Sharp R-933FS User manual

Important
R-933FS
MICROWAVE OVEN WITH GRILL AND
CONVECTION
OPERATION MANUAL
R-933
COOK
DEFROST
OPERATION MANUAL
This operation manual contains important information which you should read carefully before using
your microwave oven.
IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if the
oven is modified so that it operates with the door open.
900 W (IEC 60705)
R-933FS English 01/07/2002 15:13 Page A

R-933F English 2/7/02 12:37 PM Page B

ENGLISH
1
CONTENTS
OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
BEFORE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
SELECTING THE LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
USING THE STOP BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
ENERGY SAVE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MICROWAVE POWER LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MICROWAVE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
GRILL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
HEATING WITHOUT FOOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
CONVECTION COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 - 13
DUAL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 - 15
OTHER CONVENIENT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 - 18
AUTOMATIC OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 - 20
EXPRESS COOK CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
EXPRESS DEFROST CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 - 22
AUTO REHEAT CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
AUTO COOK CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
RECIPES FOR USING SQUARE TIN/SHELF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 - 26
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SERVICE CALL CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
SERVICE ADDRESSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 - 33
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BACK COVER
R-933F English 2/7/02 12:37 PM Page 1

2
OVEN AND ACCESSORIES
1Grill heating
element
2Oven lamp
3Control panel
4Shelf Runners
5Waveguide cover
6Oven cavity
7Coupling
8Door seals and
sealing surfaces
9Door opening
handle
10 Air-vent openings
11 Outer cabinet
12 Power cord
2
1
8
9
65
7
3
4
12
11
10
19
ACCESSORIES:
Check to make sure the following accessories are supplied:
13 Turntable, 14 Turntable support, 15 Low rack, 16 High rack,
17 Baking tin, 18 Square shelf, 19 Square tin
•Place the turntable support into the coupling in the centre of
the oven floor, ensuring you place it TOP side up, (TOP is
engraved on one side). It should be able to freely rotate
around the coupling.
•Place the turntable on to the turntable support.
•Place the high/low racks onto the turntable if necessary.
•The baking tins are only recommended for baking pastries in
convection mode. Place the tin on the low rack. In case of two
stage baking place additionally another household baking tin
(not supplied with oven) on the high rack as shown opposite.
•When using the square shelf or square tin, place them onto
the shelf runners as shown in Fig. A. When using the square
shelf, ensure the shelf locator is on the right side.
NOTES:
•Always operate the oven with the turntable and support fitted
correctly. This promotes thorough even cooking. A badly fitted
turntable may rattle, may not rotate properly and damage the
oven.
•The turntable rotates clockwise or counter clockwise.
The rotary direction may change each time you start the oven.
This does not affect cooking performance.
•When you order accessories, please mention two details: part
name and model name to your dealer or SHARP authorised
service facility.
13
14
These racks are used for cooking
in Convection, Dual or Grill mode.
16
15
18
Coupling
Shelf locator
Square shelf
Fig. A
Use for convection only. See page13.
17
Household baking tin
High rack
Low rack
Turntable
Baking tin
R-933F English 2/7/02 12:37 PM Page 2

ENGLISH
CONTROL PANEL
3
Digital display and indicators:
1COOKING IN PROGRESS indicator
2GRILL indicator
3CONVECTION indicator
4MICROWAVE indicator
5INFO indicator
Operating buttons:
6INFORMATION button
7LANGUAGE button
8AUTO REHEAT button
9EXPRESS DEFROST button
10 AUTO COOK button
11 COOKING MODE dial
Rotate the dial so that indicator points to
appropriate symbol:
for microwave cooking
for microwave cooking with GRILL
for microwave cooking with CONVECTION
for GRILL
for CONVECTION
12 CONVECTION button
Press to change the convection temperature.
13 TIMER/WEIGHT knob
Rotate the knob to enter either the
cooking/defrosting time or weight of food.
14 + 1 min /START button
15 STOP button
16 CLOCK SETTING button
17 MICROWAVE POWER LEVEL button
Press to change the microwave power
setting.
18 EXPRESS COOK button
19 LESS/MORE buttons
R-933
COOK
DEFROST
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2
1
R-933F English 2/7/02 12:37 PM Page 3

