SEVIC SV070270D User manual

- 1 -
SV070270D
- Operating manual
VISION LIBERTY COMBO 2

- 2 -
Introduction
Thank you for choosing the 7” portable DVD player. The unit applies the
latest state of the art electronics and is designed for use in hotels, offices
or your home. The DVD Player is constructed to provide years of reliable,
trouble-free service, and is compact so that you can take it with you
anywhere and is designed for quick and easy setup. Please read all
documentation prior to using this product. The documentation will assist
you in obtaining the best equipment performance. Save this manual for
later use.
Important Notice
It is unlawful in most jurisdictions for a person to drive a motor vehicle
which is equipped with a television viewer or screen that is located in the
motor vehicle at any point forward of the back of the driver’s seat, or that
is visible, directly or indirectly, to the driver while operating the vehicle.
In the interest of safety, this system should never be installed where it
will be visible, directly or indirectly, by the operator of the motor vehicle.
Safety Precaution
For safety reasons, when changing video media, it is recommended that
the vehicle is not in motion, and that you do not allow children to
unfasten seat-belts to change video media or make any adjustments to
the system.
Enjoy your entertainment system but always remember-safety of all
passengers remains the number one priority.

- -3
Important Safety Instruction
This product has been listed as class 1 laser product. The mark is on the rear panel.
CAUTION
1. The product contains a low-power laser device. In order to ensure the safety of the
laser device, do not remove any cover and attempt to repair the unit. If any service
is needed, please contact the distributor or its authorized service center.
2. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel. Unplug
the product from the wall outlet before servicing or when it is unused for a long
period of time.
3. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
4. Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
WARNING
The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of un-insulated “dangerous
voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CLASS 1 LASER PRODUCTCLASS 1 LASER PRODUCT

- 4 -
Important Safety Instruction
Notes
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Maintain well ventilated conditions around
the product. Do not put product on bed, sofa or anything that blocks ventilation.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Read, heed and follow all instructions to ensure correct and safe installation and
interconnection of the apparatus;
10. The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus;
11. The mains plug shall remain readily operable;
12. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
13. Only use attachments/accessories specified by the manufacturer.
14. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
15. Unplug the apparatus during lightning storms or when unused for long periods of
time.
16. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Copyright Protection
This product incorporates copyright protection technology that is protected by U.S.
patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.

- -5
Table Of Contents
Introduction--------------------------------------------------------------------------------------------
Important Safety Instruction---------------------------------------------------------------------
Table of Contents -----------------------------------------------------------------------------------
Main Features ----------------------------------------------------------------------------------------
View of Main Unit------------------------------------------------------------------------------------
Remote Control --------------------------------------------------------------------------------------
System Connections ------------------------------------------------------------------------------
Connecting toAC Adapter --------------------------------------------------------------------------
Connecting to a TV------------------------------------------------------------------------------------
Connecting to a NormalAmplifier ----------------------------------------------------------------
Connecting to a Digital Amplifier ------------------------------------------------------------------
Connecting to External AV Signal Source-------------------------------------------------------
Connecting to DC Adapter--------------------------------------------------------------------------
Playback Preparations ----------------------------------------------------------------------------
UsingOf Remote Control ---------------------------------------------------------------------------
Using Wired Headphone ----------------------------------------------------------------------------
UsingWireless Headphone ------------------------------------------------------------------------
Disc Formats Supported By This Player --------------------------------------------------------
Rechargeable Battery Pack----------------------------------------------------------------------
About Rechargeable Battery Pack----------------------------------------------------------------
Battery Pack Attaching and Placement----------------------------------------------------------
Charging the Battery Pack -------------------------------------------------------------------------
Detaching the Battery Pack ------------------------------------------------------------------------
Playback Operation --------------------------------------------------------------------------------
DVD Playback------------------------------------------------------------------------------------------
CD Playback--------------------------------------------------------------------------------------------
JPEG Playback----------------------------------------------------------------------------------------
DIVX Playback-----------------------------------------------------------------------------------------
System Setup ----------------------------------------------------------------------------------------
Troubleshooting -------------------------------------------------------------------------------------
Specifications-----------------------------------------------------------------------------------------
1
2
4
5
6
8
10
10
10
11
11
12
12
12
13
13
14
15
16
16
17
18
19
20
21
23
24
24
26
29
30

