Sharp SJ-BA35CHXI2-UA User manual

Home Appliances
Fridge-freezers
SJ-BA35CHXI2-UA
User ManualEN
Інструкція з Експлуатації
UA

EN -1-
Contents
CHAPTER -1: GENERAL WARNINGS ............................................................................ 2
CHAPTER -2: YOUR FRIDGE FREEZER........................................................................ 5
CHAPTER -3: USING YOUR FRIDGE FREEZER ........................................................... 6
CHAPTER -4: FOOD STORAGE GUIDANCE ................................................................ 12
CHAPTER -5: DOOR REVERSAL .................................................................................. 13
CHAPTER -6: TROUBLESHOOTING............................................................................. 13
CHAPTER -7: TIPS FOR SAVING ENERGY .................................................................. 15
FIRE
Warning; Risk of re / ammable materials
Your fridge freezer conforms to current safety requirements. Inappropriate use can lead to personal injury and damage
to property. To avoid the risk of damage read this manual carefully before using your fridge freezer for the rst time. It
contains important safety information on the installation, safety, use and maintenance of your Fridge Freezer. Retain
this manual for future use.

EN -2-
CHAPTER -1: GENERAL WARNINGS
WARNING: Keep the ventilation openings of the Fridge
clear from obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process.
WARNING: Do not use other electrical appliances inside
the Fridge.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
WARNING: To avoid personal injury or damage this
appliance must be installed in accordance with the
manufacturer instructions.
The small quantity of refrigerant used in this fridge is eco-
friendly R600a (an isobutene) and is ammable and
explosive if ignited in enclosed conditions.
* While carrying and positioning the fridge, do not damage
the cooler gas circuit.
* Do not store any containers with ammable materials, such
as spray cans or re extinguisher rell cartridges in the
vicinity of the fridge.
* This appliance is intended to be used in household and
similar applications such as;
- staff kitchen areas in shops, ofces and other working
environments which can be equated with ordinary
household
- farm houses and by clients in hotels, motels and other
residential type environments which can be equated with
ordinary household
- bed and breakfast type environments which can be
equated with ordinary household

EN -3-
CHAPTER -1: GENERAL WARNINGS
- catering and similar non-retail applications which can be
equated with ordinary household
* Your fridge requires a 220-240V, 50Hz mains supply. Do
not use any other supply. Before connecting your fridge,
ensure that the information on the data plate (voltage and
connected load) matches the mains electricity supply. If in
doubt, consult a qualied electrician)
* This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazard involved. Children shall not play with the appliance.
Cleaning and user maintenance, shall not be made by
children without supervision.
* A damaged power cord /plug can cause re or give you
an electric shock. When damaged it must be replaced, this
should only be done by qualied personnel.
* This appliance is not intended for use at altitudes exceeding
2000 m.

EN -4-
CHAPTER -1: GENERAL WARNINGS
Installation Information
Before unpacking and manoeuvring your fridge freezer please take some time to familiarise yourself with the following
points.
• Position your fridge freezer out of direct sunlight and away from any heat source such as a radiator.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores, and should be at least
5 cm away from electrical ovens.
• Do not expose your fridge freezer to moisture or rain.
• Your fridge freezer should be positioned at least 20mm away from another freezer.
• Clearance of at least 150 mm is required at the top of your appliance. Do not place anything on top of your
appliance.
• For safe operation, it is important that your fridge freezer is seated securely and balanced. The adjustable feet
are used to level your fridge freezer. Make sure that your appliance is level before placing any foodstuffs inside it.
• We recommend that you wipe all shelving and trays with a cloth soaked in warm water mixed with a teaspoon
of bicarbonate of soda before use. After cleaning, rinse with warm water and dry.
Disposal
• All packaging and materials used are environmentally friendly and recyclable. Please dispose of any packaging
in an environmentally friendly manner. Consult your local council for further details.
• When the appliance is ready to be scrapped, cut off the electrical supply cable and destroy the plug and cable.
Disable the door catch in order to prevent children getting trapped inside.
• A cut-off plug inserted into a 16 amp socket is a serious safety (shock) hazard. Please ensure the cut-off plug
is disposed of safely.
Disposal of your old appliance
This symbol on the product or package shows that the product should not be treated as domestic waste.
Instead, it should be taken to applicable waste collection sites that recycle electrical and electronic
equipment. Recycling materials will help preserve our natural resources. For more detailed information
regarding recycling this product, please contact your local authority, domestic waste disposal service, or
the shop where you purchased the product.
Please ask your local authority about the disposal of WEEE for reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance. We are not responsible
for damage resulting from misuse.
• Follow all instructions for your appliance, and keep this manual handy in order to resolve any problems that
may occur in the future.
• This appliance is produced to be used in homes and can only be used in domestic environments and for the
speciedpurposes.Itisnotsuitableforcommercialuse.Suchusewillnullifythewarrantyandourcompany
will not be responsible for any losses that occur.
• This appliance is produced for home use and it is only suitable for cooling / storing foods. It is not suitable for
commercial or use and / or for storing any substances except for food. Our company is not responsible for any
losses due to improper use.
Safety warnings
•Do not use an extension cord to connect your fridge freezer to the mains electricity supply.
• Do not use plug adapter.
• Adamagedpowercord/plugcancausereorgiveyouanelectricshock.ifdamageditmustbereplaced;this
shouldonlybedonebyqualiedpersonnel.
• Never kink the power cord.
• Never touch the power cord / plug with wet hands as this could cause electric shock.
• Do not place glass bottles or beverage cans in the freezer compartment. Bottles or cans may explode.
• When removing ice made in the freezer compartment, do not touch it because it ice may cause frostbite and /
or cuts due to ice formed with sharp edge.
• Do not remove items from the freezer if your hands are damp or wet. This could cause skin abrasions or frostbite.
• Do not refreeze food once it has thawed.
If your refrigerator has a fan condenser:
The condenser of your fridge is placed at the bottom of cabinet.
As a result of that, assemble the spacer by xing it to holes on
thecoverbottompanelandturn90°that’sshownbelowgurefor
arranging the distance between the refrigerator and the back wall
at where you place the fridge. You can move the fridge towards the
back wall until that point.
Plastic for distance setting

