Seametrics DL76 User manual

DL76
DATA LOGGER SYSTEM
INSTRUCTIONS
DL76 DATA LOGGER SYSTEM INSTRUCTIONS
9001:2008
CERTIFIED COMPANY
ISO

Page 2
GENERAL INFORMATION
The DL76 is a battery-powered data logger that can be used
with any Seametrics owmeter. It stores pulses for up to 3
years, depending on the user-selected frequency of reading.
Indicator lights on the unit ash to indicate when it is func-
tioning and when the battery is low.
The DL76 can be factory-mounted on the meter or remotely
mounted. Housings are rugged cast aluminum, gasketed for
environmental protection.
When a DL76 logger is placed into operation, it is easily set
up using a laptop computer. Data is also retrieved from the
DL76 by means of a laptop and can be analyzed on the laptop
or easily loaded on a desktop computer for analysis.
FlowInspector software (ordered separately) is required for
the downloading, storing, viewing, graphing, charting and print-
ing of data in several formats.
FlowInspector requires a PC with Windows 98, NT, 2000, XP,
Vista, or Windows 7; CD-Rom drive; 800 x 600 screen resolu-
tion; serial port or USB/serial adapter; and a Seametrics DC3
data cable. FlowInspector comes in versions compatible with
up to 4, up to 16, or 17+ dataloggers.
FEATURES
DL76
Data Logger
Data
Port
Active
Replace
Battery
Bright status LEDs ash to indicate
logger activity and battery life
Sturdy gasketed cover with potted
electronics
Cable to meter (wall mount only)
SPECIFICATIONS*
*Specications subject to change • Please consult our website for current data (www.Seametrics.com).
Size C 3.6 Vdc lithium battery (included)
Estimated life is 3-5 years depending on usage.
0˚ to 130˚ F (-18˚ to 54˚C)
mL, liter, gallon, Imperial gallon, cubic foot, cubic meter, million gallon
Seconds, minutes, hours, days
Liter, gallon, Imperial gallon, cubic foot, cubic meter, million gallon,
acre-foot, acre-inch, megaliter, thousand-gallon
Capacity at Sampling Interval
11 days at 15 seconds
22 days at 30 seconds
44 days at 60 seconds
6 months at 240 seconds
1 year at 480 seconds
3 years at 1450 seconds
500 Hz
Low battery; Power
Selectable options (Stop or Overwrite)
10 minutes/month (.02%)
Power
Battery Life
Temperature
Rate Units Volume
Time
Total Units
Data Storage Capacity
Maximum Input Frequency
Indicators
Memory Wraparound
Clock Accuracy
Removable foot brackets for remote
mounting (wall mount model only)
Data port connector for Seametrics
DC3 serial or USB data collection cable
Protective data port cap (shown open)

Page 3
MOUNTING & CONNECTIONS
MOUNTING
There are three mounting congurations for a DL76: Meter
mount for mechanical meters, meter mount for insertion
magmeters, and wall mount (DL76W). The meter mount
models match up to any Seametrics lower square housing.
All congurations can be factory-ordered or eld-installed.
Converting from one mounting conguration to another
requires use of MK10 or MK20 mounting kits.
Meter Mounting. Remove the four screws on the meter cover
with a 5/32” Allen wrench. After connecting the leads to their
respective terminals (see diagram), put the DL76 in place of
the meter cover and tighten the screws evenly. The gasket
on the DL76 should be visibly compressed by tightening all
around.
OPERATION
Seametrics FlowInspector V.2 software is required for
operation of the DL76. Please consult your FlowInspector
manual for instructions in loading the software onto your
computer, setting up your DL76 for use, downloading, storing,
and analyzing your data.
DIMENSIONS
2.82”
7.16 cm
3.95”
10.03 cm 4.52”
11.48 cm
3.35”
8.51 cm
2.06”
5.23 cm
3.95”
10.03 cm
DL76
Data Logger
Data
Port
Active
Replace
Battery
4.90”
12.45 cm
3 “
16
4.77 mm
DL76W (WALL MOUNT) DL76M (METER MOUNT)
CONNECTIONS (see also next page)
Caution: Do not apply external
power to the DL76
Red
White
Black
Flow Sensor
+
S
-
Magmeter
Connections
+
S
-
+ -
+ - Forward
Output
Power
DL76 TO MECHANICAL METER DL76 TO MAGMETER

LT-65200312-041415
4/14/2015
Seametrics Incorporated • 19026 72nd Avenue South • Kent, Washington 98032 • USA
(P) 253.872.0284 • (F) 253.872.0285 • 1.800.975.8153 • www.Seametrics.com
Problem Probable Cause Try...
Laptop screen reads
”No connection” and “Ac-
tive” light is NOT blinking
Laptop screen reads
”No connection,” but “Ac-
tive” light IS blinking
Flow rate incorrect
No ow rate
Wait for “Active” light to blink
Replace battery
Tighten cable
Test cable (tech bulletin “DL75/76: Testing the
DC3 Serial Cable” on Downloads page at
www.Seametrics.com)
Make sure K-factor in DL76 matches ow sen-
sor
Mechanical: See if rotor spins freely
EX Magmeter: See if “Status LED” indicator is
blinking
Check for ow rate
DL76 is transmitting data.
Wait two minutes before taking action.
Dead battery in DL76
Loose cable
Bad cable
K-factor setting is incorrect
Damaged ow sensor
Broken wire
TROUBLESHOOTING
CONNECTIONS
Caution: Do not apply external
power to the DL76
+
S
-
DL75
To Flow
Sensor
BATTERY
Sensor Input
Outputs
Sensor Pulse
- +-+
To Pulse Responsive
Metering Pump
FT415
BATTERY
Pulse
Passthru
Pulse
Scaled
Sensor
Input
Power
4-20 mA
To Flow Sensor
S
12-32 Vdc
Loop Power Supply
4-20 mA Device
-
+
+
-+
-
+
-
+
-
FT420
+
S
-
DL75
BATTERY
+
-
-
DL76 TO FT415
DL76 TO FT420
White
Green
White
Green
Red Black
Black
