Sharp SJ-EX770F User manual

Refrigerator-Freezer
Operation manual
Contents
•Safety information.................................................... 3
•Installation ................................................................5
•Description................................................................6
•Useful modes............................................................7
•Control panel............................................................8
•Storing food............................................................10
•Care and cleaning ..................................................11
•Before you call for service......................................12
•Product FICHE .......................................................13
Frigorico-Congelador
Manual de manejo
Contenido
•Información de seguridad.......................................14
•Instalacion ..............................................................16
•Description..............................................................17
•Modos útiles ...........................................................18
•Panel de control......................................................19
•Para almacenar los alimentos................................21
•Cuidados y limpieza ...............................................22
•Antes de llamar al servicio tecnico.........................23
•Ficha del producto..................................................24
Frigorifero-Freezer
Manuale di istruzioni
Sommario
•Informazioni di sicurezza........................................25
•Installazione............................................................27
•Descrizione.............................................................28
•Modalità utili............................................................29
•Pannello di controllo LCD.......................................30
•Conservazione degli alimenti..................................32
•Manutenzione e pulizia...........................................33
•Prima di chiamare il servizio di assistenza.............34
•Scheda prodotto.....................................................35
Refrigerateur-Congelateur
Mode d’emploi
Table des matieres
•Consignes de sécurité............................................36
•Installation ..............................................................38
•Description..............................................................39
•Modes d’utilisation..................................................40
•Panneau de commandes........................................41
•Conservation des aliments.....................................43
•Entretien et nettoyage ............................................44
•Avant d’appeler le service apres-vente ..................45
•Fiche produit...........................................................46
Kühlschrank mit Tiefkühlfach
Bedienungsanleitung
Inhalt
•Sicherheitsinformationen........................................47
•Aufstellen................................................................49
•Beschreibung..........................................................50
•Hilfreiche modi........................................................51
•Bedienfeld...............................................................52
•Aufbewahrung von lebensmitteln ...........................54
•Pege und reinigung...............................................55
•Bevor sie den sharp-service kontaktieren ..............56
•Produktdatenblatt ...................................................57
SJ-EX770F
SJ-EX820F
(B717).indb 1 2016/02/15 11:27:59

(B717).indb 2 2016/02/15 11:27:59

3
Household use only
Thank you very much for buying this SHARP product. Before using your SHARP
refrigerator, please read this operation manual to ensure that you gain the maximum
benet from it.
• This refrigerator is intended for making ice cubes, refrigerating and freezing foods.
• This refrigerator is for household use only, with ambient temperature indicated in
the table. The climate class is specied on the rating plate.
The refrigerator is fully functional at the ambient temperature range of the indicated
climate class. If the refrigerator is used at colder temperatures, the refrigerator will
not be damaged up to a temperature of +5°C.
• The refrigerator should not be subjected to temperatures of -10°C or below for a
long period of time.
Refrigerant
This refrigerator contains ammable refrigerant (R600a:
isobutane) and insulation blowing gas (cyclopentane).
Observe the following rules to prevent ignition and
explosion.
■Do not allow any sharp objects to have contact with the
refrigeration system. The refrigeration system behind
and inside the refrigerator contains refrigerant.
■Do not use mechanical devices or other means to
accelerate the defrosting process. (This refrigerator has
adopted automatic defrosting system.)
■Do not use electrical appliances inside the refrigerator.
■Do not block the space around the refrigerator.
■Do not use ammable sprays, such as spray paint near
the refrigerator.
■In the case of failure of the refrigeration system, do not
touch the wall socket and use open ames.
Open the window and air out the room. Then ask a
service agent approved by SHARP for service.
Installation
■Do not install the refrigerator in a damp or wet location.
It may cause the damage to the insulation or electrical
leak. Dew may also appear on the outer cabinet and it
causes rust.
■The refrigerator should be installed atly and rmly on
the oor.
Power cord, Plug, Socket
Read carefully the following rules to prevent electric
shock or re.
■Connect the power plug into the wall socket rmly and
directly. Do not use an extension cord or adapter plug.
■Connect the power plug to the socket with the required
rated voltage.
■Connect the earth pin to the earth terminal properly.
■Make sure that the power cord has not been damaged
during installation or moving. If the power plug or cord
is loose, do not insert the power plug.
■Do not touch the power plug with wet hands.
■Disconnect from the main electricity supply by removing
the main plug from the socket.
Do not remove by pulling the power cord.
■Dust deposited on the power plug may cause re.
Wipe it off carefully.
■Pull out the plug if the refrigerator is not used for a long
time.
■Should the exible supply cord be damaged, it must
be replaced by service agent approved by SHARP, a
special cord is required.
In use
■Do not store volatile and ammable materials such
as ether, petrol, propane gas, aerosol cans, adhesive
agents and pure alcohol etc. These materials are easy
to explode.
■Do not store temperature-sensitive products such as
pharmaceutical products in the refrigerator.
There are high risks of changes in product quality .
■Do not attempt to change or modify this refrigerator.
This may result in re, electric shock or injury.
■Do not place any object on the top of refrigerator.
If the object falls down from the top, it may cause injury.
■
This appliance can be used by children aged from 8
years or above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way or understanding the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
■Do not use other than potable water to make ice cubes.
Climate
class Acceptable range of ambient temperature
SN +10°C to 32°C
N +16°C to 32°C
ST +16°C to 38°C
T +16°C to 43°C
Safety information
Warning This means that there are high risks of death or serious injury.
Caution This means that there are high risks of material damage or personal injury.
Warning
(B717).indb 3 2016/02/15 11:27:59

