SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
SERVICE MANUAL
S15A1SE55APRF
SHARP CORPORATION
SJ-48G-GY/BE/BL
SJ-D48G-GY/BE/BL
SJ-51G-GY/BE/BL
SJ-D51G-GY/BE/BL
SJ-55G-GY/BE/BL
SJ-D55G-GY/BE/BL
REFRIGERATOR-FREEZER
MODELS
TABLE OF CONTENTS
page
OUTLINE OF PRODUCT.......................................................................................................................................2
SPECIFICATIONS .................................................................................................................................................3
DESIGNATION OF VARIOUS PARTS ..................................................................................................................4
LIST OF ELECTRICAL PARTS .............................................................................................................................5
WIRING DIAGRAM................................................................................................................................................6
FUNCTIONS ..........................................................................................................................................................8
ASSEMBLING PROCEDURES OF MAIN PARTS AND CAUTIONS ..................................................................11
COOLING UNIT ...................................................................................................................................................17
REPLACEMENT PARTS LIST ............................................................................................................................18
Refrigerant; HFC-134a
Refer to "HFC-134a COOLING UNIT" Service Manual for handling this refrigerant.
DESTINATION ............................. F
Inthe interestsofuser-safety (Requiredbysafety regulationsin some
countries) the set should be restored to its original condition and only
parts identical to those specified should be used.

2
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
OUTLINE OF PRODUCT
Comparison between Type G and Type E
G type E type
Cooling Unit
Refrigerant CFC-12
Outer dimensions
(Height~ Width~ Depth)
Heat insulator
48G@ 1620~ 735~ 700(mm)
D48G (63.8"~ 28.9"~ 27.6")
51G@ 1700~ 735~ 700(mm)
D51G (66.9"~ 28.9"~ 27.6")
55G@ 1820~ 735~ 700(mm)
D55G (71.7"~ 28.9"~ 27.6")
42E@ 1620~ 715~ 690(mm)
D42E (63.8"~ 28.1"~ 27.2")
45E@ 1735~ 715~ 690(mm)
D45E (68.3"~ 28.1"~ 27.2")
50E@ 1825~ 715~ 690(mm)
D50E (71.9"~ 28.1"~ 27.2")
Rated storage volume 48G@ 443 liter(15.6cu.ft.)
D48G F:139(4.9) R:304(10.7)
51G@ 473 liter(16.7cu.ft.)
D51G F:139(4.9) R:334(11.8)
55G@ 521 liter(18.4cu.ft.)
D55G F:139(4.9) R:382(13.5)
42E@ 400 liter(14.2cu.ft.)
D42E F:98(3.5) R:302(10.7)
45E@ 430 liter(15.2cu.ft.)
D45E F:128(4.5) R:302(10.7)
50E@ 470 liter(16.6cu.ft.)
D50E F:162(5.7) R:308(10.9)
Specifications of interior
Fresh case 2
Chilled case 0
Three position
adjustable shelf 0
Conforms to the Regulations for Specific CFCs that will take effect in 1996.
HFC-134a
Polyurethane foam that uses
CFC-11
Polyurethane foam that uses
cyclopentane
0
1
1

3
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
Items SJ-48G SJ-D48G SJ-51G SJ-D51G SJ-55G SJ-D55G
Type 2-Door 2-Door 2-Door
Outer dimensions Height 1620mm(63.8") 1700mm(66.9") 1820mm(71.7")
(Including spacer) Width 735mm(28.9") 735mm(28.9") 735mm(28.9")
Depth 700mm(27.6") 700mm(27.6") 700mm(27.6")
Rated storage volume 443 liter(15.6 cu.ft) 473 liter(16.7 cu.ft) 521 liter(18.4 cu.ft)
F: 139 liter(4.9 cu.ft) F: 139 liter(4.9 cu.ft) F: 139 liter(4.9 cu.ft)
R: 304 liter(10.7 cu.ft) R: 334 liter(11.8 cu.ft) R: 382 liter (13.5 cu.ft)
Defrosting System Heater system
Start Automatic
Finish Automatic
Temperature control Automatic (Adjustable)
No-frost freezer Yes
Interior lamp 1
Caster 4
Evaporating pan 1
Refrigerator Refrigerator shelf 1 2 3
Compartment Glass shelf 1
Fruit and Vegetable crisper 1
Egg pocket 1
Egg holder 2
Bottle pocket 1 2
Free pocket 1 2
Chilled case 1
Freezer Freezer shelf L 1
Compartment Freezer shelf S 1
Ice cube maker Twin ice cube maker
Ice cube box 1
Deodorizing system No Yes No Yes No Yes
SOURCE AND COMP. AND NET WEIGHT
Items SJ-48G-GY/BE/BL SJ-51G-GY/BE/BL SJ-55G-GY/BE/BL
SJ-D48G-GY/BE/BL SJ-D51G-GY/BE/BL SJ-D55G-GY/BE/BL
Rated voltage (V) 110
Rated frequency (Hz) 60
Climate class ST
Rated input of motor (W) 170 175 180
Rated input of defrosting heater (W) 137
Refrigerant (Charging quantity) HFC-134a(120g) HFC-134a(125g)
Net Weight (kg) 79 84 88
Power comsumption (kWh/month) 81 86 89
Energy factory (L/kWh/month) 6.8 6.7 7.0
COLOR
Items SJ-48G-GY, SJ-51G-GY, SJ-55G-GY SJ-48G-BE, SJ-51G-BE, SJ-55G-BE SJ-48G-BL, SJ-51G-BL, SJ-55G-BL
SJ-D48G-GY, SJ-D51G-GY, SJ-D55G-GY SJ-D48G-BE, SJ-D51G-BE, SJ-D55G-BE SJ-D48G-BL, SJ-D51G-BL, SJ-D55G-BL
Outside color Gray Beige Blue
Inside color White White White
SPECIFICATIONS

