Sharp ZQ-P10A User manual

Part Names
Using the Organizer for the First Time
Be sure to perform the following operations
before using the Organizer for the first time.
1. Pull out to remove the isolating film on the
back of the unit.
2. Press the RESET switch with a stylus.
"RESET?" is displayed.
3. Tap fand press xto initialize the
Organizer. Moments later, "RESET!" will be
displayed, and the Organizer's memory
contents will be cleared.
Soon after, the Select Language screen appears.
Guidance messages can be displayed in 10
languages: English, Italian, German, French,
Spanish, Portuguese, Hungarian, Czech, Polish,
and Greek. When the Organizer is initialized, the
setting will revert to English as default.
Select the desired language using >or <,
then press x. When the language is set, the
Home Clock will be displayed on the screen. (See
"Clock Mode".)
NOTES
• If the Organizer is subjected to strong,
extraneous electrical noises or shocks during
use, an abnormal condition may occur in which
no keys (including
ON
OFF
) will respond. Press
the RESET switch, tap f, then press x
to delete all the memory contents.
•To minimize battery consumption, the Organizer
is designed to turn its power off automatically
when no key activities are detected for
approximately 7 minutes.
•The key touch tone can be turned on and off by
tapping h!, select "KEY TONE?"
using >or <, and press x. Select
on/off using >or <, then press x.
When the tone is activated, “ ” will appear.
Entering Characters
Touch Keyboard
Alphabet entry mode Number entry mode
•Each time fis tapped, the touch keyboard
switches between the Alphabet entry mode and
the Number entry mode.
To tap the touch keys, use the attached stylus.
•Tap towards the center of each key.
•Numbers, alphanumeric letters, symbols, and
“+ – ×÷ .”
can be entered into the dot display area (the 1st
line).
•Numbers and some characters (only space, –,
F, and P in Telephone mode) can be entered into
the number display area (the 2nd and the 3rd
lines).
•Letters are entered in capital letters (“CAPS” is
turned on). To enter lowercase letters, tap
CAPS
to turn “CAPS” off.
Entering symbols and letters with an accent
mark
•To enter a symbol, tap
SMBL
repeatedly until
the desired symbol appears:
@#$£¥ ( )~’: /\_&<>ß!?¡¿æµ¢
•To enter a letter with an accent mark, tap the
relevant key shown below repeatedly after
tapping s.
•Activate “CAPS” on to enter capitalized letters.
•In the Greek language mode, only the
capitalized letters can be entered.
Making corrections
Move the cursor to the character to be corrected.
Enter the correct character to replace the previous
one.
Cursor
The cursor (_) indicates the position for entering a
character. Move the cursor with the cursor keys
( ).
Inserting characters
Each time
INS
is tapped, a space is inserted at
the cursor position to allow character entry.
Deleting characters
Tap
DEL
to delete the character at the cursor
position.
Tap
C•CE
to clear all the characters you have
entered and yet to be stored.
Telephone Mode
Telephone mode is composed of two directions of
storage memory. Tap
TEL
to toggle between “1”
and “2” on the display.
Use these files for convenience, e.g. business
and private files.
A telephone entry consists of name, address,
E-mail address, web address (URL) and number
fields.
Storing telephone entries
1. Tap
TEL
once or
twice to display the
Telephone mode
screen.
2. Enter name, e.g. SMITH
SPACE
ROBERT, and
press
ENTER
.
3. Enter address, e.g. f18
SPACE
fEAST
SPACE
ROAD, and press
ENTER
.
4. Enter E-mail
address, e.g. SROB
SMBL
l
(to enter “
@
”)
SHARPSEC.COM, and press
ENTER
.
•The E-mail address is automatically entered
in lowercase letters.
•To enter “
@
”, simply tap
@
instead of
SMBL
.
5. Enter web address (URL), e.g.
WWW.SHARP USA.COM, and press
ENTER
.
Schedule Mode
Schedule mode is used for storing schedule
details (36 characters or under), date and time
(year, month, day, hour, and minute).
In the 1st line the same characters are allowable
as in Telephone mode.
1. Storing schedule entries
1. Tap to
display the Schedule
mode screen.
