Sharp AQUOS LC-52LE640U User manual

LC-80LE633U LC-70/60/52LE640U LC-70/60/52C6400U OPERATION MANUAL MODE D'EMPLOI MANUAL DE OPERACIÓN
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
SHARP CORPORATION
Printed in Mexico
Imprimé au Mexique
Impreso en México
TINS-F419WJN1
12P03-MX-NM
ENGLISHFRANÇAISESPAÑOL
IMPORTANT : Please read this operation manual before starting operating the equipment.
IMPORTANT : Veuillez lire ce mode d'emploi avant de commencer à utiliser l'appareil.
IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.
LC-80LE633U
LC-70LE640U
LC-60LE640U
LC-52LE640U
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO
OPERATION MANUAL
MODE D'EMPLOI
MANUAL DE OPERACIÓN
LC-70C6400U
LC-60C6400U
LC-52C6400U
ENGLISHFRANÇAISESPAÑOL ENGLISHFRANÇAISESPAÑOL
LC-80LE633U706052LE640UC6400UECover.indd1LC-80LE633U706052LE640UC6400UECover.indd1 2012/01/0614:13:292012/01/0614:13:29

*1 Active area/Área activa/Zone active
*2 Thinnest part/Parte más delgada/Partie la plus mince
Unit: inch (mm)
Unité: pouce (mm)
Unidad: pulgada (mm)
Dimensional Drawings
LC-52LE640U/LC-52C6400U
LC-60LE640U/LC-60C6400U
AN-52AG4
AN-52AG4
47 9/16 (1208)
30 23/64 (771) 29 3/32 (739)
25 33/64
(648.0)*1
16 1/2(419)
45 23/64 (1152.0)*1
13 1/8(333)
541/64
(143)
227/32 (72)
13/64 (26.4)*2
21/64 (51)
13 19/32 (345)15 25/64 (391)
5°
15 3/4(400)
15 3/4(400)
11 17/64 (286)
43/64 (17)
815/32 (215)
21 7/64 (536)
41/2
(114)
6 17/64
(159)
21 7/64 (536)
29 7/16 (747.63)*1
52 11/32 (1329.12)*1
54 17/32 (1385)
34 11/32 (872) 33 1/32 (839)
18 1/2(470)
15 3/4(400)
91/16 (230)
15 3/4(400)
21/16 (52)
815/32 (215)
69/64 (156)
15 9/16 (395)17 13/32 (442)
417/32
(115)
621/32
(169)
5°
53/4
(146)
13 1/8(333)
259/64 (74)
17/64 (27.9)*2
LC-80LE633U706052LE640UC6400UECover.indd2LC-80LE633U706052LE640UC6400UECover.indd2 2012/01/0515:44:142012/01/0515:44:14

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
CAUTION:
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly
approved by the manufacturer could void the user's authority to operate this equipment.
1
OPERATION MANUAL
IMPORTANT:
To aid reporting in case of loss or theft, please record the
TV's model and serial numbers in the space provided. The
numbers are located at the rear and right side of the TV.
Model No.:
Serial No.:
LIQUID CRYSTAL TELEVISION
ENGLISH
IMPORTANT INFORMATION
ENGLISH
LC-80LE633U
LC-70LE640U
LC-60LE640U
LC-52LE640U
LC-70C6400U
LC-60C6400U
LC-52C6400U
LC-80LE633U706052LE640UC6400UE.indb1LC-80LE633U706052LE640UC6400UE.indb1 2012/01/0516:20:282012/01/0516:20:28

INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
DECLARATION OF CONFORMITY:
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-80LE633U/LC-70LE640U/LC-60LE640U/
LC-52LE640U/LC-70C6400U/LC-60C6400U/LC-52C6400U
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
TEL: 1-800-BE-SHARP
For Business Customers: URL http://www.sharpusa.com
“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820 of the National
Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.”
This product qualifies for ENERGY STAR when "Home" is selected for "TV Location".
Setting "TV Location" to "Home" allows the TV to achieve an energy-saving status for household use.
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Wireless Radio
For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible.
This device is going to be operated in 5.15–5.25GHz frequency range, it is restricted in indoor environment only.
Important: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Wireless Radio
For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible.
The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure.
Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where
required by the technology.
Important: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator
& your body.
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded
cables and connectors for connections.
2
IMPORTANT INFORMATION
LC-80LE633U706052LE640UC6400UE.indb2LC-80LE633U706052LE640UC6400UE.indb2 2012/01/0516:20:282012/01/0516:20:28

