OWNER’S MANUAL
LIGHTED HOLIDAY DEER
Core number: 44768
Product code: 07790217-9
UPC code: 029944528913
Date of purchase: _____/ _____/ _____

LIGHTED HOLIDAY DEER
ITEM NUMBER: TY-A-200L/4W-4(60)
A. Antler
Qty：2pcs
B. Ear
Qty：2pcs
C. Tail
Qty：1pc
D. Head
Qty：1pc
E. Body
Qty：1pc
F. Legs
Qty：4pcs
G. Bow
Qty：1pc
H. Ground Stakes
Qty：4pcs
I. Plastic Ties
ASSEMBLY INSTRUCTIONS
STEPS:
(1)Carefully remove all of the parts from the box and place on a flat surface. Check the Parts
List to make sure all of the parts are included. If there are any plastic covers to protect the
end of metal rod tips, remove the covers before assembly.
(2)Insert the rods of the Head (Part #D) into the holes top of the Boby(Part #E);Insert two posts
of each Leg (Part# F) into the matching holes in the body and fasten them togther with the
Plastic Ties(Part#I) ;Insert the rod of Tail (Part #C) into the rear of the Body (Part #E). Attached
the support bars inside of Leg to opposite Leg.(See FIG.1)
(3) Insert the rods of Antlers (Part #A) and Ears(Part #B) into the matching holes in the each
side of the Head; Insert the wires of the Bow(Part# G) through the holes of the body,then twist
the wires together(See FIG.2).
(4) Secure the Sculpture to the ground with the Ground Stakes (Part # H); (See FIG.2).
(5) Plug in.
FIG.1 FIG.2
