Sercomm UB801R v3 User manual

UB801R v3
USB Wireless-G Adapter

ii
User Guide

i
Table of Contents
CHAPTER 1 INTRODUCTION .............................................................................................1
Package Contents ..............................................................................................................1
Features..............................................................................................................................1
LEDs...................................................................................................................................1
Operation...........................................................................................................................2
CHAPTER 2 INITIAL INSTALLATION..............................................................................3
Requirements.....................................................................................................................3
Procedure...........................................................................................................................3
CHAPTER 3 USING THE WINDOWS UTILITY................................................................7
Overview ............................................................................................................................7
System Tray Icon...............................................................................................................7
Network Screen .................................................................................................................8
Link Status Screen ..........................................................................................................11
Profile Screen...................................................................................................................12
Advanced Screen.............................................................................................................17
Statistics Screen...............................................................................................................19
WMM Screen...................................................................................................................21
WPS Screen......................................................................................................................23
Radio on/off Screen.........................................................................................................25
About Screen....................................................................................................................26
APPENDIX A SPECIFICATIONS .......................................................................................27
Wireless USB Dongle.......................................................................................................27
APPENDIX B ABOUT WIRELESS LANS..........................................................................28
Modes ...............................................................................................................................28
BSS/ESS............................................................................................................................28
Channels...........................................................................................................................29
WEP & WPA-PSK..........................................................................................................29
WPA2-PSK ......................................................................................................................29
Wireless LAN Configuration..........................................................................................30
P/N: 956YMJ0030
Copyright ©2008. All Rights Reserved.
Document Version: 1.0 (2008)
All trademarks and trade names are the properties of their respective owners.

1
Chapter 1
Introduction
This Chapter provides an overview of the Wireless USB Dongle's features and
capabilities.
Congratulations on the purchase of your new Wireless USB Dongle. The Wireless USB
Dongle provides a wireless network interface for your Notebook or PC.
Package Contents
The following items should be included:
•The Wireless USB Dongle Unit
•Quick Start Guide
•CD-ROM containing the on-line manual.
If any of the above items are damaged or missing, please contact your dealer immediately.
Features
•Compatible with IEEE 802.11b and 802.11g 2.4GHz
•Data transmission rate is up to 54Mbps
•Supports Turbo Mode which can enhance the data transmission rate within the specific
wireless network
•Supports WMM (Wi-Fi Multimedia) function (IEEE 802.11e QoS standard) and can meet
the requirement of the multi-media data bandwidth
•Supports 64/128-bit WEP, WPA (TKIP with IEEE802.1x) and WPA2 (AES with IEEE
802.1x) functions for high level security
•Supports CCS (Cisco Compatible Extensions) for the radio monitoring and fast roaming
•Automatic fallback which increases the data security and reliability
•Supports USB 2.0 interface
LED
Wireless USB Dongle
The Wireless USB Dongle has a single Link/Activity LED.
Link/Act LED
(Blue) •On - Associated with the network.
•Off - Not associated with the network.
•Blinking - Data being transferred.
1

USB Wireless-G Adapter User Guide
2
Operation
You should install the supplied software on the CD-ROM before inserting the Wireless
USB Dongle.
If you have any form of the wireless utility beforehand, please uninstall it.

3
Chapter 2
Initial Installation
This Chapter covers the software installation of the Wireless USB Dongle.
Requirements
•Windows 2000/XP/Vista.
•Available USB port.
•CD-ROM drive.
•IEEE802.11b and IEEE802.11g wireless LAN.
Procedure
You should install the supplied software BEFORE inserting the Wireless USB Dongle.
1. Insert the CD-ROM into the drive on your PC.
2. The installation program should start automatically. If it does not, run the Setup.exe
program.
Figure 1: Start Installation
3. On the License Agreement screen, select I accept the terms of the license agreement.Click
Next.
2

USB Wireless-G Adapter User Guide
4
Figure 2: License Agreement Screen
4. Choose Install driver and Allnet WLAN Utility to install both the driver and Allnet utility
software, or Install driver only.
Figure 3: Setup Type Screen
5. Select either Allnet Configuration Tool or Microsoft Zero configuration Tool on the
following screen.

Initial Installation
5
Figure 4: Windows New Hardware Screen
6. On the following screen, click Install.
7. Click Finish to exit the Wizard.
8. Insert the Wireless USB Dongle firmly into USB port of the PC.
9. If the Wireless USB Dongle was installed properly, you will now have a new icon in your
system tray, as shown below.
Figure 5: System Tray Icon

USB Wireless-G Adapter User Guide
6
Wireless USB Dongle Icon Table
Connection to the Wireless USB Dongle is established. The length of
green color indicates the signal strength.
No connection to the Wireless USB Dongle.
The Wireless USB Dongle is unplugged.
10. You can double- click this icon to configure the Wireless interface. See the following
chapter for details.

