Seatcraft EUPHORIA Operating manual

ASSEMBLY & GENERAL USE GUIDE
3616
Rev. 11/30/2023
EUPHORIA
Heat, Massage, Power Headrest, Power Lumbar, &
Power Recline Loveseat w/ Storage Console

22
What’s Inside the Box
Step 1: Connect the Remote, Massage & Power
Step 2: Attach the Console Backrest
Step 3:Attach the Backrests to the Seat Base
Step 4: Connect the Power Adapter Cable
Step 5: Attach the Tray Tables
Using the Power / Massage Remote Control
Troubleshooting Guide
Seat Part List
Proposition 65 Information
Important Safety Information
Warranty Info & Contact Information
2
3
4
5
6
7
8
9
10-12
13-15
16
17
Table of Contents

STEP 1

STEP 2

STEP 3

STEP 4

STEP 5

0
PAGES
Using thePower / Massage Remote Control
POWERED HEADREST,
LUMBAR, & RECLINE
Adjust your seat to any desired
pasition with the push of a button
Push this side to
return headrest
Push this side to
extend heatrest
Push this side to
return lumbar
Push this side to
extend recline
Push this side to
return lumbar
Push this side to
extend lumbar
head rest
lumbar
recline
HOME BUTTON
push this button to retun
seat to default position
r
4 MASSAGE ZONES
Customize your massage
experiance by contolling which
zones are active. LED's will signify
which zones are currently on if no
zones are selected, then the
massage will turn off
PWT
POWER BUTTON
Turns all massage zones
on/off when pressed
PULSE WAVE ALTERNATING
ZONES
3 MASSAGE MODES
Choose your desired massage
mode by pushing this button
DEEP HEAT RELIEF
Heat On/Off button, This provides
deep relief to your back while this
feature is active

PAGE 9
Troubleshooting Guide
Q. Why doesn't my chair have power?
A. The Power Adapter has become loose or disconnected.
Unplug and re-plug in the
Power Adapter to a wall
outlet.
The green light on the
Power Adapter should be
illuminated.
Unplug and re-plug in the
Power Adapter Cable into
the Seat Base Power
Cable.
The Power Cable Connection has become loose or disconnected.
Q. Why arn't my chair’s power features functioning?
A.
Unplug and re-plug
the Power Cable
Connection to each
other.
Unplug and re-plug in
the Power Adapter to
a wall outlet.
The green light on the
Power Adapter should
be illuminated.
Unplug and re-plug in
the Power Adapter
Cable into the Seat
Base Power Cable.

PAGE 10
The Massage Remote Cable Connection has become loose or disconnected.
Troubleshooting Guide
The Massage Cable Connection has become loose or disconnected.
Q. Why aren't my chair’s Massage Features functioning?
A.
Unplug and re-plug
the Massage Cable
Connection to each
other.
Unplug and re-plug in
the Power Adapter to
a wall outlet.
The green light on the
Power Adapter should
be illuminated.
Unplug and re-plug in
the Power Adapter
Cable into the Seat
Base Power Cable.
Q. Why arn't my chair’s Massage Remote functioning?
A.
Unplug and re-plug
the Remote Cable
Connection to each
other.
Unplug and re-plug in
the Power Adapter to
a wall outlet.
The green light on the
Power Adapter should
be illuminated.
Unplug and re-plug in
the Power Adapter
Cable into the Seat
Base Power Cable.

PAGE 11
Troubleshooting Guide
Q. How do I remove the backrest from the seat base?
A.
Pull up on the locking tab on the
Backrest Female Bracket and firmly
pull the backrest upward.
The Backrest Female Bracket has a locking tab.

LAF Armrest - Power XXXXXXXXXXXXXXX
RAF Armrest Only - Power XXXXXXXXXXXXXXX
PAGE 12
Seatcraft Euphoria Loveseat LAF
TRAY TABLE
PT-STT-1
LAF
Arm
Aligner Kit for Storage Arm
PR-43-503
PR-54-610
Hinge
PR-43-514
Gas Shock
Insert for Cup Holder
PR-43-507
PR-43-511
Cup Holder LED Black Plastic w/USB
Grommet Table Mount Black Chrome
PR-43-515
I
V
Power Adapter AC/DC
PR-21-302
Bracket Backrest Female
PR-54-602
PR-54-622
Mechanism for Recline
Connecting Bracket
PR-65-717
Controller for Heat/Massage
PR-32-401
Seat Bottom
Backrest
Foot plastic for Arm
PR-54-601
Foot Plastic for Metal Base
PR-43-517
PR-54-606
LED Strip
8409
Motor Recliner PR-65-706

LAF Armrest - Power XXXXXXXXXXXXXXX
RAF Armrest Only - Power XXXXXXXXXXXXXXX
PAGE 13
Hinge Spring
PR-54-614 PR-43-511
Cup Holder LED Black Plastic w/USB
Foot Plastic for Metal Base
PR-43-517
Seatcraft Euphoria Loveseat Storage Console
8409

LAF Armrest - Power XXXXXXXXXXXXXXX
RAF Armrest Only - Power XXXXXXXXXXXXXXX
PAGE 14
Seatcraft Euphoria Loveseat RAF
LAF
Arm
Aligner Kit for Storage Arm
PR-43-503
PR-54-610
Hinge
PR-43-514
Gas Shock
Insert for Cup Holder
PR-43-507
PR-43-511
Cup Holder LED Black Plastic w/USB
Grommet Table Mount Black Chrome
PR-43-515
I V
Power Adapter AC/DC
PR-21-302
Bracket Backrest Female
PR-54-602
Seat Bottom
Backrest
Foot plastic for Arm
PR-54-601
Foot Plastic for Metal Base
PR-43-517
PR-54-606
LED Strip
8409
TRAY TABLE
PT-STT-1
Controller for Heat/Massage
PR-32-401
PR-54-622
Mechanism for Recline
Connecting Bracket
PR-65-717
Motor Recliner PR-65-706

