SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE.................................................................... i
LIST OF CHANGED PARTS (LC-32M44L)................ i
LIST OF CHANGED PARTS (LC-37M44L)............... ii
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY
PRECAUTION...........................................................iii
PRECAUTIONS A PRENDRE LORS DE LA
REPARATION .......................................................... iv
PRECAUTIONS FOR USING LEAD-FREE
SOLDER ................................................................... v
PRECAUTIONS IN SERVICING THE HDCP-
KEY ROM................................................................. vi
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS .................................................1-1
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL ..........................................2-1
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS ........................................................3-1
Parts Guide
TopPage
CONTENTS
In the interests of user-safety (Required by safety regulations in some countries) the set should
be restored to its original condition and only parts identical to those specified should be used.
LC-32M44L LC-37M44L
LCD COLOR TELEVISION
No. S48J1LC32M44L
LC-32/37M44L
LC-32M44L
LC-37M44L
MODELS
OUTLINE
This model is based on the LC-32/37D44U and is changed some parts. This Service Manual covers the modifications
alone. For the other points, refer to the LC-32D44U (No. SY7C1LC32D44U) and LC-37D44U (No. S18D7LC37D44U)
Service Manual.

LC-32/37M44L
i
LC-32/37M44L Service Manual
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
This model is based on the LC-32/37D44U and is changed some parts. This Service Manual covers the modifications alone. For the other points,
refer to the LC-32D44U (No. SY7C1LC32D44U) and LC-37D44U (No. S18D7LC37D44U) Service Manual.
LIST OF CHANGED PARTS (LC-32M44L)
Ref. No. Description LC-32D44U
(No. SY7C1LC32D44U)
LC-32M44L
(No. S48J1LC32M44L) Note
PRINTED WIRING BOARD ASSEMBLIES
R/C, LED Unit DUNTKE264FM02 ←Some parts changed
KEY Unit DUNTKE266FM02 ←—
MAIN Unit DUNTKE450FM01 DUNTKE450FM03 Some parts changed
POWER/INVERTER Unit RUNTKA397WJQZ RUNTKA419WJQZ —
LCD PANEL
LCD Panel Module Unit R1LK315T3GW20Z R1LK315T3GW30Z —
R/C, LED Unit
Q102 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q103 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q104 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q106 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q107 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
MAIN Unit
D1306 Photo Diode VHPGPFSV51T-1 VHPGPFSV51V-1 Change
D9003 Zener Diode RH-EX1234CEZZY — Delete
IC1604 IC VHiSii9185+-1Q VHiSii9185A-1Q Change
P2001 Plug QPLGN0060CEZZY — Delete
P9202 Plug QPLGNA144WJZZY — Delete
P9301 Plug QCNCWA562WJQZY — Delete
Q509 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q510 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q515 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q516 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q517 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q518 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q519 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q520 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q521 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q522 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q523 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q524 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q1101 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q1102 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q1307 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q2001 Transistor VSKRC404E++-1Y — Delete
Q5414 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q9301 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
R9209 Resistor VRS-CZ1JF470JY — Delete
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
PACKING PARTS AND ACCESSORIES
Please refer to a Parts list

LC-32/37M44L
ii
LIST OF CHANGED PARTS (LC-37M44L)
Ref. No. Description LC-37D44U
(No. S18D7LC37D44U)
LC-37M44L
(No. S48J1LC32M44L) Note
PRINTED WIRING BOARD ASSEMBLIES
R/C, LED Unit DUNTKE264FM02 ←Some parts changed
KEY Unit DUNTKE266FM02 ←—
MAIN Unit DUNTKE450FM01 DUNTKE450FM03 Some parts changed
POWER Unit RDENCA272WJQZ RDENCA270WJQZ —
INVERTER Unit RUNTKA418WJQZ ←—
LCD PANEL
LCD Panel Module Unit R1LK370T3GW20Z ←—
R/C, LED Unit
Q102 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q103 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q104 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q106 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q107 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
MAIN Unit
D1306 Photo Diode VHPGPFSV51T-1 VHPGPFSV51V-1 Change
D9003 Zener Diode RH-EX1234CEZZY — Delete
IC1604 IC VHiSii9185+-1Q VHiSii9185A-1Q Change
P2001 Plug QPLGN0060CEZZY — Delete
P9202 Plug QPLGNA144WJZZY — Delete
P9301 Plug QCNCWA562WJQZY — Delete
Q509 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q510 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q515 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q516 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q517 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q518 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q519 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q520 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q521 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q522 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q523 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q524 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q1101 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q1102 Transistor VS2SC3928AR-1Y VSKTC3875SG-1Y Change
Q1307 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q2001 Transistor VSKRC404E++-1Y — Delete
Q5414 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
Q9301 Transistor VS2SA1530AR-1Y VSKTA1504SG-1Y Change
R9209 Resistor VRS-CZ1JF470JY — Delete
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
PACKING PARTS AND ACCESSORIES
Please refer to a Parts list

