Sharp TOUCH DISPLAY User manual
LCD MONITOR
TOUCH DISPLAY DRIVER
OPERATION MANUAL
Applicable models
PN-K322B/PN-K322BH/LL-S201A
Version 1.0
for Mac
2
E
Contents
Introduction......................................................................3
System Requirements..................................................3
Setting up the Computer.................................................4
Installing the touch display driver .................................4
Touch Panel Settings.......................................................5
How to congure settings.............................................5
Calibration ....................................................................7
Properties.....................................................................8
Uninstalling the Driver Software ..................................10
Touch Action ..................................................................11
Important Information
• This software has been shipped after strict quality control and product inspection. If, however, you nd any failure or
malfunction, contact your product dealer.
• Please understand that SHARP CORPORATION bears no responsibility for errors made during use by the customer or a
third party, nor for any other malfunctions or damage to this software arising during use, except where indemnity liability is
recognized under law.
• Transcribing or duplicating part or all of this manual and/or this software without permission from our company is not
permitted.
• As a part of our policy of continuous improvement, SHARP reserves the right to make design and specication changes for
product improvement without prior notice.
• The contents or details may vary depending on the screen conguration and OS version, etc.
• This manual does not contain basic operating instructions for Mac OS.
Trademarks
• Apple, Mac and Mac OS are registered trademarks of Apple Inc.
• Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the U.S.A. and other countries.
• All other brand and product names are trademarks or registered trademarks of their respective holders.
3E
Introduction
System Requirements
To use the touch panel, the touch panel must be connected to a computer, and the touch display driver must be installed on the
computer.
OS Mac OS X v10.6, Mac OS X v10.7, Mac OS X v10.8
CPU Intel processor
Memory At least 2 GB
Free space on hard drive At least 5 MB
TIPS
• Depending on the application software, touch operation may not be possible (for example, if the application processes mouse
and other operations independently).
4
E
Setting up the Computer
To use the touch panel, the touch display driver must be installed and the touch panel must be connected to your computer.
Installing the touch display driver
The touch display driver is a program that enables you to use the touch panel to operate the computer that is connected to the
touch panel.
Caution
• Toinstall,anadministratorname(username)andpasswordarerequired.
• Ifanolderversionofthetouchdisplaydriverisinstalled,remove(uninstall)theoldversionbeforeinstallingthetouchdisplay
driver.(Seepage10.)
• DonottouchthetouchpanelwhenconnectingtheUSBcable.
Ifyoutouchthetouchpanel,itwillleadtoamalfunction.Inthiscase,disconnectandthenreconnecttheUSBcable.
1. Start your computer.
2. Exit all applications that are running.
3. Connect the USB cable for the touch panel to the computer.
To the USB terminal
of the computer
USB cable (Supplied)
USB port
USB port
LL-S201A
4. Run the setup program.
(1) Double-clickthe“TouchDisplay”folder,andthendouble-clickthe“Mac”folder.
(2) Double-click“SharpTouchDisplay.mpkg”.
5. Click “Continue”.
Followtheon-screeninstructionstoinstallthedriver.
• Ifascreenpromptingyoutoenterthenameandpasswordappears,enterthenameandpasswordoftheadministrator
andclick“InstallSoftware”(or“OK”).
• Ifthe“Whenthissoftwarenishesinstalling,youmustrestartyourcomputer.Areyousureyouwanttoinstallthesoftware
now?”screenappears,click“ContinueInstallation”.
6. Whentheinstallationnishedscreenappears,click“Restart”.
Thiscompletestheinstallationofthetouchdisplaydriver.
Eachtimethecomputerisstarted,thetouchdisplaydriverwillstartautomaticallytoenablethetouchpaneltobeused.
5E
Touch Panel Settings
The touch displaydriverstartsautomaticallyandtheicon( )appearsonthemenubar.
TIPS
• IfPN-K322B(orPN-K322BH)andLL-S201Aareconnectedatthesametime,ascreenforselectingthemodelwillappear
each time you select a setting.
• Dependingontheconnectedmodel,thescreenimageisdifferent.
Howtoconguresettings
nConguringsettingsfromthemenubar
1. Click the touch display driver icon ( ) on the menu bar.
2. Click a menu to change a setting.
• CurrentScreenResolution:Themodelcurrentlybeingusedandthecurrentscreenresolutionappear.
• Calibration:Seepage7.
• Properties:Seepage8.