- 6 -
Main Features
High Quality Audio and Video
Excellent Sound
Dolby Digital output to produce excellent
audio output signal.
High Resolution
MPEG2 decoding format achieves more
than 500 lines of horizontal resolution.
LCD (Liquid Crystal Display) Screen
Designed with a 7” color LCD screen.
Special Functions
Supports parental-lock features.
AV Input
External audio, video input can be
connected to most external AV sources.
Digital Out
Convenient optical digital audio output
jack for connecting with most amplifiers.
Headphone Output
Movie or music audio in private.
Switching Power Adapter
Automatically adapts to voltage required.
Advanced Playing Function
Compatibility
DVD, CD, CD-R, CD-RW and JPEG
discs are compatible.
ON-Screen Display
ON-screen displays in your choice of
English /Spanish/ French /Italy/German.
Viewing Performance
Multi-speed, fast forward, fast backward,
slow play and repeat playback.
Zoom Function
Allows the viewer to zoom in the picture.
Search By Time
Search for a certain time on a disc.
Last Memory Playback
Continues playing from a stopped point as
long as power is applied to the DVD
Player.
Region Code
DVD players and discs are coded by
region. These regional codes must
match the played discs. If the codes
don’t match, the disc cannot be played.
This player’s default code is region 2.

- 7 -
View of Main Unit
Front and Right Panel
1. PIC button
Press to enter the brightness, color or contrast adjusting mode, then use the +/-
button to adjust the items. Press and hold the button for about 1~2 seconds to
shift screen aspect ration between 16:9 and 4:3.
2. /-button
Press to go to beginning of a previous track/chapter.
Press to decrease the brightness, color or contrast levelin the adjusting mode.
3. +/button
Press to go to next track/chapter.
Press to increase the brightness, color or contrast level in the adjusting mode.
4. /PLAY/PAUSE button
Press to start playback or pause playback.
5. / STOP/ EJECT button
Press to stop playback. Press again to go to the beginning of the movie. Press
to eject the disc.
6. ON/OFF button
Press and hold for 1.5 seconds to turn Power On or OFF.
7. Infrared (IR) Audio Signal Emitter/ (IR) Remote Sensor
IR Transmitter for optical wireless IR headphones.
IR Sensor for remote control operation.

- 8 -
View of Main Unit
8. Power ON Indicator
Light turns green when the player is in work status. It will turn off automatically
when enter standby mode.
9. Speakers
Provides high quality Audio outputs.
10. Disc Tray
When loading the disc into the disc tray, it will be automatically slotted in.
11. LCD Screen
Provides a high-resolution picture.
Left Panel
1. Headphone Jack
Used to connect to wired headphone for private listening. When headphone is
connected, the speakers will automatically turn off.
2. Speaker/Headphone Volume Adjusting control
Used to adjust the headphone and speaker volume.
3. Video Input/Output Jack
Used for connection to an external monitor or video source.
4. Audio Input/Output and Optical Digital Output Jack
Used for connection to an external amplifier or digital processor or external audio
source.
5. AV IN/OUT Switch
Switch to IN to input an external audio/video source.
Switch to OUT when the player is connected to an external monitor.
6. DC 12V Input Jack
For connecting to power supply, including CarAdapter.

- 9 -
Remote Control
Remote Control
1. PWR button
Press to turn ON or OFF the power.
2. SUBT button
When a DVD with subtitles is
playing, press to select a subtitle
language or to turn subtitle OFF.
3. TITLE button
Press to display titles if present on
the disc.
4. Direction buttons
Press to select menu items.
5. ENTER button
Press to confirm the items or
settings.
6. SETUP button
Press to access the DVD player’s
setup menu.
7. 0-9 Number buttons
Select 0-9 numbers by pressing
these buttons.
8. PREV SKIP button
Press to go to beginning of the
previous track/chapter.

