INSTRUCTIONS FOR
X328-384 X328 885
1
INSTALLATION AND OPERATION -
\
MODEL V3200AP AND V3210AP SERIES INDoOR SCANNERS - MICROSCAN,
.J
GENERAL
SCOPE
The information in this instruction manual covers the installa-
tion, operation, and maintenance of the following indoor
scanners:
V3200AP
V32 1 OAP
V3200-24AP V32 1 O-24AP
Throughout this manual, V3200AP is used to refer to all
light-duty scanner models. V3210AP is used to refer to all
medium-duty scanners. Both models have round mounting
bases.
These units should be installed using approved materials
and wiring practices in accordance with the National
Electrical Code and applicable local wiring ordinances.
V3200AP INDOOR SCANNER
INTRODUCTION
tion-free operation. These injection-molded scanners have
The V3200AP and the V3210AP Series Scanners are indooi:-qs” both a permanent stop to permit full 360 degrees rotation
continuous-duty units rated for loads up to 15 pounds
and adjustable limit stops to set pan travel limits ar desired.
(6.8kg) and 25 pounds (11.3kg); respectively, when
mounted in either the upright or inverted positions. Slow- The scanners are energized using the appropriate control
speed, high-torque drive motors with instant start-stop
units. Refer to Table I. A line cord option (Model V32OOLC) is
characteristics provide operational stability without coast. available for the V3200AP and V3210AP models enabling
Drive trains made with acetal output gears provide lubrica- them to autoscan without the use of a control unit.
TABLE I
SCANNER/CONTROL COMPATIBILITY AND OPERATING DISTANCES
Control Model Scanner Model Working Voltage* Wire Size (AWG)
Annealed Copper Maximum Distance
ft. b-4
_... e
V130AP
V130-24AP
V3200AP
V3210AP
V3200-24AP
V3210-24AP
12ov 50/60Hz 22 10,000 (3,048)
22
5,000 (1,524)
22 1,000 (305)
24V 50/60Hz 20 1,500 (457)
18
2,500 (762)
16 4.000 (1,219)
22 350 (107)
24V 50/60Hz 20 550 (167)
18 900 (274)
16 1,400 (427)
*Working voltage refers to the voltage carried by the cable entering scanner
WARNING: TO PREVENT RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
Product specifications subject to change without notice. 8006-8328-02-00
VICON INDUSTRIES, INC. 525 BROAD HOLLOW ROAD, MELVILLE, N.Y. 11747TEL: [phone]TELEX: 144581
TOLL FREE: 800-645-9116 (OUTSIDE OF NEW YORK)

ASSOCIATED EQUIPMENT AND ACCESSORIES
Controls
Scanner controls are available in Phase Eight modules and
in two control voltages. Refer to Table Ifor a listing of
controls and their associated scanners. Each control
provides pushbutton operation of the scanner in both the
manual and automatic modes, a POWER switch, and an
indicator lamp.
Line Cord Option: Model V32OOLC Line Cord permits the
12OV versions of the V3200AP and V32 1 OAP scanners to be
connected directly to a 120V convenience outlet. The
V32OOLC consists of six-foot # 18 AWG two-conductor VW-
1 cable fitted with an unpolarized two-prong plug and a
keyed AMP connector with a positive locking device.
Mounts
The Vicon V114WM and V1600WM Wall Mounts are de-
signed for mounting the V3200AP Series Scanners. Model
V3210AP Series Scanners are designed to be used with the
V1600WM or V2000WM Wall Mounts. Installation of these
scanners on the V2000WM requires the use of the V32OOSB
Square Mounting Base.
iModel V32OOSB Square Mounting Base is available for
adapting the V3200AP and V3210AP Scanners to square-
! base applications.
IMPORTANT SAFEGUARDS
L
I
1
AA
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
GRAPHIC SYMBOL EXPLANATION
The lightning flash with an arrowhead within an
equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous vol-
tage” within the product’s enclosure that may A
be of sufficient magnitude to constitute a risk of
electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the pres-
ence of important operating and maintenance
(servicing) instructions in the literature accom-
A
panying the appliance.
