Sharp LC-32FI6522KF Operator's manual

Quick Start Set Up Guide
For information on using the TV’s features, please refer to the operating Instructions.
Quick & easy guide for setting up your TV
What is included in the box
Using the remote control
Setting up the TV for the rst time - including attaching the stand
Connecting other devices to the Television
Need help setting up or using your TV?
Please contact the UK & ROI Helpline*
Telephone UK 0330 024 0803 or ROI 01443 3323
Online support at: www.umc-uk.co.uk
Email support at: servic[email protected].uk
*Calls to 0330 numbers are charged at standard call rates and are included as part of any bundled minutes with your
phone provider.
Calls to the ROI number are charged at the local call rate.
The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.
Bank Holidays - 10am to 4pm
Closed Christmas and New Years day
Model Numbers
LC-32FI6522KF
SHA/QSW/0035
Trademark Sharp
Model ID
LC-32FI6522KF
Energy eciency class A+
Visible screen size (diagonal) 81 cm / 32 inches
On-mode power consumption 31.0 W
Annual energy consumption *1 45 kWh
Standby power consumption *2 <0.50 W
O mode power consumption n/a
Screen resolution 1920 (H) x 1080 (V)
*1: Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4
hours per day for 365 days. The actual energy consumption will depend on how the television is used.
*2: When the TV is turned o with the remote control/standby button and no function is active.
LC-32FI6522KF
RF 75 ohm Antenna / Analog / DVB / Satellite
Inputs 3 x HDMI, 2 x USB, 1 x SCART,
1 x RJ45 LAN/Ethernet, 1 x Composite/CVBS Video & Component/YPbPr Input,
1 x L/R Audio input for Composite/CVBS & Component/YPbPr
Sound Outputs 1 x Digital Optical Audio output, 1 x 3.5mm Headphone
Speaker* / Amplier Watts (RMS) 2 x 10 / 2 x 8
Voltage and power consumption AC 220V ~ 240V; 50Hz
31/45/70W (home mode/standard/max)
(<0.5W in Standby)
Dimensions including stand (mm) 730W x 648H x 187D
Net weight (Kgs) 4.9
Wall Mounting VESA 200 x 100 (mm)
Win a
Soundbar
Register your manufacturers guarantee online within 14 days of purchase at
www.registertoday.co.uk/sharp and enter into a prize draw to
Terms and conditions apply. Online registration only.
p
and
enter
into
a
prize
draw
t
o
n
ly
.
Pairing the remote control
1) If the TV turns on automatically and the first time installation screen appears, but the TV does not react
to the remote control, it will need to be paired with the set. To achieve this, press and hold the centre
two coloured buttons at the bottom of the remote control for a few seconds. The power light will then
blink 5 times to confirm that the TV and remote control are paired.
2) If the TV does not automatically turn on, you will need to do this manually by pressing the centre of
the TV control stick once, this is located on the back of the TV, at the left bottom corner. Once switched
on, press and hold the TV control stick on the TV set for a few seconds. This will prompt the ‘pairing
menu’to appear, scroll through by tilting the control stick down and highlight the ‘pair your remote’ op-
tion, then press the centre of the control stick to confirm. Now, press and hold the centre two coloured
buttons at the bottom of the remote control for a few seconds to pair with the set. The power light will
blink 5 times to confirm that the TV and remote control are paired.
Accessories
Included with this TV are the following accessories
What is included in the box
Technical Specication
Please save your box/packaging as you will need this in the event of warranty/service repair or support.
We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to
package your item in the event of warranty/service repair is in it’s original box/packaging.
1 x Operating Instructions
1 x Quick start guide
1 x TV
1 x RF cable
1 x Remote Control and 2 x AAA Batteries
*Built-in Harman Kardon speaker systems (Full-range speaker and tweeter).
Harman Kardon is trademark of HARMAN International Industries, Incorporated,
registered in the United States and/or other countries.
