Sealey Sm53.v3 User manual

SM53.V3, SM54.V3 - 1 - 22/04/05

1. SAFETY INSTRUCTIONS

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.

USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE

DAMAGE OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions

and properly maintained, give you years of trouble free performance.

INSTRUCTIONS FOR:

BENCH GRINDER & BUFFER

MODELS: SM53.V3 & SM54.V3

1.1. ELECTRICAL SAFETY. p

WARNING! It is the users responsibility to read, understand and comply with the following:

You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads, plugs and

all electrical connections for wear and damage. You must ensure the risk of electric shock is minimised by the installation of appropriate safety

devices. An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD

(Residual Current Device) is used with all electrical products. It is particularly important to use an RCD together with portable products that are

plugged into an electrical supply not protected by an RCCB. If in doubt consult a professional electrician. You may obtain a Residual Current

Device by contacting your Sealey dealer. You must also read and understand the following instructions concerning electrical safety.

1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by

a qualified electrician, using a Portable Appliance Tester (PAT), at least once a year.

1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance,

and the safety of the appliance operator. If in any doubt about electrical safety, contact a qualified electrician.

1.1.3. Ensure the insulation on all cables and the product itself is safe before connecting to the mains power

supply. See 1.1.1. & 1.1.2. above and use a Portable Appliance Tester (PAT).

1.1.4. Ensure that cables are always protected against short circuit and overload.

1.1.5. Regularly inspect power supply, leads, plugs and all electrical connections for wear and damage,

especially power connections, to ensure that none are loose.

1.1.6. Important: Ensure the voltage marked on the product is the same as the electrical power supply

to be used, and check that plugs are fitted with the correct capacity fuse. A 13 amp plug may require

a fuse smaller than 13 amps for certain products, see fuse rating at right.

1.1.7. DO NOT pull or carry the powered appliance by its power supply lead.

1.1.8. DO NOT pull power plugs from sockets by the power cable.

1.1.9. DO NOT use worn or damage leads, plugs or connections. Immediately replace or have repaired by

a qualified electrician. AU.K. 3 pin plug with ASTA/BS approval is fitted. In case of damage, cut off

and fit a new plug according to the following instructions (discard old plug safely).

(UK only - see diagram at right). Ensure the unit is correctly earthed via a three-pin plug.

a) Connect the GREEN/YELLOW earth wire to the earth terminal E.

b) Connect the BROWN live wire to live terminal L.

c) Connect the BLUE neutral wire to the neutral terminal N.

After wiring, check there are no bare wires, that all wires have been correctly connected and that the wire restraint is tight.

Double insulated products are often fitted with live (BROWN) and neutral (BLUE) wires only. Double insulated products are always marked with

this symbol . To re-wire, connect the brown & blue wires as indicated above. DO NOT connect the brown or blue to the earth terminal.

1.1.10. Some products require more than a 13 amp electrical supply. In such a case, NO plug will be fitted. You must contact a qualified electrician

to ensure a 30 amp fused supply is available. We recommend you discuss the installation of a industrial round pin plug and socket with your electrician.

1.1.11. Cable extension reels. When a cable extension reel is used it should be fully unwound before connection. A cable reel with an RCD

fitted is recommended since any product which is plugged into the reel will be protected. The section of the cores of the cable is

important and should be at least 1.5mm2. However, to be absolutely sure that the capacity of the reel is suitable for this product and

for others that may be used in the other output sockets, we recommend the use of 2.5mm2section cable.

Blue

Neutral

Wire

Yellow & Green

Earth Wire

Wire

Restraint

THIS PRODUCT MUST BE

FITTED WITH A 5 AMP FUSE

Brown

Live

Wire

1.2 GENERAL SAFETY

pWARNING! Disconnect the grinder from the mains power, and ensure the grinding wheels are at a standstill before attempting to changing

accessories, servicing or performing any maintenance.

3Maintain the grinder in good condition and check moving parts alignment regularly.

3Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the warranty.

DANGER! DO NOT use a damaged stone as it is dangerous and may cause damage or serious personal injury.

pWARNING! Only persons qualified under the Abrasive Wheels Regulations and holding a current grinding wheel

certificate are to change or dress grinding stones. Unplug grinder from mains power and refer to chapter 4 Grinding Stones for details.

pWARNING! Keep all guards and holding screws in place, tight and in good working order. Check regularly for damaged parts.

A guard or any other part that is damaged should be checked to ensure that it will operate properly and perform its intended function

before tool is used. The safety guard is a mandatory fitting where grinder is used in premises covered by the Health & Safety at Work Act.

3Locate grinder in an adequate working area for its function, keep area clean, tidy and free from unrelated materials. Ensure adequate lighting.

3Before each use check grinding wheel for condition. If worn or damaged replace immediately.

pWARNING! Always wear approved eye or face protection when operating the grinder.

3Use breathing protection in accordance with COSHH regulations if fumes or dust pose a hazard. Wear ear defenders and gloves if necessary.

3Keep hands and body clear of the workpiece when operating the grinder.

3Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.

