Sensia 3300 EFM Instruction manual

QRATE
+Scanner 3300 EFM
Hardware Installation, Operation & Maintenance Manual
Manual No. 50343919-01, Rev. 8

Important Safety Information
Symbols and Terms Used in this Manual
!WARNING: This symbol identies information about practices or circumstances that can lead to personal injury or
death, property damage, or economic loss.
CAUTION Indicates actions or procedures which if not performed correctly may lead to personal injury or
incorrect function of the instrument or connected equipment.
Important Indicates actions or procedures which may affect instrument operation or may lead to an instru-
ment response which is not planned.
Symbols Marked on Equipment
Attention! Refer to manual Protective (earth) ground
Technical Support Contact Information
TEL: [phone]
EMAIL: [email protected]
WEB: https://sensiaglobal.com/Measurement
Revision History
Revision Description of Change Issuer ApproverrDate
08 Production Release TM TM 01/06/2021

Table of Contents
Important Safety Information...................................................................................................................................................i
Symbols and Terms Used in this Manual..................................................................................................................i
Symbols Marked on Equipment................................................................................................................................i
Section 1 - Introduction ................................................................................................................................... 1
About the QRATE Scanner 3300 EFM...................................................................................................................................1
Web Browser-Based Interface ........................................................................................................................................1
Supporting Software and User Help Documents.............................................................................................................1
Standard Features..................................................................................................................................................................3
Product Identication..............................................................................................................................................................3
Hardware Options...................................................................................................................................................................3
Panel Mounting Kit..........................................................................................................................................................4
Wireless Communications...............................................................................................................................................5
External SmartMesh Antenna ..................................................................................................................................5
Remote-Mount Antenna ..........................................................................................................................................6
Conguration Lock..................................................................................................................................................................7
Specications .........................................................................................................................................................................8
Table 1.2—Hardware Options.......................................................................................................................................13
Table 1.3—Scanner Companion Software....................................................................................................................14
Flow Rate and Fluid Property Calculations ..........................................................................................................................14
Table 1.4—Flow Rate Standards...................................................................................................................................15
Table 1.5—Fluid Property and Energy Flow Calculations.............................................................................................16
Table 1.6—Flow Correction Factors..............................................................................................................................18
Section 2 - Installing the Scanner 3300 EFM ............................................................................................... 20
Overview...............................................................................................................................................................................20
CSA Installations ..................................................................................................................................................................20
Wiring Precautions.................................................................................................................................................20
Multi Variable Transmitter Mounting.....................................................................................................................................20
Panel Mounting the Scanner 3300.......................................................................................................................................23
Requirements for Wireless Communications .......................................................................................................................25
FCC Radio Frequency Compliance...............................................................................................................................26
IC Radio Frequency Compliance ..................................................................................................................................27
Radio Frequency Compliance Labeling ........................................................................................................................27
Antenna Installation Options.................................................................................................................................................28
Direct-Mount Antenna....................................................................................................................................................28
Remote-Mount Antenna for Pole Outside Diameters up to 2 Inches.............................................................................28
Remote-Mount Antenna for Pipe Outside Diameters of 2 3/8 Inches............................................................................29
Industry Standard Compliance.............................................................................................................................................30
Table 2.2—Industry Standards for Meter Installation ...................................................................................................30
Measuring Natural Gas via a Differential Pressure Meter....................................................................................................32
Best Practices ...............................................................................................................................................................32
Installation Procedure—Direct Mount to Orice Meter or Cone Meter..........................................................................33
Installation Procedure—Remote Mount to Orice Meter or Cone Meter.......................................................................34
Measuring Natural Gas via a Turbine Meter.........................................................................................................................35
Best Practices ..............................................................................................................................................................35
Installation Procedure—Direct Mount to a Turbine Meter .............................................................................................35
Installation Procedure—Remote Mount to a Turbine Meter..........................................................................................36
Installation Procedure—Remote Connection to a Turbine Meter..................................................................................37
Measuring Steam via a Differential Pressure Meter.............................................................................................................39
Best Practices ...............................................................................................................................................................39
Condensate Pots....................................................................................................................................................39
Hot Legs.................................................................................................................................................................39
Cold Legs...............................................................................................................................................................39
Antifreeze...............................................................................................................................................................39
Valves.....................................................................................................................................................................40
Installation Procedure—Direct Mount MVT to Orice Meter or Cone Meter .................................................................40
Installation Procedure—Remote Mount to Orice Meter or Cone Meter.......................................................................42
ii
Table of Contents Scanner 3300 EFM

