In the interest of user-safety the unit should be restored to its original condition and only parts identical to those specified should
be used.
WARNING TO SERVICE PERSONNEL:
This service manual is intended for use by persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable in the appliance repair trade. Sharp Electronics
Corporation cannot be responsible, nor assume any liability, for injury or damage of any kind arising from the
use of this manual.
Microwave ovens contain circuitry capable of producing very high voltage and current. Contact with the
following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor, High Voltage
Power Transformer, High Voltage Rectifier, Heat sink, Magnetron, and High Voltage Harness etc..)
R-1214TYA
OVER THE COUNTER MICROWAVE MODELS
SUPPLEMENTAL SERVICE MANUAL
This document has been published to be used for after sales service only. The contents are subject to change without notice.
SHARP ELECTRONICS CORPORATION
R-1214TYA pictured
R-1210TYA pictured
R-1210TYA/1211TYA
SENSOR
*FOR SERIAL NUMBERS: R1210TYA ~ 511869
R1211TYA ~ 511172
R1214TYA ~ 513122
This is a supplemental Service Manual for Models R-1210TYA, R-1211TYA & R-1214TYA. Use this
supplemental manual together with the following base model for complete operation, service information, etc.
R-1210TY, R-1211TY & R-1214TY S30M322R12OTCY (base model R-1200 & R1201).
Units with "A" at end of model number employ a change to the connectors on
various Components, Harnesses and PWB’s.
Use this Service Manual for all units with the Serial Number range
R1210TYA ~ 511869 and above , R1211TYA ~ 511172 and above ,
R1214TYA ~ 513122
and above.
*NOTE:

2
R-1210TYA
R-1211TYA
R-1214TYA
SUPPLEMENTAL SERVICE MANUAL
OVER THE COUNTER MICROWAVE OVEN
R-1210TYA / R-1211TYA / R-1214TYA
FOREWORD
This Manual has been prepared to provide Sharp Electronics Corp. Service Personnel with Operation and Service Informa-
tion for the SHARP OVER THE COUNTER MICROWAVE OVENS.
It is recommended that service personnel carefully study the entire text of this manual so that they will be qualified to render
satisfactory customer service.
Check the interlock switches and the door seal carefully. Special attention should be given to avoid electrical shock and
microwave radiation hazard.
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained service personnel.
DANGER
Certain initial parts are intentionally not grounded and present a risk of electrical shock only during servicing.
Service personnel - Do not contact the following parts while the appliance is energized;
HighVoltage Capacitor, PowerTransformer, Magnetron, HighVoltage Rectifier Assembly, HighVoltage Harness;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked “*” on parts list are used at voltages more than 250V.
Removal of the outer wrap gives access to voltage above 250V.
All the parts marked “∆” on parts list may cause undue microwave exposure, by themselves, or when they are dam-
aged, loosened or removed.
BEFORE SERVICING
Before servicing an operative unit, perform a microwave emission check as per the Microwave Measurement
Procedure outlined in this service manual.
If microwave emissions level is in excess of the specified limit, contact SHARP ELECTRONICS
CORPORATION immediately @1-800-237-4277.
TO ACCESS INTERNET: http://www.sharpusa.com/Support.aspx
If the unit operates with the door open, service person should 1) tell the user not to operate the oven and 2)
contact SHARP ELECTRONICS CORPORATION and Food and Drug Administration's Center for Devices
and Radiological Health immediately.
Service personnel should inform SHARP ELECTRONICS CORPORATION of any certified unit found with
emissions in excess of 4mW/cm2. The owner of the unit should be instructed not to use the unit until the oven
has been brought into compliance.

