SEW-Eurodrive MOVIMOT MM..D Series Installation and operating instructions

Drive Technology \ Drive Automation \ System Integration \ Services
Addendum to the Manual
MOVIMOT
®
MM..D – Functional Safety
Connection Example for Installation Close to the Motor
Edtion 07/2011 19317212 / EN

SEW-EURODRIVE—Driving the world

Addendum to Manual – MOVIMOT® MM..D – Functional Safety, Installation Close to Motor, Example 3
Contents
Contents
1 General Information ............................................................................................ 4
1.1 Rights to claim under limited warranty ........................................................ 4
1.2 Exclusion of liability..................................................................................... 4
1.3 Applicable documentation........................................................................... 4
1.4 Functional description ................................................................................. 4
2 Connection Variants ........................................................................................... 5
2.1 MOVIMOT®with binary control (inverter mounted on motor) ..................... 5
2.1.1 General configuration .................................................................. 5
2.1.2 Permitted terminal assignment for direction of rotation signals
(jumpers in terminal box) ............................................................. 5
2.2 MOVIMOT®with binary control (installation close to the motor)................. 6
2.2.1 General configuration .................................................................. 6
2.2.2 Hybrid cable (motor cable) connection ........................................ 7

4Addendum to Manual – MOVIMOT® MM..D – Functional Safety, Installation Close to Motor, Example
1Rights to claim under limited warranty
General Information
MOVIMOT® MM.. D– Functional Safety , Installation Close to Mo tor, Example
1 General Information
1.1 Rights to claim under limited warranty
A requirement of fault-free operation and fulfillment of any rights to claim under limited
warranty is that you adhere to the information in the documentation. Read the documen-
tation before you start working with the unit!
1.2 Exclusion of liability
You must comply with the information contained in this documentation to ensure safe
operation of and to achieve the specified product characteristics and performance
features. SEW-EURODRIVE assumes no liability for injury to persons or damage to
equipment or property resulting from non-observance of these operating instructions. In
such cases, any liability for defects is excluded.
1.3 Applicable documentation
This publication supplements the "MOVIMOT®MM..D with AC Motors DRS/DRE/DRP"
operating instructions and limits the application notes according to the following informa-
tion.
It can only be used in conjunction with the following publication:
•"MOVIMOT
®MM..D – Functional Safety" manual
1.4 Functional description
The drive systems described in this publication are characterized by the following
features:
• AMA6 plug connector (line connector/communication)
• AVR1 plug connector (binary input connection)
• AX jumper plug

Addendum to Manual – MOVIMOT® MM..D – Functional Safety, Installation Close to Motor, Example 5
2
MOVIMOT®with binary control (inverter mounted on motor)
Connection Variants
2 Connection Variants
2.1 MOVIMOT®with binary control (inverter mounted on motor)
2.1.1 General configuration
MOVIMOT®with binary control (control via terminals):
2.1.2 Permitted terminal assignment for direction of rotation signals (jumpers in terminal box)
Make sure that "24 V" and "⬜" are connected correctly and verify this with a test!
1490173451
[1]
[2]
[3]
[4]
Line connection
24 V supply of the safety relay (e.g. PNOZ..)
"24 V" safety contact
"⬜" safety contact
[1]
[2]
3 x 400 V
+ PE
+ 24 V
GND Safety Power
24V
TH TH K1a K1b RS- RS+
12345678910 11 12
13
21 22 23 24 25 26 27 28 29 30 31 32
21
2223 2425 26 2728 29 30 3132
f1/f2
LR
[3] [4]
Variant 1: "Clockwise rotation" Variant 2: "Counterclockwise rotation"
1490816907 1490175371
[1] Safety-relevant 24 V supply of the safety relay (e.g. PNOZ..)
[2] Safety contacts
[3] Jumper inside the terminal box (no switch)
[1]
X6: 4,5,6
X6: 1,2,3
X6: 9,10
24V
R X6: 11,12
L
MOVIMOT
®
[3]
[2]
[1]
X6: 4,5,6
X6: 1,2,3
X6: 9,10
24V
R X6: 11,12
L
MOVIMOT
®
[3]
[2]

6Addendum to Manual – MOVIMOT® MM..D – Functional Safety, Installation Close to Motor, Example
2MOVIMOT®with binary control (installation close to the motor)
Connection Variants
2.2 MOVIMOT®with binary control (installation close to the motor)
2.2.1 General configuration
MOVIMOT®with binary control (installation close to the motor):
[1] Line connection
[2] 24 V supply of the safety relay (e.g. PNOZ..)
[3] "24 V" safety contact
[4] "⬜" safety contact
[1]
[2]
3 x 400 V
+ PE
+ 24 V
GND Safety Power
24V
THTH K1a K1b RS- RS+
12345678910 11 12
13
21 22 23 24 25 26 27 28 29 30 31 32
21
2223 2425 26 2728 29 30 3132
f1/f2
LR
[3] [4]
DR..
MOVIMOT®

Addendum to Manual – MOVIMOT® MM..D – Functional Safety, Installation Close to Motor, Example 7
2
MOVIMOT®with binary control (installation close to the motor)
Connection Variants
2.2.2 Hybrid cable (motor cable) connection
The following figure shows the conductor assignment of the hybrid cable and the
associated terminals of the MOVIMOT®terminal box and the DR. motor:
4189022219
1a
BK/2
BK/1 1b
2b
BU
RD
WH
2a3a4a5a
BK/W1
U1V1W1
BK/V1
BK/U1
U1V1W1
W2U2V2
U1V1W1
W2U2V2
댴쑶
PE
MOVIMOT
DR..
®
1 2 3
24V
T
4 7 8
f1/f2
9
10
L
1)
11 12
R
21 22
HT1
23 24
HT2
25 26
K1a
27 28
K1b
29 30
RS-
31 32
RS+
X6 X5
5 6
U1
V1
W1
X2
X1
13 14 15 L1 L2 L3
BK/2
BK/1
BU
RD
WH
BK/W1
BK/V1
BK/U1
MOVIMOT®
Terminal
Hybrid cable
Core color/designation
DR motor
terminal
X2 U1 Black/U1 U1
V1 Black/V1 V1
W1 Black/W1 W1
X1 13 Red/13 4a
14 White/14 3a
15 Blue/15 5a
X6 24 V Black/1 1b
R or L1) Black/2 2b
PE connection Green/yellow
+ shield end (inner shield)
PE connection
1) Connect the TH cable to terminal "R" (=> CW operation) or "L" (=> CCW operation) depending on the required direction of rotation.
