22
Lighting Instructions: .............................................................................22
To Turn Off Gas To Appliance: ..............................................................22
Honeywell .......................................................................................23
Lighting Instructions: .............................................................................23
To Turn Off Gas To Appliance: ..............................................................23
Robert Shaw 24
Lighting Instructions: .............................................................................24
To Turn Off Gas To Appliance: ..............................................................24
General .......................................................................................25
Cleaning .......................................................................................25
Section10:CleaningandMaintenance............................25
Hi-Lo Burner .......................................................................................25
Adjustment: .......................................................................................25
Pilot Burner Adjustment:(SIT Nova 820). ...............................................25
Section11:ReplacementParts.........................................26
AppendixA:PowerVentLocations...................................27
AppendixB:Warranty..........................................................28
AppendixC:StateofMassachusetts................................29
Indicates a hazardous situation which, if not
avoided, WILL result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, COULD result in death or serious
injury or property damage.
Indicates a hazardous situation which, if not
avoided, WILL result in minor or moderate
injury.
Address practices that are important, but
not related to personal injury
DANGER WARNING
CAUTION NOTICE
XG0213 - 020111
Hot glass will cause
burns. Do not touch
glass until unit is cooled.
Never allow children to
touch glass.
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Congratulations on your purchase of a .
With over 30 years of experience, Montigo is committed to providing you
with a gas replace that is not only a beautiful addition to your space, but
that is also designed and manufactured to the highest safety, reliability and
engineering standards.
We strongly encourage you to read and carefully follow the instructions laid out
in this Installation, Operation and Maintenance Manual and retain it for your
future reference. Pay special attention to all cautions, warnings, and notices
throughout this manual intended to ensure your safety.
This manual covers installation, operation and maintenance. Lighting, operation
and care of this replace can be easily performed by the homeowner. All
installation and service work should be performed by a qualied or licensed
installer, plumber or gas tter as certied by the state, province, region or
governing body where the replace is being installed.
This installation, operation and maintenance manual is applicable to the
models described below. Refer to your rating plate to verify included options.
Throughout this manual instructions are applicable to all models designated
as unless otherwise noted in the Table.
The Montigo warranty will be voided by, and Montigo disclaims any responsibility
for, the following actions:
► Modication of the replace and/or components including Direct-Vent
assembly or glass doors.
► Use of any component part not manufactured or approved by Montigo
in combination with this Montigo replace system.
► Installation other than as instructed in this manual.
Consult your local Gas Inspection Branch on installation requirements for
factory-built gas replaces. Installation & repairs should be done by a qualied
contractor.
XG0213 - 020111
SectionA:BeforeYouBegin
The H*38C* Direct Vent replace must be installed in accordance with these
Instructions. Carefully read all the Instructions in this manual rst. Consult the Local
Gas Branch to determine the need for a permit prior to starting the installation. It is
the responsibility of the installer to ensure this replace is installed in compliance
with the manufacturers instructions and all applicable codes.
Determine the desired install location of your replace.
See Section 1, Dimensions on Page 5, and refer to the Framing Section 2 for
details.
Select the location of your termination and resulting vent run.
Your selected termination location must be the highest point in the Direct Vent
installation.
Should it be impossible to meet the venting requirements laid out in Section 3:
Venting, please contact Montigo regarding the use of a Montigo Power Vent.
Lay out the Vent run; calculating the required elbows and straight runs of 5"/8"
ex or rigid pipe.
Layout Electrical Requirements Refer to Section 4: Wiring for Details.
Refer to Section 5: Installing the Gas Line for details on the gas connection
and access.
Refer to local codes and guidelines for installation requirements.
Installation and repairs should be done by a qualied contractor and must
conform to:
• Installations in Canada must conform to the current CAN/CGA B-149.1
and .2 Gas Installation Code and local regulations.
• Installations in the USA must conform to local codes, or in the absence
of local codes to the National Fuel Gas Code, ANSI Z223.1-1988.
• See Appendix C for installation within the State of Massachusetts. This
replace must comply with NFPA-54 Chapter 10.
Installation and repairs should be done by an
authorized gas fireplace service technician. The
appliance should be inspected before use and at
least annually by a professional. More frequesnt
cleaning may be required due to exessive lint from
carpeting, bedding material, ect. It is imperative
that control compartments, burners and circulating
air passageways of the fireplace are kept clean.
NOTICE
XW2016
XW2018
Due to high operating temperatures, this appliance
should be located out of traffic & away from
furniture and draperies.