4
Care and Cleaning
■Unplug the refrigerator rst to prevent electric shock.
■Do not splash water directly on the outer cabinet or the
interior. This may lead to rusting and deterioration of
the electrical insulation.
Trouble
■If you smell something burnt, pull out the power plug
immediately. Then ask a service agent approved by
SHARP for service.
■In case of gas leak, ventilate the area by opening
window. Do not touch the refrigerator or the power
socket.
Disposal
■Ensure that the refrigerator presents no danger to
children while being stored for disposal. (e.g. remove
the magnetic door seals to prevent child entrapment.)
■This refrigerator should be disposed appropriately.
Take the refrigerator to a professional recycling plant
for ammable refrigerant and insulation blowing gases.
Transportation
■When you install or move your refrigerator, use curing
mat to protect the oor from being damaged.
■Carry the refrigerator by holding the handles located on
the rear and bottom side. If you lift up the refrigerator
improperly, it may cause injury.
Caution
rear bottom
In use
■Do not touch the compressor unit or its peripheral parts,
as they become extremely hot during operation and the
metal edges may cause injury.
■Do not touch foods or metal containers in the freezer
compartment with wet hands. This may cause frostbite.
■Do not place bottled drinks and cans in the freezer
compartment.
Especially “Express cool” is in operation, there is a high
risk that glass bottles may burst.
■Do not open or close the door when other people put
a hand near the door. There is a risk that the other
people may get their ngers caught in the door.
■Do not put oversized object in the pockets of the door.
If the object falls down from the pockets, it may cause
injury.
(B717).indb 4 2016/02/15 11:27:59

5
Free standing type
1Keep adequate ventilation space around the refrigerator.
• The gure shows the
minimum required
space for installing
the refrigerator. The
measurement condition
of power consumption
is conducted under
a different space
dimension.
• By keeping greater
space, the refrigerator may consume a less amount
of power consumption.
• If use the refrigerator in the smaller space
dimension than gured, it may cause temperature
rise in the unit, loud noise and failure.
• The space between the rear of the refrigerator and
the wall should be 60mm or more, and less than
75mm.
If the space is wider than 75mm, you may get
injured by touching compressor and its peripheral
parts which are extremely hot during the operation.
Overall space required in use
Installation Free standing type
90mm
or more
60mm
or more 60mm or more
1180 mm
1500 mm
2Use the two front the adjustable feet to place the refrigerator atly and rmly on the oor.
3When right and left doors are not properly aligned, adjust using the adjustable feet.
Adjustable foot
Note
• Place your refrigerator to access the plug.
• Keep your refrigerator out of direct sunlight and do not
place next to heat generating appliance.
• Do not place your refrigerator directly on the ground.
Insert suitable stand such as wooden board under the
refrigerator.
• When you insert the power plug with the door opened,
door alarm sounds but it is not abnormal. This sound
stops after closing the door.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm
water.
If soapy water is used, wipe it off thoroughly with water.
When the left door is
raised. When the right door is
raised.
Lower the foot
at right side. Lower the foot
at left side.
(Until the adjustable foot on the
other side is slightly off-ground.)
4Remove the 4 screws of the lower part of the cabinet and use these screws to set the foot cover. (The foot
cover is packed inside the refrigerator compartment.)
Screw
(4 screws) Screw
Foot cover
(B717).indb 5 2016/02/15 11:28:00

6
1. Door pocket (3 pcs)
2. Refrigerator shelf (2 pcs)
3. Shelf
4. Bottle pocket (left)
5. Fruit and vegetable crisper
The cover of the fruit and vegetable
crisper opens as the case is pulled.
6. Freezer case (small) (3 pcs)
7. Freezer case (large) (2 pcs)
8. Caster (4 pcs)
The casters allow the refrigerator
to move back and forth.
9. Adjustable foot (2 pcs)
10. Foot cover
11. Hybrid cooling panel
The panel cools the refrigerator compartment
indirectly from the rear. In this way, food is cooled
gently without being exposed to cold air ow.
12. Light
13. Utility pocket
SJ-EX820F : 2 pcs
SJ-EX770F : 1 pc
14. Egg holder
15. Bottle pocket (right)
To store large-size bottles, move
the partition all the way back.
16. Fresh case (upper)
17. Fresh case (lower)
18. Ice cube maker (2 pcs)
1) Do not overll this tray with water.
Otherwise the ice cubes will join
together when frozen.
2) When ice cubes are made, turn the
lever clockwise to put the ice into
the ice cube box.
Description
19. Ice cube box (2 pcs)
Note
To prevent the ice cube box from being damaged, do
not pour oil into the box or make ice in it.
20. Magnetic door seal (4 pcs)
21. Control panel
Deodorizing unit
Deodorizing catalyst is installed on the routes of cold air.
There is no need to operate and clean.
More food can be stored by taking out the
internal accessories with normal cooling
operation.
Partition
How to remove
To remove the partition, pull it to
the front with pushing the claw.
Partition
Push
How to set
Insert the four projections into
the upper parts.
Lever
Ice cube box
Claw
()
15
13
1
14
SJ-EX770F
16
15
5
20
20
20
20
7 7
6
2
1
1
6
88
99
10
1112 12
13
14
18
19
SJ-EX820F
1
13
17
21
4
3
How to remove the fruit and vegetable
crisper cover
Projection portion
Hole
Cover
Casters
(B717).indb 6 2016/02/15 11:28:01

