LC-22L50M
LCD COLOUR TELEVISION
OPERATION MANUAL
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many
years of trouble-free operation of your product, please read the Important Safety Precautions
carefully before using this product.
Remote control unit “AA” size battery (g2) Operation manual Antenna adaptor *φ3.5mm stereo cable
NOTE
*This
φ3.5mm stereo cable can only plug in those mobile players that have 3.5mm jack.
• Cleaning — Unplug the AC cord from the AC outlet before cleaning the product. Use a soft damp cloth to clean the
product. Do not use liquid cleaners, aerosol cleaners or chemical cloth to clean it, as such materials may damage the
product.
• Water and moisture — Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,
swimming pool and in a wet basement.
• Do not place vases or any other water-filled containers on this product.
The water may spill onto the product causing fire or electric shock.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the product to fall,
resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
• When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops, excessive force and
uneven floor surface can cause the product to fall from the cart.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the
product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed
for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation
is provided or the manufacturer’s instructions are followed.
• The LCD panel used in this product is made of glass. Therefore, it can break when the product is struck forcefully or with a
sharp object. If the LCD panel is broken, be careful not to be injured by broken glass.
• Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including amplifiers).
• To prevent fire, never place any type of candle or naked flames on the top or near the TV set.
• To prevent fire or shock hazard, do not place the AC power cord under the TV set or other heavy items.
• Do not place heavy objects on this product or stand on it. Doing so could cause injury if the product overturns. Take
special care near children and pets.
• The LCD panel is a very high technology product with 1,049,088 pixels, giving you fine picture details.
Due to the very large number of pixels, occasionally a few non-active pixels may appear on the screen as a fixed point of
blue, green or red.
This is within product specifications and does not constitute a fault.
• Precautions when transporting the TV
When transporting the TV, never carry it by holding or otherwise putting pressure onto the display.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• Install the product on the place where the AC cord can be unplugged easily from the AC outlet, or from the AC INPUT
terminal on the rear of the product.
• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
Page
Supplied accessories...........................1
Dear SHARP customer.........................2
Important Safety Precautions .............2
Trademarks...........................................2
Antenna connection .............................3
Connecting external devices...............3
Remote control unit .............................5
Part names ............................................ 6
Turning the TV on/off ...........................8
Auto Installation....................................8
Programme Setup ................................8
Setup menu.........................................10
Picture menu.......................................10
Audio menu .........................................11
Page
Feature menu......................................11
Picture and still image .......................13
Switching the analogue audio
format ..................................................13
Teletext function.................................13
Connecting a PC (Picture menu).......14
Appendix .............................................15
Specifications .....................................16
ENGLISH
LC22L50M-L50M_EN.indd 1LC22L50M-L50M_EN.indd 1 9/14/09 2:44:29 PM9/14/09 2:44:29 PM

Antenna connection Connecting external devices (Continued)
34
Connecting external devices
Connecting a VCR, game console or camcorder
A VCR, game console, camcorder and some other audiovisual equipment can be conveniently connected
using the AV-1 IN/AV-2 IN or COMPONENT terminals.
When using component cable
(commercially available)
When using composite cable or S-VIDEO cable
(commercially available)
R – AUDIO – LY
PR
(CR)
PB
(CB)
R – AUDIO – LVIDEOS-VIDEO
Connecting a DVD player/Digital TV STB (Set Top Box)
You can use the HDMI or COMPONENT terminals when connecting to a DVD player/Digital TV STB (Set Top
Box) and other audiovisual equipment.
When using HDMI-certified cable
(commercially available)
When using component cable
(commercially available)
R – AUDIO – LY
PR
(CR)
PB
(CB)
Connecting a PC
You can use the PC terminals when connecting to a PC.
ANALOGUE
RGB
AUDIO
(L/R)
Use the following diagram if you connect an outdoor antenna.
+
+
If your outdoor antenna uses a 75-ohm coaxial
cable, connect an antenna adaptor and plug it
into the antenna jack at the rear of the set.