Children and adults should be alerted to the
hazards of the high surface temperature, which
could cause burns or clothing ignition.
Young children should be carefully supervised
when they are in the same room as the appliance.
Clothing or other flammable materials should not
be placed on or near the appliance.
CAUTION
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
falling objects
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
Low temperature
Strong magnetic field
Optical radiation
Non ionizing
radiation
Radiation
Hazardous to the
Environment
Danger of harming
your hands
Irritant
Cutting
Watch your step
Slippery floor
High temperatures
Glass hazard
Danger of suffocation
High voltage
Toxic
Flammable materials
Corrosive
Fork lift trucks
Danger overhead crane
Explosion risk
Oxidising
Danger of death
Biohazard
Laser Radiation
Danger of entrapment
Hot surface
General Warning
Blank
Gas bottles
Watch for
Electricity
Danger for cutter
Entrapment hazard
Battery hazard
Rotating parts
When this appliance is installed directly
on any combustible material other than
wood flooring, it must be installed on a
metal or wood panel extending the full
width and depth of the appliance or a
fire will occur causing serious injury,
property damage or even death.
XW2020
DANGER
XW2020-When-Installed_[EN].pdf 1 1/24/2011 12:48:53 PM
XG0213 - 020111
Section1:InstallationOverviewandProductDimensions
20 5/16”
6 7/8 Vent
Ø 5”
Ø 8”
39 5/8”
Height 24 3/4”
Opening
6”
4”
3”
42 3/16” Width
25 1
/
2”
Depth
22 1/4”
Opening
33” Rear
Vent
Ø 5”
Ø 8”
20 5/16”
6 7/8 Vent
Ø 5”
Ø 8”
25 1/2”
Depth
22 1/4”
Opening
Ø 5”
Ø 8”
33” Rear
Vent
3”
39 5/8”
Height
24 3/4”
Opening
6”
4”
42
3/
1
6
” Width
39 1/4” Opening 39 1/4” Opening
H38DF CL (corner left) H38DF CR (corner right)
Top View Top View
H38DF CL (corner left) H38DF CR (corner right)
Front View Front View
H38DF CL (corner left) H38DF CR (corner right)
Side View Side View
Figure 1. Fireplace dimensions.
Please review the Pre-Installation Checklist on for general information on
preparing for a successful installation of your replace.
The replace may be installed in any location that maintains proper clearances
to air conditioning ducts, electrical wiring and plumbing. Safety, as well as efciency
of operation, should be considered when selecting the replace location. Try to
select a location that does not interfere with room trafc, has adequate ventilation
and offers an accessible path for Direct Vent installation.
The replace dimensions are shown below:
XG0213 - 020111
Section2:FramingtheFireplace
Frame in the enclosure for the unit with framing materials. The framed opening for
the assembled replace is 48 " wide, 44 " high, 25 1/4" deep, see Figure 2.
Figure 2. Framing dimensions.
Figure 3. Combustible Framing for shelves over the replace, Top vent. See
vent graph, Figure 15 for Top Vented, wall mounted terminations.
Figure 4. Combustible Framing for shelves over the replace, Rear vent.
See vent graph, Figure 16.
Clearances
When installing a shelf over the top of the replaces, the following guidelines
must be adhered to:
For Rear Vent applications, the minimum clearance is 1" from the rear of the
replace to a wall, or any combustible materials, and 13" clearance from the top
of the replace to the underside of any combustible shelf materials.
For Top Vent applications, the minimum clearance is 1" from the rear of the
replace to a wall, or any combustible materials, and 17 1/2" to the underside of
any combustible shelf materials.
To avoid elevated mantel temperatures, all H*38C* gas fireplaces
are required to have the supplied standoffs installed.
The replace is supplied with two standoffs. Bend and install these standoffs in
the channel directly behind the 4" nailing extension ensuring that the height of
the standoff maintains a 8" clearance.
Figure 6. Installing the H*38C* standoffs
Figure 7. The Nailing Flange Extension.
The supplied 4" nailing extension ships from the factory installed. The nailing
ange extension may be substituted with a piece of NON-Combustible material of
the same thermal characteristics, ie: cement board or equivalent to t the opening.
This is recommended in applications where the facing materials will not adhere
to the metal nailing ange.
48”
25¼” *43 ¾”
48”
25¼”
*43 ¾”
H38DF CL Corner Left H38DF CR Corner Right
* = Approximate Dimensions to center
For best results mount non-combustible stud onto unit
prior to installation, then bolt to 2 X 4 header and floor.
