Semtech IOT8EUSBREF-1 User manual

Smart Building
Reference Kit
User Guide
(“User Guide”)
IOT8EUSBREF-1 (EU 868)
IOT9USSBREF-1 (NA 915)
August 2019

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Welcome!
The Smart Building Reference Kit (“Kit”) is designed to provide validation of the network coverage within a
building, accelerate solution development and facilitate a portable demonstration to a wide range of stakeholders.
By moving the location of the sensors to different spots around the building, users can determine a gateway’s
range of coverage.
By relying on readily-available hardware, solution developers can focus on providing customer value through data
collection and analysis while using off-the-shelf hardware available from external suppliers.
The self-contained nature of the Kit makes it easy to set up, take down and move the network in a matter of
minutes.
All data collected in the Kit is displayed on a dashboard accessible by the user via a browser. The dashboard shows
the type of display which can be created with the data collected. The URL for the dashboard and how to locate
the log in credentials for your Kit, are explained under the Getting Started section of this User Guide.
Note: The Kit does not allow access to the underlying data directly or the ability to change the LoRaWAN-enabled
network server (LNS) to which the gateways are connected. If those are desired requirements, please contact
Semtech at [email protected].
Additionally, the user may separately access a dashboard that shows a permanent installation of a Kit inside an
office facility. This provides the user with a rich set of historical data to use in demonstrations. To access this
dashboard, log in to the following site, using the credentials below:
URL: lora-developers.semtech.com/smart-building-kit
Login: SemtechDemo1
Password: LoraWan592
The data in each dashboard is stored for a maximum of 30 days.
To provide the best user experience, we recommend visiting our LoRa® Developer Portal and downloading the
latest version of this User Guide.
https://lora-developers.semtech.com/resources/developer-kits/smart-building-kit/smart-building-kit-welcome/

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
What is in the Kit?
The Kit contains the following:
 5 desk sensors
 2 Grid-EYE® Sensors
 2 temperature/humidity sensors
 2 IR blasters
 5 door/window sensors
 5 room occupancy sensors
 1 leak sensor
 2 mini-hub gateways compliant with the LoRaWAN® protocol
 1 Wi-Fi to Mobile Portable Hotspot
Getting started
To begin, log in by scanning the QR code or, using Chrome as your web browser, navigate
to lora-developers.semtech.com/smart-building-kit.
Note: Your individual login credentials can either be found on the inside cover of the box,
or on the DEVEUI data sheet provided with the Kit.
Get to know your Hotspot and mini-hubs
The mini-hubs and hotspot are preconfigured to work together. The hotspot includes 1GB of free data service. If
you need more data, you will need to sign up for a cellular service plan. For plan options, see GlocalMe1.
If additional options are needed, you can add up to two nano SIM cards in the hotspot. Use a needle to pull out
the available the SIM slots and insert the SIM cards.
Note: The hotspot included in this Kit does not support SIM cards that require PIN codes.
It is important to NOT pull the battery tabs on the sensors until at least one mini-hub is functioning properly.
Failure to provide a LoRaWAN network before enabling the sensor can result in excessive battery drain.
1 GlocalMe is a registered trademark of UCLOUDLINK in Hong Kong. The GlocalMe logo and UCLOUDLINK are trademarks of UCLOUDLINK.
Figure 1: Scan to log in

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Setting-up the Kit
1. Fully charge the hotspot.
2. Once charged, press and hold the hotspot’s power button (#11) for five seconds and wait for the device to
boot
.
Figure 2:
Hotspot Buttons and Ports

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
3. The hotspot will automatically log-in and connect to the GlocalMe®2 service.
4. Once the hotspot displays the Wi-Fi name and password, as illustrated in Figure 4 you can start setting-up
the mini-hubs.
2 GlocalMe is a registered trademark of UCLOUDLINK in Hong Kong. The GlocalMe logo and UCLOUDLINK are trademarks of UCLOUDLINK.
Figure 3: Automatic Logon
Figure 4: GLocal Logon Complete