7
Useful modes As for the operations, refer to chapter “Control panel”.
Freezer
compartment
Fresh case
Extra cool
Express freezing
Express cool
Extra cool Express freezing Express cool
Feature This mode is to cool
beverages or foods to
ice-cold.
Note : Food with high-
moisture may freeze.
This mode speeds up
the time to freeze food. This mode is to cool beverages or foods quickly.
Point of use Fresh case Freezer compartment Freezer compartment
Caution : Do not place glass bottles. There is a
high risk that they may burst.
Operating time 6 hours *12 hours *130 minutes
• This mode ends automatically.
• The alarm does not sound. • This mode ends automatically. • The alarm sounds.
To stop the alarm *2
After the operation
completed • There is no need for taking beverages or foods out. • Be sure to take the beverages and foods out when the alarm sounds.
• If the beverages and foods are left in the freezer
compartment over approximately 30 minutes, they
may freeze.
At the time of
power failure
during the
operation
• This mode is automatically cancelled. • This mode is automatically restarted from the
previous state at the time of re-power.
Press enter button.
*1 It may take more time to complete if the operation
overlaps with defrosting. This mode starts after
defrosting is completed.
*2 If you do not stop the alarm, it sounds 30 minutes
continuously.
Note
• Extra cool, Express freezing and Express cool are not
available at the same time while one of the modes is in
operation.
• Avoid opening the door as much as possible during the
operations of these modes.
(B717).indb 7 2016/02/15 11:28:01

8
Control panel
Note
• When you press one of the
buttons, all icons ash once and
show the standby display. If the
refrigerator stops because of
power failure, the modes except
for Extra cool and Express
freezing function the same way as
before at the time of re-power.
• Operation is invalid while the
refrigerator door is open.
• Mode icons or indicators
in operation light up on
the standby display.
When Express cool is
in operation, the icon
ashes on the standby
display.
• When there is no
operation for
approximately
1 minute, the display returns to
the standby display automatically.
The standby display turns off if
there is no operation for another
1 minute.
Turn-on state
Operations of useful modes
Display
1Select the mode icon. (e.g. Extra cool)
2Select on/off.
(off)
3
Complete the setting.
(Beep) Mode icon turns
on. Mode icon turns off on the standby
display.
“Express cool”only
Complete the setting by pressing
for 3 seconds or more.
(Beep, Beep, Beep)
“Express cool”
only
(Flashing)
Flashing
When press button, the icons
change in the order shown as below.
:
Standby display
Useful modes
Operation of additional modes
Summary Cancel operation Display
Door alarm • When the refrigerator or freezer door is left open for over
1 minute, door alarm sounds once, and again after 1
minute.
• If the door is left open for approx. 3 minutes, the alarm
sounds continuously.
• The alarm stops after close all the door.
Press and simultaneously
for 3 seconds or more.
(Beep, Beep, Beep) The indicator
turns off.
Sound
of button
operation
• When you want to switch off button operation sound. Press and simultaneously
for 3 seconds or more.
(Beep, Beep, Beep) The indicator
turns off.
Note • When you want to turn on the additional mode, follow the same step again. (The indicator turns on.)
Select
button
Switching
button
Enter
button
Useful modes
Icon Meaning Default setting
Extra cool
OFF
Express freezing
Express cool
Controlling temperature
Icon Meaning Default setting
Refrigerator
compartment 3°C
Freezer compartment -18°C
Additional modes
Indicator Meaning Default setting
Door alarm
ON
Sound of button
operation
(B717).indb 8 2016/02/15 11:28:03

9
Advanced Setting of Refrigerator/Freezer compartment
The temperature of refrigerator compartment and freezer compartment can be adjusted in step of 0.5 °C by following the
steps ato c.
a. After the step 1of “Basic operations”,
press 3 seconds or more.
The current preset temperature returns to “Default setting”
(The display is indicated as the picture on the right.)
b. Press or and set the temperature.
c. Complete the setting. (Same as the step 3of “Basic operations”.)
Follow the steps ato cagain if you want to adjust the temperature in step of
1°C.
Refrigerator
compartment Freezer compartment
Beep beep beep
switch
Controlling temperature
The refrigerator controls its temperature automatically. However, you can adjust the temperature as below.
How to check the current
temperature setting
Press button to select or icon.
Setting of Refrigerator / Freezer
compartment
Freezer compartment
: Adjustable between -13°C and -21°C in step of 1°C
Refrigerator compartment
: Adjustable between 0°C and 6°C in step of 1°C
Default setting
Refrigerator compartment Freezer compartment
Basic operations Display
1
Select or
icon.
Refrigerator
compartment Freezer compartment
2
Set the
temperature.
3Complete
the setting.
(Beep)
Flashing Flashing
(up)
(down)
When press button, the icons
change in the order shown as below.
:
Standby display
Controlling temperature
Flashing
(B717).indb 9 2016/02/15 11:28:04

