Sharp R1406T User manual

1
R-1405-T
R-1406-T
R-1514-T
In the interest of user-safety the unit should be restored to its original condition and only parts identical to those specified should
be used.
WARNING TO SERVICE PERSONNEL:
This service manual is intended for use by persons having electrical and mechanical training and a level of
knowledge of these subjects generally considered acceptable in the appliance repair trade. Sharp Electronics
Corporation cannot be responsible, nor assume any liability, for injury or damage of any kind arising from the
use of this manual.
Microwave ovens contain circuitry capable of producing very high voltage and current. Contact with the
following parts may result in a severe, possibly fatal, electrical shock. (High Voltage Capacitor, High Voltage
Power Transformer, High Voltage Rectifier, Heat sink, Magnetron, and High Voltage Harness etc..)
S20M321R14OTX
R-1514-T
OVER THE RANGE MICROWAVE MODELS
SUPPLEMENTAL SERVICE MANUAL
This document has been published to be used for after sales service only. The contents are subject to change without notice.
SHARP ELECTRONICS CORPORATION
R-1514-T pictured
R-1405-T pictured
R-1405-T/1406-T
S E NS O R
M I C R O W A V E
ST OP / C L EA R
LIG HT H I/ L O
FAN H I/ LO
ST AR T / M IN PL US
This is a supplemental Service Manual for Models R-1405-T, R-1406-T and R-1514-T starting with Serial
Number 511112. Use this supplemental manual together with these base models for complete operation,
service information, etc.
This manual is to be used for models with the starting serial number
511112.

2
R-1405-T
R-1406-T
R-1514-T
SHARP ELECTRONICS CORPORATION
SHARP PLAZA, MAHWAH,
NEW JERSEY 07430-2135
SUPPLEMENTAL SERVICE MANUAL
OVER THE RANGE MICROWAVE OVEN
R-1405-T / R-1406-T / R-1514-T
FOREWORD
This Manual has been prepared to provide Sharp Electronics Corp. Service Personnel with Operation and Service Informa-
tion for the SHARP OVER THE RANGE MICROWAVE OVENS.
It is recommended that service personnel carefully study the entire text of this manual so that they will be qualified to render
satisfactory customer service.
Check the interlock switches and the door seal carefully. Special attention should be given to avoid electrical shock and
microwave radiation hazard.
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained service personnel.
DANGER
Certain initial parts are intentionally not grounded and present a risk of electrical shock only during servicing.
Service personnel - Do not contact the following parts while the appliance is energized;
High Voltage Capacitor, Power Transformer, Magnetron, High Voltage Rectifier Assembly, High Voltage Harness;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked “*” on parts list are used at voltages more than 250V.
Removal of the outer wrap gives access to voltage above 250V.
All the parts marked “∆” on parts list may cause undue microwave exposure, by themselves, or when they are dam-
aged, loosened or removed.
BEFORE SERVICING
Before servicing an operative unit, perform a microwave emission check as per the Microwave Measurement
Procedure outlined in this service manual.
If microwave emissions level is in excess of the specified limit, contact SHARP ELECTRONICS CORPORA-
TION immediately @1-800-237-4277.
If the unit operates with the door open, service person should 1) tell the user not to operate the oven and 2)
contact SHARP ELECTRONICS CORPORATION and Food and Drug Administration's Center for Devices
and Radiological Health immediately.
Service personnel should inform SHARP ELECTRONICS CORPORATION of any certified unit found with
emissions in excess of 4mW/cm2. The owner of the unit should be instructed not to use the unit until the oven
has been brought into compliance.