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage
if improperly handled. This product has been engineered and manufactured with the highest priority on safety.
However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and cleaning the product. To ensure your safety
and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully
before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Information
15) Power Sources—This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery power, or other sources, refer to the
operating instructions.
16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a qualified technician
to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for service.
19) Replacement Parts—When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
IMPORTANT SAFETY INSTRUCTIONS
LC-80LE633U706052LE640UC6400UE.indb3LC-80LE633U706052LE640UC6400UE.indb3 2012/01/0516:20:282012/01/0516:20:28

IMPORTANT SAFETY INSTRUCTIONS
4
• Outdoor Antenna Grounding — If an outside antenna is
connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base
can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product
on a wall, be sure to follow the manufacturer's instructions. Use only the mounting hardware recommended by the
manufacturer.
• Selecting the location — Select a place with no direct sunlight and good ventilation.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place
the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not
designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper
ventilation is provided or the manufacturer's instructions are followed.
• The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with
impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 2,073,600 pixels, giving you fine picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that
this does not affect the performance of your product.
• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to
the equipment due to lightning and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• To prevent fire or shock hazard, do not expose this product to dripping or splashing.
No objects filled with liquids, such as vases, should be placed on the product.
• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may
result in fire or electric shock. Exercise special caution when using the product around children.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always
carry the TV by two people holding it with two hands — one hand on each side of the TV.
Caring for the cabinet
• Use a soft cloth (cotton, flannel, etc.) and gently wipe the surface of the cabinet.
• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main unit cabinet or cause
cracking.
• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.
• If the cabinet is very dirty, wipe with a soft cloth (cotton, flannel, etc.) soaked in neutral detergent diluted with water and
thoroughly wrung out, and then wipe with a soft dry cloth.
• Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.
• Do not apply insecticides or other volatile liquids.
Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers
inside the plastic may cause the cabinet to deform and cause the paint to peel off.
LC-80LE633U706052LE640UC6400UE.indb4LC-80LE633U706052LE640UC6400UE.indb4 2012/01/0516:20:282012/01/0516:20:28

IMPORTANT SAFETY INSTRUCTIONS
5
Caring for the front panel
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Gently wipe the surface of the front panel with a soft cloth (cotton, flannel, etc.).
To protect the front panel, do not use a dirty cloth, liquid cleaners, or a chemical cloth (wet/dry
sheet type cloth, etc.). This may damage the surface of the front panel.
• Wiping with a hard cloth or using strong force may scratch the surface of the front panel.
• Use a soft damp cloth to gently wipe the front panel when it is really dirty.
(It may scratch the surface of the front panel when wiped strongly.)
• If the front panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are
available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for
ordering, or VISIT http://www.sharpusa.com/SharpDirect.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
• The home theater entertainment experience is a growing trend and larger flat panel displays
are popular purchases. However, flat panel displays are not always supported on the proper
stands or installed according to the manufacturer’s recommendations.
• Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks,
speakers, chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
• The consumer electronics industry is committed to making home entertainment enjoyable
and safe.
TUNE INTO SAFETY
• One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation
and use of your flat panel display.
• Carefully read and understand all enclosed instructions for proper use of this product.
• Don’t allow children to climb on or play with furniture and television sets.
• Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest
of drawers.
• Remember that children can become excited while watching a program, especially on a
“larger than life” flat panel display. Care should be taken to place or install the display where it
cannot be pushed, pulled over, or knocked down.
• Care should be taken to route all cords and cables connected to the flat panel display so that
they cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
• Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such
as UL, CSA, ETL).
• Follow all instructions supplied by the display and wall mount manufacturers.
• If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be
mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.
• A minimum of two people are required for installation. Flat panel displays can be heavy.
Note: CEA is the preeminent trade association promoting growth in the $161 billion U.S.
consumer electronics industry. More than 2,200 companies enjoy the benefits of CEA
membership, including legislative advocacy, market research, technical training and
education, industry promotion and the fostering of business and strategic relationships.
LC-80LE633U706052LE640UC6400UE.indb5LC-80LE633U706052LE640UC6400UE.indb5 2012/01/0516:20:282012/01/0516:20:28

