Sencore OmniHub CMP100 User manual

January 2020
www.sencore.com | 1.605.978.4600 Revision 1.6
OmniHub C P100
edia Platform
User anual

OmniHub C P100 – User anual
Page 2 of 106
Copyright
© 2019 Sencore, Inc. All rights reserved.
3200 Sencore Drive, Sioux Falls, SD USA
www.sencore.com
This publication contains confidential, proprietary, and trade secret information. No part of this document
may be copied, photocopied, reproduced, translated, or reduced to any machine-readable or electronic format
without prior written permission from Sencore. Information in this document is subject to change without
notice and Sencore Inc. assumes no responsibility or liability for any errors or inaccuracies. Sencore, Sencore
Inc, and the Sencore logo are trademarks or registered trademarks in the United States and other countries.
All other products or services mentioned in this document are identified by the trademarks, service marks, or
product names as designated by the companies who market those products. Inquiries should be made
directly to those companies. This document may also have links to third-party web pages that are beyond
the control of Sencore. The presence of such links does not imply that Sencore endorses or recommends
the content on those pages. Sencore acknowledges the use of third-party open source software and licenses
in some Sencore products. This freely available source code can be obtained by contacting Sencore Inc.
About Sencore
Sencore is an engineering leader in the development of high-quality signal transmission solutions for the
broadcast, cable, satellite, IPTV, telecommunications, and professional audio/video markets. The company’s
world-class portfolio includes video delivery products, system monitoring and analysis solutions, and test and
measurement equipment, all designed to support system interoperability and backed by bestin-class customer
support. Sencore meets the rapidly changing needs of modern media by ensuring the efficient delivery of
high-quality video from the source to the home. For more information, visit www.sencore.com.

OmniHub C P100 – User anual
Page 3 of 106
Revision History
Date
Version
Description
Author
08/24/17 1.0 First Version Z
06/06/18 1.1 Add New odules, New Features and
Adjust anagement Page
Z
11/15/18 1.2 odify the Product Picture DA
02/15/19 1.3 Add New odules, New Features and
Adjust anagement Page
DA
04/02/19 1.4 Add New odules and New Features DA
05/23/19 1.5 Add New odules RS
12/06/19 1.6 Add New odules and Features EH
This guide contains some symbols to call your attention.
DANGER
The DANGER symbol calls your attention to a situation
that, if ignored, may cause physical harm to the user.
CAUTION
The CAUTION symbol calls your attention to a situation
that, if ignored, may cause damage to Our product.
NOTE
The NOTE symbol calls your attention to important
information.
TIP
The TIP symbol calls your attention to additional
information that, if followed, can make procedures more
efficient.
Red Arrow
The Red Arrow symbols point to import details mention the
context above or below an image.
Blue Arrow
The Blue Arrow symbol indicates the motion path of an
item in an operation step.
Thick Arrow
The thick Arrow symbol calls your attention to a serial of
operation steps mentioned in the context.
This guide also contains the following text conventions.

OmniHub C P100 – User anual
Page 4 of 106
Safety Instructions
• Read these instructions
• Keep these instructions
• Heed all warnings
• Follow all instructions
• Do not use this apparatus near water
• Clean only with dry cloth
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat
• Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long periods of
time.
• Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
• Do not expose this apparatus to dripping or splashing and ensure that no objects
filled with liquids, such as vases, are placed on the apparatus.
• To completely disconnect this apparatus from the AC ains, disconnect the
power supply cord plug from the AC receptacle.
• The mains plug of the power supply cord shall remain readily operable.
• Da age Requiring Service: Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
o When the power-supply cord or plug is damaged.
o If liquid has been spilled, or objects have fallen into the product.
o If the product has been exposed to rain or water.
o If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of the controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation.
o If the product has been dropped or damaged in any way.
o The product exhibits a distinct change in performance.
• Replace ent Parts: When replacement parts are required, be sure the service
technician uses replacement parts specified by Sencore, or parts having the
same operating characteristics as the original parts. Unauthorized part
substitutions made may result in fire, electric shock or other hazards.

