The AX-1200K SuperSteam™ Oven can be built into a wall cabinet.
It coordinates beautifully when installed above Sharp’s 30-inch Microwave Drawer® appliance.
AX-1200K, AX-1200S
SuperSteam™Ovens
The Combination of Technologies in the SuperSteam™Oven
Makes It Easy to Cook Healthy
Today, more and more people aspire to a healthy lifestyle, a lifestyle that includes healthy eating—and healthy food preparation.
Enter the Sharp SuperSteam Oven. This new multi-purpose oven incorporates the healthiest ways to cook: superheated steam,
convection, steam and microwave. It is programmed to know which cooking method is best for the food selected, using the menu-
driven controls.
Versatile
• TheSuperSteamOvenoffersauniquecombinationofthehealthiest
ways to cook all in one oven: SuperSteam, Convection, Steam and
Microwave. It cooks a wide variety of foods without compromising
taste or appearance. SuperSteam technology actually browns and
crisps foods while retaining moisture and natural flavors. Meats,
poultry, fish and seafood are exceptionally moist and tender.
• Microwaveoptionprovidesspeedandconvenience.
• LCDdisplayandautomaticsettingsassureexcellentresults.
• BalancedMealssettingautomaticallycookscompletemealsin25minutes.
• It’stheperfectsecondovenorsecondmicrowave.
Healthy
• Foodsthataregoodforyouwilllookandtastebetterthanyouever
expected.
• It’snotjustwhatyoucook,it’showyoucookit.Nowyoucanget
moist, flavorful results without the addition of fats and oils.
• No other oven cooks in so many healthy ways, giving you more
control over what you eat and how you cook it. It can help change
the way you eat by changing the way you cook.
• SuperSteam Cookbook includes healthy recipes, cooking tips and
nutritional information to encourage healthier cooking and eating.
Steam is Hot
• Consumerswantfoodsthatarefreshandavorful.Theyknowthat
steam is a natural, gentle cooking method, preserving nutrients and
taste.NowSharpoffersthe benetsofsteamcookingalongwith
superheated steam that browns and crisps.
• Steam is being used in many applications:  cooking appliances,
washers and dryers, dishwashers, microwave frozen foods and
steaming bags for microwave cooking.
Flexible Placement
• Buildintoa30-inchwallovencabinetwithSharp’sdeluxebuilt-inkit.
• Built-indesigncoordinateswithotherSharpInsight®andInsight
Pro® appliances.  To create a unique cooking center, build the
Sharp SuperSteam Oven above a Sharp Microwave Drawer or
WarmingDrawer.
• Placeonthecountertoporcartifbuilt-insarenotanoption.
Consumer Trends
• The SuperSteam Oven is ideal for empty nesters, retiring baby
boomers and smaller households, some of the fastest growing
consumer segments.
• Smallermealsarebeingcookedathome.Familiesofteneatdifferent
foods, even when they dine together, fueling the need for smaller,
specialized cooking appliances.
• The“WellnessConsumer”wantstoeathealthier,tobemorephysically
active and to take action to lower health risks. What better target for
the Sharp SuperSteam Oven?

Specications AX-1200K, AX-1200S
Display Dot Matrix LCD display with visual prompts
Control Panel Right side
Controls Easy to use dial for food selection
Cooking System SuperSteam Convection, Convection, Steam, Microwave
Convection Mode 100°- 450°F temperature range, two level baking
Oven Capacity 1.1 cu. ft.
Microwave Output Wattage 700W
Microwave Distribution System Antenna system, bottom feed
Microwave Sensor Cook® Yes
Automatic Cooking Categories
SuperSteam/Convection
Steam
Microwave
Balanced Meals, Poultry, Meats, Fish, Vegetables, Pizza, Convenience Foods
Vegetables, Fish/Seafood, Poached Eggs
6 Sensor Cook® Settings, Reheat, Popcorn
Reheating Options Microwave Sensor or Manual Steam
Defrosting Options Automatic Microwave Defrost
Manual Cooking SuperSteam Convection, Convection, Steam, Microwave, Reheat,
Defrost, Proof
Cleaning Steam Clean Cycle
Door Opening Pull down door for exible placement
Interior Oven Light Yes
Color AX-1200K: Black
AX-1200S: Stainless and black
Handle Curved open handle
Accessories (included)
2 porcelain enamel baking trays
2 racks with non-stick nish: high and low
1 steam basket
SuperSteam Cookbook,Touch Guide
Built-in Kit KB-12S30 (Optional at extra cost)
Cavity Dimensions 141/8”W x 101/8”H x 133/8”D
Outside Dimensions 213/4”W x 171/4”H x 183/8”D (201/4”D including handle)
Outside Dimensions with Built-in Kit 30”W x 191/2”H
Approximate Weight Net: 51 lbs. / Shipping: 64 lbs.
AC Line Voltage 120V, 60Hz, AC only
AC Power Required Microwave: 1.04 kW, 9.0 A / Convection: 1.50 kW, 12.5 A
Power System Inverter
Safety Compliance
FCC, DHHS, UL listed
This SuperSteam Oven can be installed above
any electric wall oven, warming drawer or
Sharp Microwave Drawer models KB-6002, 6015 or 6025.
UPC Codes AX-1200K: 074000617650 AX-1200S: 074000617667
RK-12S30 Built-in Kit: 074000617674
Warranty (tentative)
1 year parts and 1 year labor with carry-in service. The warranty
continues for an additional 4 years, for a total of 5 years, on the
magnetron tube for parts only. If this model is built-in using the
designated Sharp Built-in Kit, in-home service is proved for the
initial one-year warranty period.
To receive the most current specifications visit www.dexpress.com or call Dimension Express at
925-284-3558 from a fax machine. Enter code 9026 for instructions and a directory of Sharp
microwave oven products.
For information including limited warranty, complete dimensions, installation instructions
and tips, please visit www.sharpusa.com/microwavedrawer.
Design and specications subject to change without notice.
Sharp, Insight, Insight Pro, Microwave Drawer, Sensor Cook, SuperSteam and all other
related trademarks are trademarks or registered trademarks of Sharp Corporation
and/or its related entities.
All other trademarks are property of their respective owners.
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, NJ 07495-1163
1-866-RANGE99 • www.sharpusa.com
© 2008 Sharp Electronics Corporation. All rights reserved. Printed in the U.S.A. 12-17-08 MA-02-120
HA-07F-006
AX-1200K SuperSteam Oven
is designed to coordinate with RK-12S30 Built-in Kit.
AX-1200K SuperSteam Oven
with RK-12S30 Built-in Kit
AX-1200S SuperSteam Oven
can be used on the countertop or as a built-in.
AX-1200K, AX-1200S
SuperSteam™Ovens
