Sharp Carousel R1514TY User manual

1
R-1514TY
In the interest of user-safety the unit should be restored to its original condition and only parts identical to those specified should
be used.
WARNING TO SERVICE PERSONNEL:
This service manual is intended for use by persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable in the appliance repair trade. Sharp Electronics
Corporation cannot be responsible, nor assume any liability, for injury or damage of any kind arising from the
use of this manual.
Microwave ovens contain circuitry capable of producing very high voltage and current. Contact with the
following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor, High Voltage
Power Transformer, High Voltage Rectifier, Heat sink, Magnetron, and High Voltage Harness etc..)
S20M321R14OTXY
R-1514TY
OVER THE RANGE MICROWAVE MODEL
SUPPLEMENTAL SERVICE MANUAL
This document has been published to be used for after sales service only. The contents are subject to change without notice.
SHARP ELECTRONICS CORPORATION
S E NS O R
M I C R O W A V E
ST OP / CL E A R
LIG H T HI / L O
FAN HI /LO
ST A R T / MIN PL U S
THIS IS A SUPPLEMENTAL SERVICE MANUAL FOR MODEL R-1514TY USING THE
STANDBY POWER CIRCUIT.
MODELS NOT USING STANDBY POWER, PLEASE REFER TO SERVICE MANUAL:
(R-1405-T/1406-T & R-1514-T) - S20M321R14OTX
THESE MODELS ARE SIMULAR TO ORIGINAL BASE MODELS R-1500 & R-1501.

2
R-1514TY
SHARP ELECTRONICS CORPORATION
SHARP PLAZA, MAHWAH,
NEW JERSEY 07430-2135
SUPPLEMENTAL SERVICE MANUAL
OVER THE RANGE MICROWAVE OVEN
R-1514TY
FOREWORD
This Manual has been prepared to provide Sharp Electronics Corp. Service Personnel with Operation and Service Informa-
tion for the SHARP OVER THE RANGE MICROWAVE OVENS using the Standby Power Circuit.
It is recommended that service personnel carefully study the entire text of this manual so that they will be qualified to render
satisfactory customer service.
Check the interlock switches and the door seal carefully. Special attention should be given to avoid electrical shock and
microwave radiation hazard.
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained service personnel.
DANGER
Certain initial parts are intentionally not grounded and present a risk of electrical shock only during servicing.
Service personnel - Do not contact the following parts while the appliance is energized;
HighVoltage Capacitor, PowerTransformer, Magnetron, High Voltage Rectifier Assembly, HighVoltage Harness;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked “*” on parts list are used at voltages more than 250V.
Removal of the outer wrap gives access to voltage above 250V.
All the parts marked “∆” on parts list may cause undue microwave exposure, by themselves, or when they are dam-
aged, loosened or removed.
BEFORE SERVICING
Before servicing an operative unit, perform a microwave emission check as per the Microwave Measurement
Procedure outlined in this service manual.
If microwave emissions level is in excess of the specified limit, contact SHARP ELECTRONICS CORPORA-
TION immediately @1-800-237-4277.
If the unit operates with the door open, service person should 1) tell the user not to operate the oven and 2)
contact SHARP ELECTRONICS CORPORATION and Food and Drug Administration's Center for Devices
and Radiological Health immediately.
Service personnel should inform SHARP ELECTRONICS CORPORATION of any certified unit found with
emissions in excess of 4mW/cm2. The owner of the unit should be instructed not to use the unit until the oven
has been brought into compliance.