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
5. Remove the cover plate on the first mini-hub. If necessary, attach the power adapter before plugging-in the
mini-hub to a wall socket as shown in Figure 5.
6. You will know the mini-hub is connected to the hotspot when the light on top turns green as shown in
Figure 6
Setting-up the sensors
In this Kit, we are monitoring room or desk use, temperature, humidity and leaks. To this end, set up the sensors
as follows.
1. Grid-EYE® Infrared Array Sensors are most effective if mounted on the ceiling or inside of a lighting fixture.
Use the adhesive tape provided with the sensor to mount it in an appropriate location in your conference
room. The Grid-EYE sensor can be used to determine the number of people occupying a room. The sensor
begins the count when motion is detected and provides an update approximately every 5 minutes
thereafter.
2. Window/door sensors can be mounted on either side of the window frame or door frame, as illustrated in
Figure 7.
Figure 5: Plug-in the mini-hub
Figure 6: Mini-hub connected to hotspot

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Note: The maximum allowable gap between a sensor and the corresponding magnet is 1 cm. Be sure to
align the sensor side with the blue LED to the magnet face with the notch, as illustrated in Figure 8.
The door/window sensor will provide an indication of whether the door or window is open or closed.
Figure 7: Window and Door Sensor Placement
Figure 8: Door/Window Sensor and Magnet Alignment

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
3. The desk occupancy sensor may be mounted on the underside of a desk using the double-sided tape
provided. For best results, mount the sensor horizontally approximately 25 cm from the front edge of the
desk, as shown in Figure 9.
The desk occupancy sensor may take up to 5 minutes to appear on the dashboard when first connected.
Figure 9: Desk Occupancy Sensor
Note: The sensor will send a message when motion is detected. No additional messages will be sent as long
as motion is detected anytime within the next 5 minutes. Only after detecting no motion during a 5 minute
period will it send a message indicating that the desk is unoccupied. Therefore, changes in condition may not
be reflected in the dashboard immediately.
The daily desk occupancy statistics shown on the dashboard are only calculated once a day, at midnight.
4. To detect movement in a room, place the room occupancy sensor on a flat surface, such as a table or
bookshelf. The room occupancy sensor behaves much like the desk occupancy sensor in terms of the 5-
minute behaviour.
As with desk occupancy statistics, room occupancy statistics are only calculated for the preceding 24-hour
period commencing at midnight each day.
The room occupancy sensor may take up to 5 minutes to appear on the dashboard when first connected.
5. To detect the temperature and humidity in the room, place the temperature/humidity sensor anywhere in
the room. To mitigate momentary changes in temperature due to opening a door or window, best practice
is to place this sensor away from doors and windows.
6. The IR blaster can control wall-mounted HVAC systems, heaters, televisions and any other electronic
devices that use an infrared signal with a known Pronto code. A list of codes can be found at either of these
two websites:
http://irdb.tk/

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
http://www.remotecentral.com/cgi-bin/codes/
To use, place the IR blaster so that it is three to five feet from the item to be controlled, facing the item’s
infrared receiver.
Figure 10: Face of the IR blaster
Next, navigate on your browser to your Kit’s dashboard. Click on the Environment tab on the left hand side.
You will be presented with a screen which includes a place where the Pronto code can be entered as shown
in Figure 11.
Figure 11: Entering Pronto codes for the IR blaster
7. For information about how to remove or replace the battery in any of the devices, scan the QR code below,
or use the Chrome web browser to navigate to https://qrgo.page.link/iWxb.
Note: Regulations require that the battery must be removed from the device when shipping or flying by air.
Alternatively, you can re-insert the plastic tabs to disrupt the battery current.

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Changing the mini-hub Wi-Fi connection
If you do not want to use the hotspot provided Wi-Fi network, you can configure the mini-hub to use another
network. To do so, follow these steps:
1. Leaving the mini-hub plugged-in, turn off the hotspot.
2. Using a computer, perform a network scan and select the open Wi-Fi network that starts with MiniHub-
xxxxx where xxxxx are the last 6 digits of the mini hub MAC address, as illustrated in Figure 12.
Figure 12: Mini-hub network
3. Once the computer is connected to the mini-hub, open a web browser and type 192.168.4.1 in the address
bar.
4. Edit the Wi-Fi SSID and Wi-Fi Password to reflect the new Wi-Fi network you want to connect to. Click Apply
to save your changes.

