TM
SEGA SATURN
Sound Tools Manual
Supplement
Doc. # ST-198-R1-121594
• SEGA SATURN Sound Tools Manual V1.27 11/15/94
• SATURN Sound Driver System Interface V3.02 12/1/94
• SATURN Sound Simulator Manual V2.10 11/15/94
© 1994-95 SEGA. All Rights Reserved.

SEGA Confidential
READER CORRECTION/COMMENT SHEET
Chpt. pg. # Correction
Corrections:
General Information:
Your Name Phone
Document number ST-198-R1-121594 Date
Document name SEGA SATURN Sound Tools Manual Supplement
Questions/comments:
Keep us updated!
If you should come across any incorrect or outdated information while reading through the attached
document, or come up with any questions or comments, please let us know so that we can make the
required changes in subsequent revisions. Simply fill out all information below and return this form to
the Developer Technical Support Manager at the address below. Please make more copies of this form if
more space is needed. Thank you.
Where to send your corrections:
Fax: [phone]
Attn: Evelyn Merritt,
Developer Technical Support
Mail: SEGA OF AMERICA
Attn: Evelyn Merritt,
Developer Technical Support
150 Shoreline Dr.
Redwood City, CA 94065

SEGA Confidential
REFERENCES
In translating/creating this document, certain technical words and/or phrases were interpreted
with the assistance of the technical literature listed below.
1. Dictionary of Science and Engineering, 350,000 words, 3rd Edition
Inter Press
Tokyo, Japan
1990
2. Computer Dictionary
Kyoritsu Publishing Co., LTD.
Tokyo, Japan
1978
3. IBM Dictionary of Computing
McGraw-Hill, Inc.
New York, New York
1994

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 1
Contents
1 SEGA Custom Sound Processor (SCSP) ...................................................... 2
2 SEGA SATURN Sound Box (Model M) .......................................................... 3
3 Sound Development Tools and Library Provided by SEGA............................4
4 Functions of the Wave Editor ......................................................................... 5
5 Functions of the Tone Editor .......................................................................... 5
6 Functions of the DSP Linker .......................................................................... 6
7 List of MIDI Channel Messages Supported by Sound Driver Version 1.27 ....7
8 List of MIDI System Messages Supported by Sound Driver Version 1.27....10
9 Sound Driver CPU Execution Times ............................................................ 11
10 Explanation of the Rear Panel LEDs on the Sound Target Box ................... 11
11 Precautions for the DSP Linker Version 1.11 ............................................... 13
12 Precautions for the Sound Simulator ........................................................... 13
13 Precautions for the Tone Editor Version 1.13 and
Sound Driver Version 1.27 ........................................................................... 14
14 Precautions for the Wave Editor Version 1.13 .............................................. 15
15 Problems with Sound Playback Control ....................................................... 16
16 Recommended Third Party Software/Hardware Tools for Sound/Music
Development................................................................................................ 16

SEGA Confidential
2
1. SEGA Custom Sound Processor (SCSP)
1. Overview
· The clock speed of the SCSP chip is 22.58 MHz.
· The playback sampling frequency is 44.1 kHz.
· DMA is built in.
2. Generator
· PCM waveforms can be assigned individually to the 32 slots (oscillators)
separately. The standard AIFF format is used for the PCM waveform data, and
16-bit and 8-bit linear data are used. The ADPCM format is also supported. Each
of the slots has a completely independent LFO and envelope, and loop playback
of PCM waveforms can be set to any one of four modes: ONESHOT, FORWARD,
REVERSE and ALTERNATE.
·FM
One slot can be freely assigned as a carrier or a modulator, and a self-feedback
feature is also available. A waveform that can sufficiently stand up to
practical use can be output by the use of the self-feedback feature alone, in which
case the maximum FM output polyphony is 32 notes.
3. Built-in Sound DSP
· A sound DSP that can be programmed up to 128 steps is built in the SCSP. The 16
effects that are standard in the DSP library include Reverb, Early Reflection (ER),
Delay, Pitch Shift, Chorus, Flanger, Symphonic (type of Chorus), Surround (type of
Reverb), Voice Canceler, Auto Pan, Phaser, Distortion, Filter (high-pass, low-pass,
band-pass), Dynamic Filter, Parametric EQ, and Mixer. The addition of an expansion
library that includes 3D sound is currently under development.

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 3
4. Dedicated CPU for Sound Control
· A 16-bit 11.3 MHz 68EC000 is used as the sound control CPU for the
SCSP. The 68EC000 is connected directly to the SCSP and operates independently
of the SH2. The interface also allows access of the SCSP from the SH2. During
access from the SH2, neither the SCSP nor 68000 CPU will stop. However, since
time-shared processing is used, the performance of the 68000 CPU will decrease
if there is frequent access from the SH2.
2. SEGA SATURN Sound Box (Model M)
The SEGA SATURN Sound Box (Model M) has two sets of MIDI IN, OUT and THRU
ports and a SCSI port, so it may be operated like a commercially available MIDI sound
module.
Also, beginning with version 1.21 of the sound driver, error codes can be output from
the MIDI OUT port, thus making it possible to detect data problems.