If your outdoor antenna uses a 300-ohm twin-
lead flat feeder, connect a 300-ohm to 75-ohm
impedance converter, connect an antenna
adaptor and plug it into the antenna jack at the
rear of the set.
Antenna
Connect the antenna cable from your antenna-/cable socket or the (room-/roof) antenna for antenna input
terminal on the back of your TV set to receive digitally/terrestrially broadcast stations.
An indoor antenna can also be used under good reception conditions. Passive and active room antennas
are offered commercially. In an active antenna its power is supplied via the antenna input terminal.
The supply voltage (5V) must be correspondingly set under “Supply Voltage”.
VHF/UHF
antenna
or
DVD player/
Digital TV STB
(Set Top Box)
or
VHF/UHF
antenna
300-ohm twin-lead flat
feeder (not supplied)
75-ohm
impedance
converter
(not supplied)
75-ohm coaxial
cable (round cable)
(not supplied)
You can connect many types of external equipment to your TV, like a VCR, game console, camcorder, DVD
player, Digital TV STB (Set Top Box) and PC. To view external source images, select the input source from
TV/VIDEO on the remote control unit or TV/VIDEO on the TV.
CAUTION
• To protect all equipment, always turn off the TV before connecting to a VCR, game console, camcorder, DVD player, Digital
TV STB (Set Top Box), PC or other external equipment.
• Refer to the relevant operation manual (VCR, DVD player, etc.) carefully before making connections.
VCR/Game
console/
Camcorder
VCR/Game
console/Camcorder
DVD player/
Digital TV STB
(Set Top Box)
PC
Antenna
adaptor
LC22L50M-L50M_EN.indd 2LC22L50M-L50M_EN.indd 2 9/14/09 2:44:45 PM9/14/09 2:44:45 PM

5 6
Remote control unit Remote control unit (Continued)
Part names
1
2
3
4
6
8
9
7
5
11
12
14
13
15
17
16
18
19
10
20
1 POWER (STANDBY/ON)
To switch the power on and off. (See page 8.)
2 DISPLAY
Display the channel or input information.
3 0 – 9
Set the channel.
TELETEXT* mode: Set the page. (See page 13.)
4 A(Flashback)
Press
Ato return to the previous selected channel
or external input mode.
5 WIDE
Change the wide image mode. (See page 12.)
6 FREEZE
Freeze a motion picture on the screen. (See page
13.)
7 a/b/c/d(Cursor)
Select a desired item on the setting screen.
TELETEXT* mode: Select the page. (See page 13.)
(
a) Increase the channel number.
(
b) Decrease the channel number.
ENTER
Execute a command.
Auto CH Scan mode: Stop Auto CH Scan.
8 EXIT
Exit menu screen.
9 Colour (Red/Green/Yellow/Blue)
Used for Sort menu. (See page 9 and 10.)
TELETEXT* mode: Select a page. (See page 13.)
10 AV MODE
Switches between Movie, Music, News and
Personal. (See page 11.)
11 SLEEP
Set the Sleep timer.
12 e(Mute)
Press
esMutes sound.
Press
eagain sRestores sound.
Mute will be cancelled if the VOLkis pressed at any
time.
13 MPX**
Select the sound multiplex mode. (See page 13.)
14 VOLk/VOLl
Set the volume.
(
k) Increase the volume.
(
l) Decrease the volume.
15 CHr/CHs
TV input mode: Select the channel.
Press CHr/CHsfor more than 3 seconds will
activate the Auto CH Scan.
16 TV/VIDEO (INPUT SOURCE)
Switches between TV broadcast and AV input
programmes.
17 PC
Directly select the PC terminal.
18 MENU
Display the menu screen.
19 RETURN
MENU mode: Return to the previous menu screen.
20 m(TELETEXT*)
Select the TELETEXT* mode. (all TV image, all TEXT
image, TV/TEXT image) (See page 13.)
k(Reveal hidden for TELETEXT*)
TELETEXT* mode: Display hidden characters. (See
page 13.)