1. Read Instructions - All the safety and operating instruc-
tions should be read before the appliance is operated.
2. Retain instructions - The safety and operating rnstruc-
tions should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructrons
should be followed.
5. Cleaning - Unplug the scanner from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners,
Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recom-
mended by Vicon as they may cause hazards.
7. Water and Moisture -Do not use this scanner near water
for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool,
and the like.
8. Mounts - Do not place this scanner on an unstable cart,
stand, tripod, bracket, or table. The scanner may fall,
causing serious injury and serious damage to the appli-
ance. Use only with mounting hardware recommended by
Vicon. Any mounting of the scanner should follow the
Instructions in the lnstallatron section.
9. Ventilation -The scanner should never be mounted near
or over a radiator or heat register. Thus product should not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilatron is provided or Vicon’s instructions
have been adhered to.
10. Power Sources-This scanner should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supply at your
installation site, consult your Vicon dealer or local power
company.
11. Grounding or Polarization - The V32OOLC line cord
option is equipped with a 3-wire grounding-type plug, a plug
having a third (grounding) pin. This plkg $1 only fit into a
grounding-type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the grounding-type plug.
12. Power-Cord Protection - Power-supply cords should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and
the point where they exit from the appliance.
13. Overloading - Do not overload wall outlets and exten-
sion cords as this can result in a risk of fire or electric shock.
14. Object and Liquid Entry - Never push objects of any kind
into this scanner through openings as they may touch
dangerous voltage points or short-out parts that could result
X328-885

in a fire or electric shock. Never spill liquid of any kind on the
video product.
15. Servicing - Do not attempt to service this scanner
yourself as opening or removrng covers may expose you to
dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
16. Damage Requiring Service - Unplug the scanner from
the wall outlet and refer servicing to qualified service
personnel under the following conditions
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen Into the
scanner.
c. If the scanner has been exposed to rain or water.
d. If the scanner does not operate normally by following
the operating instructions.
e. If the scanner has been dropped or the enclosure has
been damaged.
f. When the scanner exhibits a distinct change in perform-
ance - this indicates a need for service.
17. Replacement Parts - When replacement parts are re-
quired, be sure the service technician has used replace-
ment parts specified by Vicon or have the same char-
acteristics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards.
18. Safety Check, - Upon completion of any service or re-
pairs to this scanner, ask the service technician to perform
safety checks to determine that the scanner IS in proper
operating condition.
INSTALLATION
GENERAL
Fabricate interconnecting cables according to the appro-
priate cableassembly diagrams in Figure 1. For properopera-
tion, the distance between the scanner and its control unit
should not exceed the distance given in Table I for the particu-
lar wire size used.
The cable should be Class 1 wiring in accordance with article
725 of the National Electrical Code.
MOUNTING THE UNIT
These V3200AP and V3210AP series scanners are de-
signed to operate indoors with loads weighing up to 15
pounds (6.8kg) or 25 pounds (11.3kg) respectively. Proper
performance depends on secure fastening to a suitable
mount with the camera correctly mounted and balanced on
the unit. The units are installed directly on Vicon V114WM or
V 1600WM Wall Mounts.
PAN COMMON
PAN RIGHT Cl
c2
PAN LEFT
)3
AUTOPAN
SPARE
SPARE
8000 -9736-O 0
6* ’
5
4O O3
2O Ol
NOTES:
1. CONNECTOR IS SHOWN FROM WIRING SIDE
Figure 1
Interconnecting Cable Diagram
If a Model V32OOSE Square Mounting Base option is used,
refer to Instruction Sheet X505 (supplied with the mount) for
rnstallation instructions.
INVERTED MOUNTING OF UNIT
When units are mounted inverted, the left-right directions
are reversed for manual operation. This must be corrected
when wiring the cable between the control unit and the
scanner. To do this, reverse the leads going to pins 2 and 3
of the connector at one end of the cable. See Figures 3, 3C
and 30 for inverted mounting of scanner and camera.
