Sharp AQUOS LC-42PD7X User manual

MODEL
LC-42PD7X
LCD COLOUR TELEVISION
OPERATION MANUAL
Cover_42PD7X.indd 1Cover_42PD7X.indd 1 2007/01/12 15:52:312007/01/12 15:52:31

Password

1
LC-42PD7X
OPERATION MANUAL
LCD COLOUR TELEVISION
Dear SHARP customer
Dear SHARP customer........................................... 1
Contents.................................................................. 1
Trademarks............................................................. 2
Important Safety Precautions ............................... 3
Supplied accessories............................................. 4
Preparation ............................................................. 5
Inserting the batteries ......................................... 5
Using the remote control unit.............................. 5
Cautions regarding remote control unit........... 5
Attaching the stand............................................. 6
Setting the TV..................................................... 7
Setting the TV on the wall ................................... 8
Removing the stand............................................ 8
Basic connection ................................................ 9
Connecting to an antenna .............................. 9
Connecting to the AC outlet ........................... 9
Connecting a VCR, game console or
camcorder ..................................................... 10
Connecting a DVD player ................................. 10
Connecting a PC .............................................. 11
Part names .............................................................12
TV (Front)...........................................................12
TV (Rear)............................................................13
Remote control unit ...........................................14
Watching TV...........................................................15
Turning on the power.........................................15
Turning off the power.........................................15
Simple button operations for changing
channels..........................................................15
Using Flashback (A) on the remote
control unit ......................................................16
Using MPX on the remote control unit................16
Simple button operation for changing
volume/sound .................................................17
Sleep timer ........................................................17
ANALOG/DTV/RADIO buttons ...........................18
Basic adjustment settings ....................................19
Menu operation buttons.....................................19
On-Screen Display.............................................19
Menu items (TV/DTV/INPUT1-2) ........................20
Menu items (HDMI/DVI)......................................20
Auto installation .................................................21
Programme setup..............................................21
Auto search...................................................21
Manual setting for each channel ....................22
Search tuning ...........................................22
Fine tuning................................................22
Colour system ..........................................23
Sound system (Broadcasting system) ...... 23
Labelling channels ....................................23
Skipping channels ................................... 24
Setting the child lock ................................24
Password setting for child lock
(for TV/DTV input mode) See page 39.
Sort.............................................................. 24
Erase Programme ........................................ 25
AV MODE selection .......................................... 26
OPC (Optical Picture Control) setting ................ 26
Picture adjustments .......................................... 27
Advanced ......................................................... 28
Colour temperature ...................................... 28
Black.............................................................28
3D-Y/C ........................................................ 28
Monochrome ................................................29
Film Mode .................................................... 29
Range of OPC.............................................. 29
Audio adjustment.............................................. 30
Surround...................................................... 30
Power Control ...................................................31
Contents
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of
trouble-free operation of your product, please read the Important Safety Precautions carefully before
using this product.
42PD7X_en_a.indd 142PD7X_en_a.indd 1 2007/01/12 15:44:592007/01/12 15:44:59