6
Contents
•The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from
the actual operations.
•The examples used throughout this manual are based on the LC-70LE640U model.
IMPORTANT INFORMATION ............................. 1-2
DEAR SHARP CUSTOMER .................................... 3
IMPORTANT SAFETY INSTRUCTIONS............. 3-5
Supplied Accessories............................................. 7
QUICK REFERENCE
Attaching the Stand ............................................ 7
QUICK INSTALLATION TIPS............................... 8
Experiencing HD Images..................................... 8
Using the Remote Control Unit ........................... 8
Preparation
Antennas ............................................................ 9
Installing Batteries in the Remote Control Unit..... 9
Part Names
TV (Front).......................................................... 10
TV (Rear/Side)................................................... 10
Remote Control Unit ......................................... 11
Introduction to Connections
Types of Connection......................................... 12
Displaying an External Equipment Image........... 12
Connecting to External Equipment
Connecting a Blu-ray Disc/DVD Player or
HD Cable/Satellite Set-top Box ................ 13-14
Connecting a VCR, Game Console,
Camcorder or Cable/Satellite Set-top Box..... 14
Connecting a Surround System/Audio System ... 15
Connecting a PC .............................................. 16
Watching TV
Turning On/Off the Power ................................. 17
Initial Installation.......................................... 17-19
Direct Button Operation
INPUT .......................................................... 20
Changing Channels...................................... 20
Changing Volume......................................... 20
MUTE........................................................... 20
Sleep Timer.................................................. 20
FREEZE ....................................................... 20
FLASHBACK................................................ 21
SmartCentral................................................ 21
NETFLIX....................................................... 21
AV MODE .................................................... 21
AUDIO.................................................... 21-22
Closed Captions and
Digital Closed Captions.............................. 22
VIEW MODE................................................. 23
On-Screen Display Menu
On-Screen Display Menu Operation.................. 24
Menu Operation Buttons................................... 24
Menu Items....................................................... 25
Picture Settings .......................................... 26-27
Audio Settings .................................................. 28
Power Control .................................................. 29
System Options .......................................... 30-32
Initial Setup................................................. 33-36
Information ................................................. 37-39
Enjoying Photo/Music/Video Playback
Connecting a USB Memory Device/
USB Hard Drive.............................................. 40
Connecting a Home Network (DLNA) Server..... 40
Selecting the Folders to Play Back.................... 41
Playing Back Files on a USB Memory Device/
Home Network (DLNA) Server ................. 42-46
Other Viewing Options
Presetting Remote Control Function ................. 47
Operating the Connected Equipment.......... 47-48
Using AQUOS LINK
Controlling HDMI Equipment
Using AQUOS LINK.................................. 49-51
Link Operation Menu .................................. 51-52
Using a PC
Displaying a PC Image on the Screen ............... 53
Adjusting the PC Image .................................... 54
Setting Audio Input ........................................... 54
PC Compatibility Chart ..................................... 54
Control of the TV ........................................ 55-56
Using the Internet
Connecting to the Internet ................................ 57
Internet Setup............................................. 58-59
AQUOS Advantage Live.................................... 59
Entering Text (Software Keyboard).................... 60
Using the Browser ...................................... 61-63
Using Applications via the Internet .............. 64-65
Appendix
Attaching the Stand (for LC-80LE633U)............ 66
Removing the Stand ......................................... 67
Setting the TV on the Wall........................... 68-69
Troubleshooting.......................................... 70-71
Troubleshooting - Error Message...................... 71
Trademarks........................................................... 72
Specifications
TV............................................................... 73-74
Optional Accessory........................................... 74
Wireless LAN .................................................... 75
Information on the Software License for
This Product ................................................. 76-78
Calling for Service ................................................ 79
LIMITED WARRANTY ........................................... 79
Dimensional Drawings
•The dimensional drawings for the LCD TV set are shown
on the inside back cover.
LC-80LE633U706052LE640UC6400UE01.indd6LC-80LE633U706052LE640UC6400UE01.indd6 2012/01/0614:14:262012/01/0614:14:26