Measuring Liquid via a Differential Pressure Meter..............................................................................................................44
Best Practices ...............................................................................................................................................................44
Installation Procedure—Direct Mount to Orice Meter or Cone Meter..........................................................................45
Remote Mount to Orice Meter or Cone Meter .............................................................................................................46
Measuring Compensated Liquid via a Turbine Meter...........................................................................................................48
Best Practices ..............................................................................................................................................................48
Section 3 - Wiring the Scanner 3300 EFM.................................................................................................... 50
Field Wiring Connections......................................................................................................................................................50
Power Supply Wiring............................................................................................................................................................52
External Power Supply .................................................................................................................................................52
Transmitter Supply ........................................................................................................................................................53
Input Wiring ..........................................................................................................................................................................54
Pulse Inputs - Turbine Magnetic Pickup........................................................................................................................54
Pulse Inputs - Digital DC Pulse.....................................................................................................................................54
Pulse Inputs - Contact Closure......................................................................................................................................54
RTD Inputs....................................................................................................................................................................55
Analog Inputs - Voltage Input........................................................................................................................................55
Analog Inputs - Current Input........................................................................................................................................56
Digital Inputs - Contact Closure.....................................................................................................................................56
Digital Inputs - Pulse .....................................................................................................................................................57
Digital Inputs - Open Collector ......................................................................................................................................57
Output Wiring........................................................................................................................................................................58
Analog (4 to 20 mA) Outputs.........................................................................................................................................58
Digital Outputs...............................................................................................................................................................59
Communications...................................................................................................................................................................60
RS-485 Communications ..............................................................................................................................................60
RS-232 Communications ..............................................................................................................................................60
Ethernet Communications.............................................................................................................................................61
Section 4 - Kiosk Display Interface............................................................................................................... 63
Kiosk Display Navigation......................................................................................................................................................63
Power Button.................................................................................................................................................................63
Enable/Disable User Congured Device Display Button...............................................................................................64
Congure Display Button...............................................................................................................................................64
Web Interface Button.....................................................................................................................................................64
User Congured Device Display...........................................................................................................................................65
IPAddress.....................................................................................................................................................................65
Status Indicators (Glyphs).............................................................................................................................................65
Table 4.1—User Congured Device Display Status Glyph Denitions..........................................................................65
Table 4.2—Parameter Status Glyph Denitions ............................................................................................................66
Congurable Display Features......................................................................................................................................66
Message Display Mode.................................................................................................................................................66
Web Interface Kiosk Mode ...................................................................................................................................................67
IPAddress Options........................................................................................................................................................67
First-Time Connecting the Scanner 3300......................................................................................................................68
Connecting Scanner 3300 to Existing Wired Network...................................................................................................68
Connecting the Scanner 3300 to Existing Wireless Network........................................................................................68
Troubleshooting the Wireless Connection.....................................................................................................................69
Adding Security to the WiFi Connection........................................................................................................................69
Section 5 - Scanner 3300 EFM Maintenance................................................................................................ 71
Unit Replacement.................................................................................................................................................................71
Display Assembly Replacement Procedure ..................................................................................................................71
Section 6 - Scanner 3300 Parts..................................................................................................................... 75
Spare Parts and Optional Hardware.....................................................................................................................................75
Table 6.1—Scanner 3300 EFM Parts............................................................................................................................75
Table 6.2—Wireless Components.................................................................................................................................75
Table 6.3—Wired Components .....................................................................................................................................76
Table 6.4—RTD and Cable Assemblies .......................................................................................................................76
Electronics Replacement......................................................................................................................................................77
iii
Scanner 3300 EFM Table of Contents