WIRING THE UNIT TO THE SYSTEM
All scanners are supplied with the appropriate mating cable
connector. Prepare the control cable according to Figure 1.
If you have the V32OOLC line cord option, plug one end of
the cord into the pendant cable connector on the scanner.
The other end IS plugged directly into a 120V wall outlet. The
mating connector supplied with scanner is not used.
SETTING LIMIT STOPS
The stop ring is slotted at five degree intervals except for a
15 degree solid edge containing a molded permanent stop
(I on Figure 2). The pendant cord identifies the back of the
pedestal. In the front of the unit the reversing switch actuator
(4) is visible between the stop ring and the pan housing.
Located on the stop ring are two adjustable plastic snap-on
limit stops (2 and 3). Remove both pti limit stops by pulling
outwards. Full 360 degree rotation is possible with limit
stops removed.
Perform steps 1 through 5 to establish approxrmate limit
stop settings before mounting camera. Make sure that there
is adequate clearance for the camera and lens to rotate
through the required pan angle, and that the rear of the
pedestal faces away from the scene to be viewed.
X328-085

Scanner With Control
1. Energize the control and check that the AUTOPAN
switch is not energized.
2. Press MANUAL RIGHT switch on control and hold until
the scanner rotates to the desired right-hand position.
Release pushbutton.
3. Install the right limit stop (2 on Figure 2) just to the right of
the switch actuator (4) by pushing it into the groove until
it snaps in place.
4. Press MANUAL LEFT on control and hold until the
scanner rotates to the desired left-hand position.
Release pushbutton.
5. Install the left limit stop (3) to the left of the switch
actuator as in step 3.
6. Mount camera on scanner. Refer to MOUNTING THE
CAMERA Section.
7. With both limit stops securely snapped in place, pan to
both stop positions and recheck for exact trim.
Scanner With Line Cord Option
1. Plug line cord into AC outlet
2. Allow unit to autopan to desired right-hand position. Un-
plug cord.
3. Install the right limit stop (2 on Figure 2) just to the right of
the switch actuator (4) by pushing it into the groove until it
snaps in place.
VIEW A-A
2 Right Limit Stop
3 Left Limit Stop
4 Switch Actuator
5 Hex-head Screws (2)
6 Camera Mounting Holes (3)
Figure 2
Limit Stop Adjustments
4. Plug in the line cord and allow the unit to autopan to
desired left-hand position. Unplug cord.
5. Install the left limit stop (3) to the left of the switch actuator
as in step 3.
6. Mount camera on scanner. Refer to MOUNTING THE
:.
CAMERA section.
7. With both limit stops securely snapped in place, energize
the scanner and check for exact trim.
MOUNTING THE CAMERA
CAUTION: Do not mount an autoiris lens on an autopanning
unit. Such use will cause excessive wear on the iris
mechanism as it constantly compensates for different light
levels.
Use a l/4-20 screw and lockwasher to mount the camera.
To obtain the best balance, this screw must be placed in one
of three positions provided (6 on Figure 2). A simple method
to determine camera balance is to place a pencil under the
camera on a flat surface. Move the camera until it balances
on the pencil. The position of the pencil under the camera
then indicates the point which should be at the center of the
mounting place.
The scanner has an off-center pivot on the camera mounting
platform which allows the camera tilt angle to be adjusted
from 10 degrees above the horizon line to 90 degrees below,
or from 10 degrees below the horizon line to 90 degrees
above depending on camera mounting (see Figure 3). To
adjust camera tilt angle at the pivot point, loosen the hex-head
screws (5 on Figure 2) on each side of the camera mounting
bracket and tilt the bracket to the desired position. Retighten
the two screws firmly. The V3210AP Series units have an
additional pan head screw on each side of the bracket.
Loosen for adjustment, then retighten.