EN -5-
CHAPTER -1: GENERAL WARNINGS
Before using your fridge freezer
• Before setting up your fridge freezer, check for any visible damage. Do not install or use your fridge freezer
if it is damaged
• When using your fridge freezer for the rst time, keep it in an upright position for at least 3 hours before
plugging into the mains. This will allow efcient operation and prevent damage to the compressor.
• You may notice a light odour when using your fridge freezer for the rst time. This is perfectly normal and will
fade away as the fridge starts to cool.
Information about new-generation cooling technology
Fridge freezers with new-generation cooling technology have a different working system than static
fridge freezers. In normal fridge freezers, humid air entering the freezer and the water vapour
emanating from the foods, turns into frost in the freezer compartment. In order to melt this frost, in
other words defrost, the fridge has to be unplugged. In order to keep foods cold during the defrosting
period, the user must store the food elsewhere and the user must clear the remaining ice and
accumulated frost.
The situation is completely different in freezer compartments equipped with new-generation cooling
technology. With the aid of fan, cold and dry air is blown throughout the freezer compartment. As a
result of the cold air that is blown easily throughout the compartment – even in the spaces between
shelves – foods are frozen equally and properly. And there will be no frost.
The conguration in the refrigerator compartment will be nearly same as the freezer compartment. Air
emitted by the fan located at the top of refrigerator compartment is cooled while passing through the
gap behind the air duct. At the same time, air is blown out through the holes on the air duct so that
cooling process is successfully completed in the refrigerator compartment. Holes on the air duct are
designed for even air distribution throughout the compartment.
Since no air passes between the freezer and refrigerator compartment, odours will not mix.
As a result, your fridge with new-generation cooling technology is easy to use and it offers you an
access to a huge volume and aesthetic appearance.
CHAPTER -2: YOUR FRIDGE FREEZER
This gure has been drawn for information purposes to show the various parts and accessories in the appliance.
Parts may vary according to the model of the appliance.
Fridge compartment
Wine rack *
Fridge shelves
Door shelves
Door shelf / Adjustable door shelf
Chiller compartment *
Crisper cover
Bottle shelf
Crispers
Ice-matic *
Freezer top basket / ap
Freezer compartment
Freezer - middle basket
Freezer - bottom basket
Levelling feet
Egg holder
Ice tray *
* In some models

