Sharp YC-MG02E-S User manual

YC-MG02E-S, YC-MG51E-S, YC-MG81E-S
Operation manual
Microwave Oven with Grill
*Product images are for illustration purpose only. Actual product may vary.
EN ESDE PT FR PL NL

EN
GB-1
ENGLISH
&/
EN-1EN-1
dustbin!

GB-2
SPECIFICATIONS
CONTENTS
INFORMATION ON PROPER DISPOSAL ......................................................................................................................................1
CONTENTS ...........................................................................................................................................................................................2
SPECIFICATIONS ................................................................................................................................................................................ 2
OVEN AND ACCESSORIES ..............................................................................................................................................................3
CONTROL PANEL ...............................................................................................................................................................................4
IMPORTANT SAFETY INSTRUCTIONS .....................................................................................................................................5-
INSTALLATION ..................................................................................................................................................................................1
BEFORE OPERATION ......................................................................................................................................................................18
SETTING THE CLOCK ......................................................................................................................................................................18
MICROWAVE POWER LEVEL ........................................................................................................................................................18
MANUAL OPERATION ....................................................................................................................................................................19
MICROWAVE COOKING .................................................................................................................................................................19
GRILL COOKING/ MIX GRILL COOKING .................................................................................................................................20
OTHER CONVENIENT FUNCTIONS ............................................................................................................................................21
TIME DEFROST AND WEIGHT DEFROST OPERATION .........................................................................................................22
AUTO MENU OPERATION .............................................................................................................................................................22
AUTO MENU CHART ......................................................................................................................................................................23
SUITABLE OVENWARE ...................................................................................................................................................................24
CARE AND CLEANING ...................................................................................................................................................................25
Operation manual
Model name: R-642 R-742
AC Line Voltage : 230 V, 50 Hz single phase : 230 V, 50 Hz single phase
Distribution line fuse/circuitbreaker : 10 A : 10 A
AC Power required: Microwave : 1270 W : 1450 W
Outputpower: Microwave : 800 W : 900 W
Grill : 1000 W : 1000 W
O Mode (Energy Save Mode) : less than 1.0 W : less than 1.0 W
: 2450 MHz* : 2450 MHz*
: 439,5 x 257,8 x 358,5 : 513,0 x 306,2 x 429,5
: 306,0 x 208,2 x 306,6 : 330,0 x 208,0 x 369,0
: 20 litres*** : 25 litres***
: ø 255 mm : ø 315 mm
: approx. 11,4 kg : approx. 15,1 kg
Microwave Frequency
Outside Dimensions(W) x (H) x (D) mm
Cavity Dimensions(W) x (H) x (D)** mm
Oven Capacity
Turntable
Weight
Oven lamp : 25 W/240 V : 25 W/240 V
* ThisProductfullsthe requirementof the European standard EN55011.
In conformity with thisstandard, thisproductisclassied asgroup 2 class B equipment.
Group 2 meansthatthe equipmentintentionally generatesradio-frequency energy in the form of electromagnetic
radiation for the heattreatmentof food.
Class B equipmentmeansthatthe equipmentissuitable to be used in domestic establishments.
** Internal capacity iscalculated by measuring maximum width, depth and height. Actual capacity for holding food is
less.
AS PART OF A POLICY OF CONTINUOUS IMPROVEMENT, WE RESERVE THE RIGHT TO ALTER DESIGN AND SPECIFICA-
TIONS WITHOUT NOTICE.
1
6
5
EN-2EN-2
Model name: YC-MG02E-S YC-MG51E-S YC-MG81E-S
ACLineVoltage : 230 V,50 Hz single phase :230 V,50 Hz single phase :230 V,50 Hz single phase
Distribution linefuse/circuit breaker:10 A :10 A :10 A
ACPower required:Microwave:1270 W :1450 W :1450 W
Output power:Microwave:800 W :900 W :900 W
Grill :1000 W :1000 W :1100 W
Standby:< 1,0W :< 1,0W :< 1,0W
Energy SaveMode:< 0,5W :< 0,5W :< 0,5W
MicrowaveFrequency : 2450 MHz*:2450 MHz*:2450 MHz*
OutsideDimensions (W)x(H)x(D)mm :440 x258x324 :513x306 x394 :512 x300 x396
CavityDimensions (W)x(H)x(D)** mm :306 x205 x304 :328x206 x368:348x226 x356
Oven Capacity:20 litres** : 25 litres** : 28litres**
Turntable:ø255 mm :ø315 mm :ø315 mm
Weight :approx. 11,5 kg:approx. 15,4 kg:approx. 15,8 kg
Oven lamp :25 W :25 W :25 W