- 10 -
Remote Control
9. NEXT SKIP button
Press to go to next track /chapter.
10. A-B Repeat button
Used to play a section of the DVD
from point A to point B. Press once
to select the starting point (A) press
again to select the end point (B).
Press a third time to stop the A-B
Repeat
11. REP button
Press to repeat a chapter, track, title,
or the entire disc.
12. EJECT button
Press to eject disc.
13. AUDIO button
Press to access various audio
languages, when the DVD disc
contains multiple audio languages.
14. BACK LIGHT button
Press to turn the screen on or off.
15. MENU button
Press to open the disc menu.
16. INFO button
Press for detailed information on the
disc. Keep pressing the button to
remove information from screen.
17. STOP button
Press once to stop playback. Press
the PLAY/PAUSE button to resume
normal playback. Press the button
twice to stop playback completely.
18. /PLAY/PAUSE button
Press to start playback. Press again
to pause playback.
19. GOTO button
Press to select the desired disc
starting time, track or title.
20. +10 button
Select numbers greater than 9 by
pressing the (+10) button first, and
then additional number buttons as
needed.
21. FWD SCAN button
Press to search forward.
22. REV SCAN button
Press to search backward.
23. SLOW button
Press to activate slow playback.
24. ZOOM button
Press to enter and cycle through
zoom functions, use the direction
buttons to move around the screen.

- 11 -
System Connections
Always ensure that the DVD player, TV and any other electrical equipment to be
connected to the DVD player are switched OFF.
Ensure that you observe the color coding when connecting audio and video
cables.
Connecting to AC Adapter
Connect the supplied adapter to the side of the DVD player in the jack marked “DC
12V IN”. Plug the two-prong end of the power cord to an AC100-240V outlet. If you
have difficulty inserting the plug, turn it over and reinsert it. If the DVD Player will not
be used for a long time, disconnect the plug from the outlet.
Connecting To a TV
Audio/video connections
The easiest way to connect the DVD player to a television is via the supplied
Audio/Video cable. Connect the audio/video cable from the DVD player to the
audio/video inputs of the TV. And also switch the AV IN/OUT to OUT.

- 12 -
System Connections
Connecting to a Normal Amplifier
The DVD player can be connected to an amplifier. Please refer to the equipment’s
manual before connecting. After connecting, switch the AV IN/OUT to OUT.
Connecting to a Digital Amplifier
The DVD Player can be connected to an amplifier with a digital optical input. The
cable is not supplied, but can be purchased at most home electronics retailer. Refer to
the operation manual of the digital amplifier when connecting. After connecting, switch
the AV IN/OUT to OUT.

- 13 -
System Connections
Connecting to External AV Signal Source
The unit supports AV signal input function. Use the audio/video cable to connect the unit
to the external AV signal source such as a DVD, VCR etc. after connecting, switch theAV
IN/OUT button toAV IN.
Connecting to DC Adapter
To use the Vehicle DC Adapter disconnect the Battery pack and connect the supplied
Vehicle Power Plug Adapter into the DVD Player’s Power Jack and the other end into
the Vehicle DC outlet (Cigarette Lighter Socket) as shown below.
Do not operate the unit or view video software while driving a vehicle.
Place the unit in a secure position for viewing.
Do not leave battery attached when using car adaptor as power source.
Make sure the unit and the car adapter are not connected when startingthe car.

- 14 -
Playback Preparations
Using of Remote Control
1. Remove the empty battery receptacle. Refer to the drawing above.
2. Insert the battery into the receptacle and insert the receptacle into the remote.
3. For best results, aim the remote directly at the player’s receiving window within
15 feet, and angles of not exceeding 60 degrees.
4. The path between the remote control and remote sensor should be free of
obstructions.
5. Under normal use the battery will last for one year.
6. Remove battery if the remote is not to be used for a long time or during storage.

- 15 -
Playback Preparations
Using wired Headphone
Connect headphone into the
headphone Jack onthe left side of the
unit. As shown below:
Quick Tips:
Excessively loud volume could
damage your hearing.
Turn down the volume before you
connect the headphones, and then
raise the volume to comfortable
level.
Sound from the DVD Player’s
external speaker will stop when
headphones are connected.
Using Wireless Headphone
The unit also supports IR function. You
can use a wireless headphone when
listening the music. Please take the
steps below when using the wireless
headphone.
1. For best results, when using
wireless headphone sit facing the
screen, within the range of 12 feet
and angles of 60 degrees, and
without obstacles between wire-
less headphones and infrared
audiosignal emitter.
2. Set the IR ON in the audio setup
menu first.
3. If there is no sound, make sure the
batteries in the headphones are
not discharged.

