Sharp 29C-FX10T User manual

31
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
areidentifiedbyåandshadedareasintheReplacementPartsLists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★MARK : SPARE PARTS-DELIVERYSECTION
' MARK : X- RAY RELATED PARTS
Ref. No. Part No. ★Description Code
PICTURE TUBE
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A: DUNTKA254FMV0
MAIN UNIT
TUNER
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
åTU51 VTUVTBT5UF202 J Tuner BD
INTEGRATED CIRCUITS
åIC351 VHiAN5277//-1 J AN5277 AN
IC401 RH-iX3113CEZZ J TA1276AN AZ
IC502 VHiTA1241AN-1 J TA1241AN AM
åIC740 VHiKA7809AP-1 J KIA7809API AE
åIC741 VHiKA7805AP-1 J KIA7805API AE
IC753 VHiKA7805AP-1 J KIA7805API AE
IC1101 VHiM52055FP-1 J M52055FP AH
IC1102 VHiMM1111XF1E J MM1111XFBE AE
IC1301 VHiMM1313AD-1 J MM1313AD AP
IC1401 VHiTC90A53P-1 J TC90A53N-P AV
IC1402 VHiKA78L05B-1 J KIA78L05BP AE
IC1403 VHiMM1112XF1E J MM1112XFBE AF
'åIC2001 RH-iX3343CEZZ J I.C. BB
IC2002 VHiM24C16B/-1 J M24C16-BN6 AG
or
VHiBR24C16/-1
IC2003 VHiKiA7045P-1 J KIA7045P AD
or
VHiKiA7045A-1
or
VHiPST994C/-1
IC2004 VHiKA7805AP-1 J KIA7805API AE
IC2007 VHiMM1112XF1E J MM1112XFBE AF
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
IC3201 VHiAN5285K/-1 J AN5285K AP
IC3301 VHiM62494SP-1 J M62494SP AN
IC4001 RH-iX3232CEZZ J SSE96G AV
IC4002 VHiBA15218F-1 J BA15218F AD
TRANSISTORS
Q51 VS2SB709AR/-1 J 2SB709AR AC
Q52 VS2SB709AR/-1 J 2SB709AR AC
Q53 VS2SD601AR/-1 J 2SD601AR AC
Q403 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q404 VS2SK30AG//2E J 2SK30AG AD
Q405 VS2SD601AR/-1 J 2SD601AR AC
Q406 VS2SD601AR/-1 J 2SD601AR AC
Q408 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q409 VS2SD601AR/-1 J 2SD601AR AC
Q410 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q901 VS2SD601AR/-1 J 2SD601AR AC
Q902 VS2SD601AR/-1 J 2SD601AR AC
Q903 VS2SD601AR/-1 J 2SD601AR AC
Q904 VS2SD601AR/-1 J 2SD601AR AC
Q905 VS2SD601AR/-1 J 2SD601AR AC
Q906 VS2SD601AR/-1 J 2SD601AR AC
Q1301 VS2SD601AR/-1 J 2SD601AR AC
Q1302 VS2SD601AR/-1 J 2SD601AR AC
Q1303 VS2SD601AR/-1 J 2SD601AR AC
Q1401 VS2SD601AR/-1 J 2SD601AR AC
Q1402 VS2SD601AR/-1 J 2SD601AR AC
Q1403 VS2SD601AR/-1 J 2SD601AR AC
Q1404 VS2SD601AR/-1 J 2SD601AR AC
Q1405 VS2SD601AR/-1 J 2SD601AR AC
Q1406 VS2SD601AR/-1 J 2SD601AR AC
Q1436 VS2SD601AR/-1 J 2SD601AR AC
Q1450 VS2SD601AR/-1 J 2SD601AR AC
Q2003 VS2SD601AR/-1 J 2SD601AR AC
Q2004 VSUN2212///-1 J UN2212 AA
Q2005 VS2SD601AR/-1 J 2SD601AR AC
åQ2008 VS2SD601AR/-1 J 2SD601AR AC
Q2009 VS2SD601AR/-1 J 2SD601AR AC
Q2012 VS2SD601AR/-1 J 2SD601AR AC
Q4001 VS2SD601AR/-1 J 2SD601AR AC
'å VB68QCP892X2E J Picture Tube (with D.Y) CX
åL702 RCiLG0056PEZZ R Degaussing Coil AS
PMAGF3087CEZZ J Magnet AL
PMAGG3002CEZZ J Magnet AC
åQEARC2913PEZZ R Grounding Strap AK
PWB-A DUNTKA254FMV0 – MAIN Unit —
PWB-B DUNTKA119FMV0 – CRT Unit —
PWB-CDUNTKA255FMV0 – POWER Unit —
PWB-F DUNTKA256WEV0 – FRONTAV Unit —

32
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-A: DUNTKA254FMV0
MAIN UNIT (Continued)
Q4002 VS2SD601AR/-1 J 2SD601AR AC
Q4003 VS2SD601AR/-1 J 2SD601AR AC
Q4004 VS2SD601AR/-1 J 2SD601AR AC
Q4071 VS2SD601AR/-1 J 2SD601AR AC
Q4072 VS2SD601AR/-1 J 2SD601AR AC
DIODES
D405 RH-EX0628GEZZ J Zener Diode, 8.2V AC
D406 VHD1SS119//-1 J Diode AB
D411 VHD1SS119//-1 J Diode AB
D412 RH-EX0618GEZZ J Zener Diode, 6.2V AA
D413 RH-EX0618GEZZ J Zener Diode, 6.2V AA
D414 RH-EX0618GEZZ J Zener Diode, 6.2V AA
D502 RH-EX0604GEZZ J Zener Diode, 3.9V AB
D508 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D509 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D514 VHD1SS119//-1 J Diode AB
D617 RH-EX0631GEZZ J Zener Diode, 9V AA
D619 VHD1SS119//-1 J Diode AB
D620 RH-EX0604GEZZ J Zener Diode, 3.9V AB
D621 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D622 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D721 VHD1SS119//-1 J Diode AB
D745 RH-DX0441CEZZ J Diode AC
D1101 RH-EX0631GEZZ J Zener Diode, 9V AA
D1102 RH-EX0631GEZZ J Zener Diode, 9V AA
D1103 RH-EX0631GEZZ J Zener Diode, 9V AA
D1104 RH-EX0631GEZZ J Zener Diode, 9V AA
D1301 RH-EX0631GEZZ J Zener Diode, 9V AA
D1302 RH-EX0631GEZZ J Zener Diode, 9V AA
D1303 RH-EX0631GEZZ J Zener Diode, 9V AA
D1304 RH-EX0631GEZZ J Zener Diode, 9V AA
D1308 RH-EX0631GEZZ J Zener Diode, 9V AA
D1310 RH-EX0631GEZZ J Zener Diode, 9V AA
D1311 RH-EX0631GEZZ J Zener Diode, 9V AA
D1401 VHD1SS119//-1 J Diode AB
D1402 VHD1SS119//-1 J Diode AB
D1403 VHD1SS119//-1 J Diode AB
D2004 VHD1SS119//-1 J Diode AB
D2005 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2006 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2007 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2008 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2010 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2014 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2027 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2028 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2031 RH-DX0441CEZZ J Diode AC
D2032 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D2033 RH-EX0616GEZZ J Zener Diode, 6.2V AA
D4001 VHD1SS119//-1 J Diode AB
D4102 VHD1SS119//-1 J Diode AB
PACKAGED CIRCUIT
X801 RCRSB0001PEZZ R Crystal AL
FILTERS AND COILS
CF501 RFiLA0034CEZZ J Ceramic Filter AD
CF2001 RFiLC0121GEZZ J Ceramic Filter AD
L401 VP-XF4R7K0000 J Peaking 4.7µH AB
L404 VP-XF4R7K0000 J Peaking 4.7µH AB
L405 VP-XF4R7K0000 J Peaking 4.7µH AB
L501 VP-XF101K0000 J Peaking 100µH AB
L1401 VP-XF100K0000 J Peaking 10µH AB
L1402 VP-XF100K0000 J Peaking 10µH AB
L1403 VP-XF270K0000 J Peaking 27µH AB
L1404 VP-XF330K0000 J Peaking 33µH AB
L1406 VP-XF100K0000 J Peaking 10µH AB
L1407 VP-XF1R0K0000 J Peaking 1µH AB
L1408 VP-XFR27K0000 J Peaking 0.27µH AB
L1409 VP-XF100K0000 J Peaking 10µH AB
L1412 VP-XF1R0K0000 J Peaking 1µH AB
L1413 VP-XF330K0000 J Peaking 33µH AB
L2001 VP-XF100K0000 J Peaking 10µH AB
L2002 VP-MK100K0000 J Peaking 10µH AB
T2001 RCiLB0158CEZZ J Oscillation Coil AD
CAPACITORS
[EL.··· Electrolytic]
C51 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C52 VCEA0A0JW108M J 1000 6.3V EL. AC
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCQYTA1HM104K J 0.1 50V Mylar AC
C55 VCQYTA1HM473J J 0.047 50V Mylar AA
C56 VCEA0A1HW105M J 1.0 50V EL. AB
C57 VCQYTA1HM472J J 4700p 50V Mylar AB
C351 VCEA0A1HW225M J 2.2 50V EL. AB
C353 VCEA0A1HW225M J 2.2 50V EL. AB
C355 VCQYTA1HM123K J 0.012 50V Mylar AA
C356 VCEA0A1HW105M J 1.0 50V EL. AB
C357 VCEA0A1EW107M J 100 25V EL. AC
C358 VCEA0A1HW105M J 1.0 50V EL. AB
C359 VCEA0A1EW108M J 1000 25V EL. AD
C360 VCEA0A1CW106M J 10 16V EL. AB
C361 VCEA0A1VW108M J 1000 35V EL. AD
C362 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C363 VCEA0A1HW225M J 2.2 50V EL. AB
C364 VCEA0A1EW108M J 1000 25V EL. AD
C366 VCQYTA1HM123K J 0.012 50V Mylar AA
C401 VCEA0A1CW337M J 330 16V EL. AC
C402 VCEA0A1VW226M J 22 35V EL. AB
C403 VCKYCY1EB103K J 0.01 25V Ceramic AA
C404 VCEA0A1HW105M J 1.0 50V EL. AB
C405 VCEA0A1HW225M J 2.2 50V EL. AB
C406 VCKYCY1EB103K J 0.01 25V Ceramic AA
C407 VCEA0A1CW337M J 330 16V EL. AC
C408 VCEA0A1HW474M J 0.47 50V EL. AB
C409 VCFYFA1HA334J J 0.33 50V Mylar AB
C410 VCEA0A1HW105M J 1.0 50V EL. AB
C411 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C412 VCCCCY1HH270J J 27p 50V Ceramic AA