Non combustible
stud included with unit.
44” 44”
4”
Combustible Shelf
46”
Min. 44”
Exterior
Wall
17 1/2”
Min.
Combustible Header
90 elbow
1” Min.
4” Nailing flange (supplied) or
use Non-combustible material,
See figure 7.
Combustible
Shelf
59”
Min.
44”
Exterior
Wall
18”
Max.
90 elbow *
See Note:
C
ombustible
Header
1” Min
.
90 elbow
13”Min.
1” Min.
4” Nailing flange (supplied) or
use Non-combustible material,
See figure 7.
8”
Elbow must be installed directly off the back of the
fireplace. If additional horizontal distance is
required the vent run must be increased a 1:2
Horizontal to Vertical Ratio. See vent graph, Figure
16 for Rear Vented, wall mounted terminations.
NOTICE
XW2042
XG0213 - 020111
Section:3TheDirectVentSystem
Montigo supplies a variety of direct venting and termination options.
It should also be selected
such that it provides the shortest vent run possible. Should it be im-
possible to ensure that the termination is the highest point or should
it be impossible to meet the venting guidelines laid out below please
contact your Montigo dealer to discuss power venting options.
NOTES FOR PLANNING VENTING:
.
Converting the unit from top vent to rear vent.
Top vent.
CONVERTING TO TOP VENT / REAR VENT
Use the following instructions to convert an for Rear Vent use:
1. Remove the Rear ue cover and gasket (5" and 8") on the ue outlet, as
shown in Figure 7.
2. Next, Remove the Top ue collar's (5" and 8") on the ue outlet, as shown
in Figure 7.
3. Install the (removed) Rear ue cover and gasket material, to the Top vent
outlet. Fasten the cover with included hardware, as illustrated Figure 8.
4. Install the (5" and 8") collars to the rear vent outlet using the included hardware,
as illustrated Figure 8.
Figure 8. Flue cover and collar installation, Rear Vented replace.
Figure 7. Flue cover and collar removal, Top Vented replace.
Flue Gasket
Flue Cover Plate
8” Outer Flue Collar
5” Inner Flue Collar
Flue Gasket
Flue Cover Plate
8” Outer Flue Collar
5” Inner Flue Collar
XG0213 - 020111
INSTALLING A ROOF MOUNTED DIRECT VENT
TERMINATION
VENTING LAYOUT
The maximum termination point is 32’ above the replace (NOTE: if the
maximum termination height is used, the ame pattern may be affected).
The Vertical termination must be a minimum 2’ higher than where the
termination exits the roong materials, (asphalt shingles, cedar shakes, etc).
This distance should be measured from the high side of the roof slope where
the ue ashing intersects the roong materials. (see Figures 11 to 11c *).
Termination location must be a minimum 6’ from a mechanical air inlet.
Termination location must be a minimum 18” from a parapet wall.
A maximum of two offsets (each offset is made up of 2-90° bends) may
be made.
Install a restop at any location where venting passes through combustible
materials and construction.
Utilize support straps, or support plates, and rings (as required) to meet
acceptable building practices.
Install all roof ashing and storm collars as shown.
Figure 11. Top vent, Roof mounted termination with no offset in vent run.
Figure 11a. Top vent, Roof mounted with 1 offset (1 offset= two 90° bends).
Figure 11b. Top vent, Roof mounted with 2 offsets (1 offset= two 90° bends).
Roof mounted Terminations
The following details are some possible congurations for Roof
mounted terminations. See below.
Support ring
Support plate
Firestop
32’ max.
2’ min.
Obstacle
PVTK1
Termination
Support straps or
support plate & ring
2’ min.
Firestop
Firestop
Firestop
2’ max Support plate
& ring
Obstacle
PVTK1
Termination
Support ring
Support plate
Firestop
32’ max.
2’ min.
PVTK1
Termination
XG0213 - 020111
Section:
Figure 11c. Rear vent, Roof mounted venting (1 = 90° bend).
VENTING COMPONENTS
Use any combination of rigid and Flex pipe as required.
Flex sections may be stretched up to 50% of their total length (e.g. a 24”
section maybe stretched to 36”).
Connect all vent sections using a minimum of three sheet metal screws
on the outer pipe ue.
Ensure the pipe ends male to female slide in a minimum of 1 1/2” of overlap.
Ensure all runs are supported with a minimum of 3 supports per 10’ of venting.
When hanging/ supporting venting, ensure that 1” clearance is maintained
on sides and bottom of vent runs and 2” above horizontal vent runs to any
combustible material.