LC-32/37M44L
iii
LC-32/37M44L Service Manual
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuit should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER (Fire &
Shock Hazard)
Before returning the receiver to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• Plug the AC cord directly into a 110-240 volt 50/60Hz AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15µF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a nonpolarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5 mA rms AC.) or
more is excessive and indicates a potential shock hazard which
must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by " " and shaded areas in the Replacement Parts List
and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
CAUTION: FOR CONTINUED PROTECTION
AGAINST A RISK OF FIRE REPLACE ONLY WITH
SAME TYPE FUSE.
F7101 (250V 6.3A)
F7102 (250V 1A)
F7103 (250V 6.3A)
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-32/37M44L
iv
PRECAUTIONS A PRENDRE LORS DE LA REPARATION
De nombreuses pièces, électriques et mécaniques, dans les télévi-
seur ACL présentent des caractéristiques spéciales relatives à la sé-
curité, qui ne sont souvent pas évidentes à vue. Le degré de protec-
tion ne peut pas être nécessairement augmentée en utilisant des
pièces de remplacement étalonnées pour haute tension, puissance,
etc.
Les pièces de remplacement qui présentent ces caractéristiques sont
identifiées dans ce manuel; les pièces électriques qui présentent ces
particularités sont identifiées par la marque " " et hachurées dans la
liste des pièces de remplacement et les diagrammes schématiques.
Pour assurer la protection, ces pièces doivent être identiques à celles
utilisées dans le circuit d'origine. L'utilisation de pièces qui n'ont pas
les mêmes caractéristiques que les pièces recommandées par l'usine,
indiquées dans ce manuel, peut provoquer des électrocutions, incen-
dies, radiations X ou autres accidents.
AVERTISSEMENT
1.
2.
3.
4.
5.
•
•
•
•
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux
conseils suivants.
N'entreprendre aucune modification de tout circuit. C'est danger-
eux.
Débrancher le récepteur avant toute réparation.
Inspecter tous les faisceaux de câbles pour s'assurer que les fils
ne soient pas pincés ou qu'un outil ne soit pas placé entre le châs-
sis et les autres pièces métalliques du récepteur.
Inspecter tous les dispositifs de protection comme les boutons de
commande non-métalliques, les isolants, le dos du coffret, les cou-
vercles ou blindages de réglage et de compartiment, les réseaux
de résistancecapacité, les isolateurs mécaniques, etc.
S'assurer qu'il n'y ait pas de danger d'électrocution en vérifiant la
fuite de courant, de la facon suivante:
Brancher le cordon d'alimentation directem-ent à une prise de cou-
rant de 110-240V 50/60Hz. (Ne pas utiliser de transformateur
d'isolation pour cet essai).
A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ
10 watts en parallèle avec un condensateur de 0.15µF en série
avec toutes les pièces métalliques exposées du coffret et une terre
connue comme une conduite électrique ou une prise de terre
branchée à la terre.
Utiliser un voltmètre CA d'une sensibilité d'au moins 5000Ω/V pour
mesurer la chute de tension en travers de la résistance.
Toucher avec la sonde d'essai les pièces métalliques exposées qui
présentent une voie de retour au châssis (antenne, coffret métalli-
que, tête des vis, arbres de commande et des boutons, écusson,
etc.) et mesurer la chute de tension CA en-travers de la résistance.
Toutes les vérifications doivent être refaites après avoir inversé la
fiche du cordon d'alimentation. (Si nécessaire, une prise
d'adpatation non polarisée peut être utilisée dans le but de termin-
er ces vérifications.)
La tension de pointe mesurèe ne doit pas dépasser 0.75V (corre-
spondante au courant CA de pointe de 0.5mA).
Dans le cas contraire, il y a une possibilité de choc électrique qui
doit être supprimée avant de rendre le récepteur au client.
PRECAUTION: POUR LA PROTECTION CON-
TINUE CONTRE LES RISQUES D'INCENDIE,
REMPLACER LE FUSIBLE
F7101 (250V 6.3A)
F7102 (250V 1A)
F7103 (250V 6.3A)
VERIFICATIONS CONTRE L'INCEN-DIE ET LE
CHOC ELECTRIQUE
Avant de rendre le récepteur à l'utilisateur, effectuer les vérifica-
tions suivantes.
DVM
ECHELLE CA
1.5k ohm
10W
0.15
µ F
SONDE D'ESSAI
AUX PIECES
METALLIQUES
EXPOSEES
BRANCHER A UNE
TERRE CONNUE
AVIS POUR LA SECURITE