EN
GB-3
ENGLISH
OVEN AND ACCESSORIES
NOTES:
• The waveguide cover isfragile. Care should be taken when cleaning inside the oven to ensure thatitisnot
damaged.
•After cooking fatty foodswithouta cover, alwaysclean the cavity and especially the grill heating element
thoroughly, these must be dry and free from grease. Built-up grease may overheatand begin to smoke or
catch fire.
• Alwaysoperate the oven with the turntable and turntable supportfitted correctly. Thispromotesthorough,
even cooking. A badly fitted turntable may rattle, may notrotate properly and could cause damage to the
oven.
• All food and containersof food are alwaysplaced on the turntable for cooking.
• The turntable rotatesclockwise or anti-clockwise. The rotary direction may change each time you startthe
oven. Thisdoesnotaffectcooking performance.
WARNING: This symbol means that the surfaces are liable to get hot during use. The door, outer
cabinet, oven cavity, accessories and dishes will become very hot during operation. To prevent burns,
always use thick oven gloves.
OVEN
1. Door
2. Door hinges
3. Oven lamp
4. Waveguide cover (DO NOT REMOVE)
5. Control panel
6. Coupling
7. Door latches
8. Oven cavity
9. Door sealsand sealing surfaces
10. Door safety latches
11. Ventilation openings
12. Outer cabinet
13. Power supply cord
14. Door handle
ACCESSORIES:
Check to make sure the following accessoriesare
provided:
(15)Turntable (16) Turntable support(17) Coupling
(18) Rack
• Place the turntable supportin the centre of the
oven floor so thatitcan freely rotate around the
coupling. Then place the turntable on to the turn-
table supportso thatitlocatesfirmly into the cou-
pling.
• To avoid turntable damage, ensure dishesand con-
tainersare lifted clear of the turntable rim when
removing them from the oven.
For use of the rack, refer to the grilling sectionson
page &/0.
Hub (inside)
15. Turntable
(glass)
17. Coupling 16. Turntable
support
18. Rack
11
12
13
12 3
5
10 9 8
14 647
Never touch the grill when it is hot.
NOTE: When you order accessories, please
mention two items: partname and model name
EN-3EN-3
13
12
11
10 89647
12 3
5
14
Door openingbutton
YC-MG81E-S
YC-MG02E-S,
YC-MG51E-S

GB-4
CONTROL PANEL
1
2
4
5
8
11
9
1213
6
3
10
7
1. DIGITAL DISPLAY
2. WEIGHT DEFROST key
3. TIME DEFROST key
4.AUTO MENU keys
Popcorn
JacketPotato
Pizza
Frozen Vegetables
Beverage
Dinner Plate
5. TIME keys
6. MICROWAVE POWER LEVEL key:
Press to selectmicrowave power level.
7. Grill key
8. Mix Grill key
9. WEIGHT/PORTION keys (up and down)
10. KITCHEN TIMER key
Press to use asa minute timer, or to
programme standing time.
 CLOCK SET key
 START/ T
 STOP key
EN-4EN-4
2
4
5
8
9
11
12
1
3
6
7
10
13
30s
STOP/ECO key