EN -6-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Display and Control Panel
Using the Control Panel
1. Freezer temperature setting.
2. Super Freeze mode indicator
3. Fridge temperature setting
4. Super Cooling mode indicator
5. Holiday mode indicator
6. Eco mode indicator
7. Alarm indicator
8. Child Lock mode indicator
9. Screen selector
10. Decrease value
11. Increase value
12. Mode Selector
13. Child Lock Selector
1 2 3 4
5 6
78
910 1112 13
Operating your Fridge Freezer
Super Freeze Mode
Purpose
• To freeze a large quantity of food that cannot t on the fast freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain freshness.
How to use
• Press icon (#9 on control panel diagram), until the
‘Freezer temperature setting’ is selected (#1).
• Once Freezer temperature setting is selected, the
temperature will ash.
• Press the icon (#10) repeatedly until the ‘Super
Freeze logo appears’ in the top left corner (#2)
• Once the Super Freeze mode has been set, the machine
will beep to conrm the mode has been switched on.
• After the beep the original temperature of the freezer will appear on screen.
• Mode can be cancelled by repeating the above instructions from the beginning.
During this mode:
• Temperature of the fridge compartment may be adjusted, this will not impact Super Freeze Mode.
• Economy and holiday mode cannot be selected whilst Super Freeze is active.
Super Cool Mode
Purpose
• To cool and store a large quantity of food in the fridge compartment.
• To quickly cool drinks.
How to use
• Press icon (#9 on control panel diagram), until the
‘Fridge temperature setting’ is selected (#1).
• Once fridge temperature setting is selected, the
temperature will ash.
• Press the icon (#10) repeatedly until the ‘Super Cool
logo appears’ in the top right corner (#4)
• Once the Super Cool mode has been set, the machine will beep to conrm the mode has been switched on.
• After the beep the last temperature of the fridge will appear on screen.

EN -7-
CHAPTER -3: USING YOUR FRIDGE FREEZER
• Mode can be cancelled by repeating the above instructions from the beginning.
During this mode:
• Temperature of the freezer compartment may be adjusted, this will not impact Super Cool Mode.
• Economy and holiday mode cannot be selected whilst Super Cool is active.
Economy Mode
Purpose
Energy savings. During periods of less frequent use (door opening) or absence from home, such as a holiday, Eco
program can provide optimum temperature whilst saving power.
How to Use
• Press icon (#12 on control panel diagram), until the
‘Eco Mode’ icon appears (#6).
• Once the ‘Eco mode’ has been set, the machine will beep
to conrm the mode has been switched on.
• After the beep the both the fridge and freezer temperature
setting (#1 and #3) will display an ‘E’.
• Eco Mode can be cancelled by pressing the Icon (#12).
During this mode:
• The freezer and fridge temperature may be adjusted however the adjustment will not be made until Eco
Mode is cancelled. When economy mode is cancelled, the selected setting values will be activated and the
temperature(s) will be adjusted.
• Super Cool or Super Freeze mode can be selected, however by selecting either modes Eco Mode is cancelled
immediately.
• Holiday mode can only be selected after cancelling the economy mode.
Holiday Mode
Purpose
Holiday mode is to be used if the device is to be left for an extended period. During Holiday mode only the freezer
compartment remains active.
How to Use
• Press icon (#12 on control panel diagram), until the
‘Holiday Mode’ icon appears (#5).
• Once the ‘Holiday mode’ has been set, the machine will
beep to conrm the mode has been switched on.
• After the beep the fridge will display ‘--’ and the freezer will
display the -18 oC set temperature.
• Holiday Mode can be cancelled by pressing the icon
(#12).
During this mode:
• Freezer and fridge temperature may be adjusted however the adjustment will not be made until Holiday Mode is
cancelled. When Holiday mode is cancelled, the selected setting values will be activated and the temperature(s)
will be adjusted.
• Super Cool or Super Freeze mode can be selected, however by selecting either modes Holiday Mode is
cancelled immediately.
• Eco Mode can only be selected after Holiday mode has been cancelled.

EN -8-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Drink Cool Mode
Purpose
This mode is used to cool drinks within an adjustable time frame.
How to Use
• Press icon (#12) and (#9) icons simultaneously
for ve seconds.
• The cooler temperature set indicator will start showing
‘05’. This value will ash on screen
• Users can either press or buttons to adjust the
time period (05, 10, 15, 20, 25 or 30 minutes)
• When you select the time the numbers will blink 3 times
on screen and sound beep beep. If the user do not press
any button within 2 seconds the time will be set.
• The machine will then set the time, the remaining time will be shown on screen
• Once the total time has elapsed, an alarm will sound
• Cool Drink Mode can be cancelled by following pressing the icon (#12) and (#9) icons simultaneously
for ve seconds.
During this mode:
• When drink cool and child lock modes are active, the child lock mode must be cancelled in order to stop the
alarm sound
• While using this mode, you must regularly check the temperature of the bottles. When the bottles are cool
enough, you must take them out of the appliance.
• Bottles can explode if left in the appliance for too long with drink cool mode active.
Screen Saver Mode
Purpose
This mode saves energy by switching off all control panel lighting when the panel is left inactive.
How to Use
• Screen saver mode will be activated automatically after
30 seconds.
• If you press any key while the lighting of the control panel
is off, the current machine settings will reappear on the
display to let you make any change you wish.
• If you do not cancel the screen saving mode or press any
key for 30 seconds, control panel will remain off.
To deactivate the screen saving mode,
• To cancel the screen saving mode, rst of all, you need to press any key to activate the keys and then press
and hold the Mode button " " (#12) for 3 seconds.
• To reactivate screen saving mode, press and hold the mode button " " (#12) for 3 seconds.
The Child Lock Function
Purpose
Child lock can be activated to prevent any accidental or
unintentional changes being made to the appliance settings.
Activating Child Lock
Press and hold child lock button (#13) for 5 seconds.
Cancelling Child Lock
Press and child lock button (#13) for 5 seconds.