1 x Stand installation pack
4 x
1 x L (left) 1 x R (right)
Buttons to use when
pairing the remote
control to the TV.
REMOTE CONTROL
FREEVIEW PLAY - Switch on the TV when in standby or vice versa.
NETFLIX - Access the Netflix application.
STANDBY - Switch on the TV when in standby or vice versa.
NUMBER BUTTONS - 0–9 to select a TV channel directly.
MUTE - Mute the sound or vice versa.
TV GUIDE - Opens the 7 day TV guide (digital TV mode).
YOUTUBE - Access the Youtube App.
APPS - Access the APPS menu.
SOURCE - To display the input/source menu.
TV - Switches to the Digital TV source.
VOL (+/-) - To increase/decrease the sound level.
FAV - To display favourites menu.
INFO - Press once for now/next channel information.
- Press twice for information about the current programme.
CH (+/-) - To increase or decrease the channel being watched.
SUBTITLE - To switch the dialogue at the bottom of the
screen (on/off).
TEXT - To enter/exit Text.
MENU - To display OSD menu.
BACK - To go back a previous step.
EXIT - To exit all menus.
- Allows you to navigate the on-screen menus and
adjust the system settings to your preference. When there is no menu
displayed on the screen, you will be able to adjust the picture/sound
settings on the TV, use the button to change the picture settings and
the button to change the sound settings.
RECORD/DVD MENU - Access the USB record function/Access the
DVD menu of the DVD inserted (must be set to the DVD source).
REC LIST/DVD SETUP - Opens the list of previously recorded items/Access
the TV’s DVD setup menu (must be set to the DVD source).
GOTO - To go to a specific chapter.
A-B - Press once to set point, press a second time to return to point.
ANGLE - Select an alternative camera angle during playback of the DVD.
REPEAT - To repeat playback.
Key
3
4
2
1
For models with integrated DVD players.
For models with PVR Function.
For models with USB Playback.
For models with 3D functions.
5- To play in fast rewind mode
- To play in fast forward mode
- To play/pause
- To restart the current chapter
- To advance forward to the next chapter
- To stop the playback/Eject Disc
(To EJECT the disc press/hold the button for 4 seconds)
213
546
APPs
879
0
FAV
INFO
MENU
OK
EXIT
REC
DVD MENU
GOTO A-B ANGLE
REPEAT
DVD SETUP
REC
LIST
BACK
TV
GUIDE
VOL CH
TV
Freeview Play
1
5
3
4
2
1
Freeview Play brings together live TV viewing with ‘‘catch up’’
TV services such as BBC iPlayer, ITV player, More4 and Demand
5. The Freeview Play Explore app features a carousel of genres
to select from when searching for programmes, such as sport,
comedy, dramas and soaps, etc. Content is made up from
recommendations of the major broadcasters and offers an
alternative means of searching.
Note that to use the full funtionality of Freeview Play, your set
must be connected to the internet.
To receive Freeview channels, in particular Freeview HD
channels, you will need a Digital TV aerial and be in a
good Freeview coverage area.
You can check coverage for your postcode
at www.freeview.co.uk.
Please note that any Freeview HD channels found during
tuning will be placed in channel positions above 100. For
example, 101 (BBC1 HD) 102 (BBC2 HD) etc.
LC-32FI6522KF SHA-QSW-0035.indd 1LC-32FI6522KF SHA-QSW-0035.indd 1 01/10/2018 13:42:4101/10/2018 13:42:41

1. Languages
Select your preferred on screen display language. This will change the language in
which the menus and associated information is displayed in. When set up has been
completed, this can be changed by selecting Menu > Settings > Language
3. Network setup You can connect the TV to your broadband router or wire-
less network in order to take advantage of the Smart functions. If you connect the
TV to your router using an Ethernet cable (recommended) this step will be skipped.
Follow the on screen prompts to connect to your wireless network. You can set up
the Network connection later in the network menu.