3
R-1514TY
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. COOKING TIME PROGRAMMED.
3. VARIABLE COOKING CONTROL "HIGH".
4. "START" BUTTON PRESSED.
Oven Schematic-Cooking Condition
Oven Schematic-Off Condition
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. CLOCK APPEARS ON DISPLAY.
NOTES:
1.CIRCUITS SUBJECT TO CHANGE WITHOUT NOTICE.
2. TERMINAL WITH PROJECTION OR OPPOSITE BLUE MARK ON LAMP SOCKET
MUST BE CONNECTED TO NEUTRAL WIRE.
THERMAL
CAVITY
CUTOUT
120VAC
60Hz
HOOD FAN
THERMAL
COM.
CUT OUT
A5
B5
B9
B7
A1 A3 B1
E2
E1
RY4
RY3
NC
HOOD
MOTOR
CONTROL UNIT
MAGNETRON
TEMPERATURE
FUSE
N.O.
(R
(RY2)
COM.
DOOR
SENSING
SWITCH
TTM FMOL
HL
HL
TURN
TABLE
MOTOR
FAN
OVEN
MOTOR
LAMP
HOOD
LAMP SWITCH
MONITOR
PRIMARY
INTERLOCK
SWITCH
POWER
TRANSFORMER
MAGNETRON
HIGH
VOLTAGE
High
Low
CAPACITOR
HOOD MOTOR
CAPACITOR
INTERLOCK
SECONDARY
RELAY
B3
RY5
RY6
GND
F1
F2
F3
AH SENSOR
RESISTOR 470 kW 1/2W
LINE CROSS CAPACITOR 1.0 uF 275V
NOISE SUPRESSION COIL
LINE BYPASS CAPACITOR 0.0022 uF 250V
FUSE 20A
LINE BYPASS CAPACITOR 0.0022 uF 250V
NOISE FILTER
N
L
GND
FUSE
CN101
#1(N)
#3(L)
CN201
#1(+)
#2(-)
SW unit (15Vdc)
V3
N.O.
OVEN LAMP
RELAY
(RY1)
V1 V7 V5
VRS1
NOTES:
1.CIRCUITS SUBJECT TO CHANGE WITHOUT NOTICE.
2. TERMINAL WITH PROJECTION OR OPPOSITE BLUE MARK ON LAMP SOCKET
MUST BE CONNECTED TO NEUTRAL WIRE.
THERMAL
CAVITY
CUTOUT
120VAC
60Hz
HOOD FAN
THERMAL
COM.
CUT OUT
A5
B5
B9
B7
A1 A3 B1
E2
E1
RY4
RY3
NC
HOOD
MOTOR
CONTROL UNIT
MAGNETRON
TEMPERATURE
FUSE
N.O.
(R
(RY2)
COM.
DOOR
SENSING
SWITCH
TTM FMOL
HL
HL
TURN
TABLE
MOTOR
FAN
OVEN
MOTOR
LAMP
HOOD
LAMP SWITCH
MONITOR
PRIMARY
INTERLOCK
SWITCH
POWER
TRANSFORMER
MAGNETRON
HIGH
VOLTAGE
High
Low
CAPACITOR
HOOD MOTOR
CAPACITOR
INTERLOCK
SECONDARY
RELAY
B3
RY5
RY6
GND
F1
F2
F3
AH SENSOR
RESISTOR 470 kW 1/2W
LINE CROSS CAPACITOR 1.0 uF 275V
NOISE SUPRESSION COIL
LINE BYPASS CAPACITOR 0.0022 uF 250V
FUSE 20A
LINE BYPASS CAPACITOR 0.0022 uF 250V
NOISE FILTER
N
L
GND
FUSE
CN101
#1(N)
#3(L)
CN201
#1(+)
#2(-)
SW unit (15Vdc)
V3
N.O.
OVEN LAMP
RELAY
(RY1)
V1 V7 V5
VRS1

4
R-1514TY
NOISE FILTER TEST
1. Disconnect the power supply cord, and then remove outer case.
2. Open the door and block it open.
3. Discharge high voltage capacitor.
4. Disconnect the leads to the primary of the power transformer.
5. Using an ohm-meter, check between the terminals as described in the following table:
MEASURING POINT INDICATION OF OHM-METER
Between N and H 275 - 415Ω
Between terminal N and LOAD Short Circuit
Between terminal H and LOAD Short Circuit
Fuse Short Circuit
If fuse is open, replace fuse
If incorrect readings are obtained, replace the noise filter.
6. Reconnect all leads removed from components during testing.
7. Re-install the outer case (cabinet).
8. Reconnect the power supply cord after the outer case is installed.
9. Run the oven and check all functions.
NOISE FILTER UNIT
NOISE SUPPRESSION COIL
LINE CROSS CAPACITOR 1.0 µF 275V
RESISTOR 470 K Ω1/2W
LINE BYPASS CAPACITOR
LINE BYPASS CAPACITOR
0.0022 µF/ 250v
0.0022 µF/ 250v
TO LOAD TO LOAD
H
N
MONITOR
FUSE
“TO SOURCE” “TO SOURCE”
SWITCHING POWER SUPPLY
1. Check AC power into CN101,
if none check Main Harness.
2. Check DC power across CN201 (DC15V),
if none replace Switching Power Supply Unit
3. Check for DC getting from Switching Power Supply Unit
to PSU/ CPU, if none check Main Harness.
CN101
CN201