7
1Confirm that there are 12 screws (8 long screws
and 4 short screws) supplied with the stand unit.
21Set the post for the stand unit onto the
polystyrene foam.
2Attach the base to the post.
3Insert and tighten the 8 screws into the 8 holes
on the bottom of the base.
•Hold the stand unit securely with one hand, and then
tighten the screws.
FRONT
2
3
1
1
Long
screws
3
Insert the stand into the openings on the bottom of the TV.
• Make sure that the stand is firmly inserted into the TV.
Improper installation may result in tilting of the TV set.
Soft cushion
4Insert and tighten the 4 screws into the 4 holes on
the rear of the TV.
Short screws
• In the installation procedure, be careful not to catch your
fingers between the TV set and the floor.
Supplied Accessories
Make sure the following accessories are provided with the product.
Remote control unit (g1)
Page 8
“AAA” size battery (g2)
Page 9
Stand unit (g1)
Pages 7, 66
■ Operation manual (g1) ■ Connection guide (g1)
AC cord (g1)
Page 9
LC-80LE633U
70 7/8inches
1,800 mm (approx.)
• Always use the AC cord supplied with the TV.
• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.
QUICK REFERENCE
Attaching the Stand
• Before attaching (or detaching) the stand, unplug the AC cord.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
CAUTION
•Attach the stand in the correct direction.
•Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
•Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
•After attaching the stand to the TV, do not hold the stand when you put up, set up, move or lay down the TV.
■ LC-70LE640U/LC-60LE640U/LC-52LE640U/LC-70C6400U/LC-60C6400U/LC-52C6400U
Refer to page 66 for the instructions on the installation of the LC-80LE633U.
LC-80LE633U706052LE640UC6400UE01.indd7LC-80LE633U706052LE640UC6400UE01.indd7 2012/01/3011:12:032012/01/3011:12:03

8
Experiencing HD Images
An HDTV without an HD source is just an ordinary
TV.
To enjoy HD images on the TV, you should get
HD programming from the following:
• Over-the-air broadcasting via HD quality antenna
• HD cable/satellite subscription
• HD compatible external equipment
• For information on updating to HD programming, ask your
cable/satellite service provider.
Using the Remote Control Unit
Use the remote control unit by pointing it towards the
remote control sensor on the TV. Objects between the
remote control unit and the remote control sensor may
prevent proper operation.
30º 30º
30º
30º
17´ (5 m) Remote control sensor
■ Cautions regarding the remote control unit
• Do not expose the remote control unit to shock. In addition,
do not expose the remote control unit to liquids, and do not
place in an area with high humidity.
• Do not install or place the remote control unit under direct
sunlight. The heat may cause deformation of the remote
control unit.
• The remote control unit may not work properly if the remote
control sensor on the TV is under direct sunlight or strong
lighting. In such cases, change the angle of the lighting
or the TV, or operate the remote control unit closer to the
remote control sensor.
IMPORTANT:
IF THE UNIT DOES NOT POWER ON - UNPLUG THE
TELEVISION FROM THE OUTLET AND REPEAT THE
INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT
US AT 1-800-BE-SHARP.
QUICK INSTALLATION TIPS
1Attach your antenna to the back of the television.
(See page 9.)
2Connect the AC plug for the television into the AC
outlet.
LC-80LE633U
AC outlet
• Bundle the cords properly with the cable tie.
LC-60/52LE640U
LC-60/52C6400U
LC-70LE640U
LC-70C6400U
2
1
1
2
11
AC outlet
• Place the TV close to the AC outlet, and keep the power
plug within reach.
•TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT
TOUCH UN-INSULATED PARTS OF ANY CABLES
WITH THE AC CORD CONNECTED.
3When turning on the TV for the first time, press
POWER on the television.
• For model LC-80LE633U, the control panel is located
on the left side of the TV as seen from the front.
POWER
4Insert the batteries into the remote control unit. (See
page 9.)
• Speakers cannot be detached from the TV.
• The TV angle cannot be adjusted.
QUICK REFERENCE
LC-80LE633U706052LE640UC6400UE01.indd8LC-80LE633U706052LE640UC6400UE01.indd8 2012/02/1713:32:062012/02/1713:32:06

