SEMAK VCE1500 Installation and operation manual

SEMAK VITACRUSH BAR BLENDERS
MODELS VCE1500, VCM1500, VCM1390 &VCE1050
SEMAK AUSTRALIA:FACTORY 18, 87-91 HALLAM SOUTH ROAD,HALLAM VIC 3803
PH 03 9796 4583 FAX [phone] WEB WWW.SEMAK.COM.AU
OPERATION AND WARRANTY BOOKLET
VCM1390R VCE1050B VCE1500B

Page | 2
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS.................................................................... 4
BLENDER MODELS ............................................................................................... 6
OPERATING INSTRUCTIONS: VCE150B & VCE1050 .............................................. 7
OPERATING INSTRUCTIONS: VCM1500 & VCM1390............................................ 8
CLEANING & MAINTENANCE INSTRUCTIONS....................................................... 9
SERVICE & MAINTENANCE ................................................................................... 9
SPARE PARTS........................................................................................................ 9
WARRANTY .......................................................................................................... 9
WARRANTY REGISTRATION.................................................................................11

Page | 3
RETAIN THESE SAFETY INSTRUCTIONS

Page | 4
IMPORTANT SAFETY INSTRUCTIONS
Please read all of the instructions before using the Vitacrush blender and ensure
that other operators also read and are made to understand all safety and operating
instructions. Save these instructions for Future reference.
Thank you for purchasing a Semak Vitacrush Blender.
1. Important notice: Ensure that the power supply is switched off before connecting
to the electric outlet.
2. Use only on AC 220-240V –50 Hz only.
3. Do not use an extension cord.
4. To avoid risk of electric shock, do not immerse cord, plug or motor end of the
appliance in water or any other liquid. Never put the Vitacrush in a dishwasher.
5. Always switch off at the power outlet before removing the plug. Remove by
holding the plug - do not pull on the cord. When the appliance is not in use, or
prior to cleaning, always switch off the power and removes the plug.
6. Disconnect power cord from the electrical outlet when the blender is not in use.
7. The Vitacrush blender should not be used by children or infirm persons and care
should be taken when used near these persons. The Vitacrush blender should not
be used outdoors. Young children should be supervised to ensure that they do not
play with the appliance. Never leave the blender unattended.
8. Avoid physical contact with moving parts. The cutting blades are very sharp and
care is needed when handling cutting blades, and only when the Vitacrush
blender is disconnected from the power supply. Never attempt to touch the
cutting assembly when the blender is in operation.
9. Never operate the Vitacrush without the container securely in place. Never
operate the Vitacrush with an empty container.
10.Do not use on the stove or let the cord come into contact with any hot surface.
11.Keep hands and utensils out of the container while using the Vitacrush to prevent
the possibility of severe injury to persons or damage to the unit. A plunger is
supplied to aid in getting the contents of the container from the sides to the
blades.

Page | 5
12.WARNING: Blade is sharp. Please handle carefully.
DO NOT try to remove blade while the container is sitting on the motor base.
DO NOT operate with loose, nicked or damaged blade replace immediately.
CAUTION keep all utensils AWAY FROM the drive socket and blender blades during
operation. Metal utensils will damage blades.
DO NOT place container into drive socket if blender motor is operating.
DO NOT rock the blender during operation.
13.When blending liquids, especially hot liquids, ensure that the lid is on securely and
the lid insert is in place to reduce the risk of spillage and injury. Hot liquids build
up steam pressure and special care must be given when removing the container
and lid from the blender that the contents don’t splatter and burn the operator.
Keep hands, arms and face away from the lid insert to prevent possible scalding.
DO NOT start blending hot liquids on HIGH speed. Always start processing hot
liquids on LOW speed then increase while the machine is running.
14.Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, is dropped or damaged in any way. Return the appliance to Semak
Australia. (Manufacturer) or its Authorised Service Agent for repair. Do not
attempt to repair the machine.
15.For Safety reasons and to avoid maintenance by unskilled persons, the appliance
should always be returned to Semak Australia. (Manufacturer) for adjustment or
repair if required.
WARNING –This appliance should be used according to the
instructions.
MISUSE of this appliance will cause HAZARD.