- 16 -
Playback Preparations
Disc Formats Supported By This Player
DISC LOGO DIAMETER PLAYBACK TIME/
PLAYABLE SIDES
133 min (SS-SL)
242 min (SS-DL)
266 min (DS-SL)
DVD 12cm
484 min (DS-DL)
CD 12cm 74 min
JPEG 12cm
DIVX 12cm
The disc maker specifies the operation of some DVD discs. Please refer to the
instruction manual with the disc.
Care of Discs
Do not touch the playing surface of the
compact disc.
Do not stick paper labels on the disc.
Storage of Discs
Do not expose discs to direct sunlight or
excessive temperatures
Cleaning of Discs
If a disc has fingerprints or dust on it,
lightly wipe the disc with soft cloth from
the center of the disc outward in a
circular manner.
Never use record cleaning sprays, or
any other solvents to clean your discs.

- 17 -
Rechargeable Battery Pack
About Rechargeable Battery Pack
Your portable DVD player comes with a lithium ion rechargeable battery that attaches
to the bottom of the player. Your new battery should be fully charged before initial use.
Charging time is normally about 5 hours. A fully charged battery delivers about 2.5
hours of use, but playing time varies from disc to disc. If the battery will not be used
for a long period of time, first fully charge the battery prior to storage.
Working conditions and precautions of the battery
New batteries should be fully charged before initial use.
Battery should only be used and charged when temperatures are between
32-100F.
Never put the battery in fire or water.
Do not expose the battery to high temperatures or store in hot, sunny
places.
Maintain well-ventilated conditions around the product, avoiding heat. Don’t
put the product on bed, sofa or anything that may block ventilation to the
product.
Do not open the battery.
Never charge the battery for more than 8 hours. Detach battery immediately
after charging is complete if not being used. When charging the battery
pack, the light on the battery will turn red, when the charging is complete or
the battery is being used, the light will turn green.
Detach battery when not in use.
When the battery is weak, a mark which indicates the battery is weak will
appear on the LCD screen, and about one minute later, the player will turn
powerOFF automatically.
Notes: in the case of using adapter, the LCD screen will be lighter than with the
rechargeable battery.

- 18 -
Rechargeable Battery Pack
Warning:
Do not touch any metal objects to the battery connectors, as it will put the battery in
standby mode. To exit the standby mode, connect the battery and DVD player to AC or
DC power.
Battery Pack Attaching and Placement
The DVD Player’s power supply is the AC power adapter or the battery pack, which
are provided with the player. The battery pack also can be used as a stand.
Refer to the following steps for attaching the Battery Pack:
1. Place the DVD Player on a soft and smooth surface with its back cover facing UP
to avoid scratching the screen.
2. Position the Battery Pack directly toward the battery slot on the back cover of the
DVD Player.
3. Align the pins on the battery pack with holes on the player.
With one hand on the DVD Player to prevent it from moving, and push the battery
pack into the DVD Player. Then slide the Battery Pack toward the back of the DVD
Player until you hear it click and lock into place.

- 19 -
Rechargeable Battery Pack
After attaching the Battery Pack, place the DVD Player LCD screen in normal position.
The attached Battery Pack serves as a stand. The battery pack can be locked with the
main unit. As shown below:
When used in a vehicle, the DVD Player is placed into a sturdy carrying Bag/Mount.
The Bag/Mount is easy to attach to a headrest and fits on most vehicle headrest
types. This is convenient for the rear seat passengers to view the screen.
Charging the Battery Pack
The battery must be attached to the DVD player to charge it. Plug the Power Adapter
into the Player’s DC 12V IN Jack, which is located on left Side of the DVD Player. Plug
the other end of the Power Cord into a wall Outlet.

- 20 -
Rechargeable Battery Pack
Detaching the Battery Pack
If the DVD Player is not going to be used for long periods of time, the Battery Pack
should be detached. When the DVD Player is turned OFF, the DVD Player is still
consuming some power in STANDBY mode. This could lead to discharging the
battery.
1. Place the player on a soft and smooth surface with its back cover up to avoid
scratching the screen.
2. Press the button located on the backside of the unit to unlock the battery pack
and while pressing the button pullthe battery pack out fromtheDVD Player.
Note: Please detach the battery pack when Car Adapter is connected with the
unit. When attaching or detaching the battery pack, make sure to protect the
LCD screen.