[(SUBTITLE for TELETEXT*)
To turn the subtitles on and off. (See page 13.)
3(Hold)
TELETEXT* mode: Stop updating Teletext* pages
automatically. Press 3again to release the hold
mode. (See page 13.)
1(Subpage)
Display the Teletext* subpage directly when in
Teletext* mode.
Display current Teletext* clock information when not
in Teletext* mode. (See page 13.)
v(Top/Bottom/Full)
TELETEXT* mode: Set the area of magnification. (See
page 13.)
0:30 – : – – 1:00
1:302:00
0:30 – : – – 1:00
1:302:00
Inserting the batteries
Before using the TV for the first time, insert two “AA” size batteries (supplied). When the batteries become
depleted and the remote control fails to operate, replace the batteries with new “AA” size batteries.
1Open the battery cover. 2Insert the two supplied “AA”
size batteries.
3Close the battery cover.
• Place batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you find any
chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.
• Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
TV (Front)
POWER (On/Off) button
Remote control sensor
MENU button M.P. IN button
TV/VIDEO button
POWER indicator Volume down (f)/
up (e) buttons
Channel down (s)/
up (r) buttons
NOTE
* TELETEXT function is not applicable for Philippines market.
** MPX function is not applicable for Philippines market.
LC22L50M-L50M_EN.indd 3LC22L50M-L50M_EN.indd 3 9/14/09 2:44:48 PM9/14/09 2:44:48 PM

7 8
Part names (Continued) Turning the TV on/off Programme Setup
Auto Installation
TV (Rear)
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
PC terminals
RS-232C terminal
(SERVICE ONLY)
AV-1 IN terminals
COMPONENT terminals
M.P. IN terminal
HDMI terminals
Antenna input terminal
AV-2 IN terminals
Turning on the power
Press POWER on the TV.
• POWER indicator (Green): The TV is on. (After a few
seconds, an image appears with sound.)
• After turning the power “ON” by pressing POWER on the
TV, you can turn the power ON/OFF by pressing POWER
on the remote control.
Turning off the power
Press POWER on the remote control.
• The TV enters standby mode and the image on the screen
disappears.
• The POWER indicator on the TV changes from green to
red.
Press POWER on the TV.
• The POWER indicator on the TV turns off.
• When the TV is turned off by POWER on the TV, you
cannot turn on the power by pressing POWER on the
remote control.
POWER indicator
Light off Power off
Lighted (Red) The TV is in standby mode.
Lighted (Green) The TV is on.
NOTE
• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.
• Minor power is consumed when the unit is in standby
mode.
• The on-screen displays in this operation manual are for explanation purposes and may vary slightly from the actual
operations.
Setting channels to your preference
You can run the auto search procedure again at any
time by accessing the Setup menu. Channels can be
tuned automatically or manually.
Teletext
Language
Programme
Label
Colour
Sound
Manual
Skip
Auto Search
Sort
Booster
1
AUTO
M
175.25MHz
On
On
On
West Europe
English
MENU[Setup]
Picture Audio Setup Feature
*Some menu items cannot be selected depending on the
selected input source.
Auto Search
You can also automatically search by performing the
procedure below.
1Press MENU and the MENU screen displays.
2Press c/dto select “Setup”.
3Press a/bto select “Auto Search”.
4Press c/dand Auto Channel Tuning is started.
“Searching” will shown during Auto Search only.
You do not need to do anything during the auto
search. Press MENU or EXIT to exit menu
screen.
1When you turn on the TV for the first time,
Setup menu will appears and Auto Search
automatically been selected.
2Press c/dand Auto Channel Tuning is started.
“Searching” will shown during Auto Search only.
You do not need to do anything during the auto
search. Press MENU or EXIT to exit menu
screen.
LC22L50M-L50M_EN.indd 4LC22L50M-L50M_EN.indd 4 9/14/09 2:44:50 PM9/14/09 2:44:50 PM

9 10
Programme Setup (Continued) Programme Setup (Continued) Picture menu
Setup menu
Manual Adjust
You can set some channel item manually.