Ensure when cutting sections of rigid pipe to maintain integrity of internal
supports.
Place the springs, supplied with the pipe kit, between the outer and inner
pipes to keep the pipes separate and avoid any possible hot spots.
Montigo recommends the use of a ex section for the nal pipe connected
directly to the replace offering greater exibility of installation and absorption
of movement.
When penetrating a combustible ceiling, a ceiling restop must be used.
Firestops must be used in conjunction with Rigid Pipe only.
Montigo recommends that all exterior corners and joints be sealed with
exterior caulking however we encourage you to consult your Building
Envelope Engineer or Waterproong Consultant for further recommendations.
º
º
º
º
Support ring
Support plate 32’ M a.x
PVTK1
Termination
*18” Max. See
Note below
Storm Collar
Elbow must be installed directly off the back of the
fireplace. If additional horizontal distance is
required the vent run must be increased a 1:2
Horizontal to Vertical Ratio. See vent graph, Figure
16 for Rear Vented, wall mounted terminations.
NOTICE
XW2042
All venting material must be sealed with high heat
silicone sealant RV230. All venting material to be
Montigo flex pipe, with as few joints as possible.
All joints use MVA vent splice, sealed thoroughly
with silicone. Montigo will not be held responsible
for any water damage that may occur from not
installing the equipment as specified by this
document.
WARNING
XW2024
XG0213 - 020111
1
12”
2”
12”
12”
INSTALLING A WALL MOUNT, DIRECT VENT TERMINATION
(A) Installation of Termination with built in frame
A Termination with a Built-In Frame is installed during framing of a structure.
1. Frame the termination opening to 12" x 12".
2. Install exterior sheathing to the structure framing.
3. Fasten the termination to the sheathing using a minimum of 4 screws.
MSR Frame
PTO-3 (5"/8") or
PTO-4 (5"/8")
Termination
PTO-3F (5"/8") or
PTO-4F (5"/8")
Termination
Figure 13. Installing a PTO-F termination.
Figure 13a. Installing a PTO termination with the MSR frame.
Figure 14. Installing the VSS Vinyl Shield.
(E). Installation of a termination shield for Vinyl Siding
The VSS Termination shield is installed when the exterior of a structure is clad with
Vinyl siding. It is placed directly above, and on-center with the termination.
(B) Installation of termination frame only at time of framing
Terminations with a MSR frame allow the installation of the frame prior to installation
of the termination.
1. Frame the termination opening to 12" x 12".
2. Secure the MSR Frame to the exterior sheathing of the structure.
3. Fasten the termination to the MSR Frame using a minimum of 4 screws.
Figure 13c. Installing a PTO termination with the BSR frame.
(C) Installation of termination frame in Masonry
Terminations with a BSR frame allow the installation of the frame in masonry prior
to the installation of the termination
1. Frame the BSR opening to 12" x 12".
2. Secure the BSR Frame to the exterior sheathing of the structure.
3. Fasten the termination to the BSR Frame using a minimum of 4 screws.
1. Frame the MOSR opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs, concrete, or nished
wall construction using a minimum of 4 screws.
3. Insert the termination into the MOSR frame as shown here, (from the inside)
and attach to the MOSR by installing a min. quantity of 4 bolts into the threaded
nuts on the MOSR Frame.
(D). Installation of termination from inside structure
A Termination with a MOSR Frame is installed from the inside of the structure.
MOSR Frame
PTO-3 (5"/8") or
PTO-4 (5"/8")
Termination
Figure 13b. Installing a PTO termination with the MOSR frame.
BSR Frame
(5"/8")
Installing Heat Guards over Terminations is recommended in installations where the
termination is located within 7' feet above grade, or above a pedestrian walkway,
and may be Required by code in Public areas.
1. Ensure that the two longmounting brackets are facing the bottom of the
termination. (See inset). This will provide more heat protection at the top of
the termination, where temperatures are highest.
2. Attach to the faceplate of the termination using four sheet metal screws.
Figure 13c. Installing a PTO termination heat guard.
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
PTO-3 (5"/8") or
PTO-4 (5"/8")
Termination
Framing
Exterior
Sheathing
Fastening Hardware,
minimum 4-screws
12”
12”
Fastening Hardware,
minimum 4-screws
Framing,
concrete or other
materials
Exterior Sheathing,
concrete or other
materials
Exterior Vinyl siding
PTO-3 (5"/8") or
PTO-4 (5"/8")
Termination
VSS Vinyl shield
1
2”
12”
XG0213 - 020111
18”
46” Rigid
50” Flex
A
C
B
VENTING LAYOUT
Vent terminations must not be recessed in walls or siding.