2
Contents
• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
Trademarks
Basic adjustment settings (Digital)......................32
DTV input mode menu items..............................32
Selecting DTV mode ..........................................32
Programme Guide .............................................33
Info ....................................................................33
Favourite Programme List ..................................33
Programme List .................................................34
Favourite & Lock................................................34
Parental Rate.....................................................34
Installation .........................................................35
Auto Search.......................................................35
Manual Adjust....................................................35
Quick Search.....................................................36
Reset Data.........................................................36
Video Setup.......................................................36
Digital Output.....................................................37
Multilingual.........................................................37
Time Setup ........................................................37
I-Plate Setup (Information Plate Setup)...............38
Information ........................................................38
S/W Update (SERVICE ONLY) ...........................38
Useful adjustment settings.................................. 39
Password setting for child lock
(for TV/DTV input mode) ................................ 39
Input Skip ..........................................................40
Input Signal (PC input mode only) ......................40
Auto Sync. adjustment (PC input mode only) .....41
Fine Sync. adjustment (PC input mode only) ......41
Input Label........................................................ 42
Image position .................................................. 42
Wide Screen Signalling (WSS)............................43
Picture aspect ratio........................................... 43
Standby Mode...................................................44
Reset.................................................................44
WIDE mode (for TV/AV input mode) .................. 45
WIDE mode (for PC input mode) ....................... 46
Audio Only........................................................ 47
DNR (Digital Noise Reduction)........................... 47
HDMI Setup...................................................... 47
Language setting for on-screen display............. 48
Identification ......................................................48
Colour system setting ....................................... 48
Using external equipment.................................... 49
Displaying an external equipment image .......... 49
Displaying a DVD image (Example) ................... 49
Input Select .......................................................49
Useful features ..................................................... 50
Teletext function ............................................... 50
Teletext language setting .................................. 52
Freezing images................................................ 52
Appendix ............................................................... 53
Troubleshooting................................................ 53
Troubleshooting (DTV) .......................................53
RS-232C port specifications ............................. 54
PC compatibility chart....................................... 55
Specifications ................................................... 56
Optional accessories ........................................ 56
Dimensional drawings.......................................... 57
• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
42PD7X_en_a.indd 242PD7X_en_a.indd 2 2007/01/12 15:45:002007/01/12 15:45:00

3
Important Safety Precautions
• Cleaning — Unplug the AC cord
from the AC outlet before cleaning
the product. Use a damp cloth to
clean the product. Do not use liquid
cleaners or aerosol cleaners.
• Water and moisture — Do not use
the product near water, such as
bathtub, washbasin, kitchen sink,
laundry tub, swimming pool and in a
wet basement.
• Do not place vases or any other
water-filled containers on this
product.
The water may spill onto the product
causing fire or electric shock.
• Stand — Do not place the product
on an unstable cart, stand, tripod
or table. Doing so can cause the
product to fall, resulting in serious
personal injuries as well as damage
to the product. Use only a cart,
stand, tripod, bracket or table
recommended by the manufacturer
or sold with the product. When
mounting the product on a wall, be
sure to follow the manufacturer's
instructions. Use only the mounting
hardware recommended by the
manufacturer.
• When relocating the product
placed on a cart, it must be moved
with utmost care. Sudden stops,
excessive force and uneven floor
surface can cause the product to fall
from the cart.
• Ventilation — The vents and other
openings in the cabinet are designed
for ventilation. Do not cover or block
these vents and openings since
insufficient ventilation can cause
overheating and/or shorten the life
of the product. Do not place the
product on a bed, sofa, rug or other
similar surface, since they can block
ventilation openings. This product is
not designed for built-in installation;
do not place the product in an
enclosed place such as a bookcase
or rack, unless proper ventilation
is provided or the manufacturer's
instructions are followed.
• The LCD panel used in this product
is made of glass. Therefore, it can
break when the product is struck
forcefully or with a sharp object. If
the LCD panel is broken, be careful
not to be injured by broken glass.
• Heat sources — Keep the product
away from heat sources such as
radiators, heaters, stoves and other
heat-generating products (including
amplifiers).
• To prevent fire, never place any type
of candle or naked flames on the
top or near the TV set.
• To prevent fire or shock hazard, do
not place the AC power cord under
the TV set or other heavy items.
• Do not place heavy objects on this
product or stand on it. Doing so
could cause injury if the product
overturns. Take special care near
children and pets.
The LCD panel is a very high technology product
with 6,220,800 thin film transistors, giving you fine
picture details.
Due to the very large number of pixels, occasionally
a few non-active pixels may appear on the screen
as a fixed point of blue, green or red.
This is within product specifications and does not
constitute a fault.
Precautions when
transporting the TV
Be sure to always carry the TV
by two people holding it with two
hands — one hand on each side
of the TV.
• Do not display a still picture for a long time, as this could
cause an afterimage to remain.
• Install the product on the place where the AC cord can
be unplugged easily from the AC outlet, or from the AC
INPUT terminal on the rear of the product.
42PD7X_en_a.indd 342PD7X_en_a.indd 3 2007/01/12 15:45:002007/01/12 15:45:00