2. Enter the details and press
ENTER
.
3. Enter the date and time.
•The types of date and time are the same as
the types set for the clock.
•To enter a single-digit date or time, enter “0”
and the digit (e.g. “O2”).
6. Enter phone
number, and fax
number if needed,
e.g.
012-3456-7890 f
F
SPACE
SPACE
SPACE
f3456-7891,
and press
ENTER
.
•“STORED!” appears briefly, then the Telephone
mode screen is displayed. The telephone entry
is now stored.
Notes
•The symbol “NAME”, “ADDRESS”, “E-mail”, or
“URL” is turned on while entering in each field.
•To skip entry of an address, E-mail address,
web address (URL), or number, press
ENTER
when “ADDRESS?”, “E-MAIL?”, “URL?”, or
“NUMBER?” is displayed. However, entry must
be made at the "NAME?" field.
Allowable
characters
The 1st line:
Name, address,
E-mail address
and web address
(URL)
Field Number of
characters
The 2nd and the
3rd lines:
Phone number
36 characters
or under Alphabetic letters,
numbers, symbols,
“+ – ×÷ .”, space
Numbers, space, –,
F (Fax), P (Pager)
PRINTED IN CHINA/IMPRIMÉ EN CHINE/IMPRESO EN CHINA
05DGK (TINSE0837EHZZ)
ZQ-P10A English Front sheet
OPERATION MANUAL
ELECTRONIC ORGANIZER
ZQ-P10
ZQ-P10A
3. Using World clock
1. Tap
CLOCK
once or twice to display the World
clock (without “ ”).
2. Press >or <to select the desired city.
4. Changing the cities between Home
and World clocks
You can change the home city for a city in another
time zone without adjusting the stored correct
time.
1. Tap
CLOCK
once or twice to display the World
clock (without “ ”).
2. Press >or <and select the desired
city to be set as the new home city.
3. Tap feto change the cities between
Home and World clocks.
•The previous home city is now set as the
world city (without “ ”).
4. Tap
CLOCK
to check the home city.
• The selected city in step 2 is set as the home
city (with “ ”).
5. Tap
CLOCK
to recheck the world city, and
press >or <to select the new world
city, if needed.
5. Setting daylight saving time (DST:
summer time)
1. Tap
CLOCK
once or twice to display the Home
or the World clock.
2. Tap
DST
.
“#” is displayed. The time is set 1 hour ahead.
To clear DST, tap
DST
to clear “#”. The time is
set 1 hour behind.
Notes
•DST can be set independently in either Home or
World clock.
•When DST is set for one world city, it is used
for all cities displayed in World clock.
6. Setting alarms
The Organizer has 3 types of alarms:
1. Daily alarm ........beeps every day at the alarm
time (for 1 minute), when
“” is turned on.
2. Hourly alarm ...... beeps every hour when
minutes reach “00”, when
“” is turned on.
3. Schedule alarm .. beeps at the time for all the
schedule entries (for 1
minute), when “ ” is
turned on. (Refer to
“Schedule Mode”.)
Tap any key to stop the alarm beeping.
Setting/Changing the daily alarm time
1. Tap
CLOCK
once or twice to display Home
clock (with “ ”).
2. Tap to display the
daily alarm screen.
(The display differs
between the 12-hour
and 24-hour clock.)
3. Tap fe.
4. Enter the time.
5. Press
ENTER
.
•The daily alarm time is set.
Turning the alarms on and off
An alarm sounds only when the respective symbol
( , , or ) is turned on.
Display Home clock (tap
CLOCK
once or twice)
and tap to display the daily alarm screen.
Each time you tap while the daily alarm screen
is displayed, the combination of symbols
switches.
Note
•Alarms sound even when the Organizer is
turned off.
ALARM
0–00
CAPS1
NAME ?
E-mail
harpsec . com–
1
CAPS2nd
NUMBER?
2–3456–7890
3456–7891–
1
SCHEDULE?
4. Press
ENTER
to store in the memory.
Notes
•Schedules for the following dates can be stored:
January 1901 to December 2098.