Page | 6
BLENDER MODELS
VCE1500 & VCE1050
VCM1500 & VCM1390

Page | 7
OPERATING INSTRUCTIONS: VCE150B & VCE1050
The Semak Vitacrush chops, blends and mixes quickly and efficiently. Use it to make
sauces, soups, purees etc.
1. Before connecting to electrical outlet, wash the container and its parts and also,
wipe the blender base with a damp cloth.
2. Ensure that the power supply is also switched off before connecting to the
electrical outlet. Turn the power ON.
3. Turn the blender ON at the switch found at the rear left hand side of the machine.
4. Place the container on the blender. Ensure that the lid and insert are properly
located on the container. If a sound cover is being used, close the sound cover
before operating the blender.
5. Choose a program e.g. 45, 75 or 105 seconds (timed) or select a speed eg. High
Medium or Low. Press the appropriate button. Note if a speed has been selected
pressing the pulse button alters the speed of the motor to vary the blending
action.
6. Motor cuts off automatically once the timer reaches the desired blending cycle. If
using the speed option simply repress the button selected and the blender will
stop. To prevent splashing, do not lift the container lid or open the sound cover
whilst still in operation.
7. When mixing or blending hot ingredients, the following precautions should be
observed:
Take care not to lift the lid without checking if pressure has built up in the
container. Release pressure slowly by turning the lid insert a little allowing
steam to escape and taking care not to burn fingers.
Do not stand directly over container of hot ingredients when removing the lid.
If necessary allow to stand so that steam escapes slowly.
8. Do not leave the blender unattended or leave contents in the container when not
in operation.
9. The blender is overload protected. If the motor gets too hot it will cease to
operate. Allow the blender to cool down then reset the overload switch by
pressing the button located on the bottom right hand side of the rear of the
appliance.
10.If the overload is tripped it may be necessary to modify how or what you are
blending e.g. Reduce the amount being blended to smaller amounts or reduce the
time selected or add more liquid. Seek advice if necessary.

Page | 8
OPERATING INSTRUCTIONS: VCM1500 & VCM1390
The Semak Vitacrush chops, blends and mixes quickly and efficiently. Use it to make
sauces, soups, purees etc.
1. Before connecting to electrical outlet, wash the container and its parts and also,
wipe the blender base with a damp cloth.
2. Ensure that the power supply is also switched off before connecting to the
electrical outlet. Turn the power ON.
3. Turn the blender ON at the switch found at the rear left hand side of the machine.
4. Place the container on the blender. Ensure that the lid and insert are properly
located on the container. If a sound cover is being used, close the sound cover
before operating the blender.
5. Turn the ON OFF switch to the on position. Use the variable speed control knob to
select the speed that you want to blend at. Use the pulse switch to pulsate the
mixture as required.
6. To prevent splashing, do not lift the container lid or open the sound cover whilst
still in operation.
7. When mixing or blending hot ingredients, the following precautions should be
observed:
Take care not to lift the lid without checking if pressure has built up in the
container. Release pressure slowly by turning the lid insert a little allowing
steam to escape and taking care not to burn fingers.
Do not stand directly over container of hot ingredients when removing the lid.
If necessary allow to stand so that steam escapes slowly.
8. Do not leave the blender unattended or leave contents in the container when not
in operation.
9. The blender is overload protected. If the motor gets too hot it will cease to
operate. Allow the blender to cool down then reset the overload switch by
pressing the button located on the bottom right hand side of the rear of the
appliance.
10. If the overload is tripped it may be necessary to modify how or what you are
blending e.g. reduce the amount being blended to smaller amounts or reduce the
time selected or add more liquid. Seek advice if necessary.