All through-the–wall terminations within 58" Horizontal distance of the
replace must have a Montigo Heat Shield (RHS102) installed. See
All through-the-wall terminations beyond 58" Horizontal distance of the
replace must have a Montigo Heat Shield (RHS101) installed. See
Once the proposed venting layout has been determined refer to either
to ensure the layout is acceptable.
Wall Mounted Terminations: Top Vent
All dimension lengths for vertical or horizontal runs are measured from
center of the vent pipe.
Venting runs must fall within the limits set by the venting graphs, see Figure 15.
The Venting Graph
Measure the vertical height from the replace hearth to the centre of the termination
and the horizontal run from the replace ue collar to the wall ange of the termination.
Plot on the Venting Graph Figure 15 with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the installation is
acceptable.
If the vertical dimension from the hearth is 90" and the horizontal
run to the wall ange of the vent termination is 60", this would be
an acceptable installation.
If the vertical dimension from the hearth is 60" and the horizontal
run to the wall ange of the vent termination is 36", this would be
an acceptable installation.
If the vertical dimension from the oor of the replace is 60" and
the horizontal run to the wall ange of the vent termination is 144",
Wall mounted Terminations
The following details are some possible congurations for Wall
mounted terminations. See below.
If your installation does not fall
within the venting graph para-
meters, please contact Montigo
for Power Venting options.
Figure 15. Top Vent Venting Graph for wall mounted terminations.
Figure 15a. Top Vented, wall mounted installation with1 elbow (1 one 90°
bend). The vent run must comply with Venting Graph for Top vent, wall
mounted terminations, Figure 15.
Figure 15b. Top Vented, wall mounted Multi-elbow installation. See Venting
Graph for Top vent, wall mounted terminations, Figure 15.
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
Solid
Section
Flex
Section
Hearth
30”min RHS101 Heat
Shield
Termination
Exterior
Wall
RHS102 Heat
Shield
Termination
Hearth
Exterior
Wall
46” Min. Rigid Pipe
50” Min. Flex Pipe
18” Max
Flex section
XG0213 - 020111
59”
AC
B
64”
Figure 16. Rear Vent Venting Graph for wall mounted terminations.
If your installation does not fall
within the venting graph para-
meters, please contact Montigo
for Power Venting options.
Figure 16a. Rear Vented, wall mounted 2-elbow termination installation.
Installation for H*38C* must have a Minimum vertical rise of 59", and the
Horizontal distance must not exceed 64" from the replace.
If additional horizontal distance is required, the vent run must be increased at
a 1:2 Horizontal to Vertical Ratio.
Add elbows as required. The vent run must comply with the Venting Graph for
Rear vent, wall mounted terminations, Figure 16.
Wall Mounted Terminations: Rear Vent
PLEASE NOTE: REAR VENT APPLICATIONS MUST HAVE A 59" VERTICAL
RISE. THEY CANNOT TERMINATE STRAIGHT THROUGH
THE WALL, see gure 16.
All dimension lengths for vertical or horizontal runs are measured from
center of the vent pipe.
Venting runs must fall within the limits set by the venting graphs, see Figure 16.
Fireplace must be converted to Rear Vent conguration prior to running
vent, see Figure 7 and 8.
The Venting Graph
Measure the vertical height from the replace hearth to the centre of the termination
and the horizontal run from the replace ue collar to the wall ange of the termination.
Plot on the Venting Graph Figure 16 with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the installation is
acceptable.
If the vertical dimension from the hearth is 84" and the horizontal
run to the wall ange of the vent termination is 48", this would be
an acceptable installation.
If the vertical dimension from the hearth is 102" and the horizontal
run to the wall ange of the vent termination is 114", this would be
an acceptable installation.
If the vertical dimension from the oor of the replace is 66" and
the horizontal run to the wall ange of the vent termination is 90",
Unacceptable vent run
within shaded area.
Acceptable vent run
within non-shaded area.
64” Max.
59” Min.
18”
Max.
Flex Section
26”
Min.
33”
28”
XG0213 - 020111
Section:
Connection and installation of the vent components should
adhere to the following guidelines:
When penetrating a combustible ceiling, a ceiling restop must be used.
Montigo recommends that all exterior corners and joints be sealed
with exterior caulking however we encourage you to consult your
Building Envelope Engineer or Waterproong Consultant for further
recommendations.