C417 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C418 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C420 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C424 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C425 VCKYCY1HB471K J 470p 50V Ceramic AA
C426 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C427 VCFYFA1HA104J J 0.1 50V Mylar AA
C430 VCEA0A1EW476M J 47 25V EL. AB
C431 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C440 VCKYCY1EB103K J 0.01 25V Ceramic AA
C447 VCEA0A1CW337M J 330 16V EL. AC
C503 VCEA0A1CW477M J 470 16V EL. AC
C505 VCFYFA1HA223J J 0.022 50V Mylar AB
C506 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C507 VCEAGA1HW334T J 0.33 50V EL. AC
C508 VCFYHA1HA104J J 0.1 50V Mylar AB
C509 VCEACA1HC225J J 2.2 50V EL. AC
C538 VCCSPA1HL101J J 100p 50V Ceramic AA
C601 VCQYTA1HM103J J 0.01 50V Mylar AB
C613 VCKYCY1EB103K J 0.01 25V Ceramic AA
C616 VCEA0A1HW225M J 2.2 50V EL. AB
C617 VCEA0A1HW225M J 2.2 50V EL. AB
C618 VCFYFA1HA223J J 0.022 50V Mylar AB
C619 VCEA0A1CW337M J 330 16V EL. AC
C620 VCKYCY1HB271K J 270p 50V Ceramic AA
C621 VCKYCY1HB152K J 1500p 50V Ceramic AA
C743 VCEA0A1EW476M J 47 25V EL. AB
C744 VCEA0A1CW227M J 220 16V EL. AC
C745 VCEA0A1CW108M J 1000 16V EL. AD
C746 VCEA0A1HW106M J 10 50V EL. AB
C782 VCEA0A1HW106M J 10 50V EL. AB
C783 VCEA0A1EW476M J 47 25V EL. AB
C803 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C805 VCKYCY1HB103K J 0.01 50V Ceramic AA
C806 VCKYCY1CB104K J 0.1 16V Ceramic AB

33
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-A: DUNTKA254FMV0
MAIN UNIT (Continued)
C807 VCEA0A1HW225M J 2.2 50V EL. AB
C812 VCEAGA1HW224T J 0.22 50V EL. AB
C813 VCQYTA1HM222J J 2200p 50V Mylar AA
C814 VCCCCY1HH110J J 11p 50V Ceramic AA
C817 VCCCCY1HH1R0C J 1.0p 50V Ceramic AA
C818 VCKYCY1CB104K J 0.1 16V Ceramic AB
C819 VCKYCY1CB104K J 0.1 16V Ceramic AB
C843 VCKYCY1EB103K J 0.01 25V Ceramic AA
C844 VCKYCY1EB103K J 0.01 25V Ceramic AA
C845 VCKYCY1EB103K J 0.01 25V Ceramic AA
C901 VCEA0A1HW475M J 4.7 50V EL. AB
C903 VCEA0A1HW475M J 4.7 50V EL. AB
C905 VCEA0A1EW476M J 47 25V EL. AB
C956 VCEA0A1CW337M J 330 16V EL. AC
C1101 VCEA0A1HW106M J 10 50V EL. AB
C1102 VCEA0A1EW476M J 47 25V EL. AB
C1103 VCEA0A1HW106M J 10 50V EL. AB
C1104 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1105 VCEA0A1EW476M J 47 25V EL. AB
C1106 VCEA0A1HW106M J 10 50V EL. AB
C1107 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C1108 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1109 VCEA0A1HW105M J 1.0 50V EL. AB
C1110 VCKYCY1HB271K J 270p 50V Ceramic AA
C1111 VCKYCY1HB271K J 270p 50V Ceramic AA
C1112 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C1113 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1114 VCEA0A1HW105M J 1.0 50V EL. AB
C1301 VCQYTA1HM104K J 0.1 50V Mylar AC
C1302 VCEA0A1HW105M J 1.0 50V EL. AB
C1303 VCEA0A1HW105M J 1.0 50V EL. AB
C1304 VCQYTA1HM104K J 0.1 50V Mylar AC
C1305 VCEA0A1HW105M J 1.0 50V EL. AB
C1306 VCEA0A1HW105M J 1.0 50V EL. AB
C1307 VCQYTA1HM183J J 0.018 50V Mylar AB
C1308 VCEA0A1HW225M J 2.2 50V EL. AB
C1309 VCEA0A1HW225M J 2.2 50V EL. AB
C1310 VCQYTA1HM104K J 0.1 50V Mylar AC
C1311 VCQYTA1HM183J J 0.018 50V Mylar AB
C1312 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1313 VCKYCY1HB271K J 270p 50V Ceramic AA
C1314 VCKYCY1HB271K J 270p 50V Ceramic AA
C1315 VCKYCY1HB271K J 270p 50V Ceramic AA
C1316 VCKYCY1HB271K J 270p 50V Ceramic AA
C1317 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1318 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1319 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C1320 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C1322 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1323 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1324 VCQYTA1HM104K J 0.1 50V Mylar AC
C1325 VCEA0A1VW226M J 22 35V EL. AB
C1326 VCEA0A1CW107M J 100 16V EL. AC
C1327 VCKYCY1HB271K J 270p 50V Ceramic AA
C1328 VCKYCY1HB271K J 270p 50V Ceramic AA
C1329 VCEA0A1HW105M J 1.0 50V EL. AB
C1330 VCEA0A1HW105M J 1.0 50V EL. AB
C1332 VCQYTA1HM104K J 0.1 50V Mylar AC
C1333 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB
C1334 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB
C1341 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1412 VCEA0A1HW106M J 10 50V EL. AB
C1413 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1415 VCCCCY1HH220J J 22p 50V Ceramic AA
C1416 VCEA0A1CW107M J 100 16V EL. AC
C1417 VCCCCY1HH120J J 12p 50V Ceramic AA
C1418 VCCCCY1HH120J J 12p 50V Ceramic AA
C1420 VCCCCY1HH120J J 12p 50V Ceramic AA
C1421 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1422 VCEA0A1EW476M J 47 25V EL. AB
C1430 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1432 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1433 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1435 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1436 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1437 VCCSPA1HL102J J 1000p 50V Ceramic AA
C1438 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C1439 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C1440 VCEA0A1HW106M J 10 50V EL. AB
C1441 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1442 VCFYFA1HA474J J 0.47 50V Mylar AC
C1443 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1444 VCKYCY1HB472K J 4700p 50V Ceramic AA
C1445 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1446 VCCCCY1HH181J J 180p 50V Ceramic AA
C1447 VCKYCY1EB103K J 0.01 25V Ceramic AA
C1448 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1449 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1450 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1451 VCEA0A1AW107M J 100 10V EL. AB
C1452 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1453 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1454 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1455 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1456 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1457 VCEA0A1HW106M J 10 50V EL. AB
C1458 VCEA0A1HW106M J 10 50V EL. AB
C1459 VCCCPA1HH100J J 10p 50V Ceramic AA
C1460 VCCCPA1HH121J J 120p 50V Ceramic AA
C1469 VCCCCY1HH120J J 12p 50V Ceramic AA
C1470 VCCCCY1HH100D J 10p 50V Ceramic AA
C1473 VCCCCY1HH100D J 10p 50V Ceramic AA
C1720 VCEA0A1HW106M J 10 50V EL. AB
C1723 VCEA0A1HW106M J 10 50V EL. AB
C1724 VCFYFA1HA104J J 0.1 50V Mylar AA
C1725 VCFYFA1HA104J J 0.1 50V Mylar AA
C1726 VCFYFA1HA104J J 0.1 50V Mylar AA
C1727 VCEA0A1HW106M J 10 50V EL. AB
C2005 VCEA0A1HW225M J 2.2 50V EL. AB
C2006 VCEA0A1HW105M J 1.0 50V EL. AB
C2007 VCKYCY1HB561K J 560p 50V Ceramic AA
C2008 VCQYTA1HM104J J 0.1 50V Mylar AA
C2009 VCKYCY1HB102K J 1000p 50V Ceramic AA
C2010 VCKYCY1HB221K J 220p 50V Ceramic AA
C2011 VCEA0A1HW105M J 1.0 50V EL. AB
C2012 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2013 VCKYCY1CB104K J 0.1 16V Ceramic AB
C2014 VCKYCY1HB102K J 1000p 50V Ceramic AA
C2015 VCCCCY1HH101J J 100p 50V Ceramic AA
C2016 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2017 VCCCCY1HH101J J 100p 50V Ceramic AA
C2018 VCCCCY1HH101J J 100p 50V Ceramic AA
C2019 VCKYCY1HB102K J 1000p 50V Ceramic AA
C2020 VCKYCY1HB102K J 1000p 50V Ceramic AA
C2021 VCKYCY1HF103Z J 0.01 50V Ceramic AA
åC2022 VCEA0A1HW106M J 10 50V EL. AB
C2023 VCEA0A1AW107M J 100 10V EL. AB
C2024 VCEA0A1HW106M J 10 50V EL. AB
C2025 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2026 VCEA0A0JW477M J 470 6.3V EL. AC