Page | 9
CLEANING & MAINTENANCE INSTRUCTIONS
Always unplug the Vitacrush blender from the power source before cleaning. The unit is
easiest to clean by placing water in the container immediately after completing the
blending task and running the blender to dislodge blended mixture. Repeat with fresh
water until the water runs clear. Wash with a HACCP detergent and rinse clean for more
stubborn soiling.
A HACCAP sanitizer may be used to minimize bacterial contamination.
Do not place Vitacrush containers in a dishwasher.
Clean motor wiping with a barely damp cloth only.
Never immerse the motor end, plug or cord in water or any other liquid.
The bearing should be lubricated occasionally with a HACCP approved food grade
lubricant by placing a couple of drops at the base of the cutting unit and drive shaft.
Spin the blade to assist in the dispersion of lubricant into the bearing.
SERVICE & MAINTENANCE
For Service and Repair, contact Semak for your nearest Authorised Service Agent.
The Foodservice Industry is deemed a hostile environment within the scope of AS/NZS
3760:2003. Semak Vitacrush MUST be routinely electrically tested for compliance with this
standard if used commercially.
It is recommended that a Food Safety program such as HACCP be employed and that
routine service and repair be undertaken at the time of electrical testing to ensure the
correct operation and function of all parts. The equipment MUST be serviced annually or
sooner depending of the hostility of the environment in which it is operated.
SPARE PARTS
Spare Parts, exploded views and wiring diagrams are available from our webpage. Go to
www.semak.com.au and locate the appliance in the product section for the above
information.
WARRANTY
Semak Vitacrush Blenders are Commercial Grade blenders suitable for commercial use. This
product is guaranteed for 12 months from the date of purchase against mechanical and
electrical defects. If the fault is deemed caused by MISUSE/ABUSE the terms of the
warranty are invalidated. If the product has been opened or tampered with (ie. In an
attempt to repair it) the warranty is invalidated.
All warranty repairs should be undertaken by Semak Australia.
It is against company policy to authorize warranty repairs over the phone. Service Agents
will require a work order number from Semak to conduct warranty repairs.

Page | 10
SEMAKWARRANTY
THIS WARRANTY APPLIES ONLY TO PRODUCTS MANUFACTURED AND SOLD IN AUSTRALIA
The benefits conferred by this warranty are an alternative to all other rights and remedies
in respect of the product which the consumer has under the Trade Practices Act and similar
State and Territory Laws.
Semak Australia. Warrant each new SEMAK appliance manufactured by SEMAK to be free
from defects in materials or manufacturing process for a period of 1 Year from the date of
original purchase.
Should defects due to faulty materials or manufacturing process develop within the
warranty period, the appliance will be repaired without charge providing all conditions of
this warranty are observed.
1. Proof of Purchase and Warranty card must be retained and available on request.
2. This Warranty is void if the equipment has been damaged due to misuses neglect or is
used for a purpose for which it was not suited; and no repairs, alterations or
modifications have been attempted by other than Semak or its authorised Service
Agent.
3. Semak Australia. Reserves the right to reject a claim for warranty if service is required
due to misapplication, improper installation, inadequate wiring, and incorrect voltage
conditions. Under no circumstances shall SEMAK or its agents bear responsibility for
consequential damages of any kind.
4. Where required by Statute or local authority, equipment must be installed by qualified
person in accordance with all relevant regulations. Failure to do this will void product
warranty.
5. Cost of transport of any appliance or part to and from SEMAK or its Service Agent is to
be paid by the owner.
6. A charge will be made where failure is due to neglect, abuse or accidental damage on
the part of the operator, or when no fault can be found or the fault is due to causes
outside the control of Semak Australia.
7. The above does not preclude the purchaser from their Statutory rights as a consumer.
Semak Australia
Factory 18
87-91 Hallam South Road
HALLAM VIC 3803
Ph 03 9796 4583
Fax [phone]
Email techn[email protected]
Web www.semak.com.au

Page | 11
WARRANTY REGISTRATION
Retain for Future Reference
DO NOT SEND
Please complete one registration for each Semak appliance.
You may be required to provide this information when requesting after sales service. Please
staple your proof of purchase to this page.
Company Name: ________________________________________________
Company Address: ________________________________________________
Business Type: ________________________________________________
Contact: ________________________________________________
Phone: ________________________________________________
Fax: ________________________________________________
Email: ________________________________________________
Product: ________________________________________________
Serial Number: ________________________________________________
Date of Purchase: ________________________________________________
Place of Purchase: ________________________________________________

Page | 12
© Semak 2015