LC-32/37M44L
v
PRECAUTIONS FOR USING LEAD-FREE SOLDER
Employing lead-free solder
• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The
alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
Indicates lead-free solder of tin, silver and copper. Indicates lead-free solder of tin, silver and copper.
PARTS CODE PRICE
RANK
PART
DELIVERY DESCRIPTION
ZHNDAi123250E BL J φ0.3mm 250g (1roll)
ZHNDAi126500E BK J φ0.6mm 500g (1roll)
ZHNDAi12801KE BM J φ1.0mm 1kg (1roll)

LC-32/37M44L
vi
PRECAUTIONS IN SERVICING THE HDCP-KEY ROM
The HDCP-KEY ROM shall be protected and managed for its information inside. In servicing this ROM, therefore, take the following information pro-
tection/management measures.
1) When disposing of the component parts and PWBs, destruct the IC itself in a proper way.
(For repairing or replacing the component parts and PWBs as well as clearing those in stock)
2) In storing the component parts, protect and manage them against theft and disclosure.
(For storing the service parts, service units, etc.)
Applied part: HDCP-KEY ROM
IC8451 RH-IXC373WJQZY (updated ROM)

LC-32/37M44L
1 – 1
LC-32/37M44L Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: LC-32M44L Model: LC-37M44L
LCD panel
32" screen size class Advanced Super
View & BLACK TFT LCD
(Diagonal Measurement : 311/2")
37" screen size class Advanced Super
View & BLACK TFT LCD
(Diagonal Measurement : 37")
Resolution 1,049,088 pixels (1,366 768)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable*
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W 2
Terminals Rear
INPUT 1 AV in, COMPONENT in
INPUT 2 AV in, S-VIDEO in
INPUT 3 COMPONENT in
INPUT 4 HDMI in with HDCP
INPUT 5 Audio in, HDMI in with HDCP
INPUT 6 15-pin mini D-sub female connector, Audio in (Ø 3.5 mm jack)
ANT/CABLE 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
DIGITAL AUDIO OUTPUT Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
SERVICE Software update
OSD language English/French/Spanish
Power Requirement AC 110-240 V, 50/60 Hz
Power Consumption 140 W (0.9 W Standby) 172 W (0.9 W Standby)
Weight TV + stand 29.8 lbs./13.5 kg 35.3 lbs./16.0 kg
TV only 25.4 lbs./11.5 kg 30.9 lbs./14.0 kg
Dimension
(W H D)
TV + stand 30 9/16 22 41/64 91/16 inch 35 19/32 25 3/32 91/16 inch
TV only 30 9/16 20 19/32 345/64 inch 35 19/32 23 1/32 33/4inch
Operating temperature 32°F to 104°F (0°C to 40°C)
* Emergency alert messages via Cable are unreceivable.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.

LC-32/37M44L
2 – 1
LC-32/37M44L Service Manual
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
Part Names
TV (Front)
OPC indicator
POWER indicator
OPC sensor
Remote control sensor
SLEEP indicator
TV (Top/Rear)
POWER button
INPUT button
MENU button
Channel buttons
(CH /)
Volume buttons
(VOL /)
AC INPUT terminal
DIGITAL AUDIO OUTPUT terminal
INPUT 4 terminal (HDMI)
INPUT 5 terminals (HDMI)
INPUT 6 terminals (PC-IN)
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
AUDIO OUTPUT terminals
SERVICE terminal
INPUT 3 terminals
The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
The examples used throughout this manual are based on the LC-32M44L model.