OmniHub C P100 – User anual
Page 5 of 106
SAFETY PRECAUTIONS
There is always a danger present when using electronic equip ent.
Unexpected high voltages can be present at unusual locations in defective
equipment and signal distribution systems. Become familiar with the equipment
that you are working with and observe the following safety precautions.
• Every precaution has been taken in the design of your product to ensure that it is
as safe as possible. However, safe operation depends on you the operator.
• Always be sure your equipment is in good working order. Ensure that all points
of connection are secure to the chassis and that protective covers are in place
and secured with fasteners.
• Never work alone when working in hazardous conditions. Always have another
person close by in case of an accident.
• Always refer to the manual for safe operation. If you have a question about the
application or operation email ProCare@Sencore.com
• WARNING – To reduce the risk of fire or electrical shock never allow your
equipment to be exposed to water, rain or high moisture environments. If exposed
to a liquid, remove power safely (at the breaker) and send your equipment to be
serviced by a qualified technician.
• To reduce the risk of shock the power supply must be connected to a mains socket
outlet with a protective earthing connection.
• For the mains plug the main disconnect and should remain readily accessible and
operable at all times.
• When utilizing DC power supply, the power supply UST be used in conjunction
with an over-current protective device rated at 50 V, 5 A, type: Slow-blo, as part of
battery-supply circuit.
• To reduce the risk of shock and damage to equipment, it is recommended to
ground the unit to the installation’s rack, the vehicle’s chassis, the battery’s
negative terminal, and/or earth ground.
Warning: Changes or odifications to this unit not expressly approved by the
party responsible for co pliance could void the user’s authority to operate the
equip ent.

OmniHub C P100 – User anual
Page 6 of 106
Package Contents
The following is a list of the items that are included:
1. OmniHub C P100 chassis
2. OmniHub C P100 Quick Start Guide
3. AC power cables
4. Breakout or adapter cables depending on option modules
If any of these items were omitted from the packaging please email
ProCare@Sencore.com to obtain a replacement.

OmniHub C P100 – User anual
Page 7 of 106
Table of Contents
COPYRIGHT .............................................................................................................................................. 2
ABOUT SENCORE ...................................................................................................................................... 2
REVISION HISTORY ................................................................................................................................... 3
TABLE OF CONTENTS ................................................................................................................................ 7
SECTION 1 OVERVIEW .............................................................................................................................. 9
1.1 PRODUCT INTRODUCTION ...................................................................................................................10
1.2 FRONT PANEL OVERVIEW ...................................................................................................................10
1.3 REAR PANEL OVERVIEW .....................................................................................................................11
1.4 OPTION MODULE OVERVIEW ..............................................................................................................11
SECTION 2 INSTALLATION ...................................................................................................................... 15
2.1 RACK INSTALLATION ..........................................................................................................................16
2.2 AC POWER CONNECTION ...................................................................................................................16
SECTION 3 WEB INTERFACE OPERATION ................................................................................................ 18
3.1 OMNIHUB CMP100 WEB INTERFACE OVERVIEW ...................................................................................19
3.1.1 Connecting to the Management Port ......................................................................................19
3.1.2 LOGGING INTO THE CMP100 WEB INTERFACE .......................................................................................19
3.2 STATUS OVERVIEW ............................................................................................................................19
3.2.1 STATUS ...........................................................................................................................................20
3.2.2 SYSTEM SETTINGS .............................................................................................................................20
3.2.3 IP INPUT .........................................................................................................................................23
3.2.4 IP OUTPUT ......................................................................................................................................26
3.3 MODULE CONFIGURATION ..................................................................................................................31
RECEIVER MODULES .......................................................................................................................................31
3.3.1 CR-DVBC-00 .............................................................................................................................31
3.3.2 CR-DVBC-01 .............................................................................................................................36
3.3.3 CR-DVBS2CI-00 .........................................................................................................................36
3.3.4 CR-DVBS2F A-00/00A ..............................................................................................................37
3.3.5 CR-8VSB-00 ..............................................................................................................................37
3.3.5.1 Module Status .....................................................................................................................38
3.3.5.2 Module Settings ...................................................................................................................38
3.3.6 CR-DVB 2CI-00 ........................................................................................................................42
ENCODER MODULES .......................................................................................................................................44
3.3.7 CE-HDMI-00/R01 ......................................................................................................................44
3.3.8 CE-HDMI-02 .............................................................................................................................51
3.3.9 CE-HDMI-02C ...........................................................................................................................55
3.3.10 CE-HDMI-05/05A .................................................................................................................59
3.3.11 CE-SDI-00 .............................................................................................................................62
3.3.12 CE-CVBS-00/R01/R01A ........................................................................................................65
MODULATION MODULES .................................................................................................................................69
3.3.13 CM-QAMA-00/R00 ..............................................................................................................69
3.3.14 CM-QAMA-R01/R01A ..........................................................................................................73
3.3.15 CM-QAMB-00/R00 ...............................................................................................................73
3.3.16 CM-QAMB-R01/R01A ..........................................................................................................75
3.3.17 CM-8VSB-R01/R01A ............................................................................................................75
3.3.18 CM-OFDM-R01/R01A ..........................................................................................................76