EN
GB-5
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
To avoid the danger of fire.
The microwave oven should not be left unattended
during operation. Power levels that are too high,
or cooking times that are too long, may overheat
foods resulting in a re.
Thisoven isdesigned to be used on a countertop
only. Itisnotdesigned to be builtinto a kitchen unit.
Do notplace the oven in a cabinet.
The electrical outletmust be readily accessible so that
the unitcan be unplugged easily in an emergency.
The AC power supply must be 230 V, 50 Hz, with a
minimum 10 A distribution line fuse, or a minimum
10 A distribution circuitbreaker.
A separate circuitserving only thisappliance should
be provided.
Do notplace the oven in areaswhere heatisgenerated.
For example, close to a conventional oven.
Do notinstall the oven in an area of high humidity or
where moisture may collect.
Do notstore or use the oven outdoors.
IMPORTANT SAFETY INSTRUCTIONS:
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
EN-5EN-5

GB-6
IMPORTANT SAFETY INSTRUCTIONS
If smoke is observed, switch off or unplug the
oven and keep the door closed in order to stifle
any flames.
Use only microwave-safe containers and utensils.
See Page &/24. Utensils should be checked
to ensure that they are suitable for use in
microwave ovens.
When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition.
Clean the waveguide cover, the oven cavity,
the turntable and turntable support after use.
These must be dry and free from grease. Built-
up grease may overheat and begin to smoke or
catch fire.
Do notplace flammable materialsnear the oven or
ventilation openings.
Do notblock the ventilation openings.
Remove all metallic seals, wire twists, etc., from food
and food packages. Arcing on metallic surfacesmay
cause a re.
Do notuse the microwave oven to heatoil for deep
frying. The temperature cannotbe controlled and the
oil may catch re.
To make popcorn, use only special microwave
popcorn makers.
Do notstore food or any other itemsinside the oven.
Check the settingsafter you startthe oven to ensure
the oven isoperating asdesired.
EN-6EN-6

EN
GB-7
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
See the corresponding hints in the operation manual.
To avoid the possibility of injury
WARNING:
Do notoperate the oven if itisdamaged or
malfunctioning. Check the following before use:
B .BLFTVSFUIFEPPSDMPTFTQSPQFSMZBOEFOTVSF
JUJTOPUNJTBMJHOFEPSXBSQFE
C The hingesand safety door latches; check to
make sure they are notbroken or loose.
D The door sealsand sealing surfaces; ensure that
they have notbeen damaged.
E Inside the oven cavity or on the door; make
sure there are no dents.
F The power supply cord and plug; ensure that
they are notdamaged.
If the door or door sealsare damaged, the oven
must notbe operated until ithasbeen repaired by a
competentperson.
Never adjust, repair or modify the oven yourself.
It is hazardous for anyone other than a competent
person to carry out any service or repair operation
which involves the removal of a cover which gives
protection against exposure to microwave energy.
To avoid overheating and fire, special care must be
taken when cooking or reheating foodswith a high
sugar or fatcontent, for example, Sausage rolls, Pies
or Christmaspudding.
EN-7EN-7

GB-8
IMPORTANT SAFETY INSTRUCTIONS
Do notoperate the oven with the door open or alter
the door safety latchesin any way. Do notoperate the
oven if there isan objectbetween the door sealsand
sealing surfaces.
Do not allow grease or dirt to build up on the
door seals and adjacent parts. Clean the oven at
regular intervals and remove any food deposits.
Follow the instructions for "Care and Cleaning"
on page &/25. Failure to maintain the oven in a
clean condition could lead to a deterioration of
the surface that could adversely affect the life
of the appliance and possibly result in a
hazardous situation.
Individualswith PACEMAKERS should check with their
doctor or the manufacturer of the pacemaker for
precautionsregarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstancesshould you remove the outer
cabinet.
Never spill or insertany objects into the door lock
openingsor ventilation openings. In the eventof a
spill, turn o and unplug the oven immediately, and
call an authorised SHARP service agent.
Do notimmerse the power supply cord or plug in
water or any other liquid.
Do notletthe power supply cord hang over the edge
of a table or work surface.
EN-8EN-8