4
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G DESIGNATION OFVARIOUS PARTS
Figure D-2. Constructions
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
17
18
19
20
21
22
23
19
14
The names in parenthesis are the denominations
used in the REPLACEMENT PARTS LIST.
1. Freezer shelf (L) (Freezer tray L silk)
2. Freezer temp. control knob
3. Freezer shelf (S) (Freezer tray S silk)
4. Ice cube maker
5. Ice cube box (Ice storage box)
6. Chilled case
7. Light (Lamp)
8. Refrigerator temp. control knob
9. Refrigerator shelf(Ref. tray silk)
(SJ-48G/D48G type 1, SJ-51G/D51G type 2, SJ-55G/D55G type 3)
10. Threeposition adjustableshelf(Free setshelf)
11. Glass shelf
12. Fruit and Vegetable crisper (Vegetable case)
13. Evaporating pan & Cover
14. Caster
15. Adjustable feet (Adjustable leg)
16. Fan switch
17. Fan & light switch
18. Freezer pocket (F door pocket HS)
19. Magnetic door seal (Door packing)
20. Egg holder (Egg tray)
21. Egg pocket (Egg pocket HS)
22. Free pocket (Utility pocket)
(SJ-48G type 1, SJ-51G type 1, SJ-55G type 2)
23. Bottle pocket (Bottle pocket HS)
Figure D-1. External Description
Upper hinge cover
Hot pipe
Freezer temp. control knob
Hot pipe
Evaporating pan cover
(Ventilating grille)
Evaporating pan
Adjustable feet
(Adjustable leg)
Fan motor
Propeller fan
Defrost thermostat
Evaporator
Defrost heater
Damper thermostat
Refrigerator temp. control knob
Drain pipe
Vegetable case
Compressor
Starting relay, Overload relay(Protector)
Caster
Sub condenser
Freezer
compartment
Refrigerator
compartment
Mark: Cold air flow
Timer
The figure shows SJ-51G.

5
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
LIST OF ELECTRICAL PARTS
Items SJ-48G, SJ-D48G, SJ-51G, SJ-D51G, SJ-55G, SJ-D55G
Source 110V 60Hz
Climate class ST
Thermostat Type: MM1-8025 ON: –17±5˚C OFF: –22±1.5˚C(at normal notch)
Damper thermostat Type: MM1-6129
Baffle opened 1.5˚C(at normal notch)
Baffle closed –3±1.5˚C
Timer Type: TMDFX04FB2, Integration type
Cycle 10hours 50 min., Working time about 4min. 20sec.
Fuse ass'y Thermo. fuse Type: SF70E 250V 10A Working temp. 70±2˚C
or MTG4A50072 250V 10A Working temp. 72±2˚C
Defrost thermostat Type: US602S 250V 8A OPEN 10±3˚C CLOSE 1±3˚C
Door switch 3 terminals push-button 250V 0.25A
Lamp socket 250V 1A E-12(HARD PLASTIC BODY TYPE)
Lamp 110V 10W E-12
Fan motor Type: MH15SXF-BJA7 100/110V 50/60Hz
Compressor Type: GL-90BK
60Hz(OIL COOLING)
Output 225W
Main coil 1.40Ω
Aux. coil 3.535Ω(at 20˚C)
Terminal
Starting relay UH-3012 or UH-3002 4.7Ω 180V
Overload relay (Protector) 4TM783NFBZZ-51 or 53 OFF 120˚C ON 61˚C
Running capacitor 20µF/180V
Defrost heater 115V 150W
Aux. coil
Common
Main coil

6
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G WIRING DIAGRAM
Be sure to replace the electrical parts with specified ones for maintaining the safety and performance of the set.
Because these are important for maintaining the safety of the set.
Figure W-1. Wiring Diagram
THERMOSTAT TIMER
(R) (G)
(Bk)
THERMO.
FUSE OVERLOAD
RELAY
DEFROST
HEATER
STARTING
RELAY
(P) (W)
INTERIOR
LIGHT
FAN
MOTOR
(S-B) (O)
DOOR SWITCH
DEFROST
THERMOSTAT
(Bk)
C
M
A
N
2PIN
PLUG/
CORD
(B)
COMPRESSOR
LFM
TM
(Br)
RUNNING CAPACITOR
CONNECTED IN TERMINAL BOX
CONNECTOR
G
Br
O
Y
R
P
B
Bk
S-B
W
: GRAY
: BROWN
: ORANGE
: YELLOW
: RED
: PINK
: BLUE
: BLACK
: SKY-BLUE
: WHITE