• HardwareInformation:Selectthistospecify“RotateMode”.
-RotateMode:
Tocorrectthetouchpositionwhenthescreenisrotated,selectthescreenanglefromthefollowing:
Standard(0°)/90°/180°/270°
• VersionInformation:Showstheversionofthetouchdisplaydriver.
• DisableTDDriver:
Selecttodisablethetouchpanelfunction.
Todisableasingletouchpanelfunction,see“FunctionSetting”.(Seepage9.)
nConguringsettingsfromSystemPreferences
1. Click “System Preferences” from the Apple menu ( ).
2. Click “SharpTouchDisplay”.
3. Click the menu and select settings.
Menu
TIPS
• Ifthe“ShowSettingUtilityinmenubar”checkmarkisremoved,thetouchdisplaydrivericon( )doesnotappearonthe
menu bar.
6
E
nSettings when two devices are connected at the same time
IfPN-K322B(orPN-K322BH)andLL-S201Aareconnectedatthesametime,selectthemodelwhosesettingswillbechanged.
Twomodelscannotbesetatthesametime.
Caution
• Iftwodisplaysofthesamemodelareconnected,touchoperationwillonlybeenabledononemodel.
1. Click “System Preferences” from the Apple menu ( ).
2. Click “SharpTouchDisplay”.
The“DeviceSelection”screenappears.
3. Select the model whose settings you want to change.
Touch Panel Settings
7E
Calibration
If black bands appear at the top and bottom or left and right of the screen, perform position adjustment so that the mouse cursor
correctly moves to the point that is touched.
* If black bands appear both at the top and bottom and at the left and right, the touch position is not correct. In this case, change
the display.
nCalibration Method
Follow the steps below to congure the setting.
1. Click the touch display driver icon ( ) on the menu bar.
2. Click “Calibration”.
Auto
If black bands appear on the screen, position adjustment is automatically performed.
Select “Auto” and click on “Apply”.
Manual
If the automatically adjusted touch position is not correct, enter the display resolution (width, height) and click “Apply”.
In the case of PN-K322B, please check the menu screen. In addition, in the case of LL-S201A, please check by touching [Input
Select] on the menu screen.
For details, see the LCD MONITOR manual.
Touch Panel Settings
8
E
Properties
Settings for the touch action can be congured in the properties.
nDouble Click Range
Set the range over which the position can shift between the rst touch and the second touch and still be recognized as a double-
click (“Narrow” (8 pixels) to “Wide” (64 pixels)). To return the setting to the default setting, click “Default” (32 pixels).
nDouble Click Speed
Set the time that is recognized as a double-click. When a second touch occurs within the set time after the rst touch, it is
recognized as a double-click.
Speed Setting (Auto)
The inside of the frame can be touched twice (double-clicked) to set the speed automatically based on the interval between the
touches.
Set Manually
The speed can be set manually from “Slow” (about 1 second) to “Fast” (about 0.3 seconds).
Test
When the inside of the frame is double-clicked by touching it twice, the screen changes. If the screen does not change, repeat
the setting.
Default
Click to restore the default setting.
TIPS
• Depending on the application software, changing the setting may not have any effect (for example, if the setting is set
separately in the application).
Touch Panel Settings
9E
nRight-click
You can set press and hold to be recognized as a right click.*
Enable press and hold for right-clicking
When the checkbox is selected, press and hold is recognized as a right click.
Press and Hold Duration
Set the time until press and hold is recognized as a right click (“Short” (0.5 sec) to “Long” (1.5 sec)).
* If the Mac OS left-click long press action interferes with the press and hold action, do the following:
• Use “Click or tap with two ngers”
• Adjust “Press and Hold Duration” to a longer setting (toward “Long”)
nFunction Setting
Select the touch action to be used. (See page 11.)
Touch actions that are followed with a mark have multiple actions that can be used. Click a touch action and selected the
desired action.
Caution
• Touch actions that can be used vary depending on the OS.
* OS X v10.8 only
Touch Panel Settings
OS X v10.8/v10.7 OS X v10.6
*
10
E
Uninstalling the Driver Software
Caution
• To uninstall, an administrator name (user name) and password are required.
1. Disconnect the USB cable.
2. Execute uninstall.
(1) Double-click the “TouchDisplay” folder, and then double-click the “Mac” folder.
(2) Double-click “TouchDisplayDriver Uninstaller.app”.
(3) Click “Uninstall”.