4
IMPORTANT SAFETY INSTRUCTIONS
To avoid the danger of fire
The microwave oven should not be left
unattended during operation. Power
levels that are too high or cooking times
that are too long may overheat foods
resulting in a fire.
In cases where the oven is to be installed into
kitchen cabinet, the installation frame EBR-9900
licensed by SHARP must be used. This is available
from your dealer. Refer to the frame installation
instructions or ask your dealer for the proper
instruction procedure. Only the use of this frame will
guarantee the safety and quality of the product.
The electrical outlet must be readily accessible so that
the unit can be unplugged easily in an emergency.
The AC power supply must be 230 V, 50 Hz, with
a minimum 16 A distribution line fuse, or a
minimum 16 A distribution circuit breaker.
It is recommended that a separate circuit serving
only this appliance be provided.
Do not place the oven in areas where heat is
generated. For example, close to a conventional oven.
Do not install the oven in an area of high humidity
or where moisture may collect.
Do not store or use the oven outdoors.
If food being heated begins to smoke,
DO NOT OPEN THE DOOR. Turn off and
unplug the oven and wait until the food
has stopped smoking. Opening the door
while food is smoking may cause a fire.
Use only microwave-safe containers and
utensils.
Do not leave the oven unattended when
using disposable plastic, paper or other
combustible food containers.
Clean the waveguide cover, the oven
cavity and the turntable after use. These
must be dry and free from grease. Built-
up grease may overheat and begin to
smoke or catch fire.
Do not place flammable materials near the oven or
ventilation openings. Do not block the ventilation
openings.
Remove all metallic seals, wire twists, etc., from
food and food packages. Arcing on metallic
surfaces may cause a fire.
Do not use the microwave oven to heat oil for deep
frying. The temperature cannot be controlled and
the oil may catch fire.
To make popcorn, use only special microwave
popcorn makers.
Do not store food or any other items inside the oven.
Check the settings after you start the oven to ensure
the oven is operating as desired.
See the corresponding hints in the cookery book section.
To avoid the possibility of injury
WARNING:
Do not operate the oven if it is damaged or
malfunctioning. Check the following before use:
a)The door; make sure the door closes properly and
ensure it is not misaligned or warped.
b)The hinges and safety door latches; check to make sure
they are not broken or loose.
c) The door seals and sealing surfaces; ensure that they
have not been damaged.
d)Inside the oven cavity or on the door; make sure there
are no dents.
e) The power supply cord and plug; ensure that they are
not damaged.
Never adjust , repair or modify the oven
yourself. It is hazardous for anyone
other than a competent person to carry
out any service or repair operation
which involves the removal of a cover
which gives protection against exposure
to microwave energy.
Do not operate the oven with the door open or
alter the door safety latches in any way.
Do not operate the oven if there is an object
between the door seals and sealing surfaces.
Do not allow grease or dirt to build up
on the door seals and adjacent parts.
Follow instructions for “Care and
Cleaning”, Page 24.
Individuals with PACEMAKERS should check with
their doctor or the manufacturer of the pacemaker
for precautions regarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstances should you remove the
outer cabinet.
Never spill or insert any objects into the door lock
openings or ventilation openings. In the event of a
spill, turn off and unplug the oven immediately, and
call an authorised SHARP service agent.
Do not immerse the power supply cord or plug in
water or any other liquid.
Do not let the power supply cord hang over the
edge of a table or work surface.
IMPORTANT SAFETY INSTRUCTIONS: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
R-933F English 2/7/02 12:37 PM Page 4