7
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
Figure W-2. Electric Accessories Layout
Fan motor
C1(LR-09-1V)
Defrost thermo.
F-thermostat
Thermo fuse
Defrost heater
Door switch
FREEZER
REFRIGERATOR
(R-Cbox ass'y)
(C-Part. ass'y)
(E.V cover ass'y)
MACHINE ROOM
Defrost timer
Lamp
C2(ELR-02V)
C3(ELR-06V)
C4(LR-09-1V)
3(Push close)
4(Push open)
(O)
Source cord
Overload
relay
Terminal cover
Starting relay
Compressor
CE-2 CE-5 CE-2
(G)
G
Br
O
Y
R
P
B
Bk
S-B
G-Y
: GRAY
: BROWN
: ORANGE
: YELLOW
: RED
: PINK
: BLUE
: BLACK
: SKY-BLUE
: GREEN-YELLOW
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
1
21 2
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
FM
3
1
4
1
L
3
2
4
1
TM
C
MA
1
L
N
E
(G)
(P) (B)
(Br) (R)
(Bk) (W)
(W) (Y)
(O) (B)
(S-B)
(R) (Bk)
(G) (Y)
(S-B)
(P)
(Br)
Running capacitor

8
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
1. ADJUSTABLE TEMPERATURE CONTROL
(1) Temperature control of freezer
Thermostat(freezertemperaturesensingthermostat)operatesonON/OFFswitchovertocontrolthecompressor
and allows the freezer temperature to keep at a suitable temperature.
However adjust the freezer temp. control knob as follows depending upon the storing condition of foods.
FUNCTIONS
Thevalues tables above referto themeasurement carriedout centerarea and1/3 ofoverall heightfrom thebottom ateach
of the refrigerator and the freezer after machine has been operated at an ambient temperature of 30˚C with no food stored
and the door closed until the temperature is stabilized.
The values vary depending upon frequency of opening and closing the door, ambient temperature, amount of stored foods
and manner of storing foods.
Figure F-1.
(2) Temperature control of refrigerator
Damper-thermostat senses temperature of the refrigerator and changes the opening angle of the damper
automatically.
However, as the Damper-thermostat has no function to switch on or off the compressor and cool air circulating
fan, the freezer temperature control causes temperature in the refrigerator to vary to some extent.
However, adjust the refrigerator temp. control knob as follows depending upon the cooling condition.
Figure F-2.
NOTE: The refrigerator temperature is affected also by the freezer temperature. If the freezer temp. control
knobis set attheposition "MAX", the temperaturetendsto be lower thanthefollowing values, andif set
at near the position "MIN", temperature tends to be higher.
If the refrigerator is operated for a long time with the freezer temperature control sets the "MAX"
position, foods stored in the refrigerator compartment may also freeze.
When refrigerator temperature control sets to the "CHILLED ZONE", some foods stored may freeze.
In this case adjust control set back to the "MED" position.
When refrigerator temperature control sets to the "CHILLED ZONE", some foods stored in fresh cases
may also become frozen.
(3) Reference value of temperature
MIN
MED
MAX
FREEZER TEMP. CONTROL
Coldest
Coldest
MIN
MED
CHILLED
ZONE
REFRIGERATOR TEMP. CONTROL
SETTING OF
REFRIGERATOR TEMP.
CONTROL KNOB
Refrigerator
temperature
Chilled room
temperature
CHILLED
ZONE
(Coldest) MED MIN
Approx.
0˚c
Approx.
-3˚c
Approx.
3˚c
Approx.
1˚c
Approx.
6˚c
Approx.
4˚c
The values shown above refer to the case where the
freezer temp. control knob is set at "MED".
SETTING OF
FREEZER TEMP.
CONTROL KNOB
Freezer
temperature
MAX
(Coldest) MED MIN
Approx.
-21˚C Approx. -18˚C Approx. -15˚C
KNOB
SETTING
MAX (Coldest)
MIN
PURPOSE
For making ice rapidly or fast freezing.
For storing frozen food for a short period (up to one month).
When frozen food or ice cream is not stored.
For normal freezing.
MED When restocking with fresh food.
KNOB
SETTING
MED
CHILLED
ZONE
(Coldest)
MIN
PURPOSE
For keeping freshness of food longer.
For normal operation.
When the refrigerator provides excessive cooling.
When the refrigerator does not provide sufficient cooling.