10
IN
OUT
Fruit / Vegetables
Fruit and vegetables should be loosely enclosed in a
plastic material e.g. wrap, bags (do not seal) and placed
in the Fruit and vegetable crisper to minimize moisture
loss.
Dairy Products & Eggs
• Most dairy products have their best-before date on
the outer packaging which informs the recommended
temperature and shelf life of the foods.
• Eggs should be stored in the Egg holder.
Meats / Fish / Poultry
• Place on a plate or a dish and cover with paper or
plastic wrap.
• For larger cuts of meat, sh, or poultry, place to the rear
of the shelves.
• Ensure all cooked food is wrapped securely or placed in
an airtight container.
For best freezing
• Quality of foods should be fresh.
• Freeze small quantities of food at a time in order to
freeze them quickly.
• Food should be properly sealed or covered tightly.
• Place foods in the freezer evenly.
• Label bags or containers to keep an inventory of
freezing food.
Advice for preventing dew or frost
inside the refrigerator
• Keep the door securely closed. If the food falls down,
it may cause a gap between the cabinet and the door.
Move it back to the shelf or the pocket.
• Food with high-moisture should be stored in airtight
container or sealed tightly.
Note
• Evenly place the food on the
shelves to allow the cooling air
to circulate efciently.
• Hot foods should be cooled
before storing. Storing
hot foods increases the
temperature in the unit and
the risk of food spoilage.
• Do not block the outlet
and inlet of the cool air
circulating circuit with foods
or containers; otherwise
the foods is not be evenly
cooled throughout the
refrigerator.
Do not place food directly in front of cold air outlet.
This may lead to the food freezing.
Refrigeration reduces the rate of food spoilage.
Ensure that the food is of the freshest possible quality to maximize the shelf life of perishable foods.
The following is a general guide to help promote longer food storage.
Storing food
Vegetables are improper ●
in this case. They may
be frozen.
Dairy products
Small foods
Eggs etc.
Meat, Fish, Poultry etc.
Fruits, Vegetables
Small foods
Juice etc.
Bottles etc.
Frozen foods
(Small size)
Frozen foods
(Big size)
Bottles etc.
(Big size)
(B717).indb 10 2016/02/15 11:28:05

11
Power consumption
Power consumption of this model is measured according to the
international standard of refrigerator performance.
If the refrigerator is operated with the
accessories (shaded area) taken out,
it works under the most energy efcient
condition.
• The amount of power consumption
of this model is measured with these
accessories taken out as indicated
shaded area.
• The amount of power
consumption of this model
is measured under the
space dimensions on the
right picture.
■Keep the ventilation space as much as
possible around the refrigerator.
■Keep your refrigerator out of direct sunlight,
and do not place it next to heat generating
appliance.
■Avoid opening the door as much as possible.
■Hot foods should be cooled before storing.
■Place the food evenly on the shelves to allow
the cool air to circulate efciently.
Tips for saving energy
300mm
90mm
300mm
60mm
Important
To prevent cracks on inside surfaces and plastic
components, follow these tips.
• Wipe out food oil adhered to plastic parts.
• Some household chemicals may cause damage, so use
only diluted washing-up liquid (soapy water).
• If undiluted detergent is used or soapy water is not
wiped off thoroughly, it may result in cracks of plastic
parts.
Cleaning
■Remove the accessories (e.g. shelves) from the cabinet
and the door. Wash them by warm soapy dishwashing
water. After that, rinse them in clean water and dry.
(Only fruit and vegetable shelf is not removable.)
■Clean the inside with a cloth soaked in warm soapy
dishwashing water. Then, use cold water to wipe off
soapy water thoroughly.
■Wipe the exterior with a soft cloth each time it gets
dirty.
■Clean the Magnetic door seal with a toothbrush and
warm soapy dishwashing water.
■Wipe the control panel with a dry cloth.
Note
• Do not use heavy-duty cleansers or solvents (lacquer,
paint, polishing powder, benzine, boiled water, etc.)
which may cause damages.
• If you pull out the power plug once, wait 5 minutes at
least before connecting the power plug again.
• The glass shelves weigh approximately 3 kg each. Hold
them rmly when remove from the cabinet and carry.
• Do not drop objects inside the refrigerator or strike the
inner wall. This may cause cracks to inner surface.
Before transporting
Wipe up water in the evaporating pan. Before wiping
up the water, wait more than 1 hour after pulling out the
power plug because refrigeration cycle equipment is
extremely hot.
(The evaporating pan is located on the rear of the
product.)
Switching off your refrigerator
If the refrigerator needs to be switched off for an
extended period, the following steps should be taken to
reduce the growth of mold:
1. Remove all food.
2. Remove the power plug from the socket.
3. Clean and dry the interior thoroughly.
4. Keep all the doors open slightly for a few days to dry.
Defrosting
Defrosting is automatically operated by a unique energy
saving system.
When the compartment light is blown
Contact the service agent approved by SHARP to
replace the light. The light is not to be replaced other
than by qualied service personnel.
Care and cleaning
Evaporating pan
(B717).indb 11 2016/02/15 11:28:05

12
Before calling for service, check the following points.
Problem Solution
The outside of the cabinet is
hot when touching. It is normal. The hot pipe is in the cabinet in order to prevent dew generation.
When there is refrigerator
noise. It is normal for the refrigerator to make the following sounds. • Loud noise is made by the compressor when its operation starts
-- Sound becomes quieter after a while.
• The compressor makes loud noise once a day.
-- Operating sound is made immediately after automatic defrost operation.
• Sound of owing uid (gurgling sound, zzing sound)
-- Sound of refrigerant owing in pipes (sound may become louder from time to time).
• Cracking or crunching sound, squeaking sound
-- Sound produced by expansion and contraction of inner walls and internal parts during
cooling.
Frost or dew appears inside
or outside the refrigerator. This may occur in one of the following cases. Use a wet cloth for wiping frost and a dry cloth for wiping dew.
• When the ambient humidity is high.
• When the door is frequently opened and closed.
• When foods containing plenty of moisture are stored. (Wrapping is required.)
The foods in the refrigerator
compartment freeze. • Is the refrigerator operated for a long time with refrigerator temperature control set at 0°C?
-- Change the temperature control back to around 3°C.
• Is the refrigerator operated for a long time with freezer temperature control set at -21°C?
-- Change the temperature control back to around -18°C.
• If ambient temperature is low, foods may freeze even if the refrigerator compartment is
set at 6°C.
Odors in the compartment. • Wrapping is required for the foods with strong odors.
• Deodorizing unit cannot remove all odors.
If door alarm does not stop. • The alarm stops after close the door.
If you still require service
Refer to your nearest service agent approved by SHARP.
Before you call for service
(B717).indb 12 2016/02/15 11:28:05