Table 6.5—Scanner 3300 Circuit Board Replacements................................................................................................77
Appendix A - FTP Downloads.......................................................................................................................A-1
Downloading SDF Files from the Scanner 3300 ................................................................................................................A-1
Slave Device Archive Logs.................................................................................................................................................A-2
Viewing and Sharing Downloaded Data.............................................................................................................................A-2
Appendix B - Firmware, Conguration, Scanner Logic, and Modbus Register Map Uploads...............B-1
Firmware Uploads ..............................................................................................................................................................B-1
Conguration Uploads........................................................................................................................................................B-1
Register Map Uploads........................................................................................................................................................B-1
ScanFlash Upload..............................................................................................................................................................B-2
Troubleshooting a Failed Upload ......................................................................................................................... B-3
Appendix C - Scanner 3300 Panel Cutout...................................................................................................C-1
iv
Table of Contents Scanner 3300 EFM

This page intentionally left blank.
v
Scanner 3300 EFM Table of Contents

Section 1 - Introduction
About the QRATE Scanner 3300 EFM
The QRATE* Scanner* 3300 EFM is uniquely designed to serve as a stand-alone ow computer or as a network man-
ager capable of collecting and storing data from up to 20 Scanner 2000 Series ow computers. As a stand-alone ow
computer, the Scanner 3300 offers dual ow stream and bidirectional measurement and control, as well as the processing
power to handle the industry’s most challenging ow computations for liquid and natural gas measurement. For oper-
ations requiring the monitoring of several measurement points, the Scanner 3300 combines up to 20 external wired or
wireless Scanner 2000 Series devices into a single scalable local area network that can be managed via a web brows-
er-based interface. Each of the three serial ports can support multiple wired Scanner 2000 Series devices or other external
Modbus devices.
The Scanner 3300 is designed to be panel mounted. If desired, the display has also been designed in such a way as to all
the main enclosure to be mounted on a rack while the kiosk touch display is mounted a distance away from it. The op-
tional wireless communications may reduce cost by negating the need of running Ethernet to the device.
The device is approved by CSA for ordinary locations. It is designed for use with a 9-30 VDC external power supply.
The Scanner 3300 device computes the corrected (standard) amounts of uid using signals from external turbine, positive
displacement (PD), Venturi, Coriolis and ultrasonic ow meters and integral or remote pressure and temperature sensors.
The measured uids may be expressed as volume, mass or energy accumulations, or rates. See Table 1.4—Flow Rate
Standards, page 15 and Table 1.5—Fluid Property and Energy Flow Calculations, page 16 for a detailed description
of supported calculations.
The Scanner 3300 kiosk touch display, when the device is connected via Ethernet or Wi-Fi, allows the user to fully con-
gure the Scanner 3300 directly through the display. This simplies the steps necessary for setup, and also simplies any
additional calibration or conguration in the future.
In addition to its two integral ow runs, the device supports 17 inputs and outputs and communications with chromato-
graphs, samplers, and densitometers.
The device logs daily and hourly ow data for each ow run, and provides one-second triggered logging for analysis of
critical events. High-speed communication via Modbus and Enron Modbus protocols makes it easy to integrate the Scan-
ner 3300 into other measurement systems. When congured for use with Modbus master protocol, each of the device’s
three serial ports can log up to 128 data points from external Modbus devices.
For a complete list of specications, see Specications, page 8.
*Mark of Sensia
Web Browser-Based Interface
A web browser-based interface equips you to congure ow runs, gas streams, and inputs/outputs, calibrate inputs, and
view archive data from the kiosk touch display, a laptop, tablet, smartphone, or other browser-enabled mobile device
without installing software. You need only an Ethernet connection and an IP address to connect to the device. Four user
security levels are available for customizing access for up to 20 users. An electronic user manual (PDF) is embedded in
the interface, providing searchable on-screen help. To position the manual alongside the user interface for simultaneous
viewing, congure your kiosk touch display per the instructions provided in the Scanner 3300 Web Interface User manu-
al.
Supporting Software and User Help Documents
To experience the full range of the Scanner 3300’s functionality, explore the complimentary software products and user
documentation available on the Sensia website. See Table 1.3—Scanner Companion Software, page 14.
1
Scanner 3300 EFM Section 1