SEGA Confidential
4
3. Sound Development Tools and Library Provided by SEGA
· Sound Simulator
· Tone Editor
· Waveform Editor
· DSP Linker and DSP Effect Library
· Macintosh-based 68000 Assembler programming tool (SDSS)
· Macintosh-based 68000 debugging tool (SSBug)
· Invision sound library
· DSP Assembler for the SCSP (dAsm)
· Development board diagnostics program
· Sound driver
· Installation guide and ReadMe file explaining the use of the development board
diagnostics program.
· Sample demo tune
In addition to the resources above, manuals such as this one are provided by SEGA.
The SCSI firmware and the development board diagnostics program are supplied as
ROMs on the development board.

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 5
4. Functions of the Wave Editor
· Supports 16-bit and 8-bit AIFF formats
· The following are editing functions that can be applied to waveforms.
Resample
Pitch Shift
Size Shift (time compression)
Scale (normalize)
Filter
Compressor
Noise Gate
Cross Fade
Fade In
Fade Out
5. Functions of the Tone Editor
· FM sound editing with a graphical user interface.
· Velocity curves can be set as desired.
· Supports hardware LFO from 0.17 to 172.3 Hz.
· Supports playback range from -8 octaves to +7 octaves.
· Graphical editing of a 5-parameter envelope.
· Effect send level, effect return level and pan/mixer settings for 16 channels.
· Ability to edit a maximum of up to 128 layers and 128 voices.

SEGA Confidential
6
6. Functions of the DSP Linker
· The following are the standard DSP effects:
Reverb
ER (Early Reflection)
Delay
Pitch Shift
Chorus
Flanger
Symphonic (type of chorus)
Surround (type of reverb)
Voice Canceler
Auto Pan
Phaser
Distortion
Filter (high-pass, low-pass, band-pass)
Dynamic Filter
Parametric EQ
Mixer (2 input, 3 input, 4 input, 8 input)
· Can patch input and output for up to 16 channels.

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 7
7. List of MIDI Channel Messages Supported by Sound Driver
Version 1.27
Supported: 8nH Note Off
Supported: 9nH Note On
Ignored: AnH Polyphonic Key Pressure (no plan to support)
Supported: CnH Program Change
The voice number in the tone bank (SCSP.BIN) is set for each MIDI channel.
If the voice number does not exist in the corresponding tone bank, the previous
voice number (program #) is assigned. When in default mode, the program
number is set to “0” for all MIDI channels.
Ignored: DnH Channel Pressure (no plan to support)
Supported: EnH Pitch Bend
: BnH control change
Supported: 01H Modulation Wheel Sound Generator Hardware LFO
Ignored: 01H Modulation Wheel Sound Generator Software PEG
Ignored: 01H Modulation Wheel Sound Generator Software PLFO
Ignored: 05H Portamento Time
Supported: 07H Volume Control
The volume can be adjusted for each MIDI channel. When the parameter is
set to “0”,the volume is at MIN, and when it is set to “7FH (127)”, it is at MAX.
Since this indicates amplitude attenuation and is not a scaling factor, use caution.
The volume control functions even if issued during a note on event, but depending
on the waveform, there may be some hardware-based noise (clicks, pops) due to the
difference in volume.

SEGA Confidential
8
Supported: 0AH PAN pot
Rewrites the layer parameter DIPAN of all applicable voice numbers in the tone
bank (SCSP.BIN) that is set for each MIDI channel.
The normal default fixed position is the pan setting of the original voice data. When
a MIDI program change is issued, the pan control data of the applicable MIDI
channel become invalid.
Supported: 10H Mixer change
Uses MIDI control number 16.
When this control change is issued, the data of the applicable mixer number in
the tone bank (TONE.BIN) of the applicable MIDI channel are written to the
DSP block (EFREG0-15, EXTS0, EXTS1) of the SCSP sound generator. Therefore, it is
important to understand the DSP effect status when a mixer change command is
issued. Also, if the specified mixer number is invalid (data does not exist), then it is
ignored.
Mixer # 0 of bank # 0 in map # 0 is set as the default.
Supported: 20H Tone bank change
The start address of the specified tone bank TONE.BIN is retrieved from the
current Area Map. After this is done, the pitches accessed by the applicable
channel are from this TONE.BIN. Also, since the voice number (program #) of
the corresponding MIDI channel is forced to “0” at the same time, it is necessary
to set the voice number by means of a MIDI program change command before a new
sound is played.
Bank # 0 is set as the default.
Supported: 40H Damper
When the damper is enabled (on), key-off of the applicable channel is no
longer executed. When the damper is disabled (off), all of the slots that were turned
on during the damper-enabled period of the applicable channel are turned off.