EN -9-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Temperature Settings
Freezer Temperature Settings
• Press icon (#9 on control panel diagram), until the
‘Freezer temperature setting’ is selected (#1).
• Once Freezer temperature setting is selected, the
temperature will ash.
• Users can then use the up or down arrow ( / ) to
set the temperature (-16, -18, -20, -22, -24°C and Super
Freeze Mode).
• If Super Freeze mode or Eco mode is activated, the
temperature will not change until the mode is cancelled.
Cooler Temperature Settings
• Press icon (#9 on control panel diagram), until the ‘Fridge temperature setting’ is selected (#1).
• Once Fridge temperature setting is selected, the temperature will ash.
• Users can then use the up or down arrow ( / ) to set the temperature (8, 6, 5, 4, 2°C and Super Cool
Mode).
• If Super Freeze mode or Eco mode is activated, the temperature will not change until the mode is cancelled.
Door Open Alarm Function
If either the fridge or freezer door is left open for more than 2 minutes, the appliance will beep.
Warnings About Temperature Adjustments
• It is not recommended that you operate your fridge in environments colder than 10°C.
• Temperature adjustments should be made according to the frequency of door openings, the quantity of food
kept inside the fridge and ambient temperature of the placement of your fridge.
• Your fridge should be operated up to 24 hours according to the ambient temperature without interruption after
being plugged in, this is so it is completely cooled. Do not open the doors of your fridge and do not place food
inside it during this period.
• A 5 minute delay function is applied to prevent damage to the compressor of your fridge, when you take the
plug out and then plug it back in again after an energy breakdown has occurred. Your fridge will start to operate
normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature
intervals stated in the standards, according to the climate class
stated in the information label. We do not recommend operating
your fridge out of the stated temperatures value limits in terms
of cooling effectiveness.
• This appliance is designed for use at an ambient temperature
within the 10°C - 43°C range.
Climate Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Temperature indicator
In order to help you better set your refrigerator, we have equipped it with a temperature indicator located in
the coldest area.
To better store the food in your refrigerator, especially in the coldest area, make sure the message “OK”
appears on the temperature indicator. If "OK" does not appear, this means that the temperature setting has
not been done properly.
Since “OK” appears in black, it will be difcult to see this indication if the temperature indicator is badly lit. To
be able to see this indication properly, there should be enough light.
Each time the temperature setting device is changed, wait for the stabilisation of the temperature inside the appliance
before proceeding, if necessary, with a new temperature setting. Please change the position of the temperature setting
device progressively and wait at least 12 hours before starting a new check and potential change.
NOTE: Following repeated openings (or prolonged opening) of the door or after putting fresh food into the appliance, it
is normal for the indication “OK” not to appear in the temperature setting indicator. If there is an abnormal ice crystals
build-up (bottom wall of the appliance) on the refrigerator compartment evaporator (overloaded appliance, high room
temperature, frequent door openings), set the temperature setting device to a lower position until compressor off
periods are obtained again.
OK

EN -10-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Accessories
Icematic
• Take out the ice making tray
• Fill the water to the line.
• Place the ice making tray in its original position
• When ice cubes are formed, twist the lever to drop ice cubes into the icebox.
Note:
• Do not ll the icebox with water in order to make ice. It may be broken.
• The movement of the ice maker may be difcult while the refrigerator is running. In
such a case, it should be cleaned after removing the glass shelves.
Chiller shelf
Keeping food in the chiller compartment instead of the freezer or refrigerator
compartment allows food retain freshness and avour longer while
preserving its fresh appearance. If the chiller tray becomes dirty, remove it
and wash with water.
(Water freezes at 0 °C, but foods containing salt or sugar require lowered
temperatures to freeze)
Normally people use the chiller compartment for raw sh, rice, etc...
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the chiller shelf
• Pull the chiller shelf out toward you by sliding it on rails.
• Pull the chiller shelf up from the rail to remove.
Putting food in the coldest area of the refrigerator
Your foods will be better stored if you put them in the most appropriate
cooling area. The coldest area is just above the crisper.
The following symbol indicates the coldest area of your refrigerator.
To ensure a low temperature in this area, make sure the shelf is located at
the the same level as this symbol, as shown in the illustration.
The upper limit of the coldest area is indicated by the lower side of the sticker (head of
the arrow). The coldest area upper shelf must be at the same level with the arrow head.
The coldest area is below this level.
As these shelves are removable, make sure they are always at the same level with these
zone limits described on the stickers, in order to guarantee temperatures in this area.
Freezer box
• The freezer box is for foods that need to be accessed more easily.
• Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
!Make the inverse of the same operation for the resetting the
sliding compartment.
Note: Always hold the handle of box while moving in or out.
Freezer boxes
Fresh dial (In some models)
If you want to keep your vegetables longer in that compartment, you have to
change the humidty controller that is located at the front of the crisper, to closed
position. With the aid of this function, humidty level in the crisper compartment,
will stay constant and vegetables will last longer.
If you want to keep your vegetables colder in that compartment, you have to
change the humidity controller to open position. By doing this change, you will
allow the cold air to enter the crisper compartment. As a result of this, your
vegetables will be colder.
If you see any condensation on the glass shelf that is located at the top of
crisper, you can change the humidity controller to open position.

