Sculpt Jc bordelet tatiana 997 Operation manual

1. SPECIFICATIONS & COMPONENTS LIST

2. PRELIMINARY INSTALL GUIDE

3. INSTALLATION GUIDE

4. OPERATION & MAINTENANCE

5. WARRANTY

6. TEST RESULTS

7. FINAL WORDS

Tatiana 997 | Eva 992 | Gas Installation

INSTALLATION & USER GUIDE

JC BORDELET

NOTICE TO INSTALLER:

These instructions must be left with the owner, who should keep them for future use.

COMPLIANCE PLATE AND SERIAL NUMBER.

ALL FIREPLACES IN THIS MANUAL CONFORM TO AUSTRALIAN AND NEW ZEALAND STANDARDS AS/

NZS 4013; 2014 UNDER SECTION1.2.3.F.

IMPORTANT

Heating output may vary depending on factors such as building characteristics, quality of insulation,

type of rewood/ gas source used and climate zone.

All dimensions shown are approximate. Check all dimensions accurately on the unit prior to installation.

In line with our policy of continuous improvement, we reserve the right to alter specications and

installation guidelines without notice. (E&OE)

All units comply with and MUST be installed to Australian & New Zealand Standard AS/NZS 2918:2001.

When in use some parts of this appliance may become hot. A suitable re guard is recommended where

very young, elderly or inrm are concerned.

The instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions.

Please ensure to download the latest version of this manual from our website: www.sculptreplaces.com.au/installation-manuals/

Thank you for choosing Sculpt Fireplaces as your heater of choice.

Your replace is the result of careful design, artisan engineering and safety tests.

If it is properly installed, used and maintained, you may be sure that you will have an outstanding

heating feature in your home for years to come.

We advise you to read through this guide in order to become acquainted with the installation

methods specic to your replace.

It is recommended that this replace be installed by a qualied and licensed trades professional.

You will nd in this guide the answers to most of your questions, should you require further

assistance we recommend you contact your retailer.

Before igniting your replace for the rst time, please carefully read this manual.

Follow @sculptreplacecollection on Instagram, SculptFireplaceCollection on Facebook and be

sure to post your latest masterpiece installed with the hashtag #sculptres.

We hope we’ve helped make you the envy of your friends this winter and years to come.

From all of us,

Sculpt Fireplace Collectionion

CONGRATULATIONS!