ENGLISH
5
IMPORTANT SAFETY INSTRUCTIONS
To avoid burns, always test food
temperature and stir before serving and
pay special attention to the temperature
of food and drink given to babies,
children or the elderly.
Temperature of the container is not a true
indication of the temperature of the food or drink;
always check the food temperature.
Always stand back from the oven door when opening,
to avoid burns from escaping steam and heat.
Slice stuffed baked foods after heating to release
steam and avoid burns.
Keep children away from the door to prevent them
burning themselves.
Do not touch the oven door, outer cabinet, rear
cabinet, oven cavity, ventilation openings,
accessories and dishes during GRILL mode,
CONVECTION mode, DUAL mode, EXPRESS
COOK and AUTO COOK operation as they will
become hot. Before cleaning make sure they are
not hot.
To avoid misuse by children
WARNING: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the child
is able to use the oven in a safe way and
understands the hazards of improper use.
Do not lean or swing on the oven door. Do not
play with the oven or use it as a toy.
Children should be taught all important safety
instructions: use of pot holders, careful removal of
food coverings; paying special attention to
packaging (e.g. self-heating materials) designed to
make food crisp, as they may be extra hot.
Other warnings
Never modify the oven in any way.
Do not move the oven while it is in operation.
This oven is for home food preparation only and
may only be used for cooking food. It is not
suitable for commercial or laboratory use.
To promote trouble-free use of your oven
and avoid damage.
Never operate the oven when it is empty except
where recommended in the operation manual, see
Page 11. Doing so may damage the oven.
When using a browning dish or self-heating
material, always place a heat-resistant insulator
such as a porcelain plate under it to prevent
damage to the turntable due to heat stress. The
preheating time specified in the dish’s instructions
must not be exceeded.
Keep the power supply cord away from heated
surfaces, including the rear of the oven.
Do not attempt to replace the oven lamp yourself
or allow anyone who is not an electrician
authorised by SHARP to do so. If the oven lamp fails,
please consult your dealer or an authorised SHARP
service agent.
If the power supply cord of this appliance is
damaged, it must be replaced with a special cord.
The exchange must be made by an authorised
SHARP service agent.
To avoid the possibility of explosion and
sudden boiling:
WARNING: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
Never use sealed containers. Remove seals and
lids before use. Sealed containers can explode due
to a build up of pressure even after the oven has
been turned off.
Take care when microwaving liquids. Use a wide-
mouthed container to allow bubbles to escape.
Never heat liquids in narrow necked
containers such as baby bottles, as this
may result in the contents erupting from the
container when heated and cause burns.
To prevent sudden eruption of boiling liquid and
possible scalding:
1. Stir liquid prior to heating/reheating.
2. It is advisable to insert a glass rod or similar utensil
into the liquid whilst reheating.
3. Let liquid stand in the oven at the end of cooking
time to prevent delayed eruptive boiling.
Do not cook eggs in their shells, and whole
hard boiled eggs should not be heated in
microwave ovens since they may explode
even after microwave cooking has ended.
To cook or reheat eggs which have not
been scrambled or mixed, pierce the yolks
and the whites, or the eggs may explode.
Shell and slice hard boiled eggs before
reheating them in the microwave oven.
Pierce the skin of such foods as potatoes, sausages
and fruit before cooking, or they may explode.
To avoid the possibility of burns
Use pot holders or oven gloves when removing food
from the oven to prevent burns.
Always open containers, popcorn makers, oven
cooking bags, etc., away from the face and hands to
avoid steam burns.
R-933F English 2/7/02 12:37 PM Page 5