EN -11-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Adapti-Lift door shelf
Five different height adjustments can be made to provide storage areas that you need by
Adapti-Lift.
To change the position of Adapti-Lift;
Lift up front of the shelf (1) and move up or down adjustable door shelf (2) with both hands
(Fig 1)
Before releasing the door shelf make sure the door shelf is located at door positions.
Visual and text descriptions on the accessories section may vary according to the model.
Fig.1
(1) (2)
Cleaning
• Make sure to unplug the fridge before cleaning.
• Do not wash your fridge by pouring water .
• You can wipe the inner and outer sides with a soft cloth or a sponge using warm and soapy water.
• Remove the parts individually and clean with soapy water. Do not wash in washing machine.
• Never use ammable, explosive or corrosive material like thinner, gas, acid for cleaning.
Make sure that your fridge is unplugged while cleaning.
Replacing The LED (if an LED is used as lighting)
Please contact the Sharp help desk as this should be changed by
authorized personnel only.
Note: Numbers and location of LED strips may change according to
different models.
Led strip lamps
(In some models)
Led strip lamps
(In some models)

EN -12-
CHAPTER -4: FOOD STORAGE GUIDANCE
Refrigerator compartment
• To reduce frost build up never place liquids with unsealed containers in the fridge compartment.
• Allow warn or hot food to cool down before storing. This helps reduce power consumption.
• To avoid frost build-up ensure that nothing is stored touching the back wall.
• The coldest area of the refrigerator is at the bottom. We recommend to use this area to store food that will perish
easily, such as sh, ready meals, baked goods or dairy products. The warmest area is the top shelf of the door.
We recommend you store butter or cheese here.
Important Note:
• Cover any nished dishes when you put them in the fridge. Place them
in the fridge when they are cool, otherwise temperature/humidity inside
the fridge increases and this causes the fridge to operate more. Covering
food and beverages also preserves their avour and aroma.
• Potatoes, onion and garlic shouldn’t be kept in the fridge.
• Please avoid the foods from touching to temperature sensor which
is located at refrigerator compartment. In order to keep optimum
preservation temperature in refrigerator compartment, foods mustn’t
contact with the sensor.
Freezer compartment
• Use the freezer to store frozen foods for long periods of time and make ice cubes.
• To freeze fresh food - ensure that as much of the surface of food to be frozen is in contact with the cooling
surface.
• Do not put fresh food on either side of frozen food as it can thaw it.
• While freezing fresh foods(i.e meat,sh and mincemeat),divide into portion sizes.
• Once the unit has been defrosted replace the foods into freezer and remember to consume them in a short
period of time.
• Never place warm food in the freezer compartment.
• The instructions shown on frozen food packages should always be followed carefully and if no information is
provided food should not be stored for more than 3 months from the purchased date.
• When buying frozen foods ensure that these have been frozen at suitable temperatures and that the packing
is intact.
• Frozen foods should be transported in appropriate containers to maintain the quality of the food and should be
stored in the freezer as soon as possible.
• If a package of frozen food shows signs of humidity and abnormal swelling it has been previously stored at an
unsuitable temperature and that the contents have deteriorated.
• The storage life of frozen foods depends on the room temperature, thermostat setting, how often the door is
opened, the type of food and the length of time required to transport the product from the shop to your home.
Always follow the instructions printed on the package and never exceed the maximum storage life indicated.
That; If you decide to open the freezer door again immediately after closing, it may be difcult to re-open. This is normal
and after the freezer has reached an equilibrium condition the door will open easily.
Important note:
• Frozen foods, when thawed, should be cooked just like fresh foods. If they are not cooked after being thawed
they must NEVER be re-frozen.
• The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger,
garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they
are stored for a long period. Therefore, only add a small amount of spice if planning to freeze, or the desired
spice should be added after the food has been thawed.
• The storage period of food is dependent on the oil used. The suitable oils are margarine, calf fat, olive oil and
butter and the unsuitable oils are peanut oil and pig fat.
• The food in liquid form should be frozen in plastic cups and the other food should be frozen in plastic folios or
bags.
Temperature sensor area

