SeaView PM5-FMT-8 User manual

INSTALLATION
INSTRUCTIONS
For Seaview Camera Mount:
PM5-FMT-8
WWW.SEAVIEWGLOBAL.COM
Refer to website for most up to
date instructions and videos.

M6 x 12 ¼ - 20 x 7/8”
PARTS INCLUDED
TOOLS NEEDED
x1
x4 x4 x4
x1 x6 x4
Sudbury Elastomeric
Marine Sealant is
recommended. To
purchase call 800-655-7922
or visit
www.seaviewglobal.com

1
2
3
Mark the four base holes for
drilling.
Drill the four holes.
Using a hole saw, drill a hole
for the cable.

M6 x 12
4
5
6
Insert the four nuts into the
adpater plate as shown.
Note that this may have
already been done for you.
Route the cables through the adapter plate and secure the camera to
the adapter plate using the provided six M6x12 bolts.
Route the cables and place
the assembly onto the
PM5-FMT-8 mount.

¼ - 20 x 7/8”
7
8
Secure the assembly using the provided four washers and
1/4-20x7/8” bolts.
Apply marine adhesive
sealant to the base of the
mount.

x4
9
10
Route the cables through the
mounting surface and place
mount onto surface.
Apply marine adhesive sealant to the four nylon shoulder
washers and insert into the four bolt holes on the base. Use
your own hardware to secure mount into place.