C2027 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2028 VCEA0A1AW107M J 100 10V EL. AB
C2029 VCFYFA1HA474J J 0.47 50V Mylar AC
C2030 VCEA0A1HW106M J 10 50V EL. AB
C2031 VCEA0A1AW228M J 2200 10V EL. AD
C2032 VCCCCY1HH270J J 27p 50V Ceramic AA
C2034 VCCCCY1HH390J J 39p 50V Ceramic AA
C2040 VCKYCY1CB104K J 0.1 16V Ceramic AB
C2042 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3001 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3003 VCQYTA1HM123K J 0.012 50V Mylar AA
C3004 VCEA0A1HW105M J 1.0 50V EL. AB
C3005 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3006 VCEA0A1HW106M J 10 50V EL. AB
C3007 VCEA0A1HW475M J 4.7 50V EL. AB

34
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-A: DUNTKA254FMV0
MAIN UNIT (Continued)
C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3009 VCEA0A1CW227M J 220 16V EL. AC
C3010 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3011 VCEA0A1HW475M J 4.7 50V EL. AB
C3012 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
C3014 VCQYTA1HM473K J 0.047 50V Mylar AB
C3015 VCSATA1CE335K J 3.3 16V Tantalum AC
C3016 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3017 VCSATA1CE106K J 10 16V Tantalum AD
C3018 VCEA0A1HW105M J 1.0 50V EL. AB
C3019 VCEA0A1HW225M J 2.2 50V EL. AB
C3020 VCEA0A1HW225M J 2.2 50V EL. AB
C3029 VCKYCY1HB682K J 6800p 50V Ceramic AA
C3030 VCKYCY1HB682K J 6800p 50V Ceramic AA
C3031 VCKYCY1CB473K J 0.047 16V Ceramic AA
C3032 VCKYCY1CB473K J 0.047 16V Ceramic AA
C3201 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3202 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3203 VCEA0A1HW475M J 4.7 50V EL. AB
C3204 VCEA0A1HW106M J 10 50V EL. AB
C3205 VCEA0A1HW106M J 10 50V EL. AB
C3206 VCKYCY1HB103K J 0.01 50V Ceramic AA
C3207 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3208 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3209 VCEA0A1HW106M J 10 50V EL. AB
C3301 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3302 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
C3303 VCKYCY1HB183K J 0.018 50V Ceramic AB
C3304 VCKYCY1HB471K J 470p 50V Ceramic AA
C3305 VCQYTA1HM103J J 0.01 50V Mylar AB
C3306 VCFYFA1HA824J J 0.82 50V Mylar AD
C3307 VCKYCY1HB471K J 470p 50V Ceramic AA
C3308 VCEA0A1CW107M J 100 16V EL. AC
C3309 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3310 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3311 VCQYTA1HM103J J 0.01 50V Mylar AB
C3312 VCFYFA1HA224J J 0.22 50V Mylar AB
C3313 VCQYTA1HM472J J 4700p 50V Mylar AB
C3314 VCFYFA1HA104J J 0.1 50V Mylar AA
C3315 VCQYTA1HM103J J 0.01 50V Mylar AB
C3316 VCEA0A1HW106M J 10 50V EL. AB
C4003 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C4004 VCEA0A1CW337M J 330 16V EL. AC
C4005 VCCCCY1HH101J J 100p 50V Ceramic AA
C4006 VCCCCY1HH101J J 100p 50V Ceramic AA
C4007 VCEA0A1CW337M J 330 16V EL. AC
C4020 VCEA0A1EW476M J 47 25V EL. AB
C4071 VCEA0A1CW107M J 100 16V EL. AC
C4072 VCKYCY1HB152K J 1500p 50V Ceramic AA
C4073 VCKYCY1HB152K J 1500p 50V Ceramic AA
C4074 VCKYCY1CF474Z J 0.47 16V Ceramic AB
C4075 VCKYCY1CF474Z J 0.47 16V Ceramic AB
RESISTORS
[M-Ox.··· Metal Oxide]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ4 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R51 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R52 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R53 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R54 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA
R55 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R56 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R57 VRS-CY1JF151J J 150 1/16W M-Ox. AA
R58 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R59 VRS-CY1JF684J J 680k 1/16W M-Ox. AA
R60 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R61 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R62 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R353 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R354 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R357 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R359 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R360 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R401 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R402 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R403 VRD-RA2EE680J J 68 1/4W Carbon AA
R405 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R406 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R407 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R410 VRS-CY1JF820J J 82 1/16W M-Ox. AA
R411 VRS-CY1JF820J J 82 1/16W M-Ox. AA
R412 VRS-CY1JF820J J 82 1/16W M-Ox. AA
R413 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R414 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R415 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R416 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R418 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R419 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R425 VRS-CY1JF474J J 470k 1/16W M-Ox. AA
R428 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R432 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R434 VRS-CY1JF124J J 120k 1/16W M-Ox. AA
R435 VRS-CY1JF395J J 3.9M 1/16W M-Ox. AA
R436 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R437 VRS-CY1JF154J J 150k 1/16W M-Ox. AA
R438 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R439 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R440 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R441 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R444 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R445 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R447 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R448 VRS-CY1JF151J J 150 1/16W M-Ox. AA
R449 VRS-CY1JF100J J 10 1/16W M-Ox. AA
R455 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R456 VRD-RA2EE152J J 1.5k 1/4W Carbon AA
R461 VRD-RA2BE182J J 1.8k 1/8W Carbon AA
R462 VRS-CY1JF393J J 39k 1/16W M-Ox. AA
R463 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R464 VRS-CY1JF393J J 39k 1/16W M-Ox. AA
R502 VRD-RA2BE154J J 150k 1/8W Carbon AA
R503 VRD-RA2BE154J J 150k 1/8W Carbon AA
R504 VRD-RA2BE563J J 56k 1/8W Carbon AA
R505 VRD-RA2BE124J J 120k 1/8W Carbon AA
R506 VRD-RA2BE223J J 22k 1/8W Carbon AA
R507 VRD-RA2BE101J J 100 1/8W Carbon AB
R508 VRD-RA2BE101J J 100 1/8W Carbon AB
R509 VRD-RA2BE181J J 180 1/8W Carbon AA
R520 VRD-RA2BE181J J 180 1/8W Carbon AA
R521 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R523 VRD-RA2BE183J J 18k 1/8W Carbon AA
R525 VRD-RA2BE103J J 10k 1/8W Carbon AA
R527 VRD-RA2BE103J J 10k 1/8W Carbon AA
R540 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R541 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R589 VRD-RA2EE105J J 1.0M 1/4W Carbon AA
R603 VRD-RA2EE331J J 330 1/4W Carbon AA
R613 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R616 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R617 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R620 VRD-RA2BE153J J 15k 1/8W Carbon AA
R627 VRS-SV2HC680J J 68 1/2W M-Ox. AA
åR744 VRS-VV3DB330J J 33 2W M-Ox. AA
R803 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R805 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R806 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R807 VRD-RA2BE102J J 1.0k 1/8W Carbon AA