Important To download software or user documentation, visit Sensia’s Measurement website,
https://www.sensiaglobal.com/Measurement/Types/Flow-Computing-and-Automation, select Scanner
3300 Series Wired and Wireless, and click on the link for the desired software installation or user
manual.
Feature Comparison
Item
Scanner 3100
Scanner 3300
Panel Mounted
Kiosk Touch Interface
# of Flow Runs 2 + 20 Remote 2 + 20 Remote
Integrated MVT
Wi-Fi Expansion
Wireless Smart Mesh
Ethernet
eFuse Protection
Smart Battery Support
Processors Dual-Core ARM Cortex M4 Dual-Core ARM Cortex M4
+ Co-Processor M4
Core Processor Speed 96 MHz 100 MHz
Memory 2.18 Mbyte RAM
97.5 Mbyte Non-Volatile 8.18 Mbyte RAM
129.5 Mbyte Non-Volatile
Transmitter Supply Fixed 10.5V Programmable 8.5 - 24 V
Analog Inputs 4 x [4-20mA / 1-5V] 4 x [4-20mA / 1-5V]
3 x [PI / TFM / 4-20mA]
Analog Outputs 22 + HART (Future)
High Frequency Outputs (future) 2 x Digitally Isolated
Up to 10 kHz ±1 Hz resolution
Digital I/O
4 x Optical Isolated
2 x High Current
Pulse Output Max 50 Hz
4 x Digitally Isolated
2 x High Current
Pulse Output Max 500 Hz
Figure 1.1 - Feature Comparison between the Scanner 3100 and Scanner 3300 devices
2
Section 1 Scanner 3300 EFM

Standard Features
The Scanner 3300 features an enclosure with a terminal board for inputs/outputs, a WiFi module and antenna, and a large
touch display. See Section 3 - Wiring the Scanner 3300 EFM, page 51 for wiring diagrams.
Product Identication
Each device is labeled with a serial tag that identies the product by model number and serial number (Figure 1.2).
The tag content depicted illustrates the electrical protection afforded by CSA certication. CSA-approved products are
marked accordingly with the respective ratings and symbols.
Figure 1.2 - Device serial tag
Hardware Options
The following hardware options are available for customizing the Scanner 3300 to your specic needs: panel mounting
kit and wireless communication components. See the sections below for details.
!WARNING: PERSONAL RISK. Substitution of components and/or the use of equipment in a manner other
than that specied by Sensia may impair suitability for ordinary locations. Sensia bears no legal respon-
sibility for the performance of a product that has been serviced or repaired with parts that are not autho-
rized by Sensia.
! WARNING: PERSONAL RISK. Do not open equipment unless signal circuits and power have been
switched off.
3
Scanner 3300 EFM Section 1

Panel Mounting Kit
It is recommended that the Scanner 3300 is panel mounted (Figure 1.3). For installation instructions, see Panel Mounting
the Scanner 3300, page 24.
Figure 1.3 - Scanner 3300 panel mounted
4
Section 1 Scanner 3300 EFM

Wireless Communications
The Scanner 3300 wireless communications option includes a factory-installed SmartMesh wireless radio module (Fig-
ure 1.4).
External SmartMesh Antenna
The Sensia-supplied SmartMesh antenna (Figure 1.4) connects directly to the Scanner 3300 side antenna connection.
When installing the antenna, ensure that it is in a vertical position well above ground level and positioned away from
large structures that could interfere with signal transmission and reception.
Sensia’s direct-mount antenna is rated for a maximum of 1 watt of power and a maximum antenna gain of 1.6 dB (in
North America) and has a frequency range of 2.35 to 2.60 GHz. Antennas with equivalent ratings may also be used with
the coupler.
Wi-Fi Antenna
SmartMesh Antenna
(optional)
Figure 1.4 - Standard WiFi antenna and optional SmartMesh antenna
5
Scanner 3300 EFM Section 1