Proposition 65 Information
PAGE 15
Why did I find a Proposition 65 warning on my furniture product?
Q.
A. This warning label is very common and can be found on almost every piece of
furniture sold in the state of California. By law the state of California requires that
we include a Proposition 65 warning on all of our products.
A. You might have seen Proposition 65 warning labels at hotels, banks, restaurants,
and even at theme parks. Proposition 65 is a California law that requires warning
labels on products that may contain one of more than 800-plus chemicals or
ingredients that the California Office of Environmental Health Hazard Assessment
(OEHHA) has deemed to cause cancer or other reproductive toxicity. Chemicals
and elements on this list include saw dust, brass, and other everyday substances,
which can be found in very common household items, such as lamps, tableware,
jewelry, crystal glasses, electric cords, beauty products, automobiles, and furniture.
What is Proposition 65?
Q.

Important Safety Instructions
• Do not operate the unit until the back is installed and
locked.
• Closely supervise children and disabled persons using this
product.
• This product has many moving parts, serious injury can
occur if not used properly. Keep children and pets away
from the mechanism. Keep hands, fingers and body parts
away from the mechanism.
• Sit down in the unit slowly. To avoid tip over, do not throw
your weight against the back of the unit. Move the unit into
or out of the reclining position slowly, making sure that no
children or pets are in close proximity.
• Only the occupant should operate the unit. Never attempt
to open the leg rest by pulling on it.
• Do not stand, sit or place extra weight on the arms, back or
open leg rest.
• To safely exit the unit and prevent a tripping hazard bring
the back upright and close the leg rest.
• Provide a clear path for operation of the chair, back and leg
rest. Place tables and area rugs at a distance to allow the
leg rest to fully extend without rubbing or interference.
• Keep hands, arms and body parts away from the open area
between a reclined back and an upright back on a motion
sofa. This area must remain clear at all times to provide
unobstructed movement and prevent injury that could
occur when a reclined back is returning toward the upright
position.
PAGE 16
TO REDUCE THE RISK OF ELECTRIC
SHOCK OR SERIOUS INJURY:
TO REDUCE THE RISK OF BURNS, FIRE,
ELECTRIC SHOCK OR SERIOUS INJURY.
DANGER
WARNING
• Disconnect the electrical plug from the wall outlet before
cleaning, moving, servicing or when not in use for an
extended period of time.
• Do not use this product if it is wet, in water, around water or
any liquid.
• Use care when moving the product. Before lifting the
product, secure the mechanism to prevent unexpected
opening or movement. Never move the product by the
mechanism, leg rest, handle, reclining back or swivel base.
Disconnect modular units. Securely grip non-moving parts
only.
• Do not use this product if it is damaged. Do not use
attachments or substitute parts.
• Check the condition of the power transformer, electrical
cord, plug, and connectors regularly. Keep the power
transformer and electrical cords away from heat sources.
Never operate the unit with a damaged power transformer,
electrical cord, plug or connector.
• Do not use unit if power control is damaged or wet. Do not
use unit if the hand wand has been dropped in water or any
liquid.
• This product is not intended for use as a healthcare device.
• Users of medical devices should contact their healthcare
provider before using this product. Do not use this product
if you have poor circulation, are immobile or cannot sense
heat, except as directed by your healthcare provider.
• This product is intended for indoor residential use only.
• Always keep open flame and lit cigarettes away from
upholstered furniture. Upholstered furniture may burn
rapidly with toxic gas and thick smoke.

PAGE 17
Warranty Information
Seatcraft is proud of its high standards of quality and workmanship that go into our products.
The customer is protected by the following Limited Warranty, which applies to seats under
normal indoor residential use. This warranty does not apply to seats used for commercial,
institutional, or other non-residential uses.
ONE YEAR LIMITED WARRANTY: Seatcraft provides (1) one year comprehensive coverage
for all components such as materials, foam and frame parts, and mechanisms including
motorized parts from defective materials or workmanship.
MATERIAL: Normal fabric fading, shrinking, or stretching is not covered by this warranty.
Similarly, the natural markings, stretching, and shrinking of leather is a proud mark of
authenticity and therefore not covered by this warranty. Evidence of improper cleaning, abuse,
or abnormal use of the materials will void this warranty.
FOAM AND FRAME PARTS: Seatcraft warrants these components for (1) one year from the
time of delivery, against manufacturing defects. Foam compression is natural, and therefore
not covered by this warranty.
MECHANISMS: Seatcraft warrants these components for (1) one year from the time of delivery,
against manufacturing defects. After the warranty period, the customer is responsible for
inspection, labor and transportation costs.
No warranties, express or implied, apply after the expiration of this Limited Warranty. The
warranty period covers repair, substitution, and replacement. No returns or refunds are
covered. A proof of purchase is required to service a claim; simply present the bill of sale to the
dealer from whom the item was purchased, to request warranty service. Seatcraft is not liable
for incidental or consequential damages occurring outside the terms of this warranty, even if
advance knowledge of such damages was possible.
Contact Information
We’re here to help. For any missing or damaged parts or installation assistance please call us
at 1-855-244-0170.
HOURS
Mon-Fri 6AM - 7PM PST
Sat 9AM - 5PM PST
Sun 10AM - 5PM PST