7
Chapter 3
Using the Windows Utility
This Chapter provides Setup details for the AP mode of the Wireless USB
Dongle.
Overview
If using Windows, you can use the supplied utility to configure the Wireless interface.
To Use the supplied Windows utility for Configuration
•Double-click the Wireless Utility icon in the desktop.
•Click Start - Programs - Allnet-All0233 - Wireless Utility.
This Chapter assumes you are using the supplied Wireless utility.
System Tray Icon
If the Wireless Utility program is running, you can double-click the icon in the System Tray or
right-click the icon and select "Launch Config Utility" to open the application.
Status Information
The menu options available from the System Tray icon are:
•Launch Config Utility - This will display the main screen of the Utility.
•Use Zero Configuration as configuration Utility - Wireless Zero Configuration (WZC),
is a service of Microsoft Windows which dynamically selects a wireless network to con-
nect.
•Exit - Terminate the connection to the Wireless USB Dongle.
Figure 6: Wireless USB Dongle menu
3

USB Wireless-G Adapter User Guide
8
Connecting to a Wireless Network
Double-click the Icon to open the Network screen, where you can select the Wireless network
you wish to join.
Network Screen
This screen is displayed when you double-click the system tray icon. You can also click the
Network tab in the screen.
When you open the utility program, it will scan all the channels to find all the access
points/stations within the accessible range and automatically connect to one of the wireless
devices which have the highest signal strength.
Figure 7: Network Screen
Data - Network Screen
SSID The SSID (up to 32 printable ASCII characters) is a unique name
identified in a WLAN.
Network Type It displays the Network type in use, Infrastructure for BSS, Ad-Hoc
for IBSS network.
Channel The channel used by the Wireless network.
Wireless Mode AP support wireless mode. It may support 802.11a, 802.11b or
802.11g wireless mode

Using the Windows Utility
9
Security-Enable Whether AP provides security-enabled wireless network.
Signal This is displayed as percentage (0 ~ 100%) of specified network.
Rescan Click this button to rescan for all Wireless networks.
Add to File Click this button to add the selected AP to Profile setting. It will bring
up profile page and save user's setting to a new profile.
Connect Click this button to connect the Wireless network.
Wireless Network Sequence (order)
You can click the radio buttons in the Sort by >> section (ex. SSID, Channel or Signal) to
arrange the Wireless network in the desired order.
To Connect to a Wireless Network
•Click the name of the wireless network to which you want to connect, and then click
Connect.
Note that once you are connected to a Wireless network, the Network screen will identify the
current wireless network with a blue arrow icon, as shown below.
Figure 8: Network Screen – Connected

USB Wireless-G Adapter User Guide
10
Icons
It indicates network type is infrastructure mode.
It indicates network type is Ad-hoc mode.
802.11b wireless mode
802.11g wireless mode
802.11n wireless mode
It indicates security-enabled wireless network.
It shows the information of Link Status Section.
It hides the information of Link Status Section.

Using the Windows Utility
11
Link Status Screen
The Link Status section displays the detailed information of the current connection. Click
button to show the status screen.
Figure 10: Link Status
Data - Link Status
Link Information
Status It will indicate the current link status.
Extra Info It shows the link status.
Channel It displays the current channel in use.
Authentication It will indicate the current authentication mode in use.
Encryption It shows the wireless security that the wireless network is using.
Network Type This will indicate "Infrastructure" or "Ad-hoc".
IP Address It shows the current IP address on the wireless interface.
Subnet Mask Subnet mask for the current IP address.
Default Gateway Gateway IP address associated with the current IP address.
HT It displays current HT status in use (802.11n wireless card
only).
Link Quality It displays connection quality based on signal strength and
TX/RX packet error rate.
Signal Strength (1~3) It receives signal strength (1~3), user can choose to display as
percentage or dBm format.
Noise Strength It displays noise signal strength.
Link Speed It will show current transmit rate and receive rate.
Throughout It displays transmits and receive throughput in unit of Mbps.

USB Wireless-G Adapter User Guide
12
Profile Screen
Click Add to Profile button on the Network tab, or you can choose Profile tab of the utility,
then click Add, the Add Profile window will pop up. Users can setup the general settings,
encryption and authentication settings and so on. If you want to do the general settings, please
follow the instructions below.
Figure 10: Profile Screen
Data - Profile Screen
System Config
Profile Name Enter or select a suitable name for this profile. Each profile must
have a unique name.
SSID If the desired wireless network is currently available, you can
select its SSID. Otherwise, type in the SSID of the desired wire-
less network.
Power Save Mode Select either CAM (Constantly Awake Mode) or PSM (Power
Saving Mode).
RTS Threshold Select a value within the range of 0 to 2347 bytes
Fragment Threshold Select the value from 256 to 2346 bytes. The default value is
2346.