35
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-A: DUNTKA254FMV0
MAIN UNIT (Continued)
R814 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R817 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R820 VRD-RA2BE101J J 100 1/8W Carbon AB
R821 VRD-RA2BE101J J 100 1/8W Carbon AB
R822 VRD-RA2BE101J J 100 1/8W Carbon AB
R823 VRD-RA2BE101J J 100 1/8W Carbon AB
R827 VRD-RA2BE181J J 180 1/8W Carbon AA
R828 VRD-RA2BE181J J 180 1/8W Carbon AA
R829 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R830 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R903 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R904 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R905 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R906 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R907 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R908 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R910 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R911 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R912 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R913 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R914 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R915 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R920 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R921 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R922 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R963 VRD-RA2BE101J J 100 1/8W Carbon AB
R1101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1102 VRD-RA2BE101J J 100 1/8W Carbon AB
R1103 VRS-CY1JF681J J 680 1/16W M-Ox. AA
R1104 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1105 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1106 VRD-RA2BE101J J 100 1/8W Carbon AB
R1114 VRD-RA2BE471J J 470 1/8W Carbon AA
R1115 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R1116 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R1117 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1118 VRD-RA2BE101J J 100 1/8W Carbon AB
R1119 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1120 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1121 VRD-RA2BE101J J 100 1/8W Carbon AB
R1301 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R1302 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R1303 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1304 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1305 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1306 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1307 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R1309 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R1310 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1311 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1312 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1313 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1314 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1315 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1316 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R1317 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1318 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1319 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1320 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R1323 VRS-CY1JF181J J 180 1/16W M-Ox. AA
R1324 VRS-CY1JF181J J 180 1/16W M-Ox. AA
R1325 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R1326 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R1327 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1328 VRD-RA2BE101J J 100 1/8W Carbon AB
R1329 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1330 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1331 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1332 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1333 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1334 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1335 VRS-CY1JF100J J 10 1/16W M-Ox. AA
R1336 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1337 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1338 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1342 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R1350 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1352 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1402 VRS-CY1JF681J J 680 1/16W M-Ox. AA
R1403 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R1404 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1405 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R1406 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R1407 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1408 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R1409 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R1411 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1412 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R1413 VRS-CY1JF561J J 560 1/16W M-Ox. AA
R1414 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1415 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R1416 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R1417 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1418 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R1420 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1443 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R1446 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1447 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R1448 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1450 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R1452 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R1453 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1456 VRS-CY1JF564J J 560k 1/16W M-Ox. AA
R1457 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1458 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1459 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R1460 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1462 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1466 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1467 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R1471 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1473 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1474 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1475 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1494 VRD-RA2BE182J J 1.8k 1/8W Carbon AA
R2001 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2002 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2003 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2004 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2005 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2006 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2007 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
'åR2008 VRD-RA2BE273J J 27k 1/8W Carbon AA
R2009 VRD-RA2BE223J J 22k 1/8W Carbon AA
R2010 VRD-RA2BE103J J 10k 1/8W Carbon AA
