Sharp XL-S15H User manual

MODEL
XL-S15H
MICRO COMPONENT SYSTEM
1 Accessories
2 Remote control battery installation
1Remove the battery cover.
2Insert the batteries as shown.
3Replace the cover.
Use 2 “AAA” size batteries (UM-4, R03, HP-16 or similar).
Batteries are not included.
FM/AM loop aerial 1Remote control 1
If you require any advice or assistance regarding
your Sharp product, please visit our web-site
www.sharp.co.uk/customersupport.
Customers without Internet access may telephone
08705 274277 during office hours (or [phone]
if telephoning from Ireland).
This Quick Start Guide will help you to correctly install and
operate your system.
3 System connections
4 Turn on your system
Press the ON/STAND-BY button to turn
the power on.
Wall socket
(AC 230 - 240V, 50 Hz) Right speaker Left speaker
Black
White line
Right speaker Left speaker
AM loop aerial
FM aerial
0101
TINSZA015SJZZ
04D N HK 1
Downloaded from: http://www.usersmanualguide.com/

Listening to a CD
1
2
3
4
5
Listening to the radio
1
2
FM stereo mode indicator
FM stereo receiving indicator
Press the FUNCTION button until “Cd dISC” appears on the dis-
play.
Press the CD EJECT button to open the CD compartment.
Place a CD on the spindle, label side up.
Close the CD compartment by firmly pushing the corner marked
“PUSH CLOSE”.
Press the button to start playback from track 1.
Press the FUNCTION button until “FM” or “AM” appears on the
display.
Press the TUNING ( or ) button to tune in to the desired sta-
tion.
When the TUNING button is pressed for more than 0.5 seconds, scan-
ning will start automatically and the tuner will stop at the first receivable
broadcast station.
To receive an FM stereo transmission:
Press the FUNCTION button to display the “ST” indicator.
“ ” will appear when an FM broadcast is in stereo.
Listening to a cassette tape
1
2
4
3
5
Clearing all the memory (reset)
Maintenance
If trouble occurs
A Erase head
B Recording/
Playback head
D Pinch roller
C Capstan
Press the FUNCTION button until “TAPE” appears on the display.
Press the button to open the cassette
compartment.
Load a cassette into the cassette compartment
with the side to be played facing toward you.
Close the cassette compartment.
Press the button to start playback.
When this product is subjected to strong external interference (mechani-
cal shock, excessive static electricity, abnormal supply voltage due to
lightning, etc.) or if it is operated incorrectly, it may malfunction.
If such a problem occurs, do the following:
1 Set the unit to the stand-by mode and turn the power on again.
2 If the unit is not restored in the previous operation, unplug and
plug in the unit, and then turn the power on.
Note:
If neither operation above restores the unit, clear all the memory by re-
setting it.
1 Press the ON/STAND-BY button to enter the power stand-by
mode.
2 Whilst pressing down the MEMORY/SET button and the CLEAR
button, press the ON/STAND-BY button until "CL" appears.
Caution:
This operation will erase all data stored in memory including clock, timer
settings, tuner preset, and CD programme.
Cleaning the tape-handling parts
•Dirty heads, capstan or pinch roller can cause poor sound and tape
jams. Clean these parts with a cotton swab moistened with commer-
cial head/pinch roller cleaner or isopropyl alcohol.
•When cleaning the heads, pinch roller, etc., unplug the unit which con-
tains high voltages.
• After long use, the deck's heads and capstan may become magne-
tised, causing poor sound. Demagnetise these parts once every 30
hours of playing/recording time by using a commercial tape head de-
magnetiser. Read the demagnetiser's instructions carefully before use.
Cleaning the CD pickup lens
Do not touch the laser pickup lens. If finger-
prints or dust accumulate on the pickup,
clean it gently with a dry cotton swab.
D
ABC
TINSZA015SJZZ