EN
GB-9
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Keep the power supply cord away from heated
surfaces, including the rear of the oven.
Keep the appliance and its cord outof reach of
children less than 8 years.
Do notattemptto replace the oven lamp yourself or
allow anyone who isnotan electrician authorised by
SHARP to do so. If the oven lamp fails, please consult
your dealer or an authorised SHARP service agent.
If the power supply cord of thisappliance isdamaged,
itmust be replaced with a special cord.
The exchange must be made by an authorised SHARP
service agent.
To avoid the possibility of explosion and sudden
boiling:
WARNING: Liquids and other foods must not be
heated in sealed containers since they are liable
to explode.
Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be
taken when handling the container.
Never use sealed containers. Remove sealsand lids
before use. Sealed containerscan explode due to a
build up of pressure even after the oven hasbeen
turned o.
Take care when microwaving liquids. Use a wide
mouthed container to allow bubblesto escape.
EN-9EN-9
Theexchange must bemadebyqualied persons in
order to avoid ahazard.

GB-10
IMPORTANT SAFETY INSTRUCTIONS
Never heat liquids in narrow necked containers
such as baby bottles, as this may result in the
contents erupting from the container when
heated and cause burns.
To preventsudden eruption of boiling liquid and
possible scalding:
1.Do notuse excessive amountof time.
2.Stir liquid prior to heating/reheating.
3.Itisadvisable to inserta glass rod or similar utensil
(notmetal) into the liquid whilst reheating.
4.Letliquid stand for atleast 20 secondsin the oven
atthe end of cooking time to preventdelayed
eruptive boiling.
Do not cook eggs in their shells, and whole hard
boiled eggs should not be heated in microwave
ovens since they may explode even after
microwave cooking has ended. To cook or reheat
eggs which have not been scrambled or mixed,
pierce the yolks and the whites, or the eggs may
explode. Shell and slice hard boiled eggs before
reheating them in the microwave oven.
Pierce the skin of such foodsaspotatoes, sausages
and fruitbefore cooking, or they may explode.
EN-10EN-10

EN
GB-11
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
hotduring use. Young children should be keptaway.
Temperature of the container isnota true indication
of the temperature of the food or drink; alwayscheck
the food temperature.
Alwaysstand back from the oven door when opening
itto avoid burnsfrom escaping steam and heat.
Slice stuffed baked foodsafter heating to release
steam and avoid burns.
Keep children away from the door to preventthem
burning themselves.
To avoid the possibility of burns
WARNING: The contents of feeding bottles and
baby food jars must be stirred or shaken and the
temperature checked before consumption, in
order to avoid burns.
Use pot holders or oven gloves when removing
food from the oven to prevent burns.
Alwaysopen containers, popcorn makers, oven
cooking bags, etc., away from the face and handsto
avoid steam burnsand eruption of boiling.
To avoid burns, alwaystest food temperature and
stir before serving and pay special attention to the
temperature of food and drink given to babies,
children or the elderly. Accessible parts may become
EN-11EN-11

IMPORTANT SAFETY INSTRUCTIONS
To avoid misuse by children
WARNING: Only allow children aged from 8years
and above to use the oven without supervision
when adequate instructions have been given
so that the child is able to use the oven in a safe
way and understands the hazards of improper
use. When the appliance is operated in the
GRILL, MIX GRILL and AUTO MENU operation,
children should only use the oven under adult
supervision due to the temperature generated.
This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
5IJT PWFO JT FOBCMFE XJUI B DIJME MPDL NPEF
SFGFSUPQBHF&/GPSNPSFEFUBJMT
Do notlean or swing on the oven door. Do notplay
with the oven or use itasa toy.
Children should be taughtall importantsafety
instructions: use of potholders, careful removal of
food coverings; paying special attention to packaging
(e.g. self-heating materials) designed to make
food crisp, asthey may be extra hot.
EN-12EN-12