Supplied accessories
4
Make sure the following accessories are provided with the product.
Remote control unit “AAA” size battery (g2) AC cord
AC cord clamp Cable clamp
Operation manualStand unit
Page 14 Page 5 Page 7
Page 7 Page 7
Page 6
Stand base
Stand post
Short screws (g4)
Long screws
(g4)
NOTE
• Always use the AC cord supplied with the TV.
• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from the
actual operations.
Hex key
Cable tie
Page 7
Cloth
42PD7X_en_a.indd 442PD7X_en_a.indd 4 2007/01/12 15:45:042007/01/12 15:45:04

30°30°
5
Preparation
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you find any
chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.
Remote control
sensor
1 Open the battery cover.
• Place batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
2Insert two supplied “AAA” size
batteries.
3Close the battery cover.
5 m
Inserting the batteries
Before using the TV for the first time, insert two “AAA” size batteries (supplied). When the batteries become
depleted and the remote control fails to operate, replace the batteries with new “AAA” size batteries.
Using the remote control unit
Use the remote control unit by pointing it towards the
remote sensor window.
Objects between the remote control unit and sensor
window may prevent proper operation.
Cautions regarding remote control unit
• Do not subject the remote control unit to shock.
In addition, do not soak the remote control unit with liquids, or place it in an
area with high humidity.
• Do not install or place the remote control unit under direct sunlight.
The heat may cause deformation of the unit.
• The remote control unit may not work properly if the remote sensor window
of the TV is under direct sunlight or strong lighting. In such case, change the
angle of the lighting or TV, or operate the remote control unit closer to the
remote sensor window.
42PD7X_en_a.indd 542PD7X_en_a.indd 5 2007/01/12 15:45:072007/01/12 15:45:07

6
Preparation
1 3 1Insert the stand into the openings on the
bottom of the TV.
2Insert and tighten the 4 long screws into
the 4 holes on the rear of the TV.
Hex key
Long screw
Soft cushion
NOTE
• To detach the stand, perform the steps in reverse order.
2
Hex key
Short screw
Attach the supporting post for the stand unit
onto the base using the box for the stand unit
as shown below.
Confirm the 8 screws supplied with the TV.
Attaching the stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Short screws (g4)
(used in step 2)
Long screws (g4)
(used in step 3)
42PD7X_en_a.indd 642PD7X_en_a.indd 6 2007/01/12 15:45:112007/01/12 15:45:11

Preparation
7
1
AC cord
Connecting the AC cord, antenna, and external equipment to the TV
AC outlet
See pages 9 to 11 for
connecting antennas and
external equipment, such
as VCR and DVD player.
• Place the TV close to the AC outlet, and keep the power plug within reach.
Setting the TV
Notes on installing the TV
• Avoid direct sunlight and place the TV in a well-ventilated location.
• Place the TV in a level location.
Cable clamp
CAUTION
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE
AC CORD CONNECTED.
Bundling the cables
Insert the cable clamp in the hole on the TV as shown.
2
AC cord clamp
TV (rear view)
Cable tie
42PD7X_en_a.indd 742PD7X_en_a.indd 7 2007/01/12 15:45:142007/01/12 15:45:14