3
R-1405-T
R-1406-T
R-1514-T
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
ELECTRIC PARTS
1- 1 FH-DZB033MRY0 High voltage rectier assembly 1 AN
1- 2 RC-QZA026WRZZ High voltage capacitor 1 AT
1- 3 QFS-TA013WRE0 Temperature fuse 150½C (Magnetron) 1 AG
1- 4 RMOTDA252WRZZ Turntable motor 1 AN
1- 5 RTHM-A135WRZZ Thermal cut-out 145½C (Cavity) 1 AG
1- 6 RTHM-A136WRZZ Thermal cut-out N.O. 60½C (Hood Fan) 1 AK
1- 7 RTRN-B096MRE0 Power transformer 1 BL
1- 8 RV-MZA293WRE0 Magnetron 1 BH
1- 9 FPWBFA437WRKZ Noise lter 1 AS
1-10 QSW-MA085WRE0 Primary interlock and door sensing switches 3 AF
1-11 FFS-BA033WRKZ Monitor switch (V-5220Q) & fuse assy (20A, 120VAC) 1 AN
1-12 FACCDB011MRE0 Power supply cord 1 AV
1-13 QSOCLA021WRE0 Oven lamp socket 3 AG
1-14 FMOTEA469WRKZ Hood fan motor [R-1405-T/R-1406-T] 1 BL
1-14 FMOTEA489WRKZ Hood fan motor [R-1514-T] 1 BK
1-15 RMOTEB031MRE0 Fan motor 1 AT
1-16 RLMPTA086WRZZ Oven lamp 3 AL
1-17 FDTCTA225WRKZ AH sensor 1 AW
CABINET PARTS
2- 1 LSTY-A121WRWZ Rear stay 1 AN
2- 2 PDIF-A042WRFZ Hood exhaust louver [R-1405-T] 1 AX
2- 2 PDIF-A044WRFZ Hood exhaust louver [R-1406-T] 1 AX
2- 2 FDIF-B014MRK0 Hood exhaust louver [R-1514-T] 1 BF
2- 3 GDAI-A461WRWZ Base plate R 1 AQ
2- 4 HDECQA467WRFZ Front panel L [R-1405-T] 1 AP
2- 4 HDECQA469WRFZ Front panel L [R-1406-T] 1 AP
2- 4 FDECAB031MRK0 Front panel L [R-1514-T] 1 AX
2- 5 GCABUB185WRPZ Outer case cabinet [R-1405-T/R-1514-T] 1 BG
2- 5 GCABUB188WRPZ Outer case cabinet [R-1406-T] 1 BL
2- 6 TMAPCA797WRRZ Schematic diagram [R-1405-T/R-1406-T] 1 AD
2- 6 TMAPCA799WRRZ Schematic diagram [R-1514-T] 1 AD
2- 7 FANGKB009MRY0 Hood lamp glass assembly [R-1405-T/R-1514-T] 1 AP
2- 7 FANGKB029MRY0 Hood lamp glass assembly [R-1406-T] 1 AQ
2-7-1 LANGQB016MRP0 Hood lamp glass angle [R-1405-T/R-1514-T] 1 AM
2-7-1 LANGQB082MRP0 Hood lamp glass angle [R-1406-T] 1 AN
2-7-2 PGLSPB004MRE0 Hood lamp glass 1 AQ
2- 8 PCOVPA553WRPZ Base cover [R-1405-T/R-1514-T] 1 AZ
2- 8 PCOVPA561WRTZ Base cover [R-1406-T] 1 AZ
CONTROL PANEL PARTS
3- 1 GPNLCA007WRKZ T/C sub assy [R-1405-T/R-1406-T] 1 BP
3- 1 GPNLCA006WRKZ T/C sub assy [R-1514-T] 1 BQ
3- 2 FPNLCC070WRKZ Control panel sub. assembly [R-1405-T] 1 AX
3- 2 FPNLCC071WRKZ Control panel sub, assembly [R-1406-T] 1 AX
3- 2 FPNLCB420MRK0 Control panel sub, assembly [R-1514-T] 1 BH
3- 2-1 PSHEPB135MRR0 Key unit [R-1405-T] 1 AN
3- 2-1 PSHEPB134MRR0 Key unit [R-1406-T] 1 AN
3- 2-1 PSHEPB136MRR0 Key unit [R-1514-T] 1 AN
3- 2-2 JBTN-B641WRFZ Open button [R-1405-T] 1 AG
3- 2-2 JBTN-B642WRFZ Open button [R-1406-T] 1 AG
3- 2-2 FDECAB030MRK0 Open button [R-1514-T] 1 AT
3- 2-3 MSPRCA045WRE0 Button spring [R-1405-T/R-1406-T] 1 AF
3- 2-3 MSPRTA050WRE0 Button spring [R-1514-T] 1 AA
3- 3 XEPS730P10XS0 Screw; 3mm x 10mm 5 AA
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
*
*