OmniHub C P100 – User anual
Page 8 of 106
3.3.19 CM-ISDB -R01/R01A ...........................................................................................................77
FUNCTION MODULES ...................................................................................................................................... 9
3.3.20 CP-EAS-00 ............................................................................................................................79
3.3.21 CP-CAM-00 ..........................................................................................................................82
SECTION 4 APPENDICES .......................................................................................................................... 85
APPENDIX A - ACRONYMS AND GLOSSARY ........................................................................................................86
APPENDIX B - A MONROE ONENETSE CONFIGURATION AND TESTING ..................................................................8
APPENDIX C - SPECIFICATION .........................................................................................................................91
APPENDIX D - WARRANTY ......................................................................................................................... 106
APPENDIX E - SUPPORT AND CONTACT INFORMATION ..................................................................................... 106
4.4.1 Returning for Service or Calibration ...................................................................................... 106
4.4.2 RMA Number ........................................................................................................................ 106
4.4.3 Shipping the Product ............................................................................................................. 106

OmniHub C P100 – User anual
Page 9 of 106
Section 1 Overview
SECTION 1 OVERVIEW .............................................................................................................................. 9
1.1 PRODUCT INTRODUCTION ...................................................................................................................10
1.2 FRONT PANEL OVERVIEW ...................................................................................................................10
1.3 REAR PANEL OVERVIEW .....................................................................................................................11
1.4 OPTION MODULE OVERVIEW ..............................................................................................................11

OmniHub C P100 – User anual
Page 10 of 106
1.1 Product Introduction
OmniHub C P100 is a new generation of Compact edia Platform in modular design
that focuses on both cost-effective commercial TV market and traditional DTV market.
Thanks to the benefit of high-density, strong-performance and large-flexibility, OmniHub
C P100 product can meet all the major video delivery requirements of signal receiving,
descrambling, encoding, multiplexing, modulation and IP processing in one unit.
With optional commercial/broadcast encoder, multi-mode receiver/modulator module, it
can be configured flexibly to meet any video delivery requirements. Due to its compact
design and powerful function, it can be widely used at hotel, hospital, community, club,
campus and DTV headend room, where massive programs are required to be processed
in a cost-effective way. OmniHub C P100 provides with a straight-forward web interface
accessible via all major browsers and complete control of the unit. Every OmniHub ships
with the software suite pre-loaded on appropriate hardware. There are optional input and
output configurations that will change the physical connectors available on the back of
the chassis.
1.2 Front Panel Overview
1. Power Status, Baseboard Status and Reset button
2. Four 1Gbe RJ45 ports: two for management and two for PEG over IP purposes
3. Cooling Air Intake
4. 16 hot-swappable modules, each module have assigned IP address depending on
the Slot number.
5. Dual redundant power supplies