'åR2011 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R2012 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2013 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2014 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2015 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2016 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R2017 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2018 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2019 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2020 VRD-RA2EE821J J 820 1/4W Carbon AA
R2021 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2022 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2024 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2025 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2026 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2027 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2028 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2030 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2031 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2033 VRD-RA2BE471J J 470 1/8W Carbon AA
R2034 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA

36
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-A: DUNTKA254FMV0
MAIN UNIT (Continued)
R2035 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2036 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2037 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2038 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2039 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2040 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2043 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2045 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2046 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2048 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2049 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2050 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2051 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2052 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2053 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R2056 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2057 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2058 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2059 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R2060 VRS-CY1JF184J J 180k 1/16W M-Ox. AA
R2061 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2062 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2063 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2064 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2065 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2066 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R2067 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2068 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2069 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2070 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2071 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2073 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2074 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2075 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2076 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2077 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2078 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2080 VRD-RA2BE471J J 470 1/8W Carbon AA
R2081 VRD-RA2BE471J J 470 1/8W Carbon AA
R2084 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R2092 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2093 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2094 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2095 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2097 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2099 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R3001 VRD-RA2BE221J J 220 1/8W Carbon AA
R3002 VRD-RA2BE221J J 220 1/8W Carbon AA
R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3006 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA
R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R3011 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R3012 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R3013 VRD-RA2BE101J J 100 1/8W Carbon AB
R3014 VRD-RA2BE101J J 100 1/8W Carbon AB
R3015 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R3016 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R3017 VRD-RA2BE101J J 100 1/8W Carbon AB
R3018 VRD-RA2BE101J J 100 1/8W Carbon AB
R3104 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R3110 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R3201 VRS-CY1JF225J J 2.2M 1/16W M-Ox. AA
R3202 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R3203 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R3301 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R3302 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA
R3303 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA
R3304 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA
R3305 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA
R3306 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3307 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3308 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R4012 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R4013 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R4014 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R4015 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R4017 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R4020 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R4021 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R4023 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R4025 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA
R4026 VRD-RA2BE183J J 18k 1/8W Carbon AA
R4027 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R4028 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R4071 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R4072 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R4073 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R4074 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R4075 VRD-RA2EE561J J 560 1/4W Carbon AA
R4076 VRD-RA2EE561J J 560 1/4W Carbon AA
R4101 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R4103 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R4104 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R4105 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R4106 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R4108 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R4109 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R4110 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
MISCELLANEOUS PARTS
FB2002RBLN-0047CEZZ J Ferrite Bead AB
J1101 QTANJ0527CEZZ J Component Input Terminal AL
J1301 QTANJ0821CEZZ J AV Terminal AN
J1302 QSOCD0430CEZZ J Socket, S-Video AE
P51 QPLGN0160CEZZ J Plug, 1-pin (SG) AB
P352 QPLGN0461CEZZ J Plug, 4-pin (SS) AB
P401 QPLGN0341CEZZ J Plug, 3-pin (PA) AA
P801 QPLGN0541CEZZ J Plug, 5-pin (GBN) AB
P1301 QPLGN0641CEZZ J Plug, 6-pin (EJ) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin (TP2001-5) AB
P2002 QPLGN0741CEZZ J Plug, 7-pin (KA) AC
P2004 QPLGN0261CEZZ J Plug, 2-pin AB
SC603 QSOCZ1040CEZZ J Socket, 10-pin (XD) AD
SC1802 QSOCZ1040CEZZ J Socket, 10-pin (XA) AD
SC1803 QSOCZ1040CEZZ J Socket, 10-pin (XB) AD
RDA351 PRDAR0299PEFW R Heat Sink, for IC351 AH