1.1 SPECIFICATIONS & COMPONENTS TATIANA 997

CEILING

MATERIAL

HEARTH DIMENSIONS

CLEARANCES TO COMBUSTIBLES

INCLUDES

FIREPLACE WEIGHT

TRIPLE SKIN FLUE SIZES

MINIMUM FLUE HEIGHT

BEARING FLAME

& DROPPER BOX WEIGHT

4mm thick steel, hand shaped and spun

Minimum 1770mm diameter X 40mm thick

Minimum 750mm

Fire grate

120kg

240mm, 290mm, 340mm

4.5m

50kg

Tatiana 997

ADJUSTABLE

2438mm

650mm 310mm

236.5mm

620mm

980mm

min 150mm

2440mm

236.5mm

150mm

450mm

980mm

310mm

620mm

NONCOMBUSTIBLE FLOOR

1.1 SPECIFICATIONS & COMPONENTS TATIANA 997

1. BEARING PLATE & DROPPER BOX

2. CEILING COVER PLATE

3. ADDITIONAL PIPE (OPTIONAL LENGTHS)

4. THE FIREPLACE

6. BAFFLE PLATE

Tatiana 997

2438mm

360mm

460mm

620mm

1170mm

265mm

150mm min

CEILING

ADJUSTABLE

Eva 992

150mm

265mm

2650mm

1170mm

575mm

360mm

460mm

MATERIAL

HEARTH DIMENSIONS

CLEARANCES TO COMBUSTIBLES

INCLUDES

FIREPLACE WEIGHT

TRIPLE SKIN FLUE SIZES

MINIMUM FLUE HEIGHT

BEARING FLAME

& DROPPER BOX WEIGHT

4mm thick steel, hand shaped and spun

Minimum 1770mm diameter X 40mm thick

Minmum 750mm

Fire grate and ash pan

200kg

265mm, 315mm, 365mm

4.5m

50kg

NONCOMBUSTIBLE FLOOR

1.2 SPECIFICATIONS & COMPONENTS EVA 992

1. BEARING PLATE & DROPPER BOX

2. CEILING COVER PLATE

3. ADDITIONAL PIPE (OPTIONAL LENGTHS)

4. THE FIREPLACE

5. THE BAFFLE

6. SLIDING GLASS & FIXED GLASS (X2)

7. METALLIC RING

8. THE BASE

9. SHUTTER (X2)

10. ASH PAN

11. ASH GRATE

PLACE THE TWO CAPS ON EITHER SIDE OF THE BASE, IF

AN OUTSIDE AIR KIT IS INSTALLED UNDER THE FLOOR.

PUT IN PLACE THE METALLIC RING TO HIDE SCREWS.

10.

11.

Eva 992

1.2 SPECIFICATIONS & COMPONENTS EVA 992 1.2 SPECIFICATIONS & COMPONENTS EVA 992

2. PRELIMINARY INSTALL GUIDE

IMPORTANT WARNING

The hood of the replace should remain in it’s protected packaging during installation, when

possible avoid contact with the paint surface, we strongly recommend the white gloves supplied

with the unit are used during installation. The paint will naturally polymerize after several res, we

advise you to avoid contact with the unit prior to this. Do NOT scrub or clean the replace. After it’s

assembly, ideally wait for several res before touching it.

In case of marks or of accidental scratches; ensure the paint has completely polymerized, proceed

to clean the surface delicately with a wet and very hot sponge. If necessary, a small retouch of paint

can be considered. DO NOT SCRATCH, APPLY PAINT OR RUB THE PAINT WHILE THE FIREPLACE IS

IN USE.

For reasons of shipping and handling, all our replaces are delivered in separated elements.

Assembly should be carried out according to the manual which should be read entirely to install.

In observance of the assembly instructions entails the liability of the person who carries it out.

The replace should be laid and suspended on adequate elements supporting its weight.

2. PRELIMINARY INSTALL GUIDE

For the installation and use of this appliance, the tter and the user should strictly adhere to local

and national regulations in addition to Australian & New Zealand Standards AS/NZS 2918:2001. The

installer should comply with the instructions and recommendations detailed in this manual. Safety and

operation of the replace is directly dependent thereon. The liability of the manufacturer can neither be

retained nor assured following failure of installation or incorrect use which does not comply with AS/

NZS 2918:2001.

As each installation is unique, a qualied and licensed trades professional should take all required

preliminary precautions depending on the technical elements inherent to each job.

In-observance of the assembly instructions in conjunction with AS/NZS 2918:2001 entails the liability

of the person who carries it out.

As a result of faulty assembly, irrational use of parts or additional components that were not supplied

by the manufacturer, and/or modifying of the appliance or components will result in inferior or unsafe

operation. Should this occur the manufacturer bears no liability, and will result in a null and void product

warranty.

PRELIMINARY INSTALL INFORMATION

All images and diagrams in this manual are for installation reference purposes only and are not to

scale. The distributor and manufacturer bears no accuracy of these images and accepts no liability. The

purpose of these images and diagrams is to act as a guide in conjunction with the written components

and are NOT to instruct independently. The order of these steps are a recommendation only.

It is strongly recommended that the licensed trade professional who is performing the installation of

this appliance, completely read and understand all instructions in this manual prior to proceeding.

Sculpt Fireplaces & Bordelet reserves the right to change these specications without prior notice.

PLEASE READ PRIOR TO INSTALL

HEAT RESISTANT MATERIALS

Heat resistant materials must meet AS/NZS 2918:2001 clause 1:5.21 a material with an allowable

service temperature of 600° Celsius or greater.

3. INSTALLATION GUIDE

For reasons of shipping and handling, all our replaces are delivered in separate components and

require assembly.