3Remove ill fitting clothing. Remove ties, watches, rings, and other loose jewellery, and contain and/ or tie back long hair.

3Keep children and unauthorised persons away from the working area.

7DO NOT force the grinder to achieve a task it was not designed to perform.

7DO NOT operate the grinder if any parts are damaged or missing as this may cause failure or possible personal injury.

pWARNING! DO NOT grind, or sand any materials containing asbestos.

7DO NOT switch the grinder on whilst the wheel is in contact with the work piece.

3.1. EYESHIELD ASSEMBLY

3.1.1. Remove protective film from eyeshields, place support plate on top and assemble as in figure 1.

3.1.2. Assemble shield arms as in figure 2. One connects to the right hand side of grinder and the other to the left.

3.1.3. Securely attached each eyeshield to the grinding stone guard as in figure 4 A.

3.1.4. Set the clearance between the stone and the eyeshield at 5mm (fig 3).

3.2. TOOLREST ASSEMBLY

3.2.1. Bolt each tool rest to the bottom of the stone guard as in figure 4. B.

3.2.2. Set the clearance between the stone and the toolrest at 2mm (fig 3).

2. TECHNICAL SPECIFICATIONS

Model: SM53

Dry Grinding stone dims 150 x 25 x 20mm

Dry grinding stone part no SM53-5/GW150C (Course)

SM53-5/GW150F (Fine)

Dry Grinding Speed 2850 RPM

Wire Brush dims 150x16x12mm

Wire Brush part no SM53-5/WB125

Buffing Mop 125 x 16 x 12 mm

Buffing Mop part no SM53-5/BM125

Motor 1/2 Hp - 230V/1ph

Model: SM54

Dry Grinding stone dims 200 x 25 x 20mm

Dry grinding stone part no SM54-6/GW200C (Course)

SM54-6/GW200F (Fine)

Dry Grinding Speed 2850 RPM

Wire Brush dims 200x16x12mm

Wire Brush part no SM54-6/WB175

Buffing Mop 175 x 19 x 12 mm

Buffing Mop part no SM54-6/BM175

Motor 3/4 Hp - 230V/1ph

3. ASSEMBLY & ADJUSTMENT

Unpack the product and check contents, should there be any damaged or missing parts contact your supplier immediately.

WARNING! Before use, the machine must be bolted to a stable, fireproof bench or table. Strong enough to take the weight of the

machine and the workpiece. Failure to comply with this instruction could result in damage or severe personal injury.

fig 1 fig 2 fig 3

fig 5

fig 4

7DO NOT allow the workpiece to become jammed between the stone and eyeshield or tool rest.

7DO NOT get the grinder wet or use in damp or wet locations or areas where there is condensation.

7DO NOT use grinder where there is flammable liquids, solids or gases such as paint solvents, including waste wiping or cleaning rags etc.

7DO NOT touch the workpiece close to the ground surface as it will be very hot. Allow to cool. The workpiece may also be very sharp.

7DO NOT operate the grinder when you are tired, under the influence of alcohol, drugs or intoxicating medication.

7DO NOT leave the grinder operating whilst unattended.

3When not in use switch the grinder off, and disconnect from the mains power supply, and clean the machine and working area.

3.3. BRUSH OR BUFFER ATTACHMENT.

3.3.1.

Hold grinding stone firmly. To protect your hands use a cloth or wear

gloves.

Remove the thread cap from the grinding stone spindle

and screw on the adaptor arm (fig 5.1.).

3.3.2.

Install flange (2), install the brush or buffer (3) and hold the second

flange (4) against (3) and lock with nut (5). Ensure washers are

installed with the flange on the outside, (i.e. the concave side

against the blotter).

4.1. MANDATORY SAFETY INSTRUCTIONS. (The following instructions must be observed together with chapter 1 safety).

DANGER! use of a damaged stone is dangerous and may cause damage or personal injury.

WARNING! Ensure grinder is unplugged from the mains power supply before attempting to change grinding stones (or wheel).

Only persons qualified under the Abrasive Wheels Regulations and holding a current grinding wheel certificate are authorised

to change and dress grinding stones (wheels).

Grinding stones (wheels) used with the machine must be of an adequate speed rating and suitable for the material to be ground.

Ensure the cutting stones maximum speed specification is higher than that indicated on the machine data plate.

Check grinding stones are secure, and the stone is not worn or damaged, that there are no fissures or cracks. if damaged replace immediately.

Ensure replacement stone is not damaged in any way such as cracks, deformations or splinters etc. Also check the mounting flanges

to ensure they are not deformed, burred or chipped. Damaged flanges must NOT be used as they may cause irregular pressure on the stone

4. GRINDING STONES

DANGER OF FIRE/EXPLOSION HAZARD

WARNING! The grinding process can produce streams of sparks (especially when grinding metal) which are a potential source of ignition.

DO NOT use the grinder where there are flammable liquids, solids or gases.

DO NOT allow grinder sparks to make contact with the operators clothing or any other fabric such as cleaning rags. Fabrics contaminated with inflammable materials

such as petrol, oil, grease, paint and solvents are a particular fire hazard.