9
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
2. DEFROSTING
(1) No defrosting operation is necessary
No defrosting operation is necessary.
As this machine is so designed that a built-in
evaporator cools air and a fan circulates cooled air,
neither the freezer nor the refrigerator is frosted,
though the evaporator is frosted.
The frosted evaporator is defrosted automatically
due to the function of defrosting timer and heater,
requiring no defrosting operation.
(2) Where is melted ice brought
1. Meltediceis brought intotheevaporatingpanat
the bottom of the set and is evaporated here by
the heat of sub condenser.
2. Be sure to use the evaporating pan as inserted
so as to be level with the outer case.
(3) The following circuit diagrams in the table show automatic defrosting function of the refrigerator with
timer and defrost thermostat.
Operation Electric diagram Description
1. Cooling
(Normal)
2. Defrosting
(Time 20 to 30 min.)
3. Drain
(Time approx. 5 min.)
4. Cooling (start)
(Time approx. 5 min.)
The integration timer integrates running
time of the compressor. When it reaches
10 hours 50 min. at 50Hz, the timer contact
is changed to start defrosting.
When the defrost thermostat becomes
OFF, the timer motor at rest starts running.
During the operation time(4 min. 20 sec.
/50Hz) defrosted water is drained outside
the refrigerator.
Timer contact is changed to cooling operation
and the compressor starts running and
the timer motor stops.
Defrost thermostat contact becomes ON
when it's cooled. (FIgure F-3.)
Figure F-3.
Figure F-4 .
Figure F-5.
Figure F-6.
TM COMP
Defrost thermostat ON Compressor running
Timer motor running
Timer contact
Defrost
thermostat (ON)
Defrost heater
Thermo. fuse
Compressor
Timer motor
SOURCE
TM COMP
Defrost thermostat OFF Compressor running
Timer motor stops
Thermostat Timer contact
Defrost
thermostat (OFF)
Defrost heater
Thermo. fuse
Compressor
Timer motor
SOURCE
TM COMP
Defrost thermostat OFF Compressor stops
Timer motor running
Thermostat Timer contact
Defrost
thermostat (OFF)
Defrost heater
Thermo. fuse
Compressor
Timer motor
SOURCE
TM COMP
Defrost thermostat ON Compressor stops
Timer motor stops
Thermostat Timer contact
Defrost
thermostat (ON)
Defrost heater
Thermo. fuse
Compressor
Timer motor
SOURCE
Thermostat
The timer contact is changed to start
defrosting, the timer motor stops, and
power is supplied to the defrost heater.
It takes about 20 to 30 min. to defrost.
When little frosted the defrosting takes
little time.When much frosted, the
defrosting takes much time.

10
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(4) As a reference to determine the causes of trouble, malfunction and phenomena are described below. Refer
to the following when repairing.
1. Disconnection of defrost heater
Asoff-cycledefrostingisperformed,thedefrostingtimeisextremelyprolonged.Eachtimedefrostingisstarted,
the freezer temperature rises and a portion of ice and stored foods are melted.
2. Melted thermo. fuse or opened-circuit due to the defect of defrost thermostat.
Whentheabove mentioned trouble occursin cooling operation,the timer motordoes notrun, defrosting willnot
take place, and consequently freezing is caused. In the above mentioned condition, when the timer shaft is
turned by hand to defrost, the timer motor runs during the operation time. However, the motor stops from the
time when the contact is changed, and freezing causes.
NOTE:
As the thermo. fuse assembly is intended to prevent dangers, do not use it under shorted condition even for a
short period.
3. DEW PREVENTION
The hot pipe, namely D.P.-condenser, is arranged around the flange part of
cabinet and the C-partition plate, preventing dew from being generated on the
cabinet.
NOTE:
D.P.-condenserpipemaybefelthotiftouchedbyhandwhilethecompressor
is in operation.
Ifyou are asked aboutthis, pleaseexplain thatthe hotpipe serveto prevent
the dew generation.
Figure F-7.
4. INSPECTION OF INITIAL STARTING
Hot pipe
(1) Inspection of cooling unit
1. Set the temperature control knob to "MAX" and check that the compressor starts to operate.
2. Depressthedoor switch to runthefanandcheckthatcool air isblownoutofthecoldair outlet ofthefreezerand
the refrigerator.
3. When the compressor does not work, check that the timer is not set to "defrost" position.
4 It takes about an hour and a half or two hours to put food in the refrigerator after starting operation.
NOTE:
After return the temperature control knob to "MED" position.
When the refrigerator is operated initially after installed, the compressor may vibrate excessively for 1 to 2 min.
However, vibration becomes normal if it is continuously operated.
(2) Inspection of defrost device
Operate the refrigerator for 20 to 30 min. and then check the defrost device in the following procedures :
Allow 5 min. to restart the compressor since immediate starting after stopping will cause unsmooth operation.
1. Turn the timer shaft clockwise with a screw driver.
At this time, make certains the timer clinks and the compressor stops.
2. After more than 5 min., turn the shaft further to operate.
Make certain cooling operation is started again.
NOTE:
It's not necessary to switch the timer by changing of source frequency (50Hz, 60Hz).