13
Product che
ANNEX Ⅲ
(EU) Regulation No.1060/2010
ATrade mark
BModel name SJ-EX770F SJ-EX820F
CCategory 7
DEnergy efciency class A++
EEU Ecolabel award —
FAnnual energy consumption *1[KWh/
year] 370 370
GStorage volume of all compartments that
do not merit a star rating [ L ] 345 394
HStorage volume of all frozen-foodstorage
compartments that merit a star rating [ L ] 211 211
IThe design temperature of “other
compartment” warmer than +14°C —
JFrost free YES
KTemperature rise time [ h ] 17 17
LFreezing capacity [Kg/24h] 9.5 9.5
MClimate class T T
NAirborne acoustic noise emission [dB(A)] 36 36
OBuilt-in appliance No (Free-standing type)
*1Energy consumption “XYZ” kWh per year, based on standard test results for 24 hours.
Actual energy consumption will depend on how the appliance is used and where it is located.
Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the ordinary dust
bin!
Used electrical and electronic equipment must be treated separately and in accordance
with legislation that requires proper treatment, recovery and recycling of used electrical
and electronic equipment.
Following the implementation by member states private households within the EU states
may return their used electrical and electronic equipment to designated collection facilities
free of charge*. In some countries* your local retailer may also take back your old product
free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators, please
dispose of these separately beforehand according to local requirements.
By disposing of this product correctly you will help ensure that the waste undergoes the
necessary treatment, recovery and recycling and thus prevent potential negative effects
on the environment and human health which could otherwise arise due to inappropriate
waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the
correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of charge to
the dealer, even if you don't purchase a new product. Further collection facilities are listed
on the homepage of www.swico.ch or www.sens.ch.
Attention:
Your product is marked
with this symbol.
It means that used
electrical and electronic
products should not
be mixed with general
household waste.
There is a separate
collection system for
these products.
(B717).indb 13 2016/02/15 11:28:05

14
Sólo para uso doméstico
Le agradecemos la compra de este producto SHARP. Antes de utilizar su frigoríco
SHARP, es recomendable que lea este manual de funcionamiento para asegurarse
de que obtiene las máximas ventajas de su nuevo frigoríco.
• Este frigoríco está destinado a la realización de cubitos de hielo y a la
refrigeración y congelación de alimentos.
• Este frigoríco es exclusivamente de uso doméstico, con la temperatura ambiente
indicada en la tabla. El tipo climático se indica en la placa de características.
El frigoríco es completamente funcional dentro del rango de temperatura
ambiente de la clase climática indicada. Si utiliza el frigoríco a menores
temperaturas, no lo dañará siempre y cuando no sean inferiores a los +5 °C.
• El frigoríco no debe someterse a temperaturas de -10 °C ni inferiores durante
períodos prolongados.
Refrigerante
Este frigoríco contiene refrigerante inamable (R600a:
isobutano) y gas explosivo de aislamiento (ciclo pentano).
Siga las siguientes reglas para evitar la ignición y
explosión.
■No permita que ningún objeto puntiagudo entre en
contacto con el sistema de refrigeración. El sistema de
refrigeración trasero e interior del frigoríco contiene
refrigerante.
■No utilice dispositivos mecánicos u otros medios
con el n de acelerar el proceso de descongelacion.
(Este frigoríco posee un sistema de descongelacion
automático)
■No utilice dispositivos eléctricos dentro del frigoríco.
■No bloquee el espacio alrededor del frigoríco.
■No use atomizadores inamables, como por ejemplo
pintura en aerosol, cerca del frigoríco.
■En caso de fallos en el sistema de refrigeración, no
toque el enchufe de pared y no utilice llamas. Abra la
ventana y ventile la habitación. Luego pida el servicio
de un agente de servicio aprobado por SHARP.
Instalacion
■No instale el frigoríco en un sitio húmedo o mojado
ya que puede deteriorarse el aislante y se pueden
producir fugas. Además se puede formar condensación
en el exterior del frigoríco y ocasionar corrosión.
■Instale el frigoríco de modo que quede rme y
nivelado sobre el suelo.
Cable de alimentación, clavija, enchufe
Lea detenidamente las siguientes normas para evitar
descargas eléctricas o incendios.
■Conecte rme y directamente la clavija de alimentación
en el enchufe. No use cables de extensión ni clavijas
adaptadoras.
■Conecte la clavija de alimentación en un enchufe que
posea el voltaje nominal necesario.
■Conecte adecuadamente el pasador de toma a tierra al
terminal de toma a tierra.
■Asegúrese de que el cable de alimentación no se
haya dañado durante la instalación o el movimiento.
Si la clavija o el cable de alimentación se encuentran
sueltos, no inserte la clavija.
■No toque la clavija de alimentación con las manos
mojadas.
■Desconecte del suministro eléctrico principal
desenchufando la clavija principal del enchufe. No
desenchufar tirando del cable de alimentación.
■La acumulación de polvo en el enchufe de la red puede
provocar incendios. Límpielo con cuidado.
■Si no va a usar el frigoríco durante un período
prolongado, desenchufe la clavija.
■Si el cable de corriente exible se daña, debe ser
reemplazado por un agente de servicio aprobado por
SHARP debido a que se necesita un cable especial.
Durante el uso
■No guarde materiales volátiles e inamables como por
ejemplo, éter, gasolina, gas propano, atomizadores
en aerosol, sustancias adhesivas y alcohol puro, etc.
Estos materiales explotan con facilidad.
■No guarde productos sensibles a la temperatura, como
por ejemplo productos farmacéuticos, en el frigoríco.
Existe un alto riesgo de que produzca cambios en la
calidad del producto.
■No modique este frigoríco. Unicamente podrán
desmontarlo o repararlo técnicos autorizados, ya que
de lo contrario podrían producirse descargas eléctricas,
incendio o daños personales.
■No coloque ningún objeto sobre el frigoríco. Si el
objeto de cae, podría causar lesiones.
■
Este aparato puede ser utilizado por niños a partir de 8
años de edad y por personas con capacidades físicas,
sensoriales o mentales reducidas, o que no tengan
experiencia y capacitación siempre y cuando hayan
recibido supervisión o la formación relativa al uso del
aparato de una manera segura y hayan entendido
los riesgos existentes. No permita que los niños
jueguen con el aparato. La limpieza y el mantenimiento
del usuario no deben ser realizados por niños sin
supervisión.
■Al elaborar cubitos de hielo, use solamente agua
potable.
Clase
climática Gama de temperatura ambiente permisible
SN +10 °C a 32 °C
N +16°C a 32°C
ST +16°C a 38°C
T +16°C a 43°C
Información de seguridad
Advertencia Quiere decir que existe un alto riesgo de muerte o lesión grave.
Precaucion Quiere decir que existe un alto riesgo de causar daños materiales o lesiones personales.
Advertencia
(B717).indb 14 2016/02/15 11:28:05