4. The oven door may become hot during
cooking. Place or mount the oven so that
the bottom of the oven is 85 cm or more
above the floor. Keep children away
from the door to prevent them burning
themselves.
5. Ensure there is a minimum of free space above
the oven of 13 cm.
6. Securely connect the plug of the oven to a
standard earthed (grounded) household
electrical outlet.
6
IMPORTANT SAFETY INSTRUCTIONS
INSTALLATION
1. Remove all packing materials from the inside of
the oven cavity. Discard the loose polythene sheet
from between the door and cavity. Remove the
feature sticker, if attached, from the outside of the
door.
2. Check the oven carefully for any signs of
damage.
3. Place the oven on a flat, level surface strong
enough to support the oven’s weight plus the
heaviest item likely to be cooked.
Remove this film.
13 cm
NOTE:
If you are unsure how to connect your oven, please
consult an authorised, qualified electrician.
Neither the manufacturer nor the dealer can accept
any liability for damage to the oven or personal
injury resulting from failure to observe the correct
electrical connection procedure.
Water vapour or drops may occasionally form on
the oven walls or around the door seals and
sealing surfaces. This is a normal occurrence and is
not an indication of microwave leakage or a
malfunction.
Do not use metal utensils, which reflect microwaves
and may cause electrical arcing. Do not put cans
in the oven.
Use only the turntable designed for this oven.
Do not place anything on the outer cabinet during
operation.
Do not use plastic containers for microwaving if the
oven is still hot from using the GRILL mode,
CONVECTION mode, DUAL mode, EXPRESS
COOK and AUTO COOK, because they may
melt. Plastic containers must not be used during
above modes unless the container manufacturer
says they are suitable.
R-933F English 2/7/02 12:37 PM Page 6

ENGLISH
BEFORE OPERATION
7
Your oven has an energy save mode.
1. Plug in the oven. Nothing will appear on the
display at this time.
2. Open the door.
The oven display will show “SELECT
LANGUAGE” in 5 languages.
NOTE: Once you select the language using the
LANGUAGE button, the display will show
“ENERGY SAVE MODE TO GO OUT OF
ENERGY SAVE MODE SET CLOCK” when you
plug the oven in.
3. Close the door.
4. Select a language (See below).
NOTE: If you use the oven in German, you do
not have to select language, simply press the
STOP button. The display will show “.0” and
go to step 5.
5. Set the clock (See page 8).
6. Heat the oven without food (See page 11).
COOKING HINTS:
The oven has an ‘Information Display System’ which
offers you step by step instructions to easily guide you
through each feature, and enable you to gain
information in your desired language. The oven has
an INFORMATION button for getting instructions
for each button. Indicators will appear in the display,
after pressing a button, to inform you of the next
operation step.
SELECTING THE LANGUAGE
The oven comes set for German. You can change the
language. To change, press the LANGUAGE button
until the desired language is displayed. Then press the
+1 min /START button.
Example:
Suppose you want to select Italian:
Press
LANGUAGE button
once
twice
3 times
4 times
5 times
LANGUAGE
DEUTSCH
NEDERLANDS
FRANÇAIS
ITALIAN
ESPAÑOL
1. Choose the desired
language by pressing the
LANGUAGE button.
2. Press the +1 min /START
button to start the setting.
Check the display.
x4 x1
NOTE: The selected language will be memorised even if the electical power supply is interrupted.
R-933F English 2/7/02 12:37 PM Page 7

SAVE MODE SET CLOCK”. This information will
appear if you have already set the language with
the LANGUAGE button. If this occurs during
cooking, the programme will be erased. The time of
day will also be erased.
5. When you want to reset the time of day, follow the
above example again.
6. If you do not set the clock, press the STOP button
once. will appear on the display. When
the operation of the oven is finished, will
reappear on the display instead of the time of day.
7. If you set the clock, energy save mode does
not work.
There are two setting modes: 12 hour clock and 24 hour clock.
Step 1
x1
1. To set the 12 hour clock, press the CLOCK SETTING button once as in
Step 1.
2. To set the 24 hour clock, press the CLOCK SETTING button twice as in
Step 2 .
Step 2
x2
Example:
To set the 24 hour clock to 23:35.
2. Set the hours. Rotate the TIMER/
WEIGHT knob clockwise until the
correct hour is displayed (23).
Check the display.4. Set the minutes (35).
NOTES:
1. You can rotate the TIMER/WEIGHT knob
clockwise or counterclockwise.
2. Press the STOP button if you make a mistake
during programming.
3. If the oven is in cooking mode and you wish to
know the time of day, touch the CLOCK SETTING
button. As long as your finger is touching the
button, the time of day will be displayed.
4. If the electrical power supply to your microwave
oven is interrupted, plug in the oven again, then
open and close the door. The display will show
“ENERGY SAVE MODE TO GO OUT OF ENERGY
1. Choose the 24 hour clock
by pressing the CLOCK
SETTING button twice.
3. Change from hours to minutes
by pressing the CLOCK
SETTING button once.
5. Press the CLOCK SETTING
button to start the clock.
8
SETTING THE CLOCK
Use the STOP button to:
1. Erase a mistake during programming.
2. Stop the oven temporarily during cooking.
3. Cancel a programme during cooking, press
the STOP button twice.
USING THE STOP BUTTON
x2 x1
x1
R-933F English 2/7/02 12:37 PM Page 8