Remote-Mount Antenna
In locations where a physical barrier restricts the use of a direct-mount antenna or where a longer transmission distance
is required, a remote-mount antenna (Figure 1.5) may be installed up to 30 ft (10 m) away and connected by cable to the
antenna coupler. A remote-mount antenna and connecting cable may be purchased from Sensia (see Section 6 - Scanner
3300 Parts, page 77). If purchasing cable elsewhere, verify that the cable meets the maximum capacitance and induc-
tance ratings (Figure 2.7, page 27) and that the cable length is adequate to connect to both the antenna and the coupler.
See Specications, page 8 for additional details.
The installation of the antenna coupler, antennas, and antenna cable must meet the requirements shown in Figure 2.7,
page 27. For installation instructions, see:
• Remote-Mount Antenna for Pole Outside Diameters up to 2 Inches, page 29
• Remote-Mount Antenna for Pipe Outside Diameters of 2 3/8 Inches, page 30
Mounting hardware supplied with
the Sensia remote-mount antenna
(fits pole outside diameters up to 2 inches)
Optional hardware kit for mounting the
Sensia remote-mount antenna to a
2-in. pipe (fits outside diameter of 2 3/8-in.)
Figure 1.5 - Remote-mount antenna mounting options
6
Section 1 Scanner 3300 EFM

Conguration Lock
The conguration lock is located on the terminal board of the Scanner 3300 (Figure 1.6). The switch can be enabled to
prevent unauthorized individuals from changing the conguration of the Scanner 3300. By default, this conguration
lock feature is disabled and the switch position is ignored. The conguration lock feature must be enabled via the AD-
MINISTRATION>GENERAL>SECURITY page of the Scanner 3300 Web Interface. For more information, see the
Scanner 3300 Web Interface User Manual. After a device is fully congured, the lock can be enabled by changing the
mechanical switch to the active position and enabling the switch in the web interface security settings.
Configuration
Lock Switch
Figure 1.6 - Conguration lock switch
7
Scanner 3300 EFM Section 1

Specications
Table 1.1—General Specications
Approvals CSA (US and Canada) ordinary location
Environmental
Safety
Relative humidity: 0% to 95% non-condensing
Altitude: Up to 2000 meters
Enclosure Dimensions (L x W x H): 11.2” x 5.4” x 7.8”
Weight 4 lb (1.88 kg), approximate
System Power External user-supplied power supply (9 to 30 VDC, 400 mA min. current rating)
Real-time Clock Accurate within 2 minutes/year over temperature range
Lithium coin cell battery maintains clock during loss of system power (lithium content: 0.11 g)
Processor 32-bit dual-core ARM Cortex M4 + Co-Processor M4
Operating
Temperature –10 °C to 60 °C (14 °F to 140 °F)
Advanced Touch
Display
8.0 in. with 1200 x 1920 resolution
Backlight is 1.4W
Displays up to 32 user-dened parameters (ve at a time), with auto-scrolling
External power indicator
Wireless communications indicator
Parameter status indicators
Congurable background (dark or light) and scroll frequency
Touch screen used for advancing the display; simulating LCD and additional data; connecting
to the web interface; viewing communication settings, serial number, and rmware version;
and restoring factory default settings to the device
Memory 8.18 MB RAM for processing
512 KB non-volatile memory for conguration data
64+1 MB on-board system ash memory
48 MB on-board archive ash memory
Supported
Meter Types
Turbine meter
Cone meter
Orice meter
Ultrasonic meter
Positive displacement (PD) meter
Coriolis meter
Venturi meter
Download Types Per Device Complete (all records, including slave device records as applicable)
Local (integral ow records in a condensed le ideal for emailing)
Events
Triggered (one-second logs, including PID tuning)
Per Flow Run Daily
Interval (hourly)
Event
Recent (past 7 days of interval logs)
Per Slave Daily
Interval (hourly)
Recent (past 7 days of interval logs)
8
Section 1 Scanner 3300 EFM