RDA740 PRDAR5072CEFW J Heat Sink, for IC740 AC
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA

37
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-B: DUNTKA119FMV0
CRT UNIT
INTEGRATED CIRCUITS
IC850 VHiTDA6103Q-1 J TDA6103Q/N3 AL
TRANSISTORS
Q850 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q851 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q1504 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q1505 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q1506 VS2SA1964E/-1 J 2SA1964E AF
Q1507 VS2SC5248E/-1 J 2SC5248E AE
DIODES
D850 RH-DX0220CEZZ J Diode AB
D851 RH-DX0220CEZZ J Diode AB
D852 RH-DX0220CEZZ J Diode AB
D853 RH-EX0647GEZZ J Zener Diode, 15V AA
or
RH-EX0417GEZZ
D854 VHD1SS119//-1 J Diode AB
D855 VHD1SS119//-1 J Diode AB
D856 RH-EX0722GEZZ J Zener Diode, 3.2V AA
or
RH-EX0349GEZZ Zener Diode, 3.1V
D1502 VHD1SS119//-1 J Diode AB
D1503 VHD1SS119//-1 J Diode AB
D1506 RH-DX0487CEZZ J Diode AC
D1507 RH-DX0487CEZZ J Diode AC
D1508 VHD1SS119//-1 J Diode AB
CAPACITORS
[EL.··· Electrolytic]
C850 VCFYSB2EB823J J 0.082 250V Mylar AD
C851 RC-KZ018JCEZZ J 0.01 250V Ceramic AC
or
RC-KZ015JCEZZ
C852 VCEA0A1CW227M J 220 16V EL. AC
C853 VCFYFA1HA224J J 0.22 50V Mylar AB
C854 VCEA0A1CW227M J 220 16V EL. AC
C855 VCEA0A2EW106M J 10 250V EL. AD
C1501 VCEA0A1EW476M J 47 25V EL. AB
C1506 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1508 VCKYPA2HB472K J 4700p 500V Ceramic AB
C1509 VCKYPA1HB472K J 4700p 50V Ceramic AA
C1510 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1511 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1515 VCEA0A1EW476M J 47 25V EL. AB
C1516 VCEA0A1EW476M J 47 25V EL. AB
C1517 VCEA0A2AW106M J 10 100V EL. AC
C1518 VCCSPA2HL560K J 56p 500V Ceramic AA
C1519 VCEA4A2CN106M J 10 160V EL. AC
RESISTORS
[M-Ox.··· Metal Oxide]
R850 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA
R851 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA
R852 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA
R853 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R854 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R855 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R856 VRD-RM2HD224J J 220k 1/2W Carbon AA
R857 VRD-RM2HD224J J 220k 1/2W Carbon AA
R858 VRD-RM2HD224J J 220k 1/2W Carbon AA
R862 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R863 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R864 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R867 VRS-SV2HC332J J 3.3k 1/2W M-Ox. AA
R868 VRS-SV2HC222J J 2.2k 1/2W M-Ox. AA
R869 VRD-RA2BE103J J 10k 1/8W Carbon AA
R870 VRD-RA2BE223J J 22k 1/8W Carbon AA
R871 VRD-RA2BE223J J 22k 1/8W Carbon AA
R872 VRD-RA2EE680J J 68 1/4W Carbon AA
R873 VRD-RM2HD224J J 220k 1/2W Carbon AA
R874 VRD-RM2HD224J J 220k 1/2W Carbon AA
R875 VRD-RM2HD224J J 220k 1/2W Carbon AA
R876 VRD-RM2HD224J J 220k 1/2W Carbon AA
R1511 VRD-RA2BE101J J 100 1/8W Carbon AB
åR1513 VRS-VV3DB471J J 470 2W M-Ox. AA
R1514 VRD-RA2BE100J J 10 1/8W Carbon AA
R1515 VRD-RA2BE820J J 82 1/8W Carbon AA
R1516 VRD-RA2BE820J J 82 1/8W Carbon AA
R1517 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683J J 68k 1/8W Carbon AA
R1519 VRD-RA2BE123J J 12k 1/8W Carbon AA
R1520 VRD-RA2BE683J J 68k 1/8W Carbon AA
R1521 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
R1522 VRD-RA2EE471J J 470 1/4W Carbon AA
R1525 VRD-RA2EE560J J 56 1/4W Carbon AA
R1526 VRD-RA2EE560J J 56 1/4W Carbon AA
R1527 VRD-RA2EE1R5J J 1.5 1/4W Carbon AA
R1528 VRD-RA2EE1R8J J 1.8 1/4W Carbon AA
åR1529 VRS-VV3DB221J J 220 2W M-Ox. AA
R1530 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
MISCELLANEOUS PARTS
FB1501RBLN-0047CEZZ J Ferrite Bead AB
P850 QPLGN0561CEZZ J Plug, 5-pin (GBN) AB
P851 QPLGN0361CEZZ J Plug, 3-pin (PA) AB
P852 QPLGN0261CEZZ J Plug, 2-pin (PU) AB
P854 QPLGN0661CEZZ J Plug, 6-pin (BBN) AD
P858 QTiPM0083CEZZ J Tip, (CE) AB
SC850 QSOCV0936CEZZ J CRT Socket AM
RDA850 PRDAR0248PEFW R Heat Sink, for IC850 AF
RDA1506 PRDAR0083PEFW R Heat Sink, for Q1506 AD
RDA1507 PRDAR0083PEFW R Heat Sink, for Q1507 AD
LX-BZ3100CEFD J Screw AA

38
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-C: DUNTKA255FMV0
POWER UNIT
INTEGRATED CIRCUITS
IC700 VHiTDA16846-1 J TDA16846 AN
åIC701 RH-FX0008GEZZ J PC123FY8 AE
åIC702 RH-FX0008GEZZ J PC123FY8 AE
IC750 VHiSE120N//-1 J SE120N AG
åIC752 RH-FX0034CEZZ J PC817 AE
åIC1501 VHiTA8427K/-1 J TA8427K AL
IC1680 VHiiR9358//-1 J IR9358 AD
IC1700 VHiMiP0253/-1 J MIP0253SP AM
åIC1701 RH-FX0008GEZZ J PC123FY8 AE
IC1751 RH-iX0037CEZZ J UPC574J AF
TRANSISTORS
Q700 VSSPP11N60C-1 J SPP11N60C2 AR
Q701 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q750 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q752 VS2SC3198-G-1 J 2SC3198(G) AA
Q753 VS2SC1959Y/1E J 2SC1959Y AC
Q1534 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q1622 VS2SC3207//-1 J 2SC3207 AC
åQ1630 VS2SD2581++2E J 2SD2581 AM
Q1670 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q1671 VS2SD1830//1E J 2SD1830 AF
Q1680 VS2SC5022//1E J 2SC5022 AG
Q1681 VS2SC3198-Y-1 J 2SC3198(Y) AA
DIODES
åD700 RH-DX0336CEZZ J Diode AH
D701 RH-DX0130CEZZ J Diode AE
D702 RH-DX0321CEZZ J Diode AC
D703 RH-DX0130CEZZ J Diode AE
D704 RH-EX0636GEZZ J Zener Diode, 10V AC
D705 RH-DX0475CEZZ J Diode AB
D707 RH-DX0475CEZZ J Diode AB
D717 RH-DX0279CEZZ J Diode AB
D718 RH-DX0279CEZZ J Diode AB
D750 RH-DX0475CEZZ J Diode AB
D751 RH-DX0243CEZZ J Diode AF
D752 RH-DX0373CEZZ J Diode AC
D753 RH-DX0373CEZZ J Diode AC
D754 RH-DX0452CEZZ J Diode AH
D756 RH-EX0152CEZZ J Zener Diode AE
D1534 RH-DX0279CEZZ J Diode AB
D1576 RH-DX0127CEZZ J Diode AC
D1610 RH-DX0202CEZZ J Diode AD
åD1621 RH-EX0658GEZZ J Zener Diode, 21V AA
D1631 RH-DX0449CEZZ J Diode AK
D1651 RH-DX0302CEZZ J Diode AC
D1659 RH-DX0130CEZZ J Diode AE
D1664 RH-EX0631GEZZ J Zener Diode, 9V AA
D1680 RH-DX0484CEZZ J Diode AE
D1681 RH-DX0475CEZZ J Diode AB
D1682 RH-DX0475CEZZ J Diode AB
D1683 RH-DX0475CEZZ J Diode AB
D1684 RH-DX0475CEZZ J Diode AB
D1700 RH-DX0279CEZZ J Diode AB
D1701 RH-DX0279CEZZ J Diode AB
D1702 RH-DX0279CEZZ J Diode AB
D1703 RH-DX0279CEZZ J Diode AB
D1750 RH-DX0407CEZZ J Diode AD
D1751 RH-EX0631GEZZ J Zener Diode, 9V AA
D1756 RH-EX0619GEZZ J Zener Diode, 6.4V AA
åVA700 RH-VX0048CEZZ J Varistor AE
or
RH-VX1018CEZZ
PACKAGED CIRCUIT
åPR700 RMPTP0085CEZZ J Packaged Circuit AL
COILS
åL700 RCiLF0346CEZZ J Coil AL
åL701 RCiLF0313CEZZ J Coil AH
or
RCiLF0363CEZZ
or
RCiLF0345CEZZ
L751 RCiLP0268CEZZ J Coil AE
L1640 RCiLZ0982CEZZ J Coil AK
L1641 RCiLZ1022CEZZ J Coil AK
L1670 RCiLZ1005CEZZ J Coil AH
L1680 RCiLZ0976CEZZ J Coil AK
L1681 VP-XF8R2K0000 J Peaking 8.2µH AB
TRANSFORMERS
åT700 RTRNZ0201PEZZ R Transformer AT
åT1602 RTRNF0206PEZZ R H-Volt Transformer BF
åT1620 RTRNZ0731CEZZ J Transformer AG
T1680 RTRNZ0726CEZZ J Transformer AM
åT1700 RTRNZ0190PEZZ R Transformer AH
CONTROL
R1759 RVR-M4634GEZZ J 220k(B) Sub-Control Adj AB
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C701 VCFYSB2EB224K J 0.22 250V Mylar AD
åC702 RC-FZ086CGEZZ J 0.47 AC250V Mylar AF
or
RC-FZ005SCEZZ
or
RC-FZ018SCEZZ
or
RC-FZ030SCEZZ
or
RC-FZ034CUMZZ
or
RC-FZ071SGEZZ
or
RC-FZ016SGEZZ
or
RC-FZ022SCEZZ
or
RC-FZ038SCEZZ
C703 VCCSPA1HL221J J 220p 50V Ceramic AA
C704 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C705 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C706 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C707 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C708 VCQYTA1HM332J J 3300p 50V Mylar AA
