J5060098 v3.0
Digital room unit DD1 can be
used with following controller
types:
COMPACT CMP12+
COMPACT CMP12+/R
TERAMATIK D1
TERAMATIK D2
ALL HRD CONTROLLERS.
User manual
Setting manual
Installation manual
DIGITAL ROOM UNIT
DD1
SELTRON d.o.o.
Ruška cesta 96
SI-2345 Bistrica ob Dravi
Slovenija
tel: [phone]
fax: [phone]
http: //www.seltron.si
Email: [e-mail]
J5060098 v3.0
Digital room unit DD1 can be
used with following controller
types:
COMPACT CMP12+
COMPACT CMP12+/R
TERAMATIK D1
TERAMATIK D2
ALL HRD CONTROLLERS.
User manual
Setting manual
Installation manual
DIGITAL ROOM UNIT
DD1

We are thanking you for your confidence by buying a
SELTRON product.
We will further try to deepen and strengthen your confidence
by improving quality of products, information's and service.
If you want to take advantage of all device capabilities, you
must carefully read this user manual. Keep this manual at
hand for further reference.
After you no longer need this device please take care of
proper removal.
Thank you very much for your confidence. You selected a
qualitative and modern concept of central heating control.
2 43
Technical data
Rated operating voltage.....................8 V d.c.; max. 20 V d.c.
Rated supply current..........................max. 5 mA d. c.
Controller case...................................ABS - thermoplastics
Dimensions (W x H x D): .................72 x 112 x 32,5 mm
Weight unit .......................................88,0 g
Weight unit with packaging..............122,0 g
Ambient temperature.........................5 °C ... 40 °C
Storage temperature...........................-20 °C ... 65 °C
Temperature setting range .................+10 °C ... +30 °C
Type of temperature sensors..............Murata NTC
Frost protection temperature..............+6 °C
Degree of protection..........................IP30 EN 60529
This user manual is written for software version 2.0
or above, except where extra stated.
We are thanking you for your confidence by buying a
SELTRON product.
We will further try to deepen and strengthen your confidence
by improving quality of products, information's and service.
If you want to take advantage of all device capabilities, you
must carefully read this user manual. Keep this manual at
hand for further reference.
After you no longer need this device please take care of
proper removal.
Thank you very much for your confidence. You selected a
qualitative and modern concept of central heating control.
2 43
Technical data
Rated operating voltage.....................8 V d.c.; max. 20 V d.c.
Rated supply current..........................max. 5 mA d. c.
Controller case...................................ABS - thermoplastics
Dimensions (W x H x D): .................72 x 112 x 32,5 mm
Weight unit .......................................88,0 g
Weight unit with packaging..............122,0 g
Ambient temperature.........................5 °C ... 40 °C
Storage temperature...........................-20 °C ... 65 °C
Temperature setting range .................+10 °C ... +30 °C
Type of temperature sensors..............Murata NTC
Frost protection temperature..............+6 °C
Degree of protection..........................IP30 EN 60529
This user manual is written for software version 2.0
or above, except where extra stated.

Error display
By an error will the display rotate between one of following
error messages:
Error in temperature measurement
in room unit DD1.
One or more sensors have a
malfunction, battery or DD1
synchronisation error.
Communication malfunction
between DD1 and the controller.
Error ERR 02 will always occur by the first connec-
tion of DD1 to the controller, because DD1 isn't
synchronised with the controller. Please see the
chapter “ Synchronising DD1 with the controller”
and perform the needed actions.
Error in temperature measurement
in the separated sensor.
42SETTING MANUAL 3