Removing the stand
For wall mounting with the optional bracket, remove the stand.
Before detaching/attaching the stand
• Before detaching (or attaching) the stand, unplug the AC cord from the AC outlet.
• Remove all terminal covers and connected cables.
• Lay the TV down on cushioning (such as a blanket) over a table.
• Make sure two or more people perform the operation.
CAUTION
• Do not remove the stand from the TV unless using an optional bracket to mount it.
Preparation
Setting the TV on the wall
• You can mount the TV on the wall, using the optional AN-37AG2/AN-52AG1 bracket.
• For details, refer to the instructions supplied with the optional bracket.
CAUTION
• This TV should be mounted on the wall only with the AN-37AG2/AN-52AG1 (SHARP) wall mount bracket. The use
of other wall mount brackets may result in an unstable installation and may cause serious injuries.
• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service
personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.
Using an optional bracket to mount the TV
• You can ask a qualified service personnel about using an optional AN-37AG2/AN-52AG1 bracket to mount the TV to the wall.
• Carefully read the instructions that come with the bracket before beginning work.
NOTE
• Detach the cable clamps on the rear of the TV when using the optional mount bracket.
1
2
8
NOTE
• To attach the stand, perform the above steps in reverse order.
Hanging on the wall
AN-37AG2/AN-52AG1 wall mount bracket.
(See the bracket instructions for details.)
Vertical mounting Angular mounting
12
About setting the TV angle and height adjustment
10°/5°/10°/15°/20°
2-5/0/+5 cm
(can be moved 5 cm
up or down)
Unfasten the four screws used to secure the stand
in place.
Detach the stand from the TV.
(Hold the stand so it will not drop from the edge of
the base area.)
AN-37AG2 AN-52AG1
0° or 5° For AN-52AG1
Hey key
42PD7X_en_a.indd 842PD7X_en_a.indd 8 2007/01/12 15:45:162007/01/12 15:45:16

9
Preparation
Simple operations for watching a TV programme
Basic connection
Connecting to an antenna
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for coaxial cable.
Standard DIN45325 plug (IEC169-2)
75-ohm coaxial cable (round cable)
Room antenna terminal
(75-ohm type)
Antenna cable
(commercially available)
To antenna
terminal
Connecting to the AC outlet
Rear view
AC outlet
NOTE
• Always turn off the power of the TV when connecting the AC cord.
• Disconnect the AC cord from the AC outlet if the TV will not be used for a long period of time.
Antenna input terminal
(ANALOGUE)
Antenna input terminal (DTV)
42PD7X_en_a.indd 942PD7X_en_a.indd 9 2007/01/12 15:45:192007/01/12 15:45:19

10
Preparation
You can connect many types of external equipment to your TV, like a VCR, game console, camcorder, DVD player
and PC. To view external source images, select the input source from TV/VIDEO on the remote control unit or
TV/VIDEO on the TV.
CAUTION
• To protect all equipment, always turn off the TV before connecting to a VCR, game console, camcorder, DVD player, PC or
other external equipment.
• Refer to the relevant operation manual (VCR, DVD player, etc.) carefully before making connections.
Connecting a VCR, game console or camcorder
A VCR, game console, camcorder and some other audiovisual equipment can be conveniently connected using
the INPUT 1/INPUT 2 (component) terminals.
VCR/
Game console/
Camcorder
Connecting a DVD player
You can use the INPUT 1/INPUT 2 (component) or INPUT 3/INPUT 4 (HDMI) terminal when connecting to a DVD
player and other audiovisual equipment.
When using HDMI cable
(commercially available).
When using component cable
(commercially available).
NOTE
• When using a DVI-HDMI conversion adaptor, input the Audio Signal from the AUDIO terminal of INPUT 4.
DVD player
L
R
AUDIO
Y
PB
(CB)
PR
(CR)
When using component cable
(commercially available).
L
R
AUDIO
Y
PB
(CB)
PR
(CR)
DVD player
42PD7X_en_a.indd 1042PD7X_en_a.indd 10 2007/01/12 15:45:202007/01/12 15:45:20

11
Preparation
Connecting a PC
You can use the INPUT 5 (DVI) terminal when connecting to a PC.
When using DVI cable
(commercially available).
PC
DVI-I
AUDIO
(L/R)
42PD7X_en_a.indd 1142PD7X_en_a.indd 11 2007/01/12 15:45:212007/01/12 15:45:21