Using the Windows Utility
13
Network Type Select the desired option:
•Infrastructure - Select this to connect to an Access point.
•Ad-Hoc - Select this if you are connecting directly to another
computer.
Tx Power Select the Tx (transmission) power according to the real envi-
ronment.
Preamble The preamble defines the length of the CRC (cyclic redundancy
check). Select either Auto or Long Preamble.
OK button Click this button to save the settings and close the page.
Cancel button The "Cancel" button will discard any data you have entered and
exit the page.
Auth./Encyp.
Authentication You MUST select the option to match the Wireless LAN you
wish to join. The available options are:
•Open - Broadcast signals are not encrypted. This method can
be used only with no encryption or with WEP.
•Shared - Broadcast signals are encrypted using WEP. This
method can only be used with WEP.
•LEAP - Light Extensible Authentication Protocol is a pre-
EAP, Cisco-proprietary protocol. If selected, you have to en-
ter the identity, password and domain name of your
computer.
•WPA - This version of WPA requires a Radius Server on
your LAN to provide the client authentication according to
the 802.1x standard. Data transmissions are encrypted using
the WPA standard.
•WPA-PSK - PSK means "Pre-shared Key". You must enter
this Passphrase value; it is used for both authentication and
encryption.
•WPA2 - This version of WPA2 requires a Radius Server on
your LAN to provide the client authentication according to
the 802.1x standard. Data transmissions are encrypted using
the WPA2 standard.
•WPA2-PSK - This is a further development of WPA-PSK,
and offers even greater security. You must enter this Pass-
phrase value; it is used for both authentication and
encryption.
•WPA None - If selected, you can only set encryption and
WPA-Preshared Key settings.

USB Wireless-G Adapter User Guide
14
Encryption The available options depend on the Authentication method
selected above. The possible options are:
•None - No data encryption is used.
•WEP - If selected, you must enter the WEP data shown
below. This WEP data must match the Access Point or other
Wireless stations.
•AES, TKIP - These options are available with WPA-PSK,
WPA2-PSK, WPA and WPA2. Select the correct option.
Use 802.1x This setting only takes effect when using Open, Shared, WPA or
WPA2 mode. If enabled, click the 802.1x tab to configure the
related settings.
WPA Preshared Key For WPA-PSK and WPA2-PSK modes, you need to enter the
desired value (8~63 characters). Data is encrypted using a 256Bit
key derived from this key. Other Wireless Stations must use the
same key.
WEP Key (1~4) This setting is only available for Open or Shared mode.
There are 2 modes:
•Hex - Only "A~F", "a~f", and "0~9" are allowed to be
entered.
•ASCII - Numerical values, characters or signs are all al-
lowed to be entered.

Using the Windows Utility
15
802.1x
EAP Method There are 5 methods in the drop-down list.
•PEAP - Protect Extensible Authentication Protocol. PEAP
transport securely authentication data by using tunneling be-
tween PEAP clients and an authentication server. PEAP can
authenticate wireless LAN clients using only server-side cer-
tificates, thus simplifying the implementation and
administration of a secure wireless LAN.
•TLS-Smart Card - Transport Layer Security. Provides for
certificate-based and mutual authentication of the client and
the network. It relies on client-side and server-side certifi-
cates to perform authentication and can be used to
dynamically generate user-based and session-based WEP
keys to secure subsequent communications between the
WLAN client and the access point.
•TTLS - Tunneled Transport Layer Security. This security
method provides for certificate-based, mutual authentication
of the client and network through an encrypted channel. Un-
like EAP-TLS, EAP-TTLS requires only server-side
certificates.
•EAP-FAST - Flexible Authentication via Secure Tunneling.
It was developed by Cisco. Instead of using a certificate, mu-
tual authentication is achieved by means of a PAC (Protected
Access Credential) which can be managed dynamically by
the authentication server. The PAC can be provisioned (dis-
tributed one time) to the client either manually or
automatically. Manual provisioning is delivery to the client
via disk or a secured network distribution method. Automatic
provisioning is an in-band, over the air, distribution.
•MD5-Challenge - Message Digest Challenge. Challenge is
an EAP authentication type that provides base-level EAP
support. It provides for only one-way authentication - there is
no mutual authentication of wireless client and the network.
Tunnel Authentica-
tion Select the desired option from the drop-down list.
Session Resumption After reconnecting the signal which broke up, you can enable the
session resumption to reduce the transferring packet to accelerate
the speed.
Authentication ID /
Password Enter the required data into the fields.
Tunnel ID / Password Enter the ID and Password for the tunnel.
Use Client certificate Click the checkbox to enable certificate authority server function.
Use certificate chain When the EAP authentication type such as TLS, TTLS or PEAP
is selected and required a certification to tell the client what
server credentials to accept from the authentication server in
order to verify the server, you have to enable this function and
enter the required data in the related fields.

USB Wireless-G Adapter User Guide
16
To add a profile
1. On the Profile tab, click Add button.
2. Complete and verify the settings on this screen are correct.
3. Click OK.
To delete a profile
1. On the Profile tab, select the profile that you want to delete.
2. Click Delete.
To edit a profile
1. On the Profile tab, select the profile that you want to edit.
2. Click Edit button.
3. Change the profile settings as necessary.
4. Click OK.
To enable a profile
1. In the list of available profiles, click the profile that you want to enable.
2. Click Activate.