9
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector,
plug it into the antenna terminal at the rear of the TV set. For connecting the antenna cable to the TV, use
commercially available cables.
300-ohm twin-lead cable
75-ohm coaxial cable (round)
75-ohm coaxial cable
IN OUT
300-ohm
twin-lead cable
VHF
A
NTENNA
UHF
ANTENNA
Combiner To TV antenna
terminal
300/75-ohm adapter
300-ohm twin-lead cable (flat)
75-ohm coaxial cable (round)
Cable TV lead-In
Coaxial cable
Coaxial cable
Home Antenna
terminal (75-ohm)
Home Antenna
terminal (75-ohm)
or
or
Installing Batteries in the Remote Control Unit
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
1Open the battery cover. 2Insert two “AAA” size batteries (supplied with
the product).
• Place the batteries
with their terminals
corresponding to the (e)
and (f) indications in the
battery compartment.
3Close the battery cover.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage
in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a
rash. If you find any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries from it.
Preparation
Connecting Antenna Cable
•Connect the antenna cable to the TV using one of the methods in the illustration as shown (1,2,3or 4).
1Cable without a CATV
converter
3Combination VHF/
UHF antenna
4Separate VHF/UHF
antenna
2VHF/UHF antenna
1.A 75-ohm system is generally a round cable with F-type connector
that can easily be attached to a terminal without tools.
2.A 300-ohm system is a flat “twin-lead” cable that can be attached
to a 75-ohm terminal through a 300/75-ohm adapter.
F-type connector
300-ohm twin-lead cable (flat)
F-type connector
75-ohm coaxial cable (round)
75-ohm coaxial cable
NOTICE
When connecting the RF cable to the TV set, do not tighten F-type
connector with tools.
If tools are used, it may cause damage to your TV set. (The breaking
of internal circuit, etc.)
F-type connector should be finger-tightened only.
LC-80LE633U706052LE640UC6400UE.indb9LC-80LE633U706052LE640UC6400UE.indb9 2012/01/0516:20:282012/01/0516:20:28

10
Part Names
TV (Front)
Center Icon illumination
(See page 32.)
Remote control sensor
* OPC: Optical Picture Control (See page 26.)
OPC sensor *
TV (Rear/Side)
RS-232C terminal
Antenna/
Cable in
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CHU/V)
Volume
buttons
(VOLk/l)
DIGITAL AUDIO
OUTPUT terminal
HDMI 3 terminal
HDMI 4 terminal
HDMI 1 terminal
ARC: Audio Return Channel
(See pages 49 and 50.)
AUDIO OUT terminal
USB 1 terminal
USB 2
terminal
ETHERNET
terminal
HDMI 2 terminal
COMPONENT
terminals
VIDEO 1
terminals
VIDEO 2
terminals
PC IN terminal
*1*2
*1
*1
AUDIO IN terminal
(shared for PC IN
and HDMI 1) *3
*1 See pages 12 to 16 and 49 for external equipment connection.
*2 See pages 12, 17 and 24 for button operations.
For model LC-80LE633U, the control panel is located on the left side of the TV as seen from the front.
*3 See page 54 for details on the Audio Select function.
LC-80LE633U706052LE640UC6400UE01.indd10LC-80LE633U706052LE640UC6400UE01.indd10 2012/02/1713:32:102012/02/1713:32:10