OmniHub C P100 – User anual
Page 11 of 106
1.3 Rear Panel Overview
The OmniHub C P100 have 3 exhaust fans at the back of the unit. Please mind not to
obstruct the air intake at the front and air exhaust at the back.
1.4 Option Module Overview
This describe the C P100 platform and all available modules that can expand the
functionality of the C P100 platform.
CMP
100
chassis
Description
Baseboard C P100-01-SEN 4RU chassis, Dual PSU, 4xGbE ports (2
for management and 2 port IP stream
in/out)
Receiver Modules
Description
CR-DVBC-00 4 channel DVB-C Annex A/C/DT B
receiving module, 1 RF input connector
with 4 tuners and 2 CI slots
CR-DVBC-01 4 channel DVB-C Annex B/ISDBT
receiving module, 1 RF input connected
with 4 tuners and 2 CI slots
CR-DVBS2CI-00 4 channel DVB-S2 receiving module, 2
input connectors each with 2
transponders receiving, with 2 CI slots
and independent power supplies for
each LNB.
CR-DVBS2FTA-00 4 channel DVB-S2 receiving module, 4
input connectors. Independent power
supplies for LNB 1 and 3 only.
CR-DVBS2FTA-00A 8 channel DVB-S2 receiving module,
another interface card added on CR-
DVBS2FTA-00, each module occupies 2
slots.
CR-8VSB-00 4 channel 8VSB receiving module, 4
input connectors with 4 tuners.
CR-DVBT2CI-00 4 channel DVB-T/T2 receiving module, 1
input connected with 4 tuners and 2 CI
slots.
* CR-DVBC-00, CR-DVBC-01, CR-DVBT2CI-00, CR-DVBS2CI-00 are Different Hardware but
share the same Software.

OmniHub C P100 – User anual
Page 12 of 106
* CR-DVBS2FTA-00, CR-DVBS2FTA-00A are Different Hardware but share the same Software.
Encoder Modules
Description
CE-HD I-00 4 channel HD I encoding module,
supports H.264 HD/SD, PEG-2 SD,
PEG1L2, AC3/AAC.
CE-HD I-R01 4 channel HD I encoding module,
supports H.264 HD/SD, PEG-2 SD,
PEG1L2, AC3/AAC. Support OSD
subtitle, logo picture and QR code
overlay
CE-HD I-02 2 channel HD I encoding module,
supports H.264 HD/SD, PEG-2 SD,
PEG1L2, AC3/AAC, and supports CC
input.
CE-HD I-02C 2 channel HD I encoding module,
supports H.264 HD/SD, PEG-2 SD,
PEG1L2, AC3/AAC and supports CC
and analog audio input.
CE-HD I-05 4 channel HD I encoding module,
supports H.264/H.265 HD/SD, PEG-2
SD, PEG1L2, AC3/AAC, and support
OSD subtitle, logo picture and QR code
overlay.
CE-HD I-05 8 channel HD I encoding module,
supports H.264/H.265 HD/SD, PEG-2
SD, PEG1L2, AC3/AAC, and support
OSD subtitle, logo picture and QR code
overlay, each module occupies 2 slots,
CE-CVBS-00 6 channel CVBS encoding module,
supports H.264/ PEG-2 SD, PEG1L2.
CE-CVBS-R01 8 channel CVBS encoding module,
supports H.264, PEG1L2.
CE-CVBS-R01A 16 channel CVBS encoding module,
supports H.264, PEG1L2, the modules
occupy 2 slots.
CE-SDI-00 2 channel SDI encoder bitrate supports
H.264/ PEG-2 HD/SD, PEG1L2, AAC
and AC3, and supports CC and analog
audio input.

