INSTRUCTIONS FOR
IMPACT DRIVER 20V 1/4”HEX DRIVE 180NM
- BODY ONLY
MODEL NO: CP20VID
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9Maintain the Impact Driver and battery in good condition. Check moving parts alignment on a regular basis.
9Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
9Ensure the Impact Driver is switched off before installing the battery pack.
9Keep the Impact Driver and charger clean for best and safest performance.
9Remove ill tting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
9Evaluate your working area before using the Impact Driver; e.g. ceilings, oors and enclosures may contain electrical items or water
piping.
9Ensure battery pack is correctly inserted into the Impact Driver handle and latched in place before attempting to switch on Impact
Driver.
9Secure loose work pieces with a clamp, vice or other adequate holding device.
9Avoid unintentional starting.
9 Wear approved safety eye protection (standard spectacles are not adequate).
9Maintain correct balance and footing. Ensure the floor is not slippery and wear non-skid shoes.
9Keep direction switch in the locked position until the Impact Driver is required for use.
9Keep children and unauthorised persons away from the working area.
8DO NOT use the Impact Driver where there are ammable liquids, solids or gases, such as paint solvents, etc.
8DO NOT allow children to operate the Impact Driver.
8DO NOT operate the Impact Driver if any parts are missing as this may cause failure and/or personal injury.
8DO NOT hold unsecured work piece in your hand.
8DO NOT leave the Impact Driver operating unattended.
8DO NOT carry the Impact Driver with your finger on the power switch. Keep chuck direction switch in the locked position.
8DO NOT use the Impact Driver for a task it is not designed to perform.
8DO NOT operate the Impact Driver when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8DO NOT get the Impact Driver or battery charger wet or use in damp or wet locations.
2. INTRODUCTION
The 20V series has been designed to suit users from the DIY enthusiast to the professional. These body only tools offer a one battery ts all
solution with a choice of 20V lithium batteries ranging from 2Ah to 4Ah, meaning costs can be kept down whilst quality remains high. Quality,
stylish, lightweight tools with composite housing and a soft grip making them comfortable and easy to use.
3. SPECIFICATION
Model No................................................................. CP20VID
Battery ............................20V 2Ah - 4Ah Li-ion (not included)
Drive ........................................................................1/4” Hex.
Impact rate ........................................................... 0-3000bpm
No load Speed ......................................................0-2200rpm
Maximum Torque.........................................................180Nm
Battery Model No’s
2Ah ..................................................................... CP20VBP2
3Ah ...................................................................... CP20VBP3
4Ah ...................................................................... CP20VBP4
Mains Charger Model No ...................................... CP20VMC
Weight......................................................................... 1.17kg
Noise power .................................................................106dB
Noise pressure...............................................................95dB
Vibration................................................................. 15.87m/s²
Uncertainty................................................................. 1.5m/s²
CP20VID | Issue 1 06/04/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear protective
gloves
Wear ear
protection

4. OPERATION
4.1. Ensure the direction selector (g.1) is in the mid (lock)
position.
4.2. Insert the required driver bit into the chuck by pulling the
locking collar forward and sliding the bit in until the locking
ring snaps back.
4.3. Select clockwise or anticlockwise direction by means of the
direction selector.
4.4. Squeeze the trigger to start the driver; initial pressure
switches on the LED worklight, further pressure starts the
motor and increases speed.
4.5. To release the bit, pull the locking collar forward and withdraw.
WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): ...........15.87 m/s²
Uncertainty value (k): ............................1.5 m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend that a
specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm Vibration
Syndrome.
Health surveillance.
We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management procedures can be modified
accordingly.
Personal protective equipment.
We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury that may result from the
uncontrolled use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to remain warm and dry and
maintain good blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer to the Correct Use and
Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on the HSC website
www.hse.gov.uk - Hand-Arm Vibration at Work.
g.1
Original Language Version
© Jack Sealey Limited CP20VID | Issue 1 06/04/18
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