15
Cuidados y limpieza
■Desenchufe primero el frigoríco para evitar descargas
eléctricas.
■No vierta agua directamente en el compartimiento
exterior ni en el interior. Esto puede producir la
oxidación y deterioro del aislamiento eléctrico.
Problema
■Si percibe un olor a quemado, desenchufe
inmediatamente la clavija de alimentación.
A continuación, solicite a un agente de servicio
aprobado de SHARP que realice el servicio.
■En caso de que haya fugas de gas, ventile el área
abriendo una ventana. No toque el frigoríco ni el
enchufe de alimentación.
Desecho
■Asegúrese de que el frigoríco no represente ningún
peligro para los niños al ser almacenado para su
desecho. (por ejemplo, quite el cierre magnético de la
puerta para prevenir que queden atrapados los niños)
■Se debe desechar este frigoríco de forma apropiada.
Lleve el frigoríco a una planta de reciclaje profesional
para refrigerantes inamables y gases explosivos de
aislamiento.
Transporte
■Cuando instale o mueva su frigoríco, use una estera
endurecida para proteger el suelo contra daños.
■Cargue el frigoríco sosteníendolo por las asas
localizadas al frente y detrás.
Si eleva el frigoríco incorrectamente, podría sufrir
lesiones.
Precaucion
Durante el uso
■No toque la unidad del compresor o sus piezas
periféricas ya que pueden volverse muy calientes
durante el funcionamiento y los bordes de metal
pueden provocar heridas.
■No toque los alimentos o recipientes de metal del
compartimiento congelador con las manos mojadas.
Esto puede causar congelamiento.
■No coloque bebidas en botella ni en lata en el
compartimento del congelador.
Especialmente si “Enfriamiento rápido” está en
funcionamiento, existe un alto riesgo de que las botellas
de cristal exploten.
■No abra ni cierre la puerta si alguna persona ha
colocado sus manos cerca de la puerta. Existe el riesgo
de que los dedos de la otra persona queden atrapados
en la puerta.
■No introduzca objetos de gran tamaño en los
contenedores de la puerta. Si el objeto se cae del
contenedor, podría causar lesiones.
detrás al frente
(B717).indb 15 2016/02/15 11:28:06