4
R-1405-T
R-1406-T
R-1514-T
REF. NO. PART NO. DESCRIPTION Q'TY CODE
OVEN PARTS
4- 1 LSTPPB038MRF0 Door stopper 1 AF
4- 2 FROLPA097WRKZ Turntable support assembly 1 AN
4- 3 NTNT-A108WREZ Turntable tray 1 AW
4- 4 LBNDKA186WRPZ Capacitor holder 1 AF
4- 5 PDUC-B155WRFZ Magnetron duct 1 AK
4- 6 MLEVPA244WRFZ Open lever 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1
4- 8 PPACGA084WRF0 Turntable motor packing 1 AE
4- 9 PHOK-A130WRFZ Latch hook 1 AK
4-10 LANGTA477WRWZ Unit mounting plate assembly 1 AT
4-11 NFANJA060WRFZ Fan blade 1 AH
4-12 LBSHCA014WRE0 Cord bushing 1 AG
4-13 PDUC-B173WRFZ Orice 2 AK
4-14 PDUC-B157WRWZ Hood intake duct R 1 AN
4-15 PCOVPA554WRPZ Waveguide cover 1 AF
4-16 PCUSUA661WRPZ Transformer cushion 2 AC
4-17 LANGTA479WRPZ Chassis support 2 AK
4-18 PDUC-B158WRFZ Hood duct R 1 AQ
4-19 PDUC-B156WRFZ Hood duct L 1 AR
4-20 PDUC-B159WRWZ Fan duct 1 AM
4-21 PCUSUA665WRPZ Cushion [R-1514-T only] 1 AG
4-22 PCUSUA672WRPZ Cushion 1 AF
DOOR PARTS
5 CDORFB321MRK0 Door assembly [R-1405-T] 1 BL
5 CDORFB322MRK0 Door assembly [R-1406-T] 1 BL
5 CDORFB317MRK0 Door assembly [R-1514-T] 1 BQ
5-1 LSTPPB023MRF0 Latch head 1 AF
5-2 MSPRTA046WRE0 Latch spring 1 AD
5-3 GCOVHB044MRF0 Choke cover 1 AX
5-4 XCPSD40P08000 Screw : 4mm x 8mm 2 AC
MISCELLANEOUS
6- 1 CFZK-B657WRKZ Installation material assembly 1 AQ
6-1-1 LX-BZ0195WRE0 Toggle screw 4 AH
6-1-2 XBPS750P85000 Screw : 5mm x 60mm 2 AF
6-1-3 XOTS740P12000 Screw : 4mm x 12mm 3 AB
6-1-4 XTSS750P35000 Screw : 5mm x 35mm 6 AD
6-1-5 XWHS750-16300 Washer 2 AG
6-1-6 LANG-A136WRPZ Scale plate 2 AF
6- 2 TINSEB233WRKZ Operation manual [R-1405-T/R-1406-T] 1 AN
6- 2 TINSEB237WRRZ Operation manual [R-1514-T] 1 AN
6- 3 TINSKA036WRRZ Top template 1 AG
6- 4 QW-QZB023MRE0 High voltage wire A 1 AF
6- 5 FW-VZC270WREZ Main harness [R-1405-T/R-1406-T] 1 AY
6- 5 FW-VZC271WREZ Main harness [R-1514-T] 1 AY
6- 6 TCAUAA302WRRZ DHHS service caution label 2 AF
6- 7 TCAUAA301WRRZ Monitor caution label 1 AF
6- 8 TCAUAA300WRRZ Revised DHHS/GRD C/label 1 AF
6- 9 TINSKA037WRRZ Wall template 1 AH
6-10 PFIL-B002MRE0 Grease lter 2 AM
6-11 FFTA-B007MRK0 Exhaust damper assembly 1 AN
6-12 PFIL-B006MRE0 Charcoal lter [R-1514-T] 1 AR
6-13 PCUSUA660WRPZ Rear cushion (for horizontal venting only) 1 AE
6-14 QW-VZB011MRE0 Sensor ground wire [R-1514-T only] 1 AF