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 9
Ignored: 41H Portamento ON/OFF
Supported: 46H Effect Pan Change
Supported: 47H Effect Volume Change
This changes the currently active mixer data. Since the tone bank data
TONE.BIN is directly rewritten at this time, it is necessary to download mixer
data again from the host to return the mixer to its original settings.
The channel number corresponds to EFREG0--15, EXTS0, and 1of the sound
source DSP block.
Supported: 5BH Effect Change
Supported: 7BH Channel Note Off

SEGA Confidential
10
8. List of MIDI System Messages Supported by Sound Driver
Version 1.27
Supported: $F0 Exclusive (see other table)
Ignored: $F1 Quarter Frame Message (no plan to support)
Ignored: $F2 Song Position Data (no plan to support)
Ignored: $F3 Song Select (no plan to support)
Ignored: $F4 (no plan to support)
Ignored: $F5 (no plan to support)
Ignored: $F6 Tune Request (no plan to support)
Supported: $F7 End of Exclusive
Ignored: $F8 Timing Clock (no plan to support)
Ignored: $F9 (no plan to support)
Ignored: $FA Start (no plan to support)
Ignored: $FB Continue (no plan to support)
Ignored: $FC Stop (no plan to support)
Ignored: $FD (no plan to support)
Ignored: $FE Active Sensing (no plan to support)
Supported: $FF System Reset
* When a system reset [=$FF] MIDI system message or a System Exclusive reset is received,
the sound target program starts up.
System Exclusive Command Table
Command
$00: Data Dump Request Saturn ←External
$01: Set Data Saturn ←External
$02: Acknowledge Saturn ←→ External
$03: Not Acknowledged Saturn ←→ External
$04: Reset Saturn ←External
$05: Tone Bank Data Change Saturn ←External
$41: Data Dump Saturn →External

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 11
9. Sound Driver CPU Execution Times
Software DSP control is executed in 8 ms.
Software PLFO control is executed in 4 ms.
Other target programs are executed in 2 ms.
10. Explanation of the Rear Panel LEDs on the Sound Target Box
The LED’s flash in sequence from LED 1 to LED 8 while the boot ROM is
starting up. This operation is momentarily interrupted while data is being transferred
using the SCSI interface but is restored upon completion of the transfer.
When the target program is executed after being transferred, LED 1 flashes, which
confirms that the CPU is operating normally.
The flashing of other LED’s while LED 1 is flashing (CPU is operating normally)
indicates the following.
LED 2: CPU is operating at its maximum capability.
LED 3: Interrupts for BGM decompression (normally flashes) in progress.
LED 4: Ignore
LED 5: Ignore
LED 6: Ignore
LED 7: MIDI input from MIDI-IN2 on the board.
LED 8: MIDI input from MIDI-IN1 on the board.

SEGA Confidential
12
Also, flashing of the other LED’s when the LED 1 is off indicates the following errors
(if continuously on, then either the SCSI interface is being used or the SCSI driver
has halted).
LED No. Description
1 2 3 4 5 6 7 8
- - - - - - 0 0 YM3802(MIDI-1) IRQ vector error
- - - - - 0 - - // (MIDI-2) //
- - - - - 0 - 0 MIDI data error
- - - - - 0 0 - YM3802 (MIDI-1) MIDI out error
- - - - - 0 0 0 // (MIDI-2) //
- - - - 0 - - - MIDI control change $60-$7F input
- - - - 0 - - 0 Host I/F command execute error
- - - - 0 - 0 - . . . .
- - - - 0 - 0 0 . . . .
- - - - 0 0 0 - Map change error
- - - - 0 0 0 0 Bank change error
- - - 0 - - - - Mixer change error
- - - 0 - - - 0 Effect change error
- 0 - - - - - - 68k undefined vector event
- 0 - - - - - 0 . . . .
- 0 - - - - 0 - 68k bus error
- 0 - - - - 0 0 68k address error
- 0 - - - 0 - - . . . .
- 0 - - - 0 - 0 68k level-3 event
- 0 - - - 0 0 - 68k level-4 event
- 0 - - - 0 0 0 68k level-7 event
- 0 - - 0 - - -
- 0 - - 0 - - 0

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 13
11. Precautions for the DSP Linker Version 1.11
· Modulation system effects cannot be used in version ES1 of the SCSP chip. It is
recommended that they be used in versions ES2 and ES3.
· All modulation voices must be keyed on as monophonic sounds (due to a bug in
Version 1.27 of the sound driver, use of the Tone Editor parameter MONO mode
should be avoided).
· Ring Buffer in the Option Menu
The Ring Buffer menu item is used to set the size of the ring buffer (memory for
delay) used in the algorithms that are being edited. The ring buffer is located in
the 4 MB sound DRAM. If the buffer size is too small, an error will occur when
linking is executed. Even if the link is successful, it is recommended that the data
size be set to the required minimum size by referring to the information
contained in the link result dialog box.
· Since a slight noise glitch will result during an effect change due to the SCSP's
chip design, the effect return level can be lowered through a mixer change com-
mand if the noise is annoying.
12. Precautions for the Sound Simulator
· Place SYSTBL.TSK and SDDRV.TSK in the same folder as SndSimulator. Also, do
not change the names of these files.