3
R-1214TYA R-1210TYA
R-1211TYA
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. COOKING TIME PROGRAMMED.
3. VARIABLE COOKING CONTROL "HIGH".
4. "START" BUTTON PRESSED.
Oven Schematic-Cooking Condition
Oven Schematic-Off Condition
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. CLOCK APPEARS ON DISPLAY.
0.0022 uF 250V
0.0022 uF 250V
V3
V1 V5
V7
CN201 CN101
#3(L)
#1(N) #1(+)
#2(-)
SW UNIT
0.0022 uF 250V
0.0022 uF 250V
V3
V1 V5
V7
CN201 CN101
#3(L)
#1(N) #1(+)
#2(-)
SW UNIT

4
R-1210TYA
R-1211TYA
R-1214TYA
NOISE FILTER TEST
1. Disconnect the power supply cord, and then remove outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
4. Disconnect the leads to the primary of the power transformer.
5. Using an ohm-meter, check between the terminals as described in the following table:
MEASURING POINT INDICATION OF OHM-METER
Between N and H 275 - 415Ω
Between terminal N and LOAD Short Circuit
Between terminal H and LOAD Short Circuit
Fuse Short Circuit
If fuse is open, replace fuse
If incorrect readings are obtained, replace the noise filter.
6. Reconnect all leads removed from components during testing.
7. Re-install the outer case (cabinet).
8. Reconnect the power supply cord after the outer case is installed.
9. Run the oven and check all functions.
NOISE FILTER UNIT
NOISE SUPPRESSION COIL
LINE CROSS CAPACITOR 1.0 µF 275V
RESISTOR 470 K Ω1/2W
LINE BYPASS CAPACITOR
LINE BYPASS CAPACITOR
0.0022 µF/ 250v
0.0022 µF/ 250v
TO LOAD TO LOAD
H
N
MONITOR
FUSE
“TO SOURCE” “TO SOURCE”
SWITCHING POWER SUPPLY
1. Check AC power into CN101,
if none check Main Harness.
2. Check DC power across CN201 (DC15V),
if none replace Switching Power Supply Unit
3. Check for DC getting from Switching Power Supply Unit
to PSU/ CPU, if none check Main Harness.
CN101
CN201

5
R-1214TYA R-1210TYA
R-1211TYA
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
HIGH VOLTAGE RECTIFIER
HIGH VOLTAGE CAPACITOR
HIGH VOLTAGE WIRE A
HIGH VOLTAGE COMPONENTS
DISPLAY UNIT
POWER TRANSFORMER
Power Supply cord 120V 60Hz
1 2 3
WHT
GRN
BLK
WHT
GRN
BLK
CAVITY THERMAL CUT-OUT
MAGNETRON TEMPERATURE FUSE
FAN MOTOR
TURNTABLE MOTOR
WHT WHT
WHT
ORG
WHT BLK
HOOD LAMPS & SOCKETS
Blue Marking
Blue Marking
OVEN LAMP & SOCKET
GRY
WHT
WHT
WHT
WHT
PRIMARY INTERLOCK SWITCH
N.O.
N.C.
COM.
COM.
MONITOR SWITCH
GRN
RED
N.O.
COM.
DOOR SENSING SWITCH
RY1 N.O.
RY1 COM.
RY2 N.O. RY2 COM.
1
2
3 4 5
ORG
BRN
RED
CN-A
R
E
D
WHT
GRY
BLK
RED
BLK
WHT
GRY
1
2RED
CN-B
BLK
BLK RED
RED BLK
RED
MAGNETRON
W
H
T
RED
WHT
BLK
WHT
NOISE FILTER
BOARD
N
H
RED
GRY
N.O.
CN-C
CN-G
CN-C
CN-A
CN-F 1
21
5
RY1
RY3
RY4
COM.
RY2
to Base Plate
71
CN-V
1
2
3 4 5 6 7
BRN BLK
GRY
ORG
CN-V
CN101
CN201
1 2 3
12
C101
L101
C201
M1
L202
C106
C105
C202
C201
L201
SWITCHING POWER SUPPLY
RED
BLK
BRN
31
CN-B
11 1
RELAY UNIT
BLK AH SENSOR RED
1 2
WHT3
CN-F
11-PIN WIRE HARNESS
ORG
RED
BRN
YLW
GRN
BLU
PPL
GRY
WHT
3 2 1 5 4 7 6 9
BLK 10
PNK 11
8
CN-C
3215
47 6910 11
8
CN-C
RED
WHT
GRN
BLK
W
H
T
N.O.
COM.
BRN RED ORG YLW GRN BLU PPL GRY WHT BLK PNK
Pictorial Diagram

