Sharp Carousel R-1514 User manual

1
2 WALL CONSTRUCTION
This Microwave Oven/Hood should be mounted against and supported by a flat vertical wall. The wall must be flat for proper
installation. If the wall is not flat, use spacers to fill in the gaps. Wall construction should be a minimum of 2” x 4” wood studding and
3/8” or more thick dry wall or plaster/lath. The mounting surfaces must be capable of supporting weight of 110 pounds—the oven
and contents—AND the weight of all items which would normally be stored in the top cabinet above the unit.
The unit should be attached to a minimum of one 2” x 4” wall stud.
To find the location of the studs, one of the following methods may be used:
A. Use a stud finder, a magnetic device which locates the nails in the stud.
B. Use a hammer to tap lightly across the mounting surface to find a solid sound. This will indicate stud location.
The center of the stud can be located by probing the wall with a small nail to find the edges of the stud and then placing a mark
halfway between the edges. The center of any adjacent studs will normally be 16” or 24” to either side of this mark.
OVER THE RANGE MICROWAVE OVEN/HOOD SYSTEM
INSTALLATION INSTRUCTIONS
®
Please read all instructions thoroughly before installing the Microwave Oven/Hood System.
Two people are recommended to install this product.
If a new electrical outlet is required, its installation should be completed by a qualified electrician before
the Microwave Oven/Hood is installed. See 3 ELECTRICAL GROUNDING INSTRUCTIONS on page 2.
1 MOUNTING SPACE
This Microwave Oven/Hood requires a mounting space on a
wall as shown in Figure 1. It is designed to be used with standard
12-inch wall cabinets.
If the space between the wall cabinets is 36 or 42 inches, a Filler
Panel Kit can be used to fill the gap.The metal filler panels come
in 3-inch wide pairs. One set is needed for a 36-inch opening and
2 sets for a 42-inch opening. See page 8 for ordering information.
TheFillerPanelKitshould beinstalledbefore theMicrowaveOven/
Hood is installed.
Backsplash
At least 2" 30" or more from
cooking surface
66" or more
from floor
15.5"
30"
12"
Figure 1

2
3 ELECTRICAL GROUNDING INSTRUCTIONS
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug. It must be
plugged into a wall receptacle that is properly installed and grounded in accordance with the National Electrical Code and local
codes and ordinances. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape
wire for the electric current.
WARNING - Improper use of the grounding plug can result in a risk of
electric shock.
The oven is equipped with a 3-prong grounding plug. DO NOT UNDER
ANY CIRCUMSTANCES CUT OR REMOVE THE GROUNDING PIN
FROM THE PLUG.
The Power Supply Cord and plug must be connected to a separate
120 Volt AC, 60 Hz, 15 Amp, or more branch circuit, single grounded
receptacle. The receptacle should be located inside the cabinet directly
above the Microwave Oven/Hood mounting location.
NOTE:
1. If you have any questions about the grounding or electrical instruc-
tions, consult a qualified electrician or serviceperson.
2. Neither Sharp nor the dealer can accept any liability for damage to
the oven or personal injury resulting from failure to observe the
correct electrical connection procedures.
Ground
Receptacle
Opening for
Power Cord
4 HOOD EXHAUST DUCT
When the hood is vented to the outside, a hood exhaust duct is required.All ductwork must be metal; absolutely do not use plastic
duct. Check that all connections are made securely. Please read the following carefully:
Exhaust connection: The hood exhaust has been designed to connect to a standard 3-1/4”x 10”rectangular duct. If round duct
is required, a rectangular-to-round adapter must be used.
Rear exhaust: If a rear or horizontal exhaust is to be used, care should be taken to align the exhaust with the space between the
studs, or wall should be prepared at the time it is constructed by leaving enough space between wall studs to accommodate
exhaust.
Maximum duct length: For satisfactory air movement, the total
duct length of 3-1/4”X 10”rectangular or 6”diameter round duct
should not exceed 140 feet.
Elbows, adapters, wall caps, roof caps, etc. present additional
resistance to air flow and are equivalent to a section of straight
duct which is longer than their actual physical size. When
calculating the total length, add the equivalent lengths of all
transitions and adapters plus the length of all straight duct
sections. Figure 3 shows the approximate feet of equivalent
length of some typical ductwork parts. Use the values in
parentheses for calculating air flow resistance equivalent, which
should total less than 140 feet.
Figure 2
Figure 3
5 TOOLS RECOMMENDED FOR INSTALLATION
•Phillips Screwdriver
•Electric Drill
•1/2”, 5/8”and 3/32”Drill Bits
•1-1/2”Wood Bit or Metal Hole
Cutter (if metal cabinet is used)
•Saw to cut exhaust opening
(if needed)
•Protective Drop Cloth for product
and range - you may also use
carton for protection
•Scissors
•Pencil
•Measure
•Tape