1Press MENU and the MENU screen displays.
2Press c/dto select “Setup”.
3Press a/bto select the desired menu item.
4Press c/dto select the desired item.
5Press MENU or EXIT to exit menu screen.
HProgramme
The channel position changes to the higher or lower
number.
HLabel
To enter the name of the channel. Maximum 6
alphanumeric can be input.
• Press a/b: To select a desired alphanumeric.
• Press c/d: To move to the desired alphanumeric
position.
• To exit, press c/duntil input cursor disappear.
• If the wrong alphanumeric is entered, select [ ] to clear.
HColour System
Select the optimum colour system to receive.
HSound System (Broadcasting system)
Select the optimum sound system (Broadcasting
system) to receive.
HManual
• Press c/dthen can adjust the signal frequency
manually.
• Press c/dfor more than 2 seconds, the “Manual
Channel Tuning” will start. If a signal is found, the
Manual Channel Tuning will stop searching.
• Instead of pressing c/dto adjust the frequency,
you can set by directly entering the frequency
number of the channel with 0 – 9.
HSkip
Channels with “Skip” set to “On” are passed over
when using CHr/seven if selected while
watching the image from the TV.
Movie
[ 30]
[0]
[0]
[0]
[0]
[0]
Brightness
Colour
Sharpness
Backlight
Tint
Colour Temp.
Reset
Contrast
MENU[Picture]
Picture Audio Setup Feature
1Press MENU and the MENU screen displays.
2Press c/dto select “Picture”.
3Press a/bto select the desired menu item.
4Press c/dto adjust the item to the desired
level.
5Press MENU or EXIT to exit menu screen.
HPicture adjustments
Selected item c button d button
Contrast For less contrast For more contrast
Brightness For less brightness For more
brightness
Colour For less colour
intensity
For more colour
intensity
Sharpness For less sharpness For more
sharpness
Backlight The screen dims The screen
brightens
Tint Skin tones become
reddish
Skin tones become
greenish
Colour Temp.
(Colour
Temperature)
White with reddish
tone
White with bluish
tone
NOTE
• For resetting all adjustment items to factory preset values,
press a/bto select “Reset”, and then press c/dto
select “On”.
HErase programme
Delete TV2 at programme number 2.
1Repeat steps 1 to 2 in Manual Adjust.
2Press a/bto select “Sort”, and then press
ENTER. Sort menu will be displayed.
3Press a/b/c/dto select programme number
2 (e.g. TV2) to be deleted, and then press RED
button.
MENU[Setup ... Sort]
Confirm
1 TV1
2 TV2
3 TV3
4
8
9
10
11
15
16
17
18
4Press RED button again, programme number
2 (e.g. TV2) will be deleted. The programmes in
programme number 3 to 99 will be shifted up 1
position.
• TV will tune to programme number 2 having TV3
programme.
MENU[Setup ... Sort]
Move Delete
1 TV1
2 TV3
3
4
8
9
10
11
15
16
17
18
5Press MENU or EXIT to exit menu screen.
H(Programme Lock)
• On: (Programme Lock) will lock the viewing of
the selected channel. (e.g.1)
(See page 12 to “Activate ” and “Password” from
“ Programme” under the “Feature” menu.)
• Off: (Programme Lock) is deactivated.
HBooster
Enhance the picture quality during weak signal.
It is not recommended to turn on during strong
signal condition. It may induced unwanted noise.
On tOff
Sort
Channel position can be sorted freely.
HMoving a programme
TV1 (at programme number 1) to programme
number 3.
1Repeat steps 1 to 2 in Manual Adjust.
2Press a/bto select “Sort”, and then press
ENTER. Sort menu will be displayed.
3Press a/b/c/dto select programme number 1
(e.g. TV1) to be moved, and then press GREEN
button.
MENU[Setup ... Sort]
Move to
1 TV1
2 TV2
3 TV3
4
8
9
10
11
15
16
17
18
4Press a/b/c/dto select programme number
3 (e.g. TV3). Press GREEN button again, TV1 will
be moved to programme number 3 and TV3 will
be moved to programme number 1.