LC-32/37M44L
2 – 2
11
17
19
12
13
14
15
16
20
21
22
18
3
2
7
6
1
4
5
8
10
9
Part Names
Remote Control Unit
1 POWER: Switch the TV power on or enters
standby.
2 CC: Display captions from a closed-caption
source.
3 AUDIO: Selects the MTS/SAP or the audio mode
during multi-channel audio broadcasts.
40
_9: Set the channel.
5(DOT):
6 FLASHBACK: Return to the previous channel or
external input mode.
7 VIEW MODE: Select the screen size.
8 FREEZE: Set the still image. Press again to return
to normal screen.
9///,ENTER: Select a desired item on the
screen.
10 EXIT: Turn off the menu screen.
11 DISPLAY: Display the channel information.
12 SLEEP: Set the sleep timer.
13 AV MODE: Select an audio or video setting.
(When the input source is TV, INPUT 1, 2 or 3:
STANDARD, MOVIE, GAME, USER, DYNAMIC
(Fixed), DYNAMIC. When the input source is INPUT
4, 5 or 6: STANDARD, MOVIE, GAME, PC, USER,
DYNAMIC (Fixed), DYNAMIC)
14 MUTE: Mute the sound.
15 VOL /:Set the volume.
16 CH /:Select the channel.
17 ENT: Jumps to a channel after selecting with the
0_9buttons.
18 INPUT: Select a TV input source. (TV, INPUT 1,
INPUT 2, INPUT 3, INPUT 4, INPUT 5, INPUT 6)
19 PC: Quickly access to PC mode.
20 MENU: Display the menu screen.
21 RETURN: Return to the previous menu screen.
22 FAVORITE CH
A,B,C,D: Select 4 preset favorite channels in 4
different categories.
While watching, you can toggle the selected
channels by pressing A, B, C and D.
When using the remote control unit, point it at the TV.

LC-32/37M44L
2 – 3
1
2
Screws
Hex key
Soft cushion
Attaching/Detaching the Stand
Before attaching (or detaching) the stand, unplug the AC
cord from the AC INPUT terminal.
Before performing work spread cushioning over the base
area to lay the TV on. This will prevent it from being
damaged.
CAUTION
Attach the stand in the correct direction.
Do not remove the stand from the TV unless using an
optional wall mount bracket to mount it.
Be sure to follow the instructions. Incorrect installation
of the stand may result in the TV falling over.
1Confirm that there are 9 screws and a hex key
supplied with the stand unit.
2Attach the supporting post for the stand unit onto
the base using the box for the stand unit as shown
below.
Setting the TV on the Wall
CAUTION
This TV should be mounted on the wall only with the
AN-37AG5 (SHARP) wall mount bracket. The use of
other wall mount brackets may result in an unstable
installation and may cause serious injuries.
Installing the TV requires special skill that should
only be performed by qualified service personnel.
Customers should not attempt to do the work
themselves. SHARP bears no responsibility for
improper mounting or mounting that results in
accident or injury.
Using an optional bracket to mount the TV
You can ask a qualified service professional about
using an optional AN-37AG5 bracket to mount the TV
to the wall.
Carefully read the instructions that come with the
bracket before beginning work.
QUICK REFERENCE
Vertical mounting Angular mounting
Hanging on the wall
AN-37AG5 wall mount bracket.
(See the bracket instructions for details.)
About setting the TV angle
0/5/10/15/20q
LC-32M44L
The center of the display:
11/64
inch (4.0 mm) under
the "A" position.
LC-37M44L
The center of the display:
1/4
inch (6.0 mm) above
the "A" position.
Refer to the operation
manual of AN-37AG5 for
details.
3
Ԙ
Insert the stand into the openings on the bottom
of the TV.
ԙ
Insert and tighten the 4 screws into the 4 holes
on the rear of the TV.
To detach the stand, perform the steps in reverse order.
Detach the cable clamp on the rear of the TV when using
the optional mount bracket.
Due to the terminal configuration on this TV, when you
wall-mount this model, make sure there is enough space
between the wall and the TV for the cables.
To use this TV mounted on a wall, first remove the
adhesive tape at the 4 locations on the rear of the TV, and
then use the screws supplied with the wall mount bracket
to secure the bracket to the rear of the TV.
2
3
1
Hex key
Screws