11
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
ASSEMBLING PROCEDURES OF MAIN PARTS AND CAUTIONS
CAUTION: DISCONNECT THE UNIT FROM THE POWER SUPPLY BEFORE ANY REPAIRING.
1. R-CONTROL COV. ASSEMBLY
(1) Sticking of sealer
Lamp socket
Lamp
Warning label
R-temp. control knob R-Cbox cover
Defrost timer D timer lead ass'y
R-air guider A
RA-insulation
Damper
thermostat
A-sealer thermo. cap
Dial sealer
C-box base
Thermo. cap sealer
R-air guider B
A-sealer air guider B
A-sealer
RC-box
A-sealer
RC-duct
A-sealer air guider C
A-sealer air guider D
A-sealer air guider D
R-air guider A
A-sealer
thermo. cap
Dial
sealer
Start
Finish
datum
(all round)
RA-insulation
R-air guider A
R-air guider A
AA
SEC. AA
Insert RA-insulation
R-air guider A
A- sealer air guider C
Start
A-sealer
air guider B
Overlap
R-air guider B
R-air guider B
A-sealer
air guider D

12
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(2) Forming sensor of Damper thermostat
(3) Setting of C-box base, Damper thermostat, R-air guider A and R-air guider B
R-air guider A
Bend the senser
tube of Damper thermostat
Stick thermo.
cap. sealer
Less than 130
Damper
thermostat
3
±1
5
±1
Less than 12
25
±2
NOTE
Minimum bending radius is R5.
There should be no gas leak by reforming of sensor tube.
Paper tape (40 x 100)
Start
A-sealer RC-duct
Overlap
BB
Overlap
C-box
base
A-sealer
RC-box
Start
datum
A-sealer
RC-duct
datum
A-sealer
RC-box
SEC. BB
C-box base
Damper thermostat C-box base R-air guider B
Screw
Fix with claw
A-sealer air guider D

13
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(4) Fixing of Lamp socket, Defrost timer
(5) Fixing of R-Cbox cover
R-C box cover
Claws (2 places)
Claws (2 places)
Set R-temp. control knob
Lamp
socket
Lamp
R-C box cover
Connect
D timer
lead ass'y
Screw
SKY-BLUE
insert Pin No.6
BROWN
Insert Pin No.7
Defrost timer
6
7
2±1
4±1
Stick Warning label
¿ • 10W
¨ª A

14
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(1) Sticking of sealer to E.V cover
2. E.V COVER ASSEMBLY
E.V cover
E.V cover sealer AE.V cover sealer B
Overlap 10mm(min.)
E.V cover sealer E E.V cover
A
[Front View]
E.V cover Along this edge
[View from A direction]
Fix E.V cover sealer E along the edge of E.V cover.
Fuse ass'y
Alminum tape
E.V cover sealer A
Fan motor
Motor cushion
Fan motor cushion B
Fan motor cushion A
Propeller fan 100
Fan clamp
E.V cover sealer D
E.V cover sealer C
E.V cover sealer B
Lead E.V cover ass'y.
F-thermostat
E.V cover sealer E
E.V cover
L-band C
Defrost thermo. ass'y
L-band C

15
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(2) Fixing of Fan motor and Fan
E.V cover
Motor cushion Tapping screw
Fan motor cushion B
Fan motor
Fan motor cushion A
Fan clamp
Propeller fan 100 Fan motor
Motor shaft to be flush
with front surface of hub.
(3) Wiring of Lead Wire
Lead wire “WHITE”
Fuse ass'y
Alminum tape
E.V cover
sealer D
DetailA
Bend this pin
DetailB
Fan motor cushion
Lead wires
DetailC
Set Lead wires of Defrost thermo. ass'y as shown.
B C
D
A
L-band C
Defrost
thermo. ass'y
L-band C
Fuse ass'y
Alminum tape
E.V cover sealer D
B
Cut off to
7mm or shorter
7mm
Thermo. sensing element side
(Silver metal)
Horizontally
DetailD
Fasten Defrost thermo. ass'y's
wires as bellow.
And set it inside of the four pins.

16
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
(4) Setting of Lead E.V cover ass'y and F-thermostat
Set surely edges of
these two ribs.
Color: RED Color: BROWN
Under 5mm
10mm over
Standard line
(5) Wiring of Connector
E.V cover
E.V cover sealer C
E.V cover
F-thermostat
Lead E.V cover
ass'y
Through between ribs
Inside of ribs
987
654
321
View from A
A
1. Lead E.V cover ass'y
2. Lead E.V cover ass'y
3. Pink lead of Defrost thermo. ass'y
4. Blue lead of Defrost thermo. ass'y
5. Lead E.V cover ass'y
6. Lead E.V cover ass'y
7. Black lead of Fuse ass'y
8. White lead of Fuse ass'y
9. No connect
(6) Fixing of E.V cover sealer C