OPERATION
Scanners used with a line cord option (V32OOLC) do not use
a control unit. They operate automatically when connected
to the appropriate supply circuit. Other units are energized
through the main power switch on the control unit. For de-
tailed operating instructions refer to the Vicon instruction
sheet supplied with scanner control. - :
MAINTENANCE
These scanners are permanently lubricated and do not re-
quire regular maintenance.
REPAIR
Repairs should be attempted only by skilled personnel in an
adequately equipped facility. See Figure 4 through IO for
Schematic Diagrams and Replacement Parts List.
4X328-885

i ri
A. Normal upright mounting B. Upright mounting when greater than 10 degree up angle is required.
C. Normal inverted mounting
SODEGREE
ANGLE
/
L'j
.t
D. Inverted mounting when greater than 10 degree up angle is required
Figure 3
Scanner and Camera Mounting Positions
SHIPPING INSTRUCTIONS
If a unit must be returned to the factory, follow these direc-
tions:
1, Call or write Vicon for Return Authorization (R.A.) at one
of the following locations:
VICON INDUSTRIES INC.
525 Broad Hollow Road
Melville, New York 11747
516729%2200/600-645-9116
VICON INDUSTRIES INC.
Central Regional Office
400 Bonnie Brae Street
River Forest, Illinois 60305
312-848-5100/600-323-4817
VICON INDUSTRIES INC.
Western Regional Office
950 West Central Ave. Unit C
Brea, California 92621
714-990-3858/800-646- 1832
or 1833
VICON INDUSTRIES (U.K.) LTD
Gunstore Road
Hilsea. Portsmouth
Hampshire PO3 5JP. England
[phone]
VICON INDUSTRIES INC.
Southeastern Regional Office
3010 Business Park Dr., Ste. B
Norcross (Atlanta)
Georgia 30071
404-449-0499/800-824-8479
You must have an R.A. number to send a unit to Vicon
2. On a sheet of paper to be sent with the unit write your
company’s name and address and the name of the
person who issued the R.A. number.
3. Give the Vicon R.A. number. This number MUST appear
on any correspondence concerning the unit being
shipped.
4. Give a brief description of the instali%n.
5. Fully describe the problem and the circumstances under
which it occurs.
6. If the unit is still covered by the warranty, indicate the
unit’s original date of purchase.
7. Attach all the above information to the unit.
8. Pack the unit carefully, using the original shipping carton
or its equivalent for maximum protection.
9. Mark the R.A. number on the outside of the carton, pre-
ferably on the shipping label.
Refer to the Vicon Dealer Price List for complete warranty
information.
X328-885

NC YEL
RED 4
<,
RED
4<,
RED (AP)
C
.
4BRN YEL
I
I‘NO ORN
II
I
I <.
WHT WHTtCOM PAN1 --Cl
I
, </ WHT , <I
i
I
I
I
3 ; GRN
I
! GRN
I
3 (,
! GRN(L)
3 <r
*
-RED ORN
I
I
I
2 <’ ELK 2
<I ELK
] BLK IR1
!
2 <,
II
5
:
1KEYING PIN 5< I KEYING PIN
5( 1SPARE
6 1 KEYING PIN 6 <i SPARE6 </ KEYING PIN
CAPACITANCE FOR Cl
INPUT VOLTAGE 1 CAPACITANCE
II5 v 47 MFO@ 400V
230V I
MFD@ IKVlJOHz
L,2,0-3OBO-03 24V
Ll2lO-3080-02 230V ~1210-3080-01 115V
24V 1 12 MFD@ IOOV
DWG NOS:
1204-4013-00-01
ll5V/23OV
1204 -4012-00-01 24V
Figure 4
Schematic Diagram, V3200AP and V3200-24AP
4(@=--
I
I
I (+
I
I
3q-=-
2 ,
ELK
I
5(
’ KEYING PIN I
6
I KEYING PIN
7----
Ll210-3080-03 24V
~1210-3080-02 230V ~1210-3080-01 ll5V 24 V
I 12 MFD@ IOOV
4 < RED
I
I
I < ’ WHT
I
3<
’GRN
2(
BLK
5 < 1KEYING PIN
NC YEL
4< RED
C
I
BRN BRN YEL YEL
I
WORN
WHT WHT
! WHTtCOMI
ZCI
--CIA
! GRNtL)
RED RED ORN ORN
3 <,
1
2 <i
BLK (R)
1SPARE
5+------
CAPACITANCE FOR CI,CIA
DWG NOS:
1204-4016-00-01 Il5V/23OV
1204-4015-00-01 24V
Figure 5
Schematic Diagram, V3210AP and V3210-24AP
- i
4- 4(1
I
I (!