5. TV Installation – Audio.
Depending on how you use / install your TV, select the appropriate setting. The sound
settings on the TV will adjust to suit the type of installation.
6. Default Source
Select the source which you use the most. If Digital TV (Freeview) is chosen, then at
the next step, the set will tune in and default to Digital TV (Freeview). If one of the
other sources is selected, then the set will not tune in at this stage and default to
that input. If it is required to tune the set in later, this can be achieved by selecting
Menu > Channels
4
Connecting your set
First time installation
4. Environment of Use
Home Mode: For normal use, by default it is set to a power saving mode which re-
duces the energy used by up to 25% (by reducing the power to the LED/LCD panel).
This can be changed in the picture mode settings.
NOTE: In Home Mode, the TV will switch itself to the standby mode after 4 hours in
the event that the buttons on the remote control or TV set are not used.
Store Mode: For store display use. The picture is adjusted to optimum settings. The
store demonstration will appear on the screen automatically after two minutes.
1 2 3
4 5 6
2. Country Selection
Select the correct flag for the country in which the set will be used in. This will enable
the set to correctly install the functions applicable in the country of use.
3Powering On the TV
Switch on the television by pressing
the TV control stick located on the
TV set.
TV control stick
Insert the batteries supplied into the remote
control. The remote control should automati-
cally be paired with the TV set. If this is not the
case, please refer to the ‘Pairing the remote
control’ section of this Quick Start Guide.
TV Control Stick
Remote Control: Installing Batteries
Setting up the TV set for the rst time
Connectivity
1) Connect the TV to your power socket.
2) If you wish to use the TV to receive Freeview/Saorview channels,
connect the RF input from the TV to your outdoor Digital TV aerial.
If you do not wish to receive Freeview/Saorview, skip this step.
2
Outdoor Digital
TV Aerial
1.
2.
Fitting the stand
For the stand installation, there is one type of screw
provided as shown below.
To complete the stand installation you will require a
cross head screw driver.
Place the TV set on a flat and clean surface with the
panel facing downwards to avoid damage.
1
12
4 x
3
4
1
2
3
Used for attaching the stand
to the TV set (g.2)
4 x
TV panel must be facing downwards.
Place the TV set on a flat and clean surface with
the panel facing downwards to avoid damage.
When the stand feet are installed correctly the
stand feet will be longest at the front of the TV
and shortest at the back with the feet pointing
away from each other.
When the stand/feet are in the correct position, secure
the feet to the underside of the TV set using 4 screws
provided.
L
R
J
I
H
K
L
Register your manufacturers
guarantee online within
14 days of purchase at
www.registertoday.co.uk/sharp
and enter into a prize draw to
win a Sharp Soundbar
guarantee
online
within
1
4 days of purchase a
t
www.re
g
istertoday.co.uk/sharp
a
n
d
enter into a prize
d
raw t
o
win a S
h
ar
p
Soun
db
ar
Terms and conditions apply. Online registration only.
Back/Shortest
Front/Longest
M
N
Ethernet/LAN* Network connection
Digital Audio Digital Optical Audio Output
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
L/R HDMI input (ARC)
Video/YPbPr HD input (YPbPr)
SCART SCART input
SAT IN Satellite input
RF in RF / TV aerial input
HDMI 3 HDMI input
Earphones Earphone input
Service Input Input is used only by service centres
CI card in Common interface module
USB 2.0 USB port 2.0
* The Ethernet/LAN port is used for Freeview HD services and smart functions.
AH
L
K
BI
M
C
D
E
F
G
J
N
1 2
SCART
ETHERNET DIGITAL
AUDIO OUT
OPTICAL L R VIDEO/Y Pb Pr
AB
CD
E
F
Audio shared for Video/Composite
and component/ YPbPr
Video Input (green) and HD input
(Ypbpr)
G
LC-32FI6522KF SHA-QSW-0035.indd 2LC-32FI6522KF SHA-QSW-0035.indd 2 01/10/2018 13:42:4601/10/2018 13:42:46