9
ENERGY SAVE MODE
ENGLISH
MICROWAVE POWER LEVELS
Your oven comes set for the energy save mode.
If you do nothing for 3 minutes after a preceding operation, i.e. closing the door or at the end of cooking,
the power will go off automatically. To restore power on, open the door.
To start energy save mode, follow the instructions below.
Example:
To start the energy save mode, (the current time is 23:35):
NOTE: You can press the CLOCK SETTING button twice at step 2.
To set the microwave power level :
1. Rotate the COOKING MODE dial to the microwave setting.
2. Rotate the TIMER/WEIGHT knob clockwise or counter-clockwise to select cooking time.
3. Press the MICROWAVE POWER LEVEL button until the desired power level appears on the display. (If
the MICROWAVE POWER LEVEL button is touched once, will be displayed. If you miss your
desire level, continue pressing the MICROWAVE POWER LEVEL button until you reach the level again).
4. Press the +1 min /START button.
NOTE: If the power level is not selected, 900 W is automatically set.
Your oven has 5 power levels. To choose the power
level for cooking, follow the advice given in the
recipe section. Generally the following
recommendations apply:
900 W used for fast cooking or reheating e.g.
soup, casseroles, canned food, hot beverages,
vegetables, fish, etc.
630 W used for longer cooking of dense foods such
as roast joints, meat loaf and plated meals, also for
sensitive dishes such as cheese sauce and sponge
cakes. At this reduced setting, the sauce will not boil
over and food will cook evenly without over cooking
at the sides.
450 W for dense foods which require a long
cooking time when cooked conventionally, eg. beef
dishes, it is advisable to use this power setting to
ensure the meat will be tender.
270 W (Defrost setting) to defrost, select this
power setting, to ensure that the dish defrosts
evenly. This setting is also ideal for simmering rice,
pasta, dumplings and cooking egg custard.
90 W for gentle defrosting, eg. cream gateaux or
pastry.
W = WATT
x1
x1
1. Make sure the
correct time
appears on the
display.
3. Adjust the display
to 0 by rotating the
TIMER/WEIGHT
knob.
2. Press the CLOCK
SETTING button
once.
4. Press +1 min
/START button. The
power will be off and the
display will show nothing.
R-933F English 2/7/02 12:37 PM Page 9