16
Free standing type
1Mantenga un espacio de ventilación adecuado alrededor del frigoríco.
• La gura muestra el espacio
mínimo requerido para la
instalación del frigoríco.
Las condiciones de
medición de consumo
de energía se realizan
bajo dimensiones
diferentes de espacio.
• Si mantiene un espacio
mayor, el frigoríco podría
consumir menos cantidad de
energía.
• Si usa el frigoríco en un espacio de dimensiones
inferiores a las indicadas, podría causar un
aumento de la temperatura de la unidad, altos
niveles de ruido y fallos.
• El espacio entre la parte trasera del frigoríco y
la pared deberá ser de 60 mm o más y menor de
75 mm. Si el espacio es más amplio que 75 mm,
podría sufrir lesiones al tocar el compresor y sus
partes periféricas, que están extremadamente
calientes, durante el funcionamiento.
Instalacion
90mm
60mm 60mm
1180 mm
1500 mm
2Use los dos pies ajustables frontales, para asegurarse de que el frigoríco quede posicionado
rmemente y nivelado sobre el suelo.
Notas
• Coloque el frigoríco de modo que el enchufe sea
accesible.
• Mantenga el frigoríco alejado de la luz solar directa y
no lo coloque junto a aparatos generadores de calor.
• No coloque el frigoríco directamente en el suelo.
Coloque un soporte adecuado, como por ejemplo un
tablero de madera, debajo del frigoríco.
• Al introducir el enchufe de toma de corriente cuando la
puerta está abierta, suena la alarma de la puerta pero
esto es normal. La alarma se detiene al cerrar la puerta.
Antes de utilizar el frigoríco
Limpie las partes del interior con un paño humedecido
en agua tibia. Si emplea agua con jabón, frótelo bien con
agua para que no queden residuos de jabón.
4 Quite los 4 tornillos de la parte inferior del frigoríco y utilícelos para colocar la cubierta de protección
inferior. (La cubierta de protección inferior se
encuentra embalada en el interior del compartimento
del frigoríco).
Tornillo
Tipo no encastrablé
Espacio total requerido en uso
o más
o máso más
Pie ajustable
3Cuando la puerta derecha y la izquierda no están debidamente alineadas, ajústelas utilizando los pies
ajustables.
Cuando la puerta
izquierda está elevada. Cuando la puerta derecha está elevada.
Baje el pie
de la parte
derecha.
Baje el pie
de la parte
izquierda.
(Hasta que el pie ajustable del otro lado
quede ligeramente por encima del suelo.)
Cubierta de
protección inferior
Tornillo
(4 tornillos)
(B717).indb 16 2016/02/15 11:28:06

17
1. Compartimientos de la puerta (3 pzas.)
2. Estantería del frigoríc (2 pzas)
3. Estante
4. Compartimiento para botellas (izquierdo)
5. Cajón para conservar frutas y verduras
La tapa del cajón para conservar frutas
y verduras se abre al tirar del compartimiento.
6. Cajones del congelador (pequeño) (3 pzas)
7. Cajones del congelador (grande)
(2 pzas)
8. Ruedecilla (4 pzas)
Las ruedecillas permiten mover
el frigoríco hacia atrás y hacia delante.
9. Pie ajustable (2 pzas)
10. Cubierta de protección inferior
11. Panel de enfriamiento híbrido
El panel se enfría por la parte de atrás, enfriando así
de forma indirecta el compartimiento refrigerador. De
esta forma, los alimentos se congelan suavemente,
sin exponerlos a la corriente de aire frío.
12. Luz
13. Compartmiento de usos múltiples
SJ-EX820F : 2 pzas
SJ-EX770F : 1 pza
14. Huevera
15. Compartimiento para botellas (derecho)
Para meter botellas de tamaño grande,
mueva la pieza divisoria completamente
hacia atrás.
16. Compartimiento de frescosr (superior)
17. Compartimiento de frescos (inferior)
18. Dispositivo para hacer cubitos de hielo (2 pzas)
1) No llene excesivamente la bandeja; de lo
contrario los cubitos de hielo quedarían
pegados al congelarse.
2) Cuando estén hechos los cubitos, gire
la palanca en el sentido horario para
vaciarlos en la cubitera.
Description
19. Cubitera (2 pzas)
Notas
No haga hielo con la cubitera ni vierta
aceite en ella pues ésta puede agrietarse.
20. Cierre magnético de la puerta (4 pzas)
21. Panel de control
Unidad de desodorizacion
El catalizador de desodorización es instalado en las rutas
del aire frío. No se requiere operación ni limpieza.
Se podrán almacenar más alimentos
sacando los accesorios internos con la
operación de refrigeración normal.
()
15
13
1
14
SJ-EX770F
16
15
5
20
20
20
20
7 7
6
2
1
1
6
88
99
10
1112 12
13
14
18
19
SJ-EX820F
1
13
17
21
4
3
Cómo retirar la tapa del cajón para
conservar frutas y verduras
Parte saliente
Agujeros
Cubierta
Ruedecillas
Pieza divisoria
Palanca
Cubitera
Cómo extraerla
Para extraer la pieza divisoria,
tire de ella hacia el frente
apretando el agarrador.
Pieza
divisoria
Empuje
Cómo colocarla
Inserte los cuatro salientes
en las partes superiores.
Agarrador
(B717).indb 17 2016/02/15 11:28:07

18
Extra frio
Congelado rápido
Enfriamiento rápido Compartimiento
congelador
Compartimiento
de frescos
Extra frio Congelado rápido Enfriamiento rápido
Función Es el modo para enfriar
bebidas o alimentos a
temperaturas bajas.
Notas : Los alimentos
con alta humedad
podrían congelarse.
Este modo acelera el
tiempo de congelación
de los alimentos.
Es el modo para enfriar bebidas o alimentos
rápidamente.
Punto de uso Compartimiento de
frescos Compartimiento congelador Compartimiento congelador Precaucion : No coloque botellas de cristal. Existe
un alto riesgo de que exploten.
Tiempo operativo 6 horas *12 horas *130 minutos
• Este modo naliza automáticamente.
• No suena la alarma. • Este modo naliza automáticamente. • Suena la alarma.
Para parar la alarma *2
Después de
completar la
operación
• No es necesario extraer las bebidas o los
alimentos. • Asegúrese de extraer las bebidas y los alimentos cuando suene la alarma.
• Si deja las bebidas y los alimentos en el
compartimento del congelador durante
aproximadamente 30 minutos, podrían congelarse.
Cuando se
produce un fallo de
energía durante la
operación
• Este modo se cancela automáticamente. • Este modo se reinicia automáticamente desde
el estado anterior en el momento de la re-
alimentación.
Pulse el
botón Intro.
*1 Puede que tarde más tiempo en completarse si la
operación se superpone con la descongelación. Este
modo comienza después de nalizar la descongelación.
*2 Si no detiene la alarma, sonará continuamente durante
30 minutos.
Notas
• Extra frío, Congelado rápido y Enfriamiento rápido no
están disponibles al mismo tiempo mientras uno de los
modos esté funcionando.
• Evite al máximo abrir la puerta durante el funcionamiento
de uno de estos modos.
Modos útiles Para las operaciones, consulte el capítulo “Panel de control”.
(B717).indb 18 2016/02/15 11:28:07