•If an attempt is made to store an entry without a
date or time, or with an invalid date or time,
“ERROR!” appears briefly. Enter the correct
date and time and press
ENTER
.
2. Alarm for Schedule mode
When the schedule alarm (“ ”) is turned on, it
is set for all the schedule entries. Beeping sounds
for 1 minute when the time for a schedule entry is
reached. Tap any key to stop the alarm. The
schedule alarm cannot be set for an individual
entry.
1. Before setting the clock
•The default setting for the date is “DD/MM/
YYYY” (day-month-year). To change the setting
to “MM/DD/YYYY” (month-day-year) or “YYYY/
MM/DD” (year-month-day):
1. Tap
CLOCK
once or twice to display the
Home clock (with “ ”).
2. Tap !, select “DATE SET” by using kor
m, and press x.
3. Press >or <to select the desired
type.
4. Press
ENTER
to store the new setting.
•To change the 24-hour clock to the 12-hour
clock, tap Z(“A” or “P” is displayed). Each
time Zis tapped, the clock switches.
•For daylight saving time/summer time, tap
DST
in advance (“#” is displayed on the left side of
the day of the week).
2. Setting the clock
1. Tap
CLOCK
once or twice to display the Home
clock (with “ ”).
2. Tap feto start setting.
The cursor starts to flash on the city name.
3. Press >or <to select the desired
time zone. (Refer to the list of cities described
below.)
•Enter the city name, if needed (6 characters
or under). Only one changed name for Home
clock can be stored.
4. Tap to move the cursor to the day.
5. Enter the day, the month, and the year (4 digits ).
•The built-in calendar extends from January
1st, 1901, to December 31st, 2098.
•Tap
AM/PM
to select “A” (morning) or “P”
(afternoon) for the 12-hour clock. (in 12-
hour)
6. Enter the time (hours and minutes)
7. Press
ENTER
. The clock starts from “00”
seconds.
Notes
•To enter a single-digit date or time, enter “0”
and the digit (e.g. “02”).
• If you enter an invalid date or time, “ERROR!”
appears briefly. Enter the correct date and time
and press
ENTER
.
Zone Display City Zone Display City
No. No.
0TNG TONGA 10 MOW MOSCOW
1WLG
WELLINGTON 11 CAI CAIRO
2NOU NOUMEA 12 PAR PARIS
3SYD SYDNEY 13 LON LONDON
3.3 ADL ADELAIDE 14 AZ0
AZORES ISLANDS
4TYO TOKYO 15 -2H 2hrs behind LON
5HKG HONG KONG 16 RIO RIO DE JANEIRO
6BKK BANGKOK 17 CCS CARACAS
6.3 RGN YANGON 18 NYC NEW YORK
7DAC DHAKA 19 CHI CHICAGO
7.3 DEL
NEW DELHI 20 DEN DENVER
8KHI KARACHI 21 LAX LOS ANGELES
8.3 KBL KABUL 22 ANC ANCHORAGE
9DXB DUBAI 23 HNL HONOLULU
9.3 THR TEHRAN 24 MID MIDWAY
•SHARP assumes no responsibility, directly or
indirectly, for financial losses or claims from
third persons resulting from the use of this
product and any of its functions, such as stolen
credit card numbers, loss or alteration of stored
data, etc.
•The information provided in this manual is
subject to change without notice.
NOTICE
•SHARP strongly recommends that separate
permanent written records be kept of all
important data. Data may be lost or altered in
virtually any electronic memory product under
certain circumstances. Therefore, SHARP
assumes no responsibility for data lost or
otherwise rendered unusable whether as a
result of improper use, repairs, defects, battery
replacement, use after the specified battery life
has expired, or any other cause.
ON
OFF
PREV
NEXT
RESET switch
(on the back of the unit)
Stylus
Display
Touch Keyboard section
Mode keys
ENTER key
Search keys
• In this manual, these Mode keys are represented with icons in parentheses.
Power ON/OFF key
2nd Function key
Activates the second function specifically assigned to
the next key tapped.