6
R-1210TYA
R-1211TYA
R-1214TYA
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
∆*
ELECTRIC PARTS
1- 1 FH-DZB028MRY0 High voltage rectier assembly 1 AM
1- 2 RC-QZA336WRZZ High voltage capacitor 1 AT
1- 3 QFS-TA013WRE0 Temperature fuse 150oC (Magnetron) 1 AG
1- 4 RMOTDA252WRZZ Turntable motor 1 AN
1- 5 QFS-TA014WRE0 Temperature fuse 150oC (Cavity) 1 AG
1- 6 RMOTEB031MRE0 Fan motor 1 AT
1- 7 RTRN-B098MRE0 Power transformer 1 BP
1- 8 RV-MZA347WRZZ Magnetron 1 BH
1- 9 FPWBFA512WRKZ Noise lter unit 1 AN
1-10 QSW-MA168WRZZ Primary interlock and door sensing switches 2 AF
1-11 QSW-MA169WRZZ Monitor switch 1 AD
1-12 FACCDA130WREZ Power supply cord 1 AP
1-13 QSOCLA021WRE0 Oven lamp socket and hood lamp sockets 3 AG
1-14 RLMPTA086WRZZ Oven lamp and hood lamps 3 AL
1-15 FDTCTA263WRKZ AH sensor 1 AQ
1-16 DPWB-B451DRKZ Switching power supply 1 AZ
1-17 QFS-BA009WRE0 20A fuse 1 AF
CABINET PARTS
2- 1 HDECQB033MRF0 Bottom sash [R-1210TYA] 1 AR
2- 1 HDECQB034MRF0 Bottom sash [R-1211TYA] 1 AR
2- 1 FDECAB044MRK0 Bottom sash [R-1214TYA] 1 AX
2- 2 GDAI-A464WRWZ Base plate R 1 AR
2- 3 GCABUB194WRPZ Outer case cabinet [R-1210TYA] 1 BF
2- 3 GCABUB196WRPZ Outer case cabinet [R-1211TYA] 1 BK
2- 3 GCABUB198WRPZ Outer case cabinet [R-1214TYA] 1 BK
2- 4 TMAPCA836WRRZ Schematic diagram 1 AC
2- 5 FANGKB009MRY0 Hood lamp glass assembly [R-1210TY/R-1214TYA] 1 AP
2- 5 FANGKB029MRY0 Hood lamp glass assembly [R-1211TYA] 1 AQ
2-5-1 LANGQB016MRP0 Hood lamp glass angle [R-1210TYA/R-1214TYA] 1 AM
2-5-1 LANGQB082MRP0 Hood lamp glass angle [R-1211TY] 1 AN
2-5-2 PGLSPB004MRE0 Hood lamp glass 1 AQ
2- 6 PCOVPA567WRTZ Base cover [R-1210TYA/R-1214TYA] 1 AW
2- 6 PCOVPA570WRTZ Base cover [R-1211TYA] 1 AZ
RIGHT PANEL PARTS
3- 1 DPWB-B474DRKZ 8 Relay unit 1 AX
3- 2 HPNLCC283WRFZ Right panel [R-1210TYA] 1 AR
3- 2 HPNLCC284WRFZ Right panel [R-1211TYA] 1 AR
3- 2 HPNLCB187MRF0 Right panel [R-1214TYA] 1 AR
3- 3 JBTN-B643WRFZ Open button [R-1210TYA] 1 AG
3- 3 JBTN-B644WRFZ Open button [R-1211TYA] 1 AG
3- 3 JBTN-B161MRF0 Open button [R-1214TYA] 1 AH
3- 4 MSPRCA045WRE0 Button spring 1 AD
3- 5 PSHEPB078MRR0 Menu label 1 AG
3- 6 XEPS730P10XS0 Screw; 3mm x 10mm 2 AF
OVEN PARTS
4- 1 PDUC-B119MRF0 Exhaust duct 1 AP
4- 2 FROLPA097WRKZ Turntable support assembly 1 AN
4- 3 NTNT-A108WREZ Turntable tray 1 AW
4- 4 LBNDKA186WRPZ Capacitor holder 1 AF
4- 5 PDUC-B155WRFZ Magnetron duct 1 AK
4- 6 MLEVPA297WRFZ Open lever 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1 --
4- 8 PPACGA084WRF0 Turntable motor packing 1 AE
4- 9 PHOK-A182WRFZ Latch hook 1 AG
4-10 FANGTA176WRYZ Unit mounting plate assembly 1 AN
4-11 NFANJA060WRFZ Fan blade 1 AH
4-12 LBSHCA014WRE0 Cord bushing 1 AG
4-13 MLEVFA094WRPZ Mounting lever 2 AF
4-14 PSKR-A506WRPZ Bottom air guide 1 AM
4-15 PCOVPA554WRPZ Waveguide cover 1 AF
4-16 MSPRTA046WRE0 Latch spring 2 AD
4-17 LANGTA479WRPZ Chassis support 2 AK