• TV will tune to programme number 3 having TV1
programme.
MENU[Setup ... Sort]
Move Delete
1 TV3
2 TV2
3 TV1
4
8
9
10
11
15
16
17
18
5Press MENU or EXIT to exit menu screen.
1Repeat steps 1 to 2 in Manual Adjust.
2Press a/bto select “Teletext” or “Language”.
3Press c/dto select the desired item.
4Press MENU or EXIT to exit menu screen.
HTeletext*
Select from among 3 kinds of language: West
Europe, East Europe, Cyrillic.
NOTE
• Teletext* can display only when it is sent by a network. Not
used to convert between languages.
* Teletext function is not applicable for Philippines market.
HLanguage
Select from among 4 languages: English, French,
Portuguese, Arabic.
LC22L50M-L50M_EN.indd 5LC22L50M-L50M_EN.indd 5 9/14/09 2:44:51 PM9/14/09 2:44:51 PM

11 12
Feature menu Feature menu (Continued)Audio menu
DNR
M.P. IN
Audio Only
Wide Mode
Blue Back
HDMI Audio
Power Save
AV Mode
Programme
Digital
Off
Off
4:3
Off
Off
Movie
Off
MENU[Feature]
Picture Audio Setup Feature
1Press MENU and the MENU screen displays.
2Press c/dto select “Feature”.
3Press a/bto select the desired menu item.
4Press c/dto select the desired item.
5Press MENU or EXIT to exit menu screen.
HAV Mode
You can select the appropriate picture and sound
setting for the video and audio performance.
NOTE
• You can also select AV Mode options by pressing AV
MODE button on the remote control unit.
• Not available for PC input.
HDNR (Digital Noise Reduction)
Reduce noise on the screen and produces a clearer
video image.
HM.P. IN
• When external mobile player is connected with
provided φ 3.5mm stereo cable and plugged into
M.P. IN jack, you may listen to the sound source
from TV speaker.
When M.P. IN is set to “On”, “M.P. IN” will appears
on the screen.
• Press M.P. IN button on the TV set to select “On”
or “Off”.
• If external mobile player is not plugged into M.P. IN
jack, M.P. IN button will not function.
NOTE
• During M.P. IN mode, AV Mode function for audio is not
available.
HWide Mode (PC input mode only)
The Wide Mode changes as shown below.
NOTE
• Some picture sizes may not be displayable depending on
the input signal.
• Selectable picture size may vary with input signal type.
• You can also select Wide Mode options by pressing WIDE
button on the remote control unit.
HProgramme (TV programme input mode
only)
Activate
• On: To activate Programme.
• Off: To deactivate Programme.
Password
Enter 4 digits Password using 0 – 9.
(For example: 0000)
After completing the above setting, please switch the
power off to activate.
NOTE
• When “Activate ” is “On” and Password is set, “Setup”
menu item cannot be selected.
Please enter the correct Password.
Input Signal
1024 g768
1280 g1024
Normal
Keeps the
original aspect
ratio in a full
screen display.
Full Screen
An image fully
fills the screen.
Dot by Dot
Detects the
resolution of
the signal and
displays an image
with the same
number of pixels
on the screen
(only when
receiving a XGA/
WXGA signal).
HAudio Only
When listening to music from a music programme,
you can set the display off and enjoy audio only.
• On: Audio is output without screen image.
• Off: Both screen images and audio are output.
NOTE
• When you make operations that change the picture on the
TV such as by changing the input source, the Audio Only
function is set to “Off”.
• You can turn off Audio Only function by pressing any key
on the remote control unit except VOLk/VOLl, e
(Mute) and POWER button.
HWide Mode
The Wide Mode changes as shown below.
Selected item Description
Auto Automatically set to suitable Wide Mode
depending on the input signal containing
the WSS information.
4:3 For 4:3 “standard” pictures. A side bar
appears on each side.