Assembly should be carried out according to this manual which should be read in it’s entirety prior to

commencing installation. Any in-observance of the assembly instructions entails the liability of the

licensed trade professional who carries it out.

ASSEMBLING THE FIREPLACE

BASE IF REQUIRED

HOOD

MINIMUM 1000MM

NONCOMBUSTIBLE HEARTH

ROOF

CAVITY

TRIPLE SKIN

FLUE

DROPPER BOX AND

FIXING PLATE

CEILING

MINIMUM 3000MM

DIAMETER CLEARANCE

MINIMUM 150MM

FROM CEILING

Bordelet Eva 992

3. INSTALLATION GUIDE

TATIANA 992

Determine the exact location of the bearing frame and the dropper box above the ceiling in accordance

with the proposed location of the TATIANA 997 will be centred in the room and hang a minimum of

450mm above the hearth(non-combustible oor). Beams in the roof may need to be altered to suit the

Bordelet bearing frame and dropper box. (Instructions continued pg. 12)

EVA 992

Determine the exact location of the bearing frame and the dropper box above the ceiling in accordance

with the proposed location of the EVA 992 will be centred in the room and hang a maximum of 820mm

above the hearth (non-combustible oor). Beams in the roof may need to be altered to suit the Bordelet

bearing frame and dropper box. (Instructions continued pg. 14)

IMPORTANT: When connected to the bearing frame, the dropper box must sit a minimum 150mm below

the ceiling.

1. INSTALLING THE BEARING FRAME AND THE DROPPER BOX

FLAT ROOF INSTALLATION OF BORDELET

DROPPER BOX ONTO BEARING PLATE.

PITCHED ROOF INSTALLATION OF

BORDELET DROPPER BOX ONTO

BEARING PLATE.

BOLT

DROPPER

BOX &

BEARING

FRAME

USING

BOLTS PER

SIDE.

BOLT DROPPER BOX & BEARING

BEARING PLATE

150MM

MINIMUM

CEILING

FLAT ROOF INSTALLATION PITCHED ROOF INSTALLATION

3. INSTALLATION GUIDE

Centred on the planned location of the replace, install a hearth made of approved non-combustible

material such as ceramic tiles, stone, masonry or concrete etc.

4. INSTALLING THE HEARTH NONCOMBUSTIBLE

For added height(oor to ceiling), install the additional pipes(if required), onto the dropper box(using the

3 screws TF M8x16).

MINIMUM 2 OUTSIDE AIR VENTS ARE REQUIRED

This air intake is essential for the operation of this

appliance. The air intake should be located in an

area vented to the outdoors or in an area exposed

to non de pressurised prevailing winds.

The air intake outlets should be located as close

as possible to the appliance. The air intake should

be vermin proof.

The minimum fresh air intake for the TATIANA 997

is 300cm2

The connecting ue should not include more than two 45° osets (i.e. more

than one non-vertical portion), the angle of these osets should not exceed

45° with the vertical.

IMPORTANT: When a controlled mechanical ventilation includes an electric

extractor, it is absolutely necessary to stop operation of the replace. The

electric extractors of the kitchen, the bathroom, or the toilets, should also be

switched o when operating the replace.

Install the TATIANA 997 onto the dropper box (or the additional pipe if requested) with the lower shelf of

the replace 450 mm above the nished hearth.

INSTALLING THE FIREPLACE

5. OUTDOOR AIR VENTS

2. INSTALLING THE ADDITIONAL PIPES

3. 45° OFFSETS OF CONNECTING FLUES

MINIMUM

300MM FLUE

TATIANA 997 INSTALLATION GUIDE CONTINUED

To be conrmed

300cm or 600cm

45°

If the TATIANA 997 reaches a height of more than 4 meters from oor to ceiling then an Anti-Sway

bracket must be installed to stabilize the installation and prevent oscillations which might, in the long

run, loosen fasteners.