5
R-1405-T
R-1406-T
R-1514-T
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
PACKING AND ACCESSORIES
SCREWS,NUTS AND WASHERS
7- 1 LX-CZA109WREZ Special screw (R-1405-T/R-1514-T) 3 AF
7- 1 LX-CZA108WREZ Special screw (R-1406-T) 3 AD
7- 2 XOTS740P08000 Screw : 4mm x 12mm 20 AB
7- 3 XHTS740P08RV0 Screw : 4mm x 8mm 4 AG
7- 4 LX-CZ0052WREZ Special screw 2 AA
7- 5 XEBS730P08000 Screw : 4mm x 8mm [R-1514-T only] 2 AB
7- 6 XHPS740P08K00 Special screw 2 AC
7- 7 XHPS740P08000 Screw : 3mm x 8mm 4 AB
7- 8 LX-WZB003MRE0 Sensor washer [R-1514-T only] 1 AF
7- 9 XOTS840P08000 Special screw [R-1405-T/R-1514-T] 4 AB
7- 9 XOTS740P08000 Special screw [R-1406-T] 4 AB
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-3 TURNTABLE TRAY
TOP PAD
BOTTOM PAD
PACKING CASE
ACCESSORY PACK
WRAP COVER
DOOR PAD
Non-replaceable items
DOOR PROTECTOR
GREASE FILTER (x 2)
6-10
INSTALL MATERIAL ASSEMBLY
6-1
6-2 OPERATION MANUAL
6-3 TOP TEMPLATE
EXHAUST DAMPER
ASSEMBLY
6-11
6-9 WALL TEMPLATE

6
R-1405-T
R-1406-T
R-1514-T
OVEN AND CABINET PARTS
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
6-1-5
4-10
4-17
7-4
1-10
6-7
4-18
4-17
2-2
6-6
7-1
1-14
7-2
7-2
7-2
7-2
7-2
7-2
2-4
4-7
4-15
4-8
7-6
6-10
2-8 1-13
1-16
1-4
1-11
2-7
6-10
1-10 4-13
7-10
1-11
4-14
7-7
4-20
4-5
1-7
4-16
1-6
7-2
7-2
7-2
7-2
2-3
4-9
7-3
1-8
1-16
1-13
4-6
4-3
4-2
4-11
7-5
7-2
7-2
7-3 2-5
4-19
6-11
2-1
7-2
7-2
4-12
1-12
7-2
1-3 1-15 1-2
1-1
4-4
7-3
2-7-1
2-7-2
1-5
6-8
1-17
7-8
6-14 7-5
2-6
4-21
4-22
6-13
1-9
7-6
6-12
7-9
7-9
7-10

7
R-1405-T
R-1406-T
R-1514-T
MISCELLANEOUS
DOOR PARTS
CONTROL PANEL PARTS
6
4 5
123
6
4 5
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
6-5
6-4
3-2-1
3-2-2
3-2-3
3-3
3-3
3-1
3-3
5-2
5-1
5-3
5
6-1
6-1-1
6-1-5
6-1-6
6-1-3
6-1-4
6-1-2
3-2-1
3-2-2
3-2-3
7-3
3-3
3-3
3-1
3-3
5-2
5-1
5-3
5
4-1
5-4
5-4
7-3
5-4
3-2
3-2
R-1514-T
R-1405-T/1406-T
R-1514-T
R-1405-T/1406-T

8
R-1405-T
R-1406-T
R-1514-T
COPYRIGHT © 2010 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No part of this publication may be reproduced, stored
in retrieval systems, or transmitted in any form or by
any means, electronic, mechanical, photocopying,
recording, or otherwise, without prior written permis-
sion of the publisher.
'10 SHARP CORP. (9S2.420E) Printed in U.S.A