I
I (I
2 <I SFARE
I
2 <I SPARE
I I
115V LINE CORD HAS 2-PRONG
UNPOLARIZED PLUG
230VLlNE CORD HAS 2 STRIPPED
TINNED CONDUCTORS
Figure 6
Schematic Diagram, Line Cord Option
6X328-885

REPLACEMENT PARTS LIST
REFERENCE
DESIGNATION
Cl
Cl
Cl ClA
Cl CIA
PART NUMBER
8000-8714-00
1802-00 16-O
1
8000-67 14-00
1802-00 16-O 1
USABLE ON
QTY. DESCRIPTION
MODEL
1ACAPACITOR 47 MF400 VDC MYLR V32OOAP
RAD PVC4047
1ACAPACITOR 12MF AX
250 VAC POLY V3200-24AP
2CAPACITOR 400 VDC MYLR
47MF V32 1 0-AP
RAD PVC4047
2
ACAPACITOR 12MF 250 VAC V32 10.24AP
POLY AX
-
-
-
s3
Sl
Ml
MlA
-
-
-
-
-
-
-
-
-
-
-
-
1210-3080-01 1
12 1 o-3080-02 1
12 1 O-3080-03 1
8004-6360-00 1
8004-6360-00 1
1800-0119-02 1
1800-0119~02 1
12043016-00 1
1204-5082-00 1
1204-508 l-00 1
1204~5013-00 2
1204 -5028-00 2
1204 5029-00 2
1140-5098-00 2
! 204 3034 -02 1
1204-3034~01 1
1703 3004 -0 1 1
1703-3004 -02 1
1703-3004 -03 1
A CABLE ASSY, 120V V32 1 OAP V3200AP
A CABLE ASSY, 230V V3200AP V32 1 OAP
(230VAC)
ACABLE ASSY, 24V V32 ;O-24AP V3200-24AP
SWITCH 11 lSM2-T SUB MIN MICRO V32 O-24AP V32 1 OAP1
UL/CSA LISTED RATED 5A/250 VAC
SWITCH 11 lSM2-T SUB MIN MICRO V3200AP V3200-24PS
UL/CAS LISTED RATED 5A/250 VAC
MOTOR PAN 4.1 RPM 12OV ALL
(VW-l MKD ON COND C OF C BOBBIN
MATLZYTEL 101)
MOTOR PAN 4.1 RPM 120V V3210AP V3210-24AP
(VW-1 MKD ON CONC C OF C
BOBBIN MATLZY TEL 101)
PCB ASSY MICRO PAN ALL
BEARING RWK (6000-7476-00) ALL
BEARING (8000-7351-00)
ALL.
STOP PAN LIMIT ALL
SPRING PAN FRICTION AI-L
PLUNGER PAN FRICTION ALL
FRICTION WASHER ALL
ASSY MOTOR PAN 120VAC V3200AP AND V32 1 OAP
ASSY MOTOR PAN 24VAC V3200-24AP AND
V32 1023AP
CONNECTOR ASSY (120V) V3200AP V32 1 OAP
CONNECTOR ASSY (230V) V3200AP V32 1 OAP
CONNECTOR ASSY (24V) V3200-24AP V32 10.24AP
A Parts preceded by this symbol should be replaced by those parts specified in the Relacement Parts List or therr
equivalent. Failure to substitute the correct parts may result in fire, electrical shock, or other hazards.
d i
Copyrfght a 1985 Vicon Industries. Inc All RIghIs Reserved
X328-885 7