MICROWAVE COOKING
10
NOTES:
1. When the door is opened during the cooking
process, the cooking time on the digital display
stops automatically. The cooking time starts to count
down again when the door is closed and the +1
min /START button is pressed.
2. If you wish to know the power level during
cooking, press the MICROWAVE POWER LEVEL
button. As long as your finger is pressing the
MICROWAVE POWER LEVEL button, the power
level will be displayed.
3. You can rotate the TIMER/WEIGHT knob
clockwise or counter-clockwise. If you rotate the
dial counter-clockwise, the cooking time will
decrease from 90 minutes by degrees.
Example:
Suppose you want to heat soup for 2 minutes and 30 seconds on 630 W microwave power.
2. Enter desired cooking
time by rotating the
TIMER/WEIGHT
knob clockwise.
3. Press the MICROWAVE
POWER LEVEL button
twice for 630 W
microwave power.
1. Rotate the
COOKING MODE
dial to the
microwave setting.
4. Press the +1 min /
START button once to
start cooking.
Cooking Time: Increasing unit:
0-5 minutes 10 seconds
5-10 seconds 30 seconds
10-30 minutes 1 minute
30-90 minutes 5 minutes
Your oven can be programmed for up to 90 minutes.
(90.00). The input unit of cooking (defrosting) time
varies from 10 seconds to five minutes. It depends on
the total length of the cooking (defrosting) time as
shown on the table opposite:
x1
Check the display.
x2
WARNING: Never use the square shelf and square tin for microwave cooking and dual cooking as this
may cause arcing.
R-933F English 2/7/02 12:37 PM Page 10

11
GRILL COOKING
HEATING WITHOUT FOOD
ENGLISH
The grill heating element at the top of the oven cavity has one power setting only.
Example: Suppose you want to cook cheese on toast for 5 minutes (Place toast on the high rack.)
x1
1. The high or low racks are recommended when
grilling. It is not recommended to use the
square shelf and square tin for grilling.
2. You may detect smoke or a burning smell when
using the grill for the first time, this is normal and
not a sign that the oven is out of order. (Please
see heating without food below.)
3. After cooking the display may show ‘NOW COOLING’.
WARNING:
The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot,
always use thick oven gloves when removing the food or turntable from the oven to
prevent burns.
You may detect smoke or a burning smell when using the grill and convection for the first time. This is normal
and not a sign that the oven is out of order.
To avoid this problem, when first using the oven, heat the oven without food for 20 minutes on grill and then at
convection 250° C.
IMPORTANT: During operation, to allow smoke or smells to disperse open a window or switch the kitchen
ventilation on. Make sure there is no food in the oven.
2. Enter the required
heating time. (20 min.)
1. Rotate the COOKING
MODE dial to the
GRILL or CONVECTION
setting.
3. Start cooking by
pressing the
+1 min /START
button.
x1
WARNING:
The oven door, outer cabinet & oven cavity will become hot.
Take care to avoid burns when cooling the oven down after
operation.
The oven will count
down. When the
oven has finished
cooking, open the
door to cool the
oven cavity.
Check the display.
2. Enter the desired cooking time by
rotating the TIMER/WEIGHT
knob clockwise.
1. Rotate the COOKING
MODE dial to the
GRILL setting.
3. Press the +1 min /
START button to
start cooking.
R-933F English 2/7/02 12:37 PM Page 11

CONVECTION COOKING
12
Your oven can be used as a conventional oven using the convection facility and 10 pre-set oven
temperatures.
Example 1: To cook with preheating
Suppose you want to pre-heat to 180° C and cook for 20 minutes at 180° C.
4. Use the TIMER/WEIGHT knob to
input the cooking time (20 mins).
Check the display.
x5 x1
x1
1
250
Press CONVECTION
button
Oven Temp (˚ C)
2
230
3
220
4
200
5
180
6
160
7
130
8
100
9
70
10
40
5. Press the +1 min
/START button.
1. After preheating, if you want to cook at a different temperature press the CONVECTION button
until the desired setting appears on the display. In the example above, to change the temperature
you would press the CONVECTION button after entering the cooking time.
2. When the oven reaches the programmed preheating temperature, it will automatically hold at the
pre-heated temperature for 30 minutes. After 30 minutes the display will change to time of day, if set.
The selected convection programme will be cancelled.
3. After cooking the oven will automatically cool and the display may show “NOW COOLING”.
NOTES:
2. Enter the desired
preheat temperature
by pressing the
CONVECTION
button five times. The
display will show
180° C.
3. Press the +1 min
/START button
to start pre-heating.
When the pre-heated
temperature has been
reached the audible
signal sounds, the display
will show 180° C, open
the door and place the
food inside the oven.
Close the door.
1. Select the cooking
mode by rotating the
COOKING MODE
dial to .
R-933F English 2/7/02 12:37 PM Page 12