( GAME ): Game mode key
(
TEL ): Telephone mode key
(
MEMO ): Memo mode key
(
CLOCK ):
Home Clock/World Clock mode key
( CALC/CONV ): Calculation/Conversion mode key
( SCHEDULE ): Schedule mode key (
ENTER ): Enter key
Key Assignments
(Key)
(CAPS ON) (CAPS OFF)
R
Z
Y
U
P
ˇ
´
I P
Z
rˇ
lp
ÓÒÖÔÕOØ ó ò ö ô õ o ø
D
S
ˇ
D
E
d’
Ss
ˇ
Sˇ s
I
O
L
G
É È Ë Ê E E˛
L L’
´
Y Ÿ y
´
´
´
´
´´
´´ ´´
ÿ
l
Ú Ù Ü Û U U ú ù ü û u u
Í Ì Ï Î
í ì ï î
é è ë ê
(Key)
(CAPS ON) (CAPS OFF)
ˇee˛
T
N
C
ˇ
ˇ
ˇ
Tt’
CCÇ ´ˇ
ccç
A
ÁÀÄÂÃÅ Æ A áàäâãåaˇæa˛
R
ˇ
Z
°
´´
°
Z´
z
ˇ
zz
ˇ´n n ñ
NÑN
´
ˇ
In Europe:
This equipment complies with the requirements
of Directive 89/336/EEC as amended by 93/68/
EEC.
Dieses Gerät entspricht den Anforderungen der
EG-Richtlinie 89/336/EWG mit Änderung 93/68/
EWG.
Ce matériel répond aux exigences contenues
dans la directive 89/336/CEE modifiée par la
directive 93/68/CEE.
Dit apparaat voldoet aan de eisen van de
richtlijn 89/336/EEG, gewijzigd door 93/68/EEG.
Dette udstyr overholder kravene i direktiv nr.
89/336/EEC med tillægnr. 93/68/EEC
Quest’ apparecchio è conforme ai requisiti della
direttiva 89/336/EEC come emendata dalla
direttiva 93/68/EEC.
Este equipamento obedece às exigências da
directiva 89/336/CEE na sua versão corrigida
pela directiva 93/68/CEE.
Este aparato satisface las exigencias de la
Directiva 89/336/CEE modificada por medio de
la 93/68/CEE.
Denna utrustning uppfyller kraven enligt
riktlinjen 89/336/EEC så som kompletteras av
93/68/EEC.
Dette produktet oppfyller betingelsene i
direktivet 89/336/EEC i endringen 93/68/EEC.
Tämä laite täyttää direktiivin 89/336/EEC
vaatimukset, jota on muutettu direktiivillä 93/
68/EEC.
Memo Mode
Notes or other pieces of information that are not
appropriate for Telephone or Schedule mode can
be entered for convenience.
In the 1st line the same characters are allowable
as in Telephone mode. In the 2nd and the 3rd
lines you can enter numbers, –, and space. (36
characters or under can be entered in each line.)
Storing memo entries
1. Tap to display
the Memo mode
screen.
2. Enter the memo item
and numbers.
E.g. UNION
SPACE
BANK
ENTER
01
272-0011223
3. Press
ENTER
to store in the memory.
CAPS
MEMO?
CAPS2nd
UN I ONBANK
01
272–0011223–
Clock Mode
Home clock
Home city (with “ ”) Day of the week
Time
Date
Daylight saving time
set ( with “#”)
CAPS
LON THU
1– 1–2004
0–00–00
2nd
#
Each time
CLOCK
is tapped, the clock switches
between the Home clock and the World clock
mode. (For World clock, “ ” is not displayed.)
Note
•This model may not be available in some countries.
Attention: Your
product is marked
with this symbol.
It means that used
electrical and
electronic
products should
not be mixed with
general household
waste. There is a
separate collection
system for these
products.
A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do
not use the ordinary dust bin!
Used electrical and electronic equipment must be treated
separately and in accordance with legislation that requires
proper treatment, recovery and recycling of used electrical and
electronic equipment.
Following the implementation by member states, private
households within the EU states may return their used
electrical and electronic equipment to designated collection
facilities free of charge*. In some countries* your local retailer
may also take back your old product free of charge if you
purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or
accumulators, please dispose of these separately beforehand
according to local requirements.