12
Part names
TV (Front)
Volume up (e)/down (f) buttons
Channel up (r)/down (s) buttons
OPC indicator*
POWER (On/Off) button
TV/VIDEO button
*OPC: Optical Picture Control
(See page 26.)
SLEEP timer indicatorOPC sensor
Remote control sensor
POWER indicator
42PD7X_en_a.indd 1242PD7X_en_a.indd 12 2007/01/12 15:45:222007/01/12 15:45:22

13
Part names
TV (Rear)
RS-232C terminal
INPUT 3 (HDMI)
terminals
INPUT 4 (AUDIO)
terminals
MONITOR OUTPUT
terminals
INPUT 2 terminals
INPUT 1 terminals
Antenna input terminal
(ANALOGUE)
AC INPUT terminal
SERVICE ONLY terminal*
*Usually do not connect anything to this terminal as it is reserved only for service personnel.
INPUT 4 (HDMI)
terminals
INPUT 5 terminals
DIGITAL AUDIO OUTPUT
terminal (To optical digital input
of external audio devices)
Antenna input terminal (DTV)
42PD7X_en_a.indd 1342PD7X_en_a.indd 13 2007/01/12 15:45:232007/01/12 15:45:23

14
Part names
Remote control unit
NOTE
• When using the remote control unit, point it at the TV.
1 POWER (STANDBY/ON)
To switch the power on and off. (See page 15.)
2 0 – 9
TV/DTV/External input mode: Set the channel. (See page 15.)
TELETEXT mode: Set the page. (See pages 15, 50 and 51.)
3 A(Flashback)
Press to return to the previous selected channel or external input
mode. (See page 16.)
4 DTV MENU
DTV mode: Display DTV Menu screen. (See page 32.)
5 MPX
Select the sound multiplex mode. (See page 16.)
6 e(Mute)
Mute the sound. (See page 17.)
7 VOLk/VOLl
Set the volume. (See page 17.)
8 GUIDE
DTV mode: Display the programme list. (See page 33.)
9 SURROUND
Select Surround settings. (See page 30.)
10 EXIT
Turn off the On-Screen Display.
11 AV MODE
Select an audio and video setting. (See page 26.)
12 WIDE
Change the wide image mode. (See pages 45 and 46.)
13 FAV.
DTV mode: Display the favourite programme list. (See page 33.)
14 m(TELETEXT)
ANALOGUE mode: Select the TELETEXT mode. (all TV image, all
TEXT image, TV/TEXT image) (See pages 50 and 51.)
DTV mode: Select the TELETEXT mode. (all TV image, TEXT image)
k(Reveal hidden for TELETEXT)
TELETEXT mode: Display hidden characters. (See page 50.)
[(SUBTITLE for TELETEXT)
TV/INPUT mode: To turn the subtitles on and off. (See page 51.)
3(Hold)
TELETEXT mode: Stop updating Teletext pages automatically.
Press 3again to release the hold mode. (See pages 50 and 51.)
1(Subpage)
TELETEXT mode: Display the Teletext subpage directly. (See
page 51.)
v(Top/Bottom/Full)
TELETEXT mode: Set the area of magnification. (See page 50.)
15 TV/VIDEO (INPUT SOURCE)
Select an input source. (TV, DTV, INPUT 1, INPUT 2, INPUT 3,
INPUT 4, INPUT 5) (See pages 10, 42 and 49.)
16 ANALOG
Press to access ANALOG mode. (See page 18.)
DTV
Press to access DTV mode. (See page 18.)
RADIO
Press to access RADIO mode. (See page 18.)
17 DISPLAY
Display the channel or input information.
TELETEXT mode: Display the time information included in the
Teletext broadcast. (See page 51.)
18 SLEEP
Set the Sleep timer. (See page 17.)
19 CHr/CHs
TV/DTV input mode: Select the channel. (See page 15.)
TELETEXT mode: Select the page. (See pages 50 and 51.)
20 INFO
DTV mode: Display the programme information. (See page 33.)
21 MENU
Display the menu screen. (See page 19.)
22 a/b/c/d(Cursor)
Select a desired item on the setting screen. (See pages 19 and
32.)
ENTER
Execute a command. (See pages 19 and 32.)
23 RETURN
MENU mode: Return to the previous menu screen. (See pages 19
and 32.)
24 Colour (Red/Green/Yellow/Blue)
TELETEXT mode: Select a page. (See page 50.)
25 OPC
To switch the Optical Picture Control on and off. (See page 26.)
26 FREEZE
Freeze a motion picture on the screen. (See page 52.)
2
1
4
5
10
11
12
13
7
3
6
9
8
15
17
23
26
18
19
21
20
24
25
22
16
14
42PD7X_en_a.indd 1442PD7X_en_a.indd 14 2007/01/12 15:45:242007/01/12 15:45:24