VENTING COMPONENTS
Use any combination of rigid and Flex pipe as required.
Flex sections may be stretched up to 50% of their total length (e.g. a 24”
section maybe stretched to 36”).
Connect all vent sections using a minimum of three sheet metal screws
on the outer pipe ue..
Ensure the pipe ends male to female slide in a minimum of 1 1/2” of overlap.
Ensure all runs are supported with a minimum of 3 supports per 10’ of venting.
When hanging/ supporting venting, ensure that 1” clearance is maintained
on sides and bottom of vent runs and 2” above horizontal vent runs to any
combustible material.
Ensure when cutting sections of rigid pipe to maintain integrity of internal
supports.
Place the springs, supplied with the pipe kit, between the outer and inner
pipes to keep the pipes separate and avoid any possible hot spots.
Montigo recommends the use of a ex section for the nal pipe connected
directly to the replace offering greater exibility of installation and absorption
of movement.
º
º
º
º
All venting material must be sealed with high heat
silicone sealant RV230. All venting material to be
Montigo flex pipe, with as few joints as possible.
All joints use MVA vent splice, sealed thoroughly
with silicone. Montigo will not be held responsible
for any water damage that may occur from not
installing the equipment as specified by this
document.
WARNING
XW2024
XG0213 - 020111
Heat Shields
Figure 19b. RHS101 Installation. (Install by sliding Outer Section over vent
pipe where it passes through the combustible construction.
Figure 19c. Heat Shield. After sliding the outer section in place.
Installing a Wall Mounted RHS101 Heat shield.
The RHS101 Heat shield MUST be used where the Termination falls outside of 58"
horizontally from the replace. (Figure 19b and 19c) Use the RHS102 where the
termination is closer to the replace than 58" horizontally. To install the RHS101, Slide
the Inner Section over the vent pipe that will connect to the replace. Then fasten the
vent pipe to the back of the replace with a minimum of three sheet metal screws.
(Note: ensure you maintain the Max. 12" replace clearance). From the outside slide
the RHS101 outer section on see Figure 19b. To complete the installation fasten the
Heat Shield Outer Section & Termination frame to the structure Figure 19c.
Combustible
framing
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Vent pipe, from fireplace
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Installing a Wall Mounted RHS102 Heat shield.
The RHS102 where the termination is closer to the replace than 58" horizontally.
To install the RHS102, Slide the Inner Section over the vent pipe that will connect to
the replace. Then fasten the vent pipe to the back of the replace with a minimum
of three sheet metal screws. From the outside slide the RHS102 outer section on
see Figure 19. To complete the installation fasten the Heat Shield Outer Section &
Termination frame to the structure Figure 19a.
Figure 19. RHS102 Installation. (Install by sliding Outer Section over vent
pipe where it passes through the combustible construction.
Figure 19a. Heat Shield. After sliding the outer section in place.
Combustible
framing
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
Vent pipe, from fireplace
Termination
Drywall / sheetrock
RHS101 Heat Shield, inner Section
RHS101 Heat Shield
Outer Section
RHS102 Heat Shield
RHS102 Heat Shield
Outer Section RHS102 Heat Shield Inner Section
RHS102 Heat Shield Inner Section
XG0213 - 020111
Section4:Wiring
If the information in these instructions is
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or death.
WARNING
XW2008
Figure 20. Wiring with Honeywell gas control and pilot.
Honeywell (Q3450)
Pilot Assembly
Pilot Electrical
Harness Connector
Honeywell Gas
Control (SV9501M)
Gas Control
Connector
Junction Box
115VAC
24VAC
40 VA
Transformer
Black
White
Green
Gnd Screw
Wall Switch
Fan Plug
Receptacle
Figure 21. Wiring for the SIT IPI Wiring Schematic
XG0213 - 020111
Section5:InstallingtheGasLine
FUEL CONVERSION
Verify that your replace is compatible with your available gas type.
(Natural Gas or Propane shown by "N" or "L" in your model number
If gas type is not compatible, contact your local Montigo representative
to purchase a conversion kit.
Conversion kits must be installed by a qualied service technician.
GAS PRESSURE
Optimum appliance performance requires proper input pressures.
Gas line sizing requirements will be determined in ANSI Z221.3
National Fuel Gas Code in the USA and CAN/CGA B149 in Canada.
Pressure requirements are:
The manifold outlet pressure is set from the factory to the appropriate
pressure but should be veried.
To check pressures, control valves have a provision to remove a
1/8” N.PT. plug to be tted with a hose barb.