By disposing of this product correctly you will help ensure that
the waste undergoes the necessary treatment, recovery and
recycling and thus prevent potential negative effects on the
environment and human health which could otherwise arise
due to inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local
authorities and ask for the correct method of disposal.
For Switzerland: Used electrical or electronic equipment can
be returned free of charge to the dealer, even if you don’t
purchase a new product. Further collection facilities are listed
on the homepage of www.swico.ch or www.sens.ch.
B. Information on Disposal for Business Users.
1. In the European Union
If the product is used for business purposes and you want to
discard it:
Please contact your SHARP dealer who will inform you about
the take-back of the product. You might be charged for the
costs arising from take-back and recycling. Small products
(and small amounts) might be taken back by your local
collection facilities.
For Spain: Please contact the established collection system or
your local authority for take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local
authorities and ask for the correct method of disposal.
ZQ-P10_En050405.p65 05.4.5, 6:12 PM1

1. Setting a currency rate
1. Tap
CALC/CONV
several times to
display the currency
conversion mode
screen (refer to “Calculator mode”).
Example: 1 CAD (Canada dollars)
= 0.66 USD (US dollars)
2. Press <<<to change the display
and tap fe. The initial character of
“CAD” starts to flash.
•You can change each currency name by
entering characters (up to 4 in each) and
using , if needed.
3. Press
ENTER
. “0” starts to flash.
4. Enter the rate (up to
10 digits).
0.66
5. Press
ENTER
to store in the memory.
2. Converting currency/unit
You need to set the conversion rate before making
the currency conversion.
Example: Convert 500 CAD into USD using the
rate that you have set.
1. Display the screen: “CAD →USD”.
2. Enter the value to be converted.
500
3. Tap to convert
CAD into USD.
•To convert in
reverse order (e.g. 200 USD into CAD), enter
200 and tap .
•You can use the unit conversion in the same
manner. You cannot change the units or the
rates for units.
•The conversion result may have a slight error
as a result of rounding off the number (e.g. up
to 2 decimal places for currency conversions).
Use the conversion result for reference.
Memory Storage
1. Checking memory storage
1. Tap
TEL
,or to display
“NAME?”, “SCHEDULE?”, or “MEMO?”.
2. Tap f!,
select “MEMORY
CHECK” by using k
or m, and press
x. The number of remaining bytes is
displayed briefly.
Notes
•The Organizer can store up to 66838 bytes in
the memory (excluding the Calculator mode
memory).
•One byte is required per character (in the 1st
line) for telephone, schedule, and memo
entries.
•One byte is required for 2 digits in the number
part (in the 2nd and the 3rd lines) of telephone
and memo entries. (When there is an odd
number of digits in a number entry, the last
digit occupies 1 byte.)
•In addition to the memory size for characters
(in the 1st line) and numbers (in the 2nd and
the 3rd lines), each entry requires the following
memory size:
Telephone entry ..... 6 bytes
Schedule entry ....... 8 bytes (including date
and time)
Memo entry ........... 3 bytes
2. Deleting all the memory contents
Perform steps 2 and 3 as described in the section,
“Using the Organizer for the First Time”.
•To cancel the deletion operation, press any key
EXCEPT FOR fxin step 3.
Secret Function
Replacing Battery
Battery used
Type Model Quantity
Lithium battery CR2032 1
• Improper battery replacement may cause
change or loss of the memory contents.
• Be sure to write down any important
information stored in the memory before
replacing the battery.
• Make sure the power is turned off before
replacing the battery.
• Do not press
ON
OFF
until the battery replacement
procedure is completed.
1. Precautions
Since improper use of the battery may cause
leakage or explosion, strictly observe the
following instructions.
•Insert the battery with the positive side (+)
correctly facing up.
•Never throw the battery into a fire because it
might explode.
•Keep the battery out of the reach of children.
Because the battery in the Organizer was installed
at the factory, it may become depleted before the
specified expiration time is reached.
2. Battery replacement
If the display becomes dim and difficult to read,
immediately replace the battery with a new one.
Continued use of the Organizer with an exhausted
battery can alter or clear the memory contents.