5
R-1514TY
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
HIGH VOLTAGE RECTIFIER
HIGH VOLTAGE CAPACITOR
HIGH VOLTAGE WIRE A
HIGH VOLTAGE COMPONENTS
CONTROL UNIT
POWER TRANSFORMER
Power Supply cord 120V 60Hz
1 2 3
WHT
GRN
BLK
WHT
GRN
BLK
CAVITY THERMAL CUT-OUT
MAGNETRON TEMPERATURE FUSE
FAN MOTOR
TURNTABLE MOTOR
WHT WHT
ORG BLK
WHT
RED
WHT BRN
HOOD LAMPS & SOCKETS
Blue Marking
Blue Marking
OVEN LAMP & SOCKET
to Chassis Support
CN-E
GRY
WHT
WHT
WHT
WHT
PRIMARY INTERLOCK SWITCH
N.O.
N.C.
COM.
COM.
MONITOR SWITCH
GRN
RED
N.O.
COM.
DOOR SENSING SWITCH
RY1 N.O. RY1 COM. RY2 N.O. RY2 COM.
HOOD FAN MOTOR
1
2
3 4 5 6
WHT
RED
YLW
BLU
BLK
WHT
RED
YLW
BLU
BLK
1
2
RED
GRN
1
2
3 4 5
YLW
PPL
RED
CN-A
W
H
T
HOOD FAN THERMAL CUT-OUT
WHT
GRY
BRN
RED
ORG
WHT
GRY
GRN
1
2
3 4 5 6 7
RED
BLK
ORG
8 9
WHT
CN-B
BLK
ORG RED
BLK
RED
RED
PPL
MAGNETRON
R
E
D
BLU
BLK
BLK
WHT
NOISE FILTER
BOARD
N
H
RED
GRY
N.O.
CN-B
CN-C
CN-G CN-C
CN-A
CN-E
1
91
1
2 1
14
5
RY1
RY3
RY4
RY5
RY6
COM.
RY2
to Right Base Plate
71
CN-V
1
2
3 4 5 6 7
BRN BLK
GRY
ORG
CN-V
CN101
CN201
1 2 3
12
C101
L101
C201
M1
L202
C106
C105
C202
C201
L201
SWITCHING POWER SUPPLY
WHT
BLK
BLK
BRN WHT RED
BRN
W
H
T
RED
Pictorial Diagram