Montigo requires a service shut off valve be located in an accessible
location to isolate the gas supply.
Only install gas shut-off valves approved for use by the state, province,
or other governing body in which the replace is being installed.
GAS CONNECTION
See Figure 22 below for location of gas line access.
Flexible gas connectors must not exceed 3 feet in length, unless
allowable within local regulations.
Connect incoming gas line to the 1/2"or 3/8" gas inlet port.
Purge all air out of gas line.
Check appliance connection, valve and valve train under normal
operating pressure with a commercially available leak check solution.
DO NOT USE A FLAME OF ANY KIND TO TEST FOR LEAKS.
Figure 22. Gas line access.
3 3/8”
3 1/2”
2 3/8”
11 3/4”
11 3/4”
Ø 1 1/8”
Ø 1 1/8” 1 1/2”
Pressure Requirements
Gas Pressure Natural Gas Propane
Minimum Inlet Pressure 5.5" W.C. 11" W.C.
Manifold Presure 3.5" W.C. 10" W.C.
After gas line is connected, each
appliance connection, valve and valve
train MUST be checked while under
normal operating pressure with either a
Liquid Solution, or Leak Detection
Device, to locate any source of leak.
Tighten any areas where bubbling
appears or a leak is detected until
bubbling stops completely or leak is no
longer detected. DO NOT use a flame
of any kind to test for leaks. A fire or
explosion will occur, causing serious
injusy, property damage or death.
XW2030
DANGER
When pressure testing the fireplace,
Gas line, and input system follow the
appropriate local codes or your area.
DO NOT connect the fireplace to
pressures in excess of 1/2lb. This will
damage the gas control valve.
NOTICE
XW2032
XG0213 - 020111
Section6:Finishing
When covering the upper metal
portion of the fireplace, (as shown,
Fig.16) with a non-combustible
material, Please Note: The
decorative facing materials may
be subject to temperatures in
excess of 250° F. This should be
considered when selecting facing
materials.
CAUTION
XW2036
Combustible
Construction allowed
in shaded area
Top of fireplace
4” Nailing flange
Combustible Facing
Material
(supplied) or Non-
combustible material
Horizontal Run (in)
Vertica
l
Run (in)
Combustible header
Figure 24. Combustible mantles and facings (nts).
Mantels & Surrounds
National Canadian Gas Association mantel test requirements are for re
hazard prevention to combustible materials.
New technology, to meet consumer and government demands for the wise use of
energy, has prompted us to manufacture many models of replaces which are hot,
fuel and energy efcient.
Please be aware; temperatures over the mantel will rise above normal room
temperature and walls above replace may be hot to touch.
Warning:
When covering the upper metal portion of the replace with a non-combustible
material Please Note: The decorative facing materials may be subject to temperatures
in excess of 250° F. This should be considered when selecting facing materials.
We recommend careful consideration be given to the effects of elevated mantel
temperatures which may be in excess of product design, for example: candles,
plastic or pictures. This can cause melting, deformation, discoloration or premature
failure of T.V. and radio components.
Painting:
Special care is recommended by the Master Painters and Decorators Association,
when painting the replace surrounds, to select and apply a quality Alkyd sealer prior
to the applying of latex paints. This is to prevent leaching of water from evaporation
and causing a brownish staining effect to paint over coats.
FinishingAroundtheFireplace
Combustible mantels and mouldings may be safely installed over the top and on the
front of the replace provided that they do not project beyond shaded area shown
in Figure 24.
Fireplace Facing
When sizing the nish material for your replace, it is important to remember the
following:
The face of the replace may be painted to match the room decor, provided you use
a heat-resistant paint. Decorative facing must not extend past the replace opening
at all, because it will interfere with the access to retainers for removal of glass door.
XW2034
We recommend careful consideration
be given to the effects of elevated
mantel temperatures which may be in
excess of product design, for example:
candles, plastic or pictures. This can
cause melting, deformation, discolor-
ation or premature failure of T.V. radio,
and other electronic components.
CAUTION
Do not use ammonia based or abrasive
cleaners on the glass, they will
permanently etch the surface. Use an
approved gas fireplace glass cleaner
such as Kel-Kem or White off.
NOTICE
XW2000
XW2038
Do not operate this fireplace without the
glass door or with a broken glass door.
NOTICE
XG0213 - 020111
Section7:RemovingtheDoor
Removing the Front door:
The door is removed in a few simple steps. Follow these below to
remove the Horizontal access panel, unlatch the door buckles and, remove the door.