•Complete the replacement of the battery within
1 minute, otherwise all the memory contents
may be cleared.
1. Press
ON
OFF
to turn the power off.
2. Loosen the screw and remove the battery
holder cover on the back of the unit.
3. Remove the exhausted battery by prying it out
with a stylus. (Fig. 1)
4. Install a new battery with the positive side (+)
facing up into the battery holder. (Fig. 2)
5. Replace the holder cover and secure it with the
screw.
6. Press
ON
OFF
to turn the power on.
•If nothing appears on the display, press the
RESET switch and tap <.
•Do not tap fand press x. This key
sequence will clear all the memory contents.
7. Set the clock.
Fig. 1 Fig. 2
Specifications
•Model: ZQ-P10/ZQ-P10A6910
•Product name: Electronic Organizer
•Display: 3 lines of 12 digits
•Memory capacity: 96 KB Equivalent∗
•Clock mode:
Accuracy: ± 60 seconds/month at 25°C
Display: Year, month, day, day of the
week, hour, minute, second, AM/PM
Clock function: 12-hour/24-hour format
(switchable), 3 kinds of date type
(switchable), world clock function, daylight
saving time (summer time) display, daily
alarm, hourly alarm
•Telephone mode: Entering and recalling of
telephone entry (name, address, E-mail address,
phone number, and web address (URL))
•Schedule mode: Entering and recalling of
schedule entry (details, year, month, day, hour,
and minute), schedule alarm
•Memo mode: Entering and recalling of memo
entry
•Calculator mode: 10 digits (with calculation
status symbols), arithmetic calculations,
percentage, square root, memory calculation, etc.
•Currency/unit conversion mode:
5 types of currency conversion (editable) and 9
types of unit conversion
•Game mode: 2 games
•Power consumption: 0.003 W
•Operating temperature: 0°C to 40°C
•Power supply: 3V ... (DC), lithium battery
CR2032 ×1
•Auto-power off: Approx. 7 minutes
•Battery life: Approx. 2 years at ambient
temperature of 25°C, assuming the following
daily use: 30 minutes display, alarm sounding
for 20 seconds and key touch tone turned on/
off 100 times.
•Weight (including battery):
Approx. 72 g
•Dimensions:
64 mm (W) ×97 mm (D) ×14.8 mm (H)
•Accessories: 1 lithium battery (installed),
operation manual, stylus
∗Memory at 96KB Equivalent. Approx. 1,500
telephone names & numbers (name, telephone
and fax number are 14 characters per entry)
can be stored by using compression technol-
ogy. (Compression Rate: Approx. 1.5:1)
Currency/Unit Conversion Mode
Caring for Your Organizer
•Do not carry the Organizer in the back pocket of
slacks or trousers.
•Do not drop the Organizer or apply excessive
force to it.
•Do not subject the Organizer to extreme
temperatures.
•Since this product is not waterproof, do not use
it or store it where fluids can splash onto it.
•Clean only with a soft, dry cloth.
•Use only a SHARP approved service facility.
Calculator Mode
The Organizer can
calculate numbers of up
to 10 digits. Tap
CALC/CONV
several
times to display the Calculator mode screen
(Calculator →Currency conversion →Unit
conversion →Calculator...).
Calculation
Be sure to tap
C•CE
,
C•CE
, and
CM
to clear the
display and memory before performing a
calculation.
Note
• When , , , or is tapped, the respective
symbol, +, –, ×, or ÷ is displayed. (In the
examples in this manual, these symbols are not
described.)
If an error occurs
If the calculation result or the integer section in
the numerical value in the memory exceeds 10
digits or if a number is divided by zero (0), an
error occurs (“ERR” is displayed).
Calculation examples
Example Operation Display
(–24+2)÷4=–5.5
C•CE
24 2 4 –5.5
34+57=91 34 57 91.
45+57=102 45 102.
(The addend becomes a
constant.)
68×25=1700 68 25 1700.
68×40=2720 40 2720.
(The multiplicand becomes
a constant.)
200×10%=20 200 10
%
20.
9÷36=25% 9 36
%
25.
