Shadow-Caster SCM-SLF-WBR Instruction sheet

PRODUCT INSTRUCTIONSPRODUCT INSTRUCTIONS
Shadow-CasterShadow-Caster™™LED Lighting | 2060 Calumet Street | Clearwater, FL 33765LED Lighting | 2060 Calumet Street | Clearwater, FL 33765
p:p: +1 727.474.2877+1 727.474.2877 e:e: [e-mail]@shadow-caster.com w:w: shadow-caster.comshadow-caster.com
Designed & ManufacturedDesigned & Manufactured
in Clearwater, FLin Clearwater, FL
© 2022 Shadow-Caster© 2022 Shadow-Caster™LEDs. All Right Reserved.LEDs. All Right Reserved.
2022.11
SCM-SLF-WBRSCM-SLF-WBR
WHITE, BLUE AND RED FLUSH MOUNT SPREADER LIGHTWHITE, BLUE AND RED FLUSH MOUNT SPREADER LIGHT
MODEL #: SCM-SLF-WBR-WH
OPERATION
• When power is applied to the light, the brightness slowly ramps up to full
power over approximately 3 seconds
• Toggle power during ramp up to set brightness
• Subsequent power toggles will toggle from blue to red and back to white
• To reset the light, turn off for 10 seconds
INSTALLATION
• Cut hole according to template provided
• Connect power and ground
• Put a 1/8” size ball of silicone sealant in screw holes before mounting
• Screw in light
SPECIFICATIONS
• Power consumption: 2 amps at
12V and 1 amp at 24V
• Mounting depth: 1.5” [37mm]
• IP67 (waterproof)
• Durable glass window
CLEANING INSTRUCTIONS
• Clean with soap and water with a
soft towel or sponge
GROUND
10-30V
FUSE
ON/OFF SWITCH

PRODUCT INSTRUCTIONSPRODUCT INSTRUCTIONS
Shadow-CasterShadow-Caster™™LED Lighting | 2060 Calumet Street | Clearwater, FL 33765LED Lighting | 2060 Calumet Street | Clearwater, FL 33765
p:p: +1 727.474.2877+1 727.474.2877 e:e: [e-mail]@shadow-caster.com w:w: shadow-caster.comshadow-caster.com
Designed & ManufacturedDesigned & Manufactured
in Clearwater, FLin Clearwater, FL
© 2022 Shadow-Caster© 2022 Shadow-Caster™LEDs. All Right Reserved.LEDs. All Right Reserved.
2022.11
SCM-SLF-WBRSCM-SLF-WBR
WHITE, BLUE AND RED FLUSH MOUNT SPREADER LIGHTWHITE, BLUE AND RED FLUSH MOUNT SPREADER LIGHT
DRAWINGS ARE ACTUAL SIZE
1.75" [44.5mm]
WIDTH
5’’ [127mm]
TOP VIEW
LIGHT HOUSING CUTOUT
RIGHT VIEW
1.5" [38.1mm]
1.62" [41mm]
MOUNTING DEPTH
HEIGHT
MOUNTING TEMPLATE PLEASE PRINT AT
A 1:1 SCALE FOR ACCURACY
4.45'' [113mm]
2X MOUNTING SCREW HOLES
2X MOUNTING SCREW
HOLES USE
7/64'' [2.8mm] DRILL BIT
2.75'' [69.9mm]
4'' [101.6mm]
USE 1.375'' [1.5mm]
HOLE SAW