11
1 POWER: Switch the TV power on or enter standby. (See
page 17.)
2TV,STB,DVD•VCR,AUDIO: Switches the remote
control for TV, STB, BD, DVD, VCR and AUDIO operation.
(See pages 47 to 48 for details.)
* To enter the code registration mode, you need to press
an appropriate button (STB,DVD•VCR or AUDIO) and
DISPLAY at the same time.
3 External equipment operational buttons: Operate the
external equipment.
4 OPTION: Display the Link Operation Menu screen. This
button will function only when AQUOS LINK is used. (See
pages 49 to 52 for details.)
5 SLEEP: Set the sleep timer. (See page 20.)
60–9: Set the channel. (See page 20.)
7 • (DOT): (See pages 20 and 47.)
8 CC: Display captions from a closed-caption source. (See
page 22.)
9
AV MODE: Select an audio or video setting. (See page 21.)
10 MUTE: Mute the sound. (See page 20.)
11 VOLk/l:Set the volume. (See page 20.)
12 MENU: Display the menu screen. (See page 24.)
13 AAL: Display the TVkWeb screen. (See pages 59 to 63
for details.)
14 a/b/c/d,ENTER: Select a desired item on the screen.
15 EXIT: Turn off the menu screen.
16 FAVORITE CH: Set the favorite channels. (See page 34.)
17 A,B,C,D: Select 4 preset favorite channels in 4 different
categories. (See page 34.)
While watching, you can toggle the selected channels by
pressing A,B,Cand D.
18 DISPLAY: Display the channel information.
19 POWER (SOURCE): Turns the power of the external
equipment on and off.
20 FREEZE: Set the still image. Press again to return to
normal screen. (See page 20.)
21 AUDIO: Selects the MTS/SAP or the audio mode during
multichannel audio broadcasts. (See pages 21 to 22.)
22 ENT: Jumps to a channel after selecting with the 0–9
buttons.
23 FLASHBACK: Return to the previous channel or external
input mode. (See page 21.)
24 VIEW MODE: Select the screen size. (See pages 23 and
53.)
25 INPUT: Select a TV input source. (TV, HDMI1, HDMI2,
HDMI3, HDMI4, COMPONENT, VIDEO1, VIDEO2, PC IN,
Home Network (DLNA), USB) (See pages 12 and 20.)
26 CHU/V:Select the channel. (See page 20.)
27 SmartCentral: Display the application window. (See
page 21.)
28 RETURN: Return to the previous menu screen.
29 NETFLIX: Display the Netflix screen. (See page 21.)
30 FAV APP 1, 2, 3: You can assign your favorite
applications to these buttons. (See page 34.)
Remote Control Unit
• When using the remote control unit, point it at the TV.
Part Names
1
18
19
20
21
4
3
2
5
23
24
8
7
6
9
25
26
28
29
30
15
14
13
12
11
10
16
17
27
22
LC-80LE633U706052LE640UC6400UE.indb11LC-80LE633U706052LE640UC6400UE.indb11 2012/01/0516:20:282012/01/0516:20:28

12
Introduction to Connections
Types of Connection
For connecting the TV to external equipment, use commercially available cables.
• The illustrations of the terminals are for explanation purposes and may vary slightly from the actual products.
■ Connecting to video equipment or PC
Image quality differs depending on the terminal used. To enjoy clearer images, check the output terminals of your
external equipment and use its appropriate terminals for higher quality images.
Pages
13, 15, 16
Terminal
on the TV Cable Terminal on external equipment
Quality
AV cable
Component video cable
Audio cable
HDMI-certified cable
Ø 3.5 mm stereo minijack cable
DVI-HDMI conversion cable
HD
Quality
Standard
Quality
AUDIO
DVI OUT
Pages
13, 16
Page 14
Page 14
■ Connecting to audio equipment
Cable Terminal on external
equipment
Optical fiber cable
Ø3.5 mm stereo minijack to RCA audio cable
Terminal on the TV
DIGITAL AUDIO INPUT
OPTICAL
ANALOG AUDIO IN
Page 15
Page 15
1Press INPUT.
• The INPUT list screen displays.
2Press
a/bto select the input source.
• You can also select the input source by pressing
INPUT. Each time INPUT is pressed, the input source
toggles.
HDMI
4
TV
HDMI1 HDMI2 HDMI
3
• An image from the selected source automatically
displays.
• If the corresponding input is not plugged in, you
cannot change the input. Be sure to connect the
equipment beforehand.
INPUT
INPUT
TV
HDMI1
HDMI2
HDMI3
Menu
AIR
Input
Example
Displaying an External Equipment Image
To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.
• For model LC-80LE633U, the control panel is located on the left side of the TV as seen from the front.
LC-80LE633U706052LE640UC6400UE01.indd12LC-80LE633U706052LE640UC6400UE01.indd12 2012/02/1713:32:172012/02/1713:32:17

13
Connecting to External Equipment
You can connect many types of external equipment to your TV. To view external source images, select the input
source from INPUT on the remote control unit or on the TV. (See pages 12 and 20.)
For connecting the TV to external equipment, use commercially available cables.
CAUTION
• To protect equipment, always turn off the TV before connecting any external equipment.
• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.
Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box
■ When using HDMI cable (HDMI 1, 2, 3 or 4):
The HDMI (High Definition Multimedia Interface) terminal is an audio-video interface that enables a connection for audio and
video signals using a single cable. The HDMI terminal supports high-resolution video input.
• Blu-ray disc player • DVD player
• HD cable/satellite set-top box
HDMI OUT
HDMI-certified cable
• To enjoy 1080p display capability, connect your external equipment using an HDMI-certified cable or a component cable and
set the equipment to 1080p output.
• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.
• When you connect external equipment using a DVI-HDMI conversion cable or when you connect ARC-compatible
equipment, use HDMI 1.
■When using DVI-HDMI conversion cable (HDMI 1):
•Blu-ray disc player •DVD player
• HD cable/satellite set-top box
AUDIO DVI OUT
Ø 3.5 mm stereo minijack cable
DVI-HDMI conversion cable
• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to
connecting a DVI-HDMI conversion cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN
terminal and set "Audio Select" to "HDMI+Analog". (See page 54.)
LC-80LE633U706052LE640UC6400UE.indb13LC-80LE633U706052LE640UC6400UE.indb13 2012/01/0516:20:282012/01/0516:20:28