200+(200×10%)=220 200 10
%
220.
500–(500×20%)=400 500 20
%
400.
46=(43)2=4096 4 4096.
1/8=0.125 8 0.125
25×5=125
CM
25 5
M+
M
125.
–) 84÷3=28 84 3
M–
M
28.
+) 68+17=85 68 17
M+
M
85.
182
RM
M
182.
25–9=4 25 9
앀앙
4.
1234567890×145 1234567890 145 ERR
=179012344050 17.90123440
C•CE
17.90123440
(17.90123440×10
10
=179012344000)
앀앙앙
Editing or deleting entries – Telephone, Schedule, Memo –
Editing
1. Recall the entry to be edited.
2. Tap
EDIT
. The cursor starts to flash.
•In Telephone mode press
ENTER
several
times to display each field (the address field
and so on).
3. Tap , , , or to move the cursor to the
position to be edited.
4. Enter, insert, or delete characters (refer to
“Entering Characters”).
•To cancel editing, tap
C•CE
.
5. Press
ENTER
several times (until “STORED!”
appears briefly) to finish editing and to store
the entry.
Deleting
1. Recall the entry to be deleted.
2. Tap
DEL
.
•“DELETE?” is displayed.
•To cancel the deletion operation, tap f.
3. Press
ENTER
to delete the entry.
1. Registering a password and storing
secret entries
Up to 6 characters can be registered as the
password.
•One password is valid for Telephone, Schedule,
and Memo modes.
If the password is forgotten, you cannot delete the
password only. You have to delete all the memory
contents. (Perform steps 2 and 3 as described in
the section, “Using the Organizer for the First
Time”.) As a safeguard, make a written record of
the password.
Registering a password
1. Tap
TEL
,or to display
“NAME?”, “SCHEDULE?”, or “MEMO?”.
2. Tap f.
3. Enter the password (case sensitive), e.g. ABC.
4. Tap to register it.
•The display returns to the screen in step 1
with the symbol “ ”.
•If “ERROR!” appears briefly, a password has
already been registered. Enter the correct
password or delete the password and all the
memory contents.
5. Tap fto turn Secret function on.
“” disappears.
Storing secret entries
1. Enter characters in Telephone, Schedule, or
Memo mode when “ ” is not displayed
(Secret function is on).
•When “ ” is displayed, tap to turn
Secret function on.
2. Tap before pressing
ENTER
to store. “ ”
appears.
3. Press
ENTER
to store a secret entry in the
memory.
•“STORED!” appears briefly, and the display
returns to the mode screen without “ ”
(Secret function is on).
•You cannot display the secret entry until you
turn Secret function off.
2. Turning Secret function on and off
When Secret function is on, “ ” is not
displayed.
•You can display, edit, or delete entries
except secret entries.
•You can enter new entries as secret or
non-secret.
When Secret function is off, “ ” is
displayed.
•You can display, edit, or delete secret
entries only. (You cannot display non-
secret entries.)
•You cannot enter a new entry.
Turning Secret function off
1. Tap
TEL
,or and check that
“” is not displayed.
2. Tap f. “PASSWORD?” is displayed.
3. Enter the password and tap .
•“ ” is displayed and you can display
secret entries.
•If you enter an incorrect password,
“ERROR!” appears briefly. Follow the above
steps and enter the correct password.
• Even when Secret function is turned off, it
will be automatically turned on (“ ” will
disappear):
A)when
GAME
,
CLOCK
, or
CALC/CONV
is tapped,
or B)after the power is turned off manually
or automatically.
Turning Secret function on
1. Tap
TEL
,or and check that
“” is displayed.
2. Tap f.
The password is displayed. Memorize it again.
3. Tap again.
“” disappears and you cannot display
secret entries.
3. Changing the password
1. Turn Secret function off (“ ” appears).
2. Tap f. The password is displayed.
3. Tap f
EDIT
.
The initial character of the password starts to
flash.
4. Enter, or edit characters and make a new
password.
5. Tap . The new password is now registered.
ZQ-P10A English Rear sheet
2nd
0.
CAPS2nd
CAD USD
6
–
–
0.6
CAPS2nd
CAD USD
0.