14:9 For 14:9 letterbox pictures. A thin side
bar appears on each side, and you may
also see bars on the top and bottom with
some programmes.
16:9 For 16:9 letterbox pictures. Bars may
appear on the top and bottom with some
programmes.
Subtitle As 16:9 but shifted up to show subtitles.
Part of the picture (top) is cropped. Part
of the bottom black bar is cropped.
Aspect ratio corrected.
Wide Screen For 4:3 “standard” pictures. In this mode
the picture is progressively stretched
toward each side of the screen.
Full Screen For 16:9 squeeze pictures.
Good morning. How are you?
4:3 14:9 16:9
Full Screen Wide Screen Subtitle
Treble
Bass
Balance
Surround On
VMD On
Movie
[0]
[0]
[0]
MENU[Audio]
Picture Audio Setup Feature
Reset
1Press MENU and the MENU screen displays.
2Press c/dto select “Audio”.
3Press a/bto select the desired menu item.
4Press c/dto adjust the item to the desired
level.
5Press MENU or EXIT to exit menu screen.
HAudio adjustments
Selected item c button d button
Treble For weaker treble For stronger treble
Bass For weaker bass For stronger bass
Balance Decrease audio
from the right
speaker
Decrease audio
from the left
speaker
HSurround
When you set to “On”, you can enjoy surround
sound, the same as if you were in a movie theatre.
• On: Makes it possible to enjoy natural, realistic surround
sound.
• Off: Outputs the normal sound.
HVMD (Voice Music Detection)
This function automatically detects whether the
sound is voice or music and then adjusts the sound
quality so it is comfortable for your ears.
NOTE
• For resetting all adjustment items to the factory preset
values, press a/bto select “Reset”, and then press c/d
to select “On”.
LC22L50M-L50M_EN.indd 6LC22L50M-L50M_EN.indd 6 9/14/09 2:44:55 PM9/14/09 2:44:55 PM

13 14
Connecting a PC (Picture menu) Teletext* function
Picture and still image
Feature menu (Continued)
Switching the analogue audio format
HHorizontal
Centres the image by moving it to the left or
right.
HVertical
Centres the image by moving it up or down.
HPhase
Adjust when characters have low contrast or
when the image flickers.
HClock
Adjust when the image flickers with vertical
stripes.
3Press c/dto adjust the item to your desired
position.
4Press MENU or EXIT to exit menu screen.
NOTE
• For resetting all adjustment items to the factory preset
values, press a/bto select “Reset”, and then press c/d
to select “On”.
• Images may not be displayed properly depending on the
settings and/or input signals.
• For certain resolution of PC or HDMI input which TV
unable to display, “Incompatible Input Signal” message will
appear.
• For compatible resolution, please refer to PC
compatibility chart.
Power management
You can set the TV to automatically standby mode
for approximately 4 seconds when no image is
displayed on PC.
1Repeat steps 1 to 2 in Auto Sync..
2Press a/bto select “Power Management”.
3Press c/dto select “On”.
4Press MENU or EXIT to exit menu screen.
NOTE
• See page 10 for details on “Contrast”, “Brightness”,
“Colour”, “Backlight” and “Colour Temp.”.
PC compatibility chart
Resolution Horizontal
Frequency
Vertical
Frequency
VESA
Standard
VGA 640 g480 31.5 kHz 60 Hz ✓
SVGA 800 g600 37.9 kHz 60 Hz ✓
XGA 1024 g768 48.4 kHz 60 Hz ✓
WXGA 1360 g768 47.7 kHz 60 Hz ✓
SXGA
1280 g1024
64.0 kHz 60 Hz ✓
Power Management is a registered trademark of Sun
Microsystems, Inc.
VGA and XGA are registered trademarks of International
Business Machines Corp.
Power Management On
Reset
Contrast
Brightness
Colour
Backlight
Auto Sync.
Horizontal
Vertical
Phase
Clock
Colour Temp.