17
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
Figure C-1. Cooling unit
COOLING UNIT
Hot pipe L
(Side condenser) Hot pipe (DP-condenser) Hot pipe R (Side condenser)
Evaporator
Suction pipe
Bottom condenser Compressor
Capillary tube
Dryer
Back condenser
Mark: Refrigerant flow
Mark: Brazing portion
Except for SJ-48G, SJ-D48G

18
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
SJ-48G SJ-48G SJ-48G
SJ-D48G SJ-D48G SJ-D48G
-GY -BE -BL
REPLACEMENT PARTS LIST(SJ-48G/SJ-D48G)
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 RTHM-A057CBE0 F-thermostat 1 1 1 BA
1- 2 RSTT-A106CBE0 Starting relay 1 1 1 AN
1- 3 QSWTDA025CBE0 Defrost timer 1 1 1 AW
1- 4 PDMP-A025CBE0 Damper thermostat 1 1 1 AZ
1- 5 FTHM-A012CBK0 Defrost thermo.ass’y 1 1 1 AQ
1- 6 RMOTRA027CBE0 Fan motor 1 1 1 AZ
1- 7 QSOCAA037CBE0 Lamp socket 1 1 1 AM
1- 8 RLMP-A002CBE0 Lamp 1 1 1 AE
1- 9 QACC-A095CBE0 Source cord 1 1 1 AM
1-10 QSW-PA056CBEA Door switch 1 1 1 AP
1-11 RHOG-A086CBE0 Protector 1 1 1 AV
1-15 RC-EZA135CBE0 Running capacitor 1 1 1 AS
1-17 FFS-TA036CBK0 Fuse ass’y 1 1 1 AN
1-19 FW-VZA109CBE0 D timer lead ass'y 1 1 1 AN
1-20 FW-VZA110CBE0 Lead EV-cover ass’y 1 1 1 AP
1-21 FHETBA080CBE0 Def. heater ass’y(SJ-48G) 1 1 1 AX
1-21 FHETBA073CBE0 Def. heater ass’y(SJ-D48G) 1 1 1 BD
1-22 QCNW-A634CBE0 Relay wire G 1 1 1 AE
1-23 QCNW-A635CBE0 Relay wire B 1 1 1 AE
1-24 QCNW-A636CBE0 Relay wire BR 1 1 1 AE
1-25 QTAN-A032CBE0 Terminal block 1 1 1 AE
MECHANICAL PARTS
2- 1 LSTPPA078CBFA Back spacer 1 1 1 AD
2- 2 JKNB-A036CBFA F-temp. control knob 1 1 1 AL
2- 4 LPLTMA404CBE0 FL plate AL. 1 1 1 AD
2- 7 FLEGPA045CBK0 Leg holder L ass’y 1 1 1 AQ
2- 7-1 FAJS-A009CBK0 Adjustable leg ass’y 2 2 2 AD
2- 7-2 LHLD-A354CBM0 Leg holder L 1 1 1 AE
2- 8 FLEGPA046CBK0 Leg holder R ass’y 1 1 1 AQ
2- 8-2 LHLD-A355CBM0 Leg holder R 1 1 1 AE
2-11 PSPAVA074CBEA Bottom hinge spacer 1 1 1 AD
2-13 DHNG-A274CBM0 Upper hinge ass’y 1 1 1 AK
2-14 DHNG-A275CBM0 Bottom hinge R ass’y 1 1 1 AK
2-15 DHNG-A276CBK0 C-hinge RD ass’y 1 1 1 AN
2-15-1 PSPAVA075CBEA Center hinge spacer 1 1 1 AD
2-16 GCOV-A141CBFA E.V cover 1 1 1 AU
2-17 LCRA-A010CBE0 Fan clamp 1 1 1 AD
2-19 LHLD-A245CBF0 Motor cushion 2 2 2 AF
2-20 NFANPA011CBF0 Propeller fan 100 1 1 1 AD
2-21 PSEL-B128CBE0 E.V cover sealer A 1 1 1 AD
2-22 PSEL-B129CBE0 E.V cover sealer B 1 1 1 AD
2-23 PSEL-A415CBE0 E.V cover sealer C 1 1 1 AC
2-24 PCOVPA175CBFA Terminal cover 1 1 1 AF
2-26 PCOV-A151CBFA Lamp cover 1 1 1 AF
2-27 GCOVPA067CBRA R-Cbox cover 1 1 1 AN
2-28 HGRL-A133CBRA Fan louver 1 1 1 AT
2-29 GCOV-A140CBFA Upper hinge cover 1 - - AE
2-29 GCOV-A140CBFC Upper hinge cover - 1 - AE
2-29 GCOV-A140CBFF Upper hinge cover - - 1 AE
2-31 JKNB-A033CBFA R-temp. control knob 1 1 1 AD
2-33 LRALPA114CBFA C-case rail L 1 1 1 AE
2-34 LRALPA115CBFA C-case rail R 1 1 1 AE
2-36 PCAP-A006CBFK Screw cover - 1 - AD
2-36 PCAP-A006CBFL Screw cover 1 - - AB
2-36 PCAP-A006CBFM Screw cover - - 1 AB
2-38 PGID-A119CBF0 R-air guider A 1 1 1 AH
2-39 LFRM-A202CBFA C-box base 1 1 1 AK
2-40 PFPFPA809CBF0 RA-insulation 1 1 1 AD
2-41 PSEL-B244CBE0 Thermo. cap. sealer 1 1 1 AB
2-42 PGID-A118CBF0 R-air guider B 1 1 1 AG
2-49 LSTPPA074CBFA C-stopper 2 2 2 AD
2-55 HGRL-A135CBFA Multi louver 1 1 1 AL
2-56 PFPFPA824CBF0 R-louver insu. 1 1 1 AE
2-57 PSEL-B143CBE0 A-sealer R-louver 2 2 2 AC
2-63 LHLD-A302CBF0 Fan motor cushion B 1 1 1 AL
2-64 LHLD-A303CBM0 Fan motor cushion A 1 1 1 AM
2-66 PSHEMA132CBP0 Heater cover AL 1 1 1 AD
2-67 LPLTMA403CBP0 Drain support AL 1 1 1 AL

