Zoom Game Point! 4420 User manual

Now you can play Xbox®and PlayStation®2 multi-player games on any TV in your
home. Thrill to the drama of the wide-screen TV with surround sound in your family
room, or enjoy the privacy of the TV in your bedroom or study. Just plug Game Point!
into your TV-connected game console to enjoy online or in-home multi-player gaming
by linking to your wireless network.
Game Point!™lets you make a wireless
connection to any 802.11 b/g access
point or router, no matter where it is in
your home, to connect to other gaming
devices in your home and on the Internet.
Want to play head-to-head games even
without a home network?Just connect a
Game Point! adapter to each game console,
and you're ready to play.
Zoom
Game Point!
Wireless
Gaming Adapter
Model 4420
•Uses wireless-G technology plus speed
enhancements for very fast standards-
based wireless connectivity
•Two built-in omni-directional dipole
antennas increase your wireless speed
and range
•Built-in security with WEP encryption
(64 and 128 bit WEP)
•Compatible with Zoom and other
802.11g and 802.11b wireless networks
including Belkin®, D-Link®, Linksys®,
Netgear®, and mixed networks where
both 802.11b and g are used together
•Works great with Halo2, Madden NFL,
NCAA Final 4, other EA Sports, the Tom
Clancy Splinter Cell series, MMORGs, and many other games
•Works with Microsoft®Xbox , Sony®Playstation 2, or any other gaming device with
an Ethernet port. (PlayStation 2 requires an Ethernet gaming adapter from Sony.)
•Game Point! is small, so it's easily moved from one room to another
•Game Point! is fast, with extremely low lag
Enjoy the experience of online multi-player and head-to-head games
like you never have before with Game Point!
Workswith
Speed Comparison
Popular 802.11 Technologies
The 802.11g Wi-Fi standard transmits at a maximum
of 54 Mbps. Higher effective speeds, like 125 Mbps,
can be achieved by using special compression algo-
rithms and techniques like packet aggregation and
frame bursting. The maximum speed you get depends
on the type of data being sent and the actual data rate
of your 802.11g connection.
b
Zoom
125
g
The Model 4420
easily connects a
PlayStation®, XBOX®
or any game station
with an Ethernet port
to a wireless net-
work or other
802.11 wireless-
enabled gaming
devices
Works in all
802.11g, 802.11b,
and mixed networks
Zoom 125 Speed
Booster for faster
802.11g
2 moveable external
antennas extend the
range and boost
performance
2-year
manufacturer’s
warranty

Specifications
Standards • 802.11b/g (Wireless LAN)
Interface Security • 10/100 Mbps RJ45 Ethernet port
• 64/ 128 bit, WEP (Wired Equivalent Privacy) with Pass Phrase
Radio Technology • 802.11b: Direct Sequence Spread Spectrum (DSSS)
• 802.11g: Orthogonal Frequency Division Multiplexing (OFDM)
Antennas • Two adjustable omni-directional dipole antennas, each with 2 dBi minimum gain
Transmission Rates • 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps
• Zoom 125 Speed Booster for up to 125 Mbps effective rate*
Range Coverage • Indoor : Up to 100 Meters (328 Feet) depending on environment
• Outdoors: Up to 350 Meters (1155 Feet) depending on environment
Receiver Sensitivity • 54 Mbps: Typical -68 dbm @ <10 % PER (Packet Error Rate)
• 11 Mbps: Typical -82 dbm @ <8% PER (Packet Error Rate)
LED Status Indicators • Power
• Network Link/Activity
• Wireless Activity: Transmit (TX) / Receive (RX)
Wireless LAN • IEEE 802.11b/g
Frequency Range • US (FCC) Channel 1 through 11
• Canada (IC) Channel 1 through 11
• Europe (ETSI) Channel 1 through 13
Dimensions (L x W x H) • 143 x 122 x 30.3 mm / 5.63 x 4.80 x 1.19 inches
Weight • 150 grams / 0.40 LBS
Power Supply • Input Output
- US: 100-120 AC 50-60 Hz 5 VDC, 1A
- EU: 200-240 AC 50-60 Hz 5 VDC, 1A
Temperature • Operating 0 to 45 C (32 to 104 F)
• Storage -40 to 70 C (-40 to 158 F)
Humidity • 5 - 95% non-condensing
Power Consumption • 3.5 watts maximum
Transmit Power (typical) • > +15 dBm
Compliance • FCC (MPE) IEEE C95.1, 15B, Part 15C
•CE
• Canada RSS-210
• EN60950-1:2001, EN300-328-v1.4.1 (2003-04)
• AS/NZ 4771:2000
• EN301-489-1 v1.4.1 (2002-08),
• EN301-489-17 V1.2.1 (2002-08)
• EN55022:1998+A1:2000+A2:2003, Class B
• EN61000-3-2:2000 Class A,
• EN61000-3-3:1995+A1:2001, EN61000-4-2:1995+A1:1998+A2:2001
• EN61000-4-3:1996+A1:1998+A2:2001,
• EN61000-4-4:1995 +A1:2001+A2:2001,
• EN61000-4-5:1995+A1:2001,
• EN61000-4-6:1996+A1:2001,
• EN6100-4-11:1994+A1:2001
Software Drivers • Windows 98, 98SE, Me, 2000, XP
* The 802.11g Wi-Fi standard transmits at a maximum of 54 Mbps. Higher effective speeds can be achieved by using compression algorithms and techniques
like packet aggregation and frame bursting. The maximum speed obtained by the Model 4400 depends on the type of data being sent and the actual data
rate of an 802.11 connection.
System Requirements
A computer with an Internet browser and Ethernet port is required to set up the gaming adapter
0176 4420
Game Point!
Model 4420
International
Headquarters
Zoom Technologies, Inc.
207 South Street
Boston, MA 02111
USA
Tel: [phone]
Fax: [phone]
email: [email protected]
www.zoom.com
Nasdaq: ZOOM
European
Sales/Support
Zoom Technologies, Inc.
Central House
2 Kings Road
Fleet, Hants
GU51 3AD UK
Tel: [phone]
Fax [phone]
©2005 Zoom Technologies, Inc.,
207 South Street, Boston, MA 02111 USA
Zoom is a registere tra emark of Zoom
Technologies, Inc. Microsoft an Xbox are
registere tra emarks of Microsoft
Corporation. Playstation is a registere
tra emark of Sony Corporation. All other
registere tra emarks are the property of
their respective hol ers.
Package contents:
• Wireless-G Gaming Adapter
• CD with User Manual
• Quick Start Manual
• Ethernet cable