EN
GB-13
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Other warnings
Never modify the oven in any way.
Do notmove the oven while itisin operation.
Thisappliance isintended to be used in household
and similar applicationssuch as:
•staff kitchen areasin shops, officesand other
working environments;
• farm houses;
•by clients in hotels, motelsand other residential
environments;
•bed and breakfast type environments.
Thisoven isfor home food preparation only and may
only be used for cooking food. Itisnotsuitable for
commercial or laboratory use.
To promote trouble-free use of your oven and
avoid damage.
Never operate the oven when itisempty. When using
a browning dish or self-heating material, alwaysplace
a heat-resistantinsulator such asa porcelain plate
under itto preventdamage to the turntable and
turntable supportdue to heatstress. The preheating
time specied in the dishesinstructionsmust notbe
exceeded.
EN-13EN-13

GB-14
IMPORTANT SAFETY INSTRUCTIONS
Do notuse metal utensils, which reectmicrowaves
and may cause electrical arcing. Do notputcansin
the oven.
Use only the turntable and the turntable support
designed for thisoven. Do notoperate the oven
withoutthe turntable.
To preventthe turntable from breaking:
(a) Before cleaning the turntable with water, leave
the turntable to cool.
(b)Donotputhotfoodsor hotutensilson a cold
turntable.
(c) Do notputcold foodsor cold utensilson a hot
turntable.
Do notplace anything on the outer cabinetduring
operation.
EN-14EN-14

EN
GB-15
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
NOTE:
Do notuse plastic containersfor microwaving if the
oven isstill hotfrom using the GRILL and MIX GRILL
operation because they may melt.
Plastic containersmust notbe used during above
modesunless the container manufacturer saysthey
are suitable.
If you are unsure how to connectyour oven, please
consultan authorised, qualied electrician.
Neither the manufacturer nor the dealer can accept
any liability for damage to the oven or personal injury
resulting from failure to observe the correctelectrical
connection procedure.
Water vapour or dropsmay occasionally form on
the oven wallsor around the door sealsand sealing
surfaces. Thisisa normal occurrence and isnotan
indication of microwave leakage or a malfunction.
Thissymbol meansthatthe surfacesare liable
to gethotduring use.
EN-15EN-15

GB-16
INSTALLATION
 Remove all packing materialsfrom the inside of
the oven cavity and remove any protective film
found on the microwave oven cabinetsurface.
 Check the oven carefully for any signsof damage.
 Place the oven on a secure, level surface, strong
enough to take the oven weight, plusthe heaviest
item likely to be cooked in the oven. Do notplace
the oven in a cabinet.
 Selecta level surface thatprovide enough open
space for the intake and/or outletvents.
The rear surface of appliance DBO be placed
against a wall.
• The minimum installation heightis85 cm.
•"NJOJNVNTQBDFPGDNJTSFRVJSFECFUXFFO
UIFTJEFTPGUIFNJDSPXBWFPWFOBOEBOZ
BEKBDFOUXBMMTPSPCKFDUT.
• Leave a minimum space of 30 cm above the oven.
• Do notremove the feetfrom the bottom of the
oven.
• Blocking the intake and/or outletopeningscan
damage the oven.
• Place the oven asfar away from radiosand TV
aspossible. Operation of microwave oven may
cause interference to your radio or TV reception.
EN-16EN-16