15
Turning on the power
Press POWER on the TV.
• POWER indicator (Green): The TV is on. (After a few
seconds, an image appears with sound.)
• After turning the power “ON” by pressing POWER on the
TV, you can turn the power ON/OFF by pressing POWER
on the remote control.
Watching TV
POWER button
POWER button
Turning off the power
Press POWER on the remote control.
• The TV enters standby mode and the image on the screen
disappears.
• The POWER indicator on the TV changes from green to
red.
Press POWER on the TV.
• The POWER indicator on the TV turns off.
• When the TV is turned off by POWER on the TV, you
cannot turn on the power by pressing POWER on the
remote control.
POWER indicator
Off Power off
The TV is in standby mode.Red
POWER indicator
The TV is on.Green
NOTE
• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.
• Minor power is consumed when the TV is turned off by
POWER on the TV.
Simple button operations for
changing channels
You can change channels in several ways.
Using CHr/son the remote control unit
• Press CHrto increase the channel number.
• Press CHsto decrease the channel number.
NOTE
• CHr/son the TV operates the same as CHr/son
the remote control unit.
Using 0 — 9 on the remote control unit
Select the channels directly by pressing buttons 0to 9.
a
To select a 1-digit channel (e.g. channel 2):
• Press 0, followed by 2.
To select a 2-digit channel (e.g. channel 12):
• Press 1, followed by 2.
When viewing Teletext information
View a page directly which is 3-digit page number from
100 to 899 by pressing buttons 0to 9.
42PD7X_en_b.indd 1542PD7X_en_b.indd 15 2007/01/12 15:45:502007/01/12 15:45:50

Using Flashback (A) on the remote
control unit
Using MPX on the remote control
unit
16
Press Ato switch the currently tuned channel to the
previously tuned channel.
Press Aagain to switch back to the currently tuned
channel.
Press Ato toggle between the currently selected
input source and the previously selected one.
Press Ato return to the previous page in TELETEXT
mode.
When receiving a monaural signal
Each time you press MPX, the mode switches
between NICAM MONO and MONO.
Watching TV
NOTE
• “BBC2”, “99” and “PAL” are tentative network name,
channel and colour system.
In the NICAM TV broadcasts
When receiving a stereo signal
Each time you press MPX, the mode switches
between NICAM STEREO and MONO.
When receiving a bilingual signal
Each time you press MPX, the mode switches among
NICAM CH A, NICAM CH B, NICAM CH AB and
MONO.
In the TV mode of A2 TV broadcasts
When receiving a stereo signal
Each time you press MPX, the mode switches
between STEREO and MONO.
When receiving a monaural signal
When you press MPX, “MONO” displays.
When receiving a bilingual signal
Each time you press MPX, the mode switches among
CH A, CH B and CH AB.
Stereo mode
PAL
B/G
STEREO
NICAM
99
BBC2
PAL
B/G
MONO
99
BBC2
Bilingual mode
PAL
B/G
CH A
NICAM NICAM
99
BBC2
PAL
B/G
CH B
99
BBC2
PAL
B/G
MONO NICAM
99
BBC2
PAL
B/G
CH AB
99
BBC2
Monaural mode
PAL
B/G
MONO
NICAM
99
BBC2
PAL
B/G
MONO
99
BBC2
Stereo mode
PAL
B/G
STEREO
99
BBC2
PAL
B/G
MONO
99
BBC2
Bilingual mode
PAL
B/G
CH A
99
BBC2
PAL
B/G
CH B
99
BBC2
PAL
B/G
CH AB
99
BBC2
Monaural mode
PAL
B/G
MONO
99
BBC2
42PD7X_en_b.indd 1642PD7X_en_b.indd 16 2007/01/12 15:45:542007/01/12 15:45:54

