LEAF BLOWER CORDLESS 20V - BODY ONLY

MODEL NO: CB20V

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9Always wear appropriate eye protection, ear protection, substantial footwear, gloves, long trousers whilst operating.

9Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.

9Inspect and ensure equipment is in good working order before use.

9Maintain and clean tool and battery pack, regularly. Check air holes are clear.

9Must be serviced by an authorised agent. Use genuine parts only. Non authorised parts will invalidate the warranty.

WARNING! Remove battery before: performing maintenance, carrying out adjustments, inspecting the machine after striking an object,

before clearing a blockage, before leaving the tool unattended, before moving to the next job location.

9WARNING! Risk assess the work area. Keep bystanders away from the work area. DO NOT operate with anyone or pets nearby.

Check intended work area for wildlife.

8DO NOT use in bad weather conditions, especially when there is a risk of lightning. DO NOT expose to rain. Only use in good light.

8DO NOT use if tool vibrates abnormally, switch off, remove battery and then inspect.

8DO NOT touch hazardous moving parts. Allow to come to a complete stop first.

8DO NOT operate whilst tired, ill under the inuence of alcohol or other intoxicating drugs.

8DO NOT overreach and keep balance at all times.

8DO NOT use if damaged. DO NOT operate with damaged or missing air tube.

8DO NOT use for a task it was not designed to perform.

9Store with the battery removed and separate from the machine, in a dry, childproof location.

WARNING! Never allow children, persons with reduced physical sensory or mental capabilities or lack of experience and knowledge

or people unfamiliar with these instructions to use the machine, local regulations may restrict the age of the operator.

2. INTRODUCTION

Lightweight, cordless and extremely powerful garden leaf blower makes gardening easy, clean and e󰀨ective. Can be used for DIY and

professional use. Ideal for removing leaves and waste from driveways, patios and small gardens. Works in conjunction with our one battery ts

all program. Body only. Powered by a 2Ah or 4Ah battery and mains charger available.

3. SPECIFICATION

Model No: .....................................................................................................................................................CB20V

Batteries:

Model No. CP20VBP2 .................................................. Power Tool Battery 20V 2Ah Lithium-ion for CP20V Series

Model No. CP20VBP4 .................................................. Power Tool Battery 20V 4Ah Lithium-ion for CP20V Series

Charger:................................................................ CP20VMC - Battery Charger 20V Lithium-ion for CP20V Series

Voltage:....................................................................................................................................................20V Li-ion

Maximum Air Speed:................................................................................................................................... 130mph

Maximum Air Volume: ................................................................................................................................150m³/hr

Nett Weight: .................................................................................................................................................. 1.25kg

4. OPERATION

4.1. When operating, always hold the machine approximately 3cm above the ground.

▲DANGER! DO NOT blow hot, ammable or explosive material

4.2. Connect the blower tubes to the main unit, and secure with the screw provided.

4.3. Insert the battery.

4.4. Switch on using switch on handle.

Self Tapping Screw

Air Outlet Pipe

On/Off Switch

Air Inlet

Battery Socket

g.1

CB20V Issue 1 03/12/18

Original Language Version

Refer to

instructions

Wear eye

protection

Warning Wear safety

footwear

Wear protective

clothing

Keep in dry area

protect from rain

5. MAINTENANCE

WARNING! Remove battery before attempting any maintenance

5.1. Keep all nuts, bolts and screws tight to be sure that the machine is in safe working condition.

5.2. Examine the machine and replace worn or damaged parts for safety. Ensure replacement parts tted are genuine.

5.3. Before any work on the garden product itself (e.g. Maintenance, tool change, etc.) as well as during transport and storage, remove

the battery from the garden product.

5.4. There is danger of injury when unintentionally actuating the On/O󰀨 switch.

5.5. For safe and proper working, always keep the garden product and the ventilation slots clean.

5.6. Never spray with or immerse the garden product in water.

5.7. Store the garden product in a secure, dry place, out of the reach of children.

5.8. DO NOT place other objects on the blower.

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid

waste authority for recycling information.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.