19
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
SJ-48G SJ-48G SJ-48G
SJ-D48G SJ-D48G SJ-D48G
-GY -BE -BL
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2-68 PSEL-A562CBE0 Leading wire sealer 1 1 1 AC
2-69 PSEL-B127CBE0 E.V cover sealer D 1 1 1 AC
2-70 PSEL-B167CBE0 E.V cover sealer E 1 1 1 AD
2-71 PSEL-A552CBE0 Dial sealer 1 1 1 AC
2-72 PSEL-B120CBE0 A-sealer RC-box 1 1 1 AB
2-73 PSEL-B121CBE0 A-sealer RC-duct 1 1 1 AD
2-74 PSEL-B122CBE0 A-sealer thermo. cap. 1 1 1 AB
2-75 PSEL-B124CBE0 A-sealer air guider B 1 1 1 AB
2-76 LHLD-B124CBEB Key-frame holder 1 1 1 AB
2-77 LHLD-A359CBFA T-box holder 1 1 1 AH
2-78 LPLTMA399CBP0 Dryer support 1 1 1 AD
2-80 PBOX-A078CBFA Terminal box 1 1 1 AG
2-81 PPIPPA055CBE0 Drain pipe S 1 1 1 AG
2-82 PTUBBA043CBE0 Insulating tube 1 1 1 AG
2-83 PSEL-B242CBE0 A-sealer air guider C 2 2 2 AC
2-84 PSEL-B243CBE0 A-sealer air guider D 2 2 2 AD
DOOR PARTS
3- 2 HDECAA056CBEA Handle trim(SJ-48G-BL) - - 1 AX
3- 2 HDECAA056CBEB Handle trim(SJ-48G-GY) 1 - - AX
3- 2 HDECAA056CBEC Handle trim(SJ-48G-BE) - 1 - AX
3- 2 HDECAA053CBEA Handle trim(SJ-D48G-GY) 1 - - AZ
3- 2 HDECAA053CBEB Handle trim(SJ-D48G-BE) - 1 - AZ
3- 2 HDECAA053CBEC Handle trim(SJ-D48G-BL) - - 1 AZ
3- 5 FDORFA722CBK0 F-door ass’y 1 - - BP
3- 5 FDORFA732CBK0 F-door ass’y - 1 - BP
3- 5 FDORFA737CBK0 F-door ass’y - - 1 BP
3-5-1 LSTPPA075CBFA F-door stopper 1 1 1 AP
3-5-2 NBRGPA013CBFB Nylon bearing 2 1 1 1 AH
3- 6 FPACGA204CBK0 F-door packing 1 1 1 AZ
3- 9 GLIN-A145CBFA F-door liner 1 1 1 AX
3-10 PFPFPA810CBE0 F-liner plate 2 2 2 AD
3-12 PFPFPA852CBE0 F-liner plate bottom 1 1 1 AD
3-14 PSEL-B126CBE0 F-door sealer 2 2 2 AG
3-15 FDORRA574CBK0 R-door ass’y 1 - - BR
3-15 FDORRA579CBK0 R-door ass’y - 1 - BR
3-15 FDORRA596CBK0 R-door ass’y - - 1 BR
3-15-1 LSTP-A043CBM0 R-door stopper 1 1 1 AH
3-15-2 NBRGPA012CBF0 Nylon bearing R 1 1 1 AE
3-15-3 NBRGPA014CBFB Nylon bearing 3 1 1 1 AH
3-16 GLIN-A148CBEA R-door liner 1 1 1 AX
3-17 FPACGA207CBK0 R-door packing 1 1 1 AZ
3-20 PFPFPA822CBE0 R-liner plate 2 2 2 AF
3-25 HBDGDA710CBEA Badge 1 - - AN
3-25 HBDGDA710CBEB Badge - 1 - AN
3-25 HBDGDA710CBEC Badge - - 1 AN
OTHER PARTS
4- 1 LBND-A023CBE0 L-band C 4 4 4 AC
4- 3 LX-VZA003CBE0 Special screw 2 2 2 AB
4- 9 QTAN-A012CBE0 Solderless term. B 3 3 3 AH
4-14 PSPANA002CBF0 Door spacer 1 1 1 AC
4-16 LX-BZA052CBE0 Clamp screw 2 2 2 AB
4-17 LX-WZA003CBE0 Washer 4 4 4 AA
ATTACHMENT PARTS
5- 1 UPOK-A120CBRA Bottle pocket HS 2 2 2 AQ
5- 2 UPOK-A117CBRA Egg pocket HS 1 1 1 AM
5- 3 UPOK-A119CBRA F door pocket HS 2 2 2 AT
5- 4 UPOK-A118CBRA Utility pocket HS 1 1 1 AM
5- 5 UTNA-A167CBFC Egg tray 2 2 2 AG
5- 6 FSRA-A142CBY0 Ice cube maker 1 1 1 AR
5- 7 LFRM-A200CBFA Ice maker 1 1 1 AR
5- 8 USRA-A174CBRA Ref. tray silk 1 1 1 AX
5- 9 USRA-A176CBRA Freezer tray L silk 1 1 1 AT
5-11 USRA-A175CBRA Freezer tray S silk 1 1 1 AU
5-12 HDECQA360CBEA Glass shelf trim 1 1 1 AK
5-13 HGRL-A132CBFA Ventilating grille 1 - - AN
5-13 HGRL-A132CBFC Ventilating grille - 1 - AN
5-13 HGRL-A132CBFE Ventilating grille - - 1 AN