–
–
33
Game Mode
Tap
GAME
to play the game “BLACKJACK”.
Each time
GAME
is tapped, the display switches
between “ALPHA ATTACK” and “BLACKJACK”.
BLACKJACK (Twenty-one)
Make your “hand” (the total of the numbers on
the cards) as close to 21, without going over 21.
1. Tap
GAME
to
display the following
Game mode screen.
2. Press
ENTER
to start a game. The left 2 cards
are dealt for you. (One card is faced up and the
other is faced down.)
3. Agree the left-displayed maximum bet (up to
10) or enter fewer bet. Tapping also can bet
to the maximum.
4. Tap
SPACE
to
see your hand.
Each time
SPACE
is
tapped, a new card
is dealt.
•“J”, “Q”, and “K”
are counted as 10.
•“A” can be counted as 1 or 11.
•When the first 2 cards are “A” and a face
card (“J”, “Q”, or “K”), your hand is
“BLACKJACK”.
5. Press
ENTER
to
stop being dealt
and hold your
hand. The dealer’s
hand and the
results are
displayed.
•When you win, your total flashes and your
bet is doubled.
• When you win with “BLACKJACK”, your bet
is tripled.
CAPS2nd
J28 32K4
20 19
20 20
Your chips
Your bet
The dealer’s
total
Your total
CAPS
FREE %
99
CAPS2nd
PASS W ORD ?
CAPS2nd
EURO USD
0.
–
–
CAPS2nd
J28 4
10 20
Your chipsYour bet
The dealer’s
hand
Your hand
0 1234567890 1234567890
6. Press
ENTER
and display the Game mode
screen.
•When you have no more chips to bet, the
game is over.
•To quit the game, tap
C•CE
or any mode
key. Your chips are stored for the next time.
•To return your chips to 30, tap f
DEL
and
press
ENTER
on the Game mode screen.
ALPHA ATTACK
Type in characters (A to
Z) displayed on the 1st
line to clear them. 20
levels of speed are
available.
1. Tap
GAME
to display the following Game
mode screen.
2. Enter the level
number (2 digits
from 01 to 20).
•01: slow, 20: fast
3. Press
ENTER
to start a game.
4. Tap the same key as the first character at the
left end of the 1st line. (In this case, tap keys in
the order: E →Y →K →W.)
•Pressing the correct key in the correct order
deletes the character.
•When 12 characters are displayed in each
level, the game continues in the faster level
(up to 20).
•When no more characters can be displayed,
the game is over. The Game mode screen
with the level when the game is over is
displayed.
CAPS2nd
ALPHA AT TACK
01
Level
CAPS
EYK W
01
CAPS2nd
BLACKJACK
30
Your chips
SHARP CORPORATION
Notes for storing and recalling entries
•When the memory is full, “MEMORY FULL!”
appears briefly, and the entry cannot be stored.
•When the symbol “ ” or “ ” appears, more
information exists. Tap or to switch the
display.
Checking details of entries in Telephone mode
•To display each field on the 1st line, follow the
symbol “ ” or “ ” and tap or . (The
symbol above the 1st line shows each field.)
•Tap and hold to start the auto scroll on the
1st line. Tap again to stop or restart the
scroll. Tap
C•CE
to quit the auto scroll.
Recalling entries – Telephone, Schedule, Memo –
Tap the desired mode key first.
<: Recalls entries in forward order
>: Recalls entries in reverse order
Sequential search
Press <or >in each mode.
Sorting order
•Telephone and memo entries are stored by the
first character of the person's name or memo
item in the following order (case sensitive):
•"Ch" and "ch" are available in Czech language
mode only.
•Schedule entries are stored by date and time.
Note
•When there is no (further or relevant) entry to
be recalled, "NOT FOUND!" appears briefly, and
the display returns to the mode screen.
•Greek characters are sorted as follows:
Direct search
•Enter the first characters (8 characters or
under) of the person’s name, schedule details,
or memo item, and press <or >.
Press <or >then, to continue
performing a direct search.
ZQ-P10_En050405.p65 05.4.5, 6:12 PM2