1
2
20
17
Simple button operation for
changing volume/sound
NOTE
• Within 30 minutes after pressing e, press one of the
buttons below to cancel the mute.
— VOLl/VOLk
— e
• Mute will be cancelled after 30 minutes. However,
the TV will not suddenly output loud sound as the
volume level will be set to 0 automatically. Increase
the volume level by pressing VOLk.
Watching TV
Mute
Changing the volume
You can change the volume on the TV or on the
remote control unit.
• To increase the volume, press VOLk.
• To decrease the volume, press VOLl.
NOTE
• “TV”, “DTV”, “INPUT1”, “INPUT2”, “INPUT3”, “INPUT4”
and “INPUT5” modes can store volume adjustment values
separately.
Using Mute (e) on the remote control unit
emutes the current sound output.
Sleep timer
Allows you to set a time when the TV automatically
switches to standby.
Press e.
• The sound is silenced.
• “M” is displayed while the mute function is on.
Press eagain within 30 minutes to cancel the
mute.
• Before 30 minutes, the volume level returns to the
previous setting.
1
2
Sleep Timer: Remain 2 hr. 00 min.
NOTE
• The sleep timer indicator on the TV lights up when the time
has been set.
• When the time has been set, countdown automatically
starts.
• Five minutes before the preset of time expires, the
remaining time displays each minute.
• Select “Off” by pressing SLEEP to cancel the sleep timer.
Press SLEEP.
• Remaining time displays when sleep timer has
been set.
Each time you press SLEEP, the remaining
time switches as shown below.
0 hr. 30 min. 1 hr. 00 min. 1 hr. 30 min.
2 hr. 30 min. 2 hr. 00 min.
Off
42PD7X_en_b.indd 1742PD7X_en_b.indd 17 2007/01/12 15:45:572007/01/12 15:45:57

18
Watching TV
ANALOG/DTV/RADIO buttons
Use the following buttons on the remote control to
operate the menu.
ANALOG: Press to switch to analogue mode. After
switching from DTV, radio or external input
mode to analogue mode, the TV jumps to
the most recently viewed analogue channel.
DTV: Press to switch to DTV mode. After
switching from analogue, radio or external
input mode to DTV mode, the TV jumps to
the most recently viewed DTV channel.
RADIO: Press to switch to radio mode. After
switching from analogue, DTV or external
input mode to radio mode, the TV jumps to
the most recently tuned radio channel.
When you watch the TV for the first time
When the TV powers on for the first time after
purchase, perform the auto installation.
Analogue TV
You can run the auto installation to set channels
automatically.
To watch the analogue TV, select “Auto
Installation” from Setup menu. (See page 21.)
1
DTV
When the TV accesses to DTV mode for the first time,
you need to run the auto search. To scan all available
services in your area, follow the procedures below.
After setting the channels, you can select
a channel using CH r/sor 0—9on the
remote control unit. (See page 15.)
2
To watch DTV broadcasts, select “Auto
Search” from Installation menu. (See page 35.)
1
After setting the channels, you can select
a channel using CH r/sor 0—9on the
remote control unit. (See page 15.)
2
42PD7X_en_b.indd 1842PD7X_en_b.indd 18 2007/01/12 15:46:012007/01/12 15:46:01