To reduce the risk of clothing catching fire the operator should wear wool or cotton outer garments treated with a fire retardant in preference to man-made fibres.

SM53.V3, SM54.V3 - 1 - 22/04/05

4.2. Stone Changing Procedure. p

WARNING! unplug grinder from the mains power supply before changing stone.

4.2.1. Raise the eye shield up, and away from the stone.

4.2.2. Loosen and pull the tool rest out as far as possible, but, DO NOT

remove it.

4.2.3. Remove the brush or buffer (fig 6.1.)

4.2.4. Remove screws from the side of the wheel cover and remove

the cover (2).

4.2.5. Hold grinding stone firmly. To protect your hands use a cloth or wear

gloves. Unscrew retaining nut (3).

Note: The nut on the right side of the grinder has standard right

hand thread (undo anti-clockwise). The left side nut has a left hand

thread and must be loosened by turning clockwise. It may be

necessary to strike the wrench sharply in the loosening direction with

the heel of your hand to loosen the nut.

4.2.6. Remove grinding stone washer (4) stone (5) from main spindle (7), ensure sleave (6) remains on the spindle. Check that washer (8) is sound.

4.2.7. Carefully inspect the new stone before installing to ensure there are no splits, chips, or cracks.

WARNING! DO NOT USE A DAMAGED STONE.

4.2.8. Install the new stone by reversing steps above. Ensure washers (8 & 4) are installed with the flange on the outside, (i.e. the concave

side against the blotter).

4.2.9. Hold stone steady and secure locking nut. DO NOT over tighten as this may crack the stone.

4.2.10. Replace stone cover, brush or buffer and re-adjust tool rest to 2mm and eyeshield 5mm from stone face.

5.1. Pre use Inspection.

pWARNING! INSPECT THE GRINDER BEFORE OPERATING THE MACHINE. ENSURE THE GRINDER IS UNPLUGGED FROM

THE MAINS POWER BEFORE COMMENCING THE INSPECTION.

5.1.1. Check the tool rests are securely fixed and are set at a maximum of 2mm from the grinding stone.

5.1.2. Check eye shields are in good condition, set at 5mm from the stone, are secure and that you can see through them clearly.

5.1.3. Turn the grinding stones by hand and check for any damage. Check they do not touch the tool rests and are correctly aligned.

If any of the above checks fail, replace, repair, or adjust as necessary before starting the grinder.

5.2. Stone Use.

Depending on the model, grinders are supplied with one or two aluminous oxide stones. Stones have two grades, fine are preferred

for hard materials a coarse stones for soft materials.

When grinding, should surface of the stone become loaded (coated with particles of the material being ground) it is probably the

wrong grade of stone for the job.

Important reminder: Grinding stones MUST Only be assembled by a person holding a grinding wheel certificate. See chapter 4.

5.3. Using the Grinder.

pWARNING! Before commencing work, ensure you have read, understood, and apply the chapter 1. Safety Instructions

Plug grinder into the mains power supply.

Place the eyeshield in its appropriate safety location.

Switch the grinder on, and bring the workpiece slowly into contact with the spinning stone, wire wheel or buffer.

When you have completed your task. Unplug the grinder from the mains power supply, and clean the machine ready for next use.

6. MAINTENANCE

pWARNING! Ensure the grinder is unplugged from the mans power supply before performing any maintenance or service.

6.1. As the grinding stone wears, adjust the position of the tool rests. The rest must set at a maximum of 2mm from the stone surface.

6.2. Regularly remove the grinding stone covers and clean out any dust and dirt.

6.3. The machine motor and bearing are sealed units and require no regular maintenance. Should you require assistance, contact your

local Sealey service agent.

6.4. For information relating to the handling and maintenance of grinding stones refer to chapter 4.

Declaration of Conformity We, the sole importer into the UK, declare that the products listed here

are in conformity with the following EEC standards and directives

The construction files for these products are held by the Manufacturer and may be inspected on request by

contacting Jack Sealey Ltd.

For Jack Sealey Ltd. Sole importer into the UK of Sealey Quality Machinery.

BENCH GRINDERS & BUFFERS

Models: SM53.V3 & SM54.V3

73/23/EEC Low Voltage Directive (S.I. 1989/728)

89/336/EEC EMC Directive (S.I. 1992/2372).

98/37/EC Machinery Directive (S.I. 1992/3073)

93/68/EEC CE Marking Directive

1st February 2000

5. OPERATING INSTRUCTIONS

Signed by Mark Sweetman

which may cause stone to break. DO NOT over tighten a stone. Never tamper with a stone in order to adapt it to a different size holder.

Install a new stone as in 4.2. Once mounted on the grinder test the stone before use by facing the grinder in a safe direction (point

away from yourself, others and vulnerable items) and run for a short time. Dress the stone if necessary.

fig 6

SM53.V3, SM54.V3 - 1 - 22/04/05

01284 757500

01284 703534 sales@sealey.co.uk

Sole UK Distributor

Sealey Group,

Bury St. Edmunds, Suffolk.

www.sealey.co.uk

Web

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