EN
GB-17
ENGLISH
INSTALLATION
5.Securely connectthe plug of the oven to a standard
earthed (grounded) household electrical outlet.
WARNING: Do notplace the oven where heat,
moisture or high humidity are generated, (for
example, near or above a conventional oven) or near
combustible materials(for example, curtains).
Do notblock or obstructair ventopenings.
Do notplace objects on top of the oven.
%POPUUPVDIUIFFYUFSJPSPGUIFNJDSPXBWFPWFO
EVSJOHPSTIPSUMZBGUFSPQFSBUJPOBTJUXJMMCFIPU
20 cm
30 cm
20 cm
0cm
min
85 cm
EN-17EN-17

GB-18
BEFORE OPERATION
MICROWAVE POWER LEVEL
This model has a clock function and the oven usesless than 1.0 W in stand by mode. To set the clock, see below.
SETTING THE CLOCK
Your oven hasa 24 hour clock mode.
1. Press the CLOCK SET key once and“00:00” will ash.
2. Press the time keysand enter the currenttime. Enter the hoursby pressing the NJO key and enter the
minutesby pressing the 1NJO and 10 Tkeys.
3. Press the CLOCK SET key to nish clock setting.
NOTES:
• If the clock isset, when cooking iscomplete, the display will show the correcttime of day. If the clock hasnot
• To check the time of day during a cooking process, press CLOCK SET key and the LED will display the time of
day for 2-3 seconds.Thisdoesnotaectthe cooking process.
•
•
Power Level Press the MICROWAVE
POWER LEVEL key
Display
(Percentage)
• Your oven has11 power levels, asshown.
•
•
•
5PDIBOHFUIFQPXFSMFWFMGPSDPPLJOH
QSFTTUIF.*$308"7&108&3-&7&-LFZ
VOUJMUIFEJTQMBZJOEJDBUFTUIFEFTJSFEMFWFM
4FUVQUIFEFTJSFEDPPLJOHUJNFCZ
QSFTTJOH5*.&LFZT Press theSTART key to
startthe oven.
To check the power level during cooking,
press the MICROWAVE POWER LEVEL key.
Aslong asyour finger ispressing the MICRO-
WAVE POWER LEVEL key the power level will
be displayed. The oven continuesto count
down although the display will show the
power level.
If “0P” isselected, the oven will work with fan
for no power. You can use thislevel UPSFNPWF
BOZPEPVST.
HIGH x1 100P
x2 90P
MEDIUM HIGH x3 80P
x4 70P
MEDIUM x5 60P
x6 50P
MEDIUM LOW
(DEFROST)
x7 40P
x8 30P
LOW x9 20P
x10 10P
x11 0P
Generally the following recommendationsapply:
100P/ 90P- (HIGH) used for fast cooking or reheating
e.g. for casseroles, hotbeverages, vegetablesetc.
80P/ 70P- (MEDIUM HIGH) used for longer cooking of dense
foodssuch asroast joints, meatloaf and plated meals, also for
sensitive dishessuch assponge cakes. Atthisreduced setting,
the food will cook evenly withoutover cooking atthe sides.
60P/ 50P- (MEDIUM) for dense foodswhich require a
long cooking time when cooked conventionally, e.g.
beef casserole, itisadvisable to use thispower setting
to ensure the meatwill be tender.
40P/ 30P- (MEDIUM LOW) to defrost, selectthispower
setting, to ensure thatthe dish defrosts evenly. This
setting isalso ideal for simmering rice, pasta, dump-
lingsand cooking egg custard.
20P/ 10P- (LOW) For gentle defrosting, e.g. DSFBN
HBUFBVYPS pastry.
Plug in the oven. The oven display will display: “0:00”, an audible signal will sound once.
8IJMFJOUIFDMPDLTFUUJOHNPEF, if the STOP key ispressed or if there isno operation within 1 minute, the
oven will go back to the former setting.
If the electrical power supply to your microwave oven isinterrupted, the display will intermittently show “0:00” after
the power isreinstated. If thisoccursduring cooking, the programme will be erased. The time of day will also be erased.
been set, the display will only show“0:00” when cooking iscomplete.
EN-18EN-18
