Sharp LC-52/60LE830E/RU/E[B]/RU[B] User manual

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
OUTLINE
CHAPTER 1. Removing LCD Module
[1] Removing LCD Module (LC-52LE835E/
RU,831E/S,833E)........................................... 1-1
[2] Removing LCD Module (LC-60LE835E/
RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/
E[B],60LE635E/RU,636E/S,638E) ................. 1-2
Parts Guide
TopPage
CONTENTS
No. S81T352LE830E
LCD COLOUR TELEVISION
MODELS
LC-52/60LE830E/RU/E[B]/RU[B]
LC-52/60LE831E/S/E[B]/S[B]
LC-52/60LE833E/E[B]
LC-60LE635E/RU
LC-60LE636E/S
LC-60LE638E
LCD Module Edition
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
i
LC52LE830E Service Manual
OUTLINE
•Information of service parts in the LCD Module
Unit
Model Name Unit Name Description
LC-52LE830E/RU,831E/S,833E R1LK520D3GW40P 52" LCD Panel Module Unit
(LK520D3GW40P)
LC-52LE830E[B]/RU[B],831E[B]/S[B],833E[B] R1LK520D3GW4BY 52" LCD Panel Module Unit
(LK520D3GW4BY)
LC-60LE830E/RU,831E/S,833E R1LK600D3GW40H 60" LCD Panel Module Unit
(LK600D3GW40H)
LC-60LE830E[B]/RU[B],831E[B]/S[B],833E[B] R1LK600D3GW4BH 60" LCD Panel Module Unit
(LK600D3GW4BH)
LC-60LE635E/RU,636E/S,638E R1LK600D3GW7CH 60" LCD Panel Module Unit
(LK600D3GW7CH)

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
1 – 1
LC52LE830E Service Manual
CHAPTER 1. Removing LCD Module
[1] Removing LCD Module (LC-52LE835E/RU,831E/S,833E)
1. Remove the 19 lock screws , 5 lock screws , 21 lock screws and detach the Bezel Unit (Top) , Bezel Unit (Bottom) , Bezel Unit
(Right) , Bezel Unit (Left) .
2. Detach the 52” LCD Panel Unit , P-Chassis (Top) , P-Chassis (Bottom) , 2 P-Chassis (Left/Right) .
3. Detach the DBEF Sheet , Lens Sheets , Diffusion Sheets , Light Guide Plate , Reflection Sheet .
4. Remove the 28 lock screws , and detach the 2 Installation Angle .
5. Remove the 48 lock screws , and detach the 4 LED PWB .
6. Remove the 10 lock screws , and detach the 2 Holder Unit .
7. Detach the Fit Cover (Cap) , and Disconnect the LED PWB Connection Harness .
8. Detach the BL Chassis .
13
15
12
14
16
11
9
10
11
26
24
18
20
21
19
21
22
23
22
23
20
25
21
21
8
1
52" LCD
Panel Unit
Bezel Unit (Top)
Bezel Unit
(Left)
Bezel Unit (Bottom) Bezel Unit
(Right)
P-Chassis Unit (Top)
P-Chassis
Unit (Left)
P-Chassis Unit (Bottom)
P-Chassis Unit (Right)
Reflection Sheet
Diffusion Sheet
DBEF Sheet
Light Guide
Plate
Lens Sheet
Holder Unit
Holder Unit
Installation Angle
Installation Angle
LED PWB
LED PWB
LED PWB
LED PWB
Fit Cover
(Cap)
BL Chassis
3
2
7
6
1
1
1
4
5
19
18

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
1 – 2
[2] Removing LCD Module (LC-60LE835E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/
E[B],60LE635E/RU,636E/S,638E)
1. Remove the 19 lock screws , 7 lock screws , 22 lock screws and detach the Bezel Unit (Top) , Bezel Unit (Bottom) , Bezel Unit (Right/
Left) .
2. Detach the 60” LCD Panel Unit , P-Chassis (Top) , P-Chassis (Bottom) , 2 P-Chassis (Right/Left) .
3. Detach the DBEF Sheet , Lens Sheets , Micro Lens Sheets , Light Guide Plate , Reflection Sheet .
4. Remove the 18 lock screws , and detach the 2 Installation Angle .
5. Remove the 8 lock screws , and detach the 4 LED PWB .
6. Remove the 6 lock screws , and detach the 2 Holder Unit .
7. Detach the Fit Cover (Cap) , and Disconnect the LED PWB Connection Harness .
8. Detach the BL Chassis .
Light Guide Plate
Reflection Sheet
3
2
6
6
1
1
1
1
4
7
5
60" LCD Panel Unit
10
8
9
10
13
15
11
12
14
25
23
22
20
20 21
21
19 22
17
18
20
20
19
17
18
24
Micro Lens Sheet
P-Chassis
Unit (Top)
P-Chassis
Unit (Bottom)
P-Chassis
Unit Left
P-Chassis
Unit Right
Bezel Unit
(Top)
Bezel Unit
(Bottom)
Bezel Unit
(Left)
Bezel Unit (Right)
LED PWB
LED PWB
LED PWB
LED PWB
Installation Angle
Installation Angle
Holder Unit
Holder Unit
BL Chassis
Fit Cover (Cap)
DBEF Sheet
Lens Sheet

PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
PartsGuide
[1] LCD PANEL MODULE UNIT (LC-
52LE830E/RU/E[B}/RU[B],831E/S/
E[B]/S[B],833E/E[B])
[2] LCD PANEL MODULE UNIT (LC-
60LE830E/RU/E[B]/RU[B],831E/S/
E[B]/S[B],833E/E[B]/60LE635E/
RU,636E/S,638E)
CONTENTS
No. S81T352LE830E
MODELS
LC-52/60LE830E/RU/E[B]/RU[B]
LC-52/60LE831E/S/E[B]/S[B]
LC-52/60LE833E/E[B]
LC-60LE635E/RU
LC-60LE636E/S
LC-60LE638E
LCD COLOUR TELEVISION

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
2
[1] LCD PANEL MODULE UNIT (LC-52LE830E/RU/E[B}/RU[B],831E/S/E[B]/S[B],833E/E[B])
17
15
18
1
16
14
21
19
20
21
2
313
4
11
26
9
7
8
7
6
5
6
5
9
10
7
7
8
11
27
24
25
22
23
27
27
27
28
52" LCD Panel Unit

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
3
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] LCD PANEL MODULE UNIT (LC-52LE830E/RU/E[B}/RU[B],831E/S/E[B]/S[B],833E/E[B])
1R1LK520D3GW40P N P 52" LCD Panel Module Unit (LK520D3GW40P) (LC-52LE830E/RU,831E/S,833E)
1R1LK520D3GW4BY N P 52" LCD Panel Module Unit (LK520D3GW4BY) (LC-52LE830E[B}/RU[B],831E[B]/
S[B],833E[B])
2CCHSM0331TP03 J BL Chassis
3PCOVP2986TPZZ AB J Fit Cover (Base)
4ZLABL2018TPZZ AD J BL Label
5CHLDZ4800TP02 AP J Holder Unit, x2
6LX-BZ2568TPZZ AA J Screw, x10
7RUNTK4831TPZZ BD J LED PWB, x4 (LC-52LE830E/RU,831E/S,833E)
7RUNTK4989TPZZ BC J LED PWB, x4 (LC-52LE830E[B}/RU[B],831E[B]/S[B],833E[B])
8CANGT0342TP01 BA J Installation Angle, x2
9LX-HZ2417TPZZ AA J Screw, x48
10 QCNWN2672TPZZ AR J LED PWB Connection Harness
11 LX-HZ2414TPZZ AA J Screw, x28
13 PCOVP2989TPZZ AB J Fit Cover (Cap)
14 PREFL3360TPZZ AX J Reflection Sheet
15 PLGPA0787TPZZ BN J Light Guide Plate
16 PSLDK3608TPZZ BB J Micro Lens Sheet
17 POFMA1278TPZZ AY J Lens Sheet
18 POFMD0618TPZZ BQ J DBEF Sheet
19 CHLDZ4796TP09 J P-Chassis Unit (Top)
20 CHLDZ4797TP05 J P-Chassis Unit (Bottom)
21 CHLDZ4798TP01 AL J P-Chassis Unit (Left/Right), x2
22 CANGK4934TP05 J Bezel Unit (Top)
23 CANGK4935TP0C J Bezel Unit (Bottom)
24 CANGK4936TP06 J Bezel Unit (Left)
25 CANGK4937TP06 J Bezel Unit (Right)
26 LX-UZ2067TPZZ AB J Screw, x21
27 LX-BZ2568TPZZ AA J Screw, x19
28 LX-BZ2574TPZZ AA J Screw, x5