LC-32/37M44L
2 – 4
Troubleshooting
Possible Solution
Is the volume too low?
Is "Variable" selected in "Output Select"?
Have you pressed MUTE on the remote control unit?
Cautions regarding use in high and low temperature environments
Appendix
Problem
No power
Unit cannot be operated.
Remote control unit does not
operate.
Picture is cut off/with sidebar
screen.
Strange color, light color, or color
misalignment
Power is suddenly turned off.
No picture
No sound
Check if you pressed POWER on the remote control unit.
If the indicator on the TV does not light up, press POWER on the TV.
Is the AC cord disconnected?
Has the power been turned on?
External influences such as lightning, static electricity, may cause improper operation.
In this case, operate the unit after first turning off the power of the TV or unplugging
the AC cord and replugging it in after 1 or 2 minutes.
Are batteries inserted with polarity ( , ) aligned?
Are batteries worn out? (Replace with new batteries.)
Are you using it under strong or fluorescent lighting?
Is a fluorescent light illuminated near the remote control sensor?
Is the image position correct?
Are screen mode adjustments such as picture size made correctly?
Adjust the picture tone.
Is the room too bright? The picture may look dark in a room that is too bright.
Check the input signal setting.
Is the sleep timer set?
Check the power control settings.
The unit's internal temperature has increased. Remove any objects blocking vent or
clean.
Is connection to other components correct?
Is correct input signal source selected after connection?
Is the correct input selected?
Is picture adjustment correct?
Is "On" selected in "Audio Only"?
Is a non-compatible signal being input?
When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed.
This is not a malfunction, and the unit will recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a
heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: 4°F to 140°F ( 20°C to 60°C)
Troubleshooting-Digital Broadcasting
The error message about reception of broadcast
Failed to receive broadcast.
E203 Check the broadcast time in the program guide.
The example of an error message
displayed on a screen
No broadcast now.
Error code
E202
Possible Solution
Check the antenna cable. Check that the antenna is correctly
setup.
This is not a malfunction. This happens when the cabinet slightly expands and
contracts according to change in temperature. This does not affect the TV's
performance.
The TV sometimes makes a
cracking sound.

LC-32/37M44L
2 – 5
PC Compatibility Chart
It is necessary to set the PC correctly to display XGA and WXGA signal.
DDC is a registered trademark of Video Electronics Standards Association.
VGA and XGA are registered trademarks of International Business Machines Corp.
PC
31.5 kHz
31.5 kHz
37.9 kHz
37.5 kHz
35.1 kHz
37.9 kHz
48.1 kHz
46.9 kHz
48.4 kHz
56.5 kHz
60.0 kHz
47.7 kHz
640 x 480
720 x 400
VGA
800 x 600SVGA
XGA 1024 x 768
WXGA 1360 x 768
70 Hz
60 Hz
72 Hz
75 Hz
56 Hz
60 Hz
72 Hz
75 Hz
60 Hz
70 Hz
75 Hz
60 Hz
O
O
O
O
O
O
O
O
O
O
O
*
*
*
*These 3 formats are not supported by the analog RGB terminal.
PC Horizontal Frequency VESA StandardResolution Vertical Frequency

LC-32/37M44L
3 – 1
LC-32/37M44L Service Manual
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS
77/8(200)
91/16 (230)
259/64
(74)
345/64
(94)
30 Unit: inch (mm)
Unit: inch (mm)
9/16 (776)
15 27/32 (402)
27 17/32 (699.2)
15 1/2
(393.8)
13 5/64
(332)
21/16
(52)
22 41/64 (575)
20 19/32 (523)
77/8(200) 411/32
(110)
LC-32M44L
77/8(200)
77/8
(200) 361/64
(100)
91/16 (230)
225/32
(71)
33/4
(95)
14 29/64 (367)
35 19/32 (904)
21/16
(52) 23 1/32 (585)
32 15/32 (824.4)
18 17/64
(463.8)
15 27/32 (402)
25 3/32 (637)
LC-37M44L

PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32/37M44L
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
No. S48J1LC32M44L
LC-32M44L
LC-37M44L
MODELS
PartsGuide
[1] PRINTED WIRING BOARD ASSEMBLIES
[2] LCD PANEL (NOTE: THE PARTS HERE
SHOWN ARE SUPPLIED AS AN ASSEMBLY
BUT NOT INDEPENDENTLY.)
[3] DUNTKE264FM02 (R/C, LED Unit)
[4] DUNTKE450FM03 (MAIN Unit)
[5] NOTE (Conductive cloth tape/Gasket)
(LC-32M44L)
[6] CABINET AND MECHANICAL PARTS
(LC-32M44L)
[7] NOTE (Conductive cloth tape/Gasket)
(LC-37M44L)
[8] CABINET AND MECHANICAL PARTS
(LC-37M44L)
[9] SUPPLIED ACCESSORIES
[10] PACKING PARTS (NOT REPLACEMENT ITEM)
[11] SERVICE JIG (USE FOR SERVICING)

LC-32/37M44L
2
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
NDUNTKE264FM02 AP X R/C, LED Unit
NDUNTKE266FM02 AG X KEY Unit
NDUNTKE450FM03 CD N R MAIN Unit
NRDENCA270WJQZ BQ N X POWER Unit (LC-37M44L)
NRUNTKA418WJQZ BN N X INVERTER Unit (LC-37M44L)
NRUNTKA419WJQZ BU N X POWER/INVERTER Unit (LC-32M44L)
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
NR1LK315T3GW30Z CW N J 32"LCD Panel Module Unit (LC-32M44L)
NR1LK370T3GW20Z EC N J 37"LCD Panel Module Unit (LC-37M44L)
[3] DUNTKE264FM02 (R/C, LED Unit)
Q102 VSKTC3875SG-1Y AB J Transistor
Q103 VSKTC3875SG-1Y AB J Transistor
Q104 VSKTC3875SG-1Y AB J Transistor
Q106 VSKTC3875SG-1Y AB J Transistor
Q107 VSKTC3875SG-1Y AB J Transistor
[4] DUNTKE450FM03 (MAIN Unit)
D1306 VHPGPFSV51V-1 AG N R Photo Diode
IC1604 VHISII9185A-1Q AN J IC, SII9185ACTU
Q509 VSKTA1504SG-1Y AA N R Transistor
Q510 VSKTC3875SG-1Y AB J Transistor
Q515 VSKTA1504SG-1Y AA N R Transistor
Q516 VSKTA1504SG-1Y AA N R Transistor
Q517 VSKTA1504SG-1Y AA N R Transistor
Q518 VSKTA1504SG-1Y AA N R Transistor
Q519 VSKTA1504SG-1Y AA N R Transistor
Q520 VSKTA1504SG-1Y AA N R Transistor
Q521 VSKTA1504SG-1Y AA N R Transistor
Q522 VSKTA1504SG-1Y AA N R Transistor
Q523 VSKTA1504SG-1Y AA N R Transistor
Q524 VSKTA1504SG-1Y AA N R Transistor
Q1101 VSKTC3875SG-1Y AB J Transistor
Q1102 VSKTC3875SG-1Y AB J Transistor
Q1307 VSKTA1504SG-1Y AA N R Transistor
Q5414 VSKTA1504SG-1Y AA N R Transistor
Q9301 VSKTA1504SG-1Y AA N R Transistor