Table 1.1—General Specications
Archive
Capacity
Up to 58 archivable parameters per ow run
Daily log capacity 2,048 days
Interval log
capacity 2.8 years with 13 parameters (plus date, time and status) logged hourly Capacity varies with the number of parameters logged (13 to 58) and
logging frequency (1 second to 12 hours)
Triggered log
capacity
(1 to 19
parameters)
1,351,680 logs with one parameter logged;
135,168 logs with 19 parameters logged
Congurable to log periodically (1 second to 12 hours) on a real-time
period (daily, weekly, etc.) on device alarm, on digital input, or when
activated remotely via the web browser
Event Record
Archives Event/Alarm Record Capacity: 81,920 records User Change Records Capacity: 81,920 records
* Stored in a FLASH non-volatile memory with employs a 16 kB page
erase system (at least one page is partially erased with new entries).
Downloadable via FTP, HTTP (web interface), or Enron Modbus protocol (see Scanner Data
Manager User Manual for information on viewing data les)
Logs stored in non-volatile memory for up to 10 years
Communications/
Archive Retrieval Wireless WiFi radio module available with right-angle antenna. WiFi and Ethernet together support up to two TCP/IP user-congurable ports with
selectable slave protocols.
WiFi Range is 50 m.
Optional SmartMesh radio module available with or without external
antenna. See Table 1.2—Hardware Options, page 13.
Wired RS-485 Two dedicated ports (1 and 2) and one shared RS-485/RS-232 port (3)
Software-selectable 120-Ω termination resistor
Selectable master and slave protocols (Enron Modbus, Modbus RTU,
Modbus TCP)
Wired RS-232 Shared RS-485/RS-232 port (port 3)
TXD, RXD, RTS, CTS
Time-of-day digital output conguration
Ethernet/TCP One RJ-45 connection. WiFi and Ethernet together support up to two
TCP/IP user-congurable ports with selectable slave protocols.
Continuous use requires external power.
Supports 10/100 Mbits/second
Port Pass-Through Any communications port can be routed to another port
Ethernet can be bridged to serial communications for remotely
interfacing with connected Modbus devices. (For example, a Scanner
slave device can be congured using ModWorX* Pro software without
changing wiring connections.)
Flow Rate
Calculations Natural Gas AGA 3 (1992 and 2012), ISO 5167-2 (2003), ISO 5176-5, ASME MFC- 14M (2003), AGA-7 (includes scope of AGA 11)
Liquids API MPMS 5.3, AGA 3, ISO 5167, AGA 7
Fluid Property
Calculations Natural Gas AGA-8 part 1&2 (includes scope of AGA 10), AGA-3, AGA-5, GPA 2145-09, IF-97, AGA-8 part 1&2 (includes scope of AGA 10), AGA-3,
AGA-5, GPA 2145-09, IF-97, ISO 6976
Liquids API MPMS Chapter 11.1 (2004)
Pure Substances IAPWS-IF97 (Steam) Quality-corrected saturated steam (Regions 4)
IAPWS-IF97 (Steam-Water) Auto-selected Region saturated steam,
water, dry steam, critical range (Regions 1 through 4)
9
Scanner 3300 EFM Section 1

Table 1.1—General Specications
Liquid
Compensation and
Correction Factors
Temperature and pressure compensation
Meter factor compensation
Shrinkage factor compensation
Live BS&W correction
Live density correction
Dynamic oil fraction (watercut)—derived from owing density or watercut analyzer; automatic
base density updates from owing density measurement
Chisholm-Steven orice meter multiphase correction for steam
Chisholm-Steven cone meter multiphase correction for steam
Flow Streams Two integral compensated ow run inputs
Up to 20 remote ow runs via Scanner 2000 Series devices in local area Scanner network
Three additional integral uncompensated pulse/frequency inputs
Bidirectional ow measurement
Up to 8 gas streams using gas chromatograph inputs or user-entered static compositions
16-point calibrations for all inputs (linear factory and multipoint meter factor calibrations also
supported); see Table 1.6—Flow Correction Factors, page 18 for information on multipoint
meter factor calibration
Stacked differential pressure and static pressure inputs for rangeability
RTD Inputs 2 channels
100-Ω platinum RTD with 2-wire, 3-wire, or 4-wire interface
Range: –40 °C to 427 °C (–40 °F to 800 °F), excluding RTD uncertainty
Accuracy: ± 0.2 °C (0.36 °F) over sensing range at calibrated temperature
Temperature effect: ± 0.3 °C (0.54 °F) over operating range
A/D resolution: 24 bits
Sample rate: 0.1 seconds to 12 hours
Congurable shutoff for power savings when transducer warm-up period is not required
Analog Inputs 4 channels and 3 additional channels (current measurement only) congurable through Pulse/
Frequency Inputs
1 to 5 V, 0 to 5 V, 4 to 20 mA, or 0 to 20 mA (AN IN 5,6,7 are 4 to 20 mA or 0 to 20 mA only)
Accuracy: ± 0.030% of span maximum error at 25 °C (77 °F)
Temperature effect: ± 0.25% of span over operating range
Impedance: > 60 kΩ for 1 to 5 V input; approximately 250 Ω for 4 to 20 mA input
Transmitter voltage supply is congurable: 8.5 V to 24 V
Over-voltage protection: 30 VDC
A/D resolution: 22 bits (minimum 20 effective bits)
Linearity error: ± 0.020% max.; ± 0.010% typical
Single-ended inputs
Sample rate: 0.1 seconds to 12 hours
Four previous calibrations available stored in device
Congurable shutoff for saving power when transducer warm-up period is not required
10
Section 1 Scanner 3300 EFM