Replace in reverse order. The smaller Side door is bolted in place.
Figure 26a. Locate the door buckles.
Door Latch Hook
Door Latch Slot
Hand-hold
Figure 26. Removing and installing the the Horizontal Acess Panel
Figure 26b. Door buckle Tool
1
Step 4:
Firmly grasp hand-hold
end of Door buckle tool
and place the machined
end in the slot under door
frame. (as shown)
Figure 26c.
Step 2:
Step 3:
Step 1:
Remove the Horizontal cover
by placing ngers in both nger
holes, then pushing away from
you and lifting out. Place it
aside during maintenance or
cleaning.
Install in reverse order.
Installed Gas
Valve Cover
Finger Holes
Remove the Horizontal Access Panel:
To install the door, hook the top edge of the door frame into place. Lower the door
into position and follow the previous steps shown in reverse order.
Hook the top edge of the door frame into place. Lower and rest the door frame in
place and fasten the buckles.
Installing the Front Door:
2
Step 5:
Ensure the tool is rmly
in the lower end of the
slot, (as shown), Then pull
toward you (Caution: hold
the tool securely).
3
Step 6:
Pull hard if necessary to
release the spring ten-
sion. (Caution: The latch
springs back with force,
hold the tool securely).
4
Step 7:
Remove the tool from
the latch slot. Ensure the
latches are hanging freely,
the hook end is released
from the bottom of the door.
(Repeat all 4-steps for the
remaining latches).
Figure 26d.
Figure 26e.
Figure 26f.
Figure 26g. Removing and installing the glass door.
Step 8:
Grasp the Door on either side, usually midway and lift upward, lift the door
carefully up and away from the front of the replace. See Figures 26g. Place
the Door aside in a safe place while maintenance and / or cleaning is being
performed.
Door buckles
Small glass door
afixed to frame
with hardware.
XG0213 - 020111
Section8:InstallingtheAccessories
Figure 27b. (Place Logs' "A" on Left & Right stands).
Installing the Logset
Theis supplied with eight (8) bre logs. The two small bottom logs ("A" )
are mounted on the burner grate by placing them diagonally onto the supplied Log
standsThe long Front / Back logs ("B") are placed against the grate as shown in
Figure 27c. : When placing logs, arrange Logs "B" as not to cover Burner holes.
Next are the Top logs "C" which are placed diagonally, as shown in Figure 27d
The last Logs "D" are then mounted on top of logs "A" as shown in Figure 27e.
Installing the Ember Material
The ember material is supplied in two packages. Spread the material evenly around
the burner tray, or pile around burner holes for a realistic effect. Figure 27d. Log Installation. (Place Logs' "C" on-top of Logs "A".
Indentations on-top of Logs' "A"
Figure 27c. (Place Logs' "B" as shown, in front of Right-hand "A", and
behind Left-hand "B".
Figure 27e. Completed Installation.
Figure 27a. (Empty rebox showing the Left & Right stands).
Front of Fireplace
XW2044
If logs are not placed properly, excessive
sooting will result.
NOTICE
Do not use ammonia based or abrasive
cleaners on the glass, they will
permanently etch the surface. Use an
approved gas fireplace glass cleaner
such as Kel-Kem or White off.
NOTICE
XW2000
XW2038
Do not operate this fireplace without the
glass door or with a broken glass door.
NOTICE
XG0213 - 020111
Installing Firestones in N.G. (Natural Gas) Fireplaces
The is supplied with restones. Remove the Door and trim as shown in the
previous Instruction. Follow these instructions to ensure all parts are removed or
replaced as required. Once the glass door is removed place the restones randomly
across the pan and the burners as described in Figure 28 to 28b.
Figure 28. Installation of the Optional burner covers , (Place the cov-
ers end to end; do not overlap).
Figure 28a. Installation of the restones. (Ensure ONLY one layer of
restones cover the burner and pilot covers).
Figure 28b. Spreading the restones evenly .
Installing Firestones in L.P. (Propane) Fireplaces
Propane H*38C* Fireplace is supplied with restones. Remove the Door and trim
as shown in the previous Instruction. Follow these instructions to ensure all parts
are removed or replaced as required. Once the glass doors is removed place the
restones randomly across the pan as described in Figure 29 to 29a.
Figure 28c. Completed restone installation.
Figure 29. Completed restone installation. (Note: DO NOT place
ANY restones on top of the burners).
Figure 29a. Operating Propane gas replace with restones sur-
rounding burner tray.