6. INSTALLING ANTISWAY BRACKET

3. INSTALLATION GUIDE

TYPE 1: WALL BRACKET

TYPE 2: CENTRAL BELT BRACKET WITH CABLE TIES

TYPES OF ANTI SWAY BRACKETS

ANTISWAY BRACKET REQUIRED OPTION FOR 4000MM

HIGHOR MORE INSTALLATIONS

ADJUSTABLE

FASTENED BY SCREWS

TIGHTENING SCREWS

TIGHTENING NUTS

TATIANA 997 INSTALLATION GUIDE CONTINUED

3. INSTALLATION GUIDE

Centred on the planned location of the replace, install a hearth made of approved non-combustible

material such as ceramic tiles, stone, masonry or concrete etc.

4. INSTALLING THE HEARTH NONCOMBUSTIBLE

For added height (oor to ceiling), install the additional pipes(if required), onto the dropper box(using the

3 screws TF M8x16).

MINIMUM 2 OUTSIDE AIR VENTS ARE REQUIRED

This air intake is essential for the operation of this

appliance. The air intake should be located in an

area vented to the outdoors or in an area exposed

to non de pressurised prevailing winds.

The air intake outlets should be located as close

as possible to the appliance. The air intake should

be vermin proof.

The minimum fresh air intake for the EVA 992 is

1200cm2

The connecting ue should not include more than two 45° osets (i.e. more

than one non-vertical portion), the angle of these osets should not exceed

45° with the vertical.

IMPORTANT: When a controlled mechanical ventilation includes an electric

extractor, it is absolutely necessary to stop operation of the replace. The

electric extractors of the kitchen, the bathroom, or the toilets, should also be

switched o when operating the replace.

Install the EVA 992 onto the dropper box (or the additional pipe if requested) with the lower shelf of the

replace 820 mm above the oor.

INSTALLING THE FIREPLACE

5. OUTDOOR AIR VENTS

2. INSTALLING THE ADDITIONAL PIPES

3. 45° OFFSETS OF CONNECTING FLUES

MINIMUM

300MM FLUE

TO BE UPDATED WITH EVA BURNER DETAILS

EVA 992 INSTALLATION GUIDE CONTINUED

If the EVA 992 reaches a height of more than 4 meters from oor to ceiling then an Anti-Sway bracket

must be installed to stabilize the installation and prevent oscillations which might, in the long run,

loosen fasteners.

6. INSTALLING ANTISWAY BRACKET

3. INSTALLATION GUIDE

TYPE 1: WALL BRACKET

TYPE 2: CENTRAL BELT BRACKET WITH CABLE TIES

TYPES OF ANTI SWAY BRACKETS

ANTISWAY BRACKET REQUIRED OPTION FOR 4000MM

HIGHOR MORE INSTALLATIONS

ADJUSTABLE

FASTENED BY SCREWS

TIGHTENING SCREWS

TIGHTENING NUTS

EVA 992 INSTALLATION GUIDE CONTINUED

3. INSTALLATION GUIDE

This replace has knockouts for the installation of a pipe for natural gas or propane for connection to a

61cm( 24’’) max. width vented gas re log set ( max. capacity 16.2 kw / 55 mj per hour ):

1. Incorporating an automatic shuto device: and

2. Complying with AS/NZS 2918:2001, the Standard for Decorative Gas Burning Appliances For

Installation In Solid-Fuel Burning Factory-Built Fireplaces approved to UL 127: and

3. That this installation is for a vented gas-red heater. It uses air (oxygen) from the room in which it is

installed. Adequate quantities of combustion and ventilation air must be provided. The installation

and the provisions for combustion and ventilation air must conform with the AS/NZS 2918:2001

Installation Code for natural gas and propane: and

4. That, in Australia , the installation and service of the vented gas re log set be made by a licensed

gas tter or plumber licensed for gas installations: and

5. That, since the vented gas log set is designed as an attended appliance, it can only be operated in

the presence of adults. Do not operate the vented gas log set if unattended, or in the presence of

unattended children, especially those under 8 years of age, or while anyone is sleeping: and

6. That, solid fuels, garbage, scrap paper, cardboard or lumber must never be burnt on top of a vented

gas log set installed in a factory-built replace.