7
R-1214TYA R-1210TYA
R-1211TYA
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-18 LSTPPB039MRF0 Upper door stopper 1 AK
4-19 LSTPPB040MRF0 Lower door stopper 1 AK
4-20 PDUC-B159WRWZ Fan duct 1 AM
4-21 PDUC-B173WRFZ Orice 1 AK
4-22 PCUSGA796WRPZ Transformer cushion 1 AF
4-23 PCOVPA569WRPZ Light cover 1 AQ
4-24 PCUSUA674WRPZ Cushion 3 AF
4-25 LHLDPB004MRF0 PWB holder 1 AC
4-26 PCUSGA795WRPZ Vibration cushion 1 AD
4-27 PCUSGA794WRPZ Top cushion (required to keep moisture out) 1 AD
DOOR PARTS
5 CDORFB243WRKZ8 Door assembly [R-1210TYA] 1 BV
5 CDORFB244WRKZ8 Door assembly [R-1211TYA] 1 BV
5 CDORFB245WRKZ8 Door assembly [R-1214TYA] 1 BV
5- 1 DDORFB449WRKZ Door panel assembly 1 BL
5- 2 FCOV-A065WRKZ 8 Door frame assembly [R-1210TYA] 1 BR
5- 2 FCOV-A066WRKZ8 Door frame assembly [R-1211TYA] 1 BR
5- 2 FCOV-A068WRKZ8 Door frame assembly [R-1214TYA] 1 BR
5- 3 LSTPPB023MRF0 Latch head 1 AF
5- 4 MSPRTA046WRE0 Latch spring 1 AD
5- 5 GCOVHB045MRF0 Choke cover 1 AX
5- 6 PSHEPB016MRE0 Sealer lm 1 AK
5- 7 XEPS740P08000 Screw : 4mm x 8mm 2 AB
MISCELLANEOUS
6- 1 CFZK-B681WRKZ Installation material assembly 1 AQ
6-1-1 LBSHC0040MRE0 Grommet 1 AF
6-1-2 LX-BZ0195WRE0 Toggle screw 4 AH
6-1-3 XBRS750P60000 Screw : 5mm x 60mm 2 AK
6-1-4 XOTS740P12000 Screw : 4mm x 12mm 3 AB
6-1-5 XTSS750P35000 Screw : 5mm x 35mm 6 AD
6-1-6 XWHS750-16300 Washer 2 AG
6- 2 LANG-A138WRPZ Scale plate 2 AF
6- 3 TINSEB390WRRZ Operation manual 1 AG
6- 4 TINSKA034WRRZ Top and Wall template 1 AK
6- 5 QW-VZB011MRE0 Sensor gnd wire 1 AF
6- 6 QW-QZB025MRE0 High voltage wire A 1 AF
6- 7 FW-VZC510WREZ Main harness 1 AU
6- 8 TCAUAA302WRRZ DHHS service caution label 2 AF
6- 9 TCAUAA301WRRZ Monitor caution label 1 AF
6-10 TCAUAA300WRRZ Revised DHHS/GRD C/label 1 AF
SCREWS, NUTS AND WASHERS
7- 1 XOTS740P12000 Screw : 4mm x 12mm 32 AB
7- 2 XHTS740P08RV0 Screw : 4mm x 8mm 2 AG
7- 3 LX-CZ0052WRE0 Special screw 2 AA
7- 4 LX-BZ0195WRE0 Special screw 5 AH
7- 5 XCBS730P08000 Screw : 3mm x 8mm 5 AC
7- 6 XOTS740P08000 Screw : 4mm x 8mm 3 AB
7- 7 XEPS730P08XS0 Screw 4 AA