19
Operaciones de
modos útiles
Panel de control
Visualización
1Seleccione el icono de
modo.
(p. ej., Extra frio)
2Seleccione encendido/
apagado.
(apagado)
3
Completa el ajuste.
(Pitido) El icono de modo
se enciende. El icono de modo se apaga en la
visualización
modo de espera.
Solamente “Enfriamiento
rápido”
Complete los ajustes pulsando
durante 3 segundos o más.
(Pitido pitido pitido)
Solamente
“Enfriamiento rápido”
(Parpadeando)
Cuando pulse el botón los iconos
cambian en el orden indicado a
continuación.
:
Operación de modos adicionales
Resumen Cancelar operación Visualización
Alarma de la
puerta • Cuando se deje abierta la puerta del frigoríco durante
más de 1 minuto, sonará la alarma de la puerta una vez
y de nuevo transcurrido 1 minuto.
• Si se deja la puerta abierta durante aproximadamente 3
minutos, la alarma sonará continuamente.
• La alarma se detiene al cerrar la puerta.
Pulse simultáneamente y
durante 3 segundos o más.
(Pitido pitido pitido) El indicador
se apaga
Sonido de
operación
del botón
• Cuando desee desactivar el sonido de operación del
botón. Pulse simultáneamente y
durante 3 segundos o más.
(Pitido pitido pitido) El indicador
se apaga
Notas • Cuando desee activar el modo adicional, siga de nuevo el mismo paso. (El indicador se enciende.)
Modos útiles
Icono Signicado
Ajuste
predeterminado
Extra frio
DESACTIVADO Congelado rápido
Enfriamiento rápido
Control de la temperatura
Icono Signicado
Ajuste
predeterminado
Compartimiento
frigoríco 3°C
Compartimiento
congelador -18°C
Modos adicionales
Indicador Signicado
Ajuste
predeterminado
Alarma de la
puerta ACTIVADO
Sonido de
operación del
botón
Botón de
selección
Botón de
conmutación
Botón Intro
Estado de activación
Notas
• Al pulsar uno de los botones, todos los
iconos parpadean una vez aparece la
visualización del modo de espera. Si
el frigoríco se detiene a causa de un
fallo en la alimentación, los modos, a
excepción de Extra frio y Congelado
rápido, funcionan del mismo modo que
antes después de la re-alimentación.
• La operación es inválida mientras la
puerta del congelador esté
abierta.
• Los iconos o indicadores de
modo de funcionamiento se
iluminan en la visualización
modo de espera. Cuando
el Enfriamiento rápido está
activado, el icono parpadea
en la visualización modo de
espera.
• Si no se
realiza
ninguna
operación durante aproximadamente
1 minuto, la visualización regresa
a la visualización modo de espera
automáticamente. La visualización
modo de espera se desactiva si no se
realiza ninguna operación durante 1
minuto.
Parpadeando
Visualización modo de espera
Modos útiles
(B717).indb 19 2016/02/15 11:28:09

20
Ajustes avanzados del compartimiento del congelador / frigoríco
La temperatura del compartimiento del congelador y del compartimento del frigoríco se puede ajustar en incrementos
de 0,5 °C siguiendo los pasos de aa c.
a. Después del paso 1de “Operaciones básicas”,
pulse durante 3 segundos o más.
La temperatura de preajuste actual regresa a “Ajuste predeterminado”
(La visualización aparece indicada como la imagen de la derecha.)
b. Pulse o y ajuste la temperatura.
c. Complete el ajuste. (Igual que en el paso 3de “Operaciones básicas”.)
Siga los pasos aa cnuevamente si desea ajustar la temperatura en
incrementos de 1 °C.
Compartimiento
frigoríco Compartimiento congelador
Pitido pitido pitido
Control de la temperatura
El frigoríco controla automáticamente la temperatura. No obstante, puede ajustar la temperatura de la manera siguiente.
Cómo comprobar el ajuste
de temperatura actual
Pulse el botón para seleccionar o .
Ajustes del compartimiento del congelador/
frigoríco
Compartimiento congelador
: Ajustable entre -13°C y -21°C en intervalos de 1°C.
Compartimiento frigoríco
: Ajustable entre 0°C y 6°C en intervalos de 1°C.
Ajuste predeterminado
Compartimiento
frigoríco Compartimiento congelador
Operaciones básicas Visualización
1
Seleccione
el icono o
.
Compartimiento
frigoríco Compartimiento congelador
2
Ajuste la
temperatura.
3Completa el
ajuste.
(Pitido)
When press button, the icons
change in the order shown as below.
:
Parpadeando Parpadeando
Parpadeando
(arriba)
(abajo)
interruptor
Visualización modo de espera
Modos útiles
(B717).indb 20 2016/02/15 11:28:10