INSTALLATION OF A VENTED GAS FIRE LOG SET IN A BORDELET

TATIANNA 997 CENTRALLYLOCATED OPEN FIREPLACE.

CAUTION: Do not install this replace/vented gas log combination in a conned space or in

tightly constructed house without providing for combustion and ventilation air as stated in the

Australian Standard Installation Code for natural gas and LPG

NOTE: Make sure that the proper gas type will be supplied to the vented gas re log set as stated

on the manufacturer’s name plate before connecting it to any gas line. There is a ared tting

installed on the appliance at the factory. Ensure ttings are of the appropriate size on any tubing

that is to be connected to the appliance. If the gas supply tubing has to be cut to length and

shaped, be sure to use the proper cutting and aring tool. Also, be careful not to crimp the tubing

when it is being bent for connection which could restrict the gas ow to the appliance. If a crimp

does occur in the tubing, do not use for installation. Gas resistant pipe compound must be used

on all threaded male connections,

with the exception of brass to brass ttings.

3. INSTALLATION GUIDE

CAUTION: An external pressure regulator is required for L.P. gas to reduce supply pressure to a

maximum of 13’’W.C. It is required to use an exterior L.P. gas fuel tank of not less than 45kg

capacity.

WARNING: An explosion could occur if a connection is made directly to an unregulated LP gas tank.

The gas line supplying the vented gas re log set must be of sucient size to furnish adequate supply

pressure to the gas log set while operated on the high setting. The vented gas re log set must be

inspected before use and must only be installed in a solid-fuel burning UL 127 approved factory-built

replace with a working ue. During the installation, do not substitute or use materials or components

other than those supplied for use with the vented gas re log set.

WARNING: CARBON MONOXYDE POISONING MAY LEAD TO DEATH

When used without proper levels of combustion air, vented gas log sets may give o carbon

monoxide, an odorless, colorless, poisonous gas. Certain people such as: pregnant women,

or suering from heart or liver disease, anemia, or intoxicated by alcohol, or residing at high

altitude are more aected by carbon monoxide than others. Some symptoms related to

carbon monoxide poisoning resemble u symptoms, or painful headaches, or dizziness and/or

nausea. If you or anybody else in your household shows these symptoms, the gas log set may

not be installed or operating properly and/or the chimney may be obstructed or blocked.

OPEN A WINDOW AT ONCE TO GET SOME FRESH AIR AND SHUT OFF THE GAS LOG SET

IMMEDIATELY.

Before using it again, have the gas log set and the chimney checked by a licensed gas tter.

And to prevent recurrence of these problems, have a licensed heating contractor install an

outdoor com- bustion air intake leading to the room where the combination replace/gas log

set is installed.

Does this need to be included?

3. INSTALLATION GUIDE

This replace has knockouts for the installation of a pipe for natural gas or propane for connection to a

61cm( 24’’) max. width vented gas re log set ( max. capacity 16.2 kw / 100 mj per hour ):

1. Incorporating an automatic shuto device: and

2. Complying with AS/NZS 2918:2001, the Standard for Decorative Gas Burning Appliances For

Installation In Solid-Fuel Burning Factory-Built Fireplaces approved to UL 127: and

3. That this installation is for a vented gas-red heater. It uses air (oxygen) from the room in which it is

installed. Adequate quantities of combustion and ventilation air must be provided. The installation

and the provisions for combustion and ventilation air must conform with the AS/NZS 2918:2001

Installation Code for natural gas and propane: and

4. That, in Australia , the installation and service of the vented gas re log set be made by a licensed

gas tter or plumber licensed for gas installations: and

5. That, since the vented gas log set is designed as an attended appliance, it can only be operated in

the presence of adults. Do not operate the vented gas log set if unattended, or in the presence of

unattended children, especially those under 8 years of age, or while anyone is sleeping: and

6. That, solid fuels, garbage, scrap paper, cardboard or lumber must never be burnt on top of a vented

gas log set installed in a factory-built replace.

INSTALLATION OF A VENTED GAS FIRE LOG SET IN A BORDELET EVA

992 CENTRALLYLOCATED OPEN FIREPLACE.