14
Connecting to External Equipment
■ When using Component cable (COMPONENT):
• Blu-ray disc player • DVD player
• HD cable/satellite set-top box
COMPONENT OUT
AUDIO-L (White)
AUDIO-R (Red)
Y (Green)
PB(Blue)
PR(Red)
Audio cable
Component video cable
• To enjoy 1080p display capability, connect your external equipment using an HDMI-certified cable or a component cable and
set the equipment to 1080p output.
• See page 13 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the HDMI terminal.
Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box
■ When using Composite cable (VIDEO 1 or 2):
• Game console • VCR
• Camcorder • Cable/Satellite set-top box
AV cable
VIDEO (Yellow)
AUDIO-L (White)
AUDIO-R (Red)
LC-80LE633U706052LE640UC6400UE.indb14LC-80LE633U706052LE640UC6400UE.indb14 2012/01/0516:20:292012/01/0516:20:29

15
Connecting to External Equipment
Connecting a Surround System/Audio System
■ When connecting an AV amplifier for surround system
DIGITAL AUDIO INPUT
OPTICAL
HDMI INHDMI OUT
HDMI OUT
HDMI-certified cable *1
HD Cable/Satellite set-top box
Optical fiber cable *2
• Letting the TV output the audio to an AV amplifier:
*1 When you connect ARC-compatible equipment, use the HDMI 1 terminal.
*2 If the equipment to be connected is not compatible with the ARC, connect an optical fiber cable.
• If the image is not in sync with the audio, check the settings of the connected surround system.
■ When connecting an Audio amplifier
It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 30 for details.) PCM audio
outputs from the terminal.
DIGITAL AUDIO INPUT
OPTICAL
Optical fiber cable
• Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI
connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz.
•
Optical digital audio will be output in 2-ch stereo when it is from the external equipment connected to the TV using an HDMI cable.
ANALOG AUDIO IN
Ø3.5 mm stereo minijack to RCA audio cable
• See page 31 for details on the Output Select function.
LC-80LE633U706052LE640UC6400UE.indb15LC-80LE633U706052LE640UC6400UE.indb15 2012/01/0516:20:292012/01/0516:20:29

16
Connecting a PC
Refer to page 54 for a list of PC signals compatible with the TV.
■ When using HDMI cable (HDMI 1, 2, 3 or 4):
HDMI OUT
HDMI-certified cable
• Depending on the board, only video signals may be output. In this case, in addition to connecting an HDMI-certified cable
to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to
"HDMI+Analog". (See page 54.)
•The HDMI terminals only support digital signal.
■ When using DVI-HDMI conversion cable (HDMI 1):
DVI OUT
AUDIO
DVI-HDMI conversion cable
Ø 3.5 mm stereo minijack cable
• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to
connecting a DVI-HDMI conversion cable to the HDMI 1 terminal, connect
a Ø 3.5 mm stereo minijack cable to the AUDIO IN
terminal and set "Audio Select" to "HDMI+Analog". (See page 54.)
■ When using analog RGB cable (PC IN):
RGBAUDIO
Analog RGB cable
(D-sub 15-pin cable or VGA cable)
Ø 3.5 mm stereo minijack cable
• When using an analog RGB cable, input the audio signal to the AUDIO IN terminal of PC IN.
• When connecting a PC to the PC IN, set "Audio Select" to "Video+Audio". (See page 54.)
Connecting to External Equipment
LC-80LE633U706052LE640UC6400UE.indb16LC-80LE633U706052LE640UC6400UE.indb16 2012/01/0516:20:292012/01/0516:20:29