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Mini-hub LED status indicators and button functionality
LED indicators
Table 1 shows what the various LED colors and blink patterns displayed by the mini-hub indicate.
Color(s)
Blink Pattern
Mode
Status
GREEN
blinking 1 sec
GW
Wi
-
Fi
STA not connected
GREEN
blinking 1/4 sec
GW
Wi
-
Fi
STA connected, establishing connection to LNS, con
figuring
radio
GREEN
Solid
GW
Wi
-
Fi
STA connected,
STA
on connected to LNS, radio listening
GREEN/
ORANGE
blinking 1/4 sec
GW
Wi
-
Fi
STA connected, CUPS transaction in progress
Note: Do not unplug device in this state
ORANGE
blinking 1/4 sec
CONFIG
Scanning
Wi
-
Fi
networks, sett
i
ng up con
figuration AP
ORANGE
blinking 1 sec
CONFIG
Con
figuration AP active
Table 1: LED Status Indicators
Button Functionality
 To switch from GW (gateway) mode to CONFIG mode, press the Setup button for 10 seconds.
 To reboot the mini-hub, while in CONFIG mode, press the Setup button for 5 seconds.
 To return the mini-hub to factory settings, (and delete the Wi-Fi and Network Server credentials), press the
Reset button for 5 seconds.
Support
For any additional questions about operation or help with troubleshooting please contact
[email protected]
For more information about LoRa®, LoRaWAN® or the hardware contained within the kit please contact
[email protected]

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Important Information: Warranty Disclaimer
The Kits are supplied for demonstration purposes only. Your use of the Kits for any purposes (e.g., commercial) is
unauthorized by Semtech and at your own risk.
THE KITS ARE PROVIDED "AS IS" AND WITHOUT WARRANTY OF ANY KIND EXPRESSED OR IMPLIED. SEMTECH
EXPRESSLY DISCLAIMS ALL WARRANTIES, EXPRESSED, IMPLIED OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-
INFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS.
Product & Safety Instructions
Certain sensors contain magnets. Keep away from ALL children! Do not put in nose or mouth. Swallowed magnets can stick to intestines
causing serious injury or death. Seek immediate medical attention if magnets are swallowed.
Observe the following precautions to avoid a sensor explosion or fire:
Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, or paint the sensors, Hub, or other hardware.
Do not insert foreign objects into any opening on the sensors or gateways
Do not use the hardware if it has been damaged—for example, if cracked, punctured, or harmed by water.
Disassembling or puncturing the battery (whether integrated or removable) can cause an explosion or fire.
Do not dry the sensors or battery with an external heat source such as a microwave oven or hair dryer.
These products are not toys and contain small parts that can be dangerous to children under three years old. Do not allow children or pets to
play with products.
Observe proper precautions when handling batteries. Batteries may leak or explode if improperly handled.
Warnings
Do not place naked flame sources, such as lighted candles, on or near the equipment.
The battery should not be exposed to excessive heat such as sunshine, fire, or the like.
Do not dismantle, open, or shred battery pack or cells.
Do not expose batteries to heat or fire. Avoid storage in direct sunlight.
Do not short-circuit the battery. Do not store batteries in a box or drawer where they may short-circuit each other or be short-circuited by
other metal objects.
Do not remove a battery from its original packaging until required for use.
Do not subject batteries to mechanical shock.
In the event of a battery leaking, do not allow the liquid to come in contact with skin or eyes. If contact has been made, wash the affected
area with copious amounts of water, and seek medical advice.
Do not use any charger other than that specifically provided for use with the equipment.
Observe the plus (+) and minus (-) marks on the battery and equipment, and ensure correct use.
Do not use any battery which is not designed for use with the product.
Do not mix cells of different manufacture, capacity, size, or type within a device.
Keep batteries out of the reach of children.
Seek medical advice immediately if a battery has been swallowed.
Always purchase the correct battery for the equipment.
Keep batteries clean and dry.
Wipe the battery terminals with a clean, dry cloth if they become dirty.
Rechargeable batteries need to be charged before use. Always use the correct charger, and refer to the manufacturer’s instructions or
equipment manual for proper charging instructions.
Do not leave a rechargeable battery on prolonged charge when not in use.

Smart Building Reference Kit User Guide | Proprietary Information | Semtech Corporation
Notices
Avoid exposing your sensors or batteries to very cold or very hot temperatures. Low or high temperature
conditions may temporarily shorten the battery life or cause the sensors to temporarily stop working.
Take care in setting up the gateway and other hardware. Follow all installation instructions in the User Guide.
Failure to do so may result in injury.
Do not install hardware equipment while standing in water or with wet hands. Failure to do so can result in
electric shock or death. Use caution when setting up all electronic equipment.
PROP 65 WARNING: This product contains chemicals known to the State of California to cause cancer and birth
defects or other reproductive harm.
Cleaning: Use a clean, dry cloth or wipe to clean products. Do not use detergent or abrasive materials to clean
the Tabs products, as this may damage the sensors.