3
6 INSTALLATION HARDWARE
The INSTALLATION HARDWARE items
1-7are in a small bag. Items 8-"are
packed separately. All items are in a
small carton packed below the oven.
Figure 4
Parts shown not to
common scale.
ITEM NAME QUANTITY PART CODE
1Wood Screw 5 X 30 mm 6 XTSSD50P35000
2Toggle Bolt with nuts #10 - 24 X 50 mm 4 LX-BZ0195WRE0
3Top Cabinet Screw 5 X 60 mm 2 XBRSD50P60000
4Power Cord Hanger 1 LX-MZB001MRE0
5Tapping Screw 4 x 12 mm 3 XOTSD40P12000
6Flat Washer 30 mm diameter 2 XWHSD50-16300
7Grommet 1 LBSHC0040MRE0
8Rear Cushion 1 PCUSUB059MRP0
9Exhaust Damper Assembly 1 FFTA-B003MRK0
!Scale Plate 2 LANG-B002MRP0
"Grease Filter 2 PFIL-B002MRE0
7 PREPARATION OF THE OVEN
1. Openthebottom of the carton,bendthe carton flaps
back and tilt the oven over to rest on plasticfoam
pad. Lift carton off oven and remove all packing
materials, INSTALLATION INSTRUCTIONS,
WALL TEMPLATE, TOP TEMPLATE, Turntable
and Turntable Support. DO NOT REMOVE THE
WAVEGUIDE COVER, which is located on the right
side wall of the oven cavity.
2. Checktheoven foranydamage, such asmisaligned
or bent door, damaged door seals and sealing
surfaces, broken or loose door hinges and latches
and dents inside the cavity or on the door. If there
is any damage, do not operate the oven and
contact your dealer or SHARP AUTHORIZED
SERVICER.
3. Turn oven on the side. See Figure 5.
4. Followsteps(A)-(D)toremovemountingplatefrom
the back of the oven as shown in Figure 5.
(A) Release mounting plate by pulling out the lever
that is on the bottom of the oven. See Figure 6.
(B) When lever is out, pull that side of the mount-
ing plate away from the oven. See Figure 5.
(C) Repeat step (A) on other side.
(D) Repeat step (B) on other side.
Use screwdriver to
assist in releasing
mounting plate.
Mounting Plate
Bottom of Microwave
Figure 5
Figure 6
(A)
(B)
(C)
(D)
(A)

4
8 VENTILATION SYSTEM (PREPARING OVEN FOR INSTALLATION)
This Microwave Oven/Hood is designed for adaptation to three types of hood ventilation systems. Select the type required for your
installation.
Recirculating —non-vented, ductless. Follow installation procedure (A). Recirculating requires the use of the Charcoal Filter,
which has already been installed in the oven.
Horizontal Exhaust —outside ventilation. Follow installation procedure (B).
Vertical Exhaust —outside ventilation. Follow installation procedure (C).
(A) RECIRCULATING: Non-Vented, Ductless Operation
The unit is shipped assembled for recirculating.
NOTE: 1. The Exhaust Damper Assembly 9is not required for recirculating operation.
2. The Charcoal Filter should be replaced every 6 to 12 months, depending on use.
3. The Charcoal Filter RK-240 is also sold as an accessory. See Page 8 for ordering information.
(B) HORIZONTAL EXHAUST: Outside Ventilation
1. Remove 2 screws from back edge and 3 screws from the top center of Fan Cover Bracket. Save 2 screws to be used later and
discard remaining 3. Remove Fan Cover Bracket by sliding it in the opposite direction of the arrow on the Fan Cover Bracket,
as shown in Figure 7.
2. Lift Hood Fan Unit carefully and slip wires out of cavity. See Figure 8. CAUTION: Do not pull or stretch hood fan wiring.
3. Rotate the Hood Fan Unit 180˚so that the fan blade openings are facing the back of the oven. See Figure 9 (A). Replace Hood
Fan Unit into the oven. Be careful not to pinch the wire and the Hood Fan Unit. See Figure 9 (B).
4. Put the wire back into the cavity. See Figure 10.
Figure 7
Figure 9 Figure 10 Save fan cover bracket for future instructions.
Figure 8
(B)
(A) Rotate 180˚

5
(C) VERTICAL EXHAUST: Outside Ventilation
1. Remove and save 2 screws from back edge and 3 screws from the top center of the Fan Cover Bracket. Remove Fan Cover
Bracket by sliding it in the opposite direction of the arrow on the Fan Cover Bracket as shown in Figure 11.
2. Lift Hood Fan Unit carefully and slip wires out of cavity. See Figure 12. CAUTION: Do not pull or stretch hood fan wiring.
3. Rotate the Hood Fan Unit 90˚so that the fan blade openings are facing the top of the oven. See Figure 13 (A). Replace Hood
Fan Unit into the oven. Be careful not to pinch the lead wire between the inner bracket and the Hood Fan Unit. Put the lead wire
into Wire Box. See Figure 13 (B).
4. Replace the Fan Cover Bracket by sliding it into the slits in the same direction as the arrow on the Fan Cover Bracket. Make sure
the fan blades are visible through the top openings in the oven before proceeding.
5. Attach the Fan Cover Bracket to unit with the 2 screws from back edge and 3 screws from the top center of the Fan Cover
Bracket, which were removed in Step 1 above. See Figure 14. The Hood Fan Unit is now rotated for vertical exhaust operation.
6. Attach the Exhaust Damper Assembly 9to the fan cover on the top of the outercase cabinet by sliding it into the slits in the
same direction as the arrow. Use 1 Tapping Screw 4 X12 mm 5from the INSTALLATION HARDWARE and tighten into place.
See Figure 15.
Figure 13
Exhaust Damper Assembly
Figure 15
Figure 11 Figure 12
(A) Rotate 90˚
Figure 14
(B)