6
R-1514TY
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
*
*
ELECTRIC PARTS
1- 1 FH-DZB033MRY0 High voltage rectier assembly 1 AN
1- 2 RC-QZA350WRZZ High voltage capacitor 1 AT
1- 3 QFS-TA013WRE0 Temperature fuse 150½C (Magnetron) 1 AG
1- 4 RMOTDA252WRZZ Turntable motor 1 AN
1- 5 RTHM-A180WRZZ Thermal cut-out 145½C (Cavity) 1 AF
1- 6 RTHM-A181WRZZ Thermal cut-out N.O. 60½C (Hood Fan) 1 AF
1- 7 RTRN-B096MRE0 Power transformer 1 BL
1- 8 RV-MZA293WRE0 Magnetron 1 BH
1- 9 FPWBFA512WRKZ Noise lter 1 AN
1-10 QSW-MA168WRZZ Primary interlock and door sensing switches 2 AF
1-11 QSW-MA169WRZZ Monitor switch 1 AD
1-12 FACCDB011MRE0 Power supply cord 1 AV
1-13 QSOCLA021WRE0 Oven lamp socket 3 AG
1-14 FMOTEA584WRKZ Hood fan motor 1 BK
1-15 RMOTEB031MRE0 Fan motor 1 AT
1-16 RLMPTA086WRZZ Oven lamp 3 AL
1-17 FDTCTA225WRKZ AH sensor 1 AW
1-18 DPWB-B451DRKZ Switching power supply 1 AZ
1-19 QFS-BA009WRE0 20A fuse 1 AF
CABINET PARTS
2- 1 LSTY-A121WRWZ Rear stay 1 AN
2- 2 FDIF-B031MRK0 Hood exhaust louver 1 BF
2- 3 GDAI-A461WRWZ Base plate R 1 AQ
2- 4 FDECAB138MRK0 Front panel L 1 AX
2- 5 GCABUB185WRPZ Outer case cabinet 1 BG
2- 6 TMAPCA837WRRZ Schematic diagram 1 AD
2- 7 FANGKB009MRY0 Hood lamp glass assembly 1 AP
2-7-1 LANGQB016MRP0 Hood lamp glass angle 1 AM
2-7-2 PGLSPB004MRE0 Hood lamp glass 1 AQ
2- 8 PCOVPA552WRTZ Base cover 1 AZ
CONTROL PANEL PARTS
3- 1 CPNLCE375WRKZ T/C sub assy 1 BQ
3- 2 FPNLCB420MRK0 A Control panel sub, assembly 1 BE
3- 2-1 PSHEPB136MRR0 Key sheet 1 AN
3- 2-2 FDECAB139MRK0 Open button 1 AQ
3- 2-3 MSPRCA045WRE0 Button spring 1 AF
3- 2-4 LANGQA817WRWZ Key xing frame 1 AM
3- 2-5 QSW-KB057MRE0 FPC 1 AP
3- 3 XEPS730P08XS0 Screw 5 AB
3- 4 CPWBFA916WRKZ CPU unit 1 BK
3- 5 PSHEPB101MRE0 Select button rubber 1 AF
OVEN PARTS
4- 1 LSTPPB038MRF0 Door stopper 1 AF
4- 2 FROLPA097WRKZ Turntable support assembly 1 AN
4- 3 NTNT-A108WREZ Turntable tray 1 AW
4- 4 LBNDKA186WRPZ Capacitor holder 1 AF
4- 5 PDUC-B155WRFZ Magnetron duct 1 AK
4- 6 MLEVPA297WRFZ Open lever 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1
4- 8 PPACGA084WRF0 Turntable motor packing 1 AE
4- 9 PHOK-A182WRFZ Latch hook 1 AG
4-10 LANGTA477WRWZ Unit mounting plate assembly 1 AT
4-11 NFANJA060WRFZ Fan blade 1 AH
4-12 LBSHCA014WRE0 Cord bushing 1 AG
4-13 PDUC-B173WRFZ Orice 2 AK
4-14 PDUC-B157WRWZ Hood intake duct R 1 AN
4-15 PCOVPA554WRPZ Waveguide cover 1 AF
4-16 PCUSUA661WRPZ Transformer cushion 2 AC
4-17 LANGTA479WRPZ Chassis support 2 AK
4-18 PDUC-B158WRFZ Hood duct R 1 AQ
4-19 PDUC-B156WRFZ Hood duct L 1 AR