Table 1.1—General Specications
Pulse/Frequency
Inputs 3 channels (congurable as either Pulse/Frequency Inputs or as Analog Inputs for current)
Maximum voltage: 30 VDC
Maximum frequency: 10,000 Hz
Gated transmitter power for each input channel
Transmitter voltage supply is congurable: 8.5 V to 24 V
Accumulation types: uncompensated gas volume, uncompensated liquid volume, mass
Volume: pulse represents discrete units of volume from a turbine, PD, Venturi, Coriolis, or
ultrasonic meter
Mass: pulse represents discrete units of mass from a Coriolis meter
Congurable turbine sensitivity (20, 50, 100 mV, peak-to-peak)
Analog Outputs 2 channels, channel 1 supports HART communication (Future)
Type 4 to 20 mA, galvanically isolated, externally powered
Accuracy (after calibration): ± 0.1% of span maximum error at 25 °C (77 °F)
Temperature drift: ±50 ppm/°C (±27.8 ppm/°F)
Maximum output load resistance (Ωs) = {supply (volts) – 8.0} / 0.02
Maximum voltage: 30 VDC
D/A resolution: 16 bits
Calibration (zero and full-scale) via software
Programmable output alarm value for use during loss of power or communication to CPU
Regulates control valve in PID control applications
Congurable to track any value including PID Control applications
Digital I/O 6 channels, user-congurable as input or output, and two channels that are output only.
DIO1, DIO2, DIO3, and DIO4 are galvanically isolated with a max. output of 60 mA at 30 VDC
DIO5 and DIO6 are high-speed and non-isolated with a max. output of 500 mA at 30 VDC
Input Types Control switch
Pulse
Open collector
Contact closure
Special Functions Advance display
Turn SmartMesh on/off
Reset specic ow run total
Reset specic pulse input total
Unlatch specic digital inputs/output
Acknowledge alarms
Start or refresh WiFi
Publish triggered archive record
Release triggered archive latch
Create partial archive
Abort script program
Reset script program
11
Scanner 3300 EFM Section 1

Table 1.1—General Specications
Digital I/O
(cont’d) Output Modes Pulse (based on pulse count or time period)
Alarm (based on the status of any or all selected alarms; up to 32 user-
congured alarms are selectable)
Conditional (value above or below setpoint, out of setpoint range)
Programmed [time of day or output state (normally open, normally
closed)]
Congurable to track any value including PID Control applications
POUT1 and POUT2 mirror DO 5 and 6
Pulse Output Maximum frequency: 500 Hz
Congurable pulse duration (10 msec to 1 day)
Congurable pulse representation (1 pulse = 1 MCF) based on time or
volume
Based on any accumulator (ow run or turbine meter run)
Alarm Output Low/high
Out-of-range
Status/diagnostic
Web Interface—
Local Device
Management
Access data and device settings via the advanced display on the front of the device
Congure, calibrate, and maintain ow runs, inputs/outputs, and gas streams
Poll real-time data
Download data
View daily logs and up to 7 days of interval (recent) logs
Control user access with four levels of security
Congure communications with up to 20 wired or wireless Scanner 2000 Series devices
Display real-time data, ow rate calculation method, and input averages for up to 20 slave
devices
Read and store conguration data from up to 20 slave devices
Read and store daily and interval archive records for up to 20 slave devices
Change gas composition and plate size in slave device congurations
Download slave data via FTP, HTTP, or Enron Modbus protocol
Synchronize slave device conguration and slave archive data
Read gas streams connected to slave devices
Clear slave device grand totals and alarms
Load factory default conguration le
Remotely reset slave device without cycling power
12
Section 1 Scanner 3300 EFM