• If a screen prompting you to enter the name and password appears, enter the name and password of the administrator
and click “OK”.
3. Whentheuninstallnishedscreenappears,click“Quit”.
This completes the uninstallation.
11 E
Touch Action
Touch modes are nger/pen mode, pen-only mode, and nger-
only mode. The default setting is nger/pen mode.
TIPS
• To change the touch mode, see the manual for the LCD
MONITOR (PN-K322B/ PN-K322BH/LL-S201A).
• Select the action to be used in Function Setting. (See page
9.)
• You can not only move the cursor without tap operation.
Touch actions that can be used on this device vary depending
on the OS.
OS
Touch Action
OS X
v10.6
OS X
v10.7
OS X
v10.8
Tap Yes Yes Yes
Double-tap Yes Yes Yes
Drag-and-drop Yes Yes Yes
Click or tap with two ngers Yes *1Yes *1Yes *1
Scroll with two ngers Yes *1Yes Yes
Pinch with two ngers Yes *1Yes *1Yes *1
Rotate with two ngers Yes *1Yes *1Yes *1
Double-tap with two ngers No Yes *1Yes *1
Scroll left or right with two
ngers
No Yes *1, *2Yes *1, *2
Swipe with two or three ngers
Swipe with three ngers Yes *1
Swipe left from the right edge
with two ngers
No No Yes *1
Tap with three ngers No Yes *1Yes *1
Swipe left or right with three
ngers
No Yes *1, *2Yes *1, *2
Swipe left or right with four
ngers
Yes *1
Swipe up with three or four
ngers
No Yes *1, *2Yes *1, *2
Swipe down with three ngers No Yes *1, *2Yes *1, *2
Swipe down with four ngers Yes *1
Pinch with thumb and three
ngers
No Yes *1Yes *1
Spread with thumb and three
ngers *3 /
Swipe up with four ngers *4
Yes *1Yes *1Yes *1
*1 The device can be switched ON/OFF.
*2
Actions can be selected. (See “Function Setting” on page 9.)
*3 OS X v10.7/v10.8 only.
*4 OS X v10.6 only.
nCommon nger and pen actions
Tap
Same action as left-clicking a mouse.
Touch with your nger/pen.
Double-tap
Same action as double-clicking a mouse.
Quickly touch twice with your nger/pen.
Drag-and-drop
Same action as drag-and-drop with a mouse.
Touch the screen with your nger/pen and move without lifting.
When you have nished the movement, lift your nger/pen.
12
E
nFinger actions
TIPS
• The screen may not respond correctly in the following
cases:
Touching is too quick
The distance between the two points is too short
• Operation with the touch pen is not possible.
Clickortapwithtwongers
Same action as a secondary click.
Scrollwithtwongers
Use in screens that can be scrolled.
With your two ngers touching the screen, move in the
direction you want to scroll. The screen scrolls in the direction
of the movement.
The scroll direction can be changed.
Pinchwithtwongers
Use in a screen that is capable of reduction/enlargement.
Touch the screen with two ngers and move your ngers
closer together to reduce the view, or apart to enlarge the
view.
Reduction
Enlargement
Rotatewithtwongers
Use this action in a screen that is capable of image rotation.
Touch the screen with two ngers and rotate to rotate the
screen in that direction.
Rotate two ngers in the
same direction.
Double-tapwithtwongers
Use smart zoom.
Touch Action
13 E
Scrollleftorrightwithtwongers/Swipewithtwoor
threengers
Use cross page swipe.
Swipeleftfromtherightedgewithtwongers
Display the notice center.
Tapwiththreengers
Check the tapped text in a dictionary or other resource.
Swipeleftorrightwiththreeorfourngers
Move an application to the front.
Swipeupwiththreeorfourngers
Display Mission Control.
Swipedownwiththreeorfourngers
Display Application Exposé.
Pinchwiththumbandthreengers
Touch the screen with 4 ngers, and move your thumb and 3
ngers together to open Launchpad.
Touch Action
14
E
Spreadwiththumbandthreengers/Swipeupwithfour
ngers
Touch the screen with 4 ngers, and move your thumb and 3
ngers apart to show the desktop. (OS X v10.7/v10.8)
Swipe with 4 ngers to show the desktop. (OS X v10.6)
Touch Action
PN-K322BPN-K322BHLL-S201A DM EN13J(1)
This manual suits for next models
3
Table of contents
Other Sharp Touch Panel manuals