C709 VCKYPA1HB102K J 1000p 50V Ceramic AA
C710 VCKYPA1HB101K J 100p 50V Ceramic AA
C711 VCEACA1HC105J J 1.0 50V EL. AB
C712 VCQPSC2JA333K J 0.033 630V Mylar AB
C713 RC-KZ0334CEZZ J 270p 2kV Ceranic AC
C714 RC-KZ0037CEZZ J 390p 2kV Ceranic AB
C715 RC-EZ0689CEZZ J 680 400V EL. BA
C716 VCQYTA1HM102J J 1000p 50V Mylar AA
C717 VCEA0A1EW476M J 47 25V EL. AB
C718 RC-KZ020SCEZZ J 2200p 400V Ceramic AE
or
RC-KZ0105GEZZ
or
RC-KZ0128GEZZ
or
RC-KZ008SGEZZ
C720 VCQYTA1HM681J J 680p 50V Mylar AB
C721 VCKYPA1HB102K J 1000p 50V Ceramic AA
C724 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C727 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C728 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C729 VCKYPA1HB821K J 820p 50V Ceramic AA
C730 RC-FZ022SCEZZ J 0.47 AC250V Mylar AF
or
RC-FZ038SCEZZ
or
RC-FZ005SCEZZ

39
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-C: DUNTKA255FMV0
POWER UNIT (Continued)
or
RC-FZ018SCEZZ
or
RC-FZ030SCEZZ
or
RC-FZ034CUMZZ
or
RC-FZ071SGEZZ
or
RC-FZ016SGEZZ
or
RC-FZ086CGEZZ
C732 VCKYPU1HF103Z 0.01 50V Ceramic
C750 RC-KZ1022CEZZ J 47p 1kV Ceramic AC
C751 VCKYPA2HB471K J 470p 500V Ceramic AA
C752 VCKYPA2HB471K J 470p 500V Ceramic AA
C753 VCKYPA2HB471K J 470p 500V Ceramic AA
C755 RC-EZ0004PEZZ R 2200 35V EL. AH
C756 RC-EZ1226CEZZ J 3300 16V EL. AK
C757 RC-EZ0004PEZZ R 2200 35V EL. AH
C758 RC-EZ0308CEZZ J 330 160V EL. AF
C761 VCFYFA1HA104J J 0.1 50V Mylar AA
C763 RC-EZ0308CEZZ J 330 160V EL. AF
C764 VCKYPA2HB102K J 1000p 500V Ceramic AA
C765 VCKYPA1HB101K J 100p 50V Ceramic AA
C768 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C771 RC-KZ1022CEZZ J 47p 1kV Ceramic AC
C772 RC-KZ0031CEZZ J 100p 250V Ceramic AC
or
RC-KZ0329CEZZ
C1512 VCQYTA1HM563J J 0.056 50V Mylar AB
C1513 VCKYPA2HB391K J 390p 500V Ceramic AA
C1514 VCQYTA1HM392J J 3900p 50V Mylar AA
C1521 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1525 VCKYPA1HB391K J 390p 50V Ceramic AA
C1526 VCKYPA1HB391K J 390p 50V Ceramic AA
C1534 VCEA0A1HW107M J 100 50V EL. AB
C1535 VCFYAA2AA224J J 0.22 100V Mylar AD
C1536 VCEACA1HC474M J 0.47 50V EL. AB
C1537 VCEA0A1VW108M J 1000 35V EL. AD
C1538 VCEACA1HC105M J 1.0 50V EL. AC
C1539 VCQYTA1HM103J J 0.01 50V Mylar AA
C1540 VCKYPA1HB102K J 1000p 50V Ceramic AA
C1572 VCEA0H1VW228M J 2200 35V EL. AH
C1575 RC-QZ0037CEZZ J 0.01 100V Mylar AB
C1576 VCKYPA2HB102K J 1000p 500V Ceramic AA
C1610 VCFYSB2EB224K J 0.22 250V Mylar AD
åC1619 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1623 VCFPVC2DB474J J 0.47 200V M-Poly. AE
C1625 VCKYPA2HB561K J 560p 500V Ceramic AA
C1627 VCKYPA1HB102K J 1000p 50V Ceramic AA
åC1632 VCFPVC3CA103H J 0.01 1.6kV M-Poly. AE
åC1633 VCFPVC3CA912H J 9100p 1.6kV M-Poly. AE
åC1635 VCQPPC2JB223J J 0.022 630V Mylar AC
åC1636 VCQPPC2JB223J J 0.022 630V Mylar AC
C1638 VCKYPA1HB472K J 4700p 50V Ceramic AA
C1639 RC-KZ0033CEZZ J 150p 2kV Ceramic AB
C1644 RC-FZ0364CEZZ J 0.62 250V M-Poly. AF
C1651 VCKYPA2HB102K J 1000p 500V Ceramic AA
C1652 VCEA0A2EW106M J 10 250V EL. AD
C1655 VCCSPA2HL221K J 220p 500V Ceramic AB
C1659 VCEA0A1HW106M J 10 50V EL. AB
C1670 RC-FZ0374CEZZ J 4.7 100V Mylar AF
C1680 VCFPVC3CA822H J 8200p 1.6kV M-Poly. AE
C1681 RC-KZ0024CEZZ J 1000p 2kV Ceramic AC
C1682 VCKYPH3DB561K J 560p 2kV Ceramic AC
C1683 VCE9GA1HW335M J 3.3 50V EL.(N.P) AB
C1684 VCEA0A1VW106M J 10 35V EL. AB
C1695 VCFYFA1HA224J J 0.22 50V Mylar AB
C1696 VCQYTA1HM103J J 0.01 50V Mylar AA
C1700 VCEA0A2GW475M J 4.7 400V EL. AE
C1701 RC-KZ1022CEZZ J 47p 1kV Ceramic AC
C1702 VCFYFA1HA104J J 0.1 50V Mylar AA
C1703 RC-KZ020SCEZZ J 2200p 400V Ceramic AE
or
RC-KZ0105GEZZ
or
RC-KZ0128CEZZ
or
RC-KZ008SCEZZ
C1704 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C1705 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C1706 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C1707 RC-KZ0029CEZZ J 0.01 AC250V Ceramic AC
C1750 VCKYPA2HB221K J 220p 500V Ceramic AA
C1751 VCEA0A1CW477M J 470 16V EL. AC
C1753 VCEA0A1HW106M J 10 50V EL. AB
C1754 VCFYFA1HA184J J 0.18 50V Mylar AC
C1756 VCQYTA2AA563K J 0.056 100V Mylar AB
RESISTORS
[M-Ox.··· Metal Oxide, M-Film··· Metal Film]
R701 VRD-RM2HD391J J 390 1/2W Carbon AA
R702 VRW-KQ41C1R0K J 1.0 15W Cement AF
R703 VRW-KQ41C1R0K J 1.0 15W Cement AF
R704 VRW-KQ41C1R0K J 1.0 15W Cement AF
åR705 RR-DZ0053CEZZ J 8.2M 1/2W Carbon AC
åR706 RR-DZ0053CEZZ J 8.2M 1/2W Carbon AC
R707 VRD-RA2BE563J J 56k 1/8W Carbon AA
R708 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R709 VRD-RM2HD224J J 220k 1/2W Carbon AA
R710 VRD-RM2HD224J J 220k 1/2W Carbon AA
R711 VRD-RA2BE153J J 15k 1/8W Carbon AA
R712 VRD-RM2HD155J J 1.5M 1/2W Carbon AB
R713 VRD-RM2HD155J J 1.5M 1/2W Carbon AB
R714 VRD-RA2BE150J J 15 1/8W Carbon AA
R715 VRD-RA2BE330J J 33 1/8W Carbon AA
R716 VRD-RA2BE393J J 39k 1/8W Carbon AA
R717 VRS-KT3LB823J J 82k 3.0W M-Ox. AC
R718 VRD-RA2BE103J J 10k 1/8W Carbon AA
R720 VRD-RM2HD105J J 1.0M 1/2W Carbon AA
R721 VRD-RM2HD153J J 15k 1/2W Carbon AA
R723 VRD-RM2HD102J J 1.0k 1/2W Carbon AA
R725 VRD-RM2HD124J J 120k 1/2W Carbon AA
R726 VRD-RM2HD124J J 120k 1/2W Carbon AA
R727 VRD-RM2HD123J J 12k 1/2W Carbon AA
R728 VRD-RM2HD123J J 12k 1/2W Carbon AA
R729 VRD-RM2HD103J J 10k 1/2W Carbon AA
R730 VRD-RM2HD103J J 10k 1/2W Carbon AA
R752 VRD-RA2BE273J J 27k 1/8W Carbon AA
R753 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R754 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R755 VRD-RA2BE103J J 10k 1/8W Carbon AA
R761 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R762 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R1508 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1523 VRD-RA2BE124J J 120k 1/8W Carbon AA
R1524 VRD-RA2BE563J J 56k 1/8W Carbon AA
R1532 VRN-SV2HB2R7J J 2.7 1/2W M-Film. AA
R1533 VRN-SV2HB2R7J J 2.7 1/2W M-Film. AA
R1535 VRD-RA2BE101J J 100 1/8W Carbon AB
R1536 VRD-RM2HD391J J 390 1/2W Carbon AA
R1537 VRD-RM2HD391J J 390 1/2W Carbon AA
R1538 VRD-RM2HD123J J 12k 1/2W Carbon AA
R1539 VRD-RA2BE223J J 22k 1/8W Carbon AA
R1540 VRD-RA2BE274J J 270k 1/8W Carbon AA
R1541 VRS-VV3AB391J J 390 1W M-Ox. AA
R1542 VRD-RA2BE104J J 100k 1/8W Carbon AA
åR1546 VRS-SV2HC220J J 22 1/2W M-Ox. AA
R1556 VRD-RA2BE394J J 390k 1/8W Carbon AA
R1557 VRD-RA2BE273J J 27k 1/8W Carbon AA
R1558 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1559 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1560 VRN-SV2HB2R7J J 2.7 1/2W M-Film. AA
R1576 VRN-VV3AB1R0J J 1.0 1W M-Film. AA
R1610 VRS-VV3DB103J J 10k 2W M-Ox. AA
åR1619 VRD-RA2BE472J J 4.7k 1/8W Carbon AA
åR1620 VRD-RA2BE101J J 100 1/8W Carbon AB

40
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-C: DUNTKA255FMV0
POWER UNIT (Continued)
R1621 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1622 VRS-SU2HB102J J 1.0k 1/2W M-Ox. AA
R1623 VRD-RM2HD393J J 39k 1/2W Carbon AA
R1624 VRS-KT3LB122J J 1.2k 3.0W M-Ox. AC
R1625 VRS-VV3AB562J J 5.6k 1W M-Ox. AA
R1626 VRD-RA2BE470J J 47 1/8W Carbon AA
R1627 VRD-RA2BE271J J 270 1/8W Carbon AA
R1629 VRW-KQ41C3R3K J 3.3 15W Cement AG
R1638 VRD-RM2HD150J J 15 1/2W Carbon AA
R1647 VRS-KT3LB122J J 1.2k 3.0W M-Ox. AC
R1651 VRN-VV3AB5R6J J 5.6 1W M-Film. AA
R1654 VRD-RM2HD102J J 1.0k 1/2W Carbon AA
R1655 VRD-RM2HD472J J 4.7k 1/2W Carbon AA
R1659 VRN-VV3DBR68J J 0.68 2W M-Film. AA