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
4
[2] LCD PANEL MODULE UNIT (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B]/60LE635E/RU,636E/S,638E)
25
26
23
23
27
27
27
27
21
22
60" LCD Panel Unit 20
18
19
20
15
13
17
1
16
14
4
3
2
28
5
8
8
6
6
9
5
11
7
8
8
9
11
7
10
34
34

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
5
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[2] LCD PANEL MODULE UNIT (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B]/60LE635E/RU,636E/S,638E)
1R1LK600D3GW40H N P 60" LCD Panel Module Unit (LK600D3GW40H) (LC-60LE830E/RU,831E/S,833E)
1R1LK600D3GW4BH N P 60" LCD Panel Module Unit (LK600D3GW4BH) (LC-60LE830E[B]/RU[B],831E[B]/
S[B],833E[B])
1R1LK600D3GW7CH N P 60" LCD Panel Module Unit (LK600D3GW7CH) (LC-60LE635E/RU,636E/S,638E)
2CCHSM0132TP01 BS J BL Chassis
3ZLABL2018TPZZ AD J BL Label
4PCOVP2986TPZZ AB J Fit Cover (Base)
5CHLDZ4605TP01 AT J Holder Unit, x2
6LX-HZ2414TPZZ AA J Screw, x6
7CANGT0136TP01 BC J Installation Angle, x2
8RUNTK4830TPZZ BG J LED PWB , x4 (LC-60LE830E/RU,831E/S,833E)
8RUNTK5028TPZZ BD J LED PWB , x4 (LC-60LE830E[B]/RU[B],831E[B]/S[B],833E[B])
8RUNTK5032TPZZ BH J LED PWB , x4 (LC-60LE635E/RU,636E/S,638E)
9LX-HZ2417TPZZ AA J Screw, x8
10 QCNWN2671TPZZ AR J LED PWB Connection Harness
11 LX-HZ2414TPZZ AA J Screw, x18
13 PREFL3387TPZZ J Reflection Sheet
14 PLGPA0786TPZZ BR J Light Guide Plate
15 PSLDK3607TPZZ BF J Micro Lens Sheet
16 POFMA1279TPZZ BA J Lens Sheet
17 POFMD0649TPZZ BS J DBEF Sheet (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B])
17 PSLDK3521TPZZ BF J Diffusion Sheet (LC-60LE635E/RU,636E/S,638E)
18 CHLDZ4601TP0A J P-Chassis Unit (Top) (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B])
18 CHLDZ4601TP09 J P-Chassis Unit (Top) (LC-60LE635E/RU,636E/S,638E)
19 CHLDZ4602TP0D J P-Chassis Unit (Bottom) (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B])
19 CHLDZ4602TP0C J P-Chassis Unit (Bottom) (LC-60LE635E/RU,636E/S,638E)
20 CHLDZ4603TP02 AQ J P-Chassis Unit (Left/Right), x2 (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/
E[B])
20 CHLDZ4603TP03 AW J P-Chassis Unit (Left/Right), x2 (LC-60LE635E/RU,636E/S,638E)
21 CANGK4749TP03 J Bezel Unit (Top) (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B])
21 CANGK4748TP03 AS J Bezel Unit (Top) (LC-60LE635E/RU,636E/S,638E)
22 CANGK4749TP0A J Bezel Unit (Bottom) (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B])
22 CANGK4749TP09 AX J Bezel Unit (Bottom) (LC-60LE635E/RU,636E/S,638E)
23 CANGK4749TP03 J Bezel Unit (Left/Right), x2 (LC-60LE830E/RU/E[B]/RU[B],831E/S/E[B]/S[B],833E/E[B])
23 CANGK4750TP03 AQ J Bezel Unit (Left), x2 (LC-60LE635E/RU,636E/S,638E)
23 CANGK4751TP03 AQ J Bezel Unit (Right), x2 (LC-60LE635E/RU,636E/S,638E)
25 LX-UZ2067TPZZ AB J Screw, x22
26 LX-HZ2574TPZZ J Screw, x7
27 LX-HZ2568TPZZ J Screw, x19
28 PCOVP2989TPZZ AB J Fit Cover (Cap)
34 PSPAG1054TPZZ J Spacer, x4

LC-52/60LE830E,RU/831E,S/833E/60LE635E/RU,636E/S,638E
COPYRIGHT © 2011 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No Part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any from or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.
SHARP CORPORATION
AV Systems Group
CS Promotion Center
Yaita,Tochigi 329-2193, Japan
Nov. 2011
SH. DS