CONVECTION COOKING
13
ENGLISH
Check the display.
x1 x1
Example 2: To cook without preheating
Suppose you want to cook at 250° C for 20 minutes.
NOTES:
1. After cooking the oven will automatically cool and the display may show “NOW COOLING”.
2. To change the convection temperature, press the CONVECTION button until the desired
temperature appears on the display.
3. You may detect smoke or a burning smell when using convection for the first time. This is normal and
is not a sign that the oven is out of order. (Please see Heating Without Food on page 11).
WARNING:
The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot, use thick
oven gloves when removing the food or turntable from the oven to prevent burns.
3. Select the desired
cooking temperature.
(250° C).
4. Press the +1 min
/START button.
2. Use the TIMER/WEIGHT
knob to input the cooking
time (20 mins).
1. Select the cooking
mode by rotating the
COOKING MODE
dial to .
Shelf runners
1
2
SPECIAL NOTES FOR SQUARE SHELF & SQUARE TIN:
1. When using either the square shelf or the square tin, place it at position 1.
When using both of them, place the square tin at position 1 and the
square shelf at position 2 as shown in the diagram.
2. When using the square shelf and/or the sqaure tin, leave the turntable in
the oven.
3. When using the square shelf or the square tin, rotate the square tin or the
container on the square shelf 90˚ halfway to achieve better results.
4. When using the square shelf follow the notes below to prevent them
slipping out:
•Do not place container with food weighing more than 5 kg on the
square shelf.
•Ensure that the square shelf is in the correct position and does not
rattle.
•When removing the food, pull the square shelf until it is slightly
locked, and then remove the food.
5. Some recipes for using the square shelf or the square tin are included in
this operation manual. Please refer to pages 24 -26.
6. The square shelf and square tin are only recommended for use in
convection mode.
R-933F English 2/7/02 12:37 PM Page 13

14
DUAL COOKING
Cooking method
Convection 250° C
Grill
COOKING MODE
DUAL 1
DUAL 2
Initial microwave
power
270 W
270 W
2. Enter the desired
cooking time (20
minutes).
3. Press the MICROWAVE
POWER LEVEL button
twice.
NOTES: The power settings are variable:
DUAL 1 : The oven temperature can be changed from 40o C to 250° C in ten levels.
Microwave power levels can be changed from 90 W - 630 W in four levels.
DUAL 2 : Microwave power levels can be changed from 90 W - 900 W in five levels.
Example 1:
Suppose you want to cook for 20 minutes on DUAL 1 using 90 W microwave power and 200° C convection.
4. Press CONVECTION button
four times (200o C). 5. Press the +1 min
/START button.
x1
Check the display.
Your oven has 2 DUAL cooking modes combining the heat of the grill with the power of the microwave.
To select the DUAL cooking mode rotate the COOKING MODE dial to the desired setting, then choose the
cooking time. Generally, dual cooking time shortens the total cooking time.
x4
1. Select the cooking
mode by rotating the
COOKING MODE
dial to .
x2
R-933F English 2/7/02 12:37 PM Page 14

15
DUAL COOKING
ENGLISH
WARNING:
1. The oven cavity, door, outer cabinet, turntable, racks and dishes will become very hot, use
thick oven gloves when removing the food or turntable from the oven to prevent burns.
2. Never use the square shelf and square tin for microwave cooking and dual cooking as this may cause
arcing.
2. Enter the desired
cooking time (20 min.). 3. Press the MICROWAVE POWER LEVEL button
twice (90 W).
Example 2:
Suppose you want to cook for 20 minutes on DUAL 2 using 90 W microwave power and GRILL.
Check the display.
1. Select the cooking
mode by rotating the
COOKING MODE
dial to .
NOTE: After cooking, the oven will automatically cool and the display may show “NOW COOLING”.
5. Press the +1 min
/START button.
x2
x1
R-933F English 2/7/02 12:37 PM Page 15