Table 1.2—Hardware Options
Wireless
SmartMesh Radio 2.4 GHz self-healing and self-sustaining network
Factory installed antenna coupler with 12-in. coaxial cable and MMCX male connector
Transmits up to 300 m (985 ft) node-to-node
Radio Certications Supports communications with up to 20 remote Scanner 2000 Series devices (each Scanner
node can transmit and receive data)
Radio certications (by country):
Europe: CE Mark, RED
North America: FCC/IC
Antenna Direct-Mount Remote-Mount
Electrical Properties
Frequency Range 2.35 to 2.60 GHz 2.4 to 2.5 GHz
Impedance 50 Ωs nominal at 2.45 GHz 50 Ωs nominal at 2.4 GHz
Voltage Standing Wave
Range (VSWR) ≤ 2.0 typical at center <1.5
Connector SMA N female brass nickel-plated
connector, cable required for
connection to SMA
Height 25.6 mm (1.01 in.) 800 mm (32.28 in.)
Shape Elbow (right angle) Straight
Material Weatherized plastic Fiberglass
Operating Temperature –40 °C to 90 °C (–40 °F to
194 °F) –40 °C to 80 °C (–40 °F to 176 °F)
Pole Mount Hardware
—N/A Standard hardware (included
with antenna) ts pole with
outside diameter up to 2 in.
—N/A Alternate remote-mount kit
available for pipe with outside
diameter of 2 3/8 in.
Antenna Cable Length N/A 10-, 20-, and 30-ft with
connectors
Type N/A Type 400
Temperature Range N/A –40 °C to 70 °C (–40 °F to
158 °F)
Customer Tag Stainless steel tag for customer-specied information, 3 in. × 3 in., wired on, 5 lines of text, 45
character per line maximum
13
Scanner 3300 EFM Section 1

Table 1.3—Scanner Companion Software
Important To download software or software user manuals, visit the Sensia website at
https://www.sensiaglobal.com/Measurement/Types/Flow-Computing-and-Automation, select Scanner
3300 Series Wired and Wireless, and click on the link for the desired software install/manual.
Scanner Logic
IDE Creates Scanner Logic scripts (SLOGIC) and compiles them into a logic-controller program le (SLBIN).
Performs live debugging on scripts, showing immediate and upcoming script sections to be
debugged.
Uses a high-level procedural programming language designed to build logic controllers. In this way,
the program resembles a state machine.
Scanner Data
Manager
Opens proprietary data les (.sdf) downloaded from the Scanner 3300 and provides tools for data
analysis, reporting, export and conversion
Presents data in tabular and trend views
Includes tools for customizing reports
ScanMap Creates custom Scanner 3300 Modbus register maps, including user-specied units, rates, and
register names for SCADA integration
Firmware-specic templates
Auto-generates protocol manual for printing or uploading to the web interface
ScanFlash Uploads rmware (BIN), conguration (SRF), Scanner Logic IDE le (SLBIN), and custom Modbus
register map (PMAP) les to the Scanner 3300
PC Requirements
Windows 7 or later operating system
1 GHz or faster 32-bit (x86) or 64-bit (x64) processor
1 GB RAM (32-bit) or 2 GB RAM (64-bit) available hard disk space (360 MB for companion software installation, 30
MB for software for PDF reading, adequate space for data les)
DirectX 9 graphics device with WDDM 1.0 or later driver
Flow Rate and Fluid Property Calculations
The Scanner 3300 calculates ow rates and uid properties for natural gas and liquid ow in accordance with the fol-
lowing industry standards. The calculations compensate for the effects of pressure, temperature, and uid composition to
determine mass and volume at specied base conditions. The uid corrections typically require conguration of inputs
including static pressure and temperature. The ow calculation requires conguration of differential pressure or pulse
(frequency) inputs.
14
Section 1 Scanner 3300 EFM