6
9 OVEN INSTALLATION
THIS OVEN CANNOT BE PROPERLY INSTALLED WITHOUT REFERRING TO THE MOUNTING INSTRUCTIONS FOUND ON
BOTH TEMPLATES.
THE NEXT STEP IS TO READAND FOLLOW MOUNTING INFORMATION ON BOTH TOP CABINETAND WALL TEMPLATES.
NOTE: THIS OVEN SHOULD BE ATTACHED TO AT LEAST ONE WALL STUD. See WALL CONSTRUCTION on page 1.
MOUNTING SCALE PLATE
Attached 2 Scale Plates !, with tape (not included). See Figure 16 and WALLTEMPLATE for locations.
Mounting
Plate
Figure 17 Figure 18 Figure 19
Space more than
wall thickness
Wall
Figure 16
Scale Plates
MOUNTING PLATE
1. Separate 4 Toggle Bolts 2, packed in the INSTALLATION HARDWARE, from the Toggle Nuts.
2. Match 5/8”holes (not in stud/s), drilled through WALL TEMPLATE into wall to corresponding holes on Mounting Plate.
3. Insert Toggle Bolts into matched openings on Mounting Plate. Put Toggle Nuts on Toggle Bolts. See Figure 17.
4. Position the Mounting Plate with the Toggle Bolts attached at the wall location and insert Toggle Nuts and Bolts through the
holes in the wall with the Toggle Nuts closed. Figure 18. Use Wood Screws 1to attach the Mounting Plate to studs.
NOTE: Before insertion, be sure you leave a space more than the thickness of the wall between the Mounting Plate and the end
of each of the Toggle Nuts (in the closed position). If you do not leave enough space, the Toggle Nut will not be able to open on
the other side of the wall. Also, once a Toggle Nut opens, it cannot be withdrawn from the hole; therefore make sure all
of the Toggles are in the correct position before insertion.
4. Align the Mounting Plate carefully and hold in position while tightening Toggle Bolts. Pull Toggle Bolt toward you and turn
clockwise to tighten. Figure 19.
Mounting Plate

7
10 PREPARATION AND USE OF THE CARTON TO ASSIST IN
THE INSTALLATION OF THE MICROWAVE OVEN
Utilization of the carton may make installation easier.
1. Place carton upside down. See Figure 20.
2. Using cutting line around the carton, cut into two pieces (A) and (B). See Figure 21.
3. Position oven to assist in mounting to the wall. See Figure 22.
Top Side Cutting Line
Figure 21 (A)
(B)
Figure 20
Figure 22

8
CHECKLIST FOR INSTALLATION
ACCESSORIES
Check with your dealer or order directly from the SHARPAccessories and Supplies Center. Call toll-free 1-800-642-2122.
1. CHARCOAL FILTER (RK-240). Filter is used when hood exhaust is recirculated only.
2. FILLER PANELKIT. This is available for use when the oven is installed in a 36”or 42”wide opening. The metal filler panels come
in 3-inch wide pairs. One set is needed for a 36-inch opening and 2 sets for a 42-inch opening. For information and to purchase
contact:
MODERN-AIRE VENTILATING CORPORATION
7319 Lankershim Blvd.
North Hollywood, CA 91605
Phone: [phone] •Fax: [phone]
TINSEB283MRR0-A
Printed in U.S.A.
SHARP ELECTRONICS CORPORATION
SharpPlaza,Mahwah,NewJersey07430-2135
1. Make sure the unit has been installed according to all of
the Installation Instructions, the Top Template and Wall
Template.
2. Remove all packing material from the oven.
3. Plug in the power cord.
4. Read the Operation Manual.
5. Keep the Installation Instructions for the local electrical
inspector’s use.
5
3
4
6
MOUNTING OVEN TO THE WALL
Two people are recommended to attach the Microwave Oven/Hood to the
Mounting Plate.
1. Thread the Power Supply Cord through the hole made in the bottom of
the top cabinet. Install the oven by snapping it onto the Mounting Plate.
See Figure 23.
2. Use twoTapping Screws 5to secure the levers that are on the bottom
of the oven. See Figure 24.
3. Use two Top Cabinet Screws 3and two Flat Washers 6, supplied
in the INSTALLATION HARDWARE, to attach the unit to the top
cabinet. See Figure 25.
4. Make a bundle of the Power Supply Cord and attach it to the inside of
the cabinet using the Power Cord Hanger 4. See Figure 25.
Figure 23
Figure 24
Figure 25
5