16
OTHER CONVENIENT FUNCTIONS
1. LESS ( ▼)/MORE ( ▲) button
The LESS ( ▼) and MORE ( ▲) buttons allow you to
decrease or increase programmed setting times
easily, (for a less well or more well cooked result),
used for automatic operation or when cooking is
underway.
a) Changing the pre-programmed time setting:
Press the LESS ( ▼)and MORE ( ▲)button after entering
weight and before pressing the +1 min / START
button.
NOTES:
To cancel LESS or MORE press the same button again.
To change MORE to LESS simply press the LESS ( ▼)
button.
To change LESS to MORE simply press the MORE ( ▲)
button.
b) Changing the heating time while the
oven is operating:
The cooking time can be decreased or increased in 1
minute steps each time the LESS ( ▼)and
MORE ( ▲)buttons are pressed.
1. Choose the AUTO
COOK menu for Gratin
by pressing the AUTO
COOK button five times.
2. Enter the amount
(1,0 kg).
4. Press the +1 min
/START button.
Check the display.
x5
Example:
Suppose you want to cook 1,0 kg Gratin using the
AUTO COOK and MORE button.
3. Choose the desired result
(well cooked) by pressing
the MORE ( ▲)button
once.
x1
R-933F English 2/7/02 12:37 PM Page 16

NOTES:
1. You can use this function for manual cooking only.
2. When the COOKING MODE dial is on microwave ( ) and you press the +1 min /START button,
the microwave power is always 900 W.
When the COOKING MODE dial is on dual ( or ) and you press the +1 min /START
button, the microwave power is always 270 W.
When the COOKING MODE dial is on convection or dual 1 ( or ) and you press the
+1 min /START button, the convection temperature is always 250° C.
3. To avoid misuse by children the 1 minute cooking function can be used only within 3 minutes after the
preceding operation, ie closing the door, pressing the STOP button or end of cooking.
b) Extend the cooking time
You can extend the cooking time in multiples of one minute if the +1 min /START button is pressed while
the oven is in operation.
17
OTHER CONVENIENT FUNCTIONS
ENGLISH
2. +1min function
The +1 min /START button allows you to operate the two following functions:
a) 1 minute cooking
You can cook on your desired cooking mode for 1 minute without entering the cooking time.
Example:
Suppose you want to cook for 1 minute on 630 W microwave power.
2. Change the power
by pressing the
MICROWAVE
POWER LEVEL
button.
1. Select the cooking mode
by rotating the
COOKING MODE dial
to (Microwave).
3. Press the +1 min /
START button
once to begin
cooking.
x2 x1
Check the display.
R-933F English 2/7/02 12:37 PM Page 17

18
OTHER CONVENIENT FUNCTIONS
3. TO CHECK SETTINGS WHILE THE OVEN IS OPERATING
You can check the power level and the actual oven temperatures ie: when pre-heating.
TO CHECK THE POWER LEVEL:
To check the microwave power level during cooking
press the MICROWAVE POWER LEVEL button.
The oven continues to count down, although the
display shows the power level.
As long as your finger is
pressing the button, the
power level will be
displayed.
TO CHECK THE CONVECTION TEMPERATURE:
To check the convection temperature during cooking
press the CONVECTION button.
When the oven is pre-heating, you can check the
actual oven temperature.
As long as your finger is
pressing the button, the
convection temperature in
°C will be displayed.
1. Choose the
INFORMATION button
function.
2. Press the AUTO COOK
button 3 times to select
Roast Chicken.
4. INFORMATION button
Each button carries useful information. If you wish to
get the information, press the INFORMATION button
before pressing the desired button.
Example:
Suppose you want to get information about AUTO
COOK menu number 3, Roast chicken:
NOTE:
1. The information message will be repeated twice,
and then the display will show the time of day, if
set.
2. If you want to cancel the information press the
STOP button.
x1
x3
R-933F English 2/7/02 12:37 PM Page 18