[ 30]
[0]
[0]
[0]
[0]
[0]
[0]
[0]
MENU[Picture]
Picture Audio Setup Feature
Adjusting the PC image automatically
This function enables the screen to be automatically
adjusted to its best possible condition when the
analogue terminals of the TV and PC are connected
with a commercially available RGB cable, etc.
HAuto Sync.
1Press MENU and the MENU screen displays.
2Press c/dto select “Picture”.
3Press a/bto select “Auto Sync.”.
4Press c/dand Auto Sync. is started.
“Adjusting” will shown during Auto Sync. only.
5Press MENU or EXIT to exit menu screen.
NOTE
• Auto Sync. is likely to succeed when an input PC image
has wide vertical stripes (e.g. pattern with high contrast
stripes, or cross-hatched).
It may fail when an input PC image is solid (low contrast).
• Be sure to connect the PC to the TV and switch it on
before starting Auto Sync.
Adjusting the PC image manually
Ordinarily you can easily adjust the picture as
necessary to change image position using Auto
Sync. In some cases, however, manual adjustment
is needed to optimise the image.
1Repeat steps 1 to 2 in Auto Sync..
2Press a/bto select a specific adjustment item
among “Horizontal”, “Vertical”, “Phase” and
“Clock”.
What is Teletext?
Teletext broadcasts pages of information and
entertainment to specially equipped television sets.
News, weather reports, sports information, stock
exchange prices and programme previews are
among the many services available.
Turning on and off Teletext
1Select a TV channel or external input source
providing the Teletext programme.
2Press mto display the Teletext.
3Each time you press m, the screen switches
as shown below.
Button functions
Buttons Description
a/bIncrease or decrease the page number.
Colour
(Red/Green/
Yellow/Blue)
You can select a group or block of pages
displayed in the coloured brackets at
the bottom of the screen by pressing
the corresponding Colour (Red/Green/
Yellow/Blue) on the remote control unit.
0 — 9 Directly select any page from 100 to 899
by using 0 — 9.
v(Top/
Bottom/Full)
Switch the Teletext image to Top, Bottom
or Full.
k(Reveal
hidden
TELETEXT)
To reveal hidden information such as an
answer to a quiz.
3(Hold) To stop updating Teletext pages
automatically or release the hold mode.
[(Subtitle
for
TELETEXT)
Display the subtitle or exit the subtitle
screen.
• Subtitle will not be displayed when
the service does not contain subtitle
information.
1(Subpage) Change subpage display.
TELETEXT
TELETEXT
You can freeze a motion picture on the Display.
1Press FREEZE.
• A still image displays.
2Press FREEZE again to exit still image.
NOTE
• The still image automatically goes out after 30 minutes.
• FREEZE doesn’t function for HDMI/COMPONENT input
(1080p resolution) and PC input (all resolution). “Not
Available” message will appear.
HBlue Back
Automatically turns the screen blue if a broadcast
signal is not received.
HHDMI Audio (HDMI input mode only)
• Digital: Select “Digital” for audio signal via the HDMI
terminal.
• Analogue: Select “Analogue” for audio signal via
the AUDIO jack.
HPower Save
Reduces the picture brightness to create a softer
image while saving electricity.
You can switch between multiple audio modes
when watching a multiple audio or stereo broadcast
programme.
Icon Mode
b (red) Nicam Force Mono
b (green) Force Mono
(white) Stereo
(red) Nicam Stereo
I(white) Dual I
II (white) Dual II
I(red) Nicam Dual I
II (red) Nicam Dual II
empty Mono
NOTE
• The reception mode is depend on the receiving signal.
** MPX function is not applicable for Philippines market.
NOTE
* Teletext function is not applicable for Philippines market.
LC22L50M-L50M_EN.indd 7LC22L50M-L50M_EN.indd 7 9/14/09 2:45:02 PM9/14/09 2:45:02 PM

15 16
Appendix Specifications
Troubleshooting
The problems described below are not always caused by malfunctions. Check the TV again before having the
TV serviced.
Problem Possible Solution
• No power. • Check if you pressed POWER on the remote control unit. (See page 8.)
If the indicator on the TV lights up red, press POWER.