EN -13-
CHAPTER -5: DOOR REVERSAL
Repositioning the door
• It depends on which fridge freezer you have as to whether it is possible the reverse the doors.
• It is not possible where handles are attached at the front of the appliance.
• If your model does not have handles it is possible to reverse the doors, but this needs to be completed by
authorised personnel. Please call Sharp service.
CHAPTER -6: TROUBLESHOOTING
Check Warnings;
Your fridge warns you if the temperatures for cooler and freezer are in improper levels or when a problem occurs in the
appliance. Warning codes are displayed in the Freezer and Cooler Indicators.
ERROR TYPE MEANING WHY WHAT TO DO
E01 Sensor warning Contact the Sharp help desk as
soon as possible.
E02 Sensor warning Contact the Sharp help desk as
soon as possible.
E03 Sensor warning Contact the Sharp help desk as
soon as possible.
E06 Sensor warning Contact the Sharp help desk as
soon as possible.
E07 Sensor warning Contact the Sharp help desk as
soon as possible.
E08 Low Voltage Warning
Power supply to the device
has dropped to below
170W.
- This is not a device failure, this
error helps to prevent damages
to the compressor.
- The voltage needs to be
increased back to required
levels
If this warning continues, contact
the Sharp help desk as soon as
possible.
E09 Freezer compartment
is not cold enough
Likely to occur after long
term power failure.
1. Set the freezer temperature
to a colder value or set Super
Freeze. This should remove
the error code once the
required temperature has been
reached. Keep doors closed
to improve time taken to reach
the correct temperature.
2. Remove any products which
have thawed/defrosted during
this error. They can be used
within a short period of time.
3. Do not add any fresh produce
to the freezer compartment
until the correct temperature
has been reached and the
error is no longer.
If this warning continues, contact
the Sharp help desk as soon as
possible.

EN -14-
CHAPTER -6: TROUBLESHOOTING
ERROR TYPE MEANING WHY WHAT TO DO
E10 Fridge compartment
is not cold enough
Likely to occur after:
- Long term power failure.
- Hot food has been left in
the fridge.
1. Set the fridge temperature to
a colder value or set Super
Cool. This should remove the
error code once the required
temperature has been reached.
Keep doors closed to improve
time taken to reach the correct
temperature.
2. Please empty the location
at the front area of air duct
channel holes and avoid
putting food close to the
sensor.
If this warning continues, contact
the Sharp help desk as soon as
possible.
E11 Fridge compartment
is too cold Various
1. Check is Super Cool mode is
activated
2. Reduce the fridge
compartment temperature
3. Check to see if vents are clear
and not clogged
If this warning continues, contact
the Sharp help desk as soon as
possible.
If your fridge is not operating;
• Is there a power failure?
• Is the plug connected to the socket correctly?
• Is the fuse of the socket to which the plug is connected or the main fuse blown?
• Is there any failure at the socket? To check this, plug your refrigerator into a known working socket.
If your fridge is not cooling enough;
• Is the temperature adjustment right?
• Is the door of your fridge opened frequently and left open for a long while?
• Is the door of fridge closed properly?
• Did you put a dish or food on your fridge so that it contacts the rear wall of your fridge so as to prevent the air
circulation?
• Is your fridge lled excessively?
• Is there adequate distance between your fridge and the rear and side walls?
• Is the ambient temperature within the range of values specied in the operating manual?
If the food in your refrigerator compartment is over cooled
• Is the temperature adjustment right?
• Are there many food recently put inside the freezer compartment? If so, your fridge may over cool the food
inside the refrigerator compartment as it will operate longer to cool these food.
If your fridge is operating too loudly;
To maintain the set cooling level, compressor may be activated from time to time. Noises from your fridge at this time
are normal and due to its function. When the required cooling level is reached, noises will be decreased automatically.
If the noises persist;
• Is your appliance stable? Are the legs adjusted?
• Is there anything behind your fridge?
• Are the shelves or dishes on the shelves vibrating? Re-place the shelves and/or dishes if this is the case.
• Are the items placed on your fridge vibrating?
Normal Noises;
Cracking (Ice cracking) Noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise (Normal motor noise): This noise means that the compressor operates normally Compressor
may cause more noise for a short time when it is activated.
Bubbling noise and splash: This noise is caused by the ow of the refrigerant in the tubes of the system.
Water ow noise: Normal ow noise of water owing to the evaporation container during defrosting. This noise
can be heard during defrosting.