8
R-1210TYA
R-1211TYA
R-1214TYA
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
OVEN AND CABINET PARTS
4-10
2-4
4-17
7-3
1-10
1-9
6-9
4-17
6-8
7-3
7-3
7-3
7-3
7-1 A
6-10
7-1
4-13
4-15
4-8
7-5
2-1
2-6
1-13
7-1
7-1
1-14
7-1
7-1
7-1
1-4
1-11
7-1
2-5
1-10
4-21
4-13
7-4
4-16
4-16
7-3
7-6
7-1
4-20
4-5 1-7
4-23
4-24
4-22
7-1
4-14
7-1
7-1
5-2-4
2-2
6-8
4-9
7-2
1-8
1-14
1-13
4-6
4-3
4-7
4-2 7-1 4-11
7-5
7-1
7-5
6-11
7-1
2-3
1-15
6-5
4-1
7-5
7-5
1-5
4-12
1-12
7-1
7-1
1-3
1-6
1-2
1-1
4-4
7-4
7-1
2-5-1
2-5-2
1-17
B
B
A
7-5
7-7
4-25
1-16
7-6
4-26
4-27
REQUIRED
4-24

9
R-1214TYA R-1210TYA
R-1211TYA
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
RIGHT PANEL PARTS
6-6
6-7
6-5
6-1
6-1-1
6-1-2
6-1-6
6-2
6-1-4
6-1-5
6-1-3
5-2
5-5
5-6
5-1
54-18
4-19
5-7
5-7
7-2
3-3 3-4
3-5
3-2
3-1 3-6
5-4
5-3
MISCELLANEOUS
DOOR PARTS

10
R-1210TYA
R-1211TYA
R-1214TYA
PACKING AND ACCESSORIES
4-3 TURNTABLE TRAY
6-2 SCALE PLATE
TOP PAD
BOTTOM PAD
PACKING CASE
ACCESSORY PACK
WRAP COVER
Non-replaceable items
DOOR PROTECTOR
INSTALL MATERIAL ASSEMBLY
6-1
6-3 OPERATION MANUAL
6-4 TOP & WALL TEMPLATE

11
R-1214TYA R-1210TYA
R-1211TYA
NOTES

12
R-1210TYA
R-1211TYA
R-1214TYA
COPYRIGHT © 2017 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No part of this publication may be reproduced, stored
in retrieval systems, or transmitted in any form or by
any means, electronic, mechanical, photocopying,
recording, or otherwise, without prior written permis-
sion of the publisher.
SHARP ELECTRONICS CORPORATION
100 PARAGON DRIVE SUITE 100,
MONTVALE NJ 07645