20
SJ-48G/D48G
SJ-51G/D51G
SJ-55G/D55G
SJ-48G SJ-48G SJ-48G
SJ-D48G SJ-D48G SJ-D48G
-GY -BE -BL
REF. NO. PART NO. DESCRIPTION Q'TY CODE
5-14 USRA-A177CBFA Evaporating pan 1 1 1 AR
5-15 UTNA-A227CBE0 Glass shelf 1 1 1 BB
5-16 UYOK-A180CBFA Vegetable case 1 1 1 AZ
5-17 UYOK-A181CBFA Ice storage box 1 1 1 AH
5-18 UYOK-A179CBFA Chilled case 1 1 1 AS
5-19 GDORPA042CBRA Chilled door HS 1 1 1 AP
5-20 UTNA-A228CBRA F-set shelf F silk 1 1 1 AT
5-21 UTNA-A229CBFA Free set shelf B 1 1 1 AS
CYCLE PARTS
6- 1 PCMPLA132CBE0 Compressor 1 1 1 CC
6- 2 PSPAGA028CBE0 Rubber grommet 4 4 4 AF
6- 3 FCONSA052CBK0 Sub. condenser ass’y 1 1 1 AR
6- 4 FFRM-A085CBK0 Base frame ass’y 1 1 1 AF
6- 5 PDRY-A005CBE0 Dryer 1 1 1 AP
6- 6 PCLI-A035CBE0 Clip 1 1 1 AC
6- 9 PSPAFA007CBE0 Sleeve 4 4 4 AD
6-11 PPIPCA220CBE0 S.P connector 1 1 1 AH
6-12 LANG-A024CBP0 Absorbent rubber CLM 1 1 1 AC
6-13 LHLD-A061CBF0 Evaporating pan holder 2 2 2 AD
6-14 PGUM-A002CBF0 Absorbent rubber B 1 1 1 AH
6-15 PGUM-A003CBF0 Absorbent rubber B 1 1 1 AH
6-16 PGUM-A004CBF0 Absorbent rubber A 1 1 1 AH
6-18 PPIPCA222CBE0 Charge pipe L 2 2 2 BC
6-19 LHLD-A357CBE0 Clamp supplement 1 1 1 AC
6-20 LHLD-A358CBE0 Cable clamp 2 2 2 AD
6-21 PCOVPA165CBE0 Terminal cover 1 1 1 AF
MISCELLANEOUS
90- 1 TINS-A273CBR0 Operation manual 1 1 1 AF
90- 2 TLAB-A473CBR0 Lamp label 1 1 1 AB
90- 3 SPAKCG337YDE0 Packing case(SJ-48G-GY) 1 - - BH
90- 3 SPAKCG338YDE0 Packing case(SJ-48G-BE) - 1 - BH
90- 3 SPAKCG339YDE0 Packing case(SJ-48G-BL) - - 1 BH
90- 3 SPAKCG195YDE0 Packing case(SJ-D48G-GY) 1 - - BH
90- 3 SPAKCG199YDE0 Packing case(SJ-D48G-BE) - 1 - BH
90- 3 SPAKCG361YDE0 Packing case(SJ-D48G-BL) - - 1 BH
90- 6 CPADBA501YDK0 Bottom pad ass’y 1 1 1 AY
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
90- 7 CPADBA495YDK0 Top pad ass’y 1 1 1 AS