EN -15-
CHAPTER -6: TROUBLESHOOTING
Air Blowing Noise (Normal fan noise): This noise can be heard in No-Frost fridge during normal operation of
the system due to the circulation of air.
If humidity builds up inside the fridge;
• Has the food been properly packaged? Have the containers been well dried before they were put into the
refrigerator?
• Are the doors of the refrigerator opened very frequently? When the door is opened, the humidity found in the
air in the room enters the refrigerator. Especially if the humidity rate in the room is too high, the more frequently
the door is opened the faster will be the humidication.
If the doors are not opened and closed properly;
• Do the food packages prevent closing of the door?
• Are the door compartments, shelves and drawers placed properly?
• Are door gaskets broken or torn?
• Is your fridge on a level surface?
If the edges of fridge cabinet that the door joint contact are warm;
Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the
compressor, this is normal.
IMPORTANT NOTES:
• The compressor protection thermal fuse will cutout after sudden power breakdowns or after unplugging the
appliance, because the gas in the cooling system is not stabilised. This is quite normal, and the fridge will
restart after 4 or 5 minutes.
• The cooling unit of your refrigerator is hidden in the rear wall. Therefore, water droplets or ice may occur on the
rear surface of your fridge due to the operation of the compressor in specied intervals. This is normal. There
is no need to perform a defrosting operation unless the ice is excessive.
• If you will not use your fridge for a long time (e.g. in summer holidays) unplug it. Clean your fridge according to
Part 4 and leave the door open to prevent humidity and smell.
• The appliance you have purchased is designed for home type use and can be used only at home and for
the stated purposes. It is not suitable for commercial or common use. If the consumer use the appliance in
a way that does not comply with these features, we emphasise that the producer and the dealer shall not be
responsible for any repair and failure within the guarantee period.
• If the problem persists after you have followed all the instructions above, please consult an authorised service
provider.
CHAPTER -7: TIPS FOR SAVING ENERGY
1. Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near heat source (radiator,
cooker.. etc. ). Otherwise use an insulating plate.
2. Allow warm food and drinks to cool down outside the appliance.
3. When thawing frozen food, place it in the refrigerator compartment. The low temperature of the frozen food will
help to cool the refrigerator compartment when it is thawing. So it reduces the energy requirements.
4. When placing, drinks and liquids they must be covered. Otherwise humidity increases at the appliance. Therefore
the working time gets longer. Also covering drinks and liquids helps preserve the smell and taste.
5. When placing food and drinks, open the appliance door as briey as possible.
6. Keep the covers closed of any different temperature compartment in the appliance (crisper, chiller ...etc. ).
7. Door gasket must be clean and pliable. Replace gaskets if worn.

UA -16-
ЗМІСТ
ЧАСТИНА 1. ПЕРЕД ВИКОРИСТАННЯМ ХОЛОДИЛЬНИКА ..................................... 17
ЧАСТИНА 2. ЧАСТИНИ ПРИЛАДУ ТА ВІДДІЛЕННЯ ................................................. 21
ЧАСТИНА 3. ВІДОМОСТІ ЩОДО ВИКОРИСТАННЯ .................................................. 21
ЧАСТИНА 4. ЗБЕРІГАННЯ ПРОДУКТІВ У ХОЛОДИЛЬНИКУ .................................... 27
ЧАСТИНА 5. ТРАНСПОРТУВАННЯ ТА ЗМІНА МІСЦЯ РОЗТАШУВАННЯ ............... 28
ЧАСТИНА 6. ПЕРЕД ВИКЛИКОМ СЕРВІСНОЇ СЛУЖБИ ........................................... 28
ЧАСТИНА 7. ПОРАДИ ЩОДО ЕКОНОМІЇ ЕНЕРГІЇ ..................................................... 31
Шановний покупць!
Мета нашої компанії - пропонуватвати високоякісну продукцію, які відповідає всім сучасним вимогам і навіть
перевищує сподівання наших покупців. Якість цього приладу, який був виготовлений на сучасному обладнанні,
була ретельно перевірена під час виробництва. Ця інструкція призначена допомогти покупцеві впевнено і
максимально ефективно користуватися цим приладом, який виготовлений за найсучаснішими технологіями.
Перед використанням приладу уважно прочитайте цю інструкцію, яка містить загальну інформацію щодо
правильного встановлення, технічного обслуговування і експлуатації приладу. З питань встановлення приладу
зверніться до найближчої авторизованої сервісної служби.
Декларація про відповідність нормам ЄС
Цей прилад призначено тільки для домашнього використання. Використання приладу не за призначенням
(наприклад, для охолодження приміщення) є неприпустимим і небезпечним. Розроблення, виготовлення і
розповсюдження цього приладу виконується згідно з наступними стандартами:
- Директива про низьку напругу, 2006/95/EC.
- Директива про електромагнітну сумісність, 2004/108/EC.
- Директива про маркування у Євросоюзі, 93/68/EEC.
* Ця інструкція з експлуатації може стосуватися до декількох моделей. Тому можуть виникнути відмінності.
ПОЖЕЖІ
Попередження; Ризик пожежі / легкозаймисті матеріали