• Is the AC cord disconnected?
• Has the power been turned on? (See page 8.)
• Unit cannot be operated. • External influences such as lightning, static electricity, etc., may cause improper
operation. In this case, operate the unit after first turning the power off the TV or
unplugging the AC cord and re-plugging it in after 1 or 2 minutes.
• Remote control unit does not
operate.
• Are batteries inserted with polarity (e, f) aligned? (See page 6.)
• Are batteries worn out? (Replace with new batteries.)
• Are you using it under strong or fluorescent lighting?
• Is a fluorescent light shining on the remote control sensor?
• Picture is cut off. • Are screen mode adjustments such as picture size made correctly? (See page 12.)
• Strange colour, light colour, or
dark, or colour misalignment.
• Adjust the picture tone. (See page 10.)
• Is the room too bright? The picture may look dark in a room that is too bright.
• Check the colour system setting. (See page 9.)
• Power is suddenly turned off. • The unit’s internal temperature has increased.
Remove any objects blocking the vent or clean.
• Is the sleep timer set? (See page 5.)
• No picture. • Is the connection to external equipment correct? (See page 4.)
• Is the picture adjustment correct? (See page 10.)
• Is the antenna connected properly? (See page 3.)
• Is “On” selected in “Audio Only”? (See page 12.)
• No sound. • Is the volume too low? (See page 5.)
• The TV sometimes makes a
cracking sound.
• This is not a malfunction. This happens when the cabinet slightly expands and
contracts according to changes in temperature. This does not affect the TV’s
performance.
Cautions regarding use in high and low temperature environments
• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly
delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near
a heater, as this may cause the cabinet to deform and the LCD panel to malfunction.
Storage temperature:
f20°C to e60°C.
Resetting the Password
If you forget your password,
1Press MENU and the MENU screen displays.
2Press c/dto select “Feature”.
3Press a/bto select “ Programme”, and then press ENTER. The password input screen displays.
4If you enter “1147” using 0 – 9, the “ Programme” setting menu will be displayed.
5Press a/bto select “Password”.
6Enter 4 digits Password using 0 – 9. The new password is now set.
7Press MENU or EXIT to exit menu screen.
Item Model LC-22L50M
LCD panel 22o(548 mm) LCD
Resolution 1,049,088 pixels (1366 g768)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Function
TV-Standard PAL: B/G, D/K, I SECAM: B/G, D/K, K/K1NTSC: M
Receiving
Channel
VHF/UHF 44.25—863.25 MHz
CATV S1—S41ch (including Hyperband)
TV-Tuning System Auto Preset 99 ch
STEREO/BILINGUAL NICAM: B/G, I, D/K A2 stereo: B/G
Backlight life 50,000 hours (at Backlight Standard position)
Viewing angles H : 170º V : 160º
Audio amplifier 10W g2
Speakers 10 g4 cm 2 pcs + 4 passive cone
Terminals Rear Antenna input UHF/VHF 75 qDIN type
HDMI HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
1080I/60Hz, 1080P/50Hz, 1080P/60Hz), AUDIO in (φ 3.5 mm jack)
AV-1 IN S-VIDEO in, VIDEO in, AUDIO in
AV-2 IN VIDEO in, AUDIO in
COMPONENT AUDIO in, COMPONENT in (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz,
1080I/50Hz, 1080I/60Hz)
PC input 15 pin mini D-sub, AUDIO in (φ 3.5 mm jack)
M.P. IN AUDIO in (φ 3.5 mm jack)
RS-232C 9 pin D-sub male connector
OSD language English/French/Portugues/Arabic
Power Requirement AC 110—240 V, 50/60 Hz
Power Consumption 55 W (1.7 W Standby)
Dimensions 691 (W) g454 (H) g186 (D) mm
Weight 7.5 kg
Operating Temperature 0°C — 40°C
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
LC22L50M-L50M_EN.indd 8LC22L50M-L50M_EN.indd 8 9/14/09 2:45:04 PM9/14/09 2:45:04 PM