OmniHub C P100 – User anual
Page 13 of 106
Modulator Module
Description
C -QA A-R00 16 channel QA modulator module,
Annex A/C, non-adjacent output, and 1
RF female port for output
C -QA B-R00 16 channel QA modulator module,
Annex B, non-adjacent output, and 1 RF
female port for output
C -QA A-R01 4 channel QA modulator module,
Annex A/C, adjacent output, and 1 RF
female port for output
C -QA A-R01A 8 channel QA modulation module,
Annex A/C, adjacent output, and 1 RF
female port for output
C -QA B-R01 4 channel QA modulation module,
Annex B, adjacent output, and 1 RF
female port for output
C -QA B-R01A 8 channel QA modulation module,
Annex B, adjacent output, and 1 RF
female port for output
C -OFD -R01 4 channel OFD modulation module,
adjacent output, and 1 RF female port
for output
C -OFD -R01A 8 channel OFD modulation module,
adjacent output, and 1 RF female port
for output.
C -ISDBT-R01 4 channel ISDBT modulation module,
adjacent output, and 1 RF female port
for output.
C -ISDBT-R01A 8 channel ISDBT modulation module,
adjacent output, and 1 RF female port
for output
C -8VSB-R01 4 channel 8VSB (ATSC) modulation
module, adjacent output, and 1 RF
female port for output

OmniHub C P100 – User anual
Page 14 of 106
C -8VSB-R01A 8 channel 8VSB 9ATSC) modulation
module, adjacent output, and 1 RF
female port for output.
*All -R01 model share the same hardware, and all -R01A models share the same
hardware.
Function Modules
Description
CP-EAS-00 EAS processing module, supports EAS
triggering by analogue EAS input and
Digital EAS input.
CP-CA -00 CA processing module supports 2
independent CI Card slots, support
Xcrypt CA scramble, compatible with
mainstream CA cards, and support
mainstream CAS decryption

OmniHub C P100 – User anual
Page 15 of 106
Section 2 Installation
SECTION 2 INSTALLATION ...................................................................................................................... 15
2.1 RACK INSTALLATION ..........................................................................................................................16
2.2 AC POWER CONNECTION ...................................................................................................................16

OmniHub C P100 – User anual
Page 16 of 106
2.1 Rack Installation
The OmniHub C P100 is designed to be mounted in a standard 19” rack. It takes 480mm
x 177mm x 345mm (W x H x D) or 4RU of rack space. To install it into a rack, please use
the following steps:
• Determine the desired position in the rack for the C P100. ake sure that the air
intake on the top of the unit and the exhausts on the back of the unit will not be
blocked.
• Install the brackets at desired position if there’s no supporting plate in the rack.
• Insert the rack mount clips into place over the mounting holes in the rack.
• Slide the C P100 into the position in the rack.
• Secure the chassis to the rack by installing the four supplied screws through the
front mounting holes and tightening.
2.2 AC Power Connection
The Dual Redundant option allows the OmniHub C P100 to be powered by two separate
supplies either operating 110V or 220V systems. The power supply will automatically
detect the system it is connected to. To hook up the power use the following steps:
• Locate the power cords that are included. Please only use the supplied 3-prong
power connector or one with equal specifications. NEVER tamper with or remove
the grounding pin. This could cause damage to C P100, personnel, or property.
• Plug the female end of the power cords into the front of the unit.
• Locate a protected outlet to plug the male ends of the power cables into.

OmniHub C P100 – User anual
Page 17 of 106
When you take the equipment from a cold condition into a much warmer and
humid condition, the equipment should be acclimated to the warm and humidity
condition for at least 30 minutes. Powering up a non-acclimated unit may lead to
shortcut or other damage to electronic components.
A professional UPS system is recommended for better performance of your
content distribution system.