UA -17-
ЧАСТИНА 1. ПЕРЕД ВИКОРИСТАННЯМ ХОЛОДИЛЬНИКА
ПОПЕРЕДЖЕННЯ: Слідкуйте за тим, щоб у
вентиляційних отворах корпусу та внутрішній
конструкції не було сторонніх предметів.
ПОПЕРЕДЖЕННЯ: Не застосовуйте механічні
пристрої та інші засоби для прискорення процесу
розморожування окрім тих, які рекомендує виробник.
ПОПЕРЕДЖЕННЯ: Не використовуйте електричні
прилади у відсіках для зберігання харчових продуктів,
окрім рекомендованих виробником пристрою.
ПОПЕРЕДЖЕННЯ: Не допускайте пошкодження
холодильного контуру.
ПОПЕРЕДЖЕННЯ: Щоб уникнути небезпеки через
нестійкість пристрою, він має бути встановлений у
відповідності з інструкціями.
ПОПЕРЕДЖЕННЯ: Розміщуючи прилад, не допускайте
защемлення або пошкодження шнуру живлення.
ПОПЕРЕДЖЕННЯ: Не розташовуйте багатомісні
розетки або переносні джерела живлення з заднього
боку приладу.
Якщо у приладі використовується холодильний агент
R600a (про це можна дізнатися з інформації на
етикетці на холодильнику), необхідно дотримуватися
обережності під час транспортування та монтажу, щоб
уникнути пошкодження деталей приладу, що містять
холодильний агент. Хоча R600a є екологічно безпечним
природним газом, він є вибухонебезпечним, і в разі його
витікання через пошкодження деталей холодильного
контуру слід не допускати використання відкритого полум’я
або джерел тепла поблизу холодильника та провітрити
приміщення, в якому розташовано прилад, протягом
кількох хвилин.
* Під час перенесення та розташування холодильника
необхідно слідкувати за тим, щоб не пошкодити
холодильний контур.
* Не зберігайте в цьому пристрої вибухові речовини такі,
як аерозольні балони з горючим паливом.

UA -18-
ЧАСТИНА 1. ПЕРЕД ВИКОРИСТАННЯМ ХОЛОДИЛЬНИКА
* Цей прилад призначений для використання в домашніх
або подібних умовах, як-от:
- у кухонних куточках магазинів, офісів та інших робочих
зонах;
- домашніх господарствах та клієнтами в готелях,
мотелях та інших житлових приміщеннях;
- у місцях ночівлі зі сніданком;
- у місцях громадського харчування та аналогічних
неторговельних закладах.
* Якщо штепсель холодильника не підходить до
розетки, його повинен замінити виробник, його агент з
обслуговування або спеціаліст аналогічної кваліфікації,
щоб уникнути небезпеки.
* Цей прилад не призначено для використання людьми
(включно з дітьми) із обмеженими фізичними,
сенсорними або розумовими здібностями, а також
тими, які мають недостатній досвід та знання, окрім
тих випадків, коли вони користуються приладом під
наглядом або керівництвом особи, яка відповідає за
їхню безпеку.
* Слідкуйте за тим, щоб діти не гралися з приладом. До
шнура живлення цього холодильника був приєднаний
спеціальний штепсель із заземленням. Цей штепсель
можна вмикати лише у заземлену розетку, обладнану
плавким запобіжником щонайменше на 16 амперів.
* Якщо у вашому будинку немає такої розетки, зверніться
до уповноваженого електрика для встановлення такої.
Цей прилад можуть використовувати діти старші 8
років та особи зі зниженими фізичними, сенсорними та
ментальними можливостями або котрим бракує досвіду
та знань, якщо їм забезпечено нагляд та інструкції
щодо безпечного користування приладом і якщо вони
розуміють можливу небезпеку. Діти не повинні бавитися
з приладом. Чищення та обслуговування не повинні
здійснювати діти без нагляду.
* Цей прилад не призначено для використання на висоті
понад 2000 м над рівнем моря.