R1660 VRD-RM2HD101J J 100 1/2W Carbon AA
R1661 VRD-RM2HD101J J 100 1/2W Carbon AA
R1662 VRD-RM2HD103J J 10k 1/2W Carbon AA
R1670 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1671 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1672 VRD-RA2BE472J J 4.7k 1/8W Carbon AA
R1673 VRD-RA2EE822J J 8.2k 1/4W Carbon AA
R1674 VRD-RM2HD182J J 1.8k 1/2W Carbon AA
R1675 VRN-VV3DBR33J J 0.33 2W M-Film. AA
R1680 VRS-SV3LB154J J 150k 3.0W M-Ox. AC
R1681 VRS-KT3LB104J J 100k 3.0W M-Ox. AC
R1682 VRC-MA2HG333K J 33k 1/2W Solid AA
R1683 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R1684 VRD-RA2BE681J J 680 1/8W Carbon AA
R1685 VRS-VV3AB181J J 180 1W M-Ox. AA
R1686 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1687 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1688 VRD-RA2BE473J J 47k 1/8W Carbon AA
R1689 VRD-RA2BE823J J 82k 1/8W Carbon AA
R1690 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R1691 VRD-RA2BE823J J 82k 1/8W Carbon AA
R1695 VRD-RA2BE224J J 220k 1/8W Carbon AA
R1696 VRD-RA2BE474J J 470k 1/8W Carbon AA
R1700 VRW-KP3HC330J J 33 5W Cement AD
R1752 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1753 VRS-VV3DB153J J 15k 2W M-Ox. AA
R1754 VRD-RA2EE185J J 1.8M 1/4W Carbon AA
R1756 VRD-RA2EE334J J 330k 1/4W Carbon AA
R1757 VRS-VV3AB103J J 10k 1W M-Ox. AA
R1760 VRD-RA2EE104J J 100k 1/4W Carbon AA
R1761 VRD-RA2EE124J J 120k 1/4W Carbon AA
MISCELLANEOUS PARTS
åRY700 RRLYJ0093CEZZ J Relay AG
åF700 QFS-C5022CEZZ J Fuse, 5A (250V) AD
FB700 RBLN-0037CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FB702 RBLN-0037CEZZ J Ferrite Bead AB
FB750 RBLN-0037CEZZ J Ferrite Bead AB
FB751 RBLN-0037CEZZ J Ferrite Bead AB
FB752 RBLN-0037CEZZ J Ferrite Bead AB
FB753 RBLN-0037CEZZ J Ferrite Bead AB
FB754 RBLN-0037CEZZ J Ferrite Bead AB
FB755 RBLN-0037CEZZ J Ferrite Bead AB
FB756 RBLN-0037CEZZ J Ferrite Bead AB
FB757 RBLN-0037CEZZ J Ferrite Bead AB
FB1500RBLN-0037CEZZ J Ferrite Bead AB
FB1501RBLN-0037CEZZ J Ferrite Bead AB
FB1630RBLN-0047CEZZ J Ferrite Bead AB
FB1631RBLN-0047CEZZ J Ferrite Bead AB
FB1700RBLN-0037CEZZ J Ferrite Bead AB
FB1750RBLN-0037CEZZ J Ferrite Bead AB
FH700 QFSHD1017CEZZ J Fuse Holder AC
FH701 QFSHD1018CEZZ J Fuse Holder AC
J1 QCNW-2428PEZZ R Connecting Cord AC
P700 QPLGN0269GEZZ J Plug, 2-pin (A) AB
P701 QPLGN0260CEZZ J Plug, 2-pin (G) AC
P703 QPLGN0160CEZZ J Plug, 1-pin (SG) AB
P750 QPLGZ1040CEZZ J Plug, 10-pin (XB) AE
P1500 QPLGN0160FJZZ J Plug, 5-pin (K) AD
P1501 QPLGZ1040CEZZ J Plug, 10-pin (XD) AE
P1530 QPLGN0261CEZZ J Plug, 2-pin (G4) AB
P1610 QPLGN0361CEZZ J Plug, 3-pin (TP1611-3) AB
P1650 QPLGN0641CEZZ J Plug, 6-pin (BBN) AB
P1750 QPLGZ1040CEZZ J Plug, 10-pin (XA) AE
SG1680 QSPGH0025CEZZ J Spark Gap AC
SG1681 QSPGH0025CEZZ J Spark Gap AC
RDA700 PRDAR0304PEFW R Heat Sink, for Q700 AH
RDA701 PRDAR0139PEFW R Heat Sink, for D700 AC
RDA750 PRDAR0160PEFW R Heat Sink, for D754 AF
RDA1631 PRDAR0198PEFW R Heat Sink, for D1631 AG
RDA1501 PRDAR0213PEFW R Heat Sink, for IC1501 AM
RDA1630 PRDAR0249PEFW R Heat Sink, for Q1630 AL
RDA1671 PRDAR0277PEFW R Heat Sink, for Q1671 AF
RDA1680 PRDAR0135PEFW R Heat Sink, for Q1680 AE
PZETM0016CEZZ J Insulator AB
LHLDW1064PEKZ R Holder AC
LX-BZ0086TAFD J Screw AA
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
MSPRK0034BMFW J Spring AC

41
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
PWB-F: DUNTKA256WEV0
FRONT AV UNIT
TRANSISTOR
Q1200 VS2SC3198-Y-1 J 2SC3198(Y) AA
DIODES
D1200 RH-PX0274CEZZ J LED, Power Ind AC
D1201 RH-PX0274CEZZ J LED, On Timer AC
CAPACITORS
[EL.··· Electrolytic]
C1200 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1201 VCEA0A0JW107M J 100 6.3V EL. AB
C1204 VCKYPA1HB102K J 1000p 50V Ceramic AA
C1205 VCKYPA1HB102K J 1000p 50V Ceramic AA
C1207 VCKYPA1HF103Z J 0.01 50V Ceramic AA
RESISTORS
R1200 VRD-RA2BE821J J 820 1/8W Carbon AA
R1201 VRD-RA2BE472J J 4.7k 1/8W Carbon AA
R1202 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1213 VRD-RA2BE101J J 100 1/8W Carbon AB
R1214 VRD-RA2BE101J J 100 1/8W Carbon AB
R1222 VRD-RA2BE103J J 10k 1/8W Carbon AA
R1223 VRD-RA2BE153J J 15k 1/8W Carbon AA
R1224 VRD-RA2BE273J J 27k 1/8W Carbon AA
R1225 VRD-RA2BE563J J 56k 1/8W Carbon AA
R1226 VRD-RA2BE123J J 12k 1/8W Carbon AA
R1227 VRD-RA2BE563J J 56k 1/8W Carbon AA
R1228 VRD-RA2BE272J J 2.7k 1/8W Carbon AA
R1230 VRD-RA2BE750J J 75 1/8W Carbon AA
R1231 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1232 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1250 VRD-RA2BE101J J 100 1/8W Carbon AB
SWITCHES
S1200 QSW-K0202PEZZ R CH-Up AC
S1201 QSW-K0202PEZZ R CH-Down AC
S1202 QSW-K0202PEZZ R Vol-Up AC
S1203 QSW-K0202PEZZ R Vol-Down AC
S1204 QSW-K0202PEZZ R MENU AC
S1205 QSW-P0593CEZZ J Power AE
MISCELLANEOUS PARTS
J1200 QTANJ0335CEZZ J A/V Terminal AG
P1201 QPLGN0741CEZZ J Plug, 7-pin (KA) AC
P1202 QPLGN0641CEZZ J Plug, 6-pin (EJ) AB
SC1201 QTiPM0083CEZZ J Tip AB
RMC1200 RRMCU0235CEZZ J R/C Receiver AK
LHLDP1056PE00 R Holder AC

42
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29C-FX10T
29C-FH100T
SUPPLIED ACCESORRIES
PACKING PARTS
(NOT REPLACEMENT ITEM)
MISCELLANEOUS PARTS
å ACC701 QACCZ3008PEZZ R AC Cord AN
QCNW-2469PEZZ R Connecting Cord AF
QCNW-2470PEZZ R Connecting Cord AH
QCNW-2474PEZZ R Connecting Cord AH
QCNW-2475PEZZ R Connecting Cord AE
QCNW-2476PEZZ R Connecting Cord AE
QCNW-2477PEZZ R Connecting Cord AD
QCNW-2480PEZZ R Connecting Cord AE
QCNW-2540PEZZ R Connecting Cord AF
(29C-FH100T)
SP1 VSP1208PB326A J Speaker 6 ohm (R) AU
SP2 VSP1208PB326A J Speaker 6 ohm (L) AU
TCAUA0002PEZZ R Caution Card AB
RRMCG1538PESB R Infrared R/C Unit AX
TGAN-0218PEZZ R Guarantee Card AE
(29C-FH100T)
TGAN-0219PEZZ R Guarantee Card AE
(29C-FX10T)
TiNS-7085PEZZ R Operation Manual AF
SPAKC6667PEZZ – Packing Case —
(29C-FH100T)
SPAKC6668PEZZ – Packing Case —
(29C-FX10T)
SPAKP0083PEZZ – Wrapping Sheet —
SPAKX2751PEZZ – Buffer Material —
SSAKA0002PEZZ – Polyethylene Bag —
29C-FX10T
1 CCABA2603WEV0 J Front Cabinet Ass’y BR
1-1 Not Available – Front Cabinet —
1-2 HBDGB3141CESA J Badge, "SHARP" AG
1-3 HDECQ0170PESA R LED Decoration Panel AD
1-4 JBTN-0338PESA R Power Button AG
1-5 MSPRC0005PEFW J Spring, Power Button AB
1-6 GCOVA0129PESA R Cover for R/C LED AD
1-7 GDORF0185PESA R Door AN
1-8 PKAi-0007PE00 R Door Latch AE
1-9 HiNDP0267PEZZ R Indication Plate, In Door AE
1-10 HDECQ0165PESA R Speaker Punch (L) AP
1-11 HDECQ0166PESA R Speaker Punch (R) AP
2 CCABB2426WEV1 R Rear Cabinet Ass’y BG
2-1 Not Available – Rear Cabinet —
2-2 HiNDP0268PEZZ R Indication Plate, RearAV Jack AG
29C-FH100T
1 CCABA2602WEV0 J Front Cabinet Ass’y BR
1-1 Not Available – Front Cabinet —
1-2 HBDGB3141CESA J Badge, "SHARP" AG
1-3 HDECQ0170PESA R LED Decoration Panel AD
1-4 JBTN-0338PESA R Power Button AG
1-5 MSPRC0005PEFW R Spring, Power Button AB
1-6 GCOVA0129PESA R Cover for R/C LED AD
1-7 GDORF0185PESA R Door AN
1-8 PKAi-0007PE00 R Door Latch AE
1-9 HiNDP0267PEZZ R Indication Plate, In Door AE
1-10 Not Available – Port Cover —
1-11 Not Available – Speaker Punch (L) —
1-12 Not Available – Speaker Punch (R) —
2 CCABB2426WEV1 R Rear Cabinet Ass’y BG
2-1 Not Available – Rear Cabinet —
2-2 HiNDP0268PEZZ R Indication Plate, RearAV Jack AG
CABINET PARTS
1-5 1-4 1-6 1-7 1-8 1-9
22-1
2-2
11-1
1-10
1-11
1-3 1-2
1-5 1-4 1-6 1-7 1-8 1-9
22-1
2-2
11-1
1-11
1-10
1-10
1-12
1-3 1-2
29C-FH100T
29C-FX10T