LC-32/37M44L
3
[5] NOTE (Conductive cloth tape/Gasket) (LC-32M44L)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[5] NOTE (Conductive cloth tape/Gasket) (LC-32M44L)
1PSLDMB359WJZZ AG N X Conductive Cloth Tape
2PSLDMB360WJZZ AE N X Conductive Cloth Tape, x2
3QEARZA123WJZZ AD X Conductive Cloth Tape, x3
4PSLDMB361WJZZ AC N X Conductive Cloth Tape, x2
5PSLDMB362WJZZ AC N X Conductive Cloth Tape, x2
6PMLT-A533WJZZ AD N X Gasket
7PMLT-A534WJZZ AC N X Gasket
8ZSLCN-098P2KE BH J One 150g tube
Attention
When peeling off the conductive cloth tape/gasket for repair, please use the NEW conductive cloth tape/gasket. (When using
the conductive cloth tape/gasket again, keep in mind the decrease in the adhesive power of the conductive cloth tape/gasket.
The purpose of using the NEW conductive cloth tape/gasket is to prevent the conductive cloth tape/gasket from peeling off.)
Added parts
Conductive Cloth Tape
˴Parts code: ԘPSLDMB359WJZZQ'ty 1 ԙPSLDMB360WJZZQ'ty 2
ԚQEARZA123WJZZQ'ty 3 ԛPSLDMB361WJZZQ'ty 2
ԜPSLDMB362WJZZQ'ty 2
Gasket
˴Parts code: ԝPMLT-A533WJZZQ'ty 1 ԞPMLT-A534WJZZQ'ty 1
Bond
˴Parts code: ԟZSLCN-098P2KE (One 150g tube)
MAIN Unit
Main PWB Holder
Main PWB Holder
RA wire
5
5
4
4
7
6
81
Apply bond to
1 location.
Apply bond to
1 location. Apply bond to
1 location.
8
8
2
2
Apply bond to
1 location.
LCD Panel Module
Back Light Chassis
8
SP wire
3
Main Shield
3
3

LC-32/37M44L
4
[6] CABINET AND MECHANICAL PARTS (LC-32M44L)
29
14
5
1-3
2-2 41
2-1
2
3
6
46
42
27
39
1-8
1-2
7
30
1-4
1-6
1-6
1
1-5
1-1
1-5
1-7
1-7
42
44
34
33
37
37
46
24
12
12
17
17
50
50
51
51
28
46
45
21
21
9
45 48
49
49
53
20
40
26
45
25
22
23
45
45
4
8
45
45
43
10
11
45
14
45
45
35
18
16
13
19
10
KEY Unit
11
45
43
43
43
36
36
POWER/INVERTER Unit
MAIN Unit
15
47
47-2 47-3
47-1
47-3
35
35
31
R/C, LED Unit
38
38
32

LC-32/37M44L
5
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[6] CABINET AND MECHANICAL PARTS (LC-32M44L)
1CCABAB985WJ34 BM N X Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - Decoration Plate (Center)
1-3 Not Available - N - LED Decoration
1-4 HPNLSA172WJKA AR N X Speaker Net
1-5 PSPAHB406WJZZ AC N X Spacer, x2
1-6 PSPAHB407WJZZ AC N X Spacer, x2
1-7 Not Available - N - SP Spacer, x2
1-8 XJPSN30P08XS0 AA J Screw, x3
2CCABBB237WJK1 BH N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPC686WJSA AG N X Terminal Label
3R1LK315T3GW30Z CW N J 32"LCD Panel Module Unit
4GCOVAC612WJ3A AK N X Bottom Cover
5HINDPB715WJSA AF X Terminal Label
6HINDPC873WJSA AE N X Model Label
7JBTN-A718WJ3A AF N X Operation Button
8LANGKB343WJZZ AR N X Stand Fix Angle
9LANGKB346WJFW AH N X Heat Sink Fix Angle
10 LANGKB364WJFW AC N X LCD Fix Angle-A, x2
11 LANGKB365WJFW AC N X LCD Fix Angle-B, x2
12 LANGTA476WJZZ AQ N X VESA Angle, x2
13 LHLDWA133WJKZ AC J Wire Holder
14 LHLDWA143WJKZ AC J Wire Holder, x2
15 LHLDWA151WJKZ AB J Wire Holder
16 LHLDWA175WJUZ AC J Wire Holder, x4
17 LHLDZA928WJ3Z AG N X Main PWB Holder, x2
18 LHLDZA933WJKZ AB N J Wire Holder
19 LHLDZA934WJKZ AB N J Wire Holder
20 NSFTZ0134CEFW AD J Shaft, x2
21 PCLICA004WJKZ AC J Rivet, x4
22 PMLT-A534WJZZ AC N X Gasket
23 PMLT-A533WJZZ AD N X Gasket
24 PRDARA495WJFW AH X Heat Sink
25 PRDARA510WJFW AR X Heat Sink
26 PSLDMB275WJZZ AQ N X Main Shield
27 PSPAKA237WJ00 AA X Spacer, x4
28 PSPAZB086WJKZ AD J Spacer, x2
29 PSPAZA917WJKZ AH J Cool Sheet
30 QCNW-G724WJQZ AF N X Connecting Cord (KEY - MAIN)
31 QCNW-G725WJQZ AK N X Connecting Cord (LED - MAIN)
32 QCNW-H283WJPZ AL N X Connecting Cord (SP - MAIN)
33 QCNW-G727WJQZ AK N X Connecting Cord (POWER - MAIN)
34 QCNW-G728WJQZ AG N X Connecting Cord (INV - MAIN)
35 QEARZA123WJZZ AD X Conductive Cloth Tape, x3
36 QPWBME512WJPZ AN N X Connecting Cord (LCD-FPC-MAIN), x2
37 RCORFA061WJZZ AG J Core, x2
38 RSP-ZA310WJZZ AQ N X Speaker (L/R), x2
39 Not Available - - No. Label
40 XBPS830P06000 AA J Screw (for HDMI), x2
41 XEBS930P10000 AA J Screw (for S-Terminal)
42 XEBS940P16000 AB J Screw (for CAB A B), x6
43 XEBSN40P10000 AB J Screw (for CAB A Panel), x4
44 XHPS730P16WS0 AB N J Screw (for MAIN PWB2), x4
45 XHPS830P06WS0 AA N J Screw (for MAIN PWB), x30
46 XHPS830P10WS0 AB J Screw (for CAB B Chassis), x3/(for MAIN PWB2), x2
47 CDAI-A441WJ03 BF N X Stand Unit
47-1 Not Available - N - Stand Base Ass'y
47-2 Not Available - N - Stand Support Ass'y
47-3 Not Available - N - Screw (for Stand), x9
48 PSLDMB359WJZZ AG N X Conductive Cloth Tape
49 PSLDMB360WJZZ AE N X Conductive Cloth Tape, x2
50 PSLDMB361WJZZ AC N X Conductive Cloth Tape, x2
51 PSLDMB362WJZZ AC N X Conductive Cloth Tape, x2
52 ZSLCN-098P2KE BH J One 150g tube
53 TLABK0023TAZZ AA N J Tray Label