SEGA Confidential
14
13. Precautions for the Tone Editor Version 1.13 and Sound Driver
Version 1.27
· Only the poly mode is not supported. Do not use the mono mode since it has a
playback bug.
· PORTAMENTO TIME and VOLBIAS in the voice window do not function.
· Pan and Vol settings made with MIDI Control Change Events commands do not
take effect until a voice of that channel is turned on again.
· There are several bugs in the operation of the PEG, so it may not operate as
expected.
· The data format of the Tone Editor has been changed. Data created with Version
0.91 and older cannot be used.
· When playing a voice, send the number corresponding to the program change.
If the program change number of a nonexistent voice is sent, then it is ignored.
· The Tone Editor references AIFF data by file name to prevent the increase in the
amount of data due to redundant tone data. That is, if AIFF data is selected that is
the same as another layer in the same tone data, then the data is not loaded again.
Instead, the AIFF data already stored in DRAM from the preceding tone is used.
Therefore, even if an AIFF file captured to the tone data is edited with a waveform
editor, the Tone Editor will not read the newly edited AIFF data if the file name is
the same. Because of this, the tone data will not be updated. To load the data,
either change the file name or load it again after loading different data.

SEGA Confidential
SEGA SATURN Sound Tools Manual Supplement 15
14. Precautions for the Wave Editor Version 1.13
· When recording audio, be sure to record after creating a new file with the New
command.
· When playing back audio from memory, noise will be output after 7FFEH if the
SCSP version being used is ES2.
· The only waveforms that can be played back in a loop are those with a sample size
of less than 65535 (FFFEH) bytes. A sample size greater than FFFEH cannot be
played back during memory playback, and therefore the unnecessary
parts should be cut and the loop switched off or the loop should be reset.
· The Play Audio playback in the SCSP menu results in the Play button being de-
pressed, and therefore Stop should be applied when appropriate. When the
Macintosh itself is used for playback, notes at the high end of the keyboard are not
played because the Macintosh Sound Manager will not produce sounds above
65.535 Hz. Also note that popping sounds may be emitted; however, this not a bug.
· Since the DRAM of the 68000 is used as a work area during hard disk recordings,
everything above address 10000H is destroyed.
· Due to hardware limitations, stereo hard disk recording is not possible.
· Only 44.1 kHz can be used as the input sampling frequency (fs). Do not input audio
data at other sampling frequencies.
· When using DAT output, second generation digital data recording (copying)
cannot be performed due to the Serial Copy Management System (SCMS).
· The bug that prevented the loading of AIFF files created by Sound Designer II in
version 1.00 has been corrected. However, since the LoopStartPoint, LoopEndPoint,
BaseNote and other settings are ignored, reset them after loading the data in with
the Wave Editor. Also, since files loaded in with the Wave Editor are forcibly
overwritten by default (a warning in English is displayed when opening), make
sure to save a copy if necessary.
· Be sure to set the loop start and end points. Since these settings enable the
Tone Editor to generate sounds, no sound will be generated if 0’s or other incorrect
values are used. In the case of single-shot playback samples in which a loop is not
used, be sure to set loop start to 1 and end point to the same value as the sample
size.

SEGA Confidential
16
15. Problems with Sound Playback Control
· The Version 1.00 specification which required that the MIDI channels of sequences
that could be simultaneously played to be set to different channels has been
changed to a method that plays the sequences (songs, SE) by means of playback
control numbers. Refer to the SATURN Sound Driver System Interface manual for
details.
· Make sure that the tempo of the sequence does not exceed the range of 40 to
300 quarter notes.
16. Recommended Third Party Software/Hardware Tools for
Sound/Music Development
· Contact the following companies for MIDI sequencers:
Performer from Mark of the Unicorn
Vision from Opcode Systems
Cubase from Steinberg
Notator Logic from E-Magic
* Basically, any sequencer that runs on either the NEC 9801 or the IBM PC compatible may also be
used as long as it can output standard Type 1 MIDI format files.
· For advanced PCM waveform editing (requires the Audio Media II or other
sound card), contact these companies:
Alchemy from Passport Design
Sound Designer II from DigiDesign
· CD players with optical output and DAT recorders.
