Shakti Technology VC-90 User manual

User
MANUAL
VACUUM
CLEANER VC-90
Wet / Dry / Blow

02
*Read Manual Carefully Before Using
Vacuum Cleaner
Thank You For Choosing
Shakti Technology
VC-90 Vacuum Cleaner
Please Read The Owner's Manual
And Safety Instructions Carefully
Before Operating The Electric
Pressure Washer. Save This
Manual For Future Reference.
If You Have Any Problems And
Questions, Please Contact Us.

Product Description
Technical Specification
Know Your Product
What’s in the Box
Assembly Instructions
Operating Instructions
Maintenance
Troubleshooting
TABLE OF
CONTENT
03
04
05
08
09
11
13
07
06
Contact Us 14
Vacuum Cleaner

04
PRODUCT
DESCRIPTION
This 10 Litre wet & dry vacuum cleaner is intended for residential
use to clean vehicles, tiles, wooden floors, rugs, carpets, sofas,
fabric upholstery and more.
The blower function helps to clean in crevices, cracks, corners &
other places that are hard to reach. Strong & Sturdy Wheels with
360 Degree Rotation Capability Enables To Move the Vacuum Easily
Wet and dry multifunctional with long lasting durable body.
Now with the power of your Vacuum clean spilled liquid or wet
or dry debris in a jiffy
This unit can be placed vertically. Do not step on when placed vertically.
Vacuum Cleaner

05
TECHNICAL
SPECIFICATION
VC-90
Vacuum Cleaner
1000 Watts
Suction Capacity
Tank Capacity
Rated Voltage
Power
17 KPA
10 Liter
220-240V

06
KNOW YOUR
PRODUCT
Note: For the Hoses and Accessories please check inside the 10 Liter vacuum Tank.
Vacuum Cleaner
3 EXTENSION PIPES
MULTIPURPOSE
CLEANING BRUSH
CREVICE NOZZLE
WET & DR
SQUEEZING BRUSH
6 METER CABLE
HOSE PIPE
Handle bar
Tube
Hose
Floor brush Suction base
Switch
Lift handle
Blowing Port
Suction Port

07
WHAT’S
IN THE BOX
The equipment and packaging material are not toys. Do not let children play
with plastic bags, foils, or small parts. These items can be swallowed & pose a
suffocation risk!
10 L Vacuum Cleaner
Hose Pipe
3 Extension Pipes
Wet & Dry Squeezing Brush
Crevice Tool
Multi-Purpose Cleaning Brush
User's manual
Vacuum Cleaner
IMPORTANT!

08
ASSEMBLY
INSTRUCTIONS
NOTE : A Philips head screwdriver is required.
1. Release the lock button 2. Lift the top cover 3. Remove the contents from inside
the collection tank; make sure you
have all contents as listed on
4. Turn the collecon tank
upside down and insert the
four casters into the slots on
the collecon tank. Apply
downward pressure unl the
casters snap into place
5. Insert the handle into the
slots located on the top of
the power head and secure
it with the screws provided.
Do not over ghten the screws.
WARNING
Electrical Shock Hazard.
DO NOT plug into electrical supply unti assembly is complete. Failure to do so
could result in electrical shock or injury. To reduce the risk of electric shock, do
not expose to rain.
Vacuum Cleaner
6. Place the top cover
back on the collecon tank
and secure it in place using
lock buon.

09
Connect the flexible tube,
extension tube & accessories
correctly
Wet Cleaning Operations
For the dry cleaning, Remove the
Cloth dust filter and use the
vacuum without cloth
duster filter
Dust Bag
Dry Cleaning Operations
For the dry cleaning,
install the Cloth dust filter
Vacuum Cleaner
To use the blow function,
just need to plug the hose
into blowing port.
The direction of the switch should accord with
the direction of the suction inlet.
Blowing Operation
Connect the flexible tube, extension
tube & accessories correctly
OPERATING INSTRUCTIONS
Install
Remove
Suction Port
Blowing
Port

10
“1” Shows “ON”“0” Shows “OFF”
Adjust the air power control knob on handle
to adjust the suction
Soft
Powerful
Vacuum Cleaner
OPERATING INSTRUCTIONS
Switch on the vacuum cleaner

11
1) Disconnect the power cord
2) Remove the hose pipe
3) Lift the top cover
4) Remove the Filter
5) Clear all dirt or debris from the collection
tank and hose into a proper waste container.
WARNING
Always disconnect the plug from the outlet before removing
the power head from the collection tank.
Dust Bag
Vacuum Cleaner
Maintenance
Emptying the collection tank

12
1) If the dust bag gets blocked, clean it with water.
2) Remove the dust bag. Clean it. Dry it.
Maintenance
1) Clean the accessories and the vacuum with soft
wet cloth or neutrality cleanser.
2) Do not clean the body of vacuum cleaner with petrol
or oil-like liquid. Please wipe it with water or neutral
detergent. When you wipe the appliance, please dry
with soft cloth.
Note : Do not use boiled water to clean it or dry near fire.
Dust Bag
Vacuum Cleaner
Clean the Filter
Clean the vacuum cleaner and the accessories

13
Vacuum Cleaner
Trouble Shooting Guide

+91 90997 08177
+91 95582 85760
Shakti Technolgy
Rajkot, Gujarat (India).
www.shaktitool.com
!
CONTACT US
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
Do not dispose this product by normal household waste, but take it
to a collection point and recycling of electrical and electronic
equipment. This is indicated by the symbol on the product, user
manual or packaging. Re-use, material utilization or other forms of
old appliances, you make an important contribution in protecting
our environment.