7
R-1514TY
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-20 PDUC-B159WRWZ Fan duct 1 AM
4-21 PCUSUA665WRPZ Cushion 1 AG
4-22 PCUSUA672WRPZ Cushion 1 AF
4-23 LHLDPB004MRF0 PWB holder 1 AC
DOOR PARTS
5 CDORFB317MRK0A Door assembly 1 BQ
5-1 LSTPPB023MRF0 Latch head 1 AF
5-2 MSPRTA046WRE0 Latch spring 1 AD
5-3 GCOVHB044MRF0 Choke cover 1 AX
5-4 XCPS740P08000 Screw : 4mm x 8mm 2 AC
MISCELLANEOUS
6- 1 CFZK-B657WRKZ Installation material assembly 1 AQ
6-1-1 LX-BZ0195WRE0 Toggle screw 4 AH
6-1-2 LX-BZA215WREZ Screw : 2 AF
6-1-3 XOTS740P12000 Screw : 4mm x 12mm 1 AB
6-1-4 XTSS750P35000 Screw : 5mm x 35mm 4 AD
6-1-5 XWHS750-16300 Washer 2 AG
6- 2 TINSEB391WRRZ Operation manual 1 AG
6- 3 TINSKA036WRRZ Top template 1 AG
6- 4 QW-QZB023MRE0 High voltage wire A 1 AF
6- 5 FW-VZC451WREZ Main harness 1 AX
6- 6 TCAUAA302WRRZ DHHS service caution label 2 AF
6- 7 TCAUAA292WRRZ Monitor caution label 1 AF
6- 8 TCAUAA300WRRZ Revised DHHS/GRD C/label 1 AF
6- 9 TINSKA037WRRZ Wall template 1 AH
6-10 PFIL-B005MRE0 Grease lter 2 AM
6-11 FFTA-B007MRK0 Exhaust damper assembly 1 AN
6-12 PFIL-B006MRE0 Charcoal lter 1 AR
6-13 PCUSUA660WRPZ Rear cushion (for horizontal venting only) 1 AE
6-14 QW-VZB011MRE0 Sensor ground wire 1 AF
6-15 LANG-A136WRPZ Scale plate 2 AF
SCREWS,NUTS AND WASHERS
7- 1 LX-CZA109WREZ Special screw 3 AF
7- 2 XOTS740P08000 Screw : 4mm x 12mm 20 AB
7- 3 XHPS730P08XS0 Screw 1 AB
7- 4 LX-CZ0052WREZ Special screw 2 AA
7- 5 XEBS730P08000 Screw : 4mm x 8mm 2 AB
7- 6 XHPS740P08K00 Special screw 2 AC
7- 7 XHPS740P08000 Screw : 3mm x 8mm 4 AB
7- 8 LX-WZB003MRE0 Sensor washer 1 AF
7- 9 XOTS840P08000 Special screw 4 AB
7- 10 XHPS730P06000 Screw 2 AB
7- 11 XOTS740P08000 Screw : 4mm x 8mm 3 AB

8
R-1514TY
OVEN AND CABINET PARTS
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
6-1-5
4-10
4-17
7-4
1-10
6-7
4-18
4-17
2-2
6-6
7-1
1-14
7-2
7-2
7-2
7-2
7-2
7-2
2-4
4-7
4-15
4-8
7-6
6-10
2-8 1-13
1-16
1-4
1-11
2-7
6-10
1-10 4-13
7-10
1-19
4-14
7-7
4-20
4-5
1-7
4-16
1-6
7-2
7-2
7-2
7-2
2-3
4-9
7-3
1-8
1-16
1-13
4-6
4-3
4-2
4-11
7-5
7-2
7-2
7-3 2-5
4-19
6-11
2-1
7-2
7-2
4-12
1-12
7-2
1-3 1-15 1-2
1-1
4-4
7-3
2-7-1
2-7-2
1-5
6-8
1-17
7-8
6-14 7-5
2-6
4-21
4-22
6-13
1-9
7-6
6-12
7-9
7-9
7-10
7-7
4-23
1-18
7-11

9
R-1514TY
MISCELLANEOUS
DOOR PARTS
CONTROL PANEL PARTS
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
6-5
6-4
6-1
6-1-1
6-1-5
6-15
6-1-3
6-1-4
6-1-2
5-2
5-1
5-3
5
4-1
5-4
5-4
7-3
3-2
3-3
3-3
3-3
3-2-4
3-2-5
3-4
3-2-1
3-5
3-1

10
R-1514TY
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
PACKING AND ACCESSORIES
4-3 TURNTABLE TRAY
TOP PAD
BOTTOM PAD
PACKING CASE
ACCESSORY PACK
WRAP COVER
DOOR PAD
Non-replaceable items
DOOR PROTECTOR
GREASE FILTER (x 2)
6-10
INSTALL MATERIAL ASSEMBLY
6-1
6-2 OPERATION MANUAL
6-3 TOP TEMPLATE
EXHAUST DAMPER
ASSEMBLY
6-11
6-9 WALL TEMPLATE

11
R-1514TY
NOTES

12
R-1514TY
COPYRIGHT © 2016 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No part of this publication may be reproduced, stored
in retrieval systems, or transmitted in any form or by
any means, electronic, mechanical, photocopying,
recording, or otherwise, without prior written permis-
sion of the publisher.
