Sharkoon REBEL C70M User manual

REBEL C70M
ATX PC Case
Manual

Specifications
General:
Form Factor: ATX
Expansion Slots: 7
Interior Painting: 
Graphics Card Holder: 
Cable Management System: 
Side Panel: Metal
Color Versions: Black
Dimensions (L x W x H): 47.9 x 23.0 x 49.5 cm
RGB Compatibility:
Type: Addressable
Ports: 8
Manual Control: 22 Modes
Mainboard Compatibility: MSI Mystic Light Sync,
ASUS Aura Sync,
Gigabyte RGB Fusion Ready,
ASRock Polychrome Sync
RGB Pinout: 5V-D-coded-G
Max. Drive Bays:
3.5" 3
2.5" 3
I/O:
Type-C (USB 3.2 Gen 2): 1
USB 3.0 (Top): 2
Audio (Top): (TRRS)
Compatibility:
Mainboard: Mini-ITX, Micro-ATX, ATX
Max. Length Graphics Card: 40.0 cm
Max. Height CPU Cooler: 16.5 cm
Max. Length PSU: 27.0 cm
Max. Height Radiator incl. Fan (Top): 6.0 cm
Package Contents:
Rebel C70M RGB, Accessory Set
*1x 120 mm fan has same installation space for 1x HDD
Fan Configuration:
Front Panel: 3x 120 mm Addressable RGB LED PWM Fan (Pre-installed)
or 3x 140 mm Fan (Optional)
Rear Panel: 1x 120 mm Addressable RGB LED PWM Fan (Pre-installed)
Top Panel: 3x 120 mm or 2x 140 mm Fan or Radiator (Optional)
Side Panel: 4x 120 mm Fan* or Radiator (Optional)
01

Side Panel Assembly
02

Install 2.5” HDDs/SSDs
03

Install 3.5” HDDs
04

Install PSU
05

Detachable Dust Filter
06

Detachable Dust Filter
Or
07

Adjustable Graphics Card Holder
08

Install Fans
140 mm
Fans
120 mm
Fans
09

Install Fans
10

Install Fans
11

Install Radiator under Top Panel
Radiator
120 mm
140 mm
240 mm
280 mm
360 mm
12

Install Radiator on Side Panel
Radiator
Radiator
120 mm
240 mm
360 mm
13

4044951 038381 4044951 039975
Vertical Graphics Card Kit 4.0 Black
REBEL C Series
Vertical Graphics Card Kit 4.0 White
REBEL C Series
Optional Vertical Graphics Card Kit
Please check with your local dealer to purchase this kit,
if needed.
14

SATA
    
+5V D
ADD_HEADER

RESET SW
Control Addressable RGB
through Mainboard
Addressable RGB LED
Fans / Strips
Mainboard
Addressable RGB Pin Header
15

SATA
    

RESET SW
RESET SW
Manually Control
Addressable RGB
Addressable RGB LED
Fans / Strips
Press reset switch for 2 seconds to turn o the LED lights.
When the LED lights are o, press reset switch to turn on the LED lights.
Red WhiteGreen YellowBlue Cyan Pink
RGB
Mode 13
RGB
Mode 6
RGB
Mode 5
RGB
Mode 4
RGB
Mode 3
Warm
White
Natural
White
RGB
Mode 7
RGB
Mode 10
RGB
Mode 9
RGB
Mode 8
RGB
Mode 11
RGB
Mode 12
Press reset switch
to select dierent modes RGB
Mode 2
RGB
Mode 1
16

Legal Disclaimer
For potential loss of data, especially due to inappropriate handling, Sharkoon
assumes no liability.
All named products and descriptions are trademarks and/or registered
trademarks of the respective manufacturers and are accepted as protected.
As a continuing policy of product improvement at Sharkoon, the design and
specifications are subject to change without prior notice. National product
specifications may vary.
All rights reserved especially (also in extracts) for translation, reprinting,
reproduction by copying or other technical means. Infringements will lead to
compensation. All rights reserved especially in case of assignation of patent
or utility patent. Means of delivery and technical modifications reserved.
Disposal of your old products
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product,
it means the product is covered by the European Directive 2012/19/EU.
Please be informed about the local separate collection system for electrical
and electronic products. Please act according to your local rules and do not
dispose of your old products with your normal household waste. The correct
disposal of your old product will help prevent potential negative consequences
to the environment and human health.
Note
17