17
Turning On/Off the Power
POWER
POWER (On/Standby)
Press POWER on the TV or on the remote control unit
to turn the power on.
• For model LC-80LE633U, the control panel is located on
the left side of the TV as seen from the front.
• The Initial Installation starts when the TV powers on for the
first time. If the TV has been turned on before, the Initial
Installation will not be invoked. For changing the settings of
the Initial Installation, perform "EZ setup" on the Initial Setup
menu on page 33.
Press POWER on the TV or on the remote control unit
again to turn the power off.
• The TV enters standby and the image on the screen
disappears.
• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.
• Weak electric power is still consumed even when the TV is
turned off.
Watching TV
Initial Installation
When you turn on the TV for the first time, it will
automatically memorize the broadcasting channels
available in the region where you live. Perform the
following steps before you press POWER on the
remote control unit.
1. Insert the batteries into the remote control unit. (See page 9.)
2. Connect the antenna cable to the TV. (See page 9.)
3. Plug in the AC cord to the AC outlet. (See page 8.)
Language (Language setting)
Select from among 3 languages: English, French and
Spanish.
1Press
a/bto select the desired language listed
on the screen, and then press ENTER.
Language
Location & Time
TV Location
Antenna & Cable/STB
Air/Cable
English
Español
Français
CH Search
Completed
Location & Time
Make settings for the country, area and time zone
where you use the TV.
2Press
a/bto select "United States", "Canada" or
"Mexico", and then press ENTER.
Canada
United States
Mexico
LC-80LE633U706052LE640UC6400UE02.indd17LC-80LE633U706052LE640UC6400UE02.indd17 2012/02/1713:32:282012/02/1713:32:28

18
3Press
a/bto select the time zone where you are
using the TV, and then press ENTER.
Example
CST
MST
PST
AKST
HAST
EST
• The time zone differs depending on the selected
country.
• The factory preset value is the time zone for the capital
of the selected country.
4Press
a/bto select the Daylight Savings Time,
and then press ENTER.
Manual
Off
Auto
• “Auto” is the default selection.
TV Location
Select "Home" or "Store" for the location where
you plan to install the TV. This product qualifies for
ENERGY STAR in Home mode default setting.
5Press
c/dto select "Home" or "Store".
Press ENTER to enter the setting.
Select
Store
Home
Home: “Power Saving” is set to "Advanced", and AV
MODE is set to "STANDARD".
Store: “Power Saving” is set to "Off" and AV MODE is
set to "DYNAMIC (Fixed)". Picture Reset and Feature
Demo can be set.
Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)"
regardless of whether Picture Reset is "On" or "Off". If you
select "On", AV MODE will be reset to "DYNAMIC (Fixed)" if
there is no operation for 30 minutes. When "Off" is selected,
AV MODE will be set to "DYNAMIC (Fixed)".
Feature Demo: When “On” is selected, after all the settings
are completed, the Feature Demo screen is displayed if there
is no operation for several minutes.
• ENERGY STAR qualification is based on AV MODE
"STANDARD".
Antenna & Cable/STB
Select the type of connection you will use to
watch TV.
6Press
c/dto select "Antenna & Cable" or "Set-
top box", and then press ENTER.
Set-top box
Antenna & Cable
To watch TV via an antenna or cable
connection (without using a set-top box):
Select "Antenna & Cable", and then go to step 7.
To watch TV via a set-top box:
1Select "Set-top box", and then press ENTER.
2To watch TV, select the input source
corresponding to the terminal connected to the
set-top box. When doing so, you must make
the setting to skip "TV". Press c/dto select
"On", and then press ENTER.
Off
On
• When this is set to "On", the channel on the TV
cannot be changed using the remote control unit or
menu. (e.g. CH U/V, Favorite CH, etc.)
• See page 30 for details on the Input Skip function.
3Press INPUT to select the input source
corresponding to the terminal connected to the
set-top box. Make the necessary settings on
the connected external equipment.
• See the operation manual of the connected
equipment for setting up the equipment.
Air/Cable (Antenna setting)
Make sure what kind of connection is made with your
TV when selecting "Air" or "Cable".
7Press
c/dto select "Air" or "Cable".
Press ENTER to enter the setting.
Cable
Air
Watching TV
LC-80LE633U706052LE640UC6400UE.indb18LC-80LE633U706052LE640UC6400UE.indb18 2012/01/0516:20:292012/01/0516:20:29