OmniHub C P100 – User anual
Page 18 of 106
Section 3 Web Interface Operation
SECTION 3 WEB INTERFACE OPERATION ................................................................................................ 18
3.1 OMNIHUB CMP100 WEB INTERFACE OVERVIEW ...................................................................................19
3.1.1 Connecting to the Management Port ......................................................................................19
3.1.2 LOGGING INTO THE CMP100 WEB INTERFACE .......................................................................................19
3.2 STATUS OVERVIEW ............................................................................................................................19
3.2.1 STATUS ...........................................................................................................................................20
3.2.2 SYSTEM SETTINGS .............................................................................................................................20
3.2.3 IP INPUT .........................................................................................................................................23
3.2.4 IP OUTPUT ......................................................................................................................................26
3.3 MODULE CONFIGURATION ..................................................................................................................31
RECEIVER MODULES .......................................................................................................................................31
3.3.1 CR-DVBC-00 .............................................................................................................................31
3.3.2 CR-DVBC-01 .............................................................................................................................36
3.3.3 CR-DVBS2CI-00 .........................................................................................................................36
3.3.4 CR-DVBS2F A-00/00A ..............................................................................................................37
3.3.5 CR-8VSB-00 ..............................................................................................................................37
3.3.5.1 Module Status .....................................................................................................................38
3.3.5.2 Module Settings ...................................................................................................................38
3.3.6 CR-DVB 2CI-00 ........................................................................................................................42
ENCODER MODULES .......................................................................................................................................44
3.3.7 CE-HDMI-00/R01 ......................................................................................................................44
3.3.8 CE-HDMI-02 .............................................................................................................................51
3.3.9 CE-HDMI-02C ...........................................................................................................................55
3.3.10 CE-HDMI-05/05A .................................................................................................................59
3.3.11 CE-SDI-00 .............................................................................................................................62
3.3.12 CE-CVBS-00/R01/R01A ........................................................................................................65
MODULATION MODULES .................................................................................................................................69
3.3.13 CM-QAMA-00/R00 ..............................................................................................................69
3.3.14 CM-QAMA-R01/R01A ..........................................................................................................73
3.3.15 CM-QAMB-00/R00 ...............................................................................................................73
3.3.16 CM-QAMB-R01/R01A ..........................................................................................................75
3.3.17 CM-8VSB-R01/R01A ............................................................................................................75
3.3.18 CM-OFDM-R01/R01A ..........................................................................................................76
3.3.19 CM-ISDB -R01/R01A ...........................................................................................................77
FUNCTION MODULES ...................................................................................................................................... 9
3.3.20 CP-EAS-00 ............................................................................................................................79
3.3.21 CP-CAM-00 ..........................................................................................................................82

OmniHub C P100 – User anual
Page 19 of 106
3.1 O niHub CMP100 Web Interface Overview
3.1.1 Connecting to the Manage ent Port
C P100 has an embedded gigabit switch inside the chassis. The four network ports are
respectively used for managing and data reception/streaming over IP network. From left
to right, port 1 and port 2 are used for management purposes and, port 3 and port 4 are
used for IP reception/streaming.
If external IP switch needs to install between C P100 and other headend devices, this
switch should support IG P V2 and IG P snooping function.
3.1.2 Logging into the CMP100 Web Interface
To open the C P100 web interface use one of the following supported browsers and
navigate to the unit’s IP address:
• Firefox
• Google Chrome
Factory network settings of the anagement Port:
• IP address: 192.168.1.10
• Subnet ask: 255.255.255.0
• Gateway: 192.168.1.254
The user will need to login to the web interface. The default userna e and password
are ad in/ad in. Press the login button in order to login to the web interface.
3.2 Status Overview
After a successful login, a welcome screen is displayed. The welcome screen allows you
to navigate to:
1. Module List shows the module(s) installed inside the chassis
2. Settings buttons: status, system settings, IP inputs, IP outputs, admin
3. Device host operation status
At any time, the user can return to the welcome screen by clicking the Status button and
then Device Status button. Below two pictures displaying different Status View
for Single and Dual PSU versions.

OmniHub C P100 – User anual
Page 20 of 106
3.2.1 Status
This enu allow the user to access the following:
• Device Status
• Device Information
Device Status will show once you login on the C P100 management GUI as shown in
the picture above. It also shows the front view image of C P100 with friendly label that
show the status of each module connected in the 16 slots.
Device Infor ation page shows the firmware version, software version, and hardware
version of baseboard and every module physically installed. User can access Device
Information status page by clicking the Status button and then Device
information button.
3.2.2 Syste Settings
This menu allows the user to configure:
• Network
• Time
• System
• Password
• SN P
Network tab allows user to assign a static IP address to C P100 mainboard only. IP
addresses for boards/modules will be assigned automatically based on the address set
1
3
2
Other manuals for OmniHub CMP100
1
Table of contents
Other Sencore Server manuals