LC-32/37M44L
6
[7] NOTE (Conductive cloth tape/Gasket) (LC-37M44L)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY DESCRIPTION
[7] NOTE (Conductive cloth tape/Gasket) (LC-37M44L)
1PSLDMB359WJZZ AG N X Conductive Cloth Tape
2PSLDMB360WJZZ AE N X Conductive Cloth Tape
3PSLDMB276WJKZ AE X Conductive Cloth Tape
4PSLDMB375WJKZ AF N X Conductive Cloth Tape
5QEARZA123WJZZ AD X Conductive Cloth Tape
6PSLDMB361WJZZ AC N X Conductive Cloth Tape, x2
7PSLDMB362WJZZ AC N X Conductive Cloth Tape, x2
8PMLT-A533WJZZ AD N X Gasket
9PMLT-A534WJZZ AC N X Gasket
10 ZSLCN-098P2KE BH J One 150g tube
Attention
When peeling off the conductive cloth tape/gasket for repair, please use the NEW conductive cloth tape/gasket. (When using
the conductive cloth tape/gasket again, keep in mind the decrease in the adhesive power of the conductive cloth tape/gasket.
The purpose of using the NEW conductive cloth tape/gasket is to prevent the conductive cloth tape/gasket from peeling off.)
Added parts
Conductive Cloth Tape
˴Parts code: ԘPSLDMB359WJZZQ'ty 1 ԙPSLDMB360WJZZQ'ty 1
ԚPSLDMB276WJKZQ'ty 1 ԛPSLDMB375WJKZQ'ty 1
ԜQEARZA123WJZZQ'ty 1 ԝPSLDMB361WJZZQ'ty 2
ԞPSLDMB362WJZZQ'ty 2
Gasket
˴Parts code: ԟPMLT-A533WJZZQ'ty 1 ԠPMLT-A534WJZZQ'ty 1
Bond
˴Parts code: ԡZSLCN-098P2KE (One 150g tube)
Main Shield
RA wire
SP wire
MAIN Unit
Main PWB Holder
Main PWB Holder
Apply bond to
1 location.
Apply bond to
1 location.
Apply bond to
1 location.
Apply bond to
1 location.
Apply bond to
2 locations.
10
10
1
10
2
3
10
10
4
5
7
7
6
6
9
8
